USER MANUAL
V 1.1
MODEL
IBF95W
BAR FRIDGE
95L

—
2
Congratulations on purchasing your new bar freezer. The InAlto brand
is proudly distributed within Australia by esidentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual for
information regarding your product’s parts and labour warranty, or visit
us online at www.residentia.group
At esidentia Group, we are customer obsessed and our Support
Team are there to ensure you get the most out of your appliance.
Should you want to learn more about recommended temperatures,
the various features of your bar freezer, and importantly taking care
of your appliance when cleaning, our Support Team are here to help.
You can use our online Support Centre at anytime by visiting
http://support.residentiagroup.com.au, or you can contact us via
calling us on 1300 11 HELP (4357).
It is important that you read through the following use and care manual
thoroughly to familiarise yourself with the installation and operation
requirements of your appliance to ensure optimum performance.
Again, thank you for choosing an InAlto appliance and we look forward
to being of service to you.
Kind Regards,
The esidentia Team
Residentia Group
—
Head Office.
165 Barkly Avenue
Burnley, Victoria
Australia 3121
—
ACN.
600 546 656
—
Online.
residentia.group
WELCOME

—
3
CONTENTS
2Welcome
4Safety Instructions
5Your Bar Fridge
5Installation Instructions
7Operating your Unit
8Cleaning & Maintenance
10 Troubleshooting
12 Warranty

—
4
Safety Instructions
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance.
• This appliance is intended to be used in
household and similar applications such as
sta kitchen areas in shops, oces and other
working environments; farm houses and by
clients in hotels, motels and other residential
type environments; bed and breakfast type
environments; catering and similar non-retail
applications.
UNPACKING
• During transportation, protective packaging
was used to protect the appliance against any
damage. After unpacking, please dispose of
all elements of packaging in a way that will
not cause damage to the environment. All
materials used for packaging the appliance
are environmentally friendly; they are 100%
recyclable and are marked with the appropriate
symbol.
Caution! During unpacking, the packaging
materials (polythene bags, polystyrene pieces,
etc.) should be kept out of reach of children.
DISPOSAL OF THE APPLIANCE
• Old appliances should not simply be disposed
of with normal household waste, but should be
delivered to a collection and recycling centre
for electric and electronic equipment. A symbol
shown on the product, the instruction manual
or the packaging shows that it is suitable for
recycling.
• Materials used inside the appliance are
recyclable and are labelled with information
concerning this. By recycling materials or other
parts from used devices you are making a
significant contribution to the protection of our
environment.
• Information on appropriate disposal centres
for used devices can be provided by your local
authority.
R600a ISO-BUTANT REFRIGERANT
• Hydrocarbon refrigerants have excellent
refrigerant properties and minimal low global
warming potential and no ozone depletion
potential.
• This appliance contains a small quantity of
flammable, nonsynthetic R600a refrigerant:
• Hydrocarbon refrigerants cannot be
‘retrofitted’ to the appliance that has not been
designed and approved to use that type of
refrigerant.
• Ensure that the tubing of the refrigerant
circuit is not damaged during transportation
and installation.
• Leaking refrigerant may cause eye injuries or
could ignite.
• The room for installing the appliance must be
at least 1m3 per 8g of refrigerant. The amount
of refrigerant in the appliance can be found on
the rating plate attached to the appliance.
RISK OF FIRE
• If the refrigerant circuit should become
damaged. Avoid open flames and sources of
ignition. Disconnect the appliance from the
mains power. Thoroughly ventilate the room
in which the appliance is situated for several
minutes.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
Caution! If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.

—
5
Your Bar Fridge
KEY
1 Small door
2 Drain tray
3 Steel wire shelf
4 Adjustable foot
5 Thermostat
6 Wire steel bar
Installation Instructions
BEFORE USING YOUR BAR FRIDGE
• Remove the exterior and interior packing.
• Keep away from heat and avoid direct
sunlight.
• Do not place the fridge in moist or watery
places to prevent rust or reduction of
insulating effect.
• Before connecting the bar fridge to the
power source, let it stand upright for
approximately 1 hour. This will reduce
the possibility of a malfunction in the
cooling system from handling during
transportation.
• Clean the interior surface with lukewarm
water using a soft cloth.
INSTALLATION LOCATION:
• When selecting a position for your
bar fridge you should make sure that
the floor is level, and that the room is
well ventilated with an average room
temperature of between 16° and 35°.
• Always avoid locating your bar fridge near
a heat source, such as a heater.
• Also avoid direct sunlight as it may
increase the electrical consumption.
• Extreme cold ambient temperatures
may also cause the unit not to perform
properly. This unit is not designed for use in
a garage or outdoor installation.
• Do not drape the unit with any covering.
• When installing the unit, ensure that 10cm
of free space is left at both sides, 10cm at
the rear and 30cm at the top of the unit.
This will allow cold air to circulate around
the unit and improve the efficiency of the
cooling process.
• The door can be hinged to open to the
right or to the left, depending on what
better suits the location.
• Please ensure there is adequate space for
the door to fully open.
• Adjust the two levelling feet to ensure that
the bar fridge is horizontally and vertically
level.
Page:
5
User Manual:
Your Esatto Bar Fridge
Installation Instructions
BEFORE USING YOUR BAR FRIDGE
→ Remove the exterior and interior packing.
→ Keep away from heat and avoid direct sunlight.
→ Do not place the fridge in moist or watery places to prevent rust or reduction
of insulating eect.
→ Before connecting the bar fridge to the power source, let it stand upright for
approximately 1 hour. This will reduce the possibility of a malfunction in the cooling
system from handling during transportation.
→ Clean the interior surface with lukewarm water using a soft cloth.
INSTALLATION LOCATION:
→ When selecting a position for your bar fridge you should make sure that the oor is level,
and that the room is well ventilated with an average room temperature of between 16°
and 35°.
→ Always avoid locating your bar fridge near a heat source, such as a heater.
→ Also avoid direct sunlight as it may increase the electrical consumption.
→ Extreme cold ambient temperatures may also cause the unit not to perform properly. This
unit is not designed for use in a garage or outdoor installation.
→ Do not drape the unit with any covering.
→ When installing the unit, ensure that 10cm of free space is left at both sides, 10cm at the
rear and 30cm at the top of the unit. This will allow cold air to circulate around the wine
cooler and improve the eciency of the cooling process.
→ The door can be hinged to open to the right or to the left, depending on what better suits
the location.
→ Please ensure there is adequate space for the door to fully open.
→ Adjust the two levelling feet to ensure that the bar fridge is horizontally and vertically level.
1 Small door
2 Drain tray
3 Steel wire shelf
4 Adjustable foot
5 Thermostat
6 Wire steel bar

—
6
INSTALLTION INSTRUCTIONS CONT.
REVERSING THE DOOR SWING
Tools Required: Phillips head screwdriver.
• Start by ensuring the bar fridge is
unplugged and empty.
• Adjust the two levelling feet to their
highest position.
• To remove the door it is necessary to tilt
the bar fridge backwards. Rest the fridge
against something solid to prevent it from
slipping whilst removing the door.
• All parts that are removed will be used
when re-assembling the door hinge, so
ensure they are all kept safe .
• DO NOT lay the bar fridge on its back or
sides as this may damage the coolant
system.
• We recommend that this is a two person
procedure.
1Remove the plastic cover from the top
door hinge.
2 Unscrew the three screws from the
bottom bracket and remove the hinge
bracket from the opposite side. Place this
to one side.
3Slide the fridge door down approximately
15cm and remove from the top hinge,
lifting the door away from the fridge.
4Remove the two screws from the top
bracket and replace the bracket using
the same screws on to the opposite side.
Note: You will need to remove the plastic
cover caps from the opposite side first.
5Slide the fridge door back onto the top
hinge, ensuring that it is the correct way
up. Then screw the bottom hinge bracket
into place, securing the door in place.
6Fit the plastic cover caps and ensure that
the door is aligned both vertically and
horizontally, before tightening the bottom
hinge. Re-adjust the levelling feet.
Page:
6
User Manual:
REVERSING THE DOOR SWING
Tools Required: Phillips head screwdriver.
→ Start by ensuring the bar fridge is unplugged and empty.
→ Adjust the two levelling feet to their highest position.
→ To remove the door it is necessary to tilt the bar fridge backwards. Rest the fridge against
something solid to prevent it from slipping whilst removing the door.
→ All parts that are removed will be used when re-assembling the door hinge, so ensure
they are all kept safe .
→ DO NOT lay the bar fridge on its back or sides as this may damage the coolant system.
→ We recommend that this is a two person procedure.
1. Remove the plastic cover from the top door hinge.
2. Unscrew the three screws from the bottom bracket and remove the hinge bracket from
the opposite side. Place this to one side.
3. Slide the fridge door down approximately 15cm and remove from the top hinge, lifting
the door away from the fridge.
4. Remove the two screws from the top bracket and replace the bracket using the same
screws on to the opposite side. Note: You will need to remove the plastic cover caps from
the opposite side rst.
5. Slide the fridge door back onto the top hinge, ensuring that it is the correct way up.
Then screw the bottom hinge bracket into place, securing the door in place.
6. Fit the plastic cover caps and ensure that the door is aligned both vertically and
horizontally, before tightening the bottom hinge. Re-adjust the levelling feet.
1 3
4 5 5
2

—
7
Operating your Unit
TEMPERATURE CONTROL
• Your bar fridge has one control for
regulating the temperature. The
temperature control is located on the
right hand side wall of the interior.
→ Setting “Off” Unit Off
→ Setting “Min” Less Cool Temperature
→ Setting “Med” Normal Operation
(adequate for most situations)
→ Setting “Max” Coolest Temperature
• Depending on your room’s ambient
temperature, you may need to adjust
the temperature setting to achieve your
desired temperature.
• The number on the thermostat dial
does not directly represent the
temperature. Instead, the larger the
number is, the lower the fridge interior
temperature will be. Dial position 1-2 will
set your fridge to approximately -12°C,
3-4 will set your fridge to approximately
-15°C, and dial position 5-6 will set it to
approximately -20°C.
Note: If the unit is unplugged, lost power,
or turned off; you must wait 3 to 5 minutes
before restarting the unit.
• If you choose to change the thermostat
setting, adjust thermostat control by one
numerical increment at a time. Allow
several hours for temperature to stabilize
between adjustments.
NOISE FROM YOUR BAR FRIDGE
• You may notice that your bar fridge makes
some unusual noises from time to time.
Most of these are perfectly normal, but
you should be aware of them!
• These noises are caused by the circulation
of the refrigerant liquid in the cooling
system.
→ This is not a fault and will not affect the
performance of your unit and is common
with all modern fridges.
DEFROSTING YOUR BAR FRIDGE
• Defrost the freezing compartment
whenever the layer of frost on the surface
of the evaporator reaches 3 or 4 mm.
Important! Do not use boiling water because
it may damage the plastic parts. In addition,
never use a sharp or metallic instrument
to remove frost as it may damage the
cooling coils and will void the warranty. We
recommend using a plastic scraper.
• When defrosting, remove all food and set
the thermostat at the “OFF” position.
• Put the drip tray under the evaporator to
collect melted water.
• After the frost has melted, discard the
melted water and dry up the interior of
refrigerator.
• The refrigerator can now be restarted
by turning its thermostat to the desired
setting.
Helpful Tip! Defrosting usually takes a few
hours. Leaving the door open will help speed
the process. Also, pouring warm water (not
boiling) on the ice/frost will help speed
melting. If you must use a scraper- please
use caution—it is very easy to damage the
fridge compartment and void your warranty.

—
8
Cleaning & Maintenance
By ensuring proper cleaning and
maintenance of your Bar Fridge, you can
ensure that it will have a long and fault free
operation.
CLEANING YOUR BAR FRIDGE
• Warning! To avoid an electric shock,
always unplug your bar fridge before
cleaning.
Ignoring this warning may result in death or
serious injury.
Caution. Before using any cleaning products,
please read and follow the manufacturer’s
instructions and warnings to avoid any
damage to your
Bar Fridge or personal injury.
• Upon installation of your new appliance,
it is recommended that it be cleaned
thoroughly.
• Dust behind the refrigerator and on the
ground should be cleaned regularly to
improve the cooling effect and energy
saving.
• The interior of the refrigerator should be
cleaned regularly to avoid odor.
• Soft towels or sponge dipped in water
and non-corrosive neutral detergents are
suggested for cleaning.
• The freezer should be cleaned with clean
water and a dry cloth. Open the door for
natural drying before the power is turned
on.
POWER FAILURE
• Foods can be preserved for a couple of
hours even in summer in case of power
failure; it is recommended to reduce the
frequency of opening door and do not put
fresh foods into the freezer.
VACATION TIME
• Remove all the food.
• Unplug the bar fridge.
• Clean the bar fridge using the instructions
above.
• Leave the door open slightly to avoid
possible formation of condensation,
mould, or odours.
• Use extreme caution in the case of
children. The unit should not be accessible
to children.
• Short vacations: Leave the bar fridge
operating during vacations of less than
three weeks.
• Long vacations: If the bar fridge will not be
used for several months, remove all food
and unplug the power cord. Clean and dry
the interior thoroughly. To prevent odour
and mould growth, leave the door open
slightly blocking it open if necessary or
have the door removed.
MOVING YOUR BAR FRIDGE
• Remove all the food.
• Securely tape down all loose items inside
your fridge.
• Remove the rollers to prevent damage.
• Tape the doors shut.
• Be sure the fridge stays in the upright
position during transportation. Do not turn
upside, horizontally place or vibrate the
refrigerator, the carrying angle can not be
greater than 45º.
Note. Continuous operation is recommended
when the refrigerator is started.
Please do not move the refrigerator under
normal circumstances so as not to affect the
refrigerator's service life.

—
9
CLEANING & MAINTENANCE CONT.
ENERGY SAVING TIPS
• The bar fridge should be located in the
coolest area of the room, away from heat
producing appliances or heating ducts,
and out of the direct sunlight.
• Let hot foods cool to room temperature
before placing in the bar fridge.
Overloading the fridge forces the
compressor to run longer.
• Be sure to wrap foods properly, and wipe
containers dry before placing them in the
bar fridge. This cuts down on frost build-
up inside the fridge/fridge.
• Liners interfere with cold air circulation,
making the fridge less efficient.
• Organize and label food to reduce door
openings and extended searches. Remove
as many items as needed at one time, and
close the door as soon as possible.
SERVICING
• Your bar fridge should only be serviced
by an authorised service agent of the
Residentia Group.
• Under no circumstances should you
attempt to repair or alter the appliance
yourself. Repairs carried out by
inexperienced persons may cause personal
injury or serious malfunction.
OPERATION IN CASE OF EMERGENCY
In the event of an emergency you should:
• Switch off the bar fridge at the thermostat
and then unplug the fridge at the power
outlet.
• Call the Residentia Support Team on:
1300 11 HELP (4357).
• Some minor faults can be fixed by
referring to the instructions given in the
Troubleshooting section below.

—
10
Page:
10
User Manual:
Troubleshooting
The following simple issues can be handled by the user.
Please call the after-sale service department if the issues are not settled.
Fault
Possible Cause Solution
The Bar Fridge doesn’t operate.
Not plugged in. Plug the Bar Fridge in.
The circuit breaker has tripped,
or a fuse blown.
Replace any blown fuses or reset tripped circuit
breakers.
The fridge temperature is set at “OFF”. Increase the fridge temperature setting.
The compressor turns on
and o frequently.
The room temperature is hotter than normal. Try to bring the room temperature down.
A large amount of food has been added to the
fridge.
Give the Bar Fridge time to return back to your
desired temperature setting.
The door is left open too often. Try to minimise the door being opened for
sometime.
The door is not closed completely. Close the door completely and ensure a
complete seal.
The temperature control is not set properly.
Change the temperature control to your desired
setting.
The door gasket doesn’t seal properly. Try cleaning the door gasket seals with warm
soapy water. If this still doesn’t improve the seal,
you may need replacement gasket seals from
either a refrigeration specialist or Residentia
Group.
The fridge doesn’t have the correct clearances. Ensure your Bar Fridge has been installed
in an appropriate space and has the correct
clearances (as per this instruction manual).
There has been a recent power outage. Give the fridge a few hours to return to the
desired temperature setting.
The temperature inside the
Bar Fridge is too warm.
The temperature control is set too warm. Turn the temperature control down to a cooler
setting and leave for several hours for the
temperature to stabilise.
The door is kept open too long is opened too
frequently.
Try to minimise the door being opened for
sometime.
The door gasket doesn’t seal properly. Try cleaning the door gasket seals with warm
soapy water. If this still doesn’t improve the seal,
you may need replacement gasket seals from
either a refrigeration specialist or Residentia
Group.
The bar fridge doesn’t have the correct
clearances.
Ensure your Bar Fridge has been installed
in an appropriate space and has the correct
clearances (as per this instruction manual).
There has been a recent power outage. Give the fridge a few hours to return to the
desired temperature setting.
The temperature inside
the Bar Fridge is too cold.
The temperature control is set too cold. Turn the temperature control to a warmer
setting and allow several hours for the
temperature to stabilise.
There is a popping or cracking
sound when the compressor
comes on.
Metal parts undergo expansion and contraction,
as in hot water pipes.
This is normal and the sound will level o or
disappear as the fridge continues to run.
There is a bubbling or gurgling
sound like water boiling.
The refrigerant (used to cool the fridge) is
circulating throughout the system.
This is normal.
Odor
Odorous foods are not sealed.
Foods have become rotten.
The interior is dirty.
Odorous foods should be closely wrapped.
Rotten foods should be thrown out.
Ensure the interior is clean.
Troubleshooting
The following simple issues can be handled by the user.
Please call the after-sale service department if the issues are not settled.

—
11
This page
is intentionally
left blank

—
12
WARRANTY TERMS & CONDITIONS
REFRIGERATION APPLIANCES
This document sets out the terms and conditions of the
product warranties for Residentia Group Appliances. It is
an important document. Please keep it with your proof of
purchase documents in a safe place for future reference
should you require service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause 10 of this
warranty has the same meaning referred to in the ACL;
(b) ‘ACL’ means Trade Practices Amendment (Australian
Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group product
purchased by you accompanied by this document;
(d) ‘ASR’ means Residentia Group authorised service
representative;
(e) ‘Residentia Group’ means Residentia Group Pty Ltd
of 165 Barkly Ave, Burnley VIC 3121, ACN 600 546 656
in respect of Appliances purchased in Australia;
(f ) ‘major failure’ as referred to in clause 10 of this
warranty has the same meaning referred to in the ACL
and includes a situation when an Appliance cannot
be repaired or it is uneconomic for Residentia Group,
at its discretion, to repair an Appliance during the
Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal,
domestic or household use (i.e. normal
single family use) as set out in the instruction
manual, the Appliance is warranted against
manufacturing defects for 24 months, following
the date of original purchase of the Appliance;
(h) ‘you’ means the purchaser of the Appliance not having
purchased the Appliance for re-sale, and ‘your’ has a
corresponding meaning.
2. This warranty only applies to Appliances purchased
and used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia.
3. During the Warranty Period Residentia Group or its
ASR will, at no extra charge if your Appliance is readily
accessible for service, without special equipment and
subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Residentia
Group or its ASR may use remanufactured parts to
repair your Appliance. You agree that any replaced
Appliances or parts become the property of Residentia
Group. This warranty does not apply to light globes,
batteries, lters or similar perishable parts.
4. Parts and Appliances not supplied by Residentia Group
are not covered by this warranty.
Warranty Information

—
13
5. You will bear the cost of transportation, travel and
delivery of the Appliance to and from Residentia Group
or its ASR. If you reside outside of the service area,
you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance to and
from Residentia Group or its ASR, in all instances,
unless the Appliance is transported by Residentia
Group or its ASR, the Appliance is transported at
the owner’s cost and risk while in transit to and from
Residentia Group or its ASR.
6. Proof of purchase is required before you can make
a claim under this warranty.
7. You may not make a claim under this warranty unless
the defect claimed is due to faulty or defective parts
or workmanship. Residentia Group is not liable in the
following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly
maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or
incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions
supplied with the Appliance;
(b) the Appliance is modied without authority from
Residentia Group in writing;
(c) the Appliance’s serial number or warranty seal has
been removed or defaced;
(d) the Appliance was serviced or repaired by anyone
other than Residentia Group, an authorised repairer
or ASR.
8. This warranty, the contract to which it relates and the
relationship between you and Residentia Group are
governed by the law applicable where the Appliance
was purchased.
9. To the extent permitted by law, Residentia Group
excludes all warranties and liabilities (other than as
contained in this document) including liability for any
loss or damage whether direct or indirect arising from
your purchase, use or non use of the Appliance.
10. For Appliances and services provided by Residentia
Group in Australia, the Appliances come with a
guarantee by Residentia Group that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled
to have the Appliance repaired or replaced if the
Appliance fails to be of acceptable quality and the
failure does not amount to a major failure. The benets
to you given by this warranty are in addition to your
other rights and remedies under a law in relation to the
Appliances or services to which the warranty relates.
11. At all times during the Warranty Period, Residentia
Group shall, at its discretion, determine whether repair,
replacement or refund will apply if an Appliance has a
valid warranty claim applicable to it.
12. To enquire about claiming under this warranty, please
follow these steps:
(a) carefully check the operating instructions, user manual
and the terms of this warranty;
(b) have the model and serial number of the Appliance
available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
13. You accept that if you make a warranty claim,
Residentia Group and its ASR may exchange
information in relation to you to enable Residentia
Group to meet its obligations under this warranty.
IMPORTANT
Before calling for service, please ensure that the steps
in point 12 have been followed.
→ Service: Please call 1300 11 HELP (4357)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
The Australian Consumer Law requires the
inclusion of the following statement with
this warranty:

TEL. [phone]
[e-mail]
WWW.RESIDENTIA.GROUP
AN INITIATIVE BY RESIDENTIA GROUP
