Residentia Esatto E4DF474X User manual

User Mnul
Exctly wht
you need
Model Code/s:
E4DF474X
Online:
esatto.house
Product:
474L French Door
Refrigertor
Version:
V1.0 0821

User Manual
2
Applinces
Exctly wht
you need

esatto.house
3
Page 4
Welcome
Page 5
Safety Warnings
Page 8
Product Overview
Page 9
Getting Started
Page 9
Installation
Page 12
Operation
Instructions
Page 14
Maintenance
and Cleaning
Page 15
Energy
Saving Tips
Page 16
FAQs and
Troubleshooting
Page 19
Specications
Page 20
Your Receipt
Page 21
Purchase Details
Page 22
Warranty
Information
Contents

User Manual
4
Welcome
Congratulations on purchasing your new fridge. The Esatto brand is proudly distributed
within Australia by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual for information regarding your
product’s parts and labour warranty, or visit us online at: www.residentiagroup.com.au
At Residentia Group, we are customer obsessed and our Support Team are there to
ensure you get the most out of your appliance. Should you want to learn more about your
unit such as the various temperature guides or importantly taking care of the appliance,
our Support Team are here to help.
You can use our online Support Centre at any time by visiting:
→ http://support.residentiagroup.com.au
Or you can contact us via phone by dialling: 1300 11 HELP (4357).
It is important that you read through the following use and care manual thoroughly to
familiarise yourself with the installation and operation requirements of your appliance
to ensure optimum performance.
Again, thank you for choosing Esatto and we look forward to being of service to you.
Kind Regards,
The Residentia Team
Residentia Group
—
Head Office
165 Barkly Avenue
Burnley Victoria
Australia 3121
—
ACN
600 546 656
—
Online
residentia.group
www.esatto.house
@esatto.house
—
Postage
PO Box 5177
Burnley, Victoria
Australia 3121
—
Telephone
1300 11 4357
—
Email
suppor[email protected]

esatto.house
5
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before rst use, even if you are familiar with this type of product. The safety
precautions enclosed herein reduce the risk of re, electric shock and injury when correctly adhered to.
Make sure you understand all instructions and warnings.
Keep the manual in a safe place for future reference, along with the completed warranty card and purchase
receipt. If you sell or transfer ownership of this product, pass on these instructions to the new owner.
Always follow basic safety precautions and accident prevention measures when using an electrical
appliance, including the following:
IMPORTANT: Pay particular attention to messages that contain the words DANGER, WARNING or
CAUTION. These words are used to alert you to a potential hazard that can seriously injure you and others.
The instructions will tell you how to reduce the chance of injury and let you know what can happen if the
instructions are not followed.
CAUTION
RISK OF FIRE / FLAMMABLE MATERIALS
This symbol alerts you to take care as this appliance contains a ammable
refrigerant (isobutane) and insulation blowing gas (cyclopentane). Do not
expose it to high heat, sparks and open ames.
The refrigerant isobutane (R600a) is contained within the refrigerant circuit
of the appliance, a gas with a high level of environmental compatibility,
which is nevertheless ammable. During transportation and installation of
the appliance, ensure that none of the components of the refrigerant circuit
become damaged.
WARNING: Do not damage the refrigerant circuit! Never use an appliance with a damaged refrigerant
circuit! If the refrigerant circuit becomes damaged, avoid proximity to open res and all types of heat and
ignition sources. Thoroughly ventilate the room in which the appliance is located.
DANGER: It is hazardous for anyone other than an authorised service person to service this appliance.
In Queensland, the authorised service person MUST hold a Gas Work Authorisation for hydrocarbon
refrigerants to carry out servicing or repairs which involve the removal of covers.
The room for installing the appliance must be at least 1m³ per 8g of refrigerant. The amount and type of
refrigerant in the appliance can be found in the Specications on Page 19 and on the rating plate, found on
the appliance.
Usage Conditions and Restrictions
• Domestic use only: This appliance is intended for indoor household use only. It is not intended for
commercial, industrial or outdoor use. It is not intended for use in a recreational vehicle.
• Purpose: Do not use this appliance for anything other than its intended purpose. Other uses are not
recommended and may cause re, electric shock or personal injury.
• Attachments: The use of attachments is not recommended by the appliance manufacturer and distributor
as they may be hazardous.
• Improper use: Damage due to improper use, or repairs made by unqualied personnel will void
your warranty. We assume no liability for any eventual damages caused by misuse of the product or
noncompliance with these instructions.
Sfety Wrnings

User Manual
6
General Safety Instructions
• WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
• Usage restriction: This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instructions concerning use of the appliance by a person responsible for their safety.
• Children: Supervise young children to ensure they do not play with the appliance. Never allow children to
operate, play with or crawl inside the appliance.
• WARNING: Do not use electrical appliances inside the appliance, unless they are of the type
recommended by the manufacturer.
• Explosive or ammable substances: Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance. Do not store or use petrol or any other ammable vapours and
liquids in the vicinity of this or any other appliance. Do not use such substances for cleaning the appliance.
The fumes can create a re hazard or an explosion.
• Damage: Do not use the appliance if the power cord, plug or the appliance itself is damaged. If the cord is
damaged, contact the after sales support line and have the cord replaced by qualied personnel in order
to avoid a hazard.
• WARNING: Do not damage the refrigerant circuit.
• Do not modify: Do not attempt to alter or modify this appliance in any way.
• Repair: Do not attempt to repair or replace any part of this appliance unless it is specically
recommended in this manual. All other servicing should be referred to a qualied technician. Contact the
after sales support line for advice.
• WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the
appliance
Electrical Safety
• Voltage: Before connecting and turning on the appliance, ensure the electrical voltage and circuit
frequency correspond to that indicated on the appliance rating label.
• Earthing: This appliance should be properly earthed for your safety. The power cord of this appliance is
equipped with a three-prong plug for use in standard wall outlets to minimise the possibility of electrical
shock. Do not modify the cord and/or plug provided with the appliance. Improper use of the earthed plug
can result in the risk of electric shock.
• Connection: This appliance requires a standard 220-240 V AC 50Hz electrical outlet. Do not overload the
electrical circuit.
• Power cord: Do not kink or damage the power cord; do not leave it exposed or dangling. Secure it at the
back of the appliance so no one steps on or places anything on the cord or against it. Keep the cord out of
reach of children. When moving the appliance, make sure not to damage the power cord.
• WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
• Auxiliary Items: Do not use an inverter, adaptor or extension cord with this appliance. If the cord is too
short, have a qualied electrician install an outlet near the appliance. Use of an extension cord and an
inverter can negatively aect the performance of the unit.
• Protect from moisture: To protect against the risk of electric shock, do not immerse the unit, cord or plug
in water or spray it with any other liquid. Do not connect or disconnect the electric plug when your hands
are wet. Turn the power switch o before removing the plug from the socket.
• WARNING: Disconnect! To reduce the risk of re, electric shock or personal injury, always unplug the
appliance from the socket when not in use, when moving and before cleaning or servicing. Never unplug
the unit by pulling the power cord. Always grip the plug rmly and pull straight out from the power point.
• Electrical work: Any electrical work required for the installation or maintenance of this appliance should
be carried out by a qualied electrician.
Never use this appliance with a damaged refrigerant circuit! If the coolant circuit becomes damaged, avoid
proximity to open res and all types of heat sources. The room in which the appliance is located should be
ventilated for a few minutes.
Sfety Wrnings (Continued)

esatto.house
7
General Safety Instructions Cont.
Installation
Heavy: This appliance is heavy, take care when moving it. To avoid back or other injury, consider a two
person lift or mechanical aid when installing it. Failure to do so can result in back or other injury.
Damage: When unpacking, check the appliance carefully for damage. If it is damaged, do not install the
appliance. Contact our after sales support centre on 1300 43 57 for advice on examination or return of the
damaged appliance.
Protect from moisture: Install the appliance in an indoor area protected from wind, rain, water spray or drips.
Protect from heat: Do not install the appliance next to an oven, grill or other source of high heat, or where it
will be exposed to direct sunlight for prolonged periods of time.
WARNING: Ventilation: To ensure proper ventilation, keep any ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstructions. Ensure adequate air circulation around the
appliance to prevent overheating.
Level: Install the appliance level in order to ensure proper operation.
Cleaning and Maintenance
Disconnect: Unplug the appliance before cleaning or servicing. Failure to do so can result in electric shock,
injury or death. Do not connect or disconnect the plug when your hands are wet.
Flames: Do not let open ames or ignition sources enter the appliance.
Flammable/explosive substances: Never clean this appliance with ammable uids. Do not store or use
volatile, ammable or explosive propellants or liquids in or close to this or any other appliance. The fumes
can create a re hazard or explosion.
Solvents: Do not use solvent based cleaning agents or abrasives on the interior as these may damage or
discolour the surfaces of the appliances.
WARNING! Do not use mechanical devices or other means to accelerate the defrosting process. Never use a
sharp or metal instrument to remove frost or clean the appliance. Use a plastic scraper, if necessary.
Service: Do not attempt to repair, modify or replace any part of the appliance unless specically
recommended in this manual. Refer all other servicing to a qualied technician, or contact the after sales
support line for advice on examination or repair of the appliance.
Responsible disposal
At the end of its working life, do not throw this appliance out with your household rubbish. Electrical and
electronic products contain substances that can have a detrimental eect on the environment and human
health if disposed of inappropriately. Observe any local regulations regarding the disposal of electrical
consumer goods and dispose of it appropriately for recycling and recovery of the refrigerant and blowing
agent. Contact your municipal authorities for advice on recycling facilities in your area. When the appliance
is scrapped, disassemble the door and take out the shelves to prevent climbing or entrapment
of any children.
WARNING! This refrigeration appliance contains ammable refrigerants and insulation blowing gases,
which must be removed before disposal. Contact your municipal authorities for any codes or regulations
concerning the disposal of such materials.
Disposal
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environmental
safe recycling. For more detailed information about treatment, recovery and recycling of this
product, please contact your local city oce, your household waste disposal service or the
shop where you purchased the product.

User Manual
8
Product Overview
Your French Door Refrigerator
Variable Zone
Lower Drawer
Refrigerator Compartment
This compartment helps keep for food for short-term storage and is suitable for storing a variety of fruits,
vegetables, beverages and other food items ideally between 3 to 5 days.
Freezer Compartment
This low temperature helps keep food for long-term storage and is suitable for storing frozen food and
making ice.
Storage tips:
• Wait until hot food has cooled to room temperature before placing into the refrigerator.
• For food safety, we recommend sealing up any food before placing into the refrigerator.
• For quicker freezing and easy access, divide your meat and large items into smaller pieces before placing
into the freezer compartment.
• The glass shelves can be repositioned up or down to suit your storage requirements.
Note:
• The diagrams in this user manual are for reference only. Your appliance may appear dierently.
• The positioning of the drawers, food boxes and shelving in the diagram above are the most optimal
energy ecient.
• Storage of too many items during operation after the initial connection of your appliance to power may
adversely aect the freezing eect of the refrigerator.
• Do not block the air outlet or the freezing eect of the refrigerator will also be adversely aected.
Middle Drawer
Upper Drawer
Door storage
ECO-LED lighting
Glass shelves
Fruit/ Vegetable
Crisper

esatto.house
9
Getting Strted
Instlltion
Unpacking Your Fridge
• Packaging materials: This appliance has been packaged to protect it against transportation damage.
Remove all packaging materials, bottom cushions, foam pads and tapes from around and inside the
appliance, tear o the protective lm on the doors and refrigerator. Keep the original packaging carton
and materials in a safe place. It will help prevent any damage if the product needs to be transported in
the future, and you can use it to store the appliance when it is not in use. In the event the carton is to be
disposed of, please recycle all packaging materials where possible.
• Suocation: Plastic wrapping can be a suocation hazard for babies and young children, so ensure all
packaging materials are out of their reach and disposed of safely.
• Power cord: Unwind the power cord to its full length and inspect it for damage. Do not use the appliance
if it or its cord have been damaged or are not working properly. In case of damage, contact our after sales
support line for advice on examination, repair or return of the damaged product.
• Read the manual: Read this manual to familiarise yourself with the appliance. Pay particular attention to
the safety instructions on the previous pages.
• Clean: To remove any dust from transit and storage, clean the interior and exterior surfaces of the
appliance with lukewarm water and a soft cloth. Dry thoroughly. Important: do not use harsh or abrasive
detergents or powders as these will damage the nish.
• Two person installation: Use two or more people to move and install the appliance.
Failure to do so can result in back or other injury.
• Freestanding design: This appliance is designed to be freestanding only, and should not be
recessed or built-in.
• Floor surface: This appliance must be properly positioned on a dry, sturdy, level surface that is strong
enough to support it when it is fully loaded.
• Clearances: Ensure that air can circulate freely around the back of the cabinet, which is necessary to cool
the compressor and condenser. Allow at least 10cm clear space at the back, 10cm at the sides of the unit
and 30cm between the top and any surface above (i.e. a bench top). If you are installing your refrigerator
next to a xed wall, leave sucient space on the hinge side to allow for the door to swing open.
DO NOT install/use the appliance in the following locations/situations:
• In moist areas or areas of high humidity.
• In a recreational vehicle, or for use with an inverter.
• In direct sunlight, near heat sources, next to an open ame, cooking or heating appliance, or near any
other source of high heat.
• Direct sunlight may aect the acrylic coating and heat sources may increase the unit’s power
consumption. For best energy eciency install the appliance in the coolest area of the room.
• In an area with extreme cold ambient temperatures.
• In an area with excessive moisture and high humidity. Make sure it is protected from elements such as
wind, rain, water spray or drips.
• In an area where petrol or other explosive and/or ammable liquids or fumes are used or stored.
The fumes can create a re hazard or explosion.

User Manual
10
Installation Cont.
Electrical connection
• WARNING! It must be possible to disconnect the appliance from the mains power supply; the plug must
therefore be easily accessible after installation.
• Before plugging in your new fridge, let it stand upright for at least 2 hours. This will allow the refrigerant
gases to settle into the compressor and reduce the possibility of a malfunction in the cooling system.
• The appliance must be earthed. The plug of the power supply cord is equipped with a contact for this
purpose. Do not under any circumstances cut or remove the third (earth) prong from the power cord.
If the plug does not t your outlet, consult a licensed electrician for advice to have the outlet changed.
• Plug the unit into a dedicated, properly earthed wall outlet. Ensure that your outlet voltage and circuit
frequency correspond to the voltage stated on the rating label.
• Secure the fridge’s supply cord behind the unit. Do not leave it exposed or dangling to prevent injury and
accidental disconnection from the power supply.
• Adjust the temperature control as described in the Operation Instructions.
• When rst starting up, and after a period out of use, allow the unit to cool down for at least 2–3 hours
(4 hours if starting up during warm weather in summer) before placing food in the fridge.
Levelling the Fridge
Precautions before levelling the fridge:
• Ensure that the fridge is disconnected from the power source
• Make precautions to prevent any personal injury.
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust both feet so the refrigerator is level.
Instlltion (Continued)
Raise
Lower
