RFI APM1317 User manual

User’s Manual
Advanced Power
Monitor
APM1317 APM3852
APM7487 APM8796
Base Line 2.86
Australian Standard Patent No. 2011218778
Australian Patent Application No. 2016250327
U.S. Patent No. 8,983,415
U.S. Patent Application No. 15/343,133

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 2
Company Overview
RFI has been serving the needs of the wireless communications market for over 35 years. First founded as a manufacturer of
antenna systems, RFI has grown to be a key player in the development, manufacturing and distribution of wireless technology
and energy products. Through our extensive network of resellers, systems integrators and retail outlets, RFI is a key supplier to
both industry and Government.
Our research and manufacturing facilities have talented people, sophisticated test equipment, state of the art software with class
leading manufacturing systems and techniques. Additionally, we have in place a quality management program which is certified
to ISO9001, environmental management system certification to ISO14001 and occupational health and safety standard AS4801
giving you complete confidence in everything we do.
RFI’s products are truly innovative and as a result we are active around the globe taking our Australian designed and
manufactured products to key markets in Asia Pacific, the Americas and EMEA regions via offices ‘In-region’ in addition to
exporting directly to in excess of 50 countries.
One of RFI’s key principals is to remain totally customer focused as we recognise our future depends on the success of our
customers. We know that to be chosen as your supplier we must add value to your business and to achieve this we will work
hard to deliver the best product when and where you need it and back this up with the very best technical support available.

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 3
Document Number INS40648-1
Copyright 2011 RF Industries Pty Ltd
First Printing: 1st March 2011
Version Number
Version Date
1
1ST March 2011
1.2
2nd May 2011
1.4
4th July 2011
1.4c
9th November 2011
1.6
28th December 2011
1.7
04th January 2012
1.8
20th February 2012
1.9
15th April 2012
1.9a
30th May 2012
1.95
12th July 2012
2.0
29th August 2012
2.05
25th September 2012
2.10
05th May 2013
2.20
11th October 2013
2.30
8th January 2014
2.40
24th January 2014
2.50
14th March 2014
2.50b
22nd April 2014
2.50c
17th September 2014
2.50d
09th December 2014
2.50e
11th March 2015
2.60
15th July 2015
2.62
19th January 2016
2.70
15th March 2016
2.80
30th January 2017
2.81
27th April 2017
2.82
03rd July 2017
2.83
14th September 2017
2.83
14th March 2019
2.84
20th April 2019
2.85
17th February 2021
2.86
03rd June 2021
_____________________________________________________________________________
Disclaimer
Product part numbering in photographs and drawings is accurate at the time of printing. Part number labels on RFI products
supersede part numbers given within this manual. Information is subject to change without notice.

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 4
TABLE OF CONTENTS
1. GENERAL DESCRIPTION.................................................................................................. 10
2. APPLICATION DIAGRAM ................................................................................................... 13
3. APM - ELECTRICAL AND MECHANICAL SPECIFICATIONS ........................................... 14
4. COUPLER - ELECTRICAL AND MECHANICAL SPECIFICATIONS ................................. 15
5. CAM/SAM/RSM - ELECTRICAL AND MECHANICAL SPECIFICATIONS......................... 15
6. ORDERING INFORMATION ............................................................................................... 17
7. UNPACKING........................................................................................................................ 19
8. FIRMWARE LICENSE AGREEMENT................................................................................. 20
9. INSTALLATION ................................................................................................................... 21
10. OPERATION...................................................................................................................... 22
10.1 Ethernet Connection, Set-up, and Reset .......................................................................... 23
10.2 Log In Page......................................................................................................................... 25
10.3 System Overview................................................................................................................ 26
10.4 Status Menu........................................................................................................................ 27
10.5 Status –System Isolation Tests......................................................................................... 28
10.6 Status –Receive Systems Module..................................................................................... 31
10.7 Status - Rx Channels 1-20 ................................................................................................. 34
10.8 Status –Tx Port 1............................................................................................................... 36
10.9 Status –System................................................................................................................... 38
10.10 Status –Alarm Modules - Menu..................................................................................... 41
10.11 Status –Alarm Modules - SAM...................................................................................... 42
10.12 Status –Alarm Modules - CAM ..................................................................................... 45
10.13 Status –Communications................................................................................................ 48
10.14 History Menu.................................................................................................................... 50
10.15 History –Isolation Tests.................................................................................................. 51
10.16 History –Isolation Tests File........................................................................................... 57
10.17 History –Rx Power Chart............................................................................................... 58
10.18 History –Rx Power File................................................................................................... 62
10.19 History –Tx Power Chart............................................................................................... 63
10.20 History –Tx Power File................................................................................................... 67
10.21 History –Alm Mod I/P Chart ......................................................................................... 68
10.22 History –Alm Mod I/P File............................................................................................. 69
10.23 History –Alarm Event Log............................................................................................. 70
10.24 History –Access Event Log............................................................................................. 72
10.25 Service Mode .................................................................................................................... 73
10.26 Configuration Menu ........................................................................................................ 76
10.27 Configuration –User Data .............................................................................................. 77
10.28 Configuration –Isolation Tests....................................................................................... 79
10.29 Configuration –Receive Systems Module...................................................................... 82
10.30 Configuration –Channels - Menu .................................................................................. 84
10.31 Configuration –Rx Channels 1-20 ................................................................................. 85
10.32 Configuration –Tx Port 1 Channels .............................................................................. 88
10.33 Configuration –Alarms Settings Menu ......................................................................... 90
10.34 Configuration –Alarm Settings –Isolation Tests ......................................................... 91
10.35 Configuration –Alarm Settings –Receive Systems Module ........................................ 93
10.36 Configuration –Alarm Settings –Rx Channels............................................................ 95
10.37 Configuration –Alarm Settings - Tx Port 1................................................................... 97
10.38 Configuration –Alarm Settings –System...................................................................... 99
10.39 Configuration –Alarm Modules - Menu...................................................................... 101
10.40 Configuration –Alarm Modules –Channel Alarm Module....................................... 102
10.41 Configuration –Alarm Modules –Site Alarm Module .............................................. 107

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 5
10.42 Configuration –History................................................................................................. 112
10.43 Configuration –Communications ................................................................................ 114
10.44 Calibration Menu........................................................................................................... 118
10.45 Calibration –System Isolation Tests............................................................................ 119
10.46 Calibration –Rx Port .................................................................................................... 121
10.47 Calibration –Tx Port 1................................................................................................. 124
10.48 VSWR Calibration......................................................................................................... 136
10.49 Maintenance Menu ........................................................................................................ 137
10.50 Maintenance –Access Management............................................................................. 138
10.51 Maintenance –Date & Time ......................................................................................... 140
10.52 Maintenance –Manager Interface ............................................................................... 142
10.53 Maintenance –Configuration Files .............................................................................. 144
10.54 Maintenance –Test Alarms .......................................................................................... 147
10.55 Maintenance –Firmware Update................................................................................. 148
10.56 Maintenance - Restart ................................................................................................... 151
10.57 About –Advanced Power Monitor............................................................................... 152
10.58 Logout............................................................................................................................. 153
10.59 HELP Screens................................................................................................................. 154
11. SNMP............................................................................................................................... 155
12. CONNECTORS ............................................................................................................... 168
13. MAINTENANCE, INSPECTION AND REPAIR ADVICE................................................. 177
14. FREQUENTLY ASKED QUESTIONS (FAQ) .................................................................. 178
15. SUPPORTING INFORMATION....................................................................................... 180
16. USER NOTES:................................................................................................................. 181
Note:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
The user is cautioned that changes and/or modifications not approved by the
responsible party could void the user’s authority to operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class B device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area may
cause harmful interference in which case the user will be required to correct the interference at
their own expense.

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 6
Notice
The information contained in this document is subject to change without notice.
RF Industries Pty. Ltd. makes no warranty of any kind with regard to this material, including but not limited to, the
implied warranties of merchantability and fitness for a particular purpose. RF Industries Pty Ltd shall not be liable
for errors contained herein or for incidental or consequential damages in connection with the furnishing,
performance or use of the material.
All information contained in this manual has been reviewed. However RF Industries Pty Ltd accepts no liability for
any omissions, errors or construed information.
2011, RF Industries Pty Ltd. All rights reserved. Reproduction, adaptation or translation without prior written
permission is prohibited except as allowed under copyright laws.
For further information or help with this product contact your nearest RFI sales office or through the following;
Region
USA
EMEA
ASIA PACIFIC
Sales email
[email protected]
[email protected]om
[email protected]
Tech Support
[email protected]
[email protected]
[email protected]
Telephone Intl
[phone]
[phone]
[phone]
Telephone local
330 486 0706
01869 255 772
1300 000 RFI
Fax Intl
+ 1 [phone]
-
[phone]
Web
rfiamericas.com
rfiemea.com
rfi.com.au

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 7
Advanced Power Monitors
APMxxxx Series
APMxxxxK1 Series
APMxxxxK2 Series
Front View
Rear View
Rear View

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 8
Antenna Line Couplers
SP1318-2440-DFF1RU (132-174MHz)
SP3855-4440-DFF1RU (380-520MHz)
SP7496-4440-DFF1RU (746-960MHz)
Top View
Front View
Top View
Front View
Front View
Top View

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 9
Optional Modules
CAM0000 Series
Channel Alarm Module (CAM) Front Panel Layout
Channel Alarm Module (CAM) Rear Panel Layout
SAM0000 Series
Site Alarm Module (SAM) Front Panel Layout
Site Alarm Module (SAM) Rear Panel Layout
RSM0000 Series
Receive Systems Module (RSM) Rear Panel Layout

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 10
1. General Description
The Advanced Power Monitor (APM) is used to measure and monitor channel-specific Tx Forward and Reflected power and
Combiner Insertion losses between transmitter combiners their associated antenna(s) for up to 80 channels. Rx Channel and or
other frequency monitoring is also available for up to 80 channels. The capability to perform a series of Tx-to-Rx system
isolation (loop back), Rx sub-system passband gain response, and Transmitter isolation (Tx carrier rejection) tests is also
provided.
Four pairs of Tx Forward (FWD) and Tx Reverse (RFL) coaxial connector inputs fed from non-intrusive in-line directional
couplers give the APM the capability of monitoring the output of up to four (or more) separate transmitter combiner/antenna
systems.
A Receive coaxial connector input port fed from either the receiver multicoupler system and/or an external “off-air” antenna
gives the APM the capability of monitoring receiver system signal levels, or the propagation of transmitter channels located on
other sites.
In addition to measuring and monitoring transmitter forward and reflected power in analogue and digital radio communication
systems, the APM can also be configured to monitor and measure insertion loss in the network transmitter combiner(s).
For each combiner/antenna system being monitored, a 4-port Antenna Line Coupler (ALC) is inserted after the transmitter
combiner on the antenna feeder cable. These couplers have a low insertion loss (<0.2dB) and each is capable of handling up to
750Watts of RF power. The excellent PIM (<-150dBc) and PIP ratings of the coupler are maintained using 7/16 DIN (F)
connectors on the input “From Combiner” and output “To Antenna” ports, with N (F) termination connectors used on the “FWD”
and “RFL” coupling ports.
The APM and the ALC unit(s) are intended for mounting into 19” rack mount equipment cabinets or open frames, but they can
be mounted in alternate configurations if required. As standard, the APM is supplied with one ALC for connection to the first
combiner/antenna system - with additional ALCs available separately for applications requiring more than one combiner/antenna
system to be monitored.
RFI can also supply PIM-rated 7/16 DIN right-angle adapters if required to assist in rack cabinet layout and installation of the
coupler(s) if required.
The APM communicates via an Ethernet port mounted on the rear of the unit. This facilitates configuration and monitoring using
a Graphical User Interface (GUI) via an integral web server. Access to the GUI is protected by a User Name and Password that
is progressively checked for security strength.
The (up to) 80 individual Tx and Rx frequencies configured in the APM are divided across four GUI pages, each able to display
up to 20 channels each. This allows the user to view a large number of channels on a standard monitor screen size without the
excessive use of scrolling. It should be noted that each group of 20 Tx channels is not ‘physically’ assigned to a specific pair of
FWD and RFL ports, despite the GUI presenting them as four sets of 20 channels each (although it may be considered this way
if this assists in conveniently thinking of the channels and how they may be affiliated to the combiner/antenna that they are
connected to). As Tx channels are not physically assigned to a specific pair of FWD and RFL ports, one frequency cannot be
measured separately on multiple couplers (i.e. as may be desired if the multiple legs of a Distributed Antenna System were to
be monitored using multiple couplers connected to one APM), and therefore each individual frequency can only be measured
“once” across all ports of the APM.
All transmitter frequencies, channel bandwidths (12.5KHz and 25KHz), alarm level thresholds, and other relevant parameters
are user-programmable via the GUI.
A DB15 rear-mounted connector provides four (4) separate dry relay contact alarm reporting outputs which may be individually
user-assigned on an ad-hoc basis, to specific monitored channels, alarm groups (Network IDs), or to the system alarms in the
APM, CAM(s), SAM(s) or RSM. This capability allows specific channels’ alarm conditions to be accessible via discrete alarm
outputs –allowing faulty equipment to be individually identified, reported, and action to be initiated as required, or used to
control basic alarm event actions such as antenna change-over (ACO) or main/standby base station switching, etc. SNMP
Traps, SNMP GET requests, SMTP (Email) and Manager Message UDP/TCPIP data packets are also available for alarm and
status reporting. LED’s on the front panel of the APM provide visual indication of system alarms.
APM status and alarm monitoring is also supported by the Motorola UEM, Genesis Software GenWatch™ APM Applet, or by the
C² Systems SitePortal® monitoring software.
The APM is available in models that cover two DC input voltage ranges, 9-36V and 36-60V, and AC mains voltage models are
available using either a 90-264VAC plugpack-style 12VDC, or a 90-264VAC plugpack-style 48VDC PSU.

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 11

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 12
Channel Alarm Modules (CAMs) and Site Alarm Modules (SAMs)
If desired, optional Channel Alarm Modules (CAMs) or Site Alarm Modules (SAMs) may be added to the APM at any time.
CAMs/SAMs are connected using a daisy chained cabling approach using two cables - “DC power” and “Comms”.
The CAM is no longer manufactured and the SAM is a direct (and enhanced) replacement. Any mixture of up to ten (10)
Channel Alarm Modules (CAMs) or Site Alarm Modules (SAMs) may be added to a single APM unit.
When connected, CAMs and SAMs are automatically recognised by an APM, and menu selections for them will then
automatically appear in the APM GUI. Each CAM/SAM has an “ID address” which is easily set via the rotary switch on the rear
of each CAM/SAM unit. Each CAM/SAM connected to an APM should have a different ID address selected to prevent address
contention in the APM GUI.
Each CAM/SAM provides ten (10) separate alarm output relays which may be individually user-assigned, on an ad-hoc basis, to
specific monitored channels alarms in the APM. This capability allows specific channels’ alarm conditions to be accessible via
discrete alarm outputs –allowing faulty equipment to be individually identified, reported, and action to be initiated as required.
SNMP, SMTP (Email) and Manager Message UDP data packets are also available for alarm and status reporting.
A logic input on each of the CAM’s/SAM’s channels allows additional monitoring functionality –such as monitoring base station
Tx PTT or RX UNSQ lines –to enable the determination of “conditional” repeater RF output failure states. Various equipment
operational configurations can be monitored using these logic inputs –such as hot/standby conditions (and the change-over
actioned), using this functionality.
In addition to the ten (10) separate alarm channels, each CAM also has four (4) user-programmable and configurable general-
purpose logic inputs that may be used for monitoring external equipment –such as site or cabinet door opening, generator fuel
level low, UPS, solar, or other alarm conditions. This functionality has been further enhanced in the SAM, with Input #1 being
able to be configured to measure temperature, an analogue voltage range, or a digital logic input level –and inputs #2, #3, and
#4 being able to be configured to measure an analogue voltage range, or a digital logic input level respectively.
The CAM and the SAM modules provide enhanced monitoring functionality for the APM, allowing a range of PTT, temperature,
voltage and digital inputs to be monitored as part of Antenna Change-Over (ACO), base station hot/standby, equipment and site
monitoring, and auxiliary control capabilities.
Receive Systems Module (RSM)
An optional Receive Systems Module (RSM) may be fitted to an APM to support networks using two receive antennas, such as
systems using dual diversity or redundant Rx antennas.
The RSM may be added to an APM at any time –providing a network technology upgrade path if required.
The RSM also improves the APM’s receive sensitivity capability and provides an enhanced ability to monitor frequencies in
other applications –such as off-air monitoring of adjacent network sites’ coverage propagation or the monitoring of a Distributed
Antenna System (DAS).
The RSM adds two receiver paths (RA, RB) and a third ‘External’ antenna (RE) that are configurable in the APM GUI, on a per-
channel basis. Rx level measurements for all three receive paths are available in the Status, System Isolation Tests and
Service Mode pages of the APM GUI. The RSM also features a unique “RF Peak Level Detector” capability that can measure
high levels of RF, even of very short burst duration, that may be overloading the network’s base station receivers and degrading
network performance. Alarm thresholds can be configured for these received signal level peaks so that alarms can be actioned
when they occur, and these events are measured, logged and may be viewed in the APM GUI to assist fault-finding activities.
Hardware Versions
There are several hardware variants of the APM. These can be identified by the communications ports on the rear of the unit.
The earlier “K1” variant has one USB and one TCPIP port. The limited memory capacity of the K1 may restrict its compatibility
with future firmware features. Where this occurs, the webserver GUI and/or CLI interface may not display incompatible features
to prevent uncertainty in unit capabilities. The K1 unit’s memory capacity may also limit the available storage space for data
such as alarm history and log files.
The later variant of APM is identified as the “K2”. The K2 has deleted the USB port and substituted a second TCPIP port in its
place. The memory capacity of K2 units is significantly increased to support more extensive alarm history and log file storage
capability. Communications with the APM via a USB interface is still possible utilising a (user-supplied) USB-to-TCPIP adapter.

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 13
2. Application Diagram
APM FRONT VIEW
Tx ANTENNA 1
COUPLER TOP VIEW - MOUNTED ON 1RU FRONT PANEL
Tx COMBINER (1)
APM REAR VIEW
APM + 1 ANTENNA LINE COUPLER
FWD
RFL
OPTIONAL
DEDICATED Rx
MONITORING
ANTENNA FROM SPARE
PORT(S) ON
BTS Rx MUX(S)
TO ADDITIONAL COUPLERS IF REQUIRED
OPTIONAL SAM(s) or CAM(s)
1
10
to
MONITORED
CHANNELS
BTS PTT LINE
CONDITIONING
10 ASSIGNED ALARM
RELAY OUTPUTS
4 EXT ALARM INPUTS
10 EXT ALARM INPUTS
OPTIONAL RSM
4 ASSIGNED ALARM
RELAY OUTPUTS
Rx ANTENNA(s)
Diagram1

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 14
3. APM - Electrical and Mechanical Specifications
APM Model Number
APMxxxx Series
Frequency range
(Tx power and Rx level monitoring)
APM1317 132-174MHz
APM3852 380-520MHz
APM7487 746-870MHz
APM8796 870-960MHz
Maximum number of monitored channels
Tx = 80
Rx = 80
System Isolation Tests = 20
Maximum number of Tx networks (Tx ant’s)
4 (can be externally expanded)
Maximum number of Rx networks (Rx ant’s)
1 (can be externally expanded)
Frequency channel step size
1.25kHz
Channel measurement bandwidths
12.5, and 25kHz
Max spurious or IM products level
-30dBm
Measurable Rx input power level
-50dBm to -110dBm
(the RSM module can enhance APM readings to better than -125dBm)
Measurable Tx input power level
-30dBm to +20dBm
(i.e. +10dBm to +60dBm into 40dB coupler)
Conducted emissions
Complies with CISPR22 Part B & FCC Part 15 (15.207)
Radiated emissions
Complies with CISPR22 Part B & FCC Part 15 (15.209)
RF Termination connectors
All N (F) on rear
Communication interface ports
“K1” hardware variant
“K2” hardware variant
1 x USB Type B, 1 x TCPIP RJ45 Ethernet port on rear
2 x TCP/IP RJ45 Ethernet ports on rear
Internal alarm relay contacts output connector
1 x DB15 (M) on rear
Visual alarm notification
Front panel LED's
Configurable alarms
Summary Fault / Tx FWD min. power
Tx FWD max. power / Tx Combiner I.L. max.
VSWR max. / Rx RSSI min. level / RSSI max. level
Tx-to-Rx Antenna Isolation min. & max.
Rx System Gain Loss min. & max.
Tx Carrier Rejection min. & max.
(optional CAM/SAM module alarms)
Alarm Outputs
Summary Alarms –APM Relay Outputs
Detailed Alarms –APM or CAM/SAM Module Relay Outputs
SMTP Email (up to 4 Addresses)
SNMPv2c (Northbound Traps or Southbound GET)
or via Genesis Software GenWatch™ APM Applet
or via C² Systems SitePortal® monitoring software
Alarm Contact Type
Dry Relay N.O. / Common / N.C.
Alarm Relay Contact Ratings
50VDC @ 1A
Power supply options
9-36VDC, 36-60VDC, or 90-264VAC
Power consumption
10W (typical)
DC power connector
1 x Polarized 2-pin Phoenix-style connector on rear
Mounting
2RU 19" rack mounting
Dimensions
W 19 x H 3.5 x D 1.6in / W 483 x H 89 x D 40mm (incl. connectors)
Weight
< 4.4lbs / 2kgs
Operational temperature range
-22°F to 140°F / -30°C to +60°C
Table 1

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 15
4. Coupler - Electrical and Mechanical Specifications
Coupler Model Number
SPxxxx-2440-DFF1RU / SPxxxx-4440-DFF1RU
Frequency range
SP1318-2440-DFF1RU 130-180MHz
SP3855-4440-DFF1RU 380-550MHz
SP7496-4440-DFF1RU 746-960MHz
Insertion Loss
< 0.2dB
Input and Output Port Return Loss
> 20dB
Coupling Loss
40dB (+/- 0.7)
Maximum input power
750W
Maximum PIP
16kW (+72dBm)
PIM 3rd OIP (2 x 43dBm carriers)
Better than -150dBc
Connectors –“To ANT” & “From COMBINER” ports
2 x 7/16 DIN (F)
Connectors –“FWD” and “RFL” coupling ports
2 x N (F)
Mounting
1RU 19" rack mounting
Dimensions
W 19 x H 1.75 x D 3" / W 483 x H 45 x D 77mm (inc connectors)
Weight
SP1318-2440-DFF1RU < 4.4lbs / 2kgs
SP3855-4440-DFF1RU < 2.2lbs / 1kg
SP7496-4440-DFF1RU < 2.2lbs / 1kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
5. CAM/SAM/RSM - Electrical and Mechanical Specifications
CAM Model Number
CAM0000
Alarm Outputs
10
Alarm Contact Type
Dry Relay N.O. / Common / N.C.
Alarm Relay Contact Ratings
50VDC @ 1A
Alarm Inputs
10 (configurable - one per alarm output)
4 (configurable –general purpose)
Alarm Input Logic
“0” = <2.5V DC “1” = >2.5V DC
Visual alarm notification
Front and Rear panel mounted LEDs
Power Supply options
9-36VDC or 36-60VDC
Power Consumption
10W (max)
Connectors
External Alarm Inputs
Channel Alarms Outputs
Channel Alarms Inputs
Power Supply
Comms Interface to/from APM
(Note: All connectors on rear)
1 x Polarized 8-pin Phoenix connector
10 x Polarized 3-pin Phoenix connectors
10 x Polarized 2-pin Phoenix connectors
1 x Polarized 2-pin Phoenix connector
1 x DB15 (M)
Mounting
1RU 19" rack mounting
Dimensions
W 19 x H 1.75 x D 3" / W 483 x H 45 x D 77mm
Weight
< 2.2lbs / 1kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
Table 2
Table 3

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 16
SAM Model Number
SAM0000 / SAM0000-48
Alarm Outputs
10
Alarm Contact Type
Dry Relay N.O. / Common / N.C.
Alarm Relay Contact Ratings
50VDC @ 1A
Alarm Inputs
10 (configurable) digital (general purpose/one per alarm output)
4 (configurable) temperature/analogue/digital (general purpose)
Alarm Input Logic
temperature RFI temperature sensor
analogue -60V DC to +60V DC
analogue -60V DC to +5V DC
digital “0” = <2.5V DC “1” = >2.5V DC
Temperature Sensor (optional)
SAM0000-TS (ordered separately)
I/O Connector Kit (optional)
SAM0000-CK (ordered separately)
Visual alarm notification
Front and Rear panel mounted LEDs
Power Supply options
9-36VDC (SAM0000)
or
36-60VDC (SAM0000-48)
Power Consumption
10W (max)
Connectors
External Alarm Inputs
Channel Alarms Outputs
Channel Alarms Inputs
Power Supply
Comms Interface to/from APM
(Note: All connectors on rear)
1 x Polarized 8-pin Phoenix connector
10 x Polarized 3-pin Phoenix connectors
10 x Polarized 2-pin Phoenix connectors
1 x Polarized 2-pin Phoenix connector
1 x DB15 (M)
Mounting
1RU 19" rack mounting
Dimensions
W 19 x H 1.75 x D 3" / W 483 x H 45 x D 77mm
Weight
< 2.2lbs / 1kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
RSM Model Number
RSM0000 / RSM0000-48
Frequency Range
132-960MHz
Maximum RF Input Level (no damage)
0dBm
Isolation between RF Inputs
>55dB
Peak Detector Response Time
≥3mS
Peak Detector Alarm Threshold (GUI selectable per port)
-35 to -55dBm
Peak Detector Warning Threshold (GUI selectable per port)
-40 to -65dBm
Visual alarm notification
Rear panel mounted LEDs
Power Supply options
9-36VDC (RSM0000)
or
36-60VDC (RSM0000-48)
Power Consumption
10W (max)
Connectors
Connection to APM
RF In and RF Out
Power Supply
Comms Interface to/from APM
N (Male)
BNC (Female)
1 x Polarized 2-pin Phoenix connector
1 x DB15 (M)
Mounting
On rear of APM (mounting bracket supplied)
Dimensions
Mounts on rear of APM
Weight
< 2.64lbs / 1.2kg
Operational temperature range
-22°F to 140°F / -30°C to +60°C
Table 4
Table 5

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 17
6. Ordering Information
Ordering Information
Motorola ECAT
RFI
Model Number
Model Number
Description
DSAPM1317
APM1317
Advanced Power Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
DSAPM131748
APM1317-48
Advanced Power Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
DSAPM1317AC
APM1317-AC
Advanced Power Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
DSAPM131748AC
APM1317-48AC
Advanced Power Monitor 132-174MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
DSAPM3852
APM3852
Advanced Power Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
DSAPM385248
APM3852-48
Advanced Power Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
DSAPM3852AC
APM3852-AC
Advanced Power Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
DSAPM385248AC
APM3852-48AC
Advanced Power Monitor 380-520MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
DSAPM7487
APM7487
Advanced Power Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
DSAPM748748
APM7487-48
Advanced Power Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
DSAPM7487AC
APM7487-AC
Advanced Power Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
DSAPM748748AC
APM7487-48AC
Advanced Power Monitor 746-870MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
DSAPM8796
APM8796
Advanced Power Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC
DSAPM879648
APM8796-48
Advanced Power Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC
DSAPM8796AC
APM8796-AC
Advanced Power Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 9-36VDC to 90-264V AC (external)
DSAPM879648AC
APM8796-48AC
Advanced Power Monitor 870-960MHz
80 Ch / 4 Tx Fwd / 4 Tx Rfl / 1 Rx Port / 36-60VDC to 90-264V AC (external)
Additional Couplers
Description
DSSP13182440DFF1RU
SP1318-2440-DFF1RU
Directional Coupler 130-180MHz
40dB 4-Port 19in Rack Mount 1RU
Input /Output Ports DIN (F) Coupling Ports N (F)
DSSP38554440DFF1RU
SP3855-4440-DFF1RU
Dual Directional Coupler 380-550MHz
40dB 4-Port 19in Rack Mount 1RU
Input /Output Ports DIN (F) Coupling Ports N (F)
DSSP74964440DFF1RU
SP7496-4440-DFF1RU
Dual Directional Coupler 746-960MHz
40dB 4-Port 19in Rack Mount 1RU
Input /Output Ports DIN (F) Coupling Ports N (F)
Table 6

APMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 18
Ordering Information
Channel Alarm Module
Description
DSCAM0000
CAM0000
Channel Alarm Module 9-36V DC (Obsolete –use DSSAM0000)
