Advan AMM215WTTP User manual

Rev.B
AMM215WTTP
LCD Color Display
USER’s GUIDE
Rev.A

Table of Contents
Warnings and Cautions 1
Warnings ..................................................................................................................... 2
Cautions...................................................................................................................... 3
Symbol Definitions....................................................................................................... 4
Usage Notice 9
Precautions ................................................................................................................. 9
Introduction 10
About AMM215WTTP Series ......................................................................................10
Touch Screen for AMM215WTTP ...............................................................................10
Package Overview .....................................................................................................11
Installation 13
Product Overview .......................................................................................................13
Front View ..............................................................................................................13
Bottom View (Without Stand) .................................................................................13
VESA Mount for Your Monitor .....................................................................................14
Start Your Installation .................................................................................................15
Connecting the Display...............................................................................................16
Figure.....................................................................................................................17
User Controls 18
Side Panel Controls....................................................................................................18
How to Use the OSD Menus .......................................................................................19
On-Screen Display Menus ..........................................................................................20
Appendix 21
Troubleshooting..........................................................................................................21
Warning Signal ...........................................................................................................22
No Signal................................................................................................................22
Going to Sleep............................................................................................................22
Out of Range..........................................................................................................22
Product Dimensions ...................................................................................................23
Compatibility Modes ...................................................................................................24
Touch Screen Driver Installation .................................................................................25
AMM215WTTP Driver Install Instructions ................................................................25
Description of Warranty 27

The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright. All rights
are reserved. No part of this document may be reproduced,translated to another language
or stored in a retrieval system, or transmitted by any means, electronic, mechanical,
photocopying, recording, or otherwise, without prior written permission. Windows is a registered
trademark of Microsoft, Inc. Other brand or product names are trademarks of their respective
holders.
Caution!
Any changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Warnings and Cautions
Please read this manual and follow its instructions carefully. The words warning, caution, and
note carry special meanings and should be carefully reviewed:
Warning The personal safety of the patient or physician may be involved.
Disregarding this information could result in injury to the patient or
physician.
Caution Special service procedures or precautions must be followed to avoid
damaging the instrument.
Note Special information to make maintenance easier or important information
more clear.
A lightning bolt within a triangle is intended to warn of the presence of
hazardous voltage. Refer all service to authorized personnel.
Warranty is void if any of these warnings are disregarded.
ADVAN Int’l Corp accepts full responsibility for the effects on safety, reliability, and
performance of the equipment only if:
‧Re-adjustments, modications, and/or repairs are carried out exclusively by ADVAN Int’l
Corp.
‧The electrical installation of the relevant operating room complies with the applicable IEC
and CE requirements.
Warning Federal law (United States of America) restricts this device to use by,
or on order of a physician.
ADVAN Int’l Corp's AMM215WTTP monitor has been tested under ANSI/AAMI ES60601-1
standard for Medical application.
ADVAN Int’l Corp reserves the right to make improvements in the product(s) described
herein. Product(s), therefore, may not agree in detail to the published design or
specications. All specications are subject to change without notice.
Please use rear cover page with ADVAN contact points or phone your local ADVAN Int’l Corp
sales representative or agent for information on changes and new products.
1

Warnings
Warning TO AVOID POTENTIAL SERIOUS INJURY TO THE USER AND THE
PATIENT AND/OR DAMAGE TO THIS DEVICE, THE USER MUST :
1. Read the operating manual thoroughly and be familiar with its contents prior to using this
equipment.
2. Carefully unpack the unit and check if any damage occurred during shipment.
3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked
by qualied personnel before operating it any further.
4. Uplug the unit if it is not to be used for an extended period of time. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
5. Be a qualied physician, having complete knowledge of the use of this equipment.
6. Test this equipment prior to a medical procedure. This monitor was fully tested at the
factory before shipment.
7. Avoid removing covers on control unit to avoid electric shock.
8. Attempt no internal repairs or adjustments not specically detailed in this operating
manual.
9. Pay close attention to the care, cleaning instructions in this manual. A deviation may
cause damage (refer to the Cleaning section).
10. DO NOT STERILIZE MONITOR.
11. Read the entire instruction manual before assembling or connecting the camera.
12. Do not place the monitor or any other heavy object on the power cord. Damage to the
cable can cause re or electirc shock.
13. Monitor with power supply is suitable for use in patient environment.
14. DO NOT stack more than "6" boxes high.
15. To avoid risk of electric shock, this equipment must only be connected to supply mains
with protective earth.
16. Do not modify this equipment without authorization of the manufacturer.
17. Power cord is used as a disconnection device. To de-energize equipment, disconnect the
power cord. ME Equipment should be placed easily powered off place.
This equipment has been tested and found to comply with the limits for medical devices in
IEC 60601-1-2. These limits are designed to provide reasonable protection against harmful
interference in a typical medical installation.
NOTICES TO USER
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
2

Cautions
1. The AC Adapter must be plugged into a grounded power outlet.
2. Use only the proprietary AMM215WTTP power supply for the AMM215WTTP monitor.
3. Turn power off when unit is not in use. Disconnect the power plug from AC outlet if the
product is not going to be used for an extended period of time.
4. Never operate the unit right after having transported from a cold location directly to a
warm location.
5. Do not expose the monitor to moisture or directly apply liquid cleaners directly to the
screen. Spray the cleaning solution into a soft cloth and clean gently.
6. Handle the monitor with care. Do not strike or scratch the screen.
7. Do not block the monitor cooling vents. The monitor is cooled by natural convection and
has no fan.
8. Do not force the monitor past 28 degrees of vertical when adjusting the screen position.
(For monitors equipped with stands only.)
9. Remove the power module and connection when transporting the unit.
10. Save the original carton and associated packing material. They will be useful should you
have to transport or ship the unit.
11. Allow adequate air circulation to prevent internal heat buildup.
12. Do not place the unit on surfaces (rugs, blankets, etc.) or near materials (curtains,
draperies) that may block the ventilation slots.
13. Do not install the unit near sunlight, excessive dust, mechanical vibration or shock.
14. The unit is designed for operation in a horizontal position. Never operate the unit in a
vertical position.
15. Keep the unit away from equipment with strong magnets (i.e. a large loudspeaker.)
16. Equipment with SIP/SOP connectors should either comply with IEC 60601-1 and/or
IEC 60601-1-1 harmonized national standard or the combination should be evaluated.
Do not touch the patient with signal input or output connectors.
17. Use only a hospital grade power supply cord.
18. This equipment has been tested and found to comply with the limit for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable generate uses and can radiate radio frequency energy, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation, which can be detemined by turning the equipment off and on, the
user is encourage to try to correct the interference by one or more of the following
measures:
 ‧
Reorient or relocate the receiving device.
 ‧
Increase the separation distance between the equipment.
 ‧
Connect the equipment to an outlet on a circuit different from that to which the
other device(s) are connected.
 ‧
Consult the manufacturer or eld service technican for help.
19. Grounding reliability can only be achieved when the equipment is connected to an
equipment receptacle labeled “Hospital Only” or “Hospital Grade.”
Caution To connect to an international power supply, use a an attachment plug
appropriate for the power outlet.
Caution Refer to the “Electromagnetic Compatibility” (EMC) section of this manual
to ensure EMC. The AMM215WTTP must be installed and operated
according to the EMC information provided in this manual.
3

For indoor use only.
Tested to comply with FCC
Class B standards.
DC power control switch
Medical Equipment
With respect to electric shock,
re and mechanical hazards
only in accordance with
ANSI/
AAMI ES60601-1(2005/(R)2012
+ A1:2012, C1:2009/(R)2012 +
A2:2010/(R)2012), and CSA-C22.2
NO. 60601-1:14 Edition 3 -
Revision Date 2014.01.01
Tested to comply with IP
IPX1 (ingression protection) Rating
WEEE symbol for the
recyclable product. Please do
not throw the product with this
symbol in the bin.
Consult instructions for use
Symbol Denitions
General warning sign
of risk of danger
Dangerous: High Voltage
Direct Current
Serial Number
This way up
Fragile, handle with care
6Stacking limit by number
Keep dry
Recyclable
Indicates proof of conformity
to applicable European
"Economic Community Council"
directives and to harmonized
standards published in the
ofcial journal of the European
Communities.
Authorized Representative in
Europe
Date of Manufacture
Manufacturer
51LJ
E472062
4

EU Declaration of Conformity for Medical Applications
A Declaration of Conformity has been led for this product. A sample of this document may
be found in the addendum which accompanied this manual. For a copy of the Declaration
of Conformity document, please contact ADVAN Int’l Corp. and request for AMM215WTTP
DOC.
Cleaning Your Monitor
Turn off the product before cleaning. No specic liquid or chemical is necessary when
cleaning this LCD monitor. However, it is suggested to use a soft cloth moistened with mild
detergent to clean the display housing.
To clean the screen, do not spray liquid cleaners directly on to the unit. Spray cleaning
solution onto a cloth, and without applying excessive pressure, clean the screen.
Caution: Do not use abrasive cleaners, waxes or solvents for your cleaning.
5

This monitor is intended for use in Health Care Facilities Model AMM215WTTP Equipment is
not suitable for use in the presence of ammable anesthetic mixture with air or with oxygen
or nitrous oxide.
No user serviceable parts inside, ask qualied personnel when accessing inside.
This product contains electrical waste or electronic equipment. It must not be disposed of as
unsorted municipal waste and must be collected separately.
Electrical input rating: 12V DC 3A
Classication
Type of protection against electric shock: Class I Equipment.
Degree of protection against the ingress of water: IPX1 compliance.
Mode of operation: Continuous
This monitor has been tested to comply with IEC/EN 60601-1, IEC/EN60601-1-2 and is
certied by UL to medical standard(UL/cUL Mark).
Because many medical ofces are located in residential areas, this monitor, in addition to the
medical requirements, has also been tested and found to comply with
the limits for FCC Class B computing devices in a typically congured system. It is the
system integrator or congurer’s responsibility to test and ensure that the entire
system complies with applicable EMC laws.
Environmental conditions for transport and storage:
- Temperature range within -4° to 140° F (-20° to 60°C)
- Relative humidity range within 10% to 90%
- Atmospheric pressure range within 500 to 1060 hPa.
- Operating within 0° to 40°C
Environmental conditions for operating:
- Operating temperature range within 32° to 104° F (0° to 40°C)
6

Electromagnetic Compatibility
Like other electrical medical equipment, the AMM215WTTP requires special precautions to
ensure electromagnetic compatibility with other electrical medical devices. To ensure
electromagnetic compatibility (EMC), the AMM215WTTP must be installed and operated
according to the EMC information provided in this manual.
Note The AMM215WTTP has been designed and tested to comply with
EN 60601-1-2 requirements for EMC with other devices.
Caution Portable and mobile RF communications equipment may affect the
normal function of the AMM215WTTP.
Warning Do not use cables or accessories other than those provided with
the AMM215WTTP, as this may result in increased electromagnetic emissions
or decreased immunity to such emissions.
Warning If the AMM215WTTP is used adjacent to or stacked with other
equipment, observe and verify normal operation of the AMM215WTTP in the
conguration in which it will be used prior to using it in a surgical procedure.
Consult the tables below for guidance in placing the AMM215WTTP.
Manufacturer's Declaration - Electromagnetic Emission
The Model AMM215WTTP is intended for use in the electromagnetic environment specied below.
The user of AMM215WTTP should assure that it is used in such an environment.
Emission test Compliance Electromagnetic Environment - Guidance
RF emissions CISPR 11 Group 1
The Model AMM215WTTP uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not likely
to cause any interference in nearby electronic equipment
RF emissions CISPR 11 Class B AMM215WTTP is suitable for use in all establishments, including
domestic establishments and those directly connected to the public
low-voltage power supply network that supplies buildings used for
domestic purposes
Harmonic emissions
IEC61000-3-2 Class D
Voltage Fluctuations
IEC61000-3-3 Complies
Manufacturer's Declaration - Electromagnetic Immunity
The Model AMM215WTTP is intended for use in the electromagnetic environment specied below.
The user of AMM215WTTP should assure that it is used in such an environment.
Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic
Environment - Guidance
Electrostatic discharge
(ESD)
IEC61000-4-2
6 kV contact
8 kV air
6 kV contact
8 kV air
Floors should be wood,
concrete or ceramic tile.
If oors are covered with
synthetic material, the
relativehumidity should be
at least 30%.
Electrical fast transient
/burst IEC61000-4-4
2 kV for power supply lines
1 kV for input / output lines
2 kV for power supply lines
1 kV for input / output lines
Mains power quality
should be that of a typical
commercial or hospital
environment
Surge
IEC61000-4-5
1 kV differential mode
2 kV common mode
1 kV differential mode
2 kV common mode
Mains power quality
should be that of a typical
commercial or
hospital environment.
7

Power frequency
(50/60Hz) mag-netic eld
IEC 61000-4-8
3.0 A/m 3.0 A/m
Power frequency magnetic
elds should be at levels
characteristic of a typical
location in a typical
commercial orhospital
environment.
Voltage dips, short
interruptions andvoltage
variations onpower supply
inputlines IEC61000-4-11
<5% Ut (>95% dip in Ut)
for 0.5 cycle
40% Ut (60% dip in Ut)for
5 cycles
70% Ut (30% dip in Ut)for
25 cycles
<5% Ut (>95% dip in Ut)
for 5 sec.
<5% Ut (>95% dip in Ut)
for 0.5 cycle
40% Ut (60% dip in Ut)
for 5 cycles
70% Ut (30% dip in Ut)
for 25 cycles
<5% Ut (>95% dip in Ut)
for 5 sec.
Mains power quailityshould
be that of a typicalcommercial
or hospitalenvironment. If the
user of the AMM215WTTP
image intensier
requirescontinued operation
during power mains
interruptions, it is commended
that the AMM215WTTP image
intensier bepowered from an
uninterruptible power supply
or a battery.
Note: Ut is the A.C. mains voltage prior to application of the test level.
Manufacturer's Declaration - Electromagnetic Immunit
The Model AMM215WTTP is intended for use in the electromagnetic environment specied below. The customer
or the user of AMM215WTTP should ensure that it is used in such an environment.
Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic Environment - Guidance
Conducted RF
IEC61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 KHz to 80 MHz
3 Vrms
800 MHz to 2.5 GHz
3 Vrms
150 KHz to 80 MHz
3 Vrms
800 MHz to 2.5 GHz
Portable and mobile RF communications
equipment should be used no closer toany
part of the AMM215WTTP, includingcables,
than the recommended separationdistance
calculated from the equationapplicable to the
frequency of thetransmitter.
Recommended Separation Distance0.15 MHz
to 80 MHz
80 MHz to 800 MHz
800 Mhz to 2.5GHz
where P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and is the recommended separation
distance in meters (m). Field strengths from
xed RF transmitters,as determined by an
electromagneticsite survey (a), should be less
than the compliance level in each frequency
range(b).Interferency may occur in the vicinity
of equipment marked with the following
symbol:
NOTE 1: At 80MHz and 800MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reection from structures, objects, and people.
(a) Field strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast, connot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to xed RF transmitters, an electromagnetic site
survey should be considered. If the measured eld strength in the location in which the AMM215WTTP is used
exceeds the applicable RF compliance level above, the AMM215WTTP should be observed to verify normal
operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or
relocating the AMM215WTTP.
(b) Over the frequency range 150kHz to 80MHz, eld strengths should be less than [V1] V/m.
8

Recommended Separation Distances Between Portable and Mobile RF Communications
Equipement and the AMM215WTTP System
The AMM215WTTP system is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The user of the AMM215WTTP system can help prevent electromagnetic
interference by maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and the AMM215WTTP system as recommended below, according to the maximum
output power of the communications equipment.
Rated maximum output
power (W) of transmitter
Separation distance (m) according to frequency of transmitter
150kHz to 80MHz
d=1.17,
80MHz to 800MHz
d=1.17,
800MHz to 2.5GHz
d=2.33,
0.01 0.12 0.12 0.23
0.1 0.37 0.37 0.74
1 1.17 1.17 2.33
10 3.70 3.70 7.37
100 11.70 11.70 23.30
For transmitters rated at a maximum output power not listed above, the recommended separation distance (d)
in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the
maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reection from structures, objects, and people.
9

Introduction
About AMM215WTTP Series
The AMM215WTTP Touch screen LCD Monitor displays information from imaging systems and
devices.
Features include:
• Direct Analog signal input
• Direct Digital signal input
• Active matrix TFT LCD technology
• 1920 x 1080 resolution
• 21.5" viewable display area - 16:9 aspect ratio
• 31.47 ~ 82.3 KHz horizontal scan
• 56 ~ 75 Hz high refresh rate
• 0.24795mm x 0.24795mm pixel pitch
• Auto adjustment function
• Multilingual OSD user control
• 100 mm VESA mount
• Removable base for exible mounting solutions.
• Touch screen with USB controller
• Audio output(optional)
• USB HUB 2.0(optional)
Touch Screen for AMM215WTTP
• Projected Capacitive touch screen for nger input only
• Surface: Glare treatment
• Interface: USB controller
• Transmittance: 90%±5%
• HID: Windows® 7
• Driver: VISTA, XP, 2000, CE, XP Embedded, Linux, Apple® Mac OS
10

11
Package Overview
*Accessories might change depending on region.
LCD Display Power Cord VGA Signal Cable
USB Cable ( A to B) DVI-D Cable
Quick Start Guide Touch Driver CD
DC Power Supply
Audio Cable
(optional)

Unpacking the Monitor
Before you unpack your monitor, prepare a suitable workspace. You need a stable and level
surface near a grounded wall outlet in an area which is relatively free of glare from sunlight
or other sources of bright light. The monitor is cooled by natural convection (it has no fan).
For optimum performance, do not block the cooling vents.
While unpacking the monitor, inspect it and other package contents for shipping damage that
could cause a re or shock hazard. Immediately report any shipping damage to the carrier or
transportation company or contact customer service for returns.
After you unpack the monitor, make sure the following items are included:
‧
Monitor with video cable
‧
AC adapter with cable
CAUTION: AC Adapter must be plugged into grounded a power outlet
CAUTION : AC adapter
Manufacturer: BridgePower Corp.
Model No: BPM050S12F09
INPUT: 100-240Vac, 50-60 Hz, 1.5A
OUTPUT: 12Vdc, 4.2A
‧
This operations manual
Note: Your system provider may offer alternative cords or cables depending on
the installation requirement and local geography issues.
12

Installation
Product Overview
• Front View
• Bottom View (Without Stand)
VGA
DVI
USB B-Type
DC IN
RJ11
USB A-Type
AUDIO
13

Flat Panel Mounting Physical Mounting Interface by
VESA
This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface
standard which denes a physical mounting interface for at panel monitors, and
corresponding with the standards of at panel monitor mounting devices, such as wall and
table arms. The VESA mounting interface is located on the back of your monitor.
To mount the monitor on a UL certied swing arm or other mounting xture, follow the
instructions included with the mounting xture to be used.
   
Warning
Please select the proper screws!
The distance between the back cover surface and the bottom of the screw hole is 8
mm. Please use four M4 screws diameter with proper length to mount your monitor.
Please note: the mounting stand must be able to support at least 17.6 lbs (8Kg).
14
100.0 mm
100.0 mm
Slots(X6)
VESA
Mounting
Interface

Start Your Installation
Please follow these instructions so that you can hook up the cables to associated connectors.
1. Lay the LCD at on an even surface.
2. Move the stand into position as seen in the step 1 diagram.
3. Connect the cables to the appropriate connectors as seen in the step 2 diagram.
15
Step 2
VGA USB
DVI DC IN
Step 2
Step 1

16
Connecting the Display
To setup this display, please refer to the following gure and procedures.
1. Be sure all equipment is turned off.
2. Connect the DC plug to the power connector on the monitor and the other end into an
electrical outlet (8.1).
3. Connect the D-SUB or DVI cable from the display’s D-SUB or DVI input connector to the
D-SUB or DVI connector of your host computer and tighten the screws (8.1).
4. Connect the USB cable from the USB port of your display to the USB port (8.1) of your
computer.
5. Congure the touch screen. Refer to the “Touch Screen Driver Installation” section on
page 16.
6. Once the touch screen is congured, the monitor is ready for use.
Note:
Avoid placing the monitor against a bright background or where sunlight or other light
sources may reect on the area of the monitor. Place the monitor just below eye level.
To ensure the LCD display works well with your computer, please congure the display mode
of your graphics card to make it less than or equal to 1920 x 1080 resolution and make sure
the timing of the display mode is compatible with the LCD display.
We have listed the compatible “Video Modes” of your LCD display in the appendix
(on page 24) for your reference.
External power supplies applicable: Bridgepower / BPM050S12F09
Recommendation to Use more than One Unit
As unforeseen situations can occasionally occur with the monitor, when the display is used
please use a safety control. It is strongly recommended the user uses more than one unit or
prepares a spare unit in case there is an emergency.
On Burn-in
Permanent burn-in may occur from the followings:
‧ Displaying color bar or static images repeatedly or for a long period of time.
‧ Using the unit repeatedly in a high temperature/ high humidity environment
‧ Displaying an image smaller than the monitor continuously.

17
