SyncMaster 225MS

Notation
Failure to follow directions noted by this symbol could result in bodily harm or damage to
equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Ground to prevent an electric shock
Powe
r
When not used for extended period of time, set your computer to DPMS.
If using a screen saver, set it to the active screen mode.
The images here are for reference only, and are not applicable in all cases (or countries).
Do not use a damaged or loose plug.

This may cause an electric shock or fire.
Do not pull the plug out by the wire nor touch the plug with wet hands.
This may cause an electric shock or fire.
Use only a properly grounded plug and receptacle.
An improper ground may cause electric shock or equipment damage.
Insert the power plug firmly so that it does not come loose.
A bad connection may cause fire.
Do not excessively bend the plug and wire nor place heavy objects upon them, which
could cause damage.
This may cause an electric shock or fire.
Do not connect too many extension cords or plugs to an outlet.
This may cause fire.
Do not disconnect the power cord while using the monitor.
A surge may be caused by the separation and may damage the monitor.
Do not use the power cord when the connector or plug is dusty.
If the connector or plug of the power cord is dusty, clean it with a dry cloth.
Using the power cord with a dusty plug or connector may cause an electric shock
or fire.

Installation
Be sure to contact an authorized Service Center when installing your set in a location
with heavy dust, high or low temperatures, high humidity, and chemical substances,
or where it will be operated for 24 hours continuously such as an airport, train station
or etc.
Failure to do so may cause serious damage to your set.
Put your monitor in a location with low humidity and a minimum of dust.
Failure to do so may cause an electric shock or fire inside the monitor.
Do not drop the monitor when moving it.
This may cause damage to the product or human body.
Install the monitor base in a showcase or shelf so that the end of the base does not
protrude from the showcase or shelf.
Dropping the product may cause damage to the product or personal injury.
Do not place the product on an unstable or small surface area.
Place the product on an even and stable surface, as the product may fall and
cause harm to someone walking by, specifically children.
Do not place the product on the floor.
Someone, specifically children could trip over it.
Keep any flammable objects such as candles, insecticides or cigarettes away from
the product.
Otherwise, this may cause a fire.
Keep any heating devices away from the power cable.
A melted coating may lead to electric shock or fire.

Do not install the product in places with poor ventilation, for instance, a bookshelf,
closet, etc.
Any increase in internal temperature may cause fire.
Set down the monitor carefully.
The monitor could be damaged or broken.
Do not place the monitor face down.
The TFT-LCD surface may be damaged.
Installing a wall bracket must be done by a qualified professional.
Installation by unqualified personnel may result in injury.
Always use the mounting device specified in the owner's manual.
When installing the product, make sure to keep it away from the wall (more than 10
cm/4 inches ) for ventilation purposes.
Poor ventilation may cause an increase in the internal temperature of the product,
resulting in a shortened component life and degraded performance.
Keep the plastic packaging (bag) out of children's reach.
The plastic packaging (bag) may cause suffocation if children play with it.
Cleanin
g
and Use
When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a
slightly moistened, soft fabric.
Do not spray water or detergent directly on the monitor.
This may cause damage, electric shock or fire.

Use the recommended detergent with a smooth cloth.
If the connector between the plug and the pin is dusty or dirty, clean it properly with a
dry cloth.
A dirty connector may cause an electric shock or fire.
Make sure to unplug the power cord before cleaning the product.
Otherwise, this may cause electric shock or fire.
Unplug the power cord from the power outlet and wipe the product using a soft, dry
cloth.
Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air
freshener, lubricant or detergent.
Contact the Service Center or Customer Center for interior cleaning once a year.
Keep the product's interior clean.
Dust which has accumulated in the interior over an extended period of time may
cause malfunction or fire.
Others
Do not remove cover (or back).
This may cause an electric shock or fire.
Refer to a qualified servicing company.
If your monitor does not operate normally - in particular, if there are any unusual
sound or smell coming from it - unplug it immediately and the Service Center.
This may cause an electric shock or fire.

Keep the product away from places exposed to oil, smoke or moisture; do not install
inside a vehicle.
This may a malfunction, an electric shock or fire.
Especially avoid operating the monitor near water or outdoors where the monitor
could be exposed to snow or rain.
If the monitor is dropped or the casing is damaged, turn the monitor off and unplug
the power cord. Then contact the Service Center.
The monitor may cause a malfunction, electric shock or fire.
Disconnect the plug from the outlet during storms or lightening or if it is not used for a
long period of time.
Failure to do so may cause an electric shock or fire.
Do not try to move the monitor by pulling only the wire or the signal cable.
This may cause a breakdown, electric shock or fire due to damage to the cable.
Do not move the monitor right or left by pulling only the wire or the signal cable.
This may cause a breakdown, electric shock or fire due to damage to the cable.
Do not cover the vents on the monitor cabinet.
Bad ventilation may cause a breakdown or fire.
Do not place water containers, chemical products or small metal objects on the
monitor.
This may a malfunction, an electric shock or fire.
If a foreign substance enters the monitor, unplug the power cord and contact the
Service Center.
Keep the product away from combustible chemical sprays or inflammable
substances.

This may cause an explosion or fire.
Never insert anything metallic into the monitor openings.
This may cause an electric shock, fire or injury.
Do not insert metal objects such as chopsticks, wire and gimlet or inflammable
objects such as paper and match into the vent, headphone port or AV ports or etc.
It may cause a fire or an electric shock. If an alien substances or water flows into
the product, turn the product off, unplug the power connector from the wall outlet
and contact the Service Center.
If you view a fixed screen for an extended period of time, residual image or blurriness
may appear.
Change the mode to energy save or set a screensaver to moving picture when
you need to be away from the monitor for an extended period of time.
A
djust the resolution and frequency to the levels appropriate for the model.
An inappropriate resolution may cause undesirable picture quality.
22 inch (55 cm) - 1680 x 1050
Keep the volume at a comfortable level when using the headphones.
Excessively loud volume levels may damage hearing.
Watching the monitor continuously at a too close angle may result in eyesight
damage.
To ease eye strain, take at least a five-minute break after every hour of using the
monitor.
Do not install the product on an unstable, uneven surface or a location prone to
vibrations.

Dropping the product may cause damage to the product or personal injury.
Using the product in a location prone to vibrations may shorten the lifetime of the
product or may catch fire.
When moving the monitor, turn off and unplug the power cord. Make sure that all
cables, including the antenna cable and cables connected to other devices, are
disconnected before moving the monitor.
Failure to disconnect a cable may damage it and lead to fire or an electric shock.
Place the product out of children’s reach, as they could damage by hanging onto it.
A falling product could cause physical damage even death.
When not using the product for an extended time period, keep the product
unplugged.
Otherwise, this may cause heat emission from the accumulated dirt or degraded
insulation, leading to electric shock or fire.
Do not place children's favorite objects (or anything else that may be tempting) on the
product.
Children may try to climb on the product to retrieve an object.
The product could fall, causing physical damage or even death.
When lifting up or moving the monitor, do not lift the monitor upside down while
holding only the stand.
This may cause your monitor to fall, and become damaged or cause personal
injury.
Good Postures When Usin
g
the Monito
r
Try to maintain a good posture when using the monitor.
zKeep your back straight.
zKeep a distance of about 45 ~ 50 cm between your eyes and the
monitor screen. Look at the screen from slightly above it, and have
the monitor directly in front of you.
zTilt the monitor upwards by 10 ~20 degrees. Adjust the monitor
height so that the top of the monitor is slightly below eye level.
zAdjust the monitor angle so that there is no reflected light on the
screen.Try to maintain your arms perpendicular to your armpits.
zKeep your arms level with the back of your hands.
zKeep the angle of the elbow perpendicular.
zKeep the angle of the knees at more than 90 degree. Do not let your

feet fall up from the floor. Adjust the arm position so that it is below
the heart
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment) - Europe only
(Applicable in the European Union and other European countries with
separate collection systems)
This marking shown on the product or its literature, indicates that it should not
be disposed with other household wastes at the end of its working life. To
prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they
can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product should not be mixed with
other commercial wastes for disposal.

PRODUCT INFORMATION (Image Retention Free)
LCD Monitors and TVs may have an image retention when switching from one image to another
especially after displaying a stationary image for a long time.
This guide is to demonstrate a correct usage of LCD products in order to protect them from
Image retention.
Warrant
y
Warranty does not cover any damage caused by image retention.
Burn-in is not covered by the warranty.
What is Ima
g
e retention ?
During normal operation of a LCD panel, pixel image retention doesn't occur. However,
if the same image is displayed for a long time, a slight difference in electric charge
accumulates between the two electrodes which encase the liquid crystal. This may
cause the liquid crystal to build up in a certain areas of the display. Thus, the previous
image is retained when switching to a new video image. All display products, including
LCD,are subject to image retention. This is not a product defect.
Please follow the suggestions below to protect your LCD from image retention
Power Off, Screen Saver, or Power Save Mode
Ex)
zTurn the power off when using a stationary pattern.
zUse a Screen saver if possible
zSet the Monitor to power off with the PC Display Properties Power Scheme.
- Turn the power off for 4 hours after 20 hours in use
- Turn the power off for 2 hours after 12 hours in use
- Screen saver in one color or a moving image is recommended.
Su
gg
estions for s
p
ecific a
pp
lications
Ex) Airports, Transit Stations, Stock Markets, Banks, and Controlling Systems
We recommend that you follow set up of your display system program as below:
Dis
p
la
y
Information to
g
ether with Lo
g
o or Movin
g
ima
g
e c
y
cle.
Ex) Cycle : Display Information for 1 hour followed by a
Display Logo or moving image for 1 minute.
Chan
g
e the Color Information
p
eriodicall
y
(
Use 2 different colors
)
.
Ex) Rotate the Color Information with 2 colors every 30 minutes.
A
void using a combination of characters and background color with large
difference in luminance.
A
void using Grey colors, which can cause Image retention easily.
zAvoid: Colors with big difference in luminance (Black & White, Grey)
Ex)
zRecommended settings: Bright colors with little difference in luminance
- Change the characters color and background color every 30 minutes
Ex)
- Every 30 minutes, change the characters with movement.

Ex)
The best way to protect your monitor from Image retention is to set your PC or
S
y
stem to o
p
erate a Screen Saver
p
ro
g
ram when
y
ou are not usin
g
it.
Image retention may not occur when a LCD panel is operated under normal conditions.
Normal conditions are defined as continuously changing video patterns. When the LCD
panel is operated for a long time with a fixed pattern (-over 12 hours-), there may be
slight difference in voltage between electrodes that work the liquid crystal (LC) in a
pixel. The voltage difference between electrodes increases with time, forcing the liquid
crystal to lean. When this occurs, the previous image may be seen when the pattern is
changed.
To prevent this, the accumulated voltage difference must be decreased.
Our LCD Monitor satisfies ISO13406-2 Pixel fault Class II

Packa
g
e Contents
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Un
p
ackin
g
Without Stand
Monitor
With Stand
Monitor & Simple stand
Manual

Quick Setup Guide
Warranty Card,
Registration Card
(Not available in all
locations)
User's Guide, Monitor Driver,
Natural Color,
MagicTuneTM
Cable
Power Cord D-sub Cable Audio Cable
Sold se
p
aratel
y
S-Video Cable RCA Cable Earphones/Headphones
Component Cable DVI Cable DVI to HDMI cable
HDMI Cable RCA to stereo (for PC) cable
This is an accessory that can be added depending on the model.
Y
our Monito
r
Front

MENU button [ ] Opens the OSD menu.
Also use to exit the OSD menu or return to the previous menu.
Adjust buttons [ ] These buttons allow you to adjust items in the menu.
PC/DVI :
MagicBright™ button
[]
MagicBright™ is a new feature providing optimum viewing environment
depending on the contents of the image you are watching. Currently six
different modes are available: Custom, Text, Internet, Game, Sports and
Movie. Each mode has its own pre-configured brightness value. You can
easily select one of six settings by simply pressing MagicBright™ control
buttons.
1) Custom
Although the values are carefully chosen by our engineers, the pre-
configured values may not be comfortable to your eyes depending on
your taste. If this is the case, adjust the brightness and contrast by
using the OSD menu.
2) Text
For documentations or works involving heavy text.
3) Internet
For working with a mixture of images such as texts and graphics.
4) Game
For watching motion pictures such as a game.
5) Sports
For watching motion pictures such as a Sports.
6) Movie
For watching motion pictures such as a DVD or Video CD.
>> Click here to see an animation clip
AV/S-Video/
Component :
Mode button
The Monitor has four automatic picture settings ("Dynamic", "Standard",
"Movie" and "Custom") that are preset at the factory. You can activate
either Dynamic, Standard, Movie, or Custom. You can select "Custom"
which automatically recalls your personalized picture settings.
1) Dynamic
Select this mode to view a sharper image than in "Standard" mode.
2) Standard
Select this mode when the surroundings are bright. This also provides a
sharp image.
3) Movie
Select this mode when the surroundings are dark.
This will save power and reduce eye fatigue.
4) Custom
Select this mode when you want to adjust the image according to your
preferences.

>> Click here to see an animation clip
Volume button [ ] When OSD is not on the screen, push the button to adjust volume.
>> Click here to see an animation clip
Enter button [ ] /
SOURCE button
Activates a highlighted menu item. /
Push the 'SOURCE', then selects the video signal while the OSD is off.
(When the SOURCE button is pressed to change the input mode, a
message appears in the upper left of the screen displaying the current
mode -- PC, DVI, HDMI, AV, S-Video and Component input signal.)
>> Click here to see an animation clip
Changing the source is only allowed for external devices that are
connected to the monitor at the time.
AUTO button (Available in PC mode only)
When the 'AUTO' button is pressed, the Auto Adjustment screen appears
as shown in the animated screen on the center.
Press to self-adjust to the incoming Analog signal. The values of
fine,coarse and position are adjusted automatically.
>> Click here to see an animation clip
PIP button ( Available in PC/DVI Mode Only )
In PC or DVI Mode, turns on Video screens in PIP Mode.
You can view a picture from HDMI (PC mode only), AV, S-Video, or
Component (DVI mode only) through the PIP screen in PC and DVI
mode.
Power button [ ] Turns the monitor On/Off.
Power indicator This will enable you to see the overall power status of the system. For more
information, see the PowerSaver section.
Speaker You can hear sound by connecting the soundcard of your PC to the
monitor.
See PowerSaver described in the manual for further information regarding power saving
functions. For energy conservation, turn your monitor OFF when it is not needed, or
when leaving it unattended for long periods.
Rea
r
The configuration at the back of the monitor may vary from product to product.
POWER
zPOWER
: Connect the power cord for your monitor to the POWER on
the back of the monitor.

HDMI/D-SUB
HDMI
: Connect the HDMI terminal at the back of your monitor to
the HDMI terminal of your digital output device using a
HDMI cable.
D-SUB
: Connect the RGB terminal at the back of your monitor to
your computer.
S-VIDEO / VIDEO / R - AUDIO - L
R - AUDIO - L
: External device sound input termina
VIDEO
: External device (video) input terminal
S-VIDEO
: External device (S-video) input terminal
PC IN
DVI-D
: Connect the DVI-D terminal at the back of your monitor to
your computer.
A
UDIO
: Connect the AUDIO (PC IN/AUDIO) terminal at the back
of your monitor to your computer’s sound card.
COMPONENT IN
R - AUDIO - L
: DVD, VCR (DVD / DTV Set-Top Box) sound input terminal
(left/right)
PR, PB,Y
: DVD / DTV Set-Top Box input terminal(PR, PB,Y)

zHeadphone output terminal
Kensington Lock
zThe Kensington lock is a device used to physically fix the
system when using it in a public place.
(The locking device has to be purchased separately.)
For using a locking device, contact where you purchase it.
See Connecting Cables for further information regarding cable connections.

Connectin
g
Cables
Connectin
g
to a Com
p
ute
r
Connect the power cord for your monitor to the power port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
Use a connection appropriate for your computer.
Using the D-sub (Analog) connector on the video card.
- Connect the signal cable to the 15-pin, D-sub port on the back of your monitor.
[ D-SUB ]
Using the DVI (Digital) connector on the video card.
- Connect the DVI Cable to the DVI-D Port on the back of your Monitor.
[ DVI-D ]
Connect the AUDIO terminal at the back of the monitor to the speaker output terminal on your
computer’s sound card using a sound cable.
Connectin
g
to a Macintosh

Connected to a Macintosh.
Connect the monitor to the Macintosh computer using the D-sub connection cable.
[ RGB ]
Connectin
g
to Other devices
This monitor allows the user to connect it to such input devices as a DVD player, a VCR
or a camcorder without disconnecting the PC.
The configuration at the back of the monitor may vary from product to product.
Connectin
g
AV Devices
The monitor has AV connection terminals to connect AV input devices like DVD, VCR or
Camcorder. You may enjoy AV signals as long as the monitor is turned on
Input devices such as DVD, VCR or Camcorder are connected to the RCA or S-VIDEO terminal
of the monitor using the RCA or S-Video cable.
Connect the port of the DVD, VCR (DVD / DTV Set-Top Box) to the R-AUDIO-L port of the
monitor.
Then, start the DVD, VCR or Camcorder with a DVD disc or tape inserted.
Select AV or S-Video using the SOURCE.
In some areas, the image might slant to the side depending on the input broadcast signal.
