RICHTECH PITBOSS SSBOS12 User manual

12V DC BATTERY
BACKUP SUMP
PUMP SYSTEM
SSBOS12
INSTALLATION AND OPERATING INSTRUCTIONS
A RICHTECH INDUSTRIES PRODUCT
15'
LIFT
10'
LIFT
5'
LIFT
PUMP PERFORMANCE
The PitBoss Battery Backup System is designed to
automatically remove water from a sump pit during
a power outage or if the primary sump pump fails
to operate properly.
The PitBoss Battery Backup System is not intended
as a long term replacement for a primary sump
pump. This unit must be installed with a working
primary sump pump.
This complete kit includes a high performance DC
sump pump, solid state system controller, oat
sensor and battery case.
SAVE THESE IMPORTANT SAFETY INSTRUCTIONS!
READ ALL INSTRUCTIONS CONTAINED IN THIS MANUAL BEFORE USING THIS PRODUCT.
Save these instructions for future reference. Failure to read and follow the warnings and instructions
within this instruction manual could result in property damage, serious injury or death.
1860
GALLONS/HR
2580
GALLONS/HR
3150
GALLONS/HR

©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM
2
SAFETY FIRST!
READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
RISK OF ELECTRIC SHOCK. TO REDUCE THIS RISK, OBSERVE THE FOLLOWING
WARNINGS:
WARNING! To reduce the risk of electrical shock, this pump must be properly grounded in accordance with the
National Electric Code (NEC) and all applicable state and local codes and ordinances. The receptacle should be
protected with a Ground Fault Circuit Interrupter (GFCI).
WARNING! To reduce the risk of electrical shock, always disconnect the pump from the power source BEFORE
handling or servicing.
WARNING! Never remove the ground prong from the plug, or use an adapter that eliminates the ground prong.
WARNING! Never plug this pump into an electric outlet while standing on a wet surface.
WARNING! Cable should be protected at all times to avoid punctures, cuts and abrasions that may result in
exposed wiring. Never handle connected power cords with wet hands.
WARNING! This Submersible Sump Pump has not been investigated for use in or around swimming pools,
marine areas, recreational water installations, decorative fountains or any installation where human contact with
the pumped uid is common.
WARNING! Do not use an extension cord. Extension cords could present a safety hazard if not properly sized,
become damaged or the connection falls into the sump pit.
NOT SUITED FOR POTABLE WATER APPLICATIONS.
WARNING! Do not use this pump to transfer water that will be used for potable
(drinking) water. This pump is only to be used in applications for which it is designed.
WARNING! Do not use to pump ammable or explosive liquids such as gasoline, fuel oil, kerosene, etc.
WARNING! Do not use in a ammable or explosive atmosphere.
TO REDUCE THE RISK OF HAZARDS THAT CAN CAUSE INJURY OR PROPERTY DAMAGE,
OBSERVE THE FOLLOWING WARNINGS:
CAUTION! Do not block or restrict discharge hose. Discharge hose may whip under pressure. It is strongly
recommended to use rigid piping and ttings to secure the pump in the sump basin to reduce movement.
CAUTION! Do not install the pump if it has been damaged in any way.
CAUTION! Do Not carry or lift the pump by the power cord. Use the pump’s lift ring.
CAUTION! For indoor use only.
CAUTION! This pump is designed to pump ground water only. Do not drain washing machines or other
appliances into the sump pit. This will void your warranty.
CAUTION! Do not attempt to disassemble any part of the system. There are no user-serviceable parts or
repair options.
WARNING WARNING INDICATES A POTENTIALLY HAZARDOUS
SITUATION WHICH, IF NOT AVOIDED, COULD RESULT IN
DEATH, SERIOUS INJURY OR MAJOR PROPERTY DAMAGE.
CAUTION INDICATES A POTENTIALLY HAZARDOUS SITUATION
WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR INJURY OR
PROPERTY DAMAGE.
WARNING
RISK OF EXPLOSION. TO REDUCE THIS RISK, OBSERVE THE
FOLLOWING WARNINGS:

©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM 3
This system is designed to operate reliably with an
SLA Deep Cycle Marine Battery (not included).
The use of an AGM battery is strongly recommended.
The use of wet-cell batteries is strongly discouraged.
Automotive batteries are not suitable for this
application and will result in system failure.
WARNING: TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR INJURY:
• WEAR SAFETY GLASSES WHEN CONNECTING OR
DISCONNECTING THE BATTERY.
• KEEP SPARKS AND FLAMES AWAY FROM THE
BATTERY.
• KEEP METAL TOOLS FROM CONTACTING THE
BATTERY POSTS AND CREATING A SHORT
ACROSS THE TERMINALS. A SHORT CIRCUIT MAY
CAUSE AN EXPLOSION.
• FOLLOW ALL INSTRUCTIONS PUBLISHED BY THE
BATTERY MANUFACTURER. FAILURE TO DO SO
MAY RESULT IN PROPERTY DAMAGE, SERIOUS
INJURY OR DEATH.
The Pitboss Battery Backup System displays system information on the
Message Center. There are two types of messages: Informational and
Alarms.
Informational messages do not require immediate attention and do not
sound an alarm. If more than one message is active, they rotate on the
display.
Alarm messages require your immediate attention and will sound the
unit’s audible alarm. If more than one alarm is active, they rotate on the
display. Alarm messages take precedence over information messages,
no informational messages are displayed when there is an active alarm.
The Pitboss Battery Backup System is an automatic
system and will automatically operate during a power
outage or when the primary sump pump fails to
operate. The System automatically maintains and
recharges the battery.
The Pitboss Battery Backup System performs a full
system test once per week. The system will cycle
the backup pump and test the battery performance.
If any issues are found during the self test, the
appropriate alarm message will be displayed, and the
audible alarm will be activated.
The Pitboss Battery Backup System features two
push buttons on the controller.
The PUMP TEST button activates the backup pump.
The pump will continue to run as long as the button
is pressed. Do not run the backup pump in a dry
sump pit for extended periods.
The ALARM MUTE button will silence the audible
alarm for 24 hours when pressed. It will also clear
the alarm message from the LCD screen, so take
note of the cause of the alarm. If the same alarm
repeats during the 24 period, the audible alarm will
not sound. If a different alarm is triggered during
this period, the audible alarm will sound. Pressing
the alarm mute button a second time will cancel the
alarm mute.
To activate the weekly system test, press and hold
the ALARM MUTE button. This will activate the full
system test sequence.
INFORMATIONAL MESSAGES
System OK Displayed when no messages
active or after alarm muted. System is working properly
Pump
Running
Displays when the pump is on,
showing in seconds the length
of time the pump is on.
System is working properly
AC Power
Failure Displayed if AC power is lost.
Check that unit is plugged in.
Check GFI/breaker for trip.
Normal during power loss.
ALARM MESSAGES
Reverse
Polarity
Battery Red/Black leads are
connected backwards. Connect leads to correct terminals.
PWR OK/
Backup On
Backup pump is on while AC
power is present.
Check primary sump pump for
proper operation. Replace sump
pump if necessary.
CHECK
PUMP
Backup pump active but no
current draw is detected.
Check that pump cord is rmly
connected to controller jack. Call
for service.
Batt Low
Voltage
Battery voltage drops below
11.4 volts (50% discharged).
Check that unit is plugged in. Check
GFI/breaker for trip. Normal during
extended power loss.
Batt Crit
Voltge
Battery voltage drops below
10.4 volts (90% discharged).
Check that unit is plugged in.
Check GFI/breaker for trip. Replace
battery if power remains out.
Auto Test
Failed
System fault detected
during system self-test.
Alarm message will be
displayed alternately.
Correct the issue in the displayed
alarm message.
Excessive
Runtime
Backup pump has run more
than 50 seconds.
Check that backup oat sensor can
move freely, not caught on wires.
Normal during extremely heavy
rains.
Check
Fuse / Batt Blown Fuse
Check that pump cord is rmly
connected to controller jack. Call
for service.
Batt Not
Detected No battery is detected. Check battery connections. Replace battery if necessary.
BATTERY INFORMATION
SYSTEM OPERATION
USING THE
CONTROLLER BUTTONS
MESSAGES

©2021 RICHTECH INDUSTRIES 1.800.677.7791 RICHTECHINDUSTRIES.COM
4
Richtech Industries Three Year Limited Warranty
WHAT THIS WARRANTY COVERS
When used and maintained in normal use and in accordance with the Installation and Operating Instructions,
your PitBoss Battery Backup System product is warranted against original defects in material and
workmanship for a full three years from date of installation (the “Warranty Period”). During the warranty period,
Richtech Industries will repair or replace at no cost to you, to correct such defects in products found upon
examination by Richtech Industries to be defective in materials or workmanship.
WHAT THIS WARRANTY DOES NOT COVER
This warranty does not cover use of the product in a non-residential application, improper installation and/
or improper maintenance of the product, damage due to misuse, acts of God, nature, vandalism or other acts
beyond the control of Richtech Industries, owner’s acts or omissions, use outside the country in which the
product was initially purchased and resales of the product by the original owner. This warranty does not cover
pick up, delivery, transportation or house calls. However, if you ship your product to Richtech Industries for
warranty service, cost of shipping will be paid one way. This warranty does not cover products purchased from
a party that is not an authorized retailer, dealer, or distributor of PitBoss Battery Backup System products.
OTHER IMPORTANT TERMS
This warranty is not transferable and may not be assigned. This warranty shall be governed and construed
under the laws of the state of Ohio. The warranty period will not be extended by any replacement or repair
performed under this warranty. THIS WARRANTY IS THE EXCLUSIVE WARRANTY AND REMEDY PROVIDED
BY RICHTECH INDUSTRIES. ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES
OR MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT WILL
RICHTECH INDUSTRIES BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND OR NATURE TO OWNER OR ANY PARTY CLAIMING THROUGH OWNER WHETHER
BASED IN CONTRACT, NEGLIGENCE, TORT OR STRICT PRODUCTS LIABILITY OR ARISING FROM ANY CAUSE
WHATSOEVER. Some states do not allow for the exclusion of consequential damages, so the above exclusion
may not apply to you. This warranty gives you specic rights. You may also have others that vary state to state.
RICHTECH INDUSTRIES
34000 LEAR INDUSTRIAL PARKWAY
AVON, OHIO 44011
[phone]
82206-03
A RICHTECH INDUSTRIES PRODUCT
34000 LEAR INDUSTRIAL PARKWAY AVON, OH 44011 | RICHTECHINDUSTRIES.COM | 800.677.7791
A RICHTECH INDUSTRIES PRODUCT
Installer:
Date of Installation:
Serial Number:
