Cabinet
Pipari 180
Important – Please read these instructionsfully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Assembly Instructions - Please keep for future reference
132/0284
132/3384
132/3377
132/7919
132/7926
132/0318
132/0325
132/0301
132/0291
132/0277
132/0260
132/0253
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
Issue 3 - 19/02/13
DR82506
132/0253 OAK
132/0260 WAL
132/0277 WHT
132/0291 BLK GLOSS
132/0301 WHT GLOSS
132/0318 OAK
132/0325 WAL
132/7919 WHT GLOSS MIRROR
132/7926 BLK GLOSS MIRROR
132/3384 WAL FOIL MIRROR
132/3377 OAK FOIL MIRROR
132/0284 MIRROR
Doors
Mirror doors
Dimensions
Width - 180cm
Depth - 59.5cm
Height - 199.8cm

2
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
pages 3,4 and 5.
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
•This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Care and maintenance
Skin contact: Remove
contamination by washing with
soap and water. This procedure
should also be followed prior to
eating and drinking.
Eye contact: Rinse immediately
with clean water for 15 minutes
and seek medical advice.
If swallowed: Seek medical
advice immediately.
Glue safety - Take care when using glue, please follow the advice below

Cabinet
Components - Panels
Please check you have all the panels listed below
3
Left side
(199.8 x 52.9cm)
1
P2883
Right side
(199.8 x 55.8cm)
2
P2882
Upright
(190.3 x 49cm)
3
P2886
Back x2
(193 x 89cm)
4
BO3431
Bottom
(177 x 51.1cm)
6
P1897
Top
(177 x 51cm)
5
P1896
Shelf x2
(87.7 x 48.8cm)
8
P1898
Plinth x2
(177 x 6cm)
7
P7241
Segment middle x2
(91.5 x 65.1cm)
10
P3270/FA3270
Segment x4
(91.5 x 65cm)
9
P3269/FA3269
132/0325
132/0318
132/7919
132/7926
132/3377
132/3384
132/0291
132/0301 Doors
Mirror doors
Segment middle x2(91.5 x 65cm)
14
PS3276
Segment x4 (91.5 x 65cm)
13 PS3275
132/0284 Mirror doors
Segment middle x1
(91.5 x 65.1cm)
10
P3270/FA3270
Segment x2
(91.5 x 65cm)
9
P3269/FA3269
Segment middle x1
(91.5 x 65.1cm)
12
PS3274
Segment x2
(91.5 x 65cm)
11
PS3273
Finishing prole x 4, plastic (883mm)
XPK1902

4
Please check you hav tings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
Components - Fittings If you have damaged or missing components,
call the Customer Helpline: 0845 6400800
1/2
Locking screw x 18 (5x24mm)
BFK1011
Screw x 34 (4x15mm)
CFK1400
Conrmat screw x 4 (5x40mm)
AFK1005
Plug, Nylon x 32 (5x9mm)
EFK1082
Nail x 60
FFK1515
Screw x 81 (4x12.5mm)
DFK1309
Wood dowel x 8 (8x30mm)
HFK1411
Large locking nut x 24 (15x12mm)
IFK1012
15mm
Double locking screw x 3 (5x66.5mm)
GFK1052
Hanger rail support, gray x 4
KFK1217
Peg, brown x 2
LFK1234
Corner connector, white x 2
JFK1248
Nail holder x 1
NFK1419
Connecting plate x 8
OFK1236
L-Bracket x 1
MFK1235
Guide rail x 1, metal (1769mm)
QPM1611
Guide rail x 1, plastic(1769mm)
RPK1611
Hanger rail x 2
PPM1877
(869mm)
Brush x 3 (1951mm)
TPM1652C
Door trim x 1 (1951mm)
UPM1652D
Door handle x 3 (1951mm)
SPM1652B
Wall plug (6mm) and parkerscrew x 1
WZF99936
Allen key x 1 (3mm)
VFK1013
OR

Please check you hav tings listed below
Ruler - Use this ruler to help correctly identify the screws
Tools required
Note: The quantities below are the correct amount to complete the assembly. In some cases more
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Components -Fittings If you have damaged or missing components,
call the Customer Helpline: 0845 6400800
Phillips screwdriver
(medium & large)
Flatblade screwdriver
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or drill)
5mm Suitable drill bit
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
Stairs
Piercer Scissors
(medium)
(small)
Level ruler
Setsquare
5
2/2
Screw x 33 (4x15mm)
AC ZF9997L
Screw x 13 (3.5x25mm)
AB ZF9997K
Screw x 2 (3.5x35mm)
AA ZF9997I
Tapping block for guide rail x 2
AF ZF9997E
Screw x 2 (4x14mm)
AD ZF9997J
Stop guide rail x 2
AH ZF9997H
Front guide part x 2
AI ZF9997C
Spacer x 1
AE ZF9997F
End stop x 2
AG ZF9997G
Sliding door connecting plate x 2
AK ZF9997B
Sliding door connecting bracket x 2
AL ZF9997A
Back guide part x 2
AJ ZF9998D
A
AM
NO Gap! NO Gap!

6
Assembly Instructions
Step 1
Cabinet assembly
a: Screw 9 locking screws
Binto the holes on back of
the left side 1.
Mount hanger rail support
K, fasten with 1 screw D.
Screw Dinto the board
between two predrilled
holes.
Mount tapping block for
guide rail fwith two
screws b.
b: Screw 9 locking screws
Binto the holes on back of
the right side 2.
Mount hanger rail
support K, fasten with 1
screw D. Screw Dinto the
board between two
predrilled holes.
Mount tapping block for
guide rail fwith two
screws b.
C: Mount hanger rail
support Kon the
upright 3, fasten with
screw D1x. Screw Dinto
the board between two
predrilled holes
Turn upright.
Mount hanger rail
support Kon the
upright 3, fasten with
screw D1x. Screw Dinto
the board between two
predrilled holes.
K
D
1
Finished
front edge
a:
AF
AB
K
D
2
AF
AB
Finished
front edge
b:
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
K
D
3
Finished
front edge
c:
D
K
AF
AB AB
AB
AB
AF

7
Assembly Instructions
Step 1
Cabinet assembly
d: Insert 6x small locking
nuts Iinto the top 5.
Make sure the ‘arrow’ on I
is pointing towards the hole
in the edge of the top 5.
e: Insert 6x small locking
nuts Iinto the bottom 6.
Make sure the ‘arrow’ on I
is pointing towards the hole
in the edge of the
bottom 6.
f: Insert 6x small locking
nuts Iinto the shelf 6.
2x.
Make sure the ‘arrow’ on I
is pointing towards the hole
in the edge of the
bottom 6.
g: Insert 4x wooden dowels
Jinto the plinth 7.
2x.
plain chipboard
Finished
front edge
d:
Finished
front edge
Finished
front edge
e:
f:
Finished
front edge
g:
2x
2x
5
6
8
7
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
H
H

8
Assembly Instructions
Step 1
Cabinet assembly
h: Attach top 5with 2x
conrmat screws Ato the
upright 3. Use allenkey V.
Attach bottom 6with 2x
conrmat srews Ato the
upright 3.
i: Attach 2x the shelf 8to
the upright 3with 3x
double locking screws G.
Use a screwdriver to turn 6x
locking nuts clockwise to
lock.
j: Attach the left side 1
with 9x double locking
screws Gon the top 5,
shelf 8and the bottom 6.
Use a screwdriver to turn 9x
locking nuts clockwise to
lock.
V
G
G
G
6
3
1
8
8
5
5
Plain chipboard
Plain chipboard
Plain chipboard
Finished
front edge
h:
Finished
front edge
Finished
front edge
i:
j:
3
6
5
A
A
A
3
8
8
6

Assembly Instructions
Step 1
Cabinet assembly
k:Attach 2x the plinth 7
between the left site 1
and the right side 2.
Note: that the nished side
is properly placed.
Attach the right side 2
with 9x double locking
screws Gon the top 5,
shelf 8and the bottom 6.
Use a screwdriver to turn 9x
locking nuts clockwise to
lock.
Mount corner connector J
with 2 screws Con the
plinth 7and bottom 6.
l: Attach 2x foldy back 4
to back of cabinet with
the coloured surface facing
the inside of the cabinet
using 60x nails Fand
26x screws C.
Use nail holder Nto hold the
nails Fvertical and at
correct distance as you
secure the 2x foldy back 4.
Nails Fshould be spaced
about 150mm apart.
Stand up the unit!
Important:
Cabinet MUST be
‘square’ when
back is attached.
Finished
front edge
k:
Finished
front edge
J
J
C
C
F
F
F
Finished side
l:
J
C
C
7
6
7
7
6
2
8
2
5
4
4
N
6
2
F
C
N
F
9

Assembly Instructions
Step 1
Cabinet assembly
m: Position L-Bracket M
onto top 5, by using 1x
screw C.
Position metal guide rail Q
onto top 5, x with 7x
screws C.
Attach 2x end stop gon
the end of the guide rail Q
with 2x screws d.
Place 2x hanger rail Pinto
hanger rail support K.
n: Position plastic guide rail
Ronto bottom 6, x
with 9x screws b.
Attach 2x stop guide rail
hon the end of the guide
rail R, mount with 2x
screws a.
AD
m:
P
P
n:
AG
AG
M
C
C
C
C
C
C
C
C
Q
AH
AH
AB
AB
AB
AB
AB
AA
AA
R
10
8
8
1
2
3
1
2
3
6
5
AD
Q
AD
AG
Q
A
x2 x7
BC
x7
C
P
K
AB
AA
R
6
7
x9
B
A
D
C
x10
AH
. . . . . . .
x x
R

9
/
11
9
/
11
9
/
11
9
/
11
9
/
11
9
/
11
10
/
12
/@
Assembly Instructions
Step 2
3 Segment slide door left
a: Put 8x nylon plug Einto
the segment 9/!.
Use a small hammer.
Repeat this step.
c: Mount segment middle
0/@with 3x screws D
on door trim U.
Mount segment 9/!with
4x screws Don
door trim U.
b: Mount door trim Uwith
3x screws Don segment
9/!.
Note: there should be no
gap between doorsegment
9/!and door trim U.
(See m.)
d: Mount door handle S
on segment 9/!with 4x
screws Dand on middle
segment 0/@with 3x
screws D.
Note: there should be no
gap between doorsegment
9/!and door handle S.
(See m.)
a:
2x
11
132/0325
132/0318
132/0301
132/0291
132/3384
132/3377
132/7926
132/7919
E
E
b:
c:
d:
U
U
S
10
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
Doors
Mirror doors
AM
NO Gap! NO Gap!

Assembly Instructions
Step 2
3 Segment slide door left
e: Mount 4x connecting
plate O, each with 2x
screws Don segment
9/!and 2x screws D
on middle segment 0/@.
Remove protective lm from
door handle S.
Stick 1x brush Tonto
door handle Sby partially
remove the cover from
adhease as brush is applied.
f: Upside.
Mount 2x Sliding door
connecting plate k
squarely by using the guide-
marks in the plate k,
each with 6x screws c
on segment 9/!.
Attach 1x spacer ewith
1x screw con the
sliding door connecting
plate k.
g: Underside.
Mount 2x back guide
part j, each with 2x
screws con segment
9/ !.
/
11
/
11
x2
AJ
AC
YY
AK
AC
AC
x4
AK
AK
AC
AC
AC
AC
AC
9
9
9
AJ
AJ
AC
AC
AC
AC
e:
132/0325
132/0318
132/0301
132/0291
132/3384
132/3377
132/0349
132/0332
Doors
Mirror doors
f:
g:
12
T
O
O
D
D
D
D
S
10
9
AE
O
O
D
D
D
D
11
/
/
12
/
11
132/3384
132/3377
132/7926
132/7919
Mirror doors
Please remove
the protective film!
S
T
20cm
20cm

Assembly Instructions
Step 2
3 Segment slide door left
a: Put 8x nylon plug Einto
the segment #. Use a small
hammer.
Repeat this step.
c: Mount segment middle
$with 3x screws D
on door trim U.
Place 1x nishing prole
Xon segment $.
Mount segment #with 4x
screws Don door trim U.
Place 1x nishing prole
Xon segment @.
b: Mount door trim Uwith
3x screws Don segment
#. Place 1x nishing prole
Xon segment #.
Note: there should be no
gap between doorsegment
#and door trim U.
(See m.)
d: Mount door handle S
on segment #with 4x
screws Dand on middle
segment $with 3x
screws D.
Note: there should be no
gap between doorsegment
#and door handle S.
(See m.)
a:
2x
X
X
13
132/0284
E
E
b:
c:
d:
U
U
S
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
13
13
13
14
13
13
14
13
Mirror doors
Important: follow these instructions for cat no:

Assembly Instructions
Step 2
3 Segment slide door left
e: Mount 4x connecting
plate O, each with 2x
screws Don segment #
and 2x screws Don middle
segment $.
Remove protective lm from
door handle S.
Stick 1x brush Tonto
door handle Sby partially
remove the cover from
adhease as brush is applied.
f: Upside.
Mount 2x Sliding door
connecting plate k
squarely by using the guide-
marks in the plate k,
each with 6x screws c
on segment #.
Attach 1x spacer ewith
1x screw con the
sliding door connecting
plate k.
g: Underside.
Mount 2x back guide
part j, each with 2x
screws con segment
#.
AK
AK
AC
AC
AC
AC
AC
AJ
AJ
AC
AC
AC
AC
e:
132/0284
Mirror doors
f:
g:
14
T
O
D
D
S
AE
O
O
D
D
D
D
O
D
D
13
14
13
13
13
x2
AJ
AC
AC
x4
Please remove
the protective film!
S
T

13
14
13
Assembly Instructions
Step 3
Place left slide door
a: Hook the 2x back guide
part jinto the plastic
guide rail R.
a: Detail.
The hook of the back guide
part jshould be in the
front guide of the plastic
guide rail R
a:
15
9
/
12
9
/
/
10
AJ
AJ
R
R
R
11
11

Assembly Instructions
Step 3
Place left slide door
b: Hook Sliding door
connecting platek
on metal guide rail Q.
b: Detail.
The wheel of the sliding door
connecting plate kshould
be in the front guide of the
metal guide rail Q.
To lock the door, lock the
Sliding door connecting
plate kon the guide railQ
with the locking pawl.
16
13
14
13
push the yellow
lock pin to
secure part kto rail
9
/
/
10
9
/
12
b:
Q
Q
Q
Q
AK
AK
AK
11
11

Assembly Instructions
Step 4
3 Segment slide door right
a: Put 8x nylon plug Einto
the segment 9/!.
Use a small hammer.
Repeat this step.
c: Mount segment middle
0/@with 3x screws Don
door handle S.
Mount segment 9/!with
4x screws Don door
handle S.
b: Mount door handle S
with 4x screws Don
segment 9/!.
Note: there should be no
gap between doorsegment
9/!and door handle S.
(See m.)
d: Mount door handle S
on segment 9/!with 4x
screws Dand on middle
segment 0/@with
3x screws D.
Note: there should be no
gap between doorsegment
9/!and door handle S.
(See m.)
17
/
12
/
12
a:
E
E
9
9
9
9
9
c:
d:
S
S
S
10
10
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
2x
132/0325
132/0318
132/0301
132/0291
132/3384
132/3377
132/7926
132/7919
b:
Doors
Mirror doors
9
/
11
/
11
/
11
/
11
/
11
/
11

Assembly Instructions
Step 4
3 Segment slide door right
e: Mount 4x connecting
plate O, each with 2x
screws Don
segment 9/!and
2x screws Don middle
segment 0/@.
Remove protective lm from
door handle S.
Stick 2x brush Tonto 2x
door handle Sby partially
remove the cover from
adhease as brush is applied.
f: Upside.
Mount 2x sliding door
connecting bracket l
squarely by using the guide-
marks in the plate l,
each with 6x screws c
on segment 9/!.
g: Underside.
Mount 2x front guide
part i, each with 2x
screws con
segment 9/!.
18
x2
AC
AI
9
T
O
O
D
D
D
D
S
10
9
O
O
D
D
D
D
T
/
11
/
11
AC
AC
AC
AC
AC
AC
9
9
AC
AC
AC
AC
e:
132/0325
132/0318
132/0301
132/0291
Doors
132/3384
132/3377
132/7926
132/7919
Mirror doors
f:
g:
AL
AL
AL
AI
AI
/
12
/
11
/
11
Please remove
the protective film!
S
T
20cm

19
Assembly Instructions
Step 4
3 Segment slide door left
a: Put 8x nylon plug Einto
the segment #. Use a small
hammer.
Repeat this step.
c: Mount segment middle
$with 3x screws D
on door trim S.
Place 1x nishing prole
Xon segment $.
Mount segment #with 4x
screws Don door trim U.
b: Mount door trim Swith
3x screws Don segment
#. Place 1x nishing prole
Xon segment #.
Note: there should be no
gap between doorsegment
#and door handle S.
(See m.)
d: Mount door handle S
on segment #with 4x
screws Dand on middle
segment $with 3x
screws D.
Note: there should be no
gap between doorsegment
#and door handle S.
(See m.)
a:
2x
X
X
132/0284
E
E
b:
c:
d:
S
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
13
13
Mirror doors
13
13
13
13
14
14
S
S
Important: follow these instructions for cat no:

20
Assembly Instructions
Step 4
3 Segment slide door right
e: Mount 4x connecting
plate O, each with 2x
screws Don segment #
and 2x screws Don middle
segment $.
Remove protective lm from
door handle S.
Stick 2x brush Tonto 2x
door handle Sby partially
remove the cover from
adhease as brush is applied.
f: Upside.
Mount 2x sliding door
connecting bracket l
squarely by using the guide-
marks in the plate l,
each with 6x screws c
on segment #.
g: Underside.
Mount 2x front guide
part i, each with 2x
screws con segment #.
AC
AC
AC
AC
AC
AC
AC
AC
f:
g:
AL
AL
AI
AI
13
13
e:
132/0284
Mirror doors
T
O
D
D
S
O
O
D
D
D
D
O
D
D
13
14
13
T
x2
AC
AI
Please remove
the protective film!
S
T
