Roberine F3 User manual

User Manual
Mower
F3 and R3
roberine.com
© Roberine 2019Translation of the original manual Version V1.1

NOTICE Keep the details on the type plate somewhere safe. If you have any questions about your machine or
if you wish to order a component, the information on the type plate will help us to provide quick and effective
assistance.
NOTICE Read this instruction manual carefully. Failure to do so may result in serious injury or damage to the
machine. Keep this manual in a safe place. Always make sure the people who use the machine or carry out
maintenance on it have read the manual and understand the instructions.
All rights reserved. No part of this publication may be reproduced, stored in a computerised data file and/or published
in any way whatsoever, not electronically, mechanically, by photocopying or in any other way, without prior written
permission from Roberine. This also applies to the accompanying drawings and diagrams.
Roberine reserves the right to alter components at any given time without giving the purchaser prior or immediate notification. The contents of this manual
can also be updated without prior warning. Please contact your supplier’s Technical Service for information on adjustment, maintenance or repair which is
not covered in this manual. Or see the maintenance manual, which you have also received. This user manual has been produced with the greatest of care.
Roberine cannot, however, be held liable for any errors in this publication or their consequences.

Table of contents
1 Preface.............................................................................................................................. 6
1.1 Who is this manual intended for?............................................................................................................................ 6
1.2 Scope of this manual............................................................................................................................................... 6
1.3 Storing the manual................................................................................................................................................... 6
1.4 Manufacturer details................................................................................................................................................. 6
1.5 Guarantee and liability..............................................................................................................................................7
1.6 Trademarks............................................................................................................................................................... 7
1.7 Statutory standards and regulations........................................................................................................................ 7
1.8 Recommissioning...................................................................................................................................................... 7
1.9 Version history.......................................................................................................................................................... 7
2 Safety................................................................................................................................ 8
2.1 Safety messages...................................................................................................................................................... 8
2.2 Hazards.....................................................................................................................................................................8
2.2.1 Mowing units....................................................................................................................................................8
2.2.2 Protect children................................................................................................................................................8
2.2.3 Avoid roll over..................................................................................................................................................9
2.2.4 Avoid pressurised liquids.................................................................................................................................9
2.2.5 Tyres................................................................................................................................................................ 9
2.3 General safety instructions..................................................................................................................................... 10
2.4 Safety signs............................................................................................................................................................ 11
2.5 Safety features........................................................................................................................................................12
2.5.1 Safety mechanisms....................................................................................................................................... 12
2.5.2 Emergency stop.............................................................................................................................................13
2.6 Instructions to the driver.........................................................................................................................................13
2.7 Parking safely......................................................................................................................................................... 13
2.8 Personal protective equipment............................................................................................................................... 14
2.9 Environmental aspects........................................................................................................................................... 14
2.9.1 Disposal......................................................................................................................................................... 14
2.9.2 REACH declaration........................................................................................................................................14
2.9.3 End of life disposal........................................................................................................................................ 14
3 Introduction.................................................................................................................... 15
3.1 Mowing....................................................................................................................................................................15
3.2 Type plate of your machine....................................................................................................................................15
3.3 Engine..................................................................................................................................................................... 15
4 Description..................................................................................................................... 16
4.1 Equipment............................................................................................................................................................... 16
4.1.1 Description mower F3................................................................................................................................... 16
4.1.2 Description mower R3................................................................................................................................... 17
4.2 Engine compartment...............................................................................................................................................17
4.3 Cabin.......................................................................................................................................................................18
4.4 Seat.........................................................................................................................................................................19
4.5 Driver's compartment..............................................................................................................................................20
4.5.1 Command arm............................................................................................................................................... 21
5 Technical specifications............................................................................................... 22
6 Commissioning.............................................................................................................. 24
6.1 Before first use....................................................................................................................................................... 24
6.1.1 Adjusting the seat..........................................................................................................................................24
6.1.2 Adjusting the steering wheel......................................................................................................................... 24
Table of contents 3

6.1.3 Use the correct type of fuel (diesel)..............................................................................................................25
6.2 Testing the safety system.......................................................................................................................................26
6.2.1 The parking brake......................................................................................................................................... 26
6.2.2 Testing the mowing switch............................................................................................................................ 27
6.2.3 Testing the parking brake (1)........................................................................................................................ 27
6.2.4 Testing the seat mechanism..........................................................................................................................27
6.2.5 Testing the drive pedal neutral position........................................................................................................ 28
6.2.6 Testing the parking brake (2)........................................................................................................................ 28
6.3 Daily checks before use......................................................................................................................................... 28
7 Operating........................................................................................................................ 29
7.1 Starting the engine................................................................................................................................................. 29
7.1.1 Use of the hand throttle................................................................................................................................ 29
7.1.2 Turning on the engine................................................................................................................................... 29
7.1.3 Turning off the engine................................................................................................................................... 30
7.2 Driving..................................................................................................................................................................... 30
7.2.1 Cruise control.................................................................................................................................................30
7.3 Operating the mowing units................................................................................................................................... 31
7.3.1 Before you start mowing............................................................................................................................... 31
7.3.2 Lowering the mowing units............................................................................................................................31
7.3.3 Raising the mowing units.............................................................................................................................. 32
7.3.4 Cross cut option............................................................................................................................................ 32
7.3.5 Adjusting the cutting height........................................................................................................................... 32
7.4 Use of the weight transfer system......................................................................................................................... 33
7.5 Operating the free-wheeling mechanism................................................................................................................34
7.6 After operating the machine................................................................................................................................... 36
8 Maintenance................................................................................................................... 37
8.1 The bonnet..............................................................................................................................................................37
8.2 The hour meter.......................................................................................................................................................37
8.3 Maintenance intervals............................................................................................................................................. 37
8.3.1 After the first 5 hours.................................................................................................................................... 38
8.3.2 Daily maintenance......................................................................................................................................... 38
8.3.3 After the first 50 hours.................................................................................................................................. 38
8.3.4 Every 50 hours.............................................................................................................................................. 39
8.3.5 Every 250 hours............................................................................................................................................ 39
8.3.6 Every 500 hours or once a year................................................................................................................... 39
8.3.7 Every 1,000 hours......................................................................................................................................... 40
8.3.8 Every 1,500 hours or every 2 years............................................................................................................. 40
8.3.9 Every 2,000 hours or every 2 years............................................................................................................. 40
8.3.10 Every 3,000 hours or every 3 years........................................................................................................... 40
8.4 Lubrication...............................................................................................................................................................40
8.4.1 Lubricants.......................................................................................................................................................40
8.4.2 Lubrication points...........................................................................................................................................41
8.5 Engine oil................................................................................................................................................................ 42
8.5.1 Checking the engine oil level........................................................................................................................ 42
8.5.2 Changing the engine oil and filter................................................................................................................. 43
8.6 Cleaning the air intake grill and engine cooler...................................................................................................... 44
8.7 Checking the air resistance indicator..................................................................................................................... 44
8.8 Cleaning the dust unloading valve......................................................................................................................... 45
8.9 Cooling system....................................................................................................................................................... 45
8.9.1 Checking the coolant level............................................................................................................................ 45
8.10 Fuel filter and fuel/water separator...................................................................................................................... 46
8.11 V-belt..................................................................................................................................................................... 48
8.12 Transmission and hydraulic oil............................................................................................................................. 49
8.13 Cleaning the mowing units................................................................................................................................... 49
8.14 Checking and replacing the flails......................................................................................................................... 50
8.15 Maintaining the reels............................................................................................................................................ 51
Table of contents 4

8.15.1 Checking the mowing units......................................................................................................................... 51
8.15.2 Adjusting the cutting knife to the bed knife.................................................................................................52
8.15.3 Adjusting the grass deflector and scraper.................................................................................................. 52
8.15.4 Back lapping the cutting knives...................................................................................................................52
8.16 Maintaining the electrical system......................................................................................................................... 55
8.16.1 Battery..........................................................................................................................................................55
8.16.1.1 Checking the battery.......................................................................................................................... 55
8.16.1.2 Replacing the battery......................................................................................................................... 56
8.16.1.3 Cleaning the battery terminals........................................................................................................... 56
8.16.2 Replacing the light bulbs............................................................................................................................. 56
8.16.3 Replacing fuses........................................................................................................................................... 59
8.16.4 Replacing relays.......................................................................................................................................... 62
8.17 Checking the wheel bolts..................................................................................................................................... 64
8.18 Cleaning surfaces................................................................................................................................................. 64
8.19 Refuelling.............................................................................................................................................................. 65
9 Transport and storage.................................................................................................. 66
9.1 Transport................................................................................................................................................................. 66
9.2 Preparing the machine for storage.........................................................................................................................67
9.3 Preparing the fuel and engine for storage............................................................................................................. 68
10 Recommissioning........................................................................................................ 69
10.1 Safety checks....................................................................................................................................................... 69
10.2 Tyre checks...........................................................................................................................................................69
11 Troubleshooting........................................................................................................... 70
11.1 Safety problems.................................................................................................................................................... 70
11.2 Engine problems................................................................................................................................................... 70
11.3 Electrical problems................................................................................................................................................73
11.4 Vehicle problems...................................................................................................................................................74
11.5 Steering problems.................................................................................................................................................74
11.6 Hydraulic problems............................................................................................................................................... 75
11.7 Driving problems................................................................................................................................................... 76
11.8 Mowing units problems......................................................................................................................................... 76
12 Warranty conditions.................................................................................................... 77
13 Appendices...................................................................................................................78
13.1 Statement of Conformity.......................................................................................................................................78
13.2 Dimensions........................................................................................................................................................... 79
Table of contents 5

1 Preface
This is the user manual for the mower F3 and R3. This publication explains how the machine is assembled, what it is
intended for and how to use it optimally.
This manual contains important information and instructions on safety, operation and maintenance. Please read
all information and follow the instructions and guidelines in this manual carefully. This ensures long-term optimal
performance and prevention of possible accidents and injuries.
Apart from this user manual, you also received other manuals concerning your Roberine mower. One manual is
dedicated to the complete maintenance of your mower. The other manual belongs to the engine of your machine and
provides you with all the information you need concerning the maintenance and repairs of the power source. Both
manuals are mainly meant for service engineers.
1.1 Who is this manual intended for?
The user manual is intended for users and service engineers of the mower. Anyone who is not familiar with the operation
or service of the mower is advised to fully read the following chapters and to follow the instructions exactly. Personnel
that are familiar with the operation and service of the mower can use this manual for reference. The table of contents can
be used to locate specific information.
1.2 Scope of this manual
This manual is a guide for the operation and service of the mower. Each operation and maintenance action is
sequentially described in the relevant sections of this manual. Normal routine operation of the mower requires that
operators and service engineers:
• Have sufficient technical knowledge and experience to carry out the assigned tasks.
• Are able to recognise and prevent hazards.
• Have read this manual and understand the contents.
• Have been adequately trained.
• Are able to follow the procedures in this manual.
1.3 Storing the manual
The user manual is part of your machine. Store the manual in the immediate vicinity of the machine. Always present a
copy of the user manual for the mower to persons working with or on the machine. Make sure that everyone working with
the machine has fully read and understood the content, and puts it into practice.
1.4 Manufacturer details
If you need any assistance, please contact your regional service centre. If you still have questions after reading
this manual, we would encourage you to contact us. We appreciate all advice, feedback and suggestions from our
customers. Please contact:
Manufacturer: Roberine
Postal address: PO Box 818
7500 AV Enschede
The Netherlands
Visiting address: Goolkatenweg 65
7521 BE Enschede
The Netherlands
Telephone:
Fax:
[phone]
[phone]
E-Mail:
Internet:
[email protected]
www.roberine.com
Preface 6

1.5 Guarantee and liability
Please refer to the order confirmation and the delivery terms and conditions for the applicable guarantee and liability.
1.6 Trademarks
All trademarks stated in this manual are registered trademarks of Roberine or her suppliers.
1.7 Statutory standards and regulations
The instructions in this document take no account of the different national regulations and laws that must be obeyed
when operating the mower. It is the sole responsibility of the purchaser to obey these regulations and laws.
1.8 Recommissioning
In the event of a recommissioning (e.g. relocation of the machine or a transfer of ownership), you MUST contact
Roberine or representative subcontractor to discuss the procedures, terms and conditions, service contract, etc., so that
the proper functioning and safety of the machine after recommissioning can be guaranteed. This manual should always
be relocated with the mower.
If Roberine is not involved in a recommissioning, then Roberine is not liable for any claims of third parties arising from
that recommissioning.
1.9 Version history
Every effort has been made to make this manual as accurate and complete as possible. Should you discover any errors
or omissions, please bring this to the attention of your local Roberine service department or distributor, so that we can
make amendments. This will enable us to improve our documentation.
The instructions in this manual do not take into account different national regulations and laws. When operating the
mower, it is the sole responsibility of the user to make sure that all applicable local laws and regulations are obeyed.
During the lifetime of the mower, engineering improvements may result in the need to revise this manual. It is then at the
discretion of Roberine, if a revision/new version of this manual is required.
The following table describes the main changes for each document version of this manual.
Version Date Changes
V1.0 May 2019 Initial version
V1.1 September 2019 Minor revisions
The information in this document concentrates solely on the use and maintenance of the mower as intended by Roberine
In the event that the products, parts or procedures are applied in any way other than described in this manual, then
confirmation from Roberine must be obtained as to the correctness and suitability of that use.
Preface 7

2 Safety
The mowers F3 and R3 have been carefully designed and expertly built for safe which is confirmed by the EG
declaration. However, there will always be dangers and safety risks that cannot be excluded. These risks are inherent to
operators and service engineers using the machine.
This chapter is devoted to safety instructions and precautions, how they are indicated and the conditions the driver must
comply with. It is very important that you carefully read and understand the safety instructions and precautions and will
take them into account during all circumstances!
2.1 Safety messages
This manual contains various pictograms to show which dangers or risks may occur. Your machine is also provided
with several pictograms, see Safety signs on page 11. Below you will find an overview of the pictograms used in this
manual, what they mean, what they refer to or what they warn you for.
Warning Indicates a situation which may lead to physical injury and/or
material damage if one does not obey the safety instructions.
Caution Warns of a situation that may cause material damage if one does
not follow the safety instructions.
Information Provides additional information that is helpful to acomplish a task
or to avoid problems.
2.2 Hazards
2.2.1 Mowing units
WARNING Avoid injury resulting from contact with the mowing units:
• Rotating mowing blades can cut off arms and legs or throw objects into the air.
• Keep hands, feet and clothes away from the mowing units and rotating parts when the engine is running.
• Always remain alert and carefully drive forwards. People and, in particular, children can enter the area to be
mowed before you realise it.
• Before driving in reverse, turn off the mowing units and look to see whether anybody is behind or next to the
machine, particularly children.
• Do not mow while driving in reverse.
• Stop the mowing blades when you are not mowing.
• Always park the machine safely before leaving the driver’s seat.
• Keep all body parts away from the edges of the mowing blades. If the locking mechanism is released, the
mowing blades may start to rotate as a result of any residual hydraulic pressure or any other energy stored
in the system.
• Keep bystanders away from the mowing units when adjusting them or performing maintenance work on
them.
• Always wear gloves when rotating the mowing blades by hand.
• If one of the mowing blades is rotated by hand other cylinders may also start rotating.
2.2.2 Protect children
WARNING Children find mowers and mowing interesting and fun. They do not understand the risks of rotating
blades and do not realise that the user is not aware of their presence.
• Never give children a ride on the machine or an add-on component, even if the blades are turned off.
Serious injury or even death may be the result if young children think that they are allowed to play with the
machine.
Safety 8

• Children who were given a ride on the machine in the past may suddenly appear in the mowing area for
another ride and be knocked down or run over by the machine.
• A child may be involved in a serious accident if the driver does not pay attention to the possible presence
of children, particularly if a child approaches the machine from the rear. Before and while driving in reverse,
turn off the mowing blades and look to see whether anybody is behind or next to the machine.
• Never use the machine as a recreational vehicle or to amuse children.
• Always be aware of the presence of children. Never assume that children remain in the place where you last
saw them. Stop the machine if a child enters the work area.
2.2.3 Avoid roll over
WARNING Inclines play an important role in accidents where the driver loses control of the machine and/or the
machine tips over, often with serious or fatal consequences. It is necessary to take extra care when working on
inclines:
• Do not mow on an incline if you feel unsafe.
• Drive straight up and down inclines, not crossways.
• Never use the machine on an incline steeper than 32 %.
• Look out for holes, uneven surfaces, rocks, stones, or other hidden obstacles. The machine could tip over
on uneven terrain. Objects can be hidden from view by high grass.
• It is not recommended to drive the machine on an incline with wet grass. The wheels may lose their grip
even if the brakes work properly.
• Preferably do not start, stop or turn the machine on an incline. If the tyres lose their grip, turn off the mowing
cylinders and slowly drive straight down the incline.
• Make sure that all movements on an incline are performed slowly and carefully. Do not suddenly change
speed or direction.
• Do not mow close to steep inclines, ditches, embankments, dykes or water. The machine could suddenly tip
over if one of the wheels protrudes over the edge or if an edge collapses. Maintain a safe distance between
the machine and any dangers.
• Always drive the machine very slowly and avoid stopping suddenly if the mowing units have been removed.
• Lower the mowing units when driving on slopes or inclines, because this increases stability.
2.2.4 Avoid pressurised liquids
WARNING Pressurised liquids can cause serious personal injuries.
• Depressurise the hydraulic systems when you do maintenance on your machine or ask your Roberine
dealer to relieve the pressure before you disconnect hydraulic lines or other lines.
• Make sure that all hydraulic fluids connections are tightened before you pressurise the system.
• Regularly check the hydraulic fluids connections. They can loosen as a result of damage or vibrations.
Tighten loose connections.
• Regularly check the hydraulic hoses and lines. Hydraulic hoses can become faulty as a result of damage,
kinks, ageing and exposure to the elements. Replace any damaged hoses and lines.
CAUTION! In the event of an accident, immediately contact a medical specialist. If the fluid penetrates the skin,
it must be removed within a couple of hours by means of an operation in order to prevent gangrene. Medical
specialists who are not familiar with this type of injury are requested to consult reliable medical sources.
2.2.5 Tyres
WARNING Tyres or rims that unexpectedly spring loose can cause serious injury or even death.
• Do not fit tyres if you do not have the correct equipment or sufficient experience.
• Always ensure the tyres have the correct tyre pressure. Do not inflate the tyres to more than the
recommended pressure.
• Never perform welding work on or heat a wheel while a tyre is still fitted. The heat can cause the pressure to
increase and cause the tyre to explode. Welding can weaken the structure or deform the wheel.
• When inflating the tyres, use a clamping valve with an extension hose that is long enough to allow you to
stand to the side of the tyre so that you do not have to stand in front of or hang over the tyre.
• Regularly check the tyres for cuts and bulges, damaged rims and missing nuts or bolts.
Safety 9

2.3 General safety instructions
WARNING
• Do not run the engine in a confined space, where hazardous carbon monoxide vapours can collect.
• Do not leave the machine unattended while the engine is running.
• Never raise the mowing platforms while the blades are rotating.
• Never use the machine if a protective cover is faulty or if the safety devices are not in place.
• Do not change the settings of the speed controller and do not tune the engine to increase its power.
Running the engine at a speed too high for the engine, increases the risk of personal injury.
• Turn off the engine and remove the ignition key before:
> checking, cleaning or working on the machine;
> refuelling;
> changing the height setting of the mowing units; and
> removing a blockage or foreign object. Always inspect the machine for damage and make any repairs
before you restart and use the machine again.
• Do not use the machine when under the influence of alcohol, drugs or medicines that can impair your
driving abilities.
• Do not wear (in-ear) headphones to listen to music. Safe operation and maintenance of the machine
requires your full attention.
CAUTION!
• Only mow in daylight or with good artificial lighting.
• Remember that there is no such thing as a safe incline. Pay close attention, particularly when driving on
grass inclines. To avoid roll-over:
> Do not suddenly stop or start driving when facing uphill or downhill.
> Drive slowly on inclines.
> Always pay attention to uneven surfaces, holes and other hidden dangers.
> Never mow crossways on an incline.
• Drive slowly around sharp corners. Be careful when approaching blind corners, bushes, trees and other
objects that can impede vision.
• Pay attention to traffic when crossing or working close to public roads.
• Stop the mowing blades before driving over a terrain that is not covered by grass.
• Never aim the ejected material at bystanders and do not allow people to get close to the machine while it is
in use. Stop the machine if somebody enters the work area.
• Only use accessories and add-on units that have been approved by the manufacturer.
• Do not transport passengers:
> Only the driver is allowed to sit on the machine. Passengers on the machine or the add-on units may be
hit by flying objects or be thrown off the machine, which may result in serious injury.
> Passengers can impede the driver’s view and make the machine unsafe to use.
Safety 10

2.4 Safety signs
The following safety signs are located on the machine.
CAUTION!
This user manual contains important information necessary for safe
machine operation. Observe all safety rules to avoid accidents.
CAUTION!
Avoid injury from rotating blades. Keep hands and feet away from
rotating blades. Turn off the engine before servicing, lubricating or
removing cutting units. Remember that the machine can keep moving
after the engine has been turned off. Wait until everything has come
to a complete stop.
CAUTION!
Avoid injury from fan. Do not open or remove safety shields while
engine is running.
Safety 11

CAUTION!
• Read the user manual before using the machine.
• Risk of flying objects. Keep away from the machine when it is in
operation.
• Risk of tipping over: take corners slowly and drive slowly on
inclines.
• Always wear the seat belt when the ROPS is up. Do NOT wear
the seat belt when the ROPS is folded down.
• Do not use the machine on an incline steeper than 32%. Always
use the ROPS when driving on an incline.
CAUTION!
• Do not smoke and keep fire away from battery.
• Wear eye protection and gloves when carrying out maintenance
on the battery.
• Keep children away from the battery when carrying out
maintenance on the battery.
• Do not spill electrolyte on skin.
• Read the user manual before carrying out maintenance on
battery.
• Batteries produce a flammable and explosive gas.
This label on your machine indicates that this model complies with
the applicable requirements of the 2000/14/EC Noise Emission in the
Environment Directive.
2.5 Safety features
2.5.1 Safety mechanisms
Seat belt
Safety 12

• Always use a seat belt when you operate the machine to minimise the chance of injury from an accident, such as an
overturn.
• Never modify, disassemble or attempt to repair the seat belt.
• Replace entire seat belt if mounting hardware, buckle, belt, or retractor show signs of damage.
• Inspect seat belt and mounting hardware at least once a year. Look for signs of loose hardware or belt damage, such
as cuts, fraying, extreme or unusual wear, discolouration or abrasion. Replace only with replacement parts approved
by Roberine
• Layers of heavy clothing can interfere with proper positioning of the seat belt and can reduce the effectiveness of the
seat belt.
Roll-over Protection Structure
CAUTION! Keep the ROPS installed properly.
• Never operate the machine without the ROPS installed.
• Make sure all parts of the ROPS are installed correctly if the ROPS structure is loosened or removed for any reason.
All ROPS hardware should be tightened to the proper torque as per manufacturer’s recommendations.
• Any changes to the ROPS must be approved by the manufacturer. The protection provided by the ROPS will be
impaired if the ROPS is subjected to structural damage, is involved in an overturn incident, or is in any way altered by
welding, bending, drilling, or cutting.
• The seat is part of the ROPS safety zone. Replace only with a seat approved by Roberine.
• Never attempt to repair a damaged or altered ROPS. It must be replaced to maintain the manufacturer’s certification
of the structure.
2.5.2 Emergency stop
CAUTION! Always stay seated and hold the steering wheel when you need to make an emergency stop.
Leaving the seat or releasing the steering wheel may cause dangerous situations.
In case of emergencies:
1. Quickly remove your foot from the foot pedal.
The hydraulic brake will be activated.
2. If necessary, slowly pull the parking break until the machine slows down.
2.6 Instructions to the driver
The driver is responsible for working safely with the mower. When the driver does not follow the safety rules and
instructions, it can cause serious personal injury and damage to the machine.
The driver:
• has been trained and is qualified to operate the machine.
• is attentive to and avoids dangerous situations.
• always inspects the machine before use.
• tests the functioning of the machine.
• inspects the working environment.
• keeps bystanders at a safe distance.
• only uses the machine for which it is intended.
• wears the correct safety equipment and clothes.
• does not operate the machine when under the influence of medicines, alcohol or drugs.
• fully read and understood the safety and operating instructions.
• is familiar with local legislations and rules.
2.7 Parking safely
Always park the machine safely before carrying out maintenance tasks or storage.
1. Park the machine on a horizontal surface and not on an incline.
2. Turn off the mowing units.
Safety 13

3. Lower the mowing units to the ground.
4. Apply and lock the parking break
5. Turn off the engine.
6. Remove the ignition key.
7. Wait until the engine and all the moving parts have come to a standstill before leaving the driver’s seat.
8. Close the fuel tap if the machine has one.
9. Disconnect the battery’s negative cable before carrying out any maintenance work on the machine.
2.8 Personal protective equipment
It is it important to follow the safety instruction to prevent damage or personal injury.
• Always wear safety glasses with side protection when operating the machine.
• Wear close-fitting clothing and use personal protective equipment that is suitable for the work.
• When mowing, always wear sturdy shoes and long trousers. Do not operate the machine in bare feet or when
wearing open sandals.
• Use the necessary personal protective equipment, such as earplugs. Loud noises can cause a loss of hearing or
deafness.
2.9 Environmental aspects
2.9.1 Disposal
The owner and/or user of the mower is responsible for the disposal of waste materials (oil etc.) in accordance with the
applicable local laws or regulations. When the machine has reached the end of its useful life, the owner and/or user is
responsible for the safe disassembly of the machine and for the disposal of the components, in accordance with the local
laws or regulations.
2.9.2 REACH declaration
The REACH regulation became effective on 1st June 2007. The aim of the REACH regulation is to ensure a high level of
protection of human health and the environment from chemical substances.
Roberine manufactures articles in compliance with current revision of the REACH regulation, and is downstream-user of
chemical substances.
Roberine has the intention to fully comply to REACH regulation and has checked its suppliers to make sure they comply
with REACH requirements for all materials and substances used in our products.
Roberine will provide relevant information e.g. Material Safety Data Sheet (MSDS) on request.
2.9.3 End of life disposal
When the mower has finally reached the end of its useful life, the owner and/or user is responsible for the safe
disassembly of the mower and for the disposal of its components and parts in accordance with the local laws, regulations
and recommendations.
Safety 14

3 Introduction
3.1 Mowing
The Roberine F3 and R3 have been specially designed to mow grass on sports grounds, parks and green public areas.
The flail mower unit of the F3 has been developed in collaboration with Votex. Votex is especially known for its verge and
ditch-side flail mowers. The specially designed cutting head in combination with the unique Votex flails enable a relatively
high cutting speed to be realised even when the grass is high. This ensures a smooth mowing result. Furthermore, the
cuttings spread out evenly, creating a smooth mowing result. The easily adjustable cutting height makes the machine
extremely versatile and guarantees a perfect mowing result even on uneven surfaces.
CAUTION! Only use the mower for purposes for which it is developed and intended. Any other,
improper, use without written consent from Roberine, will invalidate the guarantee!
3.2 Type plate of your machine
The machine’s type plate indicates that this model satisfies the applicable safety requirements of Machinery Directive
2006/42/EC and EMC 2004/108/EC.
The type plate is located on the battery frame of the mower.
NOTICE Keep the information of your type plate in a safe and secure place. When you have questions about
your mower F3 or R3 or need to order replacements parts, this information will enable us to provide efficient
and adequate service.
3.3 Engine
The engine used for the drive unit of the mower and for the pump for the oil supply for the hydraulic functions is the
Yanmar 3TNV84T-BKVX
NOTICE All the properties of the engine and information about its use, maintenance and repairs can be found
in the engine’s manual. You have received this manual from us.
Introduction 15

4 Description
Your machine is the mower F3 or R3. Both models can be provided with either an ROPS or a cabin.
1. Command arm: This is where all the
operating buttons and the display are
located.
2. Steering wheel.
3. ROPS. The Roll Over Safety Structure
prevents entrapment should the machine
roll over.
4. Seat.
5. Engine. The engine powers the mower
6. Mowing units. These are either flail units
(F3) or reel units (R3)
7. Locking lever
4.1 Equipment
4.1.1 Description mower F3
1. Pivot
2. Cutting height adjuster
3. Counter weight
4. Slide shoe
5. Flail
6. Roller
7. Rotor shaft
8. Scraper
Description 16

4.1.2 Description mower R3
1. Pivot
2. Cutting height adjuster
3. Adjuster
4. Slide shoe
5. Bed knife
6. Roller
7. Mower reel
8. Scraper
4.2 Engine compartment
1. Cooling fluid filling cap
2. Oil dipstick
3. Oil filling cap
4. Air cleaner cap
Description 17

4.3 Cabin
1. Windscreen wiper
2. Dashboard
3. Rear view mirror
4. Side mirror
5. Command arm
6. AC Cooler
7. Handle
8. Seat
9. Steering wheel
1. Step switch for radial blower speed
2. Controller for temperature (Thermostat)
3. Switch for air conditioner
4. Radio
5. Air vents
6. Rear view mirror
7. Beacon light switch
8. Windscreen wiper fluid
9. Windscreen wiper switch
Description 18

4.4 Seat
1. Armrest adjuster
2. Back rest adjuster
3. Seat position adjuster
4. Seat height adjuster
5. Horizontal shock absorber
6. Lumbar support adjuster
Description 19

4.5 Driver's compartment
1. Steering wheel adjuster
2. Ignition
3. Hour meter
4. Steering wheel
5. Foot pedal
6. Command arm
1. Battery charge indicator
2. Low engine oil pressure indicator
3. Coolant temperature indicator
4. Preheat system indicator
5. Cruise control indicator
6. Indicator left and right
7. Hydraulic oil temperature indicator
8. Fuel indicator
1. Parking brake
2. Hand throttle
3. Fuel gauge
Description 20
