Roland HT-TX01 User manual

Before using this unit, carefully read the sections entitled“USING THE UNIT SAFELY” and “IMPORTANT NOTES”
on back side. These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature of your new unit, read
Owner's Manual in its entirety. This manual should be saved and kept on hand as a convenient reference.
Owner’s Manual
RS-232 Connector (RS-232 Conversion Cable) Specications
D-sub 9-pin (female)
54321
9876
TXD
RXD
GND
3.5mm miniature
phone plug
54321
9876
TXD
RXD
GND
Pin No. Signal
1 N.C.
2 RXD
3 TXD
4 N.C.
5 GND
6 N.C.
7 N.C.
8 N.C.
9 N.C.
Communication method Synchronous (asynchronous), full-duplex
Communication speed 9600 bps, 19200 bps, 38400 bps, 115200 bps
Parity none
Data length 8 bit
Stop bit 1 bit
Code set ASCII
Flow control none
Cable Wiring Diagram
When using the included RS-232 conversion cable, RXD, TXD, and GND are wired as shown below.
Unit end
(conversion cable end) Controller end
N.C. : 1 1 :
RXD : 2 2 : RXD
TXD : 3 3 : TXD
N.C. : 4 4 :
GND : 5 5 : GND
N.C. : 6 6 :
N.C. : 7 7 :
N.C. : 8 8 :
N.C. : 9 9 :
* When you want to extend the RS-232 conversion cable, use a straight cable.
Attaching the Ferrite Cores
1. Open an included ferrite core by spreading apart the tabs at two places.
2. Attach the ferrite core to an HDMI cable, LAN cable, or RS-232 conversion cable.
* Close the ferrite core by pressing down on each tab until it clicks into place.
Attach near the base of the plug at
the end that connects to the unit.
Connection Examples
* For a connection to the HDBaseT connector, use a Cat5e (Category 5e) or higher shielded LAN cable.
* *For a connection to the RS-232 connector, use the included RS-232 conversion cable.
HDMI INPUT
connector
RS-232
connector
RS-232-compatible
projector, etc.
RS-232-compatible
device (computer, etc.)
Displays,
projectors, etc.
Roland XS series device, etc.
HT-RX01
HDBaseT OUTPUT
connector
RS-232
connector
RS-232
connector
RS-232
connector
RS-232-compatible
device (computer, etc.)
Displays,
projectors, etc.
Roland V-40HD device, etc.
HT-RX01
HT-TX01
RS-232
connector
HDMI INPUT
connector
HDMI OUTPUT
connector
Panel Descriptions
HT-TX01 (Transmitter)
1 2 3 * These connectors are not used.
4 5 6
HT-RX01 (Receiver)
1 2 7 * These connectors are not used.
4 8 6
No. Name Explanation
1Power indicator This lights up when power is supplied.
2LINK indicator This lights up when the transmitter/receiver is correctly connected
3HDMI INPUT connector The HDMI signal from the source device is input here.
4AC adaptor connector This is for connecting the included AC adaptor.
No. Name Explanation
5HDBaseT (TX) connector This is for connecting a receiver.
6RS-232 connector This is for connecting a remote-control device (RS-232-compatible
computer, projector, or the like) using the included RS-232 conversion cable.
7HDMI OUTPUT connector This outputs the HDMI signal to a display device.
8HDBaseT (RX) connector This is for connecting a transmitter, Roland XS series unit, or other such
device.
Main FeaturesChecking the Included Items
• The unit
• AC adaptor, insertion plugs (3 types)
• RS-232 conversion cable (2 m)
• Ferrite core x 3
• Owner’s Manual (this document)
This unit is a transmitter/receiver for long-distance transmission of HDMI signals over up to 100 meters using a single LAN cable (Cat5e or higher).
• Support for 1080/59.94p (full HD) and 3D video
• Support for HDMI 1.4 and HDCP 2.0
• Support for RS-232 signals
Attaching an AC Adaptor Insertion Plug
1. Attach an included AC adaptor insertion plug to the AC adaptor.
* Attach the insertion plug for your country or region.
* Attach the insertion plug by pressing it in until it clicks into place.
* Be sure always to use the included AC adaptor with the unit.
To detach, pull out the insertion plug
while squeezing the left and right
sides of the lock section inward.
Main Specications Roland HT-TX01/HT-RX01 : HDBaseT TRANSMITTER/HDBaseT RECEIVER Dimensions
Copyright © 2014 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in
any form without the written permission of ROLAND CORPORATION.
90
93
81
69
24
24.9
60
73.4
Unit: mm
Input Formats 480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p, 720/50p,
1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p, 640 x 480, 800 x 600,
1024 x 768, 1280 x 768, 1280 x 1024, 1366 x 768, 1400 x 1050,
1600 x 1200, 1920 x 1200
* RGB formats : Conforms to VESA DMT Version 1.0 Revision 11.
* The maximum refresh rates of RGB is 75 Hz. (excluding 1600 x 1200
and 1920 x 1200. The refresh rate of these 2 is 60Hz)
* 1920 x 1200/60Hz : Reduced blanking
* Also check the supported resolutions of the connected device.
Audio Formats The maximum is PCM 8ch, Dolby Digital, True HD DTS-HD Master Audio
Input Connectors HT-TX01 HDMI x 1: Type A 19 pins
HT-RX01 RJ45 x 1
Output Connectors HT-TX01 RJ45 x 1
HT-RX01 HDMI x 1: Type A 19 pins
Other Connectors RS-232 x 1: 9 pins D-sub type * When using additional RS-232 cable.
Transmission distance The maximum is 100 m (328 ft)
* The available distance depends on the quality of the LAN cable.
Operating temperature range 0 to 40 degree C
32 to 104 degrees F
Operating temperature humidity 10 to 85 % (no condensation)
Storage temperature range -20 to 60 degree C
-4 to 140 degrees F
Storage temperature humidity 10 to 85 % (no condensation)
Power Supply AC Adaptor
Power Consumption 10 W
Dimensions 81 (W) x 93 (D) x 24 (H) mm
3-3/16 (W) x 3-11/16 (D) x 1 (H) inches
Weight excl. AC adaptor 300 g
11 oz
* In the interest of product improvement, the specications and/or appearance of this unit are subject to
change without prior notice.
When you need repair service, access this URL and nd your nearest Roland Service Center or
authorized Roland distributor in your country.
https://roland.cm/service
Roland Service Centers and Distributors
Roland Service Centers and Distributors
When you need repair service, access this URL and nd your nearest Roland Service Center or authorized Roland distributor in
your country.
https://roland.cm/service
Roland Service Centers and Distributors
Roland Service Centers and Distributors
When you need repair service, access this URL and nd your nearest
Roland Service Center or authorized Roland distributor in your country.
https://roland.cm/service
Roland Service Centers and Distributors
Roland Service Centers and Distributors
*5100044591-04*

WARNING
To completely turn o power to the unit, pull
out the plug from the outlet
Even with the power switch turned
o, this unit is not completely
separated from its main source
of power. When the power needs
to be completely turned o, turn o the
power switch on the unit, then pull out the
plug from the outlet. For this reason, the
outlet into which you choose to connect
the power cord’s plug should be one that is
within easy reach and readily accessible.
Do not disassemble or modify by yourself
Do not carry out anything unless
you are instructed to do so in the
owner’s manual. Otherwise, you
risk causing malfunction.
Do not repair or replace parts by yourself
Refer all servicing to your retailer,
the nearest Roland Service
Center, or an authorized Roland
distributor, as listed on the
“Information.”
Do not use or store in the following types of
locations
• Subject to temperature
extremes (e.g., direct sunlight
in an enclosed vehicle, near a
heating duct, on top of heat-
generating equipment); or are
• Damp (e.g., baths, washrooms,
on wet oors); or are
• Exposed to steam or smoke; or are
• Subject to salt exposure; or are
• Exposed to rain; or are
• Dusty or sandy; or are
• Subject to high levels of vibration and
shakiness.
Do not place in an unstable location
Otherwise, you risk injury as the
result of the unit toppling over or
dropping down.
Use only the supplied AC adaptor and the
correct voltage
Be sure to use only the AC adaptor
supplied with the unit. Also,
make sure the line voltage at the
installation matches the input voltage
specied on the AC adaptor’s body. Other
AC adaptors may use a dierent polarity, or
be designed for a dierent voltage, so their
use could result in damage, malfunction,
or electric shock.
Do not bend the power cord or place heavy
objects on it
Otherwise, re or electric shock
may result.
WARNING
Do not allow foreign objects or liquids to
enter unit; never place containers with liquid
on unit
Do not place containers containing
liquid (e.g., ower vases) on this
product. Never allow foreign
objects (e.g., ammable objects,
coins, wires) or liquids (e.g., water
or juice) to enter this product.
Doing so may cause short circuits,
faulty operation, or other malfunctions.
Turn o the unit if an abnormality or
malfunction occurs
Immediately turn the unit o,
remove the AC adaptor from the
outlet, and request servicing by
your retailer, the nearest Roland
Service Center, or an authorized Roland
distributor, as listed on the“Information”
when:
• The AC adaptor or the power cord has
been damaged; or
• If smoke or unusual odor occurs; or
• Objects have fallen into, or liquid has
been spilled onto the unit; or
• The unit has been exposed to rain (or
otherwise has become wet); or
• The unit does not appear to operate
normally or exhibits a marked change in
performance.
Be cautious to protect children from injury
Always make sure that an adult is
on hand to provide supervision
and guidance when using the
unit in places where children are
present, or when a child will be using the
unit.
Do not drop or subject to strong impact
Otherwise, you risk causing
damage or malfunction.
Do not share an outlet with an unreasonable
number of other devices
Otherwise, you risk overheating
or re.
Do not use overseas
Before using the unit in overseas,
consult with your retailer, the
nearest Roland Service Center, or
an authorized Roland distributor,
as listed on the “Information.”
CAUTION
Place in a well ventilated location
The unit and the AC adaptor
should be located so their location
or position does not interfere with
their proper ventilation.
CAUTION
When disconnecting the power cord, grasp it
by the plug
To prevent conductor damage,
always grasp the power cord by its
plug when disconnecting it from
this unit or from a power outlet.
Periodically clean the power plug
An accumulation of dust or foreign
objects between the power plug
and the power outlet can lead to
re or electric shock.
At regular intervals, be sure to pull out the
power plug, and using a dry cloth, wipe
away any dust or foreign objects that may
have accumulated.
Disconnect the power plug whenever the
unit will not be used for an extended period
of time
Fire may result in the unlikely event
that a breakdown occurs.
Route all power cords and cables in such a
way as to prevent them from getting
entangled
Injury could result if someone were
to trip on a cable and cause the
unit to fall or topple.
Avoid climbing on top of the unit, or placing
heavy objects on it
Otherwise, you risk injury as the
result of the unit toppling over or
dropping down.
Never connect/disconnect a power plug if
your hands are wet
Otherwise, you could receive an
electric shock.
Disconnect all cords/cables before moving
the unit
Before moving the unit, disconnect
the power plug from the outlet,
and pull out all cords from external
devices.
Before cleaning the unit, disconnect the
power plug from the outlet
If the power plug is not removed
from the outlet, you risk receiving
an electric shock.
Whenever there is a threat of lightning,
disconnect the power plug from the outlet
If the power plug is not removed
from the outlet, you risk receiving
an electric shock.
Keep small items out of the reach of children
To prevent accidental ingestion of
the parts listed below, always keep
them out of the reach of small
children.
• Included Parts: Ferrite core
IMPORTANT NOTESUSING THE UNIT SAFELY
Power Supply
• Do not connect this unit to same electrical
outlet that is being used by an electrical
appliance that is controlled by an inverter
or a motor (such as a refrigerator, washing
machine, microwave oven, or air conditioner).
Depending on the way in which the electrical
appliance is used, power supply noise
may cause this unit to malfunction or may
produce audible noise. If it is not practical
to use a separate electrical outlet, connect a
power supply noise lter between this unit
and the electrical outlet.
• The AC adaptor will begin to generate heat
after long hours of consecutive use. This is
normal, and is not a cause for concern.
• This unit is equipped with a protection
circuit. A brief interval (a few seconds)
after turning the unit on is required
before it will operate normally.
Placement
• This unit may interfere with radio and
television reception. Do not use this unit in
the vicinity of such receivers.
• Noise may be produced if wireless
communications devices, such as cell
phones, are operated in the vicinity of this
unit. Such noise could occur when receiving
or initiating a call, or while conversing.
Should you experience such problems, you
should relocate such wireless devices so
they are at a greater distance from this unit,
or switch them o.
• When moved from one location to
another where the temperature and/or
humidity is very dierent, water droplets
(condensation) may form inside the unit.
Damage or malfunction may result if you
attempt to use the unit in this condition.
Therefore, before using the unit, you must
allow it to stand for several hours, until the
condensation has completely evaporated.
• Do not place containers or anything else
containing liquid on top of this unit. Also,
whenever any liquid has been spilled on the
surface of this unit, be sure to promptly wipe
it away using a soft, dry cloth.
Additional Precautions
• Use a reasonable amount of care when
using its jacks and connectors. Rough
handling can lead to malfunctions.
• When disconnecting all cables, grasp the
connector itself—never pull on the cable.
This way you will avoid causing shorts, or
damage to the cable’s internal elements.
• When you need to transport the unit,
pack it in shock-absorbent material.
Transporting the unit without doing
so can cause it to become scratched or
damaged, and could lead to malfunction.
Copyrights/Licenses/Trademarks
• MMP (Moore Microprocessor Portfolio)
refers to a patent portfolio concerned
with microprocessor architecture, which
was developed by Technology Properties
Limited (TPL). Roland has licensed this
technology from the TPL Group.
• Roland is an either registered trademark
or trademark of Roland Corporation in the
United States and/or other countries.
• Company names and product names
appearing in this document are registered
trademarks or trademarks of their respective
owners.
Used for instructions intended to alert the
user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic animals
or pets.
Used for instructions intended to alert the
user to the risk of death or severe injury
should the unit be used improperly.
The symbol alerts the user to things that must be
carried out.The specific thing that must be done is
indicated by the design contained within the circle. In the
case of the symbol at left, it means that the power-cord
plug must be unplugged from the outlet.
The symbol alerts the user to important instructions or
warnings.The specific meaning of the symbol is
determined by the design contained within the triangle.In
the case of the symbol at left, it is used for general
cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never be
carried out (are forbidden).The specific thing that must
not be done is indicated by the design contained within
the circle. In the case of the symbol at left, it means that
the unit must never be disassembled.
About WARNING and CAUTION Notices About the Symbols
ALWAYS OBSERVE THE FOLLOWING
For the USA
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment requires shielded interface cables in order to meet FCC class B limit.
Any unauthorized changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
For Canada
CAN ICES-3 (B)/NMB-3 (B)
Roland Corporation
2036-1 Nakagawa, Hosoe-cho, Kita-ku, Hamamatsu, Shizuoka 431-1304, JAPAN
Roland Corporation
ENA 23 Zone 1 nr. 1620 Klaus-Michael Kuehnelaan 13, 2440 Geel, BELGIUM
Importer:
Manufacturer:
For EU Countries
Roland Corporation
2036-1 Nakagawa, Hosoe-cho, Kita-ku, Hamamatsu, Shizuoka 431-1304, JAPAN
Roland Europe Group Limited
Hive 2, 1530 Arlington Business Park, Theale, Reading, Berkshire. RG7 4SA United Kingdom
Importer:
Manufacturer:
For the U.K.
产品中有害物质的名称及含量
环保使用期限
󴂸󷼲󴉓󱜅󳨛󾙓󾙓󾙕󾙘󾙖󵯔󸇛󲰬󶯢󱭧
󷼲󶀱󸘃󴁸󲱛󵒜󸟰󲍨󸘃󸻉󱘎󳡇󴁸󲎑󸟰󴃮󳸃󱓩󵯔󱺂󹂩󲎑󲍨󾙔󾙘󾙗󾙙󾙔󸇛󲰬󵯔󹠠󹂩󸅲󴦔󱗵󱒷
󷼲󶀱󸘃󴁸󲱛󵒜󸟰󷆹󲴞󲍨󸘃󸻉󱘎󵯔󴆨󱒪󲎑󸟰󴃮󳸃󱓩󵯔󱺂󹂩󸡤󱬕󾙔󾙘󾙗󾙙󾙔󵯔󹠠󹂩󸅲󴦔
󽙏󱘡󱓐󱸯󲍨󴟾󲙓󽙓󴉐󳨛󲰴󹠏󳖐󱪦󲳳󱒶󷼲󱓩󳡳󾛒󾛓󵯔󳢸󴂼󱶫󲋶󸱞󷼇󸱞󱒪󴠁󸘒󳻛󽙐

󴟾󴇾󳐋󸳁󵥌󱕨󲍨󱓩󲌢󲌢󱩣󹙷󱿺󵯔󵥟󲮚󱝵󳓽󱖓󱽢󽙓󷼲󶀱󵚦󱝫󱛔󵥌󴂠󹠠󵯔󳅸󳶹󳡇󸘱󵚦󱝫󱛔󵥌
󴂠󹠠󳼎󳥸󲍨󷆦󱭧󸴓󳺝󸡐󵯔󸇛󲰬󴂠󹠠󱩣󽙓󱖓󱽢󱓩󳡇󱺂󵯔󴁸󲱛󵒜󸟰󱒹󷆻󳊷󸡐󵚦󲖀󴧅󴆭󽙓󱒹󱙃󲳳
󱖶󸩒󸟪󱖓󸴓󳟸󱓞󹂧󵯔󱒹󷋣󳍧󱽰
󵚦󱝫󱛔󵥌󴂠󹠠󱗃󲍨󸷸󵊉󱖓󱽢󱛔󵥌󸘒󳻛󱔲󽙓󴟽󵻗󱛔󵥌󱖓󱽢󵯔󴄄󱘎󱒷󳡪󴁸󳵿
󱒹󳌯󵯔󱛔󵥌󽙓󲴉󱙃󲳸󷆻󴁸󲱛󵒜󸟰󴩗󴸡󵯔󱵨󹡄
󸻉󱘎󱹔󶆃
󴁸󲱛󵒜󸟰
󲙻󲙁󽙏󲙁󱚏󽙐
󵥟󲮚󸻉󱘎󽙏󱵦󱭨󵥟󸤀󴄰󶑂󽙐
󹠎󱘎󽙏󵥟󴴰󶮋󱖍󴬓󸳁󸾆󽗉󶑂󽙐
󹘼󽙏󽙐 󴧁󽙏󽙐 󹛁󽙏󽙐 󱩁󱘐󹙣
󽙏󽙏󽙐󽙐 󲚃󴵲󶹎󷏬 󽙏󽙐 󲚃󴵲󱕦󷏬󹀫 󽙏󽙐

有关产品中所含有害物质的说明
󴂸󸠌󳸃󲵊󴂸󱨾󱸻󱖓󱽢󱓩󳡇󱺂󵯔󵒲󲰬󴁸󲱛󵒜󸟰󱷷󱩎󲰈󱨴󳒋󱕡󱗵󸘒󳻛
󴂸󸠌󳸃󸳁󵥌󱕨󾙔󾙒󾙒󾙙󳅸󾙕󴁷󾙓󳺝󱗵󱹖󴂸󱨾󱸻󳡇󱭧󸴓󵯔󱖓󱽢
For EU Countries
For the USA
DECLARATION OF CONFORMITY
Compliance Information Statement
Model Name :
Type of Equipment :
Responsible Party :
Address :
Telephone :
HT-TX01 / HT-RX01
HDMI Extender
Roland Corporation U.S.
5100 S. Eastern Avenue Los Angeles,
CA 90040-2938
[phone]
