Carlson NR3 User manual

NR3
User Manual
Ver 1.00

Table of Contents
1NR3 Overview.................................................................................................................................................. 5
1.1 Shipping Case Contents............................................................................................................................................................6
1.2 NR3 Appearance.......................................................................................................................................................................7
1.3 NR3 Front Panel........................................................................................................................................................................8
1.3.1 Power Button Functions.......................................................................................................................................................9
1.4 Ports and Connections ...........................................................................................................................................................10
1.4.1 NR3 9-Pin Lemo Connector ................................................................................................................................................10
1.4.2 Power Input Specifications.................................................................................................................................................10
1.4.3 SD / SIM Card Slots.............................................................................................................................................................11
2NR3 Initial Setup............................................................................................................................................ 12
2.1 Install Battery .........................................................................................................................................................................12
2.2 Install on a Range Pole ...........................................................................................................................................................13
2.3 Powering On / Off...................................................................................................................................................................13
3Carlson NR3 Key Features ............................................................................................................................. 14
3.1 Navigation Accuracy ...............................................................................................................................................................14
3.2 Interference Suppression .......................................................................................................................................................14
3.3 Full SurvCE / SurvPC Compatibility.........................................................................................................................................14
4General Operation......................................................................................................................................... 15
4.1 On-Board Web UI ...................................................................................................................................................................15
4.1.1 Web UI Overview ...............................................................................................................................................................16
4.1.2 GNSS...................................................................................................................................................................................20
4.1.3 Communication..................................................................................................................................................................26
4.1.4 Corrections.........................................................................................................................................................................32
4.1.5 NMEA / SBF ........................................................................................................................................................................39
4.1.6 Admin.................................................................................................................................................................................46
4.1.7 GNSS Base Configurations..................................................................................................................................................53
4.1.8 GNSS Rover Configurations................................................................................................................................................61
4.2 Carlson SurvCE / PC Operation...............................................................................................................................................67
4.2.1 Incomplete SurvCE / SurvPC GNSS Base Listen - Listen .....................................................................................................67
4.2.2 SurvCE / SurvPC GNSS Rover..............................................................................................................................................70
5NR3 Advanced Operation.............................................................................................................................. 72
5.1 Firmware Updates ..................................................................................................................................................................72
5.2 Web UI Security......................................................................................................................................................................72
5.3 Satellite Tracking ....................................................................................................................................................................73
6NR3 Technical Specifications......................................................................................................................... 74
6.1 GNSS Receiver ........................................................................................................................................................................74
6.2 Performance...........................................................................................................................................................................74
6.3 Satellite Tracking ....................................................................................................................................................................74
6.4 Communication and Port Specifications ................................................................................................................................74
6.5 Wireless Specifications...........................................................................................................................................................75
6.6 Cellular Specifications.............................................................................................................................................................75

Page | 3
6.7 Power Specifications ..............................................................................................................................................................75
6.8 Memory Specifications...........................................................................................................................................................75
6.9Environmental Specifications .................................................................................................................................................76
6.10 Mechanical Specifications ......................................................................................................................................................76
7Index .............................................................................................................................................................. 77

Environmental
Temperature –operating‐30°C to +75°C (-22°F to +167°F).
Temperature –storage -40° C to +75° C (-40° F to +167° F).
CE Compliance
Receivers of the NR3 family carry the CE mark and as such are compliant with the 2004/108/EC-EMC Directive and amendments,
2006/95/EC-Low Voltage directive, both amended by the CE marking directive 93/68/EC. With regards to EMC, these devices are
declared as class B, suitable for residential or business environments. This device meets the EU requirements (199/519/EC) and the
International Commission on Non-Ionizing Radiation Protection (ICNIRP) on the limitation of exposure of the general public to
electromagnetic fields by way of heath protection. To comply with the RF exposure requirements, this equipment must be operated
in a minimum of 20 cm separation distance to the user.
FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or and experienced radio/TV technician for assistance.
FCC RF Exposure Compliance
This equipment complies with radio frequency (RF) exposure limits adopted by the Federal Communications Commission for an
uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator
and your body.
IC Compliance
RSS-Gen 7.1.3: This device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
IC RF Exposure Compliance (MPE)
This equipment complies with IC RSS-102 RF exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20 cm between the radiator and your body.
ROHS/WEEE Notice
NR3 receivers comply with European Union (EU) Directive 2002/95/EC on the restriction of the use of certain hazardous substances
in electrical and electronic equipment (RoHS Directive).
NR3 receivers comply with the European Union (EU) Directive 2002/96/EC on waste electrical and electronic equipment (WEEE).
The purpose of the Directive is the prevention of waste electrical and electronic equipment (WEEE), and in addition, the reuse,
recycling and other forms of recovery of such wastes so as to reduce the disposal of waste. If purchased in the European Union,
please return the receive rat the end of its life to the supplier from which it was purchased.

Page | 5
1NR3 Overview
Carlson Software’s NR3 is a multi-GNSS, multi-frequency smart antenna offering robust centimeter-level RTK performance in a
variety of applications. The on-board Web user interface (Web UI) allows firmware and features to be configured and managed with
any Wi-Fi capable phone or device. The NR3 supports all constellations, 448 channels, worldwide 4G LTE connectivity, and meets
IP67 requirements.
Figure 1: NR3
This user guide is intended to introduce the NR3 operation to the user along with its many features. We understand there may be
questions or comments. If you have a question, we’d like to answer it!
Carlson Technical Support:
•Email: [e-mail]
•Phone: [phone]
•Online: www.CarlsonSW.com/support

1.1 Shipping Case Contents
The Carlson NR3 system is shipped with the following items:
Figure 2: Shipping Case Contents
Shipping Contents
Item
Main Kits
Part Number
Quantity
1
Carlson Software NR3 Receiver
410222B1775
1
2
USB Cable
214100
1
3
Internal Batteries
215344
4
4
Battery Charger
215501
1
5
DB9 Serial RS232 Male Connector (optional, not pictured)
214995
1
6
DB9 Serial RS232 Female Connector and open-ended
power connector (supply range 9 –30 VDC) (optional, not pictured)
214969
1
7
Bluetooth to Bluetooth dongle for iOS (optional, not pictured)
215258
1
8
AC Wall Adapter (EU / UK / AU / US) (optional, not pictured)
EU: 214879
UK: 214871
AU: 214872
US: 214873
1

Page | 7
1.2 NR3 Appearance
The lightweight Carlson NR3 has a simple and intuitive front panel with informative LED’s, a single serial/power port, two battery
bays, and a SIM card slot.
Figure 3: NR3, Front and Back View
Figure 4: NR3, Bottom View

1.3 NR3 Front Panel
Figure 5: Carlson NR3 Front Panel
LED
ICON
Description
Battery Power (Left / Right)
Blinking: Battery not in use
On and solid: Battery in use
Bluetooth
Off: Bluetooth not in use
Blinking: Bluetooth is discoverable
On and solid: Bluetooth link is active
Wi-Fi
Off: Wi-Fi Access Point Inactive
On and Solid: Wi-Fi Access Point Active
Cellular Modem
Off: Cellular Modem not in use
On and Connecting: Orange and solid
On and Connected: Green and solid
On with Connection Error: Red and solid
Receiver Mode
Green and solid: Fixed RTK
Red and solid: Autonomous (SA)
Orange and solid: Other Modes
Off: No Position
Differential Corrections
On and solid: Differential Corrections Received
Off: Differential Corrections no Received
Data Logging
Off: Logging disabled
On: Logging enabled

Page | 9
1.3.1 Power Button Functions
The NR3 Power Button has several functions.
•Power the device On / Off
•Enable / Disable Data Logging
•Enable / Disable Wi-Fi Status
•Reset to Factory Default
Each of these functions can be selected using the following table:
Current Power Status
Action
Resultant Power Status
NR3 is Off
Press Once
Device will Power On (~20 seconds)
NR3 is On
Press Twice
Wi-Fi will Toggle On / Off (LED indicated)
Press Once
Data Logging will Toggle On / Off (LED Indicated)
Note: Data Logging can only toggle on if messages have been previously
selected.
Press and Hold for 2 Seconds
Device will Power Off
Figure 6: NR3 Power Button Functions

1.4 Ports and Connections
Battery bays, SIM card, and serial port are located on the bottom of the unit, as shown below.
Figure 7: Ports and Connections
1.4.1 NR3 9-Pin Lemo Connector
The Carlson NR3’s 9 Pin Lemo connection will power the device without batteries when using the optional AC Adapter cable. If the
device has batteries installed, this connection will charge and power the NR3.
Communication and logged data transfers can be initiated through the provided USB cable.
1.4.2 Power Input Specifications
Item
Description
Battery
Rechargeable 3.6V –12.24 Wh
Battery Life
6 hours with two batteries (P/N: 215344)
Voltage
9-30V DC external power input with over-voltage protection
Charge Time
4 Hours (typical)

Page | 11
1.4.3 SD / SIM Card Slots
The Micro SD SIM card is located behind the left battery door. To access, compress the battery door latch an open. Lift the SIM
card cover up to remove. Slide the SIM (micro) with the contact facing away from the battery and toward the GNSS antenna of the
unit into the slot (shown below). The SIM card is fully inserted with an audible ‘click’sound. Replace the SIM card cover.
Figure 8: SIM and SD Card Slot Locations
To remove the SIM card, push the SIM card further into the slot, listen for the ‘click’sound and allow the SIM to spring free.

2NR3 Initial Setup
2.1 Install Battery
The NR3 allows two batteries to be installed. When installing the batteries, ensure the correct orientation with the positive end
towards the front of the device (see figure 10).
Access the battery bay by compressing the battery latch towards the inside of the device and pull up. This will swing the battery
latch open.
Figure 9: Battery Door Latch Location
Place the batteries into the designated spot and close the battery cover until the battery latch clicks into place. The projected run
time of the battery is ~6 hours.
Figure 10: Battery Installation
To remove the battery, compress the battery latch towards the inside of the device and pull up. The battery can now be removed
from the battery compartment.

Page | 13
2.2 Install on a Range Pole
Using the standard 5/8-11” mount on the bottom of the receiver, the unit can be secured to a field standard 5/8-11” range pole.
The receiver should be placed carefully on the range pole, to ensure cross-threading does not occur. Hand tighten (35-40 in-lbs of
torque) to secure the unit.
Figure 11: Range Pole Installation
2.3 Powering On / Off
To power on the receiver, press the ‘Power’ button for 1 second. The receiver will power up. To power off the receiver, press the
‘Power’ button for >2 seconds.

3Carlson NR3 Key Features
3.1 Navigation Accuracy
Navigation Performance
Horizontal (m)
Vertical (m)
RTK
0.006m + 0.5ppm
0.01m + 1ppm
Static (long occupation)
0.003m + 0.1ppm
0.0035m + 0.4ppm
Static (rapid occupation)
0.003m + 0.5ppm
0.005m + 0.5ppm
SBAS (WAAS)
0.6m
0.8m
DGNSS
0.3m
0.7m
Autonomous, no SA
1.2m
2.4m
3.2 Interference Suppression
The Carlson NR3 offers superior on-board anti-jamming technology to suppress a wide frequency spectrum of interferences. The
RTK spectrum can be monitored in real-time via the Web Interface or reviewed via logged files.
3.3 Full SurvCE / SurvPC Compatibility
The Carlson NR3 is can be fully configured, operated and monitored using Carlson’s SurvCE and SurvPC programs.

Page | 15
4General Operation
4.1 On-Board Web UI
To view the NR3 Web UI, a connection needs to be made the NR3’s Wi-Fi network. In a phone, tablet, PC, or any other Wi-Fi
capable device, search for the NR3 Wi-Fi network and connect. The name of the NR3 Wi-Fi network will be the serial number of the
device: Shown below using Windows 10.
Figure 12: Connection made to NR3 Wi-Fi Network
The Web UI is located via browser at 192.168.20.1 and the login details are not needed. Once connected to the NR3’s Wi-Fi, open a
browser window and type the address into the address bar.
Figure 13: 192.168.20.1 Entered in Web Browser
Once the web address is loaded, the Overview tab of the Web UI will be presented.

4.1.1 Web UI Overview
From the Carlson NR3 Web UI, receiver configuration and status can be monitored. The upper portion of the Web UI remains on
each of the tabs and pages discussed below. The left portion contains receiver details along with position and accuracy information.
The right portion contains quick ICON statuses of the device on the right. The Log in (if managing user level access) is located on the
far right.
Figure 14: NR3 –Web UI –Upper portion
4.1.1.1 Receiver, Position and Accuracy
The upper-left portion of the Web UI shows important Receiver details along with the current position and accuracy estimates.
These items are shown in all Web UI screens for easy viewing access.
4.1.1.2 Status Icons
The status icons, shown on the upper-right portion of the Web UI show the status of the NR3. These icons indicate important subtle
details.
4.1.1.2.1 Position Mode Icon
Icon
Description
Base
Fixed RTK
Float RTK
Differential
SBAS
Standalone
No PVT
4.1.1.2.2 Cellular Icon
Icon
Description
Enabled, Connecting, Connected w/data flow
Disabled

Page | 17
4.1.1.2.3 Wi-Fi Icon
Icon
Description
Enabled
Disabled
4.1.1.2.4 Bluetooth Icon
Icon
Description
Enabled
Disabled
4.1.1.2.5 Battery Icon
Icon
Description
Charge Level
Battery In Use
No Battery
Battery Charging
4.1.1.2.6 Corrections Icon
Icon
Description
Corrections Received / Sent
No Corrections

4.1.1.2.7 Logging Icon
Icon
Description
Logging On
Logging Off
Disk Not Mounted
Figure 15: Web UI - Overview
The Overview tab shows general information regarding the current receiver status and configuration.
•Quality Indicators: This field illustrates a basic view of the current overall status, signal quality and CPU load of the receiver.
•GNSS: This field shows the satellite constellations tracked and used in position calculation.
oGreen indicates tracking and position use.
oBlue indicates tracking and no position use.
oGray indicates no tracking and no position use.
•Cellular: This field illustrates the status of the cellular modem.
•NTRIP: This field shows the status of the NTRIP feature.

Page | 19
•Wi-Fi: This field reflects the current Wi-Fi settings. If the Wi-Fi is On, connections will be shown (green = current
connection, gray = recent / lost connection).
•Bluetooth: This field illustrates the status of the Bluetooth module. Bluetooth status is shown as ‘paired’ and ‘connected’.
A green line reflects a device is paired and connected to the receiver. A gray line indicates a device is paired but
disconnected.
•Data Streams: This field shows a current map of where data is logged or acquired. A green line indicates data coming into
the receiver from an external source. A blue line indicates data flowing out of the receiver to an external source.
•Logging: This field reflects the status of the internal disk and current logging sessions.
•Battery 1 & 2: These fields show the status (In Use) and power level (%) of the on-board batteries.

4.1.2 GNSS
The GNSS tab shows specific GNSS related data in three categories.
Figure 16: GNSS - Status
