Rongpeng RP27101 User manual

INSTRUCTION MANUAL
AIR-POWERED DRILL
RP27101
TABLE OF CONTENTS:
TECHNICAL SPECIFICATIONS
SAFETY GUIDELINES
KEY PARTS DIAGRAM
IMPORTANT INFORMATION
OPERATING INSTRUCTIONS
MAINTENANCE
TROUBLESHOOTING
EXPLODED VIEW
PARTS LIST
TECHNICAL SPECIFICATIONS:
Drill chuck:
3/8”
Air hose required:
3/8”(9.52mm)
SPEED (NO LOAD):
1800RPM
Weight:
2.58Lb(1.17kg)
SCFM Requirement:
3.8@90PSI
Working pressure:
90PSI(6.3Bar)
Air inlet:
1/4”(6.4mm)
SCFM: Standard Cubic Feet per Minute (the volumetric flow rate of a far corrected to standardized conditions of
temperature and pressure).
NPT: National Pipe Thread
Environmental Responsibilities
Please recycle unwanted materials instead of disposing of them as waste. All tools, hoses and packaging should be sorted,
taken to the local recycling centre and disposed of in an environmentally safe way.
IMPORTANT:
Upon receipt of the product, read and follow all safety rules,
operating instructions before first use it.
And retain this manual for
future reference.
2018

SAFETY GUIDELINES:
DANGER!
Potential hazard that will result in serious injury or loss of life.
WARNING!
Potential hazard that could result in serious injury or loss of life.
CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
NOTE: The world “Note”is used to inform the reader of something he/she needs to know about the tool.
PERSONAL SAFETY
These precautions are intended for the personal safety of the user and others working with the user. Please take time to
read and understand them.
DANGER!
Potential hazard that will result in serious injury or loss of life.
Keep children away from the work area. Do not allow children to handle power tools.
Do not use a tool that is leaking air, that has missing or damaged parts, or that requires repairs. Verify that all screws
are securely tightened.
Never attempt to override tool safety features.
Do not allow unskilled or untrained individuals to operate Air-powered drill or any other air-powered tools.
Do not use oxygen or any other combustible or bottled gas to power air powered tools. Failure to
observe this warning can cause explosion and serious personal injury or death. Use only
the compressed air to power air-powered tools, Use a minimum of 25’(7.6m) of hose to
connect the tool to the compressor. Failure to comply will result in serious injury or loss of
life.
Risk of electric shock: Do not expose a compressor to rain. Store it indoors. Compressor must be
grounded. Do not use grounding adaptors.
Risk of personal injury: Do not direct compressed air from the air hose toward the user or other personnel.
Risk of inhalation: Never directly inhale the air produced by the compressor.
Risk of bursting: Do not adjust the pressure switch or safety valve for any reason. They have been preset at the factory
for this compressor’s maximum pressure. Tampering with the pressure switch or the safety valve may cause
personal injury or property damage.
Risk of burns: The pump and the manifold generate high temperatures. In order to avoid burns or other injuries, do not
touch the pump, the manifold, or the transfer tube while the compressor is running. Allow the parts to cool
down before handling or servicing. Keep children away from the compressor at all
times.
Risk of bursting: Make sure the regulator is adjusted so that the compressor outlet pressure is
set lower than the maximum operating pressure of the tool. Before starting the
compressor, pull the ring on the safety valve to make sure the valve moves freely. Drain
water from tank after each use. Do not weld or repair tank. Relieve all pressure in the
hose before removing or attaching accessories.
WARNING!
Potential hazard that will result in serious injury or loss of life.
Always ensure that the work piece is firmly secured leaving both hands free to control the tool.
Always keep your air tool clean and lubricated. Daily lubrication is essential to avoid internal corrosion and possible

failure.
Do not overload the tool. Allow the tool to operate at its optimum speed for maximum efficiency. Excessive overload
can cause the tool casing to split, and may also lead to excessive wear on moving parts and possible failure.
Use only the light weight coil hoses. For connecting the tool to the compressor coupling. Do not fit quick chande
couplings onto the tool, as the vibration can lead to damage or failure of the coupling.
Always ensure that the tool has stopped before connecting it to the air supply.
Verify that drill’s accessories that are used with this tools are rated at or above the tool’s speed rating (1800RPM).
Failure to properly match the accessory to the tool could result in serious personal injury.
Always ensure that the accessories are rated/ designed for use with the tool.
Ensure that the accessories are correctly and securely fastened before connecting the tool to the air supply.
Locate the compressor in a well-ventilated area. For cooling, at a minimum of 12”(31cm) away from the nearest wall.
Protect the air hose and the power cord from damage and puncture. Inspect them for weak or worn spots every week,
and replace them if necessary.
Always wear hearing protection when using the air compressor. Failure to do so may result in hearing loss.
Do not carry the compressor while it is running.
Do not operate the compressor if it is not in a stable position.
Do not operate the compressor on a rooftop or in an elevated position that could allow the unit to fall or be tipped
over.
Always replace a damaged gauge before operating the unit again.
CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
Keep proper footing at all times in order to ensure correct balance.
Do not wear watches, rings, bracelets, or loose clothing when using any air tool.
For optimal safety and tool performance, inspect the tool daily in order to ensure free movement of the trigger, safety
mechanisms, and springs.
Keep the work area clean. A cluttered or dirty workbench may lead to an accident. Floors should be kept clear.
This tool is not a toy. Use it with caution.
Use the tool in a well-ventilated area.
Verity that the tool has stopped before putting it down after use.
Handling and storage of oil: Use with adequate ventilation. Avoid contact of oil with eyes, skin and clothing. Avoid
breathing spray or mist. Store in a tightly closed container in a cool, dry, well-ventilated area free from incompatible
substances.
Do not use the tool near or below freezing temperatures, as doing so may cause tool failure.
Do not store the tool in a freezing environment to prevent ice formation on the operating valves of
the tool, as doing may cause tool failure.
Disconnect the tool from the air supply and turn off the compressor before changing any accessories,
performing any maintenance, servicing, when the tool is not in use, when it is being handed to
another person, and when it is left unattended. Failure to comply may result in moderate injury or
damage to equipment.
Use safety goggles and ear protection: Wear safety glasses with side shields when operating the
tool/compressor and verify that others in the work area are also wearing safety glass.
requirements and must provide protection from flying particles from the front and the
sides. Air-powered tools are loud and the sound can cause hearing damage. Always wear
ear protection to help prevent hearing damage and loss. Failure to comply may result in
moderate injury.
Note: Recycle unwanted materials rather than disposing of it as waste. Sort the tools, hoses, and package in specific
categories and take them to the local recycling center or dispose of them in an environmentally safe way.

KEY PARTS DIAGRAM
IMPORTANT INFORMATION
General usage description
The RONGPENG Air-powered Drill is a heavy-duty reversible air drill featuring a quiet design, speeds from 1200 to 1700 RPM,
and a 3/8" chuck. No matter what the job entails, this drill will help you conquer whatever the day brings. Applications for
this air drill include: home improvement projects, body work installation and repair, farm implement assembly and repair,
general equipment, auto repair and maintenance, boat repair, truck repair and more.
Compatible compressor and air tool:
GUIDELINES FOR PROPER USAGE AND POERATION
Always ensure the use of appropriately matched air tools and compressors. The compressor should be able to supply a
minimal air delivery of 3.8 SCFM@90PSI to ensure the compressor can run continuously with the RONGPENG Air-Powered
drill. Using tools or a combination of tools that together or separately require air pressure more than that of which the air
compressor can deliver will reduce performance and could void the compressor or tool guarantee/warranty.
Air compressor size & power
2HP
2-1/2 HP
3+ HP
5-6 Gallons
Light duty and intermittent
use
Light duty and intermittent
use
Medium duty and
intermittent use
8-11 Gallons
Light duty and intermittent
use
Medium duty and
intermittent use
Heavy duty and continuous
use
15+ Gallons
Medium duty and
intermittent use
Heavy duty and continuous
use
Heavy duty and continuous
use
AIR SYSTEM
Always use clean, dry, regulated, compressed air at 4 to 7bar (60 to 100PSI).
Do not exceed the maximum and minimum pressure. Operating the tool at the wrong pressure (too low or too high)
will cause excessive noise or rapid wear.
It is recommended that a filter-regulator-lubricator be used and be located as close to the tool as possible.
If a filter-regulator-lubricator is not installed, place up to 6 drops of pneumatic tool oil into the air inlet plug before
each use.
If a filter-regulator-lubricator is installed, keep the air filter clean. A dirty filter will reduce the air pressure to the tool,
which will cause a reduction in power, efficiency, and general performance.
NO.
Description
1
3/8" chuck
2
Trigger
3
Handle
4
1/4”Air inlet plug

CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
Verify that all connections in the air supply system are sealed in order to prevent air from leaking. Failure to comply will
result in moderate injury or damage to equipment.
Read this instruction manual thoroughly or have tool operators read thoroughly before using the tool.
Read all safety guidelines (see section “Safety guidelines”) at the beginning of this manual.
Always inspect the air tool prior to each use to
-Ensure proper use of power source.
-Determine whether the tool is in proper working order.
Only use accessories which are specifically designed for use with this tool (see section ”technical specifications”).
Drain the compressor tank daily. Water in the air supply line will damage the tool.
Clean the air inlet and the filter weekly.
Line pressure should be increased to compensate for unusually long air hoses. The hose diameter should be 3/8”ID.
WARNING!
Potential hazard that will result in serious injury or loss of life.
Do not use the tool if it is not in proper working order.
Do not use oxygen or any other combustible or bottled gas to power this tool.
Do not use this tool in the presence of any flammable liquids or gases.
Keep hose away from heat, oil, and sharp edges. Check hose for wear and tear, and ensure that all connections are
secure. Failure to comply could lead to serious injury or loss of life.
Keep hands and other parts of the body away from the work areas when connecting the air supply. Failure to comply
could lead to serious injury or loss of life.
OPERATING INSTRUCTIONS
Loading and operation
DANGER!
Potential hazard that will result in serious injury or loss of life.
1. Plug in compressor, turn it on, set the pressure regulator to 90 PSI. Attach one end of the air hose to the compressor and
the other end of the air hose (1) to the air-powered drill (2). Use plumber’s tape to prevent air leaks (Fig. A).
2. Insert a drill bit with up to a 3/8" (9.5 mm) diameter shaft. Rotate chuck clockwise to tighten and counter-clockwise to
loosen. (Fig. B).
3. Start by drilling a pilot hole using a smaller diameter drill bit or by punching an indent at the location in which you wish to
drill. Apply steady pressure while drilling, withdrawing drill occasionally to clear cutting. Pull drill out of hole before
releasing trigger (Fig. C).
4. One-handed forward/reverse switch allow for fast direction changes (Fig. D).
WARNING!
Potential hazard that will result in serious injury or loss of life.
Carefully read all instructions in this manual and understand them thoroughly before using the air-powered drill.
Failure to comply could result in serious injury or loss of life.

MAINTENANCE
WARNING!
Potential hazard that will result in serious injury or loss of life.
Disconnect the tool from the air supply before changing accessories, servicing, or performing maintenance.
Only use the tool after replacing or repairing the damaged parts or accessories.
Use only recommended and properly rated replacement parts and accessories. Failure to comply will lead to serious
injury or loss of life.
Repairs must be performed by a qualified service technician.
Maintenance required
Description
Tools or materials
required
Maximum service interval
Each use or every 2 hrs
Monthly
As needed
General inspection-free
movement
Trigger, spring, safety
mechanism
None

In-depth inspection
Worn or broken parts


Replace worn or broken
parts

Lubrication
See below
Pneumatic tool oil

Lubrication: If the Air-powered drill and the compressor are not equipped with an
in –line lubrication system, place up to 6 drops of pneumatic tool oil into the air
inlet before each work day or after every 2 hours of continuous use, depending on
the characteristics of work piece.
Air-operated tools must be inspected periodically, and worn or broken parts must
be replaced in order to keep tools operating safety and efficiently.
Inspect and replace worn or damaged O-rings, seals, etc. Tighten all screws and
caps frequently in order to help prevent personal injury.
Loss of power or erratic action may be due to the following
-Excessive drain in the air line.
-Moisture or restriction in the air pipe.
-Incorrect size or type of hose connector. Check the air supply and follow instructions.
Inspect the trigger, the spring, and the safety mechanism for free movement on a regular basis in order to ensure that
the safety system is fully functional.
Verify that no part is loose or missing and that no part is stuck or jammed.
Disconnect the tool from the air supply, clean, and store it in a sale, dry, and childproof location, when tool is not in
use.
When temperatures are below freezing, keep tools as warm as possible using any safe, convenient method.
Check the air supply for correct size and type of hose connectors. To avoid loss of power or erratic action, ensure that
there is no additional drain on the air line and no moisture or restriction in the air pipe.
Storage:
Apply an ample amount of lubrication before storing the tool.
Run the tool for approximately 30 seconds after lubricating, in order to ensure that the lubrication is uniformly
distributed throughout the tool.
Store the tool in a clean and dry environment.

TROUBLESHOOTING
The following chart lists common issues and solutions. Please read it carefully and follow all instructions closely.
WARNING!
Potential hazard that will result in serious injury or loss of life.
If any of the following symptoms appear while the tool is in use, turn it off and disconnect it from the air supply
immediately. Failure to heed this warning will result in serious personal injury.
Disconnect the tool from the air supply before making any adjustments.
Repairs must be performed by a qualified service technician only.
PROBLEMS
POSSIBLE CAUSES
REMEDIES
Tool runs at normal
speed but loses under
load
■Motor parts worn.
■Cam clutch worn or sticking due
to lack of lubricant.
■Lubricating clutch housing.
■Check for excess clutch oil. Clutch cases need only be half
full. Overfilling
can cause drag on high speed clutch parts, ie. a typical
oiled/lubricated wrench requires 1⁄2 ounce of oil.
GREASE LUBRICATED:NOTE: Heat usually indicates
insufficient grease in chamber. Severe operating conditions
may require more frequent lubrication.
Tool runs slowly. Air
flows slightly from
exhaust
■Motor parts jammed with dirt
particles
■Power regulator in closed
position
■Air flow blocked by dirt.
■Check air inlet filter for blockage.
■Pour air tool lubricating oil into air inlet as per
instructions.
■Operate tool in short bursts quickly reversing rotation back
and forth where applicable.
■Repeat above as needed.
Tools will not run. Air
flows freely from
exhaust
■One or more motor vanes stuck
due to material build up.
■Pour air tool lubricating tool into air inlet.
■Operate tool in short bursts of forward and/or reverse
rotation where applicable.
■Tap motor housing gently with plastic mallet.
■Disconnect supply. Free motor by rotating drive shank
manually where applicable
Tool will not shut off
■‘O’ rings throttle valve dislodged
from seat inlet valve.
■Replace O-rings or return to service center.
Note: Repairs should be carried out by a qualified person.

EXPLODED VIEW
PARTS LIST
No.
Description
Qty.
No.
Description
Qty.
No.
Description
Qty.
1
Bolt M5 x 20
1
14
Rotor blade
1
27
O-ring 11.5 x 1.8
1
2
3/8" Chuck
1
15
Cylinder
1
28
Reverse valve
1
3
Gasket
1
16
Steel wire
1
29
Copper pipe
1
4
Connector
1
17
Rear end plate
1
30
O-ring 12 x 3
1
5
Ball bearing 6201ZZ
2
18
Sealing ring
1
31
O-ring 4 x 1.1
1
6
Gear wheel
1
19
Gun body
1
32
Pin
1
7
Planet cage
1
20
Housing
1
33
O-ring 4 x 2
1
8
Planet gear pin
3
21
Bolt M6x8
1
34
Grip
1
9
Planet gear
3
22
Logo
2
35
O-ring 14.5 x 1.8
1
10
Washer
1
23
Pin 3 x 26
1
36
Air inlet plug
1
11
Front rotor ball bearing 626 ZZ
2
24
Trigger
1
37
Silencing cover
1
12
Front end plate
1
25
Bolt M4 x 8
1
38
Bolt M4 x 6
1
13
Rotor
1
26
Spring
1
If any parts are missing or damaged, or if you have any questions, please contact to distributer.
