RSA-TDPA Differential Pressure Transmitter
Applications & Features
 Apply high accuracy MEMS sensor and digital technologies,
can measure positive, negative or differential pressure .
RSA-TDPA is suitable for wall mount, RSA-TDPA -F is
suitableforflushmount
 It can measure system pressure of fan, blower, filter,
furnace draft and orifice plate and can apply to various
clean room, biological safety cabinet, clean bench, ducts
collection,medical or pharmaceutical machine,etc.
 Multiple ranges, engineering units andoutputs
 Good performance with accuracy of 1.0% and range as low
as 25Pa
 Function keys: zero calibrate, unit select, response timeset,
etc
 Field upgradable LCD display module and multiple ranges
selection
Specifications
Medium: non-combustible, non-corrosive air, insensitive to
moisture, dust, condensation and oil
Working Temp.: -20~70°C
Medium Temp.:0~60°C
Temp. Compensation: 0~50°C
Working Pressure: overload 10xFS, burst 15xFS
Accuracy: ±1.0%FS(±2.0%FS@25Pa range)
Long term stability: ±0.5%FS/Year
Thermal effect: <0.05%FS/°C (zero), <0.08%FS/°C (FS)
Response Time: 0.5~30s, can be set by keys
Process Connection: 5mm ID tubing
Display: 5 digits LCD, displayarea 44x18mm, with unit
indication, field upgradable
Output: 0~10V, 4~20m A (2 wires), RS485 selectable
Output Load: ≤500Ω (current), ≥2kΩ (voltage)
Power: Voltage: 16~28VAC/ 16~35VDC
Current: 18.5~35VDC (RL=500Ω); 8.5~35VDC (RL=0Ω)
Units: 5 units, selected by keys
Measuring Ranges
Zero set: easy to reset by external key
Materials: ABS (housing) & PC (cover)
Protection: IP54
Weight:165g
Approval: CE
Accessories: LCD displaymodule (model RSA-TDPA -LCD),
including 1 LCD module and 1 panel film , and flush mount
panel (model RSA-TDPA -A), can be ordered separately
Models
Model
RSA-TDPA
DP transmitter
RSA-TDPA -F
Flush Mount DP Transmitter
Range
X
Range selection
Output
1
0-10V
2
4-20mA(2 wires)
8
RS485/Modbus
Display
0
N/A
1
LCD
RSA-TDPA-F Flush Mount Differential Pressure Transmitter
It’s the combination of RSA-TDPA (with LCD) and flush mount panel
(model RSA-TDPA -A). The specifications are the same as RSA-
TDPA. And the model is RSA-TDPA -F xx1(with LCD). It’s good for
flush mount in clean room or equipment with no dust and easy to
clean 316 brushed stainless steel panel, with the size
W104×H88×T1.5 and flush mount opening size W93
×H79×D42(mm).
Code
Unit & Range & Display Resolution
Pa
Pa
kPa
in w.c.
mm w.c.
mbar
0
0-25
25.00
0.025
0.100
2.500
0.250
1
0-60/125
60.00
0.060
0.250
6.000
0.600
125.0
0.125
0.500
12.00
1.250
3
0-250/500/1000
250.0
0.250
1.000
25.00
2.500
500.0
0.500
2.000
50.00
5.000
1000
1.000
4.000
100.0
10.00
6
0-2500
2500
2.500
10.00
250.0
25.00
7
0-5000
5000
5.000
20.00
500.0
50.00
8
0-10000
10000
10.00
40.00
1000
100.0
1. Code 1 and 3 have multiple rangeswhich couldbejumperselected.
2. Set the 5 engineering unitsby button keysand the related LCDindicator will be on.
3. For zero center models, add “Z” at the end of the model. For example, RSA-TDPA 1**Z, means
the range is-30-0-30/-62.5-0-62.5pa. Only ranges1~6 have thisselection.

RSA SENSORES, CONTROLES, VALVULAS, ATUADORES, EQUIPAMENTOS, HVAC E AUTOMAÇÃO - Avenida Ragueb Chohfi, 960 - Torre 3, Sala 73 - Jardim Três Marias, São
Paulo-SP, Cep: 08375-000 Telefone Sac: 55 11 2031 6658 –WHATSAPP [phone] Email: [e-mail] Site: http://www.rsa-sensors.com.br
Edition:B/2
-2-
Connection:
Different m odels ha ve different electri ca l connections. Refer to the table as below (x m eans for any m odels).
B
A
GND
OUT
24V
J6 J5
J7
ADJ
SET
ZERO
Note:The ZERO button can be operated outside the
front cover.It’s for resetting zero point. Other
buttons and jumpers are on PCB, customers
need to open the front cover to operate them.
SEL
SET
ADJ
SEL
Terminal:
Models
Connections
RSA-TDPA X1X
Terminal
24V
GND
OUT
Signal
Power+
Power-
0-10V
RSA-TDPA X2X
Terminal
24V
OUT
Signal
Power+
4-20mA
RSA-TDPA X8X
Terminal
24V
GND
OUT
B
A
Signal
Power+
Power-
N/A
B/Z
A/Y
RSA-TDPA1XX and RSA-TDPA3XX Range Jumpers Setting(J5, J6, J7)：
Models
Jumpers
Remark
RSA-TDPA 1XX
Range
J5
J6
J7
√：ON (Connected)
0-60Pa
√
0125Pa
√
RSA-TDPA 3XX
0-250Pa
√
0-500Pa
√
0-1000Pa
√
Surface Mounting:
It can be installed bysurface mount and connected high(+) and low(-) pressures with accessories.
Flush Mounting:
(1) Cut a 95(W)×80(H)mmrectangularholeonthe wall.
(2) Assemble the panel with the transmitter as shownabove.Connect the tubes (be careful of the high(+)/low( -) ports) and the
electrical terminals, then coat some glue on the back of the stainless steel installation panel, insertthe transmitter body into
the holeandpastethe panel with the wall properly.

RSA SENSORES, CONTROLES, VALVULAS, ATUADORES, EQUIPAMENTOS, HVAC E AUTOMAÇÃO - Avenida Ragueb Chohfi, 960 - Torre 3, Sala 73 - Jardim Três Marias, São
Paulo-SP, Cep: 08375-000 Telefone Sac: 55 11 2031 6658 –WHATSAPP [phone] Email: [e-mail] Site: http://www.rsa-sensors.com.br
Edition:B/2
-3-
Zero reset & Calibration:
According to diffe re nt environm ent and sensor’s characteristics , fo r long te rm of using, the s ens o r’s accu ra cy
ma yb e drift. The transm i tter should be ze ro reset after in i ti al installed to meet the spe ci fied a ccu ra cy, and be
ze ro res et pe ri odi ca ll y in e ve ry 6 -12 months’ us ing. It is recommended to be “ze ro reset” after the ini tia l 7 days
continuous working.
Zero reset: keep the high（+）/l ow（-）p ressu re ports un con nected in s table ai r, or directly connect them , p ress the
button “ZERO” for 5s to perfo rm “zero reset”. It means “remove the zero d ri ft of the transmitter in o rd er to imp ro ve the
accuracy”. It is recommended that this operation could be done periodi ca ll y.
Initial ze ro reset: when in i ti al power on, i t should be ze ro rese t after fu ll y wa rm -up and s table, to m eet the
s pecified accuracy.
Long term ze ro drift & reset: It m ay ha ve long term ze ro drift after continuous working; cus tom e rs can reset i t periodi ca ll y.
Re-cal ibration & ze ro reset: when re-calib ra tion needed, ze ro reset should be done firs t. A qualified s tanda rd
m anometer is needed for re -calibration operation. Please follow the operation procedures below.
Attention:
It should be power OFF du ri ng ins ta ll ing and wiring. When using 24 VAC , i t is s trongly re comme nded to power the unit
with independent trans form e r. If sha ri ng a 24 VAC trans fo rme r with other equipments s u ch as contro ll e rs, transmitte rs
or actuators , please m ake s u re the terminals 24 V and GND are connected co rre ctly. Othe rw ise, i t m ay reduce s erious
damages.
Warranty:
●It has l imited warranty for eighteen (18) m onths after the production date.
●It does not extend to any unit that has been s ubjected to m isuse or accident.
●It is , in any event, s trictly lim i ted to the replacement or repair of the product i ts elf.
RSA-TDPA Differential Pressure Transmitter - Operation Instruction
Button definition:
“SET”: Set/Confirm/Save; “SEL”: Bit Select/Decrease; “ADJ”: Adjus t/Increase; “Zero ”:Ze ro Reset
Zero reset: keep the high（+）/low（-）pressu re ports unconnected in s table ai r, or di re ctly connect the two, press the
button “Ze ro ” 5s to rese t the actual “zero point”. It m eans “rem ove the zero d ri ft of the transmitter in order to im prove the
accuracy”. It is recommended that this ope ra tion could be doneperiodically.
Operation instruction:
1. "P810":Reset
SET→SEL/ADJ→P810→SET
User can restore the factory default set. Input “P810”, “Pret” will blink, press button SET, all factory default set will res tore.
2. "P075":Set the response time (Default set: 0.7s, available range: 0.5-30.0s)
SET→SEL/ADJ→P075→SET→SEL/ADJ→XXX→SET. (XXX means set time).
3. "P083": Check LEDdisplay function,it will display the 4 digits one byone.
SET→SEL/ADJ→P083→SET
4. "P081":Set EngineeringUnit(Defaultset: 1, forengineeringunitPa, availableranges:1-5)
SET→SEL/ADJ→P081→SET→SEL/ADJ→XXX→SET (XXXmeans the code of engineering unit),then the relevant LED on.
(Index: 1: Pa; 2: kPa; 3: mbar;4:mmW.C.; 5: inW.C.)
5. "P485": Set RS485 address(Default set: 1, available ranges 1~255, but recommend 1~30)
SET→SEL/ADJ→P485→SET→SEL/ADJ→XXX→SET (XXX means RS485 address) Note
：Refer to the communication data table
6. "P484": Set RS485 RTUMode(Default set: 1, available 1 or 2)
SET→SEL/ADJ→P484→SET→SEL/ADJ→XXX→SET (XXXmeans RTU Mode index)
Index：1: 9600-N-8-1; 2:9600-N-8-2.
Calibration by user:
Even though the product can be re-calibrated by user, it should be operated very carefully. The calibration is already finished in
factory. It may be out of accuracy or even damaged after un-properly re-calibrated.
There are sets of parameters can be re-calibrated by user. Current outputs at both zero (4mA) and full range (20mA) or voltage
outputs at both zero(0V) and full range(10V). All calibrated data will be stored and kept in the flash memory even power supp ly is
fail. But the factory default sets are always kept and can be restored any time.
7. "P271": Re-calibrate analog output,include zero and full range
SET→SEL/ADJ→P271→SET→SEL/ADJ→”key”→SET→SEL/ADJ→Waitjump→SEL/ADJ→SET
“Key” is calibration password:1021.

RSA SENSORES, CONTROLES, VALVULAS, ATUADORES, EQUIPAMENTOS, HVAC E AUTOMAÇÃO - Avenida Ragueb Chohfi, 960 - Torre 3, Sala 73 - Jardim Três Marias, São
Paulo-SP, Cep: 08375-000 Telefone Sac: 55 11 2031 6658 –WHATSAPP [phone] Email: [e-mail] Site: http://www.rsa-sensors.com.br
Edition:B/2
-4-
RSA SENSORES, CONTROLES, VALVULAS, ATUADORES, EQUIPAMENTOS, HVAC E AUTOMAÇÃO - Avenida Ragueb Chohfi, 960 - Torre 3, Sala 73 - Jardim Três Marias, São
Paulo-SP, Cep: 08375-000 Telefone Sac: 55 11 2031 6658 –WHATSAPP [phone] Email: [e-mail] Site: http://www.rsa-sensors.com.br
Calibration method：Enter P271 and password, connect the transmitter with standard meter. At this time the LED will
alternatedisplay “ZErO” and “ FULL”. During “ FULL” display period(last about 25s), press SEL/ADJ to adjust the output become
10V or 20mA. During “ZErO” display period(last about 25s), pressSEL/ADJ to adjust the output become 0V or 4mA, then press
SET to finish. If adjust to the limit, it will display"Err".
System Error signal:
Err 1 Keys input operation code is wrong
Err 2 Input data is notavailable
Err 3 Modbusattempt to write read only register error
Err 4 Modbus CRCcheckerror
Err 6 Password Key input error
