The Programmer is designed to give you the ease and
convenience of programming the memories and options of the
radio from your PC.
Using the Programmer, you can create separate files for
unique applications such as travel, emergency activities, or
special events. These files can contain different settings, such
as memories, power management features, and DTMF
numbers, for each purpose.
The Programmer also gives you the ability to read a
configuration from the radio. The configuration would be stored
in a file on your computer to be changed easily. Then, with
minimal button pushing, you can send the altered file back to
program the radio.
