RTITraq 103 User manual

1
Model 103 GSM/GPRS/GPS Vehicle Tracker
Thank you for purchasing RTITraq. Please read this manual carefully before using
this product, to ensure proper operation. Please note that all specifications and
information contained herein are subject to change without prior notice. Any
changes will be integrated into the latest release. The manufacturer assumes no
responsibility for any errors or omissions in this document.

2
Contents
Table of Contents
Introduction......................................................................................................................................
Applications.....................................................................................................................................
Hardware Description......................................................................................................................4
Specifications...................................................................................................................................5
Installation........................................................................................................................................5
SIM Card Installation.......................................................................................................................6
Turn on the RTITraq........................................................................................................................7
GSM/GPS LED Indicators...............................................................................................................7
Initialization......................................................................................................................................7
Change Password...........................................................................................................................7
Auto Authorization............................................................................................................................7
Authorization....................................................................................................................................8
Delete Authorization.........................................................................................................................8
Single Locating................................................................................................................................8
Auto Track........................................................................................................................................8
Cancel Auto Track............................................................................................................................9
Get Location in Absolute Street Address.........................................................................................9
Location-Based Service (LBS) .......................................................................................................9
Set Monitor Mode............................................................................................................................9
Set Tracker Mode..........................................................................................................................10
Set Geo-Fence..............................................................................................................................10
Cancel Geo-Fence.........................................................................................................................10
Set Movement Alarm.....................................................................................................................10
Cancel Movement Alarm...............................................................................................................10
Set Overspeed Alarm.....................................................................................................................10
Cancel Overspeed Alarm...............................................................................................................10
Alarm Reports................................................................................................................................10
Cut Off the Fuel and Power System..............................................................................................11
Resume the Fuel and Power System............................................................................................11
Arm.................................................................................................................................................11
Disarm............................................................................................................................................11
Alarms During an Armed State......................................................................................................11
Set Silent Mode.............................................................................................................................12
Cancel Silent Mode .......................................................................................................................12
Report the Vehicle Status..............................................................................................................12
Resetting the RTITraq Unit............................................................................................................12
IMEI Checking...............................................................................................................................12
Terminal (local) Time Setting.........................................................................................................12
GPRS Setting................................................................................................................................1
Setting Up APN..............................................................................................................................1

GPRS User Name and Password Setup.......................................................................................1
IP and Port Setup..........................................................................................................................1
Modes: Switch between SMS and GPRS......................................................................................1
Web Platform and PC Tracking Software User Manual Installation .............................................1
Precautions....................................................................................................................................14
Symptoms & Solutions..................................................................................................................14
Introduction
The RTITraq is based on the GSM/GPRS network and GPS satellite positioning
system, which sets multiple functions of security, positioning, monitoring surveillance,
emergency alarms and tracking. It can track and monitor remote targets by SMS or
internet.
eatures
Supports both GPS / GSM station positioning methods.
Supports SMS/GPRS/Internet Network data transmission (GPRS/Internet
instructions on included CD).
Supports GPRS on-line and automatic reconnect GPRS upon signal loss.
Supports SMS/GPRS dual-mode switching.
Supports configuration by remote terminal.
Support for point-to-point, point to group, group-to-group monitoring.
Set multiple functions of security, positioning, monitoring,
surveillance,emergency alarms and tracking.
Applications
Used widely for vehicle and other moving objects tracking.

4
Hardware Description
(1)GSM Antenna connector
(2)SIM card slot
( )SIM card slot Pop-up switch
(4)Monitor jack
(5)GPS Antenna connector
(6)Sensor jack
(7)External harness connection jack
(8)Power/GSM/GPS LED indicator
(9)Backup battery switch
(10) Remote controller receiver antenna (Optional, For model B
only)

5
Specifications
Dimensions .27” x 2.125” x 1.02” (8 *54*26mm)
Weight 0.26 lb. (120g)
Network GSM/GPRS
Band 850/900/1800/1900MHz
GSM/GPRS Module SIM900B
GPS Module SIRF chip
GPS Sensitivity -159dBm
GPS Accuracy 5 meters
GPS Start time Cold status 45s / Warm status 5s / Hot status 1s
Operating Voltage 12 V to 24V
Backup battery Chargeable, changeable .7V 800mAh Li-ion battery
Storage Temp. -40° F to 185° F (-40°C to +85°C)
Operation Temp. -4° F to 149° F (-20°C to +65°C)
Humidity 5% to 95% non-condensing

6
Installation
Installation should be performed by qualified personnel only.
Take care to position the antennas in a location with strong signals.
Install in a location that is free of water and dust.
Locate the 10-position harness and insert into the corresponding connector of the
RTITraq, then connect the wires into the vehicle circuits as shown below:
Wiring diagram
1. Note: The orange wire can be connected to the original car horn; it can also be
connected to a separate siren (purchased separately).
2. Determine whether the door switch is positive- or negative-active. If positive, then
connect the green wire; if negative, then connect the blue wire.
. Install the Reset button and SOS button within a driver's convenient reach.
4. Insert the shock sensor plug into the sensor jack. (shock sensor is optional)
5. Insert the external monitor Microphone into the monitor jack.
6. Connect the GPS and GSM antenna to the corresponding connectors, and
find a suitable place to mount the antennas to ensure adequate signal reception.

7
SIM Card Installation
(1) Use tweezers or other sharp object to grip the SIM CARD popup switch.
(2) Remove the SIM card holder and place the SIM card in it. Replace the SIM card
holder into its original position.
( ) Make sure that the SIM card is capable of executing incoming calls display,
where no calls can be diverted and PIN numbers can be locked. The SMS format
must be in TXT format (the unit cannot recognize PDU format).
Turn on the RTITraq
Connect the positive (RED) and ground (BLACK) wires to the 12V or 24V vehicle
power supply, then wait for 1 minute after connecting to confirm that the tracker is
operating properly. Upon confirmation, turn on the backup battery switch.
GSM/GPS LED Indicators
LED Indicator Status
RED Steady ON No GSM Network Signals
RED Flashing Quickly (1 per Second) GSM Mode Active
RED Flashing Slowly (1 per Seconds) GPRS Mode Active
Green ON GPS Signal Normal
Green OFF No GPS Signal Detected
Initialization
Command: begin+password
Reply: begin ok
Note: Initializes all the settings to default factory settings. (default password: 12 456)
Change Password
Command: password+old password+space+new password
Reply: password ok
Note:
Be sure to record the new password—it will be required in case you need to upload the software
to restore the original setting.
Make sure the new password consists of a 6 digit numeral; otherwise, the tracker will not
recognize the password.

8
Auto Authorization
Command: Call the RTITraq 10 times in succession to establish the calling number as
authorized.
Reply: add master ok
You can enter a maximum of 5 authorized phone numbers for the tracker.
Authorization
Command: admin+password+space+phone number
Reply: admin ok
Note: Authorized numbers should be set by the first authorized number.
Delete Authorization
Command: noadmin+password+space+authorized number
Reply: noadmin ok
Note: If you want to track the target RTITraq when it enters into another country, you
must add the country code before the cell phone number.
Single Locating
If no authorized numbers have been established, any phone number calling the RTITraq will
reply with an SMS, including the current latitude and longitude information. If any authorized
number has been set successfully, the RTITraq will respond only to authorized numbers with
tracking information.
Calling the RTITraq from an authorized number will disconnect the call and respond with real-
time latitude and longitude information.
When GPS signals are weak, the SMS message will report the last position where the tracker
received a valid location. If it is different from the exact current location, note the time included in
the received SMS message.

9
Auto Track
Command: fix0 0s005n +password
Reply: Reports the Geo-info 5 times at 0s intervals. (s:second, m:minute, h:hour).
Note: To report continuously at 0s intervals, replace 005 with *** wildcard.
Interval must not be less than 20s
Cancel Auto Track
Command: nofix+password”
Reply: (Tracker will stop reporting)
Get Location in Absolute Street Address
You must set up the APN of your local GSM network for the SIM card in the RTITraq before
using this function. If there is a user name and password established for GPRS login, please
refer to 5.27 and 5.28 to configure the APN, user name and password for GPRS login.
Command: address+password
Reply: (real street address and name)
Example: 12 Main Street, Anytown U.S.A. 00000
Location-Based Service (LBS)
When the RTITraq can't receive valid GPS signals, it will report positions by location-based
service(LBS). The messages include the GPS coordinates of the last position in SMS mode, but
the LAC (Location Area Code) in the message will be the current new position. The location can
be seen by inputting the LAC code in the menu “Manual Track” of the web platform
www.gpstrackerxy.com. You can also send the command “address+password” to tracker to get
the newest absolute address and GPS coordinates as well. RTITraq will automatically switch to
track by location- based service in GPRS mode, and displayed on the map of web server with
LBS mark. There may be some discrepencies with actual location by LBS tracking; the precision
depends on GSM reception. Note: This feature can be used normally in most areas, depending
on the signal strength of your GSM network. It may not be available in all areas.

10
Set Monitor Mode
Command: monitor+password
Reply: monitor ok!
Note: The factory default mode is Tracker mode.
Set Tracker Mode
Command: tracker+password
Reply: tracker ok!
Note: This is the default mode.
Set Geo- ence
Command: stockade+password+space+lat,lon;lat,lon
Reply: stockade ok
Note: First lat/lon = upper left corner; second lat/lon = lower right corner
Cancel Geo- ence
Command: nostockade+password
Reply: nostockade ok
Set Movement Alarm
Command: move+password
Reply: move ok
Note: Default movement is 200m
Cancel Movement Alarm
Command: nomove+password
Reply: nomove ok
Set Overspeed Alarm
Command: speed+password+space+ digit-speed
Reply: speed ok!
Note: The recommended speed should be not less than 0km/h
Cancel Overspeed Alarm
Command: nospeed+password
Reply: nospeed ok

11
Alarm Reports
Alarm Type Alarm Message Comment
Low Battery low battery+lat./long
Power Off power alarm+lat./long
Driver SOS Button help me!+lat./long Unit will stop sending message if any
authorized number replies “help me!
Geo-fence stockade+geoinfo
Movement move ok
Overspeed speed+ digit-speed+geoinfo
Cut Off the uel and Power System
Command: stop+password
Reply: stop engine succeed
Note: Vehicle will remain immobilized until a resume command is issued.
Resume the uel and Power System
Command: resume+password
Reply: resume engine succeed
Arm
Command: arm+password
Reply: tracker is activated
Note: User must stop the engine, which will send an SMS “arm+password” when the
door has been exited and closed. You will receive an arm-status fail if the
engine is turned on (key is in the ACC position), with the reply “set up fail! pls
turn off ACC”
Disarm
Command: disarm + password
Reply: tracker is deactivated

12
Alarms During an Armed State
Alarm Type Alarm Message Comment
Door door alarm+lat/lon Siren will be sounded if in non-
silent mode.
Shock Sensor sensor alarm+lat/lon Siren will be sounded if in non-
silent mode.
ACC (Key is place in accessory
position) acc alarm+lat/lon Siren will be sounded if in non- silent mode.
Note: The siren will sound for 30 seconds, then recycle after 1 minute. Send
disarm+password to stop.
Set Silent Mode
Command: silent+password”
Reply: silent ok!
Note: The siren will not be sounded after an alarm is triggered, but RTITraq will
continue to send alarm SMS messages to authorized numbers.
Cancel Silent Mode
Command: loud+password
Reply: loud ok!
Note: The siren will be sounded locally after an alarm is triggered.
Important: As a safety precaution, when the vehicle is an area without GSM network
service, the siren will be sounded under non-silent mode if any alarm is triggered (door,
sensor, ACC), but no SMS alarm will be sent.
Report the Vehicle Status.
Command: check+password
Reply:
Power: ON
Battery: HIGH
GPS: OK
ACC: Off
Door: Off
GSM Signal: 1- 2 (performance). Note: The larger the number, the stronger the GSM signal.
Resetting the RTITraq Unit
Command: reset+password
Reply: reset ok
Note: Press the tracker reset button for 1 second to perform a hardware reset.

1
IMEI Checking
Command: imei+password
Reply: The 15-digit IMEI number will be returned.
Terminal (local) Time Setting
Command: time+space+zone+password+space+time
Reply: time ok
GPRS Setting
User must send SMS via cell phone to set up APN, IP and port before starting tracking by GPRS
Setting Up APN
Command: APN+password + Space + your local APN
Reply: apn ok
Note: APN standards for Access Point Name differs from country to country.
For more information about your local APN, please inquire with your local
GPRS network operator.
GPRS User Name and Password Setup
Info: In most countries, the user name and password involving GPRS login are
not compulsory; therefore, this entry can be skipped. For those countries
requiring user name and password, please configure as follows:
Command: up+password+space+user+space+password
Reply: user, password ok!
Note: 12 456 is the default RTITraq password, jonnes is the user name for
GPRS login, 666666 is the password for GPRS login.
IP and Port Setup
Command: adminip+password+space+ipaddress+space+portnumber
Reply: adminip OK
Modes: Switch between SMS and GPRS
Command: gprs+password
Reply: gprs ok!
Note: The default mode is SMS

14
Web Platform and PC Tracking Software User Manual Installation
Web-based Platform: www.gpstrackerxy.com.
Configuration IP: 202.104.150.75 Port: 9000.
Please check “Software Platform User Manual” which can be downloaded from:
www.roboticstech.com/support for detailed operation information.
Registration is required to use this online service. Contact RTI for details.
PC-based tracking software, which can be downloaded from www.roboticstech.com. This is a
free application.
Precautions
1. Please follow these instructions to ensure reliable RTITraq operation:
2. Keep the unit dry. Any liquid, i.e. rain, moisture, etc. may destroy or damage the internal
circuitry.
. Do not use or store the unit in dusty places.
4. Do not put the unit in overheated or overcooled places.
5. Handle carefully. Do not vibrate or shake the device violently.
6. Clean the unit with a piece of dry cloth. Do not clean with chemicals or detergents.
7. Do not paint the unit—doing so may contaminate the product.
8. Do not disassemble nor refit the unit.
9. Please read the user manual carefully before installation and operation. Become familiar
with required voltages and proper operating conditions.
Symptoms & Solutions
Symptoms Solution
Startup Fail Please check the power wiring.
Call Fail Confirm that the GSM antenna is connected. Check whether
the SIM card in place. Check power supply voltage.
Hang up Fail In existence of an authorized number, an unauthorized number dials
up the unit. Please initialize the unit and re-set up the authorized
numbers.
Monitor Fail Check if the authorized number is set up
Location report in
zero digits.
Confirm the position and connection of the external GPS antenna.
