Ruggard PDC9-BRS User manual

PDC9-BRS
Portable Dry Case
9.6 L

2
THANK YOU FOR CHOOSING RUGGARD.
The Ruggard Portable Dry Case protects your
lenses, photographic and optical equipment, mobile
electronics, and other valuables from excessive
moisture. Using the included rechargeable
dehumidifier, you can reduce the interior relative
humidity to help prevent fungus and corrosion from
damaging your gear. The case oers silent operation
with no fan or compressor, and the unit is dripless, so
there’s no need for a water tray. Grab the case and bring
it with you to your next location shoot, and keep your
equipment sealed and protected against moisture-rich
climates.
PRECAUTIONS
• Please read and follow these instructions, and keep this
manual in a safe place.
• Keep this product away from children under 3 years old, as
the small parts can pose a choking hazard.
• Keep this product away from direct sunlight and high-
temperature heat sources.
• Do not cover the vents.
• Do not attempt to disassemble the unit.
• Do not drop or expose the dehumidifier to strong shocks.
• All images are for illustrative purposes only.

3
(RH) Level Recommended Items
40%-50% Camcorders, cameras, lenses,
telescopes, microscopes, endoscopes,
compact discs, film negatives, film
transparency/slides, microfilm, disk
drives, audio tape
Optimal Relative Humidity (RH) Levels
Dimensions
(H × W × D)
Inner: 8 × 10.1 × 7.5 in. (20.3 × 25.7 × 19 cm)
Outer: 8.4 × 11.4 × 9.25 in.
(22.9 × 29 × 23.5 cm)
Volume 0.34 cu. ft. (9.6 L)
Weight Case: 2.8 lb. (1.3 kg)
Case with dehumidifier: 3.6 lb. (1.6 kg)
Case, dehumidifier, and fabric insert:
3.86 lb. (1.75 kg)
Input voltage 110 to 220 V, 50/60 Hz
Relative humidity 50% to 25%
Input voltage 12 V / 2 A DC
Charging time 4-6 hr.
AC Adapter 12 V / 2 A
Dimensions
(H × W × D)
3.2 × 6.5 × 1.6 in.
(8.1 × 16.4 × 4 cm)
Weight 12.1 oz. (344 g)
SPECIFICATIONS
Dehumidifier
PDC9-BRS

4
OVERVIEW
1. Handle
2. Hygrometer: Displays relative humidity level.
3. Rubber gasket
4. Latch
5. Security lock slot
6. Shoulder strap mount
Also included
PDC9-BRS
• Foam liner
• Fabric insert
• Padded dividers (×2)
• Shoulder strap: Adjustable from 35 to 58 in.
(89 to 147.3 cm)

5
1
43 5 6
2

6
OVERVIEW
1. Gel status window: View the current moisture
saturation level of the gels. Orange is low
saturation, and green is high saturation. After
completely charging the gels, let the dehumidifier
cool for 10 to 20 minutes before use. Then,
place it inside the Portable Dry Case along
with the equipment you want to keep dry.
2. Air vents
3. Power LED: Shows that the dehumidifier is
receiving power. Charging can last up to 12 hours
or until the gels turn orange.
Warning! When the dehumidifier is plugged into
an outlet for charging, the unit can become hot to
the touch.
4. DC socket
Dehumidifier
Also included
• AC adapter

7
W
E
T
D
R
Y
4
1
2
3

NINETY-DAY LIMITED WARRANTY
This Ruggard product is warranted to the original purchaser to be free
from defects in materials and workmanship under normal consumer
use for a period of ninety (90) days from the original purchase date or
thirty (30) days after replacement, whichever occurs later. The warranty
provider’s responsibility with respect to this limited warranty shall be
limited solely to repair or replacement, at the provider’s discretion, of
any product that fails during normal use of this product in its intended
manner and in its intended environment. Inoperability of the product or
part(s) shall be determined by the warranty provider. If the product has
been discontinued, the warranty provider reserves the right to replace
it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse,
neglect, accident, alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY
PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. This warranty provides you with specific legal
rights, and you may also have additional rights that vary from state
to state.
To obtain warranty coverage, contact the Ruggard Customer Service
Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Ruggard along with the
RMA number and proof of purchase. Shipment of the defective product
is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.ruggard.com or
call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Ruggard is a registered trademark of the Gradus Group.
© 2021 Gradus Group LLC. All Rights Reserved.
GG1
