Ruijie Cloud Class RCD6000E V3 Series User manual

Ruijie Cloud Class RCD6000E V3 (V4.XX) Series Server
User Manual

Statement
Ruijie Networks ©2000-2018
Ruijie Networks Co., Ltd. All Rights Reserved.
Thank you for using Ruijie products.
Ruijie strongly recommends that you carefully read this manual before using the device. If you perform operations on
the device without reading this manual, Ruijie assumes no responsibilities for any losses incurred. In addition, Ruijie
may make small adjustments to the device to enhance device performance, which may result in slight differences
between operations described in this manual and actual ones. We are sorry for this inconvenience but you can rest
assured that the adjustments will not affect use.

Ruijie Cloud Class RCD6000E V3 (V4.XX) Series Server User Manual
Precautions
The device is a grade-A product. It may cause wireless interference in the living environment. Therefore, take proper
anti-interference measures.
To ensure safe and stable running of the Ruijie Cloud Desktop (RCD) server, correctly connect the power cords of the
RCD server and peripheral devices to the power distribution device (branch connection line or socket). Check that the
power distribution device is correctly grounded before installation, and ensure that the 3-pole power cord delivered with
the device be used.
The power cord can be unplugged to disconnect the device from a power supply. Therefore, install the power socket in
an easily accessible position near the device.
Shut down the RCD server by clicking the start/shutdown button on the Web page or by directly pressing the Power
button on the RCD server. Do not directly cut off power to shut down the device. Otherwise, the hardware of the
RCD server may be damaged. It is recommended to cut off power after normal shutdown of the RCD server.
Ensure that the AC power is within the range of 100 V to 240 V before connecting the device to a power socket.
Do not forcibly insert the power plug into the socket. If you encounter great resistance during insertion, check that the
power plug is inserted in the correct direction.
Shut down the device and remove the power adapter before cleaning.
Do not disconnect the power supply during the product software update.
Contact maintenance personnel for a check if any of the following cases occurs:
- The power cord or plug is damaged.
- Liquid penetrates the device.
- The device is exposed to moisture.
- The device cannot work properly, or fails to work properly after you perform operations in accordance with the
manual.
- The device once fell and is damaged.
- The device shows obvious signs of damage.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
1 Introduction
1.1 Overview
Ruijie Cloud Class (RCC) RCD6000E V3 series servers change the traditional classroom structure and achieve an
unparallel combination of desktop virtualization and computerized classroom, to provide rich teaching approaches
based on courses and deeply optimize teaching. The RCD servers adopt centralized and unified management to
improve the efficiency by 90%, and offer multiple interaction means to enliven the classroom atmosphere.
RG-RCD6000E V3 supports a maximum of 60 virtual desktops.
RCC RCD6000E V3 series servers are high-performance dual-channel servers developed based on the Intel
Grantley-EP platform, support Intel Xeon E5-26XX V3 series processors, and are manufactured using the 22 nm
technology. The servers support a maximum of 16 Double Data Rate 4 (DDR4) Dual In-line Memory Module (DIMMs), a
highest frequency up to 2400 MHz, the Error Checking and Correction (ECC) Registered memory, and multiple
advanced memory redundancy functions.
The front panel of an RCC RCD6000E V3 server provides 12 (2.5-inch or 3.5-inch) Serial Advanced Technology
Attachment (SATA) hot-swapping hard disk slots. The mainboard integrates two high-performance 1000M network
ports to ensure data transmission stability. It also integrates the Baseboard Management Controller (BMC) and
Keyboard, Video, and Mouse (KVM) chips to implement server management and control, including remote control,
alarm management, status monitoring, device information management, heat dissipation control, and commands
delivered by the IPMItool.
Each of the RCC RCD6000E V3 series servers provides two hot-swapping power slots and supports 1+1 redundancy
as well as the PMBus function.
The conformal coating on the mainboards of the RCC RCD6000E V3 series servers achieve excellent anti-oxidation,
anti-corrosion, and anti-moisture performance, thereby ensuring more stable and reliable running and prolonging the
product service life.
1.2 Specifications
Model
RCD6000E V3
CPU
2 x socket-R3 (LGA2011-3)
2 x Intel Xeon E5-26XX V4 CPU
Memory
Maximum
number of slots
16
Maximum
expansion
capacity
640 GB (32 GB per slot)
Memory type
DDR4 RDIMM (2400/2133/1833 MHz)
Standard
configuration
DDR4 ECC RDIMM
16 GB x 6

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
capacity
Unit memory
size
4 GB, 8 GB, 16 GB, and 32 GB (RDIMM)
Hard disk
Slot quantity
Front: 12 x 2.5/3.5-inch SATA hot-swapping hard disk
Standard
configuration
capacity
3 x 240 GB SSD
1 x 1 TB mechanical hard disk
Unit hard disk
capacity
0–1 TB, 2 TB, 4 TB, 6 TB and 10 TB SATA hard disks
Peripheral
device interface
Network
interface
controller
Mainboard: 1 x Intel I350 dual 1000M NIC
2x 1000M adaptive R-J45 network interface
Management
chip
1 x 1000M network interface for management
USB interface
Front: 1 x USB 3.0 interface
Rear: 2 x USB 3.0 interface
Display
interface
Rear: 1 x VGA interface
Expansion slot
PCIe slot
3 x PCIe 3.0 x 8 HHHL expansion slot
1 x FCI Mezzanine slot
Rated power
100–240 V, 9.0–4.5 A, 60/50 Hz
Dimensions
87.6 mm (H) x 448 mm (W) x 750 mm (D)
Ambient
conditions
Operating
temperature
5°C to 35°C
Storage
temperature
-40°C to +70°C
Operating
relative
humidity
20% to 80%
Storage relative
humidity
10% to 90%
Operating
altitude
≤ 3000 m

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
1.3 Appearance
1.3.1 Front Panel
No.
Description
1
Front panel 1
2
Hard disk status indicator
3
Hard disk activity indicator
4
Hard disk drive
5
Front panel 2
● Buttons and Indicators on the Front Panel
No.
Description
1
USB port 0
2
USB port 1
3
NIC1 link/activity indicator
4
NIC2 link/activity indicator
5
ID button and indicator
6
Power button/indicator
7
System health status indicator

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
Front Panel Indicators
Indicator Type
Color
Status
Description
Hard disk indicator
Hard Disk Activity
Indicator
Hard Disk Status Indicator
Green
Green
Red
Idle: Solid on
Reading: Blinking
Solid on
Off
The hard disk drive is
identified or located.
Idle: Solid on
Reading: Blinking
Solid on
Solid on
The hard disk drive is being
rebuilt.
Idle: Solid on
Reading: Blinking
Off
Solid on
The hard disk drive is
faulty.
Power indicator
Amber
Solid on
The power supply is off.
Green
Solid on
The power supply is on.
ID indicator
Blue
Solid on
(IPMI) The machine
identification command is
enabled or the machine ID
button on the front panel is
pressed.
Blinking
The machine identification
command is being
executed.
Off
The identification command
is not being executed or the
machine ID button on the
front panel is not pressed.
NIC1 activity
indicator (front panel)
Green
Solid on
Network interface 1 is
connected/No data is being
transmitted.
Blinking
Network interface 1 is
connected/Data is being
transmitted.
Off
Network interface 1 is not
connected.
NIC2 activity
indicator (front panel)
Green
Solid on
Network interface 2 is
connected/No data is being
transmitted.
Blinking
Network interface 2 is
connected/Data is being
transmitted.
Off
Network interface 2 is not
connected.
System health status
Red
Blinking
A non-critical alarm (for

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
indicator
example, severe
temperature/voltage state)
occurs.
Red
Solid on
A critical or unrectifiable
fault (for example,
critical/unrecoverable
temperature/voltage state)
occurs.
1.3.2 Rear Panel
No.
Description
1
Power device interface 2 (filler panel)
2
Serial port
3
10GE network port 1 (unavailable)
4
10GE network port 2 (unavailable)
5
GE network interface 1
6
GE network interface 2
7
Network management port
8
GE network interface 3 (unavailable)
9
GE network interface 4 (unavailable)
10
Dual USB3.0 ports
11
VGA connector
12
Power device interface 1
● Indicators on the Rear Panel

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
No.
Description
1
AC power indicator 2 (unavailable)
2
Speed indicator of GE network interface 1
3
Link/Activity indicator of GE network interface 1
4
Speed indicator of GE network interface 2
5
Link/Activity indicator of GE network interface 2
6
Speed indicator of the network management port
7
Link/Activity indicator of the network management port
8
Speed indicator of GE network interface 3 (unavailable)
9
Link/Activity indicator of GE network interface 3 (unavailable)
10
Speed indicator of GE network interface 4 (unavailable)
11
Link/Activity indicator of GE network interface 4 (unavailable)
12
AC power indicator 1
Rear Panel Indicators
Indicator Type
Color
Status
Description
AC power indicator
Green
Solid on
The power supply is on.
Off
The power supply is off or is
in hibernation mode.
Speed indicator of the
network management port
Green
Solid on
The network management
port is connected.
Off
The network management
port is not connected.
Link/Activity indicator of the
network management port
Green
Blinking
The network management
port is connected, and data
is being transmitted.
Off
No data is being transmitted.
Link/Activity indicator of GE
network interface 1
Green
Solid on
GE network interface 1 is
connected but no data is
being transmitted.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
Blinking
GE network interface 1 is
connected and data is being
transmitted.
Off
GE network interface 1 is not
connected.
Speed indicator of GE
network interface 1
Green
Solid on
GE network interface 1 is
connected with a speed of
100 Mbit/s.
Amber
Solid on
GE network interface 1 is
connected with a speed of 1
Gbit/s.
Off
GE network interface 1 is
connected with a speed of
10 Mbit/s.
1.4 Hard Disk Slots and Indicators
On Ruijie Cloud Class RCD V3 series servers, the front hard disk interfaces are compatible with 2.5/3.5-inch SATA hard
disks.
Hard Disk Slots
Slot
Description
1
SSD, system disk
2
HDD, data disk
3–4
SSD, cache disks
5–12
Expansion disks
1.5 Memory Module Installation
The mainboard is equipped with 16 DDR4 DIMM slots, with each slot supporting a capacity up to 32 GB. The system is
equipped with 16 GB DDR4 RDIMM ECC memory modules by default. To ensure stable running of the RCD server, one
RCD server supports only one type of memory module. If more memory modules are required for capacity expansion,
learn the existing model before purchase.
To prevent personal injuries and device damage, read through safety suggestions in this manual carefully before
installation.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
Using memory modules of different models will affect system stability and even result in startup failures.
The table below provides rules for installing memory modules.
Quantity of memory
installed
1
2
4
5
6
8
10
12
14
16
CPU0_DIMM_A0
√
√
√
√
√
√
√
√
√
√
CPU0_DIMM_A1
√
√
√
√
CPU0_DIMM_B0
√
√
√
√
√
√
√
√
CPU0_DIMM_B1
√
√
√
CPU0_DIMM_C0
√
√
√
√
√
√
√
CPU0_DIMM_C1
√
√
CPU0_DIMM_D0
√
√
√
√
√
CPU0_DIMM_D1
√
CPU1_DIMM_A0
√
√
√
√
√
√
√
√
√
CPU1_DIMM_A1
√
√
√
√
CPU1_DIMM_B0
√
√
√
√
√
√
√
√
CPU1_DIMM_B1
√
√
√
CPU1_DIMM_C0
√
√
√
√
√
√
CPU1_DIMM_C1
√
√
CPU1_DIMM_D0
√
√
√
√
√
CPU1_DIMM_D1
√
Note: √ indicates that a memory module is installed in this slot. The installation rules are as follows:
For memory channels of different CPUs, install a memory module in one memory slot of CPU0 first and then in one
memory slot of CPU1.
For different memory channels, install memory modules in memory channels A-B-C-D of CPU0 in sequence, and then
in memory channels E-G-F-H of CPU1 in sequence.
For the same memory channel, install memory modules in slots 0 and 1 in sequence.
The performance of the RCD server may deteriorate if you fail to comply with the rules above during memory module
installation. In severe cases, memory modules may fail to be identified and even a black screen (startup failure) and
other faults may occur.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
1.6 Power Module
Ruijie Cloud Class RCD6000E V3 series servers provide two power slots each, and support hot swap and 1+1
redundancy. One system power module is configured by default. A single power module can output power up to 750 W.
1.6.1 Specifications
Item
Description
Rated input voltage range
100-240 V AC, 50/60 Hz
Input current range
9.0-4.5 A
Output voltage
12 V
Maximum output current
62.5 A
Maximum output power
750 W
Operating temperature
5°C to +35°C
Storage temperature
-40°C to +85°C
Operating relative humidity
5% to 95%
Storage relative humidity
5% to 95%
Operating altitude
0-3000 m
1.6.2 Indicators
Name
Indication on the Panel
Status
Description
Output status
indicator
DC OK
Solid green
The system power output is normal.
Blinking green
The system power is normal, and
there is no system power output.
Solid orange
The system power supply is faulty.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
2 Installation Preparations
2.1 Safety Suggestions
To prevent personal injuries and device damage, read through safety suggestions in this document carefully
before RCD server installation.
Safety suggestions below do not cover all possible dangerous situations.
2.1.1 General Safety Suggestions
Follow safety suggestions below during RCD server installation and use:
1. Install the RCD server inside a 19-inch standard cabinet.
2. Do not install the RCD server in a wet place. Keep the RCD server away from liquid and dust and keep the chassis
clean.
3. Keep the RCD server away from heat sources.
4. Ensure that the cabinet and power distribution system are properly grounded.
5. Do not place the device in a passageway. Do not wear loose clothes during operations; otherwise, loose clothes
may hook with components and cause damage. Tighten your coat belts, scarves, and sleeves.
6. Put tools and components away from personnel to prevent collisions.
2.1.2 Movement Safety
The RCD server is large and heavy. Therefore, pay attention to the following points when moving the server:
Prevent frequent movement.
Cut off power and unplug all power cords before moving or handling.
Move the device by at least two persons.
Keep balance and prevent personal injuries during movement.
2.1.3 Electric Safety
Observe local regulations and specifications during electric operations. Only personnel with relevant qualifications can
perform such operations.
Check whether there are hidden risks in the work area, for example, check whether the device is grounded, whether the
grounding is reliable, and whether the ground is wet.
Learn about the position of the indoor emergency power switch before installation. Cut off power in case of accidents.
Check the device carefully for confirmation when the power supply needs to be disconnected.
Do not put the device in a wet place. Keep the device away from liquid.
Improper or incorrect electric operations may cause a fire, electric shock, and other accidents, and lead to severe
and fatal personal injuries and device damage.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
Direct or indirect contact with high voltage or mains power supply via wet objects may cause fatal dangers.
2.1.4 Static Electricity Safety
To prevent damage caused by static electricity, pay attention to the following points:
Properly ground the device and cabinet.
Keep the indoor installation environment clean and free of dust.
Keep proper humidity conditions.
2.2 Installation Environment Requirements
The RCD server must be installed indoors. To ensure normal running of the RCD server and prolong the service life, the
installation site should meet the following requirements:
2.2.1 Bearing Requirements
Evaluate the ground bearing requirements based on the actual weight of the RCD server and its accessories (for
example, cabinet, chassis, and power modules), and ensure that the ground of the installation site meets the
requirements.
2.2.2 Space Requirements
To ensure sufficient space for chassis movement as well as module insertion/removal and maintenance, it is
recommended that the width of corridors in the equipment room be no less than 0.8 m.
Do not install the RCD server against walls for ease of heat dissipation and maintenance. Reserve certain space (no
less than 0.4 m) on the left and right panels before and after installation, to facilitate heat dissipation.
2.2.3 Temperature/Humidity Requirements
To ensure normal running of the RCD server and prolong its service life, it is necessary to maintain proper temperatures
and humidity in the equipment room. If the humidity of the equipment room is too high for a long time, the insulation
performance of insulation materials may deteriorate and mechanical performance degradation such as electric shocks
may be incurred. If the humidity is too low, the insulation pad may shrink and cause loosening screws. Moreover, static
electricity is prone to occur in dry environments and endanger the internal circuits of the RCD server. Overhigh
temperatures can accelerate the aging of insulation materials, greatly reducing the reliability of the RCD server and
severely affecting its service life.
The requirements of Ruijie RCD servers for the temperature and humidity are as follows:
Temperature: 5°C to 35°C
Relative humidity: 20% to 80%
The temperature and humidity of the operating environment of the device are measured at 1.5 m above the
ground and 0.4 m in front of the RCD server rack when no protection plate is used in front of and behind the RCD
server rack.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
2.2.4 Cleanliness Requirements
Dust is hazardous to device running. Dust accumulated on the device will cause electrostatic adsorption and result in
poor contact at metal contacts. Especially, when the indoor relative humidity is low, accumulated dust is more apt to
cause electrostatic adsorption, which will not only shorten the service life but also cause communication failures. The
table below lists the requirements for the content and diameter of dust particles in the equipment room.
Dust
Content (Unit: Particle/m³)
Dust particle (diameter ≥ 0.5 µm)
≤ 3.5 x 10^6
Dust particle (diameter ≥ 5 µm)
≤ 3.5 x 10^4
Apart from dust, salt, acid, and sulphide in the air are strictly limited in the equipment room. These harmful substances
will accelerate metal corrosion and component aging. Therefore, the equipment room should be properly protected
against the intrusion of harmful gases, such as sulfur dioxide, hydrogen sulfide, nitrogen dioxide, and chlorine gas. The
table below lists limit values for harmful gases.
Gas
Average Value (mg/m3)
Maximum Value (mg/m3)
Sulfur dioxide
0.2
1.5
Hydrogen sulfide
0.006
0.03
Nitrogen dioxide
0.04
0.15
Ammonia gas
0.05
0.15
Chlorine gas
0.01
0.3
The average value refers to the average value in a week. The maximum value refers to the maximum value in a
week. The device cannot stay in an extreme hazardous gas environment for more than 30 minutes.
2.2.5 Grounding Requirements
A proper grounding system is the basis for stable and reliable running and is indispensable for preventing lightning
strikes and interference. Carefully check the grounding conditions at the installation site according to the grounding
specifications, and complete grounding properly based on the actual situation.
Safety Grounding
It is necessary to ensure that the cabinet and power distribution device are securely grounded when the device uses the
AC power supply. Otherwise, electric shock may be aroused when the insulation resistance between the power supply
inside the device and the device housing becomes small.
Protection grounding connections should be provided in buildings so that the device can be connected to the
protection ground.
Lightning Grounding
The lightning protection system of facilities is standalone, and is composed of a lightning rod, a lower conductor, and a
connector connected to the grounding system. The grounding system is usually used for power reference grounding and
safety grounding of the cabinet. Lightning discharge grounding is required only for facilities and is not required for the device.
Electromagnetic Compatibility Grounding
Grounding required for electromagnetic compatibility includes shielded grounding, filter grounding, noise and
interference suppression, and level reference, which contribute to the overall grounding requirements. The grounding

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
resistance is required to be smaller than 1 ohm and the ground terminals of the cabinet should be grounded before
device running.
2.2.6 Anti-interference Requirements
Anti-interference herein refers to resistance against electromagnetic and current interference. The anti-interference
requirements are as follows:
Take effective power grid interference prevention measures for the power supply system.
Keep the RCD server away from the grounding device or lightning grounding device of the power equipment to prevent
strong interference.
Keep the RCD server far away high-frequency heavy-current devices such as high-power radio transmitting station and
radar launcher.
Take electromagnetic shielding measures when necessary.
2.2.7 Lightning Protection Requirements
Ruijie RCD servers can guard against lightning strikes. As electric devices, too strong lightning strikes may still damage
the devices. Therefore, it is necessary to take lightning protection measures.
Ensure that the ground cable of the cabinet is in good contact with the ground.
Ensure that the neutral point of the AC power socket is in good contact with the ground.
It is recommended to install a power lightning arrester in front of the power input end to enhance the lightning
prevention for the power supply.
2.2.8 Installation Unit
Ensure that the following conditions are met regardless of whether the RCD server is installed inside a cabinet or
directly placed on a workbench:
Sufficient space is reserved at the air inlet and air vents of the RCD server, to facilitate heat dissipation of the RCD
server chassis.
Ruijie RCD server is equipped with fans. Its heat dissipation principle is as follows: Cold air around the housing is
sucked into the device via air vents and hot air is exhausted from the rear side of the housing via the fans. Therefore, at
least 15 cm space needs to be reserved around the air vents, for ease of heat dissipation. It is recommended to install
the RCD server inside a 19-inch standard cabinet. The RCD server can be horizontally placed on a clean plane if
conditions are limited. It is recommended to install air conditioners in hot areas.
The ventilation and heat dissipation of the cabinet and workbench are satisfactory.
The cabinet and workbench are strong enough to support the weight of the RCD server and its accessories.
The cabinet and workbench are properly grounded.
2.3 Cabinet Installation Requirements
If the RCD server is to be installed inside a cabinet, check that the cabinet meets the following conditions:
1. A 4-column 19-inch standard cabinet is used.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
2. The distance between square hole strips on the left and right sides of the 19-inch standard cabinet is 465 mm.
The figure below shows a 19-inch standard cabinet.
3. The distance between the square hole strip on the rack column and the outer side of the front cabinet panel is
greater than 180 mm, the thickness of the front cabinet panel is smaller than 25 mm, the available space is greater
than 155 mm, and the cabinet depth (distance between the front and rear panels) is greater than 1000 mm.
4. The slide rails (or trays) of the cabinet meet the requirements of the RCD server and can support its weight.
5. A ground terminal is installed reliably for the cabinet to ensure that RCD server is securely grounded.
6. The cabinet is well-ventilated and the porosity of the front and rear panels is both greater than 50%.
2.4 Installation Tools and Devices
Common tool
Phillips screwdriver, wires, network cable, fastening bolt, diagonal pliers, and binding strap
Special tool
ESD gloves, wire stripper, crimping tool, RJ11 crimping tool, and impact tool
Meter
Multimeter
Relevant Device
PC and display
Some of the tools are prepared by users.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
3 Installation Procedure
Ensure that you have read through Chapter 2 carefully and requirements in Chapter 2 are all met.
3.1 Installing Guide Rails
1. Horizontally place the guide rail in the installation position on the cabinet, hook the rear end of the guide rail to the
hole on the cabinet, and fasten the positioning screws on the front end to corresponding positions.
2. Use screws to fasten the guide rail. Front end of the guide rail: Reserve the middle hole for fastening the server. Use
a screw to fasten the upper hole. Rear end of the guide rail: Use a screw to fasten the lower hole.
3. Place the server on the guide rail and install screws to fasten the server.
3.2 Installing the Chassis Inside a Cabinet
1. Uplift the RCD server, align the three rivets on each side of the server with the three rivet holes of the guide rail on
the same side, lean the server backwards by about 5°, and then fasten the rear, middle, and front rivets of the
server to the rivet holes of the guide rails in sequence.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
2. Uplift the clips marked with 1 in the following figure on the guide rails on both sides, and push the server into the
cabinet in the direction indicated by the arrow marked with 2 in the following figure.
3. After pushing the server into the cabinet, tighten screws on the left and right handles of the server.

Ruijie Cloud Class RCD6000E V3 (V1.XX) Series Server User Manual
3.3 Connecting Cables
Connect the power cord delivered with the device to a power supply.
Insert the plug of the power cord into a power strip. Ensure that the main power supply is disconnected before the
power plug is inserted.
Connect the network cable with the standard RJ45 connector to the system network.
Ensure that the power cord delivered with the device be used, to prevent safety accidents.
3.4 Verifying Installation
After the mechanical installation of the RCD server is completed, check the following items before powering on the RCD
server:
If the RCD server is installed inside a cabinet, check whether the cabinet and the installation angle iron are secured. If
the RCD server is placed on a workbench, check whether sufficient space for heat dissipation is reserved around the
RCD server and whether the workbench is steady.
Check whether the power cord delivered with the device is used.
Check whether the cabinet is securely grounded.
Check whether the RCD server is correctly connected to other devices.
Check whether the power cord is long enough and prevent overstretch of the power cord.
Learn about the position of the indoor emergency power switch before installation. Cut off power in case of accidents.
