Russell Hobbs RHCF99B User manual

Model number(s):
RHCF99B & RHCF142B
For Customer Services & Spare Parts please call 0345 2088750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
IMPORTANT:
RETAIN FOR FUTURE REFERENCE
Chest Freezer
Instruction Manual

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
Contents
Safety Instructions ………………………………………. 3-4
Electrical Safety ………………………………………. 4
Before switching on ………………………………………. 5
Unit & Spare Parts ………………………………………. 5
Transportation & Handling ………………………………………. 6
Positioning ………………………………………. 6
Product Overview ………………………………………. 7
Installation ………………………………………. 8
How to use ………………………………………. 9
Temperature selection ………………………………………. 9
Power Failure ………………………………………. 10
Storage Advice ………………………………………. 10
Defrosting ………………………………………. 11
Internal Cleaning ………………………………………. 12
External Cleaning ………………………………………. 12
When not in Use ………………………………………. 12
Trouble shooting ………………………………………. 13-14
Important notes ………………………………………. 15
Connection to the mains ………………………………………. 16
Guarantee ………………………………………. 17
Technical specification ………………………………………. 18

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
3
Safety Instructions
Important note:
Please read this booklet before installing and switching on this appliance.
The manufacturer assumes no responsibility for incorrect installation and
usage as described in this booklet.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
•Children should be supervised to ensure that they do not play with the
appliance.
•If the supply lead is damaged it must be replaced by a qualified person using
the correct lead, available from 0345 208 8750.
•Do not store chemicals or liquids such as methanol or petrol etc., which are
easy to evaporate, burn or explode.
•Do not store heavy objects on top of the appliance and do not allow the
refrigerator to become wet.
•The circuitry for the appliance should be isolated. The unit should always be
plugged into its own plug socket and never into an extension lead.
•The voltage of this products should be 220-240V,50Hz
•Only ever remove the plug from the socket by gripping the plug firmly –do
not pull the wire to remove the plug.
•Do not use electrical appliances in the freezer appliance.
Do not use mechanical devices or other artificial means to accelerate the
defrosting process.
Caution: Risk of fire –do not store flammable liquid or other flammable
material in this appliance.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
4
Safety Instructions
•If this appliance is to replace an old refrigerator with a lock; break or
remove the lock as a safety measure before storing it, to protect children
from locking themselves inside.
•Old refrigerators and freezers contain insulation gases and refrigerant,
which must be disposed of properly. Entrust the disposal of a scrap unit
categorically to the competence of your local waste disposal service and
contact your local authority or your dealer if you have any questions.
•Please ensure that the gas pipe at the rear of your appliance does not get
damaged prior to being picked-up by the relevant waste disposal service.
•This model contains R600a refrigerant (the coolant isobutane), a natural gas
that is very environmentally friendly but also combustible. When
transporting and installing the unit care must be taken to ensure that none
of the refrigeration circuit components become damaged. In the event of
damage avoid any naked flames or any sources of ignition and ventilate the
room in which the unit is placed for a few minutes.
Warning: Keep the ventilation openings in the appliance enclosure, clear of
obstruction.
Electrical Safety
THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET
Before switching on, make sure that the voltage of your electricity supply is the same
as that indicated on the rating plate. This product is designed to operate on 220 –
240V AC; 50Hz, 120 W, 1A. Connection to any other power source may damage the
unit.
This product may be fitted with a non re-wireable plug. If it is necessary to change the
fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or
damaged, the plug must not be used until a suitable replacement is obtained.
If the plug has to be changed because it is not suitable for your socket, or becomes
damaged in any way, it should be cut off and an appropriate plug fitted following the
wiring instructions below. This should be carried out by a qualified electrician. The plug
removed must be disposed of safely, as insertion into a 13 Amp socket is likely to
cause an electrical hazard.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
5
Before Switching On
•Wait 3 hours before plugging in the appliance in to the mains supply
to ensure optimum performance, this allows the refrigerant to
settle.
•There may be an odour when you first switch on the appliance, it
will disappear when the appliance starts to cool.
•To save energy, you should minimize the frequency and duration of
door opening.
Unit Parts
Before installation, check that all parts listed below are present. If any
parts are missing, please contact the product care service team on
0345 208 8750.
Important Information
Unit & Spare Parts
For the following spares please contact the customer
service team on
0345 208 8750 or visit productcareuk.com
Item Quantity
Basket/shelf 1
Ice Scraper 1
Instruction Booklet 1

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
6
Transportation and Handing
For safe lifting, tilt the appliance backwards by no more than 45 degrees, hold
the base and rear corners of cabinet. Lift the freezer carefully. Never use the
door handles for lifting. To move the appliance on a flat level surface, tilt it
slightly backwards onto the two rear rollers and push backwards.
This unit is heavy and could cause injury –ensure there is sufficient person
power to move the appliance.
Positioning
This appliance should only be placed on a flat, firm surface.
Choose a dry and well-ventilated space. No less than 10cm must be left around the
sides and at the back, to allow efficient cooling.
Choose a location away from a heat source, such as direct sunlight, a radiator or
oven.
The appliance should be positioned so that the plug is easily accessible.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
7
Product overview
1
2
3
4
5
6
1. Handle
2. Wire basket
3. Temperature control dial & indicator lights
4. Adjustable feet
5. Power cord
6. Drainage hole

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
8
Installation
After installation, do not switch the power to the freezer on for at least 3
hours –the unit needs to stand. The unit should be kept away from direct
sunlight. If the appliance is located on carpet, damage may be caused to the
carpet due to heat being emitted from the unit.
Remove all transport tapes and foam protection pieces . Clean the interior
of the freezer with a cloth dampened in lukewarm soap and water. Wipe
with clean water and wipe dry.
When the appliance has been positioned, adjust the two side feet to ensure
the unit is stable. This is essential to ensure quiet running and proper door
opening /closing. See below.
Once the appliance has been standing for 3 hours, plug in the freezer, locate
the thermostat knob on the outside of the product and set to "3" position
and switch on the power. The compressor will begin to work. Close the
door.
This appliance is suitable to be placed in garages.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
9
Allow to stand for a minimum of 3 hours before plugging in to the mains
The temperature in the appliance is controlled by the temperature
control knob located on the front face, at the bottom right hand side.
Rotate the control knob left or right to regulate the temperature inside
the freezer.
On the temperature control, 1 is the warmest setting and 6 is the coldest
setting. Under normal conditions the temperature control should be set
between 2 and 3. Once the temperature control has been set, close the
door and plug in the appliance. We recommend that the door is not
opened for a minimum of 4 hours to allow the appliance to reach the
standard operating temperature. The ‘OFF’ position is an automatic
shutdown, and it will defrost.
Note: The standard operating temperature for the freezer compartment
should be between -12°C and -30°C.
Indicator lights
Power Indicates the freezer is switched on.
Run Indicates the appliance is working. (The red indicator
light will switch on and off as required, this is normal)
Alarm Indicates when the inside temperature of the appliance is
too high
How To Use and Temperature Selection

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
10
Power Failure
If there is a power failure during the storage of frozen foods, keep the
door closed. If the temperature within your freezer should rise, do not
refreeze the food without checking it's condition.
•Ice Cream: Once thawed should be discarded.
•Fruit and Vegetables: If soft should be cooked and used up.
•Bread and Cakes: Can be refrozen without danger.
•Shellfish: Should be refrigerated and used up quickly.
•Cooked Dishes: i.e. casseroles should be refrigerated and used up.
•Large Pieces of Meat: Should be refrigerated and used up quickly
•Small Joints: Should be refrigerated and used up quickly
•Chicken: Should be refrigerated and used up quickly
Storage Advice
•Store fresh food in airtight boxes or wrap in bags or foil which is
suitable for freezing.
•Do not allow frozen food into direct contact with food to be
frozen.
•Pre frozen food must be place in the freezer as quickly as
possible after purchasing.
•To prevent frost damage to fresh vegetables or fruits they must
be processed appropriately before being placed into the freezer
compartment.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
11
Never use sharp metal tools as it may damage the appliance.
Never use an electrical heater, this may cause an electric shock.
Note: Care must be taken when performing the following procedure.
Defrost twice a year or when a frost layer of approximately 7 mm (1/4”) has
formed.
•6 hours before the defrosting process, set the thermostat knob at the “6”
position to make sure the food is at the lowest temperature before removing
the frozen foods. All food should be wrapped in several layers of newspaper
and stored in a cool place (e.g. fridge or larder).
•Switch off the appliance at the socket outlet and pull out the mains plug.
•Remove the freezer basket. Leave the lid open. Containers of warm water (not
hot) may be placed carefully in the freezer to speed up the defrosting process.
•Never use hairdryers, electrical heaters or other such electrical appliances for
defrosting.
•When the ice has melted, drain the water in the bottom of the freezer by
removing the plastic tap in the bottom of the appliance (this is inside the
appliance)
•NOTES: PLEASE KEEP THE RUBBER COVER SAFE DURING THE DEFROSTING
PROCESS AND PUT IT BACK AFTER THE DEFROSTING PROCESS IS COMPLETE
•Situated at the front left bottom corner of the appliance (this is on the outside
of the appliance), is a small plastic drain cap. Place a container under the drain
tap to catch the defrosted water. Unscrew the tap slowly so the drips out at
first, once the tap is completely unscrewed the water will flow in to the
container. This may take several attempts to drain all the water. After the
draining has been completed, replace the tap in the appliance and rotate the
drainage cap on the outside of the appliance.
•Wipe up any spillages that may have occurred.
Defrosting

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
12
Internal Cleaning
Disconnect the appliance from the power supply before cleaning.
Do not pour water over the appliance.
The cavity should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water.
Clean the accessories separately with soap and water. Do not put
them in the dishwasher.
Do not use abrasive products, detergents or soaps. After washing,
rinse with clean water and dry carefully. When the cleaning
operations are complete, reconnect the plug with dry hands.
External Cleaning
Wash the outer cabinet with warm soapy water. Do NOT use
abrasive products.
There are sharp edges on the underside of the product so care
should be taken when cleaning.
When the appliance is not in use
When the appliance is not in use for long periods, disconnect from
the electricity supply, empty all of the food and clean the inside.
Leave the door open to prevent the build-up of odours.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
13
Troubleshooting
If the appliance has stopped functioning completely:
• Check the electrics in the location of the appliance.
• Check the plug has been correctly connected to the socket.
• Check the fuse in the plug.
• Are there any faults with the socket? For this purpose, try the plug of your
appliance by connecting it to a socket which you are sure is working.
If your freezer does not get cold enough:
• Turn the Thermostat control further towards 6.
• Are the doors of your freezer opened frequently and do they remain open
for long periods of time? If so, reduce the frequency and length of time the
doors are open for.
• Ensure the door is fully shut and the seal is making complete contact to the
cabinet.
• Is your appliance over-filled?
If the appliance is operating noisily (compressor noise):
• This is normal. This noise indicates that the compressor is operating
normally.
• As the compressor is being energized, it might run a bit more noisily for a
short period of time.
If the appliance is still noisy:
• Check the appliance is level. Use a spirit level if necessary. Adjust the feet at
the front base of the appliance.
• Check there is nothing behind the appliance.
• If there is a vibrating sound from the basket or the items placed on the
shelves, rearrange the items so that they are more secure.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
14
Bubbling and gurgling sound:
• This noise is emitted as the coolant fluid flows through the
pipes within the system. This is normal.
Water flowing sound:
• This is the normal sound of water flowing into the drain trough
during the defrosting process.
Excessive moisture build up inside the refrigerator:
• Check all food is covered and sealed. Check wet containers have not
been placed in the appliance.
• Are the doors of the appliance opened frequently? Once the door is
opened, the humidity found in the air in the room enters the appliance,
especially if the humidity levels in the room are very high. The more
frequently the door is opened in humid conditions the more chance of
the build up of moisture.
The doors do not close properly:
• Ensure there are no obstructions preventing door closure.
• Check the door compartments and shelves are correctly in place.
• Check the door seal is not warped or torn.
• Check the appliance is level.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
15
IMPORTANT NOTES:
•In case of a sudden power loss or disconnecting and reconnecting
of the plug to the electrical socket, the compressor protective
thermal element will be opened, as the pressure of the gas in the
cooling system of your refrigerator has not yet been balanced. 4
or 5 minutes later, your refrigerator will start to operate; this is
normal.
•If you won't be using your refrigerator for a long time, disconnect
the plug from the socket. Clean your refrigerator as per the
cleaning instructions and leave the door open to prevent any
humidity or odour formation.

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
16
WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of AC230V ~ 50HZ.
Check that the voltage marked on the product corresponds with your supply voltage.
For UK use only –Plug fitting details (where applicable):
As the colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as follows:
The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which
is marked with the letter E or by the earth symbol or coloured GREEN or
GREEN/YELLOW.
The BLUE wire is the NEUTRAL and must be connected to
the terminal marked with the letter N or coloured BLACK.
The BROWN wire is the LIVE wire and must be connected
to the terminal marked with the letter L or coloured RED.
Always ensure that the plug cord grip is fastened correctly.
If a13A (BS1363) fused plug is used it must be fitted with a 13amp fuse conforming
to BS1362 and be BSI or ASTA approved.
Connection to the mains supply

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
17
Guarantee
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship you must contact Product Care with the original proof
of purchase so a replacement or refund can be arranged.
Refund or replacement is at the discretion of Product Care.
The following conditions apply:
•Product Care will require a valid proof of purchase at the point of
replacement or refund.
•The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which has been supplied.
•It must be used for domestic purposes only and for its intended
use.
•This guarantee does not cover wear and tear, damage, misuse or
consumable parts.
This does not affect your statutory rights.
Imported by
G2S LIMITED
WIGAN
WN2 4AY

For Customer Services & Spare Parts please call 0345 208 8750
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
or visit us at www.productcareuk.com
18
Technical Specification
Model number RHCF99B
Rated Voltage 230V –240V ~ 50Hz
Capacity 99L
External Dimensions(HxWxD) 850mm x 565mm x 523mm
Net Weight; Approx. 25.0 kg
Model number RHCF142B
Rated Voltage 230V –240V ~ 50Hz
Capacity 142L
External Dimensions(HxWxD) 850mm x 730mm x 523mm
Net Weight; Approx. 30.0 kg

For Customer Services & Spare Parts
please call
UK: 0345 2088750
Opening times: Monday - Friday
8am –8pm & Saturday 9am –1pm or visit
us at www.productcareuk.com
Revision R2
This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this
symbol is marked on a product/batteries, it means that the product/batteries
should not be disposed of with your general household waste. Only discard
electrical/electronic/battery items in separate collection schemes, which cater
for the recovery and recycling of materials contained within. Your co-operation
is vital to make sure thesuccess of these schemes and for the protection of the
environment. For your nearest disposal facility, visit www.recycle-more.co.uk
or ask in store for details.
We reserve the rightdue to possible changes to design to alter the
instruction manual without prior notice.
