Russell Hobbs RHVM901 User manual

Family Flatbed Inverter Microwave
User Guide
Model Number:
RHVM901
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
PLEASE RETAIN
FOR FUTURE REFERENCE

CONTENTS
Page(s)
SAFETY INSTRUCTIONS
3-9
ABOUT YOUR MICROWAVE
10-11
PRODUCT INFORMATION
12
UNPACKING THE MICROWAVE
13
PRODUCT OVERVIEW
14
MICROWAVE OVEN INSTALLATION
15-16
CONTROL PANEL
17
HOW TO USE THE MICROWAVE
18-26
COOKING TIPS
27
CLEANING THE MICROWAVE
28
PROBLEM SOLVING
29-32
GUARANTEE & CUSTOMER SERVICES
33
CONNECTION TO THE MAINS SUPPLY
34-35
NOTES
36
DISPOSAL
37
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
2

SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•This appliance is intended to be used in the household
and general domestic applications. It is not intended
to be used in industrial or commercial applications.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervised.
•If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent
person.
•It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection
against exposure to microwave energy.
•Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
3

SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•A minimum clearance of 7.5cm is required between the
oven and any adjacent walls. Leave a minimum
clearance of 30cm above the oven.
•Use only cookware and utensils that are approved
for use in a microwave oven.
•When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
•This microwave is intended for heating food and
beverages only. The drying of food or clothing and
heating of warming pads, wheat bags, slippers,
sponges, damp cloth and similar is extremely dangerous
and may lead to risk of injury, ignition or fire.
•If materials inside the oven smoke or catch fire, keep
the oven door closed to stifle the flames, turn the oven
off at the wall switch, or shut the power off at the fuse
or circuit-breaker panel. If smoke is emitted , switch off
or unplug the appliance and keep the door closed in
order to stifle any flames.
•Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be
taken when handling the container.
4

SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
Do not heat baby bottles with the teat left on. Remove
it if replacing the bottle back into the oven.
•Eggs in their shell and whole hard-boiled eggs should not
be heated in microwave ovens since they may explode,
even after microwave heating has ended.
•The oven should be cleaned regularly and any
food deposits removed.
•Failure to maintain the oven in a clean condition,
especially if liquid is left under the turntable, could lead
to deterioration of the surface that will adversely affect
the life of the appliance that may result in a hazardous
condition.
•The microwave oven should be used freestanding
only and must not be built-in or used in a cabinet
•If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
5

SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•To avoid fire, electric shock, or injury, never immerse
the microwave, cord, or plug in water or liquid.
•Do not use attachments not recommended by the
manufacturer. Only use thermometers approved for
use in microwaves.
•The appliance and its accessible parts may become hot
during use. Care should be taken to avoid touching
heating elements.
•Do not leave the microwave oven unattended while
you are using it.
•Do not use the microwave when it is empty. This
could damage the oven.
•Do not use metal pans, dishes with metal handles or
anything with a metal trim inside the microwave. Do
not use paper covered wire twist-ties on plastic bags.
•Never put objects into the openings on the outer case.
•Food containing a mixture of fat and water (for example,
stock) should stand for 30 to 60 seconds in the oven
after it has been turned off. This is to allow the mixture
to settle and to prevent it from bubbling when a spoon
is placed in it, or a stock cube is added.
6

SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•When heating or cooking food or liquid, remember that
there are certain foods (such as, jam, Christmas pudding,
and mincemeat) which heat up very quickly.
•Do not cook any food surrounded by a membrane, such
as egg yolks, potatoes, chicken livers, sausages, ready
meals and so on without piercing them several times
with a fork.
•Do not try to deep-fry foods in this microwave oven.
•Do not overcook food.
•Please remember that as food or liquids heat up, they
will release steam or may be spitting. Never cover any
container fully, always leave a gap for steam to escape.
•Do not use plastic containers when heating or cooking
foods that contain a lot of fat or sugar.
•Do not cook food directly on the flatbed. Put food on a
suitable plate or in a bowl before putting it in the oven.
7

SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not use melamine dishes as they contain a material
which will absorb microwave energy. This may cause the
dishes to crack or burn, and will slow down the cooking
speed.
•Do not use the microwave oven for heating
utensils, plates or dishes.
•Do not cook using a container with a restricted
opening, such as bottles, as they may explode.
•Before you clean your microwave oven, turn it off
and unplug it.
•Keep the inside of the oven clean. When food or
liquids stick to the oven walls, wipe with a damp
cloth. We recommend that you do not use harsh
detergent or abrasives.
8

SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•You should clean the outside of the oven with a
damp cloth. Do not allow water to seep into the
ventilation openings.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering
of the glass.
•If steam builds up inside or around the outside of the
oven door, wipe with a soft cloth. This may happen
when the microwave oven is used in humid conditions.
•Regularly clean the flatbed and oven floor. Simply
wipe the bottom surface of the oven with mild
detergent and water, then dry.
9

ABOUT YOUR MICROWAVE
Thank you for purchasing your Russell Hobbs microwave oven.
The Russell Hobbs RHVM901 microwave has a sleek black housing
with stainless steel details, sure to make a statement in your home.
The concealed handle looks stylish and modern whilst reducing
fingerprints on the mirrored door. With an impressive 22 litre
capacity and 5 power levels, this microwave is perfect for your
family. This freestanding microwave also comes with non-slip feet
for your peace of mind about safety.
The RHVM901 has intelligent Inverter technology, allowing you to
make the most of your microwave. Inverter microwaves are more
energy efficient which give you greater versatility over
temperature settings and therefore not only can you heat and
defrost your food, you can also keep your food warm in the
microwave without overcooking it and slow cook meats too.
What is more, this microwave is a Flatbed microwave and therefore
has no internal plate. Not only does this make the microwave easier
to clean, it also provides a more thorough and even cooking
temperature, ensuring your food is delicious every time.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
10

ABOUT YOUR MICROWAVE
How do microwaves work?
Microwaves are high-frequency electromagnetic waves similar to
radio waves. While radio waves may vary in length from one
metre to many kilometres, microwaves are very short (less than
12.5 centimetres.)
Microwaves do not make any heat themselves but cause
water molecules in food to vibrate.
This vibration produces heat that cooks the food. This is why your
food will come out of the microwave piping hot, when your utensils
inside the oven stay much cooler. The microwaves do not stay in the
air or in the food when you open the microwave oven door.
The microwave oven will work using an ordinary household
electrical socket. Inside the microwave oven is the magnetron,
which turns the electrical energy into microwaves.
Microwaves cannot travel through metal, so the inside of the
oven is lined with metal. The door is lined with a fine metal mesh
which stops microwaves getting through. This means that when the
microwave oven door is shut, there is no possibility that
microwaves can be released.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
11

PRODUCT INFORMATION
Rated Voltage
220V-240V~50Hz
Rated Input Power (Microwave)
1400W
Rated Output Power (Microwave)
850W- 900W
Oven Capacity (litres)
22
Produced for:
G2S Limited
Wigan
WN2 4AY
12

UNPACKING THE MICROWAVE
Before you use your microwave oven
1. Check the oven after unpacking for any visual damage such as:
●A misaligned door
●Damage to the door
If you can see any damage do not use the oven, please contact
This microwave oven must be put on a horizontal surface that
is strong enough to support its weight.
The oven must be placed away from high temperatures and
steam. Do not put anything on the top of the microwave oven.
13

PRODUCT OVERVIEW
25
134
1. Door Safety Lock System
2. Oven Window
3. Flatbed
4. Control Panel
5. Display
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
14

MICROWAVE OVEN INSTALLATION
•Place the oven as far away from radios and televisions as
possible. Using the oven may cause interference with the
reception.
•Plug the oven into a suitable 13 amp mains socket, make sure
the voltage is the same as on the rating label (do not use
extension cables or mains socket adaptors.)
•The microwave oven should be used freestanding only and
must not be built-in or used in a cabinet.
•Select a level surface that provides enough space for the
outlet vents.
15

MICROWAVE OVEN INSTALLATION
The minimum installation height is 85cm.
A minimum clearance of 7.5cm is required between the oven and
any adjacent walls. Leave a minimum clearance of 30cm above the
oven.
WARNING:
DO NOT install the oven over a cooker or other heat or steam
producing appliance as this will damage the microwave oven.
30cm
7.5cm
7.5cm
7.5cm
Min 85cm
DO NOT obstruct
the ventilation from
the microwave
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
16

CONTROL PANEL
Display Window cooking time, power, action
indicators, and time is displayed.
Clock use to set the time.
Power Level press this button a number of
times to set a cooking power level.
Preset press to set a pre-set cooking program.
Auto Cook press this button for the auto
cooking menus that is required.
Weight press to select weight of your food in
defrost function.
Defrost press this button for the defrost
function. Press weight to select a defrost
weight; or press the ’10Min’, ’1Min’, and
’10Sec’ buttons to select a defrost time.
Select press to choose a menu, power or
weight.
Pause/Cancel press once to pause a cooking
program and twice to cancel a cooking
program. Press for 3 seconds for the child lock.
Start/Quick Start press to start the microwave
on full power for the 30 seconds, the time will
then be increased by 30 seconds each time the
button/dial is pressed. Press to start cooking
program.
17

HOW TO USE THE MICROWAVE
Setting the clock (24 hour)
For example, if you want to set the time to 08:35 (am:)
1. Press the 'Clock' button. The display will show ‘Hr24', and the
clock symbol will be displayed.
2. Press the ‘10 Min' button until the display shows '8:00'.
3. Press the ‘1 Min' button until the display shows '8:30' .
4. Press the ‘10 Sec' button until the display shows '08:35'. Press the
'Clock' button to confirm. The clock is now set.
Note:
Before setting a cooking program the clock needs to be set.
If the clock is not set, the clock will not function when powered.
During the process of clock setting, if you press ‘Pause/Cancel’ button, the
oven will go back to the previous status.
Microwave cooking
Once you have correctly installed the unit, turned on the power and set the
clock, you are ready to start cooking.
Your microwave has 5 power levels, the lowest at 20%, then 40%, 60%, 80%,
up to 100% (or full power.)
Most recipes are cooked on full power –this should be indicated on the
packaging of microwavable food.
1. To select a power level, press the ‘Power Level’ button.
•When pressed once the screen display will show P100.
18

HOW TO USE THE MICROWAVE
•When pressed twice the screen display will show P-80
•When pressed three times the screen display will show P-60
•When pressed four times the screen display will show P-40
•When pressed five times the screen display will show P-20
•When pressed six times the screen display will show P-00
2. Press the ’10Min’, ’1Min’, and ’10Sec’ buttons to set the required
time.
3. Press the ‘‘Start/Quick Start’button to commence cooking.
4. Please note: 'End' will be displayed and a sound will be heard
every 2 minutes until the oven door is opened or the
‘Pause/Cancel'button is pressed.
The maximum cooking time is 99 minutes and 50 seconds. Do not operate
the oven empty, this can cause irreparable damage.
Pausing cooking
If you want to pause the cooking to turn over or stir the food, simply open
the door, turn or stir, then close again and press the ‘Start/Quick Start’
button to continue the cycle.
If you wish to stop cooking with time left on the display, take out the
contents, close the door and press the ‘Pause/Cancel’button once to clear.
When the cooking process has finished 'End' will be displayed and a sound
will be heard every 2 minutes until the oven door is opened or the
‘Pause/Cancel' button is pressed.
Quick start function
For quick and easy microwave cooking, you can press the ‘Start/Quick Start’
dial to automatically add 30 seconds of cooking time. This can be pressed
multiple times for cooking up to 10 minutes on full power. Note: This
function does not work for defrost, auto menu, multi-stage cooking or during
the cooking process.
19

HOW TO USE THE MICROWAVE
Weight Defrost
Note: Ensure food is thoroughly defrosted before starting the
cooking process
The microwave generally penetrates 4cm into most foods. Therefore you must
ensure food is thoroughly defrosted before starting the cooking process.
For even defrosting results, ensure you turn the food over during the cycle.
Defrosting generally takes longer than the cooking time of food.
Defrosted food should be consumed as soon as possible, do not put it back
in the fridge or freeze again.
As an example, to defrost 400g of poultry:
1. Press the ‘Defrost’button –‘dEF’will be displayed.
2. Press the ‘Weight’button –‘100g’ will be displayed.
3. Keep pressing the ‘Weight’button until you reach the desired weight
‘400g’; or press the ‘Up Arrow’ or the ‘Down Arrow’ to the required
weight and then press ‘Select’ to confirm.
4. To commence defrosting, close the microwave door and press the
‘Start/Quick Start’button.
5. Approximately one third of the way through the defrosting time, the
oven will beep and pause. This is to allow you to turn over the food for
even defrosting. Turn over or rearrange the food and press the
‘Start/Quick Start' dial to resume defrosting. To defrost fatty meat,
defrost intermittently until fully defrosted. Ice and ice particles from the
food being defrosted should be completely removed.
6. Please note: 'End' will be displayed and a sound will be heard every 2
minutes until the oven door is opened or the ‘Pause/Cancel'button is
pressed.
20
