Safavieh PAT7037 User manual

NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
A
B
C
D
E
H1
H2
H3
H4
Seat Frame
Hinge
Back panel
Front panel
Bottom panel
Leg frame
Screw
Screw
Allen key
1X
1X
2X
1X
1X
2X
17X
8X
1X
5 mm
PIECE DESCRIPTION PICTURE QUANTITY
Model# PAT7037
Product Dimensions:47.6" W x 19.5" D x 18.9" H
CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
M4x15
M6x60

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 40 minutes.
Tools Required for Assembly (included): Allen Key
1234
Step 1 Step 2 Step 3 Step 4
(D)
Attach font panel (B) and back panel (A)
to leg frame (C) by using screw (H3),
tighten with allen (H4)
Attach back panel (A)
to seat frame (E)
by using screw (H2),
Use screw (H2) to attach hinge (H1)
to seat frame (E) and leg frame (C),
Pull down as the arrow
H3
H3
H3
H3
H3
H3
H3
H3
A
B
D
E
A
C
C
H2
H2
H2
H2
H2
H1
