Sagido gr-1733 User manual

http://www.sapido.com.tw 1 Quick Installation Guide

FCC Caution
FCC Part 15.19 Caution:
1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation
2.This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.
3.Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user authority to operate the equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
The antennas used for this transmitter must be installed to provide a separation distance
of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.
http://www.sapido.com.tw 2 Quick Installation Guide

FCC Statement in ser’s Manual (for calss B)
FCC Section 15.105
“Federal Communications Commission (FCC) Statement”
This equipment has been tested and found to comply with the limits for a lass B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
--Consult the dealer or an experienced radio/TV technician for help.
CE Statement of Conformity
Our product has been tested in typical configuration by Ecom Sertech Corp and was found
to comply with the essential requirement of “Council Directive on the Approximation of the
Laws of the Member States relating to Electromagnetic Compatibility” (89/336/EEC;
92/31/EEC; 93/68/EEC)
http://www.sapido.com.tw 3 Quick Installation Guide

Introduction
GR-1733 provides many Internet connecting ways, including 802.11n Wi-Fi/3.5G and
smartphone, to meet different users’ need. GR-1733 has intelligent Plug-n-Play and can
detect user’s environment to make connecting Internet more easily. GR-1733 has firewall
and WEP/WPA/WPS to make the network environment more secure when many devices
are sharing bandwidth. 11n Broadband Router is designed for home user and business
user and is a secure, reliable, and easy-to-use network solution. GR-1733 has Green AP
function. When it is standby, system will save power. It also supports IEEE 802.3az
standard and saving 80% power in Ethernet part.
The main features of GR-1733
➢Super giga fiber optics internet and MIT quality: Built-in gigabit ethernet port
provides high quality media transmission and high speedy video entertainment. MIT
quality assurance standards and uses power-saving green technology.
➢Easy 3-step setup: CD-free installation, automatic network detection allows users
to configure network quickly in 3 easy steps within 30 seconds.
➢ser-friendly smart cloud management: User-friendly smart cloud portable tablet
applications allow users to remotely connect to home or business and upload or
download files.
➢Multi-function SB 3G/4G plug and play:Connect webcam, USB devices for
cloud monitor, files sharing and airplay music via smart APP. Supports more than
300+3G/4G modem.
➢IPv6 and network lab approved: Provides superior stability, complies with all IPv6
standards, and assures continuous 720 hours above of transmission without break
down.
➢Support PPTP/L2PT and 10 VPNs: Provides 10 VPNs and virtual private network
tunnel support, and supports up to 253 PCs to break through the network blocking
lines.
➢Flexible smart and convenient: Can function as a standard router, connect to
public hotspots, be used as an access point (AP), or extend a wireless network
(WiFi AP).
➢QoS technology and dual firewalls: IP/Mac dual bandwidth technology allows
users to allocate their network usage efficiently to avoid any parental lag.
http://www.sapido.com.tw 4 Quick Installation Guide

1.1 LED Indicators
ED Function Color Status Description
Power indication Green on System is ready to work
Blinking
120ms
1. Power is being applied and system
boot in progress
2. Reset or firmware upgrade in
progress
System status Green on
Reset / Firmware update in progress
Blinking
120ms
/ Wireless activity
& WPS status Green
on Wireless is connected
Blinking
30ms Wireless Tx/Rx activity
Reddish
Orange
Blinking
120ms WPS function in progress
WAN port activity
Green
On 100Mbps Ethernet is connected
Blinking
30ms 100Mbps Ethernet Tx/Rx activity
Green
On 10Mbps Ethernet is connected
Blinking
120ms 10Mbps Ethernet Tx/Rx activity
LAN port activity
Green
On 100Mbps Ethernet is connected
Blinking
30ms 100Mbps Ethernet Tx/Rx activity
Green
On 10Mbps Ethernet is connected
Blinking
120ms 10Mbps Ethernet Tx/Rx activity
http://www.sapido.com.tw 5 Quick Installation Guide

1.2 Product Appearance
2 Installation Diagram
Step 1. Connect Internet connection which ISP provides to the WAN port of GR-133.
Step 2. Power on GR-1733.
http://www.sapido.com.tw 6 Quick Installation Guide

3 Setting
3.1 sing Laptop
Step 1.Set up the router using laptop. Connect to GR-1733 through wireless.
Step 2. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
http://www.sapido.com.tw 7 Quick Installation Guide

3.1.1 Internet Connection Type
Sapido router will detect the Internet connection type and help users enter into the
setting page automatically.
3.1.1.1 ADSL/xDSL Modem
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically. Please enter in the
username and password for ADSL/xDSL connection. Also, we recommend
users set up the wireless security.
Step 2. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 3. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 8 Quick Installation Guide

3.1.1.2 Cable Modem
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
Step 2. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 3. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw Quick Installation Guide

3.1.1.3 Static IP Address
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
Step 2. Enter in the IP address, subnet mask, gateway, and DNS for Internet
connection. (Please use the correct connection data that ISP provided)
Step 3. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 4. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 10 Quick Installation Guide

3.2 sing iPhone/iPad
Step 1. Set up the router using iPhone/iPad. Go to Settings → Wi-Fi → Enable Wi-Fi
→ Connect to GR-17333 through wireless.
Step 2. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
http://www.sapido.com.tw 11 Quick Installation Guide

3.2.1 Internet Connection Type
Sapido router will detect the Internet connection type and help users enter into the
setting page automatically.
3.2.1.1 ADSL/xDSL Modem
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically. Please enter in the
username and password for ADSL/xDSL connection. Also, we recommend
users set up the wireless security.
Step 2. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 3. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 12 Quick Installation Guide

3.2.1.2 ADSL/xDSL Modem
Step 1.Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
Step 2. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 3. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 13 Quick Installation Guide

3.2.1.3 Static IP Address
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
Step 2. Enter in the IP address, subnet mask, gateway, and DNS for Internet
connection. (Please use the correct connection data that ISP provided)
Step 3. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 4. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 14 Quick Installation Guide

3.3 sing Android Mobile Device
Step 1. Set up the router using Android mobile device (smartphone/tablet). Go to
Settings → Wireless & Networks → Enable Wi-Fi → Wi-Fi settings →
Connect to GR-17333 through wireless.
Step 2. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
http://www.sapido.com.tw 15 Quick Installation Guide

3.3.1 Internet Connection Type
Sapido router will detect the Internet connection type and help users enter into the
setting page automatically.
3.3.1.1 ADSL/xDSL Modem
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically. Please enter in the
username and password for ADSL/xDSL connection. Also, we recommend
users set up the wireless security.
Step 2. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 3. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 16 Quick Installation Guide

3.3.1.2 Cable Modem
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
Step 2. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 3. After the connection is successful, please download Sapido Cloud to
complete the setting.
http://www.sapido.com.tw 17 Quick Installation Guide

3.3.1.3 Static IP Address
Step 1. Open the web browser. Sapido router will detect the Internet connection type
and help users enter into the setting page automatically.
Step 2. Enter in the IP address, subnet mask, gateway, and DNS for Internet
connection. (Please use the correct connection data that ISP provided)
Step 3. Click Apply. Please do not power off the router or disconnect the Internet
while counting down.
Step 4. After the connection is successful, please download Sapido Cloud to
complete the setting.
※Please refer to pdapp Guide on Sapido website for pdapp settings.
※Please refer to User Manual on Sapido website for advanced settings.
http://www.sapido.com.tw 18 Quick Installation Guide
