Samsung NS***HHXEH Guide

INV HSP MA DUCT_DB98-33882A.indd 1 2011-5-31 18:54:08

2
For easy future reference, write the model and serial number
down. You will nd your model number on the bottom right side
of the air conditioner.
Model #
Serial #
 
On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool
comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest. This summer,
beat the heat with your own
air conditioner.
 
Your new air conditioner not only provides maximum cooling power in the summer, but can also be an ecient heating
method in the winter with the advanced“Heat pump”system.This technology is up to 300% more ecient than electrical
heating, so you can further reduce its running cost. Now, meet year-round needs with one air conditioner.
 
Duct type air conditioner is designed to be slimmer and oers dierent solutions for any shape room allowing for specic
air ow requirements. Also, the air intake can be set up on either the bottom or rear of the unit, so there is more exibility in
installation.

INV HSP MA DUCT_DB98-33882A.indd 2 2011-5-31 18:54:19

3

  


Tips on using your air conditioner ......................................................................................................................................................................... 9

Cleaning the lter ........................................................................................................................................................................................................ 10
Maintaining your air conditioner .......................................................................................................................................................................... 11

Troubleshooting ........................................................................................................................................................................................................... 12
Operation ranges ......................................................................................................................................................................................................... 13














USING PARTS
INSTALLATION PARTS
INV HSP MA DUCT_DB98-33882A.indd 3 2011-5-31 18:54:19

4
A

Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to safely and
eciently operate the extensive features and functions of your new appliance.
Because the following operating instructions cover various models, the characteristics of your air conditioner may dier slightly
from those described in this manual. If you have any questions, call your nearest contact center or nd help and information
online at www.samsung.com.

WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.

WARNING



Sharing a wall socket with other appliances using a power strip or extending the power cord may result in
electric shock or re.
Do not use an electric transformer. It may result in electric shock or re.
If the voltage/frequency/rated current condition is dierent, it may cause re.

Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury.

Failing to do so may result in electric shock or fire.

If the outdoor unit falls, it may result in injury, death or property damage.

Failing to do so may result in electric shock or fire.



This may result in electric shock or fire.


Failure to do so may result in electric shock, fire, an explosion, or other problems with the product.
Never plug the power cord into a socket that is not grounded correctly and make sure that it is in accordance with
local and national codes.

CAUTION

Failing to do so may result in electric shock or fire due to electric leakage.

Failing to do so may result in abnormal vibrations, noise, or problems with the product.
USING PARTS
INV HSP MA DUCT_DB98-33882A.indd 4 2011-5-31 18:54:20

5

CAUTION

Failing to do so may result in water overflowing and property damage.


The water generated during the heating operation by the outdoor unit may overflow and result in property damage. In
particular, in winter, if a block of ice falls, it may result in injury, death or property damage.

WARNING


Unplug the power plug and clean it with a dry cloth.
Failing to do so may result in electric shock or fire.

If you plug the power plug into the socket in the opposite direction, the electric wires within the cable may be
damaged and this may result in electric shock or fire.



This may result in electric shock or fire.

Unplug the power plug by holding the plug.
Failing to do so may result in electric shock or fire.



This may result in electric shock or fire.

CAUTION


Failing to do so may result in electric shock or fire.

WARNING

Failing to do so may result in electric shock or fire.


Failing to do so may result in electric shock or fire.


Do not use a ventilating fan.
A spark may result in an explosion or fire.

Failing to do so may result in problems with the product, water leakage, electric shock, or fire.
A delivery service for the product is not provided. If you reinstall the product in another location, additional
construction expenses and an installation fee will be charged.
Especially, when you wish to install the product in an unusual location such as in an industrial area or near the seaside
where it is exposed to the salt in the air, please contact your nearest service center.
INV HSP MA DUCT_DB98-33882A.indd 5 2011-5-31 18:54:21

6

WARNING

This may result in electric shock.

Plugging the power plug into the wall outlet or turning the air conditioner on from the circuit breaker may cause a
spark and result in electric shock or fire.


If a child places a bag over its head, it may result in suffocation.

Take special care that children do not injure themselves by inserting their fingers into the product.

This may result in fire, injury, or problems with the product.

This may result in children seriously injuring themselves.

Since this may be dangerous due to a lack of oxygen, Open a window at least once an hour.


Failing to do so may result in electric shock or fire.

Do not use any fuse (such as cooper, steel wire, etc.)other than the standard fuse.
Failing to do so may result in electric shock, fire, problems with the product, or injury.

CAUTION

Water dripping from the indoor unit may result in fire or property damage.

Failing to do so may result in injury, death or property damage.




This may result in electric shock, fire, problems with the product, or injury.

This may result in electric shock.

As well as being harmful to humans, it may also result in electric shock, fire or problems with the product.

The water may be harmful to humans.


This may result in burns or injury.

INV HSP MA DUCT_DB98-33882A.indd 6 2011-5-31 18:54:21

7

CAUTION



This may result in property damage.



This may result in harm to humans, animals or plants.





WARNING



This may result in discoloration, deformation, damage, electric shock or re.



Failing to do so may result in electric shock or re.

CAUTION


To avoid cutting your ngers, wear thick cotton gloves when cleaning it.


For cleaning inside the appliance, contact your nearest service center.

When cleaning the internal lter, refer to the descriptions in the‘Cleaning the air conditioner’ section.

Failure to do may result in damage, electric shock or re.
INV HSP MA DUCT_DB98-33882A.indd 7 2011-5-31 18:54:21

8
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool
or warm with optimal eciency.
Please read the user manual to get started and to make the best use of the air conditioner.
Your air conditioner may slightly look dierent from illustration shown above depending on your model.
Air intake
Air outlet
Ceiling
Air lter (the return air side)

INV HSP MA DUCT_DB98-33882A.indd 8 2011-5-31 18:54:22

9


Here are some tips that you would follow when using your air conditioner.
TOPIC RECOMMENDATION
 • If current outside temperatures are much higher than the selected indoor
temperature, it may take time to bring the inner temperature to the desired coolness.
• Avoid drastically turning down the temperature.
Energy is wasted and the room does not cool faster.
 • Since the air conditioner heats the room by taking heat energy from outdoor air, the
heating capacity may decrease when outdoor temperatures are extremely low. If you
feel the air conditioner insuciently heats, using an additional heating appliance in
combination with the air conditioner is recommended.
 • When the air conditioner runs in Heat mode, due to temperature dierence between
the unit and the outside air, frost will form.
If this happens:
- The air conditioner stops heating.
- The air conditioner will operate automatically in De-ice mode for
10 minutes.
- The steam produced on the outdoor unit in De-ice mode is safe.
No intervention is required; after about 10 minutes, the air conditioner operates again
normally.
The unit will not operate when it starts to de-ice.
 • Fan may not operate for about 3~5 minutes at the beginning to prevent any cold
blasts while the air conditioner is warming up.


• If both indoor and outdoor temperatures are high and the air conditioner is running in
Heat mode, the outdoor unit’s fan and compressor may stop at times. This is normal; wait
until the air conditioner turns on again.
 • If a power failure occurs during the operation of the air conditioner, the operating
immediately stops and unit will be o. When power returns, the air conditioner will run
automatically.
 • If the air conditioner has just been turned on after operation stops or being plugged
in, cool/warm air does not come out for 3 minutes to protect the compressor of the
outdoor unit.
INV HSP MA DUCT_DB98-33882A.indd 9 2011-5-31 18:54:22

10
For the best performance from your air conditioner, clean it periodically. When cleaning, make sure to unplug from the unit
for user’s safety.

When cleaning the lter, make sure to unplug the power from the unit. Washable foam based Air lter captures large
particles from the air. The lter is cleaned with a vacuum or by hand washing.
 
 

• For best conditions, repeat every two weeks.
• If the Air lter dries in a conned (or humid) area, odors may generate. If it occurs,
re-clean and dry it in a ventilated area.
 
The designs and shape are subject to change according to the model.
• The illustration shown above may dier from your depending on your model.
• After cleaning the lter, press the  button on the remote control for 2 seconds to reset the ller
schedule. Filter sign indicator will be on for cleaning time.

INV HSP MA DUCT_DB98-33882A.indd 10 2011-5-31 18:54:23

11

If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition.






Type Description Monthly Every 4
months Once a year


Clean the air filter (1)

Clean the condensate drain pan (2)

Thoroughly clean the heat exchanger (2)

Clean the condensate drain pipe (2)

Replace the remote control batteries (1)



Clean the heat exchanger on the outside of the
unit (2)

Clean the heat exchanger on the inside of
the unit (2)

Clean the electric components with jets of
air (2)

Verify that all the electric components are firmly
tightened (2)

Clean the fan (2)

Verify that all the fan assembly is firmly
tightened (2)

Clean the condensate drain pan (2)

The checks and maintenance operations described are essential to guarantee the eciency of the air conditioner. The
frequency of these operations varies according to the characteristics of the area, the amount of dust, etc.
(1) The described operations should be performed more frequently if the area of
installation is very dusty.
(2) These operations must always be performed by qualied personnel. For more detailed information, see the
Installation Manual.
INV HSP MA DUCT_DB98-33882A.indd 11 2011-5-31 18:54:24

12



Type Description

The internal fan will be off to against cold air when the heat pump is heating.

The internal fan will be off to against cold air when the heat pump is heating.


The compressor will be off to protect internal battery when the air conditioner oper-
ates in Cool mode.

The air conditioner does not start operating immediately to protect the compressor of
the outdoor unit after it has been started.
If the heat pump is operating in Heat mode, De-ice cycle is actuated to remove frost from an outdoor unit that may
have deposited at low temperatures.
The internal fan is switched o automatically and restarted only after the de-ice cycle is completed.


Refer to the following chart if the air conditioner operates abnormally.This may save time and unnecessary expenses.
PROBLEM SOLUTION



• Because of the protective mechanism, the appliance does not start operating
immediately to keep the unit from overloading.
The air conditioner will start in 3 minutes.


• Check that the power plug is properly connected. Insert the power plug into the wall
socket correctly.
• Check if the circuit breaker is switched o.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown out.

• Check if you selected Fan mode.
Press the Mode button on the remote control to select another mode.


• Check if the set temperature is higher (lower) than the current temperature. Press the
Temperature button on the remote control to change the set temperature. Press the
Temperature button to decrease or increase the temperature.
• Check if the air lter is blocked by dirt.
• Check if the air conditioner has just been turned on. If so, wait 3 minutes. Cool air does
not come out to protect the compressor of the outdoor unit.

INV HSP MA DUCT_DB98-33882A.indd 12 2011-5-31 18:54:24

13

PROBLEM SOLUTION


• Check if the air conditioner is installed in a place with a direct exposure to sunlight. Hang
curtains on windows to boost cooling eciency.
• Check if the cover or any obstacle is not near the outdoor unit.
• Check if the refrigerant pipe is too long.
• Check if the air conditioner is only available in Cool mode.
• Check if the remote control is only available for cooling model.

• Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the fan speed to Auto in Auto/Dry mode.

• Check if you press the Power button on the remote control after you have set the time.


• Check if the appliance is running in a smoky area or if there is a smell entering from
outside. Operate the air conditioner in Fan mode or open the windows to air out the room.


• A bubbling sound may be heard when the refrigerant is circulating through the
compressor. Let the air conditioner operate in a selected mode.
• When you press the Power button on the remote control, noise may be heard from the
drain pump inside the air conditioner.


• Check if the air conditioner has been cooling for an extended period of time with the
air ow blades pointed downwards. Condensation may generate due to the dierence in
temperature.

• Check if your batteries are depleted.
• Make sure batteries are correctly installed.
• Make sure nothing is blocking your remote control sensor.
• Check that there are strong lighting apparatus near the air conditioner. Strong light
which comes from uorescent bulbs or neon signs may interrupt the electric waves.


• Check if you set the wired remote control for group control.


• Check if TEST indicator is displayed on the wired remote control. If so, turn o the unit
and switch o the circuit breaker. Call your nearest contact center.


• Press the Power button on the remote control to turn the unit o and switch the circuit
breaker o. Then, switch it on again.

The table below indicates the temperature and humidity ranges the air conditioner can be operated within. Refer to the
table for ecient use.
MODE OPERATIONAL TEMPERATURE INDOOR
HUMIDITY IF OUT OF CONDITIONS
INDOOR OUTDOOR
 18˚C to 32˚C -15˚C to 50˚C 80%
or less
Condensation may occur on the indoor
unit with risk to have either water blow
o or drops on the oor.
 27˚C or less -20˚C to 24˚C - Internal protection triggers and the air
conditioner will stop.
 18˚C to 32˚C -15˚C to 50˚C -
Condensation may occur on the indoor
unit with risk to have either water blow
o or drops on the oor.
The standardized temperature for heating is 7˚C. If the outdoor temperature drops to 0˚C or below, the heating
capacity can be reduced depending on the temperature condition.
If the cooling operation is used at over 32˚C (indoor temperature), it does not cool at its full capacity.
INV HSP MA DUCT_DB98-33882A.indd 13 2011-5-31 18:54:24

14
INSTALLATION PARTS

(Carefully follow the precautions listed below because they are essential to guarantee the safety of the
equipment.)
• Always disconnect the air conditioner from the power supply before servicing it or
accessing its internal components.
•
Verify that installation and testing operations are performed by qualified personnel.
• Verify that the air conditioner is not installed in an easily accessible area.
General information
Carefully read the content of this manual before installing the air conditioner and store the manual in a safe place in
order to be able to use it as reference after installation.
For maximum safety, installers should always carefully read the following warnings.
Store the operation and installation manual in a safe location and remember to hand it over to the new owner if the
air conditioner is sold or transferred.
This manual explains how to install an indoor unit with a split system with two SAMSUNG units. The use of other types
of units with different control systems may damage the units and invalidate the warranty. The manufacturer shall not
be responsible for damages arising from the use of non compliant units.
The air conditioner is compliant with the requirements of the Low Voltage Directive (72/23/EEC),
the EMC Directive (89/336/EEC) and the Directive on pressurized equipment (97/23/EEC).

The manufacturer shall not be responsible for damage originating from unauthorized changes or the improper connection
of electric and hydraulic lines. Failure to comply with these instructions or to comply with the requirements set forth in the
“Operating limits”table, included in the manual, shall immediately invalidate the warranty.
The air conditioner should be used only for the applications for which it has been designed: the indoor unit is not
suitable to be installed in areas used for laundry.
Do not use the units if damaged. If problems occur, switch the unit off and disconnect it from the power supply.
In order to prevent electric shocks, fires or injuries, always stop the unit, disable the protection switch and contact
SAMSUNG’s technical support if the unit produces smoke, if the power cable is hot or damaged or if the unit is very noisy.
Always remember to inspect the unit, electric connections, refrigerant tubes and protections regularly.
These operations should be performed by qualified personnel only.
The unit contains moving parts, which should always be kept out of the reach of children.
Do not attempt to repair, move, alter or reinstall the unit. If performed by unauthorized personnel, these operations
may cause electric shocks or fires.
Do not place containers with liquids or other objects on the unit.

All the materials used for the manufacture and packaging of the air conditioner are recyclable.
The packing material and exhaust batteries of the remote control(optional) must be disposed of in accordance with
current laws.
The air conditioner contains a refrigerant that has to be disposed of as special waste. At the end of its life cycle, the air
conditioner must be disposed of in authorized centers or returned to the retailer so that it can be disposed of correctly
and safely.
installinG the unit
IMPORTANT: When installing the unit, always remember to connect first the refrigerant tubes, then the electrical lines.
Always disassemble the electric lines before the refrigerant tubes.
Upon receipt, inspect the product to verify that it has not been damaged during transport. If the product appears
damaged, DO NOT INSTALL it and immediately report the damage to the carrier or retailer (if the installer or the
authorized technician has collected the material from the retailer.)
After completing the installation, always carry out a functional test and provide the instructions on how to operate
the air conditioner to the user.
Do not use the air conditioner in environments with hazardous substances or close to equipment that release free
flames to avoid the occurrence of fires, explosions or injuries.
The air conditioner should be used only for the applications for which it has been designed: the indoor unit is not
suitable to be installed in areas used for laundry.
WARNING
INV HSP MA DUCT_DB98-33882A.indd 14 2011-5-31 18:54:24

15
 Make sure that you earth the cables.
- Do not connect the earth wire to the gas pipe, water pipe, lighting rod or telephone wire.
If earthing is not complete, electric shock or fire may occur.

Install the circuit breaker.
- If the circuit breaker is not installed, electric shock or fire may occur.

Make sure that the condensed water dripping from the drain hose runs out properly and safely.

Install the power cable and communication cable of the indoor and outdoor unit at least 1m
away from the electric appliance.

Install the indoor unit away from lighting apparatus using the ballast.
- If you use the wireless remote control, reception error may occur due to the ballast of the
lighting apparatus.

Do not install the air conditioner in following places.
- Place where there is mineral oil or arsenic acid.
Resin parts flame and the accessories may drop or water may leak.
The capacity of the heat exchanger may reduce or the air conditioner may be out of order.
- The place where corrosive gas such as sulfurous acid gas generates from the vent pipe or air
outlet.
The copper pipe or connection pipe may corrode and refrigerant may leak.
- The place where there is a machine that generates electromagnetic waves.
The air conditioner may not operate normally due to control system.
-
The place where there is a danger of existing combustible gas, carbon fiber or flammable dust.
The place where thinner or gasoline is handled.
Gas may leak and it may cause fire.
CAUTION
Our units must be installed in compliance with the spaces indicated in the installation manual to ensure either
accessibility from both sides or ability to perform routine maintenance and repairs. The units’ components must be
accessible and that can be disassembled in conditions of complete safety either for people or things.
For this reason, where it is not observed as indicated into the Installation Manual, the cost necessary to reach and repair
the unit (in safety, as required by current regulations in force) with slings, trucks, scaffolding or any other means of
elevation won’t be considered in-warranty and charged to end user.
Power suPPly line, fuse or circuit breaker
Always make sure that the power supply is compliant with current safety standards. Always install the air conditioner in
compliance with current local safety standards.
Always verify that a suitable grounding connection is available.
Verify that the voltage and frequency of the power supply comply with the specifications and that the installed power is
sufficient to ensure the operation of any other domestic appliance connected to the same electric lines.
Always verify that the cut-off and protection switches are suitably dimensioned.
Verify that the air conditioner is connected to the power supply in accordance with the instructions provided in the
wiring diagram included in the manual.
Always verify that electric connections (cable entry, section of leads, protections…) are compliant with the electric
specifications and with the instructions provided in the wiring scheme. Always verify that all connections comply with
the standards applicable to the installation of air conditioners.
INV HSP MA DUCT_DB98-33882A.indd 15 2011-5-31 18:54:24

16
A


The following accessories are supplied with the indoor unit.
The type and quantity may dier depending on the specications.

User’s&
Installation
manual(1)
Insulation
drain(1) Insulation cover pipe(2) Insulation cover pipe 2(1) Insulation pipe(1)
Insulation
drain pipe(1) Flexible hose(1) Clamp hose(2) Rubber(8) Cable-tie(8)
There must be no obstacles near the air inlet and outlet.
Install the indoor unit on a ceiling that can support its weight.
Maintain sufficient clearance around the indoor unit.
Make sure that the water dripping from the drain hose runs away correctly and safely.
The indoor unit must be installed in this way, that they are out of public access. (Not touchable by the
users)
After connecting a chamber, insulate the connection part between the indoor unit and the chamber with
t10 or thicker insulation. Otherwise, there can be air leak or dew from the connection part.

Wired remote
control(1) Cable-tie(2) Cable clamp(4) M4x16 tapped screw(5)
Indoor unit
power draw-
ing cable(1)
Communication
cable of the wired
remote control(1)
Wire joint(4) User’s
manual(1) Installation manual(1)
Indoor unit
INV HSP MA DUCT_DB98-33882A.indd 16 2011-5-31 18:54:26

17
A
Indoor Unit A B C D Front/Back
NSHHXEH 1200x650x360 1200x650 1200x650 650x360 650x360
Insulate the front and back side in
proper size at the same time when
insulating the suction duct and
discharge duct.

 Construction Standard for Inspection Hole
1) In case, the ceiling is tex tile, Inspection hole dose not need.
2) In case, the ceiling is plaster board, Inspection hole depends on Inside height of the ceiing.
a. Height is more than 3.28ft(1m) : Only "B" [Inspection for PBA] is applied.
b. Height is less than 3.28ft(1m) : Both "A"&"B" are applied.
c. "A"&"B" are inspection holes .
Unit Width(W)
"A"=W+100mm
Unit Depth(D)+50mm
"B"=500mm
You must have20mm or more space between the ceiling and the bottom of indoor unit. Otherwise, the noise
from the vibration of indoor unit may bother the user.When the ceiling is under construction, the hole for check-
up must be made to take service, clean and repair the unit.
 It is possible to install the unit at an height of between 2.2~2.5m from the ground,
if the unit has a duct with a well defined lenght (300mm or more), to avoid fan motor blower contact.
If you install the cassette or duct type indoor unit on the ceiling with humidity over 80%, you must apply extra
10mm of polyethylene foam or other insulation with similar material on the body of the indoor unit.
20mm
20mm
or more
or more
A C
B
D







Space requirements for installation & service
Insulation Guide
INV HSP MA DUCT_DB98-33882A.indd 17 2011-5-31 18:54:27

18
A
No. Name Description
1 Liquid pipe connection ø9.52
(3/8”)
2 Gas pipe connection ø19.05 (3/4”)
3 Drain pipe connection OD32 ID26(without drain pump)
4 Drain pipe connection Using drain pump (Optional)
5Power supply/Communication connection -
6 Power supply connection -
7 Air discharge grille flange -
8 Hook
3/8” or M10
NS

HHXEH
7
8
6
4
3
2
1
5
700
650
1200 1300500
534 (Suspension position)
Suction sideDischarge side
360
253
(Air outlet duct flange)
2×100=200
80
170
244
299
OD32
28
121
137
20-ø3.2hole
(All around)
1236 (Suspension position)
1200
1000 (Air outlet duct flange)
6×150=900
Unit : mm
86 222

Drawing of the indoor unit
INV HSP MA DUCT_DB98-33882A.indd 18 2011-5-31 18:54:29

19
Model A
NS

HHXEH 3mm

When deciding on the location of the air conditioner with the owner, the following restrictions must be taken into account.
1
Place the pattern sheet on the ceiling at the spot where you want
to install the indoor unit.
2
Insert bolt anchors. Use existing ceiling supports or construct a suit-
able support as shown in figure.
3 Install the suspension bolts depending on the ceiling type.
4 Screw eight nuts to the suspension bolts making space for hanging
the indoor unit.
5 Hang the indoor unit to the suspension bolts between two nuts.
6 Screw the nuts to suspend the unit.
7 Adjust level of the unit by using measurement plate for all 4 sides.
Concrete
Suspension bolt(M8)-field supply
Hole in anchor
hole in plug
Ceiling support
When the drain hose is installed to the right.
Drain hose port
Amm
Insert
• Since the diagram is made of paper, it may shrink or
stretch slightly due to temperature or humidity. For this
reason, before drilling the holes maintain the correct
dimensions between the markings.
•Ensure that the ceiling is strong enough to support the weight
of the indoor unit. Before hanging the unit, test the strength of
each attached suspension bolt.
• If the length of suspension bolt is more than 1.5m,
it is required to prevent vibration.
• If this is not possible, create an opening on the false ceiling in
order to be able to use it to perform the required operations on
the indoor unit.
• Piping must be laid and connected inside the ceiling when
suspending the unit. If the ceiling is already constructed, lay the
piping into position for connection to the unit before
placing the unit inside the ceiling.
•For proper drainage of condensate, give a 3mm slant to the
left or right side of the unit which will be connected with the
drain hose, as shown in the gure. Make a tilt when you wish to
install the drain pump, too.
• You must install all the suspension rods.
INV HSP MA DUCT_DB98-33882A.indd 19 2011-5-31 18:54:30

20
The designs and shape are subject to change
according to the model.

From factory the unit is supplied and set with a pre-charge of nitrogen gas. (insert gas) Therefore, all insert gas must be
purged before connecting the assembly piping.

RESULT : All inert gas escapes from the indoor unit.
• To prevent dirt or foreign objects from getting into the
pipes during installation, do NOT remove the pinch pipe
completely until you are ready to connect the piping.
INV HSP MA DUCT_DB98-33882A.indd 20 2011-5-31 18:54:30
