Samsung DW50R4070F Series User manual

Dishwasher
User manual
DW50R4070F*/DW50R4060F*/DW50R4050F*/
DW50R4040F*
DW4000RM_DD81-03019B-00_EN.indd 1 9/4/2020 11:22:33 AM

English2
Contents
Contents
Safety information 4
What you need to know about safety instructions 4
Important safety symbols 4
Instructions about the WEEE 5
Important safety precautions 6
Instructions when using your dishwasher 8
Instructions for protecting your children 9
Instructions for installing your dishwasher 10
Installation 13
What’s included 13
Installation requirements 14
Step-by-step installation 16
Before you start 18
Dishwasher at a glance 18
Unsuitable items for the dishwasher 20
Basic use of racks 21
Detergent compartment 26
Rinse aid reservoir 29
Salt storage 30
Setting mode 31
Operations 33
Control panel 33
Cycle overview 35
Simple steps to start 36
Salt storage 37
Delay Start 39
Control Lock 39
Maintenance 40
Cleaning 40
Long-term care 43
Troubleshooting 44
Checkpoints 44
Information codes 47
DW4000RM_DD81-03019B-00_EN.indd 2 9/4/2020 11:22:33 AM

English 3
Contents
Cycle chart 48
Appendix 50
Transportation/relocation 50
Protection against frost 50
Disposing the dishwasher and helping the environment 50
Specications 51
For standard test 52
DW4000RM_DD81-03019B-00_EN.indd 3 9/4/2020 11:22:33 AM

English4
Safety information
Safety information
Congratulations on your new Samsung dishwasher. This manual contains important
information on the installation, use and care of your appliance. Please take time to read
this manual to take full advantage of your dishwasher’s many benets and features.
What you need to know about safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efciently
operate the extensive features and functions of your new appliance and retain it at a safe
place near the appliance for your future reference. Use this appliance only for its intended
purpose as described in this user manual.
Warning and important safety instructions in this manual do not cover all possible
conditions and situations that may occur. It is your responsibility to use common sense,
caution, and care when installing, maintaining, and operating your dishwasher.
Because the following operating instructions cover various models, the characteristics
of your dishwasher may differ slightly from those described in this manual and not all
warning signs may be applicable. If you have any questions or concerns, contact your
nearest service center or nd help and information online at www.samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or
property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
These warning symbols are here to prevent injury to you and others. Please follow them
explicitly.
Keep these instructions in a safe place and ensure that new users are familiar with the
content. Pass them on to any future owner.
DW4000RM_DD81-03019B-00_EN.indd 4 9/4/2020 11:22:33 AM

English 5
Safety information
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic
Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that
the product and its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household waste at the
end of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government ofce, for details of
where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
For information on Samsung’s environmental commitments and product specic regulatory
obligations e.g. REACH, WEEE, Batteries, visit our sustainability page available via
Samsung.com
DW4000RM_DD81-03019B-00_EN.indd 5 9/4/2020 11:22:34 AM

English6
Safety information
Safety information
Important safety precautions
To reduce the risk of re, electric shock, or injury
to persons when using your appliance, follow basic
precautions, including the following:
1. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
2. For use in Europe: This appliance can be used by
children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning use
of the appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not
be made by children without supervision.
3. Children should be supervised to ensure that they do
not play with the appliance.
4. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
5. The new hose-sets supplied with the appliance are to
be used and old hose-sets should not be reused.
DW4000RM_DD81-03019B-00_EN.indd 6 9/4/2020 11:22:34 AM

English 7
Safety information
6. For appliances with ventilation openings in the base,
a carpet must not obstruct the openings.
7. For use in Europe: Children of less than 3 years
should be kept away unless continuously supervised.
8. CAUTION:In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out, this
appliance must not be supplied through an external
switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by the
utility.
9. WARNING: Knives and other utensils with sharp
points must be loaded in the basket with their points
down or placed in a horizontal position.
This appliance is intended to be used in household and
similar applications such as:
• staff kitchen areas in shops, ofces and other working
environments;
• farm houses;
• by clients in hotels, motels and other residential type
environments;
• bed and breakfast type environments.
DW4000RM_DD81-03019B-00_EN.indd 7 9/4/2020 11:22:34 AM

English8
Safety information
Safety information
Instructions when using your dishwasher
This dishwasher is not designed for commercial use. It is intended for use in domestic
households and in similar working and residential environments such as:
• Shops
• Ofces and showrooms
and by residents in establishments such as:
• Hostels and guest houses.
It must only be used as a domestic appliance as specied in this user manual, for cleaning
domestic crockery and cutlery. Any other usage is not supported by the manufacturer and
could be dangerous.
The manufacturer cannot be held liable for damage resulting from incorrect or improper
use or operation.
Do not use solvents in the dishwasher. Danger of explosion.
Do not inhale or ingest dishwasher detergent. Dishwasher detergents contain irritant or
corrosive ingredients which can cause burning in the nose, mouth and throat if swallowed,
or inhibit breathing. Consult a doctor immediately if detergent has been swallowed or
inhaled.
Avoid leaving the door open unnecessarily, as you could trip over it.
Do not sit or lean on the opened door. This could cause the dishwasher to tip and be
damaged, and you could get injured.
Only use detergent and rinse aid formulated for domestic dishwashers. Do not use
washing-up liquid.
Do not use any strong acid cleaning agent.
Do not ll the rinse aid reservoir with powder or liquid detergent. This will cause serious
damage to the reservoir.
Inadvertently lling the salt reservoir with powder or liquid dishwasher detergent
will damage the water softener. Make sure you have picked up the correct packet of
dishwasher salt before lling the salt reservoir.
Please only use special coarse grained dishwasher salt for reactivation, as other salts may
contain insoluble additives which can impair the functioning of the softener.
In an appliance with a cutlery basket (depending on model), cutlery is cleaned and dried
more if placed in efciently the basket with the handles downwards. However, to avoid the
risk of injury, place knives and forks etc. with the handles upwards.
Plastic items which cannot withstand being washed in hot water, such as disposable plastic
containers, or plastic cutlery and crockery should not be cleaned in the dishwasher. The
high temperatures in the dishwasher may cause them to melt or lose shape.
On models with Delay Start function, make sure that the dispenser is dry before adding
detergent. Wipe dry if necessary. Detergent will clog if poured into a damp dispenser and
may not be thoroughly dispersed.
DW4000RM_DD81-03019B-00_EN.indd 8 9/4/2020 11:22:34 AM

English 9
Safety information
Knives and other utensils with sharp points must be loaded in the basket with their points
down or placed in a horizontal position.
Instructions for protecting your children
This appliance is not a toy! To avoid the risk of injury, keep children well away and do
not allow them to play in or around the dishwasher or to use the controls. They will not
understand the potential dangers posed by it. They should be supervised whenever
you are working in the kitchen. There is also a danger that children playing might shut
themselves in the dishwasher.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Older children may only use the dishwasher when its operation has been clearly explained
to them and they are able to use it safely, recognising the dangers of misuse.
KEEP CHILDREN AWAY FROM DETERGENTS!
Dishwasher detergents contain irritant and corrosive ingredients which can cause burning
in the mouth, nose and throat if swallowed, or inhibit breathing.
Keep children away from the dishwasher when the door is open. There could still be
detergent residues in the cabinet.
Consult a doctor immediately if your child has swallowed or inhaled detergent.
DW4000RM_DD81-03019B-00_EN.indd 9 9/4/2020 11:22:34 AM

English10
Safety information
Safety information
Instructions for installing your dishwasher
Before setting up the appliance, check it for any externally visible damage. Under no
circumstances should you use a damaged appliance. A damaged appliance could be
dangerous.
The dishwasher must only be plugged into the electricity supply via a suitable switched
socket. The electrical socket must be easily accessible after the dishwasher is installed
so that it can be disconnected from the electricity supply at any time. (Refer to the
“Dishwasher at a glance” section on page 18.)
There must be no electrical sockets behind the dishwasher. Danger of overheating and re
risk if the dishwasher were to be pushed up against a plug.
The dishwasher must not be installed under a hob. The high radiant temperatures which
are sometimes generated by a hob could damage the dishwasher. For the same reason it
should not be installed next to open res or other appliances which give off heat, such as
heaters etc.
Do not connect the dishwasher to the mains supply until it has been fully installed and any
adjustment has been made to the door springs.
Before connecting the appliance, check that the connection data on the data plate (voltage
and connected load) match the mains electricity supply. If in any doubt, consult a qualied
electrician.
The electrical safety of this appliance can only be guaranteed when continuity is complete
between it and an effective grounding system. It is most important that this basic safety
requirement is present and regularly tested and where there is any doubt the electrical
system in the house should be checked by a qualied electrician.
The manufacturer cannot be held liable for the consequences of an inadequate grounding
system (e.g. electric shock).
Do not connect the appliance to the mains electricity supply by a multi-socket unit or an
extension lead. These do not guarantee the required safety of the appliance (e.g. danger of
overheating).
This appliance may only be installed in mobile installations such as ships if a risk
assessment of the installation has been carried out by a suitably qualied engineer.
DW4000RM_DD81-03019B-00_EN.indd 10 9/4/2020 11:22:34 AM

English 11
Safety information
The plastic housing of the water connection contains an electrical component. The housing
must not be submerged in water.
There are electrical wires in the hose of Aqua-Stop. Never cut the water inlet hose, even if
it is too long.
Installation, maintenance and repairs may only be carried out by a suitably qualied and
competent person in strict accordance with current national and local safety regulations.
Repairs and other work by unqualied persons can be dangerous. The manufacturer cannot
be held liable for unauthorised work.
The integrated waterproof system offers protection from water damage, provided the
following conditions are met:
• The dishwasher is correctly installed and plumbed in.
• The dishwasher is properly maintained and parts are replaced where it can be seen that
this is necessary.
• The stopcock has been turned off when the appliance is not used for a longer period of
time (e.g. during holidays).
• The waterproof system will work even if the appliance is switched off. However, the
appliance must remain connected to the electricity supply.
A damaged appliance can be dangerous. If the dishwasher gets damaged, switch it off at
the mains and call your dealer or the service department.
Unauthorised repairs could result in unforeseen dangers for the user, for which the
manufacturer cannot accept liability. Repairs should only be undertaken by an approved
service technician.
Faulty components must only be replaced by original spare parts. Only when these parts
are tted can the safety of the appliance can be guaranteed.
Always disconnect the dishwasher from the electrical supply for maintenance work (switch
off at the wall socket and remove the plug).
If the connection cable is damaged it must be replaced with a special cable, available from
the manufacturer. For safety reasons, this must only be tted by the service department or
an authorised service technician.
In countries where there are areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and its surroundings in a
clean condition at all times. Any damage which may be caused by cockroaches or other
vermin will not be covered by the guarantee.
DW4000RM_DD81-03019B-00_EN.indd 11 9/4/2020 11:22:34 AM

English12
Safety information
Safety information
In the event of a fault or for cleaning purposes, the appliance is only completely isolated
from the electiricity supply when:
• it is switched off at the wall socket and the plug is withdrawn, or
• it is switched off at the mains, or
• the mains fuse is disconnected, or
• the screw-out fuse is removed (in countries where this is applicable).
Do not make any alterations to the appliance, unless authorised to do so by the
manufacturer.
Never open the casing/housing of the appliance. Tempering with electrical connections or
components and mechanical parts is highly dangerous and can cause operational faults or
electric shock.
While the appliance is under guarantee, repairs should only be undertaken by a service
technician authorised by the manufacturer. Otherwise the guarantee will be invalidated.
When installing the product, make sure there is space at the top, left, right and back of the
product to ensure proper ventilation. If there is insufcient space between the product and
the sink, it may damage the sink or allow mold to grow.
Make sure that your dishwasher’s hardness level setting is correct as your area. (Refer to
the “Salt storage” section on page 30.)
DW4000RM_DD81-03019B-00_EN.indd 12 9/4/2020 11:22:34 AM

English 13
Installation
Installation
What’s included
Make sure all the parts are included in the product package. If you have a question about
the dishwasher or the parts, contact a local Samsung customer centre or your retailer. The
actual appearance of the dishwasher may differ, depending on your model and country.
CAUTION
After unpacking the dishwasher, keep packaging materials out of children’s reach to ensure
their safety.
Installation kit (not provided)
Hose clamp
Tools required (not provided)
Safety glasses Gloves Flashlight Wrench (22 mm)
for the front foot
Torx T15 Pliers Nipper Tape measure
Pencil Phillips screwdriver Flat head
screwdriver
Cutting knife
Level Hole saw
(80-100 mm)
DW4000RM_DD81-03019B-00_EN.indd 13 9/4/2020 11:22:35 AM

English14
Installation
Installation
Installation requirements
To prevent a risk of re, electric shock, or
personal injury, all wiring and grounding
must be done by a qualied technician.
Power supply
• An individual 220-240 V, 50 Hz
branch circuit that is dedicated to the
dishwasher.
• Power outlet with a maximum allowable
current of 16 A (maximum 11 A for the
dishwasher)
WARNING
• Do not use an extension cord.
• Use only the power plug that comes
with the dishwasher.
• After installation is complete, make sure
the power plug is not bent or damaged.
Grounding
For permanent grounding, the dishwasher
must be properly grounded to a grounded
metal or permanent wiring system. The
grounding conductor must be run with
the circuit conductors and then connected
to the grounding terminal or lead on the
dishwasher.
WARNING
• Do not connect the ground wire to
plastic plumbing, gas lines, or hot water
pipes. Improperly connected grounding
conductors may cause electric shock.
• Do not modify the power plug of the
dishwasher. If the power plug does
not t the outlet, have a proper outlet
installed by a qualied electrician.
Water supply
• The water supply line must support
water pressures between 0.04 and
1 MPa.
• Water temperatures must be lower than
60 °C.
• A stopcock with a 3/4” male thread must
be installed on the water tap.
To reduce a risk of leaks:
• Make sure water taps are easily
accessible.
• Turn the water tap off when the
dishwasher is not in use.
• Check for any leaks at the water hose
ttings on a regular basis.
• To stop any leak, seal the water line
connections and joints using Teon tape
or sealing compound.
Aqua Stop
The Aqua Stop is an electrical component
that is designed to prevent water leaks. The
Aqua Stop is attached to the water hose
and automatically cuts off the water ow in
the event of damage to the hose.
CAUTION
• Handle the Aqua Stop with care.
• Do not kink or twist the water hose
connected to the Aqua Stop. If the Aqua
Stop is damaged, shut off the water taps
and unplug the power plug immediately.
Then, contact a local Samsung customer
centre or a qualied technician.
DW4000RM_DD81-03019B-00_EN.indd 14 9/4/2020 11:22:35 AM

English 15
Installation
Drain
If you are using a drain system dedicated
to the dishwasher, connect the drain hose
to a drain system that is between 30 cm
and 70 cm off the ground. Connecting the
drain hose to a drain system more than
80 cm off the ground can cause the drained
water to ow backward.
Flooring
For safety, the dishwasher must be
installed on a solidly constructed oor.
Wooden oors may need to be reinforced
to minimise vibrations. Avoid installing
on carpet or soft tile. Carpeting and soft
tile may cause vibrations and may cause
your dishwasher to move slightly while
operating.
WARNING
Do not install the dishwasher on a poorly
supported structure.
Ambient temperature
Do not install the dishwasher in an area
exposed to freezing temperatures. The
dishwasher always retains some water in
the water valve, pump, and hose. If the
water freezes in the dishwasher or hoses,
it may damage the dishwasher and its
components.
Test run
After installing the dishwasher, run the
Quick cycle to make sure the dishwasher is
installed correctly.
DW4000RM_DD81-03019B-00_EN.indd 15 9/4/2020 11:22:35 AM

English16
Installation
Installation
Step-by-step installation
STEP 1 Level the dishwasher
0-20 mm
1. Use a level to check whether the
dishwasher is level.
2. Turn the levelling feet under the four
bottom corners to adjust the height.
- You can adjust the height up to
20 mm.
3. When levelling is complete, check if the
door opens and closes properly.
DW4000RM_DD81-03019B-00_EN.indd 16 9/4/2020 11:22:35 AM

English 17
Installation
STEP 2 Connect the drain hose
Max. 80 cm
Min. 30 cm
1. Connect the drain hose to the drain
outlet.
CAUTION
• Install the drain system properly so that
the drain hose does not come out of the
drain outlet in the draining process.
• Make sure that the drain hose, supply
hose, and power cord is not kinked or
folded.
STEP 3 Final check
1. Remove all foam, paper packaging, and unnecessary parts from inside the dishwasher.
2. Turn the circuit breaker on.
3. Open the water supply valve to supply water to the dishwasher.
4. Plug in and turn the dishwasher on. Then, select and run the Quick cycle.
5. Check if the dishwasher turns on normally and if there are any water leaks while the
dishwasher is operating. Make sure to check for water leaks on both ends of the water
line and the drain hose connector.
DW4000RM_DD81-03019B-00_EN.indd 17 9/4/2020 11:22:36 AM

English18
Before you start
Before you start
Follow these instructions carefully to ensure proper installation of the dishwasher and to
prevent accidents when washing dishes.
Dishwasher at a glance
DW50R4060F* / DW50R4040F*
04
05
07
08
06
01
02
03
01 Upper rack 02 Lower rack 03 Salt storage
04 Dispenser 05 Door 06 Base
07 Inlet hose 08 Drain hose
DW4000RM_DD81-03019B-00_EN.indd 18 9/4/2020 11:22:36 AM

English 19
Before you start
DW50R4070F* / DW50R4050F*
05
06
08
09
07
01
02
04
03
01 Cutlery rack 02 Upper rack 03 Salt storage
04 Lower rack 05 Dispenser 06 Door
07 Base 08 Inlet hose 09 Drain hose
DW4000RM_DD81-03019B-00_EN.indd 19 9/4/2020 11:22:36 AM

English20
Before you start
Before you start
CAUTION
• Do not wash items that are covered with ash, sand, wax, lubricating grease, or paint.
These materials will damage the dishwasher. Ash does not dissolve and will spread
inside the dishwasher.
• Remove food remains such as bones, fruit seeds, etc. and waste such as toothpicks,
paper napkins, etc. from your dishes. Food remains and waste can make noise, cause the
dishwasher to malfunction, and damage your dishes and dishwasher.
Unsuitable items for the dishwasher
WARNING
Wash only items such as glass, porcelain, and cutlery which the manufacturer declares as
dishwasher safe. Do not wash aluminium (e.g. grease lters). The dishwasher may damage
aluminium, or in extreme cases, cause a severe chemical reaction.
Do not wash the following items in the dishwasher.
• Copper, brass, tin, ivory, and aluminium items or items with adhesive
• Non-heat resistant plastics
• Craft items, antiques, valuable vases, and decorative glassware
• Pottery or glazed-ceramic items
• Wooden cutlery and crockery or items with wooden parts
• Delicate glassware or glassware containing lead crystal. Clouding may occur on the
glassware after frequent washing.
NOTE
Silverware that has contacted foods containing sulphur may become discoloured. Food
with sulphuric content include egg yolks, onions, mayonnaise, mustard, sh, sh brine, and
marinades.
