Samsung HG26NA470 User manual

Installing the LED TV Stand
♦HG26NA470 / HG26NA477 / HG32NA470 / HG32NA477 / HG32NA478 / HG40NA570 /
HG40NA577 / HG40NA578 / HG46NA570 / HG46NA577 / HG46NA578
Components
When installing the stand, use the provided components and parts.
A
1 EA
B
1 EA
D
x4 (M4 X L12, SECURITY)
C
x8 (M4 X L12)
yStand
(depending on the model) yGuide Stand yScrews
To register this product please visit
www.samsung.com/register.
Quick Setup Guide
STOP
Please do not return
this unit
If you are having problems operating this TV,
Please call;
US : 1-866-894-0524
CANADA : 1-800-726-7864
For web support please visit
http://www.samsung.com/us/business
BN68-04292A
BN68-04292A-00
Viewing the Connection Panel
➣The product color and shape may vary depending on the model.
1COMPONENT IN / AV IN1 (46” Model: COMPONENT IN / AV IN)
2DATA
3HDMI IN 1 (DVI), 2, 3 / PC/DVI AUDIO IN
4DIGITAL AUDIO OUT (OPTICAL)
5PC / DVI AUDIO IN
6PC IN
7AUDIO OUT
8ANT IN
9EX-LINK
0USB / CLONING
!VIDEO / R-AUDIO-L
Connecting the TV with an SBB or STB
1. Connect the [DATA] jack of the TV to the [ETH MODEM] jack of the STB (SBB) with
the Data cable.
➣Use data communication.
List of Vendors and Compatible Data Cables Supplied with the TV
♦Refer to the code label on the data cables.
Vendor Cable code
OCC BN39-00865B
NXTV BN39-01011B
nStreams BN39-01110A
MTI BN39-01011C
[TV Rear Panel]
Conrm the code on the
Code Label
Note the
labeled end.
Note the
labeled end.
1
B
A
C
(M4 X L12)
x4
Top View
DO NOT USE
CHEMICALS
DO NOT USE
GREASE
DO NOT USE
OIL
ATTENTION
Rear
Front
✎ Place a soft cloth over the table to
protect the TV, and then place the T V
on the cloth screen side down.
✎ Inser t the Stand Guide into the slot on
the bot tom of the TV.
2
(Incorrect assembly)
(Correct assembly)
Side View
33
D
(M4 X L12, SECURITY)
x4
C
(M4 X L12)
x4
4
♦Hotel Mount Kit
♦Assembling the swivel
The 32” and larger LED TVs have swivel stands. You can set these stands so
that the TVs swivel 20 degrees left and right, 60 degrees left and right, or 90
degrees left and right. The 26” LED TVs do not have swivel stands.
60" 90"
Leaving the BRACKET HOLDER SWIVEL
unchanged lets the TV swivel 20° left and right.
Rotating the BRACKET HOLDER SWIVEL 180°,
and then assembling the stand as shown above
lets the TV swivel 60° left and right.
Removing the BRACKET HOLDER SWIVEL and
assembling the stand as shown above without the
BRACKET HOLDER SWIVEL lets the TV swivel
90° left and right.
Top
Bottom
Afxing the stand to a at surface
such as a dresser top, desk top, or
entertainment center.
✎ Make sure to distinguish between the front and back of Stand and
Stand Guide when assembling them.
✎ Make sure that at least two people lift and move the LED TV.
✎ Lay the product down, with the screen facing down, and then fasten the screws.
2
3
1
4
5
7 86
9
3
0
!
3
0
[TV Rear Panel]
Power
Input
[46” Model]
ETH MODEM
Data Cable
Hotel Plug & Play
Hotel Plug & Play function automatically performs the Hotel mode selection, Country Setup, Clock Setup, and Picture mode Setup runs once,
when power is rst turned ON. Setup also runs automatically after you have executed a Service Reset.
♦UI Scenario
♦Hotel Plug & Play OSD
-Initial Highlight: Interactive
-If you select the Standalone Only button, the Standalone hotel mode is set by default
and the “Standalone mode is set” OSD appears for 3 seconds.
-TV enters into RF mode automatically after displaying “Standalone mode is set” OSD for
3 seconds.
-If you select the Interactive mode, the Interactive Setup Menu is displayed. Press the
power off key to exit from the Interactive menu.
-If you select the Standalone Plug & Play mode, the “Select Menu Language” OSD
appears.
♦Select Menu Language OSD
-If you select Standalone from the “Select Hotel TV Mode” OSD, the “Select Menu
Language” OSD appears.
-Initial Highlight : English
-Display time: OSD timeout and operation are the same as Samsung’s consumer TV
models.
-If you press the Enter key, the “Select Country” OSD appears.
♦Clock Mode OSD
-Initial Highlight: Auto.
-Display time: 30 seconds.
-The Clock Set item OSD appears if you select Manual.
-If you press the Enter key after setting the clock, or while in Auto clock set, the Picture
Mode OSD appears.
♦Set daylight saving time OSD
-Initial Highlight: Off
-If you press the Enter key, the Select the DST area OSD appears.
♦Picture Mode OSD
-Initial Highlight: Dynamic.
-The TV displays the Picture Mode OSD where you can choose the Dynamic or a
Standard Picture mode.
-After you select the picture mode, the TV displays the Standalone Setup Menu OSD.
Press power off to exit.
♦Auto Search Mode OSD
-If you select the Skip option, the TV displays the Clock Mode OSD.
-If you press the Enter key, the TV auto searches for channels.
-The OSD Display time, which starts at the time that Auto Store is completed goes to the
time Auto Sort starts, is 30 seconds.
When in the Hotel mode (Interactive or Standalone), the Channel menu items in
the Menu OSD, except for Channel List, are deactivated. If you need to change the
channel line up, use the Channel Setup item in the Hotel option menu.
Hotel Plug & Play is not supported in B-LAN models (HG478/578).
Notice
If you select the
Factory Reset, the
TV resets all values
to their factory
defaults and then
displays the Hotel
Plug & Play menu.
Go to the rst Hotel
Plug & Play screen
above right labeled
Setup>Plug & Play.
Standalone Hotel
Option Menu
If you select Standalone
Plug & Play
Press Power
OFF to exit.
E
E
E
E
E
E E
E
Easy Set up
Setup > Plug & Play
• Interactive
• Standalone Plug & Play
• Standalone Only
Next
Select the language you want to use
Setup > Menu Language
Next
Select English
as the language
• English
• Español
• Français
Fastory Reset
Type
32P6AF0D
Local Set
US
Basic Model
HA477
SVC Model
477
Tuner
SI_ATC2
Light Effect
OFF
Ch Table
NONE
Front Color
NONE
Let's nd and store channels on
your TV. How do you receive
programming?
Setup > Auto Program (1/5)
Next
Skip
Previous
Select antenna
cable means all
the channels
available
through your
RF cable (air)
will be stored.
(Auto Program
necessary)
• I use an antenna cable..
• I use a set-top box.
Setup > Auto Program (2/5)
Next
Skip
Previous
Set the search options for auto tuning.
Air
c
Cable
Set the parameters for cable auto
program.
Select the digital
cable system
Setup > Auto Program (3/5)
Next
Skip
Previous
• Digital Cable System STD
• Analog Cable System STD
Auto Program is nding channels
for you ...
Cable 64
Setup > Auto Program (4/5)
Stop
DTV Air
Air
DTV Cable
Cable
0
0
0
0
Auto Program is complete
110 channels are memorized.
Setup > Auto Program (5/5)
OK
DTV Air
Air
DTV Cable
Cable
40
30
20
10
Set the Clock Mode.
Setup > Clock (1/3)
Next
Skip
Previous
Set the
current time
automatically
using the time
from the digital
broadcast.
• Auto
• Manual
What time zone are you in?
Setup > Clock (2/3)
Next
Skip
Previous
Select Eastern if
you are located in
that region.
• Newfoundland
• Atlantic
• Eastern
• Central
• Mountain
Add Daylight Savings Time?
Setup > Clock (3/3)
Next
Skip
Previous
Switch are DST
function off.
• Off
• On
Select Picture Mode.
Setup > Picture Mode
Next
Previous
• Off
• On
If you select
"I use an
antenna
cable..."
If you select "I use a
set-top box."
Standalone mode is set. TV will enter the RF
mode.
After 3
seconds
Interactive
Hospital Option Menu
Press Power OFF
to exit.
If you select
Interactive
If you select
Standalone Only
Long Bolt (2EA) Short Bolt (2EA) Nut (2EA) Washer (2EA)
Bolt + Nut
List of Parts
1Remote Control (AA59-00628A) &
Batteries (AAA x 2)
2Power Cord
3Data Cable
(BN39-00865B, BN39-01011C : except
478/578 model)
4Hotel Mount Kit
5• Owner’s Instructions
• Safety Guide
6Security Screw x 4
Bit tool (sold separately)
1
5 6
23 4
[HG470570-QSG]BN68-04292A-ENG.indd 1 2012-04-17 �� 8:34:20

Specications
Environmental
Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
50°F to 104°F(10°C to 40°C)
10% to 80%, non-condensing
-4°F to 113°F(-20°C to 45°C)
5% to 95%, non-condensing
Model Name HG26NA470 / HG26NA477 HG32NA470 / HG32NA477 / HG32NA478
Display Resolution 1366 x 768
Screen Size
(Diagonal)
26" Class
(26.0" measured diagonally)
32" Class
(31.5" measured diagonally)
Sound (Output) 5W x 2 10W x 2
Dimensions (WxDxH)
Body
With stand
24.2 X 3.6 X 14.3 inches
(615.1 X 92.9 X 365.6 (mm))
24.2 X 7.1 X 16.5 inches
(615.1 X 180.7 X 419.2 (mm))
29.0 X 3.6 X 17.1 inches
(738.8 X 93.2 X 436.7 (mm))
29.0 X 7.5 X 19.7 inches
(738.8 X 191.7 X 500.8 (mm))
Weight
Without Stand
With Stand
9.2 Ibs (4.2 kg)
10.5 Ibs (4.8 kg)
12.7 lbs (5.8 Kg)
17.3 lbs (7.8 Kg)
Stand Swivel (Left / Right) 0˚ 20˚ L and R or 90˚ L and R
Model Name HG40NA570 / HG40NA577 / HG40NA578 HG46NA570 / HG46NA577 / HG46NA578
Display Resolution 1920 x 1080
Screen Size
(Diagonal)
40” Class
(40.0” measured diagonally)
46” Class
(45.9” measured diagonally)
Sound (Output) 10W x 2
Dimensions (WxDxH)
Body
With stand
36.5 X 3.6 X 21.6 inches
(927.6 X 93.0 X 551.0 (mm))
36.5 X 8.9 X 23.8 inches
(927.6 X 227.6 X 607.0 (mm))
41.7 X 3.7 X 24.6 inches
(1059.8 X 94.3 X 625.6 (mm))
41.7 X 8.9 X 26.8 inches
(1059.8 X 227.6 X 681.2 (mm))
Weight
Without Stand
With Stand 19.8 Ibs (9.0 kg)
26.2 Ibs (11.9 kg)
27.5 Ibs (12.5 kg)
33.9 Ibs (15.4 kg)
Stand Swivel (Left / Right) 20˚ L and R or 90˚ L and R
➣Design and specications are subject to change without prior notice.
➣This device is a Class B digital apparatus.
➣For the power supply and Power Consumption, refer to the label attached to the
product.
Setting the Hotel Option Data
HG26NA470 / HG26NA477 / HG32NA470 / HG32NA477 / HG32NA478
12345678
HG26NA470
HG26NA477
24.4 22.7 12.7 14.1 15.6 17.7 3.7 7.1
HG32NA470
HG32NA477
HG32NA478
29.3 27.5 15.5 16.5 18.3 20.6 3.7 7.5
HG40NA570 / HG40NA577 / HG40NA578 / HG46NA570 / HG46NA577 / HG46NA578
123456
HG40NA570
HG40NA577
HG40NA578
36.5 20.3 21.6 23.8 3.6 8.9
HG46NA570
HG46NA577
HG46NA578
41.7 20.3 24.6 26.8 3.7 8.9
(unit: inches)
(unit: inches)
Wall Mount Kit Specications (VESA)
Install your wall mount on a solid wall perpendicular to the oor. When attaching to
other building materials, please contact your nearest dealer. If installed on a ceiling or
slanted wall, TV may fall and result in severe personal injury.
➣Standard dimensions for wall mount kits are shown in the table below.
➣Samsung wall mount kits contain a detailed installation manual. All parts
necessary for assembly are provided.
➣Do not use screws that do not comply with the VESA standard screw
specications.
➣Do not use screws that are longer than the standard dimension or do not
comply with the VESA standard screw specications. Screws that are too
long may cause damage to the inside of the TV set.
➣For wall mounts that do not comply with the VESA standard screw
specications, the length of the screws may differ depending on the wall
mount specications.
➣Do not fasten the screws too rmly. This may damage the product or cause
the product to fall, leading to personal injury. Samsung is not liable for these
kinds of accidents.
➣Samsung is not liable for product damage or personal injury when a non-
VESA or non-specied wall mount is used or the consumer fails to follow
the product installation instructions.
➣Do not mount the TV at more than a 15 degree tilt.
➣Always have two people mount the TV on a wall.
Product
Family
TV size in
inches
VESA screw hole
specs (A * B) in
millimeters
Standard Screw
(Length*
Pitch in mm)
Quantity
LED-TV
19 ~ 22 75 X 75 M4
(10~15 * 0.7)
4
26 100 X 100
32 ~ 40 200 X 200 M6
(10~15 * 1.0)
46 400 X 400 M8
(10~15 * 1.25)
Do not install your Wall Mount Kit while your TV is turned on.
It may result in personal injury due to electric shock.
Sound Bar
♦Samsung Sound-Bars and Hospitality TVs in 2012
-Samsung Sound-Bars and hospitality TVs support the ARC feature in HDMI 1.4. If you
connect a compatible Samsung Sound-Bar to a compatible Samsung hospitality TV
using a single HDMI cable, guests can listen to theTV’s sound through the Sound-Bar.
-Models supporting the ARC function are listed below:
• Sound-Bars: HW-E350/E450/E550
♦Setting the Sound-Bars to Hotel Mode.
1. Set the following Hotel menu options:
-Hotel option > External Device > Sound Bar Out = On.
-Hotel option > Power On > Power On Volume EN = User Dened.
-Hotel option > Power On > Power On Volume > Set greater than 0.
-Hotel option > Power On > Max Volume > Set greater than 0.
2. Connect an HDMI cable from the HDMI OUT jack on the back of Sound-Bar to the
HDMI2 port (supporting ARC) on the hospitality TV.
3. After the Sound-Bar is connected to the hospitality TV, when the TV turns on, the Sound-
Bar automatically detects the TV, and then automatically switches to Hotel Mode.
Sound Bar Hotel mode functional characteristics:
• Power On/Off is synchronized with the TV
• HDMI_CEC defaults to On
• Functions through the “HDMI OUT” port only
• Disables the “Input mode” key on the VFD to prevent unexpected audio-source changes.
• Acquires adjustable Power On and Max Volume settings from the TV’s Hotel option
menu. The Sound-Bar’s Power On Volume and Max Volume values, however, are ½ of
the Power On Volume and Max Volume settings in the TV’s Hotel option menu.
Example: If the TV’s Power On Volume=20 and Max Volume=90, then the Sound Bar’s
Power On Volume=10 and Max Volume=45.
License
Menu Item initial Value Description
Hospitality
Mode
Hospitality
Mode Standalone
Select the Hospitality mode.
• Standalone
• Interactive
SI Vendor SI Vendor Samsung
Available in the Interactive menu only.
Select the SI Vendor.
• Samsung / OCC / MTI / Nstreams / NXTV / Enseo / Cardinal /
Guestek / SeaChange / EBL
Power On
Power On
Channel EN Last Saved
Set the default values, which will be applied when the TV is turned
on.
• User Dened : Refers to the settings congured for Power On
Channel, Channel Type.
• Last Saved : Refers to the last saved settings.
Power On
Channel 3When the TV is turned on, it switches automatically to this channel when in Stand Alone Hospitality mode.
Channel Type ...
Channel search CABLE and AIR.
• ATD, DTV : ON-AIR
• CATV (Cable Analog TV), CDTV (Cable Digital TV) : CABLE TV
Power On
Volume EN Last Saved
Set the default volume values which will be applied when the TV is
turned on.
• User Dened : Uses the settings congured for Power On
Volume.
• Last Saved : Uses the last saved settings.
Power On
Volume ... TV will switch on at this Volume Level in Stand Alone Hospitality mode.
Min Volume 0 Minimum Volume Level user can set in Stand Alone Hospitality
mode.
Max Volume 100 Maximum Volume Level user can set in Stand Alone Hospitality
mode.
Panel Button
Lock Unlock
Front panel (Local key) operation on/off.
• Unlock : Unlock all panel keys
• Lock : Lock all panel keys
• Power : Lock all panel buttons except Power
• Menu/Source : Lock Menu and Source
Power On
Source TV Select the input source the TV displays when it is turned on.
Power On
Option Last Option
Determines the TV's state when power returns after a power failure
or after you have unplugged the TV and then plugged it in again.
- LAST OPT: Returns to its last Power state. If it was in Stand-by, it
returns to Stand-by. If it was on, it turns on.
Channel
Channel
Setup You can use the Channel menu option in the OSD.
Channel
Editor Edit Channel Number and Name.
Dynamic SI ON
• On : Check the DTV Program channel number. (DTV channel
editor is inaccessible)
• Off : No check of the DTV Program channel number. (DTV
channel editor is accessible, but additional channel program
number update is not supported)
Menu OSD
Picture Menu
Lock OFF Enable or disable the Picture Menu.
Menu
Display ON • On : Main Menu displays.
• Off : Main Menu does not display.
Menu Item initial Value Description
Operation Panel Button
Lock Unlock
Front panel (Local key) operation on/off.
• Unlock : Unlock all panel keys
• Lock : Lock all panel keys
• Power : Lock all panel buttons except Power
• Menu/Source : Lock Menu and Source
Clock Local Time Manual Select the way to update clock data.
• Manual: Manual clock setting (without updating from TTX data)
Music Mode
Music Mode
AV OFF
To get music output from an mp3/audio player through an AV
Input Source. When on, you can hear sound from the player
through the TV even there is no video signal. The TV’s backlight,
however, remains on. And add a video signal, it works normally.
Music Mode
PC OFF
To get music output from an mp3/audio player through a PC Input
Source. When on, you can hear sound from the player through
the TV even there is no video signal. The TV’s backlight, however,
remains on. And add a video signal, it works normally.
Music Mode
Comp OFF
To get music output from an mp3/audio player through a
Component Input Source. When on, you can hear sound from the
player through the TV whether even there is no video signal. The
TV’s backlight, however, remains on. And add a video signal, it
works normally.
Music Mode
Backlight OFF When set to Off, the TV’s backlight is turned off entirely when a guest uses the Music mode. To save energy, set to Off.
External
Device
7610 Priority
AV 1
Lets you set the priority of the 7610 RJP AV jack. You can choose
1, 2, or 3, with 1 being the highest and 3 the lowest. The TV
automatically displays the source with the higher priority. For
example, lets say AV is set to 1 and HDMI is set to 2. If a guest
has attached a device to the HDMI jack, and then plugs a device
into the AV jack, the TV will automatically switch to the device
plugged into the AV jack (the jack with the higher priority). Note
that a guest can also switch devices manually by pushing a button
on the 7610 RJP.
7610 Priority
PC 2
Lets you set the priority of the 7610 RJP PC jack. You can choose
1, 2, or 3, with 1 being the highest and 3 the lowest. The TV
automatically displays the source with the higher priority. See
above for a more detailed explanation.
7610 Priority
HDMI 3
Lets you set the priority of the 7610 RJP HDMI jack. You can
choose 1, 2, or 3, with 1 being the highest and 3 the lowest. The
TV automatically displays the source with the higher priority. See
above for a more detailed explanation.
7610 AV
Option AV1 Select RJP AV Source. (AV1/AV2)
RJP HDMI
Option HDMI1/DVI Select RJP HDMI Source. (HDMI1/HDMI2/HDMI3)
HDMI Music
Mode OFF
To get music output from an mp3/audio player through a HDMI
Input Source. When on, you can hear sound from the player
through the TV whether there is a video signal or not. (This option
is only compatible with the Guest link RJP.)
Sound Bar
Out OFF ON/OFF sound bar out.
Menu Item initial Value Description
External
Source
USB Media
Mode Defalut
When USB is connected to the TV,
• Default : Popup window appears.
• Automatic : Enters the USB contents menu automatically.
• Disable : Neither the pop-up window or nor the menu appears.
External
Source
Banner
ON
Displays the External Source information when you change the
TV source to external input. Press the info key and the TV turns
on.
• On : The External Source information is displayed on the TV
screen.
• Off : The External Source information is not displayed on the
TV screen.
Auto Source OFF
On : When an external source is connected to the TV, the TV will
auto ident and switch the input source.
• PC : Auto Ident PC Input only.
• Off : Auto Source is Off.
Anynet+
Return
Source
Power On Src Select Return Source for Guest-Link RJP (HDMI-CEC).
Eco Solution Energy
Saving OFF
This feature adjusts the brightness of the TV to reduce power
consumption.
• Off: Turns off the energy saving function.
• Low: Sets the TV to low energy saving mode.
• Medium: Sets the TV to medium energy saving mode.
• High: Sets the TV to high energy saving mode.
Logo/
Message
Welcome
Message OFF Display the Welcome Message for 5 seconds when the TV turns On.
Edit
Welcome
Message
Edit Welcome Message.
Hospitality
Logo OFF
Turns the Hospitality logo feature on/off. The Logo is shown
during the initial turn on for the amount of time set in the "Logo
Display Time"
Hospitality
Logo DL ...
Hospitality Logo Download. (File name required: samsung.bmp/
avi,
Max le size: BMP 960 x 540 / AVI 30MB, File Type: BMP/AVI)
Logo Display
Time ... Hospitality Logo Display Time (3/5/7 seconds).
Cloning
Clone TV to
USB Clone the current TV option values to a USB memory device.
Clone USB
to TV
Clone the saved TV option values in a USB memory device to the
TV.
Setting Auto
Initialize OFF
If you set Setting Auto Initialize to On, and the TV's power is
turned off and on, guest side menu items are restored to their
cloned values.
Menu Item initial Value Description
SIRCH
SIRCH
update Time 12:00 PM
Available in the Standalone menu only.
SIRCH (Samsung Interactive Remote Control for Hospitality) is
a professional) interactive remote controller for DTV that lets you
deliver
TV rmware updates, cloning data, and channel mapping
changes
to several hundred hospitality TVs simultaneously.
SIRCH is sold separately.
SIRCH
Update
Immediate
On
• On : Whenever TV goes to Stand-By mode, always works
SIRCH Update
• Off : Only works SIRCH Update on selected SIRCH Update
Time
Manual
SIRCH Upgrade SIRCH Clone / Binary by manual
SIRCH
Channel 87 Select SIRCH Update Channel
SIRCH
Version 0000 Display the current SIRCH Clone version
SIRCH
Group ID ALL Select SIRCH Group ID
REACH Off REACH Display On/Off
IPG Room
Type Default Select IPG Room Type
Service
CAS Pro:idiom Select CAS.
PI AES DATA 0x0000 Displays the state of Pro:Idiom operation.
Self
Diagnosis
Enter Self Diagnosis Menu.
• Picture Test: Use to check for picture problems. If the problem
appears in the test picture, select Yes and follow the directions
on the screen.
• Sound Test: Use the built-in melody sound to check for sound
problems. If the problem occurs during the test, select Yes and
follow the directions on the screen.
PI AES Log OFF Displays the state of Pro:Idiom AES operation.
View PI AES
Log ... Display/Save Pro:idiom AES log.
SW Upgrade Upgrade the TV SW.
Service
Pattern Off Display SVC pattern.
ATV Calble
AGC Gain 0 Control AGC Gain for ONLY SVC.
DTV
OpenCalble
AGC Gain
0 Control AGC Gain for ONLY SVC.
TV Reset Reset the TV. Same as Factory Reset in Factory option.
1
4
5
6
7
8
5
1
2
3
6
6
2
3
5
3
4
2
1
4
1
2
34
5
6
Dimensions
[HG470570-QSG]BN68-04292A-ENG.indd 2 2012-04-17 �� 8:34:24
