Samsung QN55QN95B User manual

55″
65″
QN55QN95B 48.3 inches
(1228.0 mm)
27.8 inches
(707.3 mm)
0.7 inches
(17.4 mm)
30.6 inches
(777.3 mm)
11.7 inches
(298.4 mm) 54.6 inches 35.5 lbs
(16.1 kg)
53.4 lbs
(24.2 kg)
QN65QN95B 57.0 inches
(1446.9 mm)
32.7 inches
(829.7 mm)
0.7 inches
(17.4 mm)
35.4 inches
(900.2 mm)
11.7 inches
(298.4 mm) 64.5 inches 49.2 lbs
(22.3 kg)
67.0 lbs
(30.4 kg)
QN55QN7**B 48.2 inches
(1224.8 mm)
27.8 inches
(705.3 mm)
0.7 inches
(17.8 mm)
30.5 inches
(775.8 mm)
12.7 inches
(298.4 mm) 54.6 inches 36.6 lbs
(16.6 kg)
53.8 lbs
(24.4 kg)
QN65QN8**B 56.8 inches
(1443.7 mm)
32.6 inches
(828.4 mm)
0.7 inches
(17.2 mm)
35.3 inches
(897.7 mm)
11.7 inches
(298.4 mm) 64.5 inches 51.4 lbs
(23.3 kg)
68.8 lbs
(31.2 kg)
QN65QN9**B 56.4 inches
(1433.1 mm)
32.3 inches
(819.9 mm)
0.6 inches
(15.2 mm)
35.2 inches
(893.4 mm)
11.7 inches
(298.4 mm) 64.5 inches 49.8 lbs
(22.6 kg)
67.2 lbs
(30.5 kg)
* : 0~9, A~Z
VESA x (mm) (mm)
QN55QN95B
400 x 300 5-6 M8
QN65QN95B
QN55QN7**B
QN65QN8**B
QN65QN9**B
* : 0~9, A~Z
-00
QUICK SETUP GUIDE
GUIDE D’INSTALLATION RAPIDE
* When installing the TV as wallmount, You can place the One Connect Box as shown below. (65″) / Lorsque vous installez le téléviseur sur un support mural, vous pouvez positionner le boîtier One Connect comme indiqué ci-dessous. (65″)
* To install using a wall mount, be sure to use the supplied HOLDER-WALL RING. (65″) / Pour procéder à l’installation à l’aide d’un support mural, utilisez les ANNEAUX DE SUPPORT MURAL fournis. (65″)
HOLDER-BOLT x 3 (65″)
BOULON DE SUPPORT x 3 (65″)
HOLDER-WALL RING x 4 (65″)
ANNEAU DE SUPPORT MURAL x 4 (65″)
[When installing the TV as stand, Don’t place
the One Connect Box on back of the TV.
[Lorsque vous installez le téléviseur sur un
socle, ne positionnez pas le boîtier One
Connect à l’arrière du téléviseur.

x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
15 cm
6 inches
1 2
3 4
5 6
7
