Samsung CM1039-K User manual

Refer to the service manual in the GSPN(see rear cover) for the more information.
1. Precaution
2. ProductSpecication
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded Views and Part List
6. Schematic Diagrams
BASIC: CM1039-K
MODEL: CM1039A-K
MODEL CODE: CM1039A-K/XEU
VERSION : 00,01

2
• Contents
1.Precaution..............................................................................3
1-1Safetyprecautions.....................................................................4
1-2SpecialHighVoltagePrecautions .........................................................5
2.Specications ...........................................................................6
2-1Features.............................................................................6
2-2 Table of Specications ..................................................................6
3.DisassemblyandReassembly..............................................................7
3-1 Disassembly of Magnetron, Motor Assembly and Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3-2ReplacementofHighVoltageTrancefomer..................................................9
3-3ReplacementofDoorAssembly..........................................................11
3-4ReplacementofDoorAssembly..........................................................12
3-5ReplacementofFuse..................................................................12
3-6ReplacementofDriveMotor ............................................................12
3-7ReplacementofControlCircuitBoard.....................................................14
4.ExplodedViewsandPartsList ............................................................15
4-1ExplodedViews(00,01Version)..........................................................15
4-2VersionList(00,01Version) .............................................................17
4-3MainPartsList(00,01Version)...........................................................18
4-4DoorPartList(00,01Version)............................................................20
4-5ControlPartList(00,01Version)..........................................................22
4-6StandardPartsList(00,01Version) .......................................................24
5.WiringDiagrams ........................................................................26
5-1WiringDiagrams......................................................................26

3
1. Precaution

4
1. Precaution
Follow these special safety precautions. Although the microwave oven is completely safe during ordinary use,
repair work can be extremely hazardous due to possible exposure to microwave radiation, as well as potentially
lethal high voltages and currents.
1-1 Safety precautions ( )
1. All repairs should be done in accordance with the
procedures described in this manual. This product
complies with Federal Performance Standard 21
CFR
2. Microwave emission check should be performed to
prior to servicing if the oven is operative.
3. If the oven operates with the door open :Instruct
the user not to operate the oven and contact
the manufacturer and the center for devices and
radiological health immediately.
4. Notify the Central Service Center if the microwave
leakage exceeds 5 mW/cm2.
5. Check all grounds.
6. Do not power the MWO from a “2-prong” AC cord.
Be sure that all of the built-in protective devices are
replaced. Restore any missing protective shields.
7. When reinstalling the chassis and its assemblies,
be sure to restore all protective devices, including:
nonmetallic control knobs and compartment covers.
8. Make sure that there are no cabinet openings
through which people --particularly children--might
insert objects and contact dangerous voltages.
Examples: Lamp hole,ventilation slots.
9. Inform the manufacturer of any oven foundto have
emission in excess of 5 mW/cm2 ,Make repairs to
bring the unit into compliance at no cost to owner
and try to determine cause. Instruct owner not to use
oven until it has been brought into compliance.
CENTRAL SERVICE CENTER
10. Service technicians should remove their watches
while repairing an MWO.
11. To avoid any possible radiation hazard,replace parts
in accordance with the wiring diagram. Also, use
only the exact replacements for the following parts:
Primary and secondary interlock switches, interlock
monitor switch.
12. If the fuse is blown by the Interlock Monitor Switch:
Replace all of the following at the same time:
Primary, door sensing switch and power relay, as
well as the Interlock Monitor Switch. The correct
adjustment of these switches is described elsewhere
in this manual. Make sure that the fuse has the
correct rating for the particular model being repaired.
13. Design Alteration Warning: Use exact replacement
parts only, i.e.,only those that are specied in
thedrawings and parts lists of this manual. This
is especially important for the Interlock switches,
described above. Never alter or add to the
mechanical or electrical design of the MWO.
Any design changes or additions will void the
manufacturer’s warranty. Always unplug the unit’s
AC power cord from the AC power source before
attempting to remove or reinstall any component or
assembly.
14. Never defeat any of the B+ voltage interlocks. Do not
apply AC power to the unit (or any of its assemblies)
unless all solid-state heat sinks are correctly
installed.
15. Some semiconductor (“solid state”) devices
are easily damaged by static electricity. Such
components are called Electrostatically Sensitive
Devices (ESDs). Examples include integrated
circuits and eld-effect transistors. Immediately
before handling any semiconductor components or
assemblies, drain the electrostatic charge from your
body by touching a known earth ground.
16. Always connect a test instrument’s ground lead to
the instrument chassis ground before connecting the
positive lead; always remove the instrument’s ground
lead last.
17. When checking the continuity of the witches or
transformer, always make sure that the power is
OFF, and one of the lead wires is disconnected.
18. Components that are critical for safety are indicated
in the circuit diagram by shading, or .
19. Use replacement components that have the same
ratings, especially for ame resistance and dielectric
strength specications. A replacement part that does
not have the same safety characteristics as the
original might create shock, re or other hazards.
NOTE : Connect the oven to a 20A. When
connecting the oven to a 15A,make sure that circuit
breaker can operate.

5
1. Precaution
1-2 Special High Voltage Precautions
1. High Voltage Warning Do not attempt to measure any of
the high voltages --this includes the lament voltage of the
magnetron. High voltage is present during any cook cycle.
Before touching any components or wiring, always unplug
the oven and discharge the high voltage capacitor (See
Figure 1-1)
2. The high-voltage capacitor remains charged about 30
seconds after disconnection. Short the negative terminal
of the high-voltage capacitor to to the oven chassis. (Use a
screwdriver.)
3. High voltage is maintained within specied limits by close-
tolerance, safety-related components and adjustments. If
the high voltage exceeds the specied limits, check each
of the special components.
H. V. Diode
Short
H. V. Capacitor
PRECAUTION
There exists HIGH VOLTAGE ELECTRICITY with high current capabilities in the circuits of the HIGH
VOLTAGE TRANSFORMER secondary and lament terminals. It is extremely dangerous to work on or
near these circuits with the oven energized.
DO NOT measure the voltage in the high voltage circuit including lament voltage of magnetron.
PRECAUTION
Servicemen should remove their watches whenever working close to or replacing the magnetron.
PRECAUTION
Never touch any circuit wiring with your hand nor with uninsulated tool during operation.

6
2.Specications
2-1 Features
Features
- 1.0 cu.ft Tact
- Crusty-Tray
- Steam Clean
- Harmonious Design
2-2TableofSpecications
Items Model
Model Basic Model New
Model Name CM1039-K/XEU CM1039A-K/XEU(00,01)
Power source 230V 50Hz 230V 50Hz
Power consumption Microwave 1450W 1450W
Grill 1300W 1300W
Conmbined mode 2700W 2700W
Output power 100W / 900W 100W / 900W
Operating frequency 2450MHz 2450MHz
Magnetron OM75P(31) OM75P(31)
Cooling Method Cooling fan motor Cooling fan motor
Dimension
(W x H x D)
Outside 517 x 297 x 412mm 517 x 297 x 412mm
Oven cavity 336 x 225 x 349mm 336 x 225 x 349mm
Volume 26liter 26liter
Weight Net 17.5Kg 17.5Kg
Export Zone UK UK

7
3. Disassembly and Reassembly
Parts Explaination Photo Explaination
Magnetron,
Motor Assembly
and Lamp
1. Disconnect all lead wires from
the magnetron and lamp.
2. Remove a screw securing air
cover.
3. Remove the air cover.
3-1 Disassembly of Magnetron, Motor Assembly and Lamp
Remove the magnetron including the shield case, permanent magnet, choke coils and capacitors (all of which
are contained in one assembly)

8
3. Disassembly and Reassembly
Parts Explaination Photo Explaination
Magnetron,
Motor Assembly
and Lamp
4 . Remove screws securing the
magnetron to the wave guide.
5. Take out the magnetron very
carefully.
6. Remove two screws from the
back panel.
7. Take out the fan motor.
3-1 Disassembly of Magnetron, Motor Assembly and Lamp

9
3. Disassembly and Reassembly
Parts Explaination Photo Explaination
Magnetron,
Motor Assembly
and Lamp
8. Remove the oven lamp from
hole of air cover.
NOTE1: When removing the magnetron, make sure that its antenna does not hit any adjacent parts, or it may be
damaged.
NOTE2: When replacing the magnetron, be sure to remount the magnetron gasket in the correct position and
make sure the gasket is in good condition.
3-2 Replacement of High Voltage Trancefomer
Parts Explaination Photo Explaination
High Voltage
Transformer
1. Discharge the high voltage
capacitor.
2. Disconnect all the leads.
3-1 Disassembly of Magnetron, Motor Assembly and Lamp

10
3. Disassembly and Reassembly
3-2 Replacement of High Voltage Trancefomer
Parts Explaination Photo Explaination
High Voltage
Transformer
3. Remove the mounting bolts.
4. Replace the High Voltage
Transformer
5. After replace, reconnect the
leads correctly and rmly.
PRECAUTION
Servicemen should remove their watches whenever working close to or replacing the magnetron.
PRECAUTION
There exists HIGH VOLTAGE ELECTRICITY with high current capabilities in the circuits of the
HIGHVOLTAGE TRANSFORMER secondary and lament terminals. It is extremely dangerous to work on
or near these circuits with the oven energized.
DO NOT measure the voltage in the high voltage circuit including lament voltage of magnetron.

11
3. Disassembly and Reassembly
3-3 Replacement of Door Assembly
Parts Disassembly Photo Explaination
Removal of
Door “C”
Door “C”
Insert at screwdriver into the gap
between Door “A” and Door “C”. Be
careful when handing Door “C” because it
is fragile. Then remove the door assembly.
Removal
of Door
Assembly
ScrewScrew
ScrewScrew
Upper
Hinge
Upper
Hinge
Lower
Hinge
Lower
Hinge
Remove hex bolts securing the upper
hinge and lower hinge. Then remove the
door assembly.
Removal of
Door “E”
Following the procedure as shown in the
gure, insert and bend a thin metal plate
between Door “E” and Door “A” until you
hear the ‘tick’ sound.
• Insertion depth of the thin metal plate
should be 0.5mm or less.
Removal of
Key Door &
Spring
Remove pin hinge from Door “E”
Detach spring from Door “E” and key door.

12
3. Disassembly and Reassembly
3-4 Replacement of Door Assembly
Reassembly Test
After replacement of the defective component parts of the door, reassemble it and follow the
instructions below for proper installation and adjustment so as to prevent an excessive microwave
leakage.
1. When mounting the door to the oven, be sure to adjust the door parallel to the bottom line of the oven face plate
by moving the upper hinge and lower hinge in the direction necessary for proper alignment.
2. Adjust so that the door has no play between the inner door surface and oven front surface. If the door assembly is
not mounted properly, microwave energy may leak from the space between the door and oven.
3. Do the microwave leakage test.
3-5 Replacement of Fuse
1. Disconnect the oven from the power source.
2. When 12A fuse blows out by the operation of interlock monitor switch failure, replace the primary interlock switch,
door sensing switch, monitor switch and power relay.
3. When the above three switches operate properly, check if any other part such as the control circuit board, blower
motor or high voltage transformer is defective.
3-6 Replacement of Drive Motor
Parts Explaination Photo Explaination
Drive Motor
1. Take out the glass tray,
guide roller from oven cavity,
disconnect power.
2. Remove turn table motor cover
from case bottom.
CAUTION : Remove sharp edge
after cover removal.
3. Disconnect leads from motor.
4. Remove the screws securing
motor to bottom of over cavity.

13
3. Disassembly and Reassembly
Parts Explaination Photo Explaination
Drive Motor
6. Lift out the motor.
5. When replacing the motor, be
sure to remount it in the correct
position.
NOTE : The shaft of motor should
t tip coupler.
COVER FIXING SCREW :
MATCHINE SCREW(6006-001170)
6. When reassemble a drive
motor cover. give a turn in a
180° and x with a screw.
NOTE : Bring the spare screw
from service center.
3-6 Replacement of Drive Motor

14
3. Disassembly and Reassembly
3-7 Replacement of Control Circuit Board
Parts Explaination Photo Explaination
Removal of
Control Box
Assembly
CONTROL BOX
SCREW
1. Disconnect the connectors from the
control box assembly. .
2. Remove screws securing the control
box assembly.
3. Remove the knobs of the control box
A’ssy.
4. Remove the screw securing the
timer.

15
4. Exploded Views and Parts List
4-1 Exploded Views (00Version)
M045
M155
M042
M047 M048
M038
M049
B018
H018
M023
P109
M017
M019
M035
M037
M036
W002
M015
M029
M001
B001
B006
B002
B006
B010
B017 B018
B011
B001
M051
M040
M039
M042
M052
M078
P001
T002

16
4. Exploded Views and Parts List
4-1 Exploded Views (01Version)
M045
M155
M042
M047 M048
M038
M049
B018
H018
M023
P109
M017
M019
M035
M037
M036
W002
M015
M029
M001
B001
B006
B002
B006
B010
B017 B018
B011
B001
M051
M040
M039
M042
M052
M078
P001
T002

17
4. Exploded Views and Parts List
(S.N.A : SERVICE NOT AVAILABLE)
No. Code No. Version Description Specication Q’ty SA/
SNA
Remark
B001 3405-001034 1 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2 SA BODY LATCH
B002 3405-001032 1 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1 SA BODY LATCH
B006 DE72-00137G 1 LATCH-BODY AMC6158/JMC9158,PBT(VB-5050G) 1 SA -
B010 DE66-00093A 1 LEVER SWITCH (A) NC2000 PP-TH53 NTR HA 1 SA BODY LATCH
B011 DE66-00094A 1 LEVER-SWITCH(B) NC2000,PP-TH53,-,-,-,-,N 1 SA BODY LATCH
B026 DE66-00158A 1 LATCH-STOPPER(L) MG1480STB/XAX,PP,-,-,-, 1 SA LATCH LOWER
C029 DE64-02058A 1 KNOB-DIAL CM1039-K,ABS,-,-,-,-,BLK,-,- 2 SA -
C289 DE96-00738A 1 ASSY-TIMER CONTROL MW71E,DAM-TCM1-00,-,W 1 SA -
M017 DE96-00010C 1 ASSY NOISE FILTER SN-3WED(12),250V12A,EU 1 SA -
M019 3601-001019 1 FUSE-CARTRIDGE 250V,12A,SLOW-BLOW,CERAMI 1 SA -
M038 DE26-00051B 1 TRANS H.V SHV-E1049B,230V,50HZ,2360V/3.4 1 SA -
X007 DE60-10067A 1 SCREW-TAP TH -,-,FEFZB,2-SLOT,TH,M4,-,L8 1 SA OUT PANEL SIDE
Z097 DE60-10082I 1 SCREW-A -,-,-,-,2S-4X10,FEFZY,-,-,-,- 4 SA TIMER
4-2 Version List (00,01Version)

18
4. Exploded Views and Parts List
(S.N.A : SERVICE NOT AVAILABLE)
No. Code No. Description Specication Q’ty SA/
SNA
Remark
B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2 SA Body Latch
B002 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1 SA BODY LATCH
B006 DE72-00137G LATCH-BODY AMC6158/JMC9158,PBT(VB-5050G) 1 SA -
B010 DE66-00093A LEVER SWITCH (A) NC2000 PP-TH53 NTR HA 1 SA -
B011 DE66-00094A LEVER-SWITCH(B) NC2000,PP-TH53,-,-,-,-,N 1 SA -
B017 DE66-00117D LATCH-STOPPER AMC6158/JMC9158,PP,-,-,-,B 1 SA LATCH-UPPER
B018 DE96-00120Y ASSY BODY LATCH AMC6158/JMC9158,MAYTAG1. 1 SA -
B026 DE66-00158A LATCH-STOPPER(L) MG1480STB/XAX,PP,-,-,-, 1 SA LATCH-LOWER
H018 DE31-90051A BLADE-FAN P.P,T,D130,-,-,-,- 1 SA -
M001 DE70-00011T PANEL-OUTER SECC T0.6 BLK COAT 360X1128 1 SA -
M015 DE96-00180C ASSY POWER CORD BSI,UK,250V/13A,1500MM,1 1 SA -
M017 DE96-00636A ASSY NOISE FILTER SN-3WEB(12),250V/12A,M 1 SA -
M023 DE31-10177C MOTOR FAN SMF-1049EA,-,-,230V50HZ,15MM,- 1 SA -
M029 DE47-20173A THERMOSTAT PW-2N(90/60)30,187Y,250V7.5A, 1 SA -
M035 OM75P(31)ESGN ASSY-MGT 1 SNA -
M036 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1 SA -
M037 DE71-60016E COVER-AIR CM1049,FH44N,-,-,-,-,-,-,SEMI- 1 SA -
M038 DE26-00051A TRANS H.V SHV-E1049A,230V,50HZ,2255V/3.5 1 SA -
M039 2501-001284 C-OIL 1.10UF,2100V(CLASS P),AL CAN T 1 SA -
M040 DE61-00419A BRACKET-HVC CM1049,SECC,T0.8,-,-,-,- 1 SA -
M042 DE91-70061H ASSY-H.V.FUSE THV060T-0900-H,5KV0.90A,WH 1 SA -
M042 DE59-00002A DIODE-H.V 2CL4512H,450mA, 13KV,MWO ALL, 1 SA -
M045 DE96-00042A ASSY BASE PLATE-SUB 3RD-1.0,SEPARATE-HIN 1 SA -
M047 DE61-40066A FOOT -,PP,-,BLK,-,-,- 2 SA -
M048 DE80-10001G BASE-PLATE 3RD,SGCC,T0.8,W345,L565,-,- 1 SNA -
M049 DE31-10173C MOTOR SYNCHRONOUS -,SEMI-COMM,-,-,-,21V, 1 SA -
M051 DE71-00163A COVER-CEILING CM1049,-,T0.5,W122.2,L137. 1 SA -
M052 DE73-90027A FERRITE-CORE NI-ZN,T13.8,W21.0,L28.0,BNF 1 SA -
M057 DE93-90112C ASSY-B/RESISTOR 10W LB-TYPE 15OHM,TERMIN 1 SA -
M078 DE69-90054A CLIP-STIRRER 5MM,PFA,CM1819/29,-, 4 SA -
M155 DE96-00240A ASSY BASE PLATE CM1049/XEU,SEMI COMMERCI 1 SNA -
P001 DE97-00190A ASSY-STIRRER CM1049,ALS 1 SA -
P109 DE71-00061A COVER-MOTOR 2&2 PROJECT,PP(TB53)95G,-,-, 1 SA -
T002 DE97-00191A ASSY-TRAY CERAMIC CM1049,T3.2,COMMERCIAL 1 SA -
W002 DE39-00295A WIRE HARNESS-A CM1039,-,-,-,-,-,-,-,-,-, 1 SA -
4-3 Main Parts List (00Version)

19
4. Exploded Views and Parts List
(S.N.A : SERVICE NOT AVAILABLE)
No. Code No. Description Specication Q’ty SA/
SNA
Remark
B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2 SA BODY LATCH
B002 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1 SA BODY LATCH
B006 DE72-00137G LATCH-BODY AMC6158/JMC9158,PBT(VB-5050G) 1 SA -
B010 DE66-00093A LEVER SWITCH (A) NC2000 PP-TH53 NTR HA 1 SA BODY LATCH
B011 DE66-00094A LEVER-SWITCH(B) NC2000,PP-TH53,-,-,-,-,N 1 SA BODY LATCH
B017 DE66-00117A LATCH STOPPER MW1480STA,PP, 1 SNA LATCH UPPER
B018 DE94-01862B ASSY BODY LATCH SEMI COMM,PBT BODY LATCH 1 SNA -
B026 DE66-00158A LATCH-STOPPER(L) MG1480STB/XAX,PP,-,-,-, 1 SA LATCH LOWER
H018 DE31-90051A BLADE-FAN P.P,T,D130,-,-,-,- 1 SA -
M001 DE70-00011T PANEL-OUTER SECC T0.6 BLK COAT 360X1128 1 SA -
M015 DE96-00180C ASSY POWER CORD BSI,UK,250V/13A,1500MM,1 1 SA -
M017 DE96-00010C ASSY NOISE FILTER SN-3WED(12),250V12A,EU 1 SA -
M019 3601-001019 FUSE-CARTRIDGE 250V,12A,SLOW-BLOW,CERAMI 1 SA -
M023 DE31-10177C MOTOR FAN SMF-1049EA,-,-,230V50HZ,15MM,- 1 SA -
M029 DE47-20173A THERMOSTAT PW-2N(90/60)30,187Y,250V7.5A, 1 SA -
M035 OM75P(31)ESGN ASSY-MGT 1 SNA -
M036 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1 SA -
M037 DE71-60016E COVER-AIR CM1049,FH44N,-,-,-,-,-,-,SEMI- 1 SA -
M038 DE26-00051B TRANS H.V SHV-E1049B,230V,50HZ,2360V/3.4 1 SA -
M039 2501-001284 C-OIL 1.10UF,2100V(CLASS P),AL CAN T 1 SA -
M040 DE61-00419A BRACKET-HVC CM1049,SECC,T0.8,-,-,-,- 1 SA -
M042 DE91-70061H ASSY-H.V.FUSE THV060T-0900-H,5KV0.90A,WH 1 SA -
M042 DE59-00002A DIODE-H.V 2CL4512H,450mA, 13KV,MWO ALL, 1 SA -
M045 DE96-00042A ASSY BASE PLATE-SUB 3RD-1.0,SEPARATE-HIN 1 SA -
M047 DE61-40066A FOOT -,PP,-,BLK,-,-,- 2 SA -
M048 DE80-10001G BASE-PLATE 3RD,SGCC,T0.8,W345,L565,-,- 1 SNA -
M049 DE31-10173C MOTOR SYNCHRONOUS -,SEMI-COMM,-,-,-,21V, 1 SA -
M051 DE71-00163A COVER-CEILING CM1049,-,T0.5,W122.2,L137. 1 SA -
M052 DE73-90027A FERRITE-CORE NI-ZN,T13.8,W21.0,L28.0,BNF 1 SA -
M078 DE69-90054A CLIP-STIRRER 5MM,PFA,CM1819/29,-, 4 SA -
M155 DE96-00240A ASSY BASE PLATE CM1049/XEU,SEMI COMMERCI 1 SNA -
P001 DE97-00190A ASSY-STIRRER CM1049,ALS 1 SA -
P109 DE71-00061A COVER-MOTOR 2&2 PROJECT,PP(TB53)95G,-,-, 1 SA -
T002 DE97-00191A ASSY-TRAY CERAMIC CM1049,T3.2,COMMERCIAL 1 SA -
W002 DE96-00743A ASSY WIRE HARNESS-A CM1059,-,TCM 1 SNA -
4-3 Main Parts List (01version)

20
4. Exploded Views and Parts List
(S.N.A : SERVICE NOT AVAILABLE)
No. Code No. Description Specication Q’ty SA/
SNA
Remark
D002 DE64-00075B DOOR-A CM1049,ABS(HR0370D),-,D-GRY/G3 1 SA -
D004 DE92-50127H ASSY DOOR-E COATING,BLACK,T0.8 1 SA -
D005 DE01-00002B FILM-DOOR -,PC,-,175,T0.15,275,MW5574W,- 1 SA -
D006 DE64-40012D DOOR-C JES1036NL02,ROH,-,EMBO HEIGHT 1 SA -
D007 DE61-00199A SPRING-KEY M1977,HSWR,D6,-,-,25 1/4,-,T0 1 SA -
D009 DE61-80002A HINGE-UPPER WHT,SHV-745CC1,SSEC,T2.3,26, 1 SA -
D010 DE61-80003A HINGE-LOWER WHT,TN-5630T,SSEC,T2.3,26,77 1 SA -
D011 DE64-00547D KEY-DOOR AMC6158,NYLON#66,-,-,-,-,- 1 SA -
D015 DE94-00265R ASSY DOOR-SUB CM1039,SUS,SEMI COMMERCIAL 1 SA -
D019 DE64-00076C HANDLE CMO EUROPE,CK99FS,ZN DIE CASTI 1 SA -
D024 DE63-00019G SCREEN-DOOR(B) CM1039,-,T3.2,-,-,-,-,- 1 SA -
D026 DE64-00077A HANDLE-COVER CK99FS,PC,-,-,-,-,-,- 2 SA -
D049 DE94-00267K ASSY DOOR CM1039,SUS+ABS,SEMI COMMERCIAL 1 SA -
D068 DE80-00009A CHASSIS-DOOR CK99FS,STS,-,-,-,-,- 1 SNA -
D024
D015
D005
D002
D004 D006
D049
D007
D011
D068
D009
D010
D019
D026
D024
D026
4-4 Door Part List (00Version)
