Samsung M1713 User manual

MICROWAVE OVEN
M1733 / M1713
Owner’s Instructions
M1733/13(GB1) 1/22/00 11:10 PM Page 1

2 SAMSUNG ELECTRONICS
GB
Quick Look-up Guide (M1733)
If you want to cook some food
1 Place the food in the oven.
Select the power level by pressing the button once or more
times.
2 Select the cooking time by pressing the 10min, 1min or 10s
buttons as required.
3 Press the button.
Result: Cooking starts.
The oven beeps four times when cooking is over.
If you want to defrost some food
1 Place the frozen food in the oven.
Press the Auto ( ) button.
Result:The following indication is displayed:
If you want to add an extra minute
1 Leave the food in the oven.
Press +30s once or more times for each extra 30 seconds that
you wish to add.
2 Select the weight by pressing the 100g buttons as required.
3 Press the button.
M1733/13(GB1) 1/22/00 11:10 PM Page 2

GB
SAMSUNG ELECTRONICS
3
Quick Look-up Guide (M1713)
If you want to cook some food
1 Place the food in the oven.
Select the power level by rotating the COOKING POWER
CONTROL knob.
2 Select the cooking time by rotating the TIMER knob.
If you want to defrost some food
1 Turn the COOKING POWER CONTROL knob to ( ).
If you want to adjust the cooking time
1 Leave the food in the oven.
Turn the TIMER knob to desired time.
2 Turn the TIMER knob to select the appropriate time.
M1733/13(GB1) 1/22/00 11:10 PM Page 3

4 SAMSUNG ELECTRONICS
GB
Contents
Quick Look-up Guide................................................................................2
Oven ........................................................................................................5
Control Panel............................................................................................6
Accessories ..............................................................................................8
Using this Instruction Booklet ..................................................................9
Safety Precautions....................................................................................10
Installing Your Microwave Oven................................................................12
Setting the Time(M1733) ..........................................................................12
How a Microwave Oven Works ................................................................13
Checking that Your Oven is Operating Correctly......................................14
What to Do if You are in Doubt or Have a Problem..................................15
Cooking/Reheating....................................................................................16
Power Levels ............................................................................................17
Stopping the Cooking................................................................................18
Adjusting the Cooking Time ......................................................................18
Setting a Standing Time (M1733) ............................................................19
Using the Instant Reheat Feature ............................................................20
Instant Reheat Settings ............................................................................20
Using the Auto Defrost Feature ................................................................22
Manual Defrosting Food (M1713) ............................................................22
Auto Defrost Settings (M1733) ................................................................23
Multistage Cooking (M1733) ....................................................................24
Cookware Guide ......................................................................................25
Cooking Guide ..........................................................................................26
Cleaning Your Microwave Oven................................................................33
Storing and Repairing Your Microwave Oven ..........................................34
Technical Specifications............................................................................35
M1733/13(GB1) 1/22/00 11:10 PM Page 4

GB
SAMSUNG ELECTRONICS 5
Oven
SAFETY
INTERLOCK HOLES
TURNTABLE
DOOR LATCHES
VENTILATION HOLES LIGHT
DISPLAY
OPEN DOOR
PUSH BUTTON
ROLLER RING
DOOR COUPLER
CONTROL PANEL
SAFETY
INTERLOCK HOLES
TURNTABLE
DOOR LATCHES
VENTILATION HOLES LIGHT TIMER KNOB
OPEN DOOR
PUSH BUTTON
ROLLER RING
COUPLER
DOOR
VARIABLE COOKING
POWER CONTROL
KNOB
Model : M1733
Model : M1713
M1733/13(GB1) 1/22/00 11:10 PM Page 5

6 SAMSUNG ELECTRONICS
GB
Control Panel (M1733)
1. DISPLAY 7. STANDING TIME SETTING
2. INSTANT REHEAT SELECTION 8. CLOCK SETTING
3. AUTO DEFROST FEATURE SELECTION 9. START BUTTON
4. WEIGHT SELECTION 10. STOP / CANCEL BUTTON
5. TIME SETTING 11. OPEN DOOR PUSH BUTTON
6. MICROWAVE MODE SELECTION
1
2
3
5
6
9
11
8
4
7
1010
M1733/13(GB1) 1/22/00 11:10 PM Page 6

GB
SAMSUNG ELECTRONICS
7
Control Panel (M1713)
1. DEFROST
2. INSTANT REHEAT
3. OPEN DOOR PUSH BUTTON
2
1
3
M1733/13(GB1) 1/22/00 11:10 PM Page 7

8 SAMSUNG ELECTRONICS
GB
Accessories
Depending on the model that you have purchased, you are supplied
with several accessories that can be used in a variety of ways.
☛DO NOT operate the microwave oven without the roller ring
and turntable.
1Coupler, already placed over the motor shaft in the base of the oven.
Purpose: The coupler rotates the turntable.
2Roller ring, to be placed in the centre of the oven.
Purpose: The roller ring supports the turntable.
3Turntable, to be placed on the roller ring with the centre fitting onto the
coupler.
Purpose: The turntable serves as the main cooking surface. It can be
easily removed for cleaning.
M1733/13(GB1) 1/22/00 11:10 PM Page 8

GB
SAMSUNG ELECTRONICS
9
Using this Instruction Booklet
You have just purchased a SAMSUNG microwave oven. Your Owner’s
Instructions contain much valuable information on cooking with your
microwave oven:
◆Safety precautions
◆Suitable accessories and cookware
◆Useful cooking tips
Inside the cover you will find a quick look-up guide explaining three basic
cooking operations:
◆Cooking food
◆Defrosting food
◆Adding extra cooking time
At the front of the booklet you will find illustrations of the oven, and more
importantly the control panel, so that you can find the buttons more easily.
The step-by-step procedures use two different symbols.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Failure to observe the following safety precautions may result in harmful exposure to
microwave energy.
(a) Under no circumstances should any attempt be made to operate the oven with
the door open or to tamper with the safety interlocks (door latches) or to insert
anything into the safety interlock holes.
(b) Do not place any object between the oven door and front face or allow food or
cleaner residues to accumulate on sealing surfaces. Ensure that the door and
door sealing surfaces are kept clean by wiping after use first with a damp cloth
and then with a soft dry cloth.
(c) Do not operate the oven if it is damaged until it has been repaired by a qualified
microwave service technician trained by the manufacturer.
It is particularly important that the oven door closes properly and that there is no
damage to the:
(1) Door, door seals and sealing surfaces
(2) Door hinges (broken or loose)
(3) Power cable
(d) The oven should not be adjusted or repaired by anyone other than a properly
qualified microwave service technician trained by the manufacturer.
☛
➢
Important Note
M1733/13(GB1) 1/22/00 11:10 PM Page 9

Safety Precautions
Before cooking food or liquids in your microwave oven, please check that the
following safety precautions are taken.
1. DO NOT use any metallic cookware in the microwave oven:
◆ Metallic containers
◆ Dinnerware with gold or silver trimmings
◆ Skewers, forks, etc.
Reason: Electric arcing or sparking may occur and may damage the oven.
2. DO NOT heat:
◆ Airtight or vacuum-sealed bottles, jars, containers
Ex) Baby food jars
◆ Airtight food.
Ex) Eggs, nuts in shells, tomatoes
Reason: The increase in pressure may cause them to explode.
Tip: Remove lids and pierce skins, bags, etc.
3. DO NOT operate the microwave oven when it is empty.
Reason: The oven walls may be damaged.
Tip: Leave a glass of water inside the oven at all times.
The water will absorb the microwaves if you accidentally set the oven going when
it is empty.
4. DO NOT cover the rear ventilation slots with cloths or paper.
Reason: The cloths or paper may catch fire as hot air is evacuated from the oven.
5. ALWAYS use oven gloves when removing a dish from the oven.
Reason: Some dishes absorb microwaves and heat is always transferred from the food to
the dish.The dishes are therefore hot.
6. DO NOT touch heating elements or interior oven walls.
Reason: These walls may be hot enough to burn even after cooking has finished, although
they do not appear to be so. Do not allow inflammable materials to come into
contact with any interior area of the oven. Let the oven cool down first.
7. To reduce the risk of fire in the oven cavity:
◆ Do not store flammable materials in the oven
◆ Remove wire twist ties from paper or plastic bags
◆ Do not use your microwave oven to dry newspapers
◆ If smoke is observed, keep the oven door closed and switch off or disconnect the oven
from the power supply
10 SAMSUNG ELECTRONICS
GB
M1733/13(GB1) 1/22/00 11:10 PM Page 10
