Manual abstract:
To receive more complete service, please register your product at www.samsung.com/register 800W This manual is made with 100 % recycled paper.
MS23F301TAK_EU_DE68-04182K_EN.indd 1 3/20/2013 8:50:20 AM Using this instruction booklet You have just purchased a SAMSUNG microwave oven.
Your Ownerâs Instructions contain valuable information on cooking with your microwave oven: â¢ Safety precautions â¢ Suitable accessories and
cookware â¢ Useful cooking tips â¢ Cooking tips Legend for symbols and icons Hazards or unsafe practices that may result in severe personal injury or
death. Hazards or unsafe practices that may result in minor personal injury or property damage. Warning; Hot surface Warning; Explosive material Do NOT
touch. Follow directions explicitly. Make sure the machine is grounded to prevent electric shock.
Note Important safety instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. Make sure that these safety precautions are obeyed at all
times. Before using the oven, confirm that the following instructions are followed. WARNING (Microwave function only) WARNING: If the door or door seals
are damaged, the oven must not be operated until it has been repaired by a competent person. WARNING: It is hazardous for anyone other than a competent
person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode. This appliance is intended to be used in
household only. 2 ENGLISH WARNING CAUTION Warning; Fire hazard Warning; Electricity Do NOT attempt. Do NOT disassemble. Unplug the power
plug from the wall socket.
Call the service center for help. Important MS23F301TAK_EU_DE68-04182K_EN.indd 2 3/20/2013 8:50:21 AM WARNING: This appliance can be used by
children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children unless they are aged from 8 years and above and supervised. Only use utensils that
are suitable for use in microwave ovens. When heating food in plasitic or paper containers, keep an eye on the oven due to the possibility of ignitions. The
microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and
similar may lead to risk of injury, ignition or fire. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
WARNING: Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container. WARNING:
The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns. Eggs
in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended. The oven
should be cleaned regularly and any food deposites removed. Failure to maintain the oven in a clean conditioin could lead to deterioration of the surface that
could adversely affect the life of the appliance and possibly result in a hazardous situation. The appliance is not intended for installing in road vehicles,
caravans and similar vehicles etc. 3 ENGLISH MS23F301TAK_EU_DE68-04182K_EN.indd 3 3/20/2013 8:50:21 AM This appliance is not intended for use
by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not
play with the appliance.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
WARNING: Liquids or other foods must not be heated in sealed containers since they are liable to explode; The appliance should not be cleaned with a water
jet. This oven should be positioned proper direction and height permitting easy access to cavity and control area. Before using the your oven first time, oven
should be operated with the water during 10 minute and then used. 4 If the oven generates a strange noise, a burning smell, or smoke is emitted, unplug the
power plug immediately and contact your nearest service center. The microwave oven has to be positioned so that plug is accessible.
The microwave oven is intended to be used on the counter or counter top use only, the microwave oven shall not be placed in a cabinet. WARNING (Oven
function only) - Optional WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due
to the temperatures generated. During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. WARNING:
Accessible parts may become hot during use.
Young children should be kept away. A steam cleaner is not to be used. ENGLISH MS23F301TAK_EU_DE68-04182K_EN.indd 4 3/20/2013 8:50:21 AM
WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. WARNING: The appliance and its
accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless
continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of
the glass. 5 The temperature of accessible surfaces may be high when the appliance is operating. The door or the outer surface may get hot when the
appliance is operating. Keep the appliance and its cord out of reach of children less than 8 years. Appliances are not intended to be operated by means of an
external timer or separate remote-control system. This product is a Group 2 Class B ISM equipment. The definition of group 2 which contains all ISM
equipment in which radiofrequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and
EDM and arc welding equipment. For Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to
a low voltage power supply network which supplies buildings used for domestic purposes. ENGLISH MS23F301TAK_EU_DE68-04182K_EN.indd 5
3/20/2013 8:50:21 AM Installing your microwave oven Place the oven on a flat level surface 85 cm above the floor.
The surface should be strong enough to safety bear the weight of the oven. 20 cm 10 cm 1. hen you install your oven, W above behind make sure there is
adequate ventilation for your oven by 10 cm on 85 cm of leaving at least 10 cm (4 inches) the floor the side of space behind and, on the sides of the oven and
20 cm (8 inches) of space above. 2. emove all packing materials inside the oven.
R 3. nstall the roller ring and turntable. Check I that the turntable rotates freely. (Turntable type model only) 4. his microwave oven has to be positioned T so
that plug is accessible.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

For your personal safety, plug the cable into a proper AC earthed socket. Do not install the microwave oven in hot or damp surroundings like next to a
traditional 6 oven or radiator. The power supply specifications of the oven must be respected and any extension cable used must be of the same standard as
the power cable supplied with the oven. Wipe the interior and the door seal with a damp cloth before using your microwave oven for the first time. Cleaning
your microwave oven The following parts of your microwave oven should be cleaned regularly to prevent grease and food particles from building up: â¢
Inside and outside surfaces â¢ Door and door seals â¢ Turntable and Roller rings (Turntable type model only) ALWAYS ensure that the door seals are
clean and the door closes properly. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the
life of the appliance and possibly result in a hazardous situation. 1. lean the outside surfaces with a soft cloth C and warm, soapy water. Rinse and dry.
ENGLISH MS23F301TAK_EU_DE68-04182K_EN.indd 6 3/20/2013 8:50:21 AM 2. emove any splashes or stains on the R inside surfaces of oven with a
soapy cloth. Rinse and dry. 3. o loosen hardened food particles and T remove smells, place a cup of diluted lemon juice in the oven and heat for ten minutes at
maximum power. 4. ash the dishwasher-safe plate whenever W necessary. DO NOT spill water in the vents. NEVER use any abrasive products or chemical
solvents.
Take particular care when cleaning the door seals to ensure that no particles: â¢ Accumulate â¢ Prevent the door from closing correctly Clean the
microwave oven cavity right after each use with a mild detergent solution, but let the microwave oven cool down before cleaning in order to avoid injury.
When cleaning the upper part inside the cavity, it will be convenient to turn heater downward by 45 ° and clean it. 7 (Swing heater model only) Storing and
repairing your microwave oven A few simple precautions should be taken when storing or having your microwave oven serviced. The oven must not be used if
the door or door seals are damaged: â¢ Broken hinge â¢ Deteriorated seals â¢ Distorted or bent oven casing Only a qualified microwave service
technician should perform repair NEVER remove the outer casing from the oven. If the oven is faulty and needs servicing or you are in doubt about its
condition: â¢ Unplug it from the wall socket â¢ Contact the nearest after-sales service centre If you wish to store your oven away temporarily, choose a
dry, dustfree place.
Reason : Dust and damp may adversely affect the working parts in the oven. ENGLISH MS23F301TAK_EU_DE68-04182K_EN.indd 7 3/20/2013 8:50:21 AM
This microwave oven is not intended for commercial use. The Light bulb should not be replaced in person for safety reasons. Please contact nearest
authorised Samsung customer care,to arrange for a qualified engineer to replace the bulb.
WARNING Only qualified staff should be allowed to modify or repair the appliance. Do not heat liquids and other food in sealed containers for microwave
function. For your safety, do not use high-pressure water cleaners or steam jet cleaners. Do not install this appliance; near heater, inflammable material; in a
humid, oily or dusty location, in a location exposed to direct sunlight and water or where gas may leak; on un level ground. This appliance must be properly
grounded in accordance with local and national codes. Remove all foreign substances such as dust or water from the power plug terminals and contact points
using a dry cloth on a regular basis. Do not pull or excessively bend or place heavy objecton the power cord. In the event of a gas leak (such as propane gas,
LP gas, etc.), ventilate immediately without touching the power plug. Do not touch the power plug with wet hands.
8 Do not turn the appliance off by unplugging the power plug while an operation is in progress. Do not insert fingers or foreign substances, If any foreign
substance such as water has entered the appliance, unplug the power plug and contact your nearest service centre.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Do not apply excessive pressure or impact to the appliance. Do not place the oven over a fragile object such as a sink or glass object. Do not use benzene,
thinner, alcohol, steam cleaner or high pressure cleaner to clean the appliance. Ensure that the power voltage, frequency and current are the same as those of
the product specifications. Plug the power plug into the wall socket firmly. Do not use a multiple plug adapter, an extension cord or an electric transformer.
Do not hook the power cord on a metal object, insert the power cord between the objects or behind the oven. Do not use a damaged power plug, damaged
power cord or loose wall socket.
When the power plug or power cord is damaged, contact your nearest service centre. Do not pour or directly spray water onto the oven. Do not place objects
on the oven, inside or on the door of the oven. Do not spray volatile material such as insecticide onto the surface of the oven. ENGLISH
MS23F301TAK_EU_DE68-04182K_EN.
indd 8 3/20/2013 8:50:25 AM Do not store flammable materials in the oven. Take special care when heating dishes or drinks that contain alcohol as alcohol
vapours may contact a hot part of the oven. Keep children away from the door when opening or closing it as they may bump themselves on the door or catch
their fingers in the door. WARNING: Microwave heating of beverages can result in delayed eruptive boiling,therefore care must be taken when handling the
container; To prevent this situation ALWAYS allow a standing time of at least 20 seconds after the oven has been switched off so that the temperature can
equalize. Stir during heating, if necessary, and ALWAYS stir after heating.
In the event of scalding, follow these FIRST AID instructions: â¢ Immerse the scalded area in cold water for at least 10 minutes. â¢ Cover with a clean,
dry dressing. â¢ Do not apply any creams, oils or lotions. Do not immerse the power cable or power plug in water and keep the power cable away from
heat. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has
ended; Also do not heat airtight or vacuum-sealed bottles, jars, containers, nuts inshells, tomatoes etc. Do not cover the ventilation slots with cloth or paper.
They may catch fire as hot air escapes from the oven. The oven may also overheat and switch itself off automatically, and will remain off until it cools
sufficiently. Always use oven mitts when removing a dish from the oven to avoid unintentional burns. Stir liquids halfway during heating or after heating ends
and allow the liquid stand at least 20 seconds after heating to prevent eruptive boiling.
Stand at arms length from the oven when opening the door to avoid getting scalded by escaping hot air or steam. Do not operate the microwave oven when it
is empty. The microwave oven will automatically shut down for 30 minutes for safety purposes. We recommend placing a glass of water inside the oven at all
times to absorb microwave energy in case the microwave oven is started accidentally. Install the oven in compliance with the clearances stated in this manual.
(See installing your microwave oven.) Take care when connecting other electrical appliances to sockets near the oven. ENGLISH CAUTION Only use utensils
that are suitable for use in microwave ovens; DO NOT use any metallic containers, Dinnerware with gold or silver trimmings, Skewers, forks, etc. Remove
wire twist ties from paper or plastic bags. Reason: Electric arcing or sparking may occur and may damage the oven.
Do not use your microwave oven to dry papers or clothes. Use shorter times for smaller amounts of food to prevent overheating and burning food. 9
MS23F301TAK_EU_DE68-04182K_EN.indd 9 3/20/2013 8:50:27 AM Precautions to avoid possible exposure to excessive microwave energy.(microwave
function only) Failure to observe the following safety precautions may result in harmful exposure to microwave energy.
(a) Under no circumstances should any attempt be made to operate the oven with the door open or to tamper with the safety interlocks (door latches) or to
insert anything into the safety interlock holes.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

(b) Do NOT place any object between the oven door and front face or allow food or cleaner residues to accumulate on sealing surfaces. Ensure that the door
and door sealing surfaces are kept clean by wiping after use first with a damp cloth and then with a soft dry cloth. (c) Do NOT operate the oven if it is
damaged until it has been repaired by a qualified microwave service technician trained by the manufacturer. It is particularly important that the oven door
closes properly and that there is no damage to the: (1) door (bent) (2) door hinges (broken or loose) (3) door seals and sealing surfaces (d) The oven should
not be adjusted or repaired by anyone other than a properly qualified microwave service technician trained by the manufacturer.
Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect if the damage to the unit and/or damage to or loss of the accessory
was caused by the customer. Items this stipulation covers include: (a) A Dented, Scratched, or Broken Door, Handle, Out-Panel, or Control Panel. (b) A
Broken or missing Tray, Guide Roller, Coupler, or Wire Rack. â¢ Use this appliance only for its intended purpose as described in this instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use
common sense, caution, and care when installing, maintaining, and operating your appliance. â¢ Because these following operating instructions cover
various models, the characteristics of your microwave oven may differ slightly from 10 those described in this manual and not all warning signs may be
applicable. If you have any questions or concerns, contact your nearest service centre or find help and information online at www. samsung.com.
â¢ This microwave oven is supposed for heating food. It is intended for domestic home-use only. Do not heat any type of textiles or cushions filled with
grains, which could cause burns and fire. The manufacturer cannot be held liable for damage caused by improper or incorrect use of the appliance. â¢
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possible
result in a hazardous situation. ENGLISH Correct disposal of this product (waste electrical & electronic equipment) (Applicable in countries with separate
collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of
material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of
where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should
not be mixed with other commercial wastes for disposal. MS23F301TAK_EU_DE68-04182K_EN.indd 10 3/20/2013 8:50:27 AM contents Quick look-up
guide.11 Oven12 Control panel12 Accessories.
13 . Setting the time13 How a microwave oven works14 Checking that your oven is operating correctly.14 . Cooking/Reheating15 . Power levels.
15 Adjusting the cooking time.15 Stopping the cooking.15 Setting the energy save mode16 Using the deodorize feature16 Using the healthy cooking
features.16 Using healthy cooking programmes: vegetables & grains16 Using healthy cooking programmes: poultry & fish17 Using the auto power defrost
feature18 Using the auto power defrost programmes.18 Using the my plate feature19 Using the my plate programmes.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

19 Power steam cooking guide (Only MS23F301TF**, MS23F302TF** models).19 Using the memory feature21 . Using the memory programmes.21 .
Switching the beeper off.
21 Safety-locking your microwave oven22 . Cookware guide.22 Cooking guide23 Installation & Wiring Instructions.29 . Wiring instructions29 Cooking
instructions on food packaging.30 Cooking instructions.30 What to do if you are in doubt or have a problem.31 Technical specifications31 11 Quick look-up
guide If you want to cook some food. 1. Place the food in the oven.
Select the power level by pressing the Microwave ( ) button one or more times. ENGLISH 2. Select the cooking time by turning the dial knob as required. 3.
Press the Start/+30s ( ) button.
Result : Cooking starts. The oven beeps 4 times when cooking is over. If you want to auto Power defrost some food. 1. Place the frozen food in the oven.
Select the type of food that you are cooking by pressing the Power defrost ( ) button one or more times. 2. Select the weight by turning the dial knob as
required. 3. Press the Start/+30s ( ) button. If you want to add extra 30 seconds. Leave the food in the oven. Press +30s one or more times for each extra 30
seconds that you wish to add. MS23F301TAK_EU_DE68-04182K_EN.indd 11 3/20/2013 8:50:28 AM Oven 1 2 3 4 Control panel 1 ENGLISH 2 3 4 5 800W 8
9 10 6 5 6 7 8 9 10 11 7 800W 11 12 1.
DOOR HANDLE 2. VENTILATION HOLES 3. LIGHT 4. DISPLAY 5. DOOR LATCHES 6. DOOR 7. TURNTABLE 8. COUPLER 9. ROLLER RING 10.
AFETY INTERLOCK HOLES S 11.
ONTROL PANEL C 1. DISPLAY 2. HEALTHY COOKING BUTTON 3. POWER DEFROST BUTTON 4. MICROWAVE BUTTON 5.
CHILD LOCK BUTTON 6. DIAL KNOB (WEIGHT/SERVING/TIME) 7. STOP/ECO BUTTON 8. MY PLATE BUTTON 9. DEODORIZATION BUTTON 10.
EMORY BUTTON M 11. LOCK SETTING BUTTON C S 12. TART/+30s BUTTON 12 MS23F301TAK_EU_DE68-04182K_EN.indd 12 3/20/2013 8:50:28 AM
Accessories Depending on the model that you have purchased, you are supplied with several accessories that can be used in a variety of ways. 1. Coupler,
already placed over the motor shaft in the base of the oven. Purpose : The coupler rotates the turntable. 2. Roller ring, to be placed in the centre of the oven.
Purpose : The roller ring supports the turntable.
3. Turntable, to be placed on the roller ring with the centre fitting to the coupler. Purpose : The turntable serves as the main cooking surface; it can be easily
removed for cleaning. 4. Steam cooker, see page 19 to 21. (Only MS23F301TF**, MS23F302TF** models) Purpose : The plastic steam cooker when using
power steam function. DO NOT operate the microwave oven without the roller ring and turntable. Setting the time Your microwave oven has an inbuilt clock.
When power is supplied, â:0â, â88:88â or â12:00â is automatically displayed on the display. Please set the current time.
The time can be displayed in either the 24- hour or 12-hour notation. You must set the clock: â¢ When you first install your microwave oven â¢ After a
power failure Do not forget to reset the clock when you switch to and from summer and winter time. Auto energy saving function If you do not select any
function when appliance is in the middle of setting or operating with temporary stop condition, function is canceled and clock will be displayed after 25
minutes. Oven Lamp will be turned off after 5 minutes with door open condition. 1.
To display the time in the. 24-hour notation 12-hour notation Press the Clock ( ENGLISH ) button once or twice. 2. Turn the dial knob to set the hour. 3.
Press the Clock ( ) button. 4. Turn the dial knob to set the minute. 5. Press the Clock ( ) button. 13 MS23F301TAK_EU_DE68-04182K_EN.indd 13 3/20/2013
8:50:29 AM How a microwave oven works Microwaves are high-frequency electromagnetic waves; the energy released enables food to be cooked or reheated
without the foods form or colour changing. ENGLISH Checking that your oven is operating correctly The following simple procedure enables you to check
that your oven is working correctly at all times.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Open the oven door by pulling the handle on the right side of the door. Place a glass of water on the turntable.
Then, close the door. 1. Press the Microwave ( Result : ) button. The 800Â W (maximum cooking power) indications are displayed: You can use your
microwave oven to: â¢ Defrost (manual & auto) â¢ Cook â¢ Reheat Cooking Principle. 1. The microwaves generated by the magnetron are distributed
uniformly as the food rotates on the turntable. The food is thus cooked evenly. 2. The microwaves are absorbed by the food up to a depth of about 1 inch (2.5
cm).
Cooking then continues as the heat is dissipated within the food. 3. Cooking times vary according to the recipient used and the properties of the food: â¢
Quantity and density â¢ Water content â¢ Initial temperature (refrigerated or not) 2. Set the time 4 to 5 minutes by turning the dial knob and press the
Start/+30s ( ) button. Result: 800W The oven light comes on and the turntable starts rotating.
1) Cooking starts and when it has finished the oven beeps 4 times. 2) The end reminder signal will beep 3 times (once every minute). 3) The current time is
displayed again. As the centre of the food is cooked by heat dissipation, cooking continues even when you have taken the food out of the oven. Standing times
specified in recipes and in this booklet must therefore be respected to ensure: â¢ Even cooking of the food right to the centre â¢ The same temperature
throughout the food The oven must be plugged into an appropriate wall socket.
The turntable must be in position in the oven. If a power level other than the maximum is used, the water takes longer to boil. 14
MS23F301TAK_EU_DE68-04182K_EN.indd 14 3/20/2013 8:50:30 AM Cooking/Reheating The following procedure explains how to cook or reheat food.
ALWAYS check your cooking settings before leaving the oven unattended. First, place the food in the centre of the turntable. Then, close the door. 1. Press the
Microwave ( Result : ) button. The 800Â W (maximum cooking power) indications are displayed: Select the appropriate power level by pressing the
Microwave ( ) button again until the corresponding wattage is displayed.
Refer to the power level table. The cooking time is displayed. Power levels You can choose among the power levels below. Power level HIGH MEDIUM
HIGH MEDIUM MEDIUM LOW DEFROST ( ) LOW/KEEP WARM Output 800Â W 600Â W 450Â W 300Â W 180Â W 100Â W ENGLISH 2. Set the cooking
time by turning the dial knob. Result : If you select higher power level, the cooking time must be decreased. If you select lower power level, the cooking time
must be increased. Adjusting the cooking time You can increase the cooking time by pressing the +30s button once for each 30 seconds to be added. Press the
+30s button once for each 30 seconds to be added. 3.
Press the Start/+30s ( ) button. Result : The oven light comes on and the turntable starts rotating. 1) Cooking starts and when it has finished the oven beeps 4
times. 2) The end reminder signal will beep 3 times. (once every minute) 3) The current time is displayed again.
Stopping the cooking You can stop cooking at any time to check the food. 1. To stop temporarily; 1) Open the door. Result : Cooking stops. To resume
cooking, close the door and press ( ) again.
2) Press the Stop ( ) button. Result : Cooking stops. To resume cooking, press ( ) again. 2. To stop completely; Press the Stop ( ) button. Result : The cooking
stops. If you wish to cancel the cooking settings, press the Stop ( ) button again. Never switch the microwave oven on when it is empty. If you wish to heat a
dish for a short period of time at maximum power (800Â W), simply press the +30s button once for each 30 seconds of cooking time. The oven starts
immediately.
800W You can also cancel any setting before starting by simply pressing Stop ( ). 15 MS23F301TAK_EU_DE68-04182K_EN.indd 15 3/20/2013 8:50:30 AM
Setting the energy save mode The oven has an energy save mode. This facility saves electricity when the oven is not in use.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Normal condition is standby mode and show clock when not using. ENGLISH â¢ Press the Energy Save ( Result : Display off. ) button. 3. Press the
Start/+30s ( ) button. Result : Cooking starts.
When it has finished. 1) The oven beeps 4 times. 2) The end reminder signal will beep 3 times (once every minute). 3) The current time is displayed again. Use
only recipients that are microwave-safe.
â¢ To remove energy save mode, open the door and then display shows current time. The oven is ready for use. Using the deodorize feature Use this feature
after cooking odorous food or when there is a lot of smoke in the oven interior. First clean the oven interior. Press the Deodorization ( ) button after you have
finished cleaning.
you will hear four beeps when it has finished. The deodorization time has been specified as 5 minutes. It increases by 30 seconds whenever the +30s button is
pressed. The maximum deodorization time is 15 minutes. Using healthy cooking programmes: vegetables & grains The following table presents the 10
Healthy diet auto programmes for cooking vegetables or grains. It contains its quantities, standing times and appropriate recommendations. Programmes
1-10 are running with microwave energy only. Code 1 Food Broccoli Portion (g) 250 500 Standing time (min.) 1-2 Recommendations Rinse and clean fresh
broccoli and prepare florets. Put them evenly into a glass bowl with lid.
Add 30 ml (2 tablespoons) water when cooking for 250Â g, and add 60-75 ml (4-5 tablespoons) for 500Â g. Put bowl in the centre of turntable. Cook covered.
Stir after cooking. Rinse and clean carrots and prepare even slices. Put them evenly into a glass bowl with lid. Add 30 ml (2 tablespoons) water when cooking
for 250Â g. Put bowl in the centre of turntable. Cook covered. Stir after cooking.
Using the healthy cooking features The Healthy Cooking Features has sixteen pre-programmed cooking times. You do not need to set either the cooking times
or the power level. You can adjust the item of the serving by turning the dial knob. First, place the food in the centre of the turntable and close the door. 1.
Select the type of food that you are cooking by pressing the Healthy Cooking ( ) or Healthy Cooking ( ) button once or more times. 2. Select the size of the
serving by turning the dial knob. (Refer to the table on the side). 2 Carrots 250 1-2 16 MS23F301TAK_EU_DE68-04182K_EN.
indd 16 3/20/2013 8:50:31 AM Code 3 Food Green Beans Portion (g) 250 Standing time (min.) 1-2 Recommendations Rinse and clean green beans. Put them
evenly into a glass bowl with lid. Add 30 ml (1 tablespoon) water when cooking 250Â g. Put bowl in the centre of turntable. Cook covered. Stir after cooking.
Rinse and clean spinach. Put into a glass bowl with lid. Do not add water.
Put bowl in the centre of turntable. Cook covered. Stir after cooking. Rinse and clean corn on the cobs and put into an oval glass dish. Cover with microwave
cling film and pierce film. Wash and peel the potatoes and cut into a similar size. Put them into a glass bowl with lid. Add 45-60 ml (3-4 tablespoons) water.
Put bowl in the centre of turntable. Cook covered.
Use a large glass ovenware dish with lid. Add double quantity of cold water (1/4Â l). Cook covered. Stir before standing time and add salt and herbs. Use a
large glass ovenware dish with lid.
Add 1/2 l hot boiling water, a pinch of salt and stir well. Cook uncovered. Cook covered. Stir before standing time and drain thoroughly afterwards. Code 9
Food Quinoa Portion (g) 125 Standing time (min.
) 1-3 Recommendations Use a large glass ovenware dish with lid. Add double quantity of cold water (250 ml). Cook covered. Stir before standing time and
add salt and herbs. Use a large glass ovenware dish with lid. Add double quantity of cold water (250 ml). Cook covered. Stir before standing time and add
salt and herbs. ENGLISH 10 Bulgur 125 2-5 4 Spinach 150 1-2 5 Corn on the cob 250 (1 pcs) 1-2 Using healthy cooking programmes: poultry & fish The
following table presents the 6 Healthy diet auto programmes for cooking poultry and fish, its quantities, standing times and appropriate recommendations.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Programmes 1-6 are running with microwave energy only.
Code 1 Food Chicken Breast Portion (g) 300 (2 pcs) Standing time (min.) 2 Recommendations Rinse pieces and put on a ceramic plate. Cover with
microwave cling film. Pierce film. Put dish on turntable. Rinse pieces and put on a ceramic plate. Cover with microwave cling film. Pierce film. Put dish on
turntable. Rinse fish and put on a ceramic plate, add 1 tablespoon lemon juice.
Cover with microwave cling film. Pierce film. Put dish on turntable. 6 Peeled Potatoes 250 500 2-3 7 Brown Rice (parboiled) 125 5-10 2 Turkey Breast 300 (2
pcs) 2 8 Wholemeal Macaroni 125 1 3 Fresh Fish fillet 300 (2 pcs) 1-2 17 MS23F301TAK_EU_DE68-04182K_EN.indd 17 3/20/2013 8:50:32 AM Code 4
ENGLISH Food Fresh Salmon Filet Portion (g) 300 (2 pcs) Standing time (min.
) 1-2 3. Press the Start/+30s ( ) button. Recommendations Rinse fish and put on a ceramic plate, add 1 tablespoon lemon juice. Cover with microwave cling
film. Pierce film.
Put dish on turntable. Rinse prawns on a ceramic plate, add 1 tablespoon lemon juice. Cover with microwave cling film. Pierce film. Put dish on turntable.
Put 2 fresh whole fish into an ovenproof dish. Add a pinch salt, 1 tablespoon lemon juice, salt and herbs. Cover with microwave cling film. Pierce film. Put
dish on turntable.
Result : â¢ Defrosting begins. â¢ The oven beeps half way through defrosting to remind you to turn the food over. â¢ Press ( ) button again to finish
defrosting. You can also defrost food manually. To do so, select the microwave cooking/reheating function with a power level of 180Â W. Refer to the section
entitled âCooking/Reheatingâ on page 15 for further details. 5 Fresh Prawns 250 1-2 Using the auto power defrost programmes The following table
presents the various Auto Rapid Defrost programmes, quantities, standing times and appropriate recommendations. Remove all kinds of package material
before defrosting. Place meat, poultry, fruit/berry on a ceramic plate. Food Meat Poultry Fish Serving size (g) 200-1500 Standing Recommendations time
(min.
) 15-60 Shield the edges with aluminium foil. Turn the pieces over, when the oven beeps. This programme is suitable for meat such as steaks, chops or minced
meat, chicken pieces, whole chicken or fish fillets. 6 Fresh Trout 200 (1 fish) 2 Using the auto power defrost feature The Auto Power Defrost feature enables
you to defrost meat, poultry, fish and bread/cake. The defrost time and power level are set automatically.
You simply select the programme and the weight. Use only dishes that are microwave-safe. First, place the frozen food in the centre of the turntable and close
the door. 1. Select the type of food that you are cooking by pressing the Power Defrost ( ) button one or more times.
(Refer to the table on the side). 2. Set the weight of food by turning the dial knob. It is possible to set up to a maximum of 1500Â g. Select the Manual
Defrosting function with a power level of 180Â W if you want to defrost food manually. For further details on manual defrosting and defrosting time, refer to
the page 27. 18 MS23F301TAK_EU_DE68-04182K_EN.indd 18 3/20/2013 8:50:33 AM Using the my pLAte feature The my plate feature has two pre-
programmed cooking times. You do not need to set either the cooking times or the power level. You can adjust the number of servings by turning the dial knob.
First, place the food in the centre of the turntable and close the door. 1. Select the type of food that you are cooking by pressing the My plate ( ) button once or
more times. 2. Select the size of the serving by turning the dial knob. (Refer to the table on the side.) Code/Food 2. Chilled Vegetarian Meal Serving size (g)
300-350 400-450 Standing time (min.) 2-3 Recommendations Put meal on a ceramic plate and cover with microwave cling film. This programme is suitable
for meals consisting of 2 components (e.
g. spaghetti with sauce or rice with vegetables). ENGLISH Power steam cooking guide (Only MS23F301TF**, MS23F302TF** models) The Power Steamer
is based on the principle of steam cooking, and is designed for fast, healthy cooking in your Samsung Microwave oven.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

This accessory is ideal for cooking rice, pasta, vegetables, etc. in record time, while preserving their nutritional values.
The Microwave Power steamer set is made up of 3 items: 3. Press the ( ) button. Result : Cooking starts. When it has finished. 1) The oven beeps 4 times.
2) The end reminder signal will beep 3 times (once every minute). 3) The current time is displayed again. Use only recipients that are microwave-safe. Using
the my plate programmes The following table presents the My Plate auto reheat programmes, quantities, standing times and appropriate recommendations.
Those programmes are running with microwave energy only. Code/Food 1. Chilled Ready meal Serving size (g) 300-350 400-450 Standing time (min.) 2-3
Recommendations Put on a ceramic plate and cover with microwave cling film. This programme is suitable for meals consisting of 3 components (e.g.
meat with sauce, vegetables and a side dishes like potatoes, rice or pasta). Bowl Insert tray Lid All parts withstand temperatures from -20 °C to 140 °C.
Suitable for freezer storage. Can also be used separately or together. CONDITIONS of USE: Do not use: â¢ to cook foods with a high sugar or fat content,
â¢ with the grill or rotating heat function or on a hob. Wash all parts well in soapy water before first use. To find out cooking times, please refer to the
instructions in the table on next page. 19 MS23F301TAK_EU_DE68-04182K_EN.indd 19 3/20/2013 8:50:33 AM MAINTENANCE: Your steamer can be
washed in a dishwasher. When washing by hand, use hot water and washing-up liquid.
Do not use abrasive pads. ENGLISH Food Rice Some foods (such as tomato) may discolour the plastic. This is normal and not a manufacturing fault.
DEFROSTING: Place the frozen food in the steam bowl without the lid. The liquid will remain in the bottom of the pot and will not harm the food.
Jacket potatoes COOKING: Cooking Standing Power Food Portion time time Handling levels (min.) (min.) Artichokes 300Â g 800Â W 5-6 1-2 Bowl with
insert (1-2 pcs) tray + Lid Instructions Rinse and clean artichokes. Put insert tray into bowl. Set artichokes on tray.
Add one tablespoon lemon juice. Cover with lid. Fresh 300Â g 800Â W 4-5 1-2 Bowl with insert vegetables tray + Lid Instructions Weigh the vegetables (e.g.
broccoli, cauliflower, carrots, pepper) after washing, cleaning and cutting into similar size. Put tray into bowl. Distribute vegetables on insert tray. Add 2
tablespoons water. Cover with lid. 300Â g 600Â W 7-8 2-3 Bowl with insert Frozen vegetables tray + Lid Instructions Put the frozen vegetables into the steam
bowl.
Put insert tray into bowl. Add 1 tablespoon water. Cover with lid. Stir well after cooking and standing. 20 Stew (chilled) Soup (chilled) Frozen soup Frozen
yeast dumpling with jam filling Cooking Standing time time Handling (min.) (min.) 250Â g 800Â W 15-18 5-10 Bowl + Lid Instructions Put rice into the steam
bowl. Add 500 ml cold water. Cover with lid. After cooking let stand white rice 5 minutes, brown rice 10 minutes.
500Â g 800Â W 7-8 2-3 Bowl + Lid Instructions Weigh and rinse the potatoes and put them into steam bowl. Add 3 tablespoons water. Cover with lid. 400Â g
600Â W 5-6 1-2 Bowl + Lid Instructions Put stew into the steam bowl. Cover with lid.
Stir well before standing. 400Â g 800Â W 3-4 1-2 Bowl + Lid Instructions Pour into steam bowl. Cover with lid. Stir well before standing. 400Â g 800Â W
8-10 2-3 Bowl + Lid Instructions Put frozen soup into steam bowl.
Cover with lid. Stir well before standing. 150Â g 600Â W 1-2 2-3 Bowl + Lid Instructions Moist the top of filled dumplings with cold water. Put 1-2 frozen
dumplings side by side into the steam bowl. Cover with lid. Portion Power levels MS23F301TAK_EU_DE68-04182K_EN.indd 20 3/20/2013 8:50:33 AM
Food Fruit compote Cooking Standing time time Handling (min.) (min.) 250Â g 800Â W 3-4 2-3 Bowl + Lid Instructions Weigh the fresh fruits (e.g.
apples, pears, plums, apricots, mangoes or pineapple) after peeling, washing and cutting into similar sizes or cubes.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Put into steam bowl. Add 1-2 tablespoons water and 1-2 tbsp. sugar. Cover with lid. Portion Power levels 2. Set your cooking programme as usual (power
level and cooking time) see if necessary. 3. Press the ( ) button. Result : Your setting are now stored in the ovenâs memory.
ENGLISH Using the memory programmes First, place the food in the centre of the turntable and close the door. 1. To select the. Then press the ( button Once
(Display is P1) Twice (Display is P2) ) Handling of power steam cooker + Bowl + Lid Bowl with insert tray + Lid First setting Second setting 2. Press the ( )
button.
Result : PRECAUTIONS: Take special care when opening the lid of your steamer, because the steam escaping may be very hot. Use oven gloves when
handling after cooking. The food is cooked as requested. Switching the beeper off You can switch the beeper off whenever you want. 1.
Press the ( ) and ( ) buttons at the same time. Result : â¢ The following indication is displayed. â¢ The oven does not beep each time you press a button. 2.
To switch the beeper back on, press the ( ) and ( ) buttons again at the same time. Result : â¢ The following indication is displayed. â¢ The oven operates
with the beeper on again. 21 Using the memory feature If you often cook or reheat the same types of dishes, you can store the cooking times and power levels
in the ovenâs memory, so that you do not have to reset them each order. You can store two different setting. Storing the settings.
1. To programme the. First setting Second setting Then press the ( button Once (Display is P1) Twice (Display is P2) )
MS23F301TAK_EU_DE68-04182K_EN.indd 21 3/20/2013 8:50:34 AM Safety-locking your microwave oven Your microwave oven is fitted with a special
Child Safety programme, which enables the oven to be âlockedâ so that children or anyone unfamiliar with it cannot operate it accidentally. The oven
can be locked at any time. ENGLISH Cookware China and earthenware Microwave-safe â Comments Porcelain, pottery, glazed earthenware and bone
china are usually suitable, unless decorated with a metal trim. Some frozen foods are packaged in these dishes. 1. Press the ( ) buttons at the same time.
Result : â¢ The oven is locked (no functions can be selected).
â¢ The display shows âLâ. Disposable polyester cardboard dishes Fast-food packaging â¢ Polystyrene cups containers â¢ Paper bags or
newspaper â¢ Recycled paper or metal trims Glassware â¢ Oven-to-tableware â¢ Fine glassware â â 2. To unlock the oven, press the ( ) buttons
again at the same time. Result : The oven can be used normally. â â Can be used to warm food.
Overheating may cause the polystyrene to melt. May catch fire. May cause arcing. Cookware guide To cook food in the microwave oven, the microwaves must
be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken when choosing the cookware.
If the cookware is marked microwave-safe, you do not need to worry. The following table lists various types of cookware and indicates whether and how they
should be used in a microwave oven. Cookware Aluminum foil Microwave-safe ââ Comments Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to the oven wall or if too much foil is used. Do not preheat for more than 8 minutes. â â â¢ Glass
jars Metal â¢ Dishes â¢ Freezer bag twist ties Paper â¢ Plates, cups, napkins and kitchen paper â¢ Recycled paper â Can be used, unless
decorated with a metal trim. Can be used to warm foods or liquids. Delicate glass may break or crack if heated suddenly. Must remove the lid. Suitable for
warming only.
May cause arcing or fire. â â â Crust plate â â For short cooking times and warming. Also to absorb excess moisture. May cause arcing. 22
MS23F301TAK_EU_DE68-04182K_EN.indd 22 3/20/2013 8:50:35 AM Cookware Plastic â¢ Containers Microwave-safe â Comments Particularly if
heat-resistant thermoplastic.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Some other plastics may warp or discolour at high temperatures. Do not use Melamine plastic. Can be used to retain moisture. Should not touch the food.
Take care when removing the film as hot steam will escape. Only if boilable or oven-proof. Should not be airtight. Prick with a fork, if necessary. Can be used
to retain moisture and prevent spattering.
frozen vegetables, fruit, pasta, rice, grains, beans, fish, and meat. Sauces, custard, soups, steamed puddings, preserves, and chutneys can also be cooked in a
microwave oven. Generally speaking, microwave cooking is ideal for any food that would normally be prepared on a hob. Melting butter or chocolate, for
example (see the chapter with tips, techniques and hints). Covering during cooking To cover the food during cooking is very important, as the evaporated
water rises as steam and contributes to cooking process.
Food can be covered in different ways: e.g. with a ceramic plate, plastic cover or microwave suitable cling film. Standing times After cooking is over food the
standing time is important to allow the temperature to even out within the food. Cooking Guide for frozen vegetables Use a suitable glass pyrex bowl with lid.
Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir twice during cooking and once after cooking. Add salt,
herbs or butter after cooking. Cover during standing time.
Food Spinach Portion (g) 150 Power (W) 600 Time (min.) 4½-5½ Standing time (min.) 2-3 Instructions Add 15 ml (1 tablespoon) cold water. Add 30 ml (2
tablespoon) cold water. Add 15 ml (1 tablespoon) cold water. Add 30 ml (2 tablespoon) cold water. ENGLISH â¢ Cling film â â¢ Freezer bags
ââ Wax or grease-proof paper â â : Recommended ââ : Use Caution â : Unsafe Cooking guide MICROWAVES Microwave energy
actually penetrates food, attracted and absorbed by its water, fat and sugar content. The microwaves cause the molecules in the food to move rapidly. The
rapid movement of these molecules creates friction and the resulting heat cooks the food. Broccoli 300 600 9-10 2-3 COOKING Cookware for microwave
cooking: Cookware must allow microwave energy to pass through it for maximum efficiency.
Microwaves are reflected by metal, such as stainless steel, aluminium and copper, but they can penetrate through ceramic, glass, porcelain and plastic as well
as paper and wood. So food must never be cooked in metal containers. Food suitable for microwave cooking: Many kinds of food are suitable for microwave
cooking, including fresh or 23 Peas 300 600 7½-8½ 2-3 Green beans 300 600 8-9 2-3 MS23F301TAK_EU_DE68-04182K_EN.indd 23 3/20/2013 8:50:35
AM Food Mixed vegetables (carrots/peas/ corn) Mixed vegetables (chinese style) Portion (g) 300 Power (W) 600 Time (min.) 7½-8½ Standing time (min.
) 2-3 Cooking Guide for fresh vegetables Instructions Add 15 ml (1 tablespoon) cold water. Add 15 ml (1 tablespoon) cold water. 300 600 8-9 2-3 Use a
suitable glass pyrex bowl with lid. Add 30-45 ml cold water (2-3 tbsp.) for every 250Â g unless another water quantity is recommended â see table.
Cook covered for the minimum time â see table. Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or
butter after cooking. Cover during a standing time of 3 minutes. Hint : Cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker
they will cook. All fresh vegetables should be cooked using full microwave power (800Â W). Food Broccoli Portion (g) 250 500 250 250 250 500 250 Time
(min.) 4-4½ 7-7½ 5½-6½ 4½-5 5-5½ 8½-9 3½-4 Standing time (min.
) 3 Instructions Prepare even sized florets. Arrange the stems to the centre. Add 60-75 ml (5-6 tbsp.) water. Cut carrots into even sized slices. Prepare even
sized florets. Cut big florets into halves. Arrange stems to the centre. Cut courgettes into slices. Add 30 ml (2 tbsp.
) water or a knob of butter.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Cook until just tender. Cut egg plants into small slices and sprinkle with 1 tablespoon lemon juice. Cut leeks into thick slices. Prepare small whole or sliced
mushrooms.
Do not add any water. Sprinkle with lemon juice. Spice with salt and pepper. Drain before serving. ENGLISH Cooking Guide for rice and pasta Rice : Use a
large glass pyrex bowl with lid - rice doubles in volume during cooking.
Cook covered. After the cooking time is over, stir before standing time and salt or add herbs and butter. Remark: the rice may not have absorbed all water
after the cooking time is finished. Use a large glass pyrex bowl. Add boiling water, a pinch of salt and stir well. Cook uncovered. Stir occasionally during and
after cooking. Cover during standing time and drain thoroughly afterwards. Portion (g) 250 250 250 250 250 Power (W) 800 800 800 800 800 Time (min.)
16-17 21-22 17-18 18-19 11-12 Standing time (min.
) 5 5 5 5 5 Instructions Add 500 ml cold water. Add 500 ml cold water. Add 500 ml cold water. Add 400 ml cold water. Add 1000 ml hot water. Pasta :
Brussels sprouts Carrots Cauliflower 3 3 3 Food White rice (parboiled) Brown rice (parboiled) Mixed rice (rice + wild rice) Mixed corn (rice + grain) Pasta
Courgettes 3 Egg plants 250 3½-4 3 Leeks Mushrooms 250 125 250 4½-5 1½-2 3-3½ 3 3 24 MS23F301TAK_EU_DE68-04182K_EN.indd 24 3/20/2013
8:50:35 AM Food Onions Portion (g) 250 Time (min.) 5½-6 Standing time (min.) 3 Instructions Cut onions into slices or halves. Add only 15 ml (1 tbsp.
) water. Cut pepper into small slices. Weigh the peeled potatoes and cut them into similar sized halves or quarters. Cut turnip cabbage into small cubes. It is
preferable to underestimate cooking time and add extra heating time, if necessary.
Heating and standing times When reheating food for the first time, it is helpful to make a note of the time taken â for future reference. Always make sure
that the reheated food is piping hot throughout. Allow food to stand for a short time after reheating - to let the temperature even out. The recommended
standing time after reheating is 2-4 minutes, unless another time is recommended in the chart. Take particular care when heating liquids and baby food.
See also the chapter with the safety precautions. Pepper Potatoes 250 250 500 250 4½-5 4-5 7½-8½ 5-5½ 3 3 ENGLISH Turnip cabbage 3
REHEATING Your microwave oven will reheat food in a fraction of the time that conventional ovens hobs normally take. Use the power levels and reheating
times in the following chart as a guide. The times in the chart consider liquids with a room temperature of about +18 to +20 °C or a chilled food with a
temperature of about +5 to +7 °C. Arranging and covering Avoid reheating large items such as joint of meat â they tend to overcook and dry out before
the centre is piping hot. Reheating small pieces will be more successful. Power levels and stirring Some foods can be reheated using 800Â W power while
others should be reheated using 600Â W, 450Â W or even 300Â W. Check the tables for guidance. In general, it is better to reheat food using a lower power
level, if the food is delicate, in large quantities, or if it is likely to heat up very quickly (mince pies, for example). Stir well or turn food over during reheating
for best results.
When possible, stir again before serving. Take particular care when heating liquids and baby foods. To prevent eruptive boiling of liquids and possible
scalding, stir before, during and after heating. Keep them in the microwave oven during standing time. We recommend putting a plastic spoon or glass stick
into the liquids. Avoid overheating (and therefore spoiling) the food. 25 REHEATING LIQUIDS Always allow a standing time of at least 20 seconds after the
oven has been switched off to allow the temperature to even out. Stir during heating, if necessary, and ALWAYS stir after heating. To prevent eruptive boiling
and possible scalding, you should put a spoon or glass stick into the beverages and stir before, during and after heating.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

Reheating Liquids and Food Use the power levels and times in this table as a guide lines for reheating.
Food Drinks (coffee, tea and water) Portion 150 ml (1 cup) 250 ml (1 mug) Power (W) 800 Time (min.) 1-1½ 1½-2 Standing time (min.) 1-2 Instructions
Pour into cup and reheat uncovered. Put cup/ mug in the centre of turntable. Keep in microwave oven during standing time and stir well.
Pour into a deep ceramic plate. Cover with plastic lid. Stir well after reheating. Stir again before serving. Soup (chilled) 250 g 800 3-3½ 2-3
MS23F301TAK_EU_DE68-04182K_EN.
indd 25 3/20/2013 8:50:35 AM Food Stew (chilled) ENGLISH Portion 350 g Power (W) 600 Time (min.) 5½-6½ Standing time (min.) 2-3 REHEATING
BABY FOOD Instructions Put stew in a deep ceramic plate. Cover with plastic lid. Stir occasionally during reheating and again before standing and serving.
Put pasta (e.g. spaghetti or egg noodles) on a flat ceramic plate. Cover with microwave cling film. Stir before serving.
Put filled pasta (e.g. ravioli, tortellini) in a deep ceramic plate. Cover with plastic lid. Stir occasionally during reheating and again before standing and
serving. Plate a meal of 2-3 chilled components on a ceramic dish. Cover with microwave cling-film. Pasta with sauce (chilled) 350 g 600 4½-5½ 3
BABY FOOD: Empty into a deep ceramic plate. Cover with plastic lid. Stir well after reheating! Let stand for 2-3 minutes before serving.
Stir again and check the temperature. Recommended serving temperature: between 30-40 °C. BABY MILK: Pour milk into a sterilised glass bottle. Reheat
uncovered. Never heat a babyâs bottle with teat on, as the bottle may explode if overheated.
Shake well before standing time and again before serving ! Always carefully check the temperature of baby milk or food before giving it to the baby.
Recommended serving temperature: ca. 37 °C. REMARK: Baby food particularly needs to be checked carefully before serving to prevent burns. Use the
power levels and times in the next table as a guide lines for reheating.
Reheating baby food and milk Use the power levels and times in this table as guide lines for reheating. Food Baby food (vegetables + meat) Portion 190Â g
Power (W) 600 Time 30 sec. Standing time (min.) 2-3 Instructions Empty into ceramic deep plate. Cook covered. Stir after cooking time. Stand for 2-3
minutes. Before serving, stir well and check the temperature carefully. Filled pasta with sauce (chilled) 350Â g 600 5-6 3 Plated meal (chilled) 350Â g 600
5½-6½ 3 26 MS23F301TAK_EU_DE68-04182K_EN.indd 26 3/20/2013 8:50:35 AM Food Baby porridge (grain + milk + fruit) Portion 190 g Power (W)
600 Time 20 sec.
Standing time (min.) 2-3 MANUAL DEFROSTING Instructions Empty into ceramic deep plate. Cook covered. Stir after cooking time. Stand for 2-3 minutes.
Before serving, stir well and check the temperature carefully. Stir or shake well and pour into a sterilized glass bottle. Place into the centre of turn-table.
Cook uncovered. Shake well and stand for at least 3 minutes.
Before serving, shake well and check the temperature carefully. Baby milk 100 ml 200 ml 300 30-40 sec. 50 sec. to 1 min. 2-3 Microwaves are an excellent
way of defrosting frozen food.
Microwaves gently defrost frozen food in a short period of time. This can be of great advantage, if unexpected guests suddenly show up. Frozen poultry must
be thoroughly thawed before cooking. Remove any metal ties and take it out of any wrapping to allow thawed liquid to drain away. Put the frozen food on a
dish without cover.
Turn over half way, drain off any liquid and remove any giblets as soon as possible. Check the food occasionally to make sure that it does not feel warm. If
smaller and thinner parts of the frozen food start to warm up, they can be shield by wrapping very small strips of aluminium foil around them during
defrosting. Should poultry start to warm up on the outer surface, stop thawing and allow it to stand for 20 minutes before continuing. Leave the fish, meat and
poultry to stand in order to complete defrosting.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

The standing time for complete defrosting will vary depending on the quantity defrosted. Please refer to the table below. Hint : Flat food defrosts better than
thick and smaller quantities need less time than bigger ones. Remember this hint while freezing and defrosting food. For defrosting of frozen food with a
temperature of about -18 to -20 °C, use the following table as a guide.
All frozen food should be defrosted using defrosting power level (180 W). Food Meat Minced beef Pork steaks Portion Time (min.) 6½-7½ 10-12
7½-8½ Standing time (min.) 5-25 Instructions ENGLISH 250 g 500 g 250 g Place the meat on a flat ceramic plate. Shield thinner edges with
aluminium foil. Turn over after half of defrosting time! 27 MS23F301TAK_EU_DE68-04182K_EN.indd 27 3/20/2013 8:50:35 AM Food Poultry Chicken
pieces ENGLISH Portion Time (min.) 14½-15½ 28-30 Standing time (min.) 15-40 SPECIAL HINTS Instructions MELTING BUTTER Put 50 g butter into
a small deep glass dish. Cover with plastic lid.
Heat for 30-40 seconds using 800Â W, until butter is melted. MELTING CHOCOLATE Put 100Â g chocolate into a small deep glass dish. Heat for 3-5
minutes, using 450Â W until chocolate is melted. Stir once or twice during melting. Use oven gloves while taking out! MELTING CRYSTALLIZED HONEY
Put 20Â g crystallized honey into a small deep glass dish.
Heat for 20-30 seconds using 300Â W until honey is melted. MELTING GELATINE Lay dry gelatine sheets (10Â g) for 5 minutes into cold water. Put drained
gelatine into a small glass pyrex bowl. Heat for 1 minute using 300Â W. Stir after melting.
COOKING GLAZE/ICING (FOR CAKE AND GATEAUX) Mix instant glaze (approximately 14 g) with 40Â g sugar and 250 ml cold water. Cook uncovered in
a glass pyrex bowl for 3½ to 4½ minutes using 800 W, until glaze/icing is transparent. Stir twice during cooking. COOKING JAM Put 600 g fruits (for
example mixed berries) in a suitable sized glass pyrex bowl with lid. Add 300Â g preserving sugar and stir well. Cook covered for 10-12 minutes using
800Â W. Stir several times during cooking. Empty directly into small jam glasses with twist-off lids. Stand on lid for 5 minutes. COOKING PUDDING Mix
pudding powder with sugar and milk (500 ml) by following the manufacturers instructions and stir well.
Use a suitable sized glass pyrex bowl with lid. Cook covered for 6½ to 7½ minutes using 800 W. Stir several times well during cooking. BROWNING
ALMOND SLICES Spread 30 g sliced almonds evenly on a medium sized ceramic plate. Stir several times during browning for 3½ to 4½ minutes using
600Â W. Let it stand for 2-3 minutes in the oven. Use oven gloves while taking out! 28 Whole chicken 500Â g (2 pcs) 900Â g First, put chicken pieces first skin-
side down, whole chicken first breast-side-down on a flat ceramic plate. Shield the thinner parts like wings and ends with aluminium foil. Turn over after half
of defrosting time! Put frozen fish in the middle of a flat ceramic plate. Arrange the thinner parts under the thicker parts.
Shield narrow ends with aluminium foil. Turn over after half of defrosting time! Fish Fish fillets 250Â g (2 pcs) 400Â g (4 pcs) 6-7 12-13 5-15
MS23F301TAK_EU_DE68-04182K_EN.indd 28 3/20/2013 8:50:35 AM Installation & Wiring Instructions IMPORTANT NOTE : The mains lead on this
equipment is supplied with a moulded plug incorporating a fuse. The value of the fuse is indicated on the pin face of the plug and, if it requires replacing, a
fuse approved to BS1363 of the same rating must be used. Never use the plug with the fuse cover omitted if the cover is detachable.
If a replacement fuse cover is required, it must be of the same colour as the pin face of the plug. Replacement covers are available from your Dealer. If the
fitted plug is not suitable for the power points in your house or the cable is not long enough to reach a power point, you should obtain a suitable safety
approved extension lead or consult your Dealer for assistance.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

However, if there is no alternative to cutting off the plug, remove the fuse and then safely dispose of the plug. Do not connect the plug to a mains socket, as
there is a risk of shock hazard from the bared flexible cord.
Connect the blue wire to the terminal marked with the letter N or coloured black. Consult a qualified electrician or service technician if in doubt about any of
these instructions. The manufacturer of this oven will not accept any liability for damage to persons or material for non observance of these requirements.
There are no user-serviceable parts inside the oven and if the mains lead of this appliance is damaged, it must only be replaced by qualified service personnel
approved by the manufacturer because special tools are required. WARNING ENGLISH Wiring instructions WARNING THIS APPLIANCE MUST BE
EARTHED. This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock providing an escape wire for
the electric current. The appliance is equipped with a mains lead which includes an earth wire for connecting to the earth terminal of your mains plug. The
plug must be plugged into a socket that is properly installed and earthed. The wires in this mains lead are coloured in accordance with the following code:
â¢ Green and yellow : Earth â¢ Blue : Neutral â¢ Brown : Live As the colours of the wires in the mains lead of this appliance may not correspond with
the coloured markings indentifying the terminals in your plug, proceed as follows.
Connect the green and yellow wire to the terminal in the plug marked with the letter E or the earth symbol ( ) or coloured green or green-and-yellow. 29
WARNING WARNING : Ensure that the plug and power cord are not damaged before use. If you have any reason to remove the moulded plug from this
appliance, immediately remove the fuse and dispose of the plug. Do not connect the plug to a mains socket under any circumstances as there is a danger of
electric shock. CIRCUITS : Your microwave oven should be operated on a separate circuit from other appliances. Failure to do this may cause the circuit
breaker to trip, the fuse to blow, or the food to cook more slowly. MS23F301TAK_EU_DE68-04182K_EN.indd 29 3/20/2013 8:50:35 AM Cooking
instructions on food packaging Microwave Symbols On the front of your oven there is a microwave oven symbol, as shown below. This symbol has been
introduced for your benefit when cooking or reheating packaged food. 800W Cooking instructions The IEC Power Output rating is an internationally
standardised rating, so all microwave manufacturers now use the same method of measuring power output.
If food packaging gives cooking instructions based on IEC Power ratings, set cooking times according to the IEC Power of your oven. For example : If the
cooking instructions are based on a 650 W oven, then you will need to reduce some cooking time for the MS23F301T**, MS23F302T** (800 W) Ready meals
are now very convenient and popular. These are meals which are already prepared and cooked by the food manufacturer, and then frozen, chilled or vacuum
sealed for long life. Increasingly, heating times for such ready meals are being based on the Heating Categories A, B, C, D and E. On this instance, simply
match the heating category of your oven to the instructions on the food package, and set your timer accordingly.
For example : If the heating instructions are 3 minutes on HIGH for a D category oven, then you will need to set your timer for less than 3 minutes on HIGH
for the MS23F301T**, MS23F302T** (E category). Always remember that cooking instructions are intended only as a guide. If you have followed the
instructions and the food is still not piping hot throughout, simply return it to the oven and cook it until it is. ENGLISH Packaged food is also, increasingly,
using a microwave symbol similar to the one below. When you see this 800W Symbol on food packaging, the cooking instructions are based on either the IEC
Power Output Rating, or the Reheating Categories A, B, C, D or E.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714

30 MS23F301TAK_EU_DE68-04182K_EN.indd 30 3/20/2013 8:50:35 AM What to do if you are in doubt or have a problem If you have any of the problems
listed below try the solutions given. This is normal. â¢ Condensation inside the oven. â¢ Air flow around the door and outer casing. â¢ Light reflection
around the door and outer casing. â¢ Steam escaping from around the door or vents. The oven does not start when you press the ( ) button. â¢ Is the door
completely closed? The food is not cooked at all. â¢ Have you set the timer correctly and/or pressed the ( ) button? â¢ Is the door closed? â¢ Have you
overloaded the electric circuit and caused a fuse to blow or a breaker to be triggered? The food is either overcooked or undercooked.
â¢ Was the appropriate cooking length set for the type of food? â¢ Was an appropriate power level chosen? Sparking and cracking occur inside the oven
(arcing). â¢ Have you used a dish with metal trimmings? â¢ Have you left a fork or other metal utensil inside the oven? â¢ Is aluminum foil too close to
the inside walls? The light bulb is not working. â¢ The Light bulb should not be replaced in person for safety reasons. Please contact nearest authorised
Samsung customer care, to arrange for a qualified engineer to replace the bulb. The oven causes interference with radios or televisions. â¢ Slight
interference may be observed on televisions or radios when the oven is operating. This is normal. To solve this problem, install the oven away from
televisions, radios and aerials. â¢ If interference is detected by the ovenâs microprocessor, the display may be reset. To solve this problem, disconnect
the power plug and reconnect it.
Reset the time. If the above guidelines do not enable you to solve the problem, then contact your local SAMSUNG customer service centre. Please have the
following information read. â¢ The model and serial numbers, normally printed on the rear of the oven â¢ Your warranty details â¢ A clear description
of the problem Then contact your local dealer or SAMSUNG aftersales service. ENGLISH Technical specifications SAMSUNG strives to improve its products
at all times.
Both the design specifications and these user instructions are thus subject to change without notice. Model Power source Power consumption Microwave
MS23F301T** , MS23F302T** 230 V ~ 50 Hz 1150Â W 100 W / 800 W (IEC-705) - 240 V : 800 W - 230 V : 750 W 2450 MHz OM75S (31) Cooling fan
motor 489 x 275 x 374 mm 330 x 211 x 324 mm 23 liter 12 kg approx Output power Operating frequency Magnetron Cooling method Dimensions (W x H x D)
Outside Oven cavity Volume Weight Net 31 MS23F301TAK_EU_DE68-04182K_EN.indd 31 3/20/2013 8:50:35 AM AUSTRIA BELGIUM DENMARK
FINLAND FRANCE GERMANY ITALIA CYPRUS GREECE LUXEMBURG NETHERLANDS NORWAY PORTUGAL SPAIN SWEDEN SWITZERLAND U.K
EIRE 0810 - SAMSUNG (7267864, â¬ 0.07/min) 02-201-24-18 70 70 19 70 030-6227 515 01 48 63 00 00 0180 5 SAMSUNG bzw.
0180 5 7267864* (*0,14 â¬/Min. aus dem dt. Festnetz, aus dem Mobilfunk max. 0,42 â¬/Min.) 800-SAMSUNG(726-7864) 8009 4000 only from landline
([phone] from mobile and land line 80111-SAMSUNG (80111 726 7864) only from land line ([phone] from mobile and land line 261 03
710 0900-SAMSUNG (0900-7267864) (â¬ 0,10/Min) 815 56480 808 20-SAMSUNG(808 20 7267) 902 - 1 - SAMSUNG (902 172 678) 0771 726 7864
(SAMSUNG) 0848 - SAMSUNG(7267864, CHF 0.08/min) 0330 SAMSUNG (7267864) 0818 717100 www.samsung.com www.samsung.com/be (Dutch) www.
samsung.com/be_fr (French) www.samsung.com www.samsung.com/fr www.samsung.com www.samsung.com/ch (German) www.
samsung.com/ch_fr (French) www.samsung.com Code No.: DE68-04182K MS23F301TAK_EU_DE68-04182K_EN.
.
You're reading an excerpt. Click here to read official SAMSUNG
MS23F301TAK/EU user guide
http://somemanuals.com/dref/5329714
Powered by TCPDF (www.tcpdf.org)
