Samsung NQ70M9770DM/AA User manual

Built-In Microwave Combi Oven
User manual
NQ70M9770D*
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 1 2018-10-05  4:17:01

2 English
Regulatory Notice
For products sold in the US and Canadian markets, only
channels 1~11 are available. You cannot select any other
channels.
FCC STATEMENT:
This equipment has been tested and found to comply within
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
A. Do not attempt to operate this microwave oven with the door open since
open-door operation can result in harmful exposure to microwave energy. It is
important not to defeat or tamper with the safety interlocks.
B. Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on the sealing surface.
C. Do not operate the microwave oven if it is damaged. It is particularly
important that the oven door close properly and that there is no damage to
the:
1) Door (bent),
2) Hinges and latches, (broken or loosened),
3) Door seals and sealing surface.
D. The microwave oven should not be adjusted or repaired by anyone except
properly qualied service personnel.
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is
Subject to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 2 2018-10-05  4:17:01

English 3
Regulatory Notice
2. IC Notice
The term “IC” before the radio certication number only
signies that Industry Canada technical specications were
met. Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only
channels 1~11 are available. You cannot select any other
channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated so there is at least
8 inches (20 cm) between the radiator and your body. This
device and its antenna(s) must not be co-located or operated in
conjunction with any other antenna or transmitter.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV
• Consulting the dealer or an experienced radio/TV technician for
help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated so there is at least 8 inches
(20 cm) between the radiator and your body. This device and
its antenna(s) must not be co-located or operated in conjunction
with any other antenna or transmitter.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 3 2018-10-05  4:17:01

4 English
Contents
ContentsContents
Important safety instructions 5
Introducing your new oven 19
Overview 19
What’s included with your oven 19
Before you begin 20
Energy saving tips 20
Turntable (For microwave oven) 20
Water reservoir 21
Basic operations 22
Control panel 22
Setting the temperature 22
Control lockout 23
Kitchen timer 23
Microwave oven (Upper Oven) 26
Setting the power level 26
Timed cooking 26
Microwave 27
Power convection 28
Broil 28
Speed power convection 29
Speed broil 29
Auto cook 30
Defrost 35
Sensor cook 36
Fit choice 40
Slim fry 43
Power auto cook 44
Oven (Lower Oven) 46
Timed cooking 46
Delay start 47
Using the temp probe 48
Twin cooking mode temperature setting ranges 49
Oven functions 50
Using the healthy cook feature 57
Using the favorite recipes and gourmet cook feature 59
Using the smart control feature (Lower oven only) 60
Using the oven racks 61
Using the gliding rack 63
Using the divider 64
Using the clean feature 65
Settings 71
Using the Sabbath feature 73
Maintaining your appliance 75
Care and cleaning of the oven 75
Removing the oven door (Lower oven only) 77
Replacing the oven door (Lower oven only) 78
Changing the oven light (Lower oven only) 79
Troubleshooting 79
Control Display 79
For the Microwave Oven 80
For the Lower Oven 83
Information codes 86
Warranty (U.S.A) 87
Warranty (CANADA) 88
Appendix 90
Open Source Announcement 90
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 4 2018-10-05  4:17:01

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal
injury when using your oven, follow these basic safety
precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric
shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and
others. Please follow them explicitly.
After reading this section, keep it in a safe place for future
reference.
Important safety instructions
Read and follow all instructions before using your oven to
prevent the risk of re, electric shock, personal injury, or
damage when using the oven. This guide does not cover all
possible conditions that may occur. Always contact your service
agent or the manufacturer about problems that you do not
understand.
WHAT YOU NEED TO KNOW ABOUT SAFETY
INSTRUCTIONS
Warnings and important safety instructions in this manual do
not cover all possible conditions and situations that may occur.
It is your responsibility to use common sense, caution, and care
when installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 5 2018-10-05  4:17:01

6 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Microwave Oven)
9. This appliance should be repaired or serviced only by qualied service
personnel. Contact the nearest authorized service facility for examination,
repair, or adjustment.
10. Do not cover or block any openings in the appliance.
11. Do not tamper with or make any adjustments or repairs to the door.
12. Do not store this appliance outdoors. Do not use this product near water, for
example, near a kitchen sink, in a wet basement, near a swimming pool, or
similar locations.
13. Do not immerse the cord or plug in water.
14. Keep the cord away from heated surfaces (including the back of the oven).
15. Do not let the cord hang over edge of table or counter.
16. When cleaning surfaces of the door and oven that come together when the
door closes, use only mild, nonabrasive soaps, or detergents applied with a
sponge or soft cloth. Unplug the plug before cleaning the unit.
17. To reduce the risk of re in the oven cavity:
• Do not overcook food. Carefully attend appliance when paper, plastic,
or other combustible materials are placed inside the oven to facilitate
cooking.
• Remove wire twist-ties from paper or plastic bags before placing the bags
in the oven.
18. If materials inside the oven ignite, keep the oven door closed, turn the oven
off, and disconnect the power cord, or shut off the power at the fuse or circuit
breaker panel. If the door is opened, the re may spread.
19. Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
WARNING
To reduce risk of burns, electric shock, re, personal injury or exposure to
excessive microwave energy:
1. Read all safety instructions before using the appliance.
2. Read and follow the specic “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY” on page 2.
3. This appliance must be grounded. Connect only to properly grounded outlets.
See Important “GROUNDING INSTRUCTIONS” on page 7of this manual.
4. Install or locate this appliance only in accordance with the provided
installation instructions.
5. Some products such as whole eggs and sealed containers (for example, closed
glass jars) can explode if heated rapidly. Never heat them in a microwave
oven.
6. Use this appliance only for its intended use as described in the manual. Do
not put corrosive chemicals or vapors in or on this appliance. This type of
microwave oven is specically designed to heat, cook, or dry food. It is not
designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when it is used by
children. Keep children away from the door when opening or closing it as they
may bump themselves on the door or catch their ngers in the door.
8. Do not operate this appliance if it has a damaged cord or plug, if it is not
working properly, or if it has been damaged or dropped.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 6 2018-10-05  4:17:02

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
WARNING
Improper use of the grounding plug can result in a risk of electric shock.
• Plug into a grounded 3 prong outlet. Do not remove the third (grounding)
prong. Do not use an adaptor or otherwise defeat the grounding plug.
• Consult a qualied electrician or service person if you do not understand
the grounding instructions or if you are not sure if the appliance is properly
grounded.
• We do not recommend using an extension cord with this appliance. If the
power-supply cord is too short, have a qualied electrician or serviceman
install an outlet near the appliance. However, if it is necessary to use an
extension cord, read and follow the “Use of Extension Cords” section below.
USE OF EXTENSION CORDS
A short power-supply cord is provided to reduce the risk of your becoming
entangled in or tripping over a longer cord. Longer cord sets or extension cords
are available and you can use them if you exercise care. If you use a long cord or
extension cord:
1. The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance.
2. The extension cord must be a grounding-type 3-wire cord and it must be
plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled on by children or tripped over
accidentally. If you use an extension cord, the interior light may icker and the
speed of the blower may vary when the microwave oven is on. Cooking times
may be longer too.
20. Liquids, such as water, milk, coffee, or tea can be overheated beyond the
boiling point without appearing to be boiling. Visible bubbling or boiling when
the container is removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN
THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED
INTO THE LIQUID. To reduce the risk of injury:
• Do not overheat liquid.
• Stir liquid both before and halfway through heating it.
• Do not use straight-sided containers with narrow necks.
• After heating, let containers with liquid stand in the microwave oven for a
short time before removing.
• Use extreme care when inserting a spoon or other utensil into a container
holding liquid.
21. Oversized foods or oversized metal utensils should not be inserted into the
microwave oven as they may create a re or electric shock.
22. Do not clean with metal scouring pads. Pieces can burn off the pad and touch
electrical parts creating a risk of electric shock.
23. Do not store any materials, other than manufacturer’s recommended
accessories, in this microwave oven when not in use.
24. Do not cover the racks or any other part of the microwave oven with metal
foil. This will cause overheating of the oven.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for the
electrical current. This appliance is equipped with a cord that includes a grounding
wire and a grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 7 2018-10-05  4:17:02

8 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Oven)
• Do not enter the oven.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the
room.
• Do not use water on grease res. Turn off the oven to
avoid spreading the ames. Smother the re or ames by
closing the door or use a dry chemical, baking soda, or
foam-type extinguisher.
• Avoid scratching or striking the glass doors and the control
panel. Doing so may lead to glass breakage. Do not cook on
a product with broken glass. Shock, re, or cuts may occur.
FOR YOUR SAFETY
When using electrical appliances, you should follow basic
safety precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include the oven vent opening, surfaces
near the opening, and crevices around the oven door.
Proper Installation - Be sure your appliance is properly
installed and grounded by a qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual.
All other servicing should be referred to a qualied
technician.
Always disconnect the power to the appliance before
servicing by removing the fuse or switching off the circuit
breaker.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 8 2018-10-05  4:17:02

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not
let the potholder touch hot heating elements. Do not use a
towel or other bulky cloth instead of a potholder.
• Teach children not to play with the controls or any other
part of the oven.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the oven.
• If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly qualied
persons to avoid creating a hazard.
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
• If there is a re in the oven during self-cleaning, turn the
oven off and wait for the re to go out. Do not force the
door open. The introduction of fresh air at self-cleaning
temperatures may lead to a burst of ame from the oven.
Failure to follow these instructions may result in severe
burns.
• If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place
creates a risk of re.
• Wipe up heavy soil on the oven bottom with a paper tower
or rag before self-cleaning. Self-cleaning the oven when
there is heavy soil on the oven bottom requires longer
cleaning cycles and produces more smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from
parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 9 2018-10-05  4:17:02

10 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Oven)
WARNING
• Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children
or inrm persons without the adequate supervision of a
responsible adult.
• Young children should be supervised to ensure that they do not
play with the appliance.
• Keep children away from the door when opening or closing it as
they may bump themselves on the door or catch their ngers in
the door.
• During self-cleaning, the surfaces may get hotter than usual.
Keep small children away from the oven when it is in the self-
cleaning mode.
WARNING
Accessible parts may become hot during use. To avoid burns,
young children should be kept away.
ELECTRICAL SAFETY
• Use only the factory installed exible power cord to
connect to the power supply. Do not use a 3rd party power
supply cord kit.
• The appliance should be serviced only by qualied service
personnel. Repairs carried out by unqualied individuals
may cause injury or a serious malfunction. If your appliance
is in need of repair, contact a Samsung authorized service
center. Failure to follow these instructions may result in
damage and void the warranty.
• Flush - mounted appliances may be operated only after
they have been installed in cabinets and workplaces that
conform to the relevant standards. This ensures that the
appliances are installed in compliance with the appropriate
safety standards.
• If your appliance malfunctions or if fractures, cracks, or
splits appear:
-Switch off the oven.
-Unplug the oven from the AC wall outlet.
-Contact your local Samsung service center.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 10 2018-10-05  4:17:02

English 11
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use care when opening the door. Let hot air or steam
escape before you remove food from or put food into the
oven.
• Protective liners. Do not use aluminum foil to line the oven
bottoms, except as suggested in this manual. Improper
installation of these liners may result in a risk of electric
shock or re.
• Placement of oven racks. Always place oven racks in the
desired location while the oven is cool. If the rack must be
moved while the oven is hot, use potholders. Do not let the
potholders come in contact with the hot heating element in
the oven.
• Do not allow aluminum foil or a meat probe to contact the
heating elements.
• During use, the appliance becomes hot.
Care should be taken to avoid touching heating elements
inside the oven.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass. They can scratch the surface
which may result in the glass shattering.
OVEN
• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot
even though they are dark in color. Interior surfaces of
an oven become hot enough to cause burns. During and
after use, do not touch or let clothing or other ammable
materials contact the heating elements or interior surfaces
of the oven until they have had sufcient time to cool.
Other surfaces of the appliance may become hot enough to
cause burns. Among these surfaces are oven vent openings
and surfaces near these openings, the oven door, and the
window of the oven door.
• Do not heat unopened food containers. The build-up of
pressure may cause the container to burst and result in
injury.
• Do not use the oven to dry newspapers. If overheated,
newspapers can catch re.
• Do not use the oven for a storage area. Items stored in an
oven can ignite.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 11 2018-10-05  4:17:02

12 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Oven)
• Do not use any commercial oven cleaner or oven liner
protective coating of any kind in or on the outside of the
oven.
-Remove the nickel oven shelves from the oven before
you begin the self-cleaning cycle or they may discolor.
-If the self-cleaning mode malfunctions, turn the oven
off and disconnect the power supply. Have it serviced
by a qualied technician.
-Excess spillage must be removed before you run the
self-cleaning cycle.
VENTILATING HOOD
• Clean ventilating hoods frequently. Do not let grease
accumulate on the hood or lter.
• When aming foods under the hood, turn the fan on.
CAUTION
Do not attempt to operate the oven during a power failure.
If the power fails, always turn the oven off. If the oven is
not turned off and the power returns, the oven may begin to
operate again. Food left unattended could catch re or spoil.
SELFCLEANING OVENS
Do not clean the door gasket. The door gasket is essential
for a good seal. Care should be taken not to rub, damage,
or move the gasket.
• Never keep pet birds in the kitchen. Birds are extremely
sensitive to the fumes released during an oven self-clean
cycle. Fumes may be harmful or fatal to birds. Move birds
to a well-ventilated room.
• Clean only the parts listed in this manual in the self-clean
cycle. Before self-cleaning the oven, remove the partition,
racks, utensils, and any food.
• Before operating the self-clean cycle, wipe grease and food
soils from the oven. Excessive amounts of grease may
ignite, leading to smoke damage to your home.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 12 2018-10-05  4:17:02

English 13
Important safety instructions
SAVE THESE INSTRUCTIONS
• Do not cut or remove the ground prong from the power
cord under any circumstances.
• Connect the oven to a circuit that provides the correct
amperage.
• Do not install this appliance in a humid, oily or dusty
location, or in a location exposed to direct sunlight or water
(rain drops).
-This may result in electric shock or re.
• Do not use a damaged power cord or loose wall socket.
-This may result in electric shock or re.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a
heavy object on the power cord, or insert the power cord
between objects.
-This may result in electric shock or re.
If the power cord is damaged, contact your nearest
Samsung service center.
CRITICAL INSTALLATION WARNINGS
WARNING
• This appliance must be installed by a qualied technician
or service company.
-Failing to have a qualied technician install the oven
may result in electric shock, re, an explosion, problems
with the product, or injury.
• Unpack the oven, remove all packaging material and
examine the oven for any damage such as dents on the
interior or exterior of the oven, broken door latches, cracks
in the door, or a door that is not lined up correctly. If there
is any damage, do not operate the oven and notify your
dealer immediately.
• Keep all packaging materials out of the reach of children.
Children may use them for play and injure themselves.
• This appliance must be properly grounded.
• Do not ground the appliance to a gas pipe, plastic water
pipe, or telephone line.
-This may result in electric shock, re, an explosion, or
problems with the product
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 13 2018-10-05  4:17:02

14 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Oven)
• Always observe safety precautions when using your
oven. Never try to repair the oven on your own - there is
dangerous voltage inside. If the oven needs to be repaired,
contact an authorized Samsung service center near you.
• If you use the appliance when it is contaminated by foreign
substances such as food waste, it may result in a problem
with the appliance.
• Take care when removing the wrapping from food you
have taken out of the oven.
-If the food is hot, hot steam may be emitted abruptly
when you remove the wrapping and this may result in
burns.
• Do not attempt to repair, disassemble, or modify the
appliance yourself.
-Since a high voltage current enters the product chassis,
it may result in electric shock or re.
-When a repair is needed, contact your nearest Samsung
service center.
• If any foreign substance such as water has entered the
appliance, contact your nearest Samsung service center.
-Failing to do so may result in electric shock or re.
CRITICAL USAGE WARNING
CAUTION
• If the appliance is ooded by any liquid, please contact
your nearest Samsung service center. Failing to do so may
result in electric shock or re.
• If the appliance produces a strange noise, a burning smell,
or smoke, unplug the power plug immediately and contact
your nearest Samsung service center.
-Failing to do so may result in electric shock or re
• In the event of a gas leak (such as propane gas, LP gas,
etc.), ventilate the area immediately. Do not touch the
power cord. Do not touch the appliance.
-A spark may result in an explosion or re.
• Take care not to contact the oven door, heating elements,
or any of the other hot parts with your body while cooking
or just after cooking.
-Failing to do so may result in burns.
• If materials inside the oven should ignite, keep the oven
door closed, turn the oven off and disconnect the power
cord, or shut off power at the fuse or circuit breaker panel.
If the door is opened, the re may spread.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 14 2018-10-05  4:17:02

English 15
Important safety instructions
SAVE THESE INSTRUCTIONS
• Do not insert ngers, foreign substances, or metal objects
such as pins or needles into inlets, outlets, or holes. If
foreign substances are inserted into any of these holes,
contact your product provider or nearest Samsung service
center.
• Do not tamper with or make any adjustments or repairs to
the door. Under no circumstances should you remove the
door or outer shell of the oven.
• Do not store or use the oven outdoors.
• Never use this appliance for purposes other than cooking.
-Using the appliance for any purpose other than cooking
may result in re.
• Open the cap or stopper of sealed containers (herb tonic
tea bottle, baby bottle, milk bottle and so on) before
heating them. Make a hole in food items that have shells
(eggs, chestnuts, etc.) with a knife before cooking them.
-Failing to do so may result in burns or injury.
• Never heat plastic or paper containers and do not use them
for cooking.
-Failing to do so may result in re.
• Do not touch the power cord with wet hands.
-This may result in electric shock.
• Do not turn the appliance off while an operation is in
progress.
-This may cause a spark and result in electric shock or
re.
• Do not let children or any person with reduced physical,
sensory, or mental capabilities use this appliance
unsupervised.
• Make sure that the appliance’s controls and cooking areas
are out of the reach of children.
-Failing to do so may result in electric shock, burns, or
injury.
• Do not touch the inside of the appliance immediately after
cooking. The inside of the appliance will be hot.
-Failing to do so may result in burns.
• Do not use or place ammable sprays or objects near the
oven.
-Flammable items or sprays can cause res or an
explosion.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 15 2018-10-05  4:17:02

16 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Oven)
USAGE CAUTIONS
CAUTION
• If the surface is cracked, turn the appliance off.
-Failing to do so may result in electric shock.
• Dishes and containers can become hot. Handle with care.
• Hot foods and steam can cause burns. Carefully remove
container coverings, directing the steam away your hands
and face.
• Remove lids from baby food jars before heating. After
heating baby food, stir well to distribute the heat evenly.
Always test the temperature by tasting before feeding the
baby. The glass jar or the surface of the food may appear
to be cooler than the interior, which can be hot enough to
burn an infant’s mouth.
• Take care as beverages or food may be very hot after
heating.
-Especially when feeding a child, make sure the food or
beverage has cooled sufciently.
• Do not heat food wrapped in paper from magazines,
newspapers, etc.
-This may result in re.
• Do not open the door when the food in the oven is burning.
-If you open the door, it causes an inow of oxygen and
may cause the food to ignite.
• Do not apply excessive pressure to the door or the inside
of the appliance. Do not strike the door or the inside or the
appliance.
-Hanging on to the door may result in the product
falling and cause serious injury.
-If the door is damaged, do not use the appliance.
Contact a Samsung service center.
• Do not hold food in your bare hands during or immediately
after cooking.
-Use cooking gloves. The food may be very hot and you
could burn yourself.
-As the handle and oven surfaces may be hot enough
to cause burns after cooking, use cooking gloves to
protect your hands from burns.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 16 2018-10-05  4:17:02

English 17
Important safety instructions
SAVE THESE INSTRUCTIONS
• Do not put your face or body close to the appliance while
cooking or when opening the door just after cooking.
-Take care that children do not come too close to the
appliance.
-Failing to do so may result in children burning
themselves.
• Do not place food or heavy objects over the edge of the
oven door.
-If you open the door, the food or object may fall and
this may result in burns or injury.
• Do not abruptly cool the door, the inside of the appliance, or
a dish by pouring water over it during or just after cooking.
-This may result in damage to the appliance. The steam
or water spray may result in burns or injury.
• Do not operate while empty except for self-cleaning.
• Do not defrost frozen beverages in narrow-necked bottles.
The bottles can break.
• Do not scratch the glass of the oven door with a sharp
object.
-This may result in the glass being damaged or broken.
• Do not store anything directly on top of the appliance
when it is in operation.
• Take care when heating liquids such as water or other
beverages.
-Make sure to stir during or after cooking.
-Avoid using a slippery container with a narrow neck.
-Wait at least 30 seconds after heating before removing
the heated liquid.
-Failing to do so may result in an abrupt overow of the
contents and cause burns.
• Do not stand on top of the appliance or place objects
(such as laundry, an oven cover, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the
appliance.
-Items, such as a cloth, may get caught in the door.
-This may result in electric shock, re, problems with the
product, or injury.
• Do not operate the appliance with wet hands.
-This may result in electric shock.
• Do not spray volatile substances such as insecticide onto
the surface of the appliance.
-As well as being harmful to humans, it may also result
in electric shock, re, or problems with the product.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 17 2018-10-05  4:17:02

18 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions (Oven)
CRITICAL CLEANING WARNINGS
CAUTION
• Do not clean the appliance by spraying water directly on to
it.
• Do not use benzene, thinner, or alcohol to clean the
appliance.
-This may result in discoloration, deformation, damage,
electric shock, or re.
• Take care not to hurt yourself when cleaning the appliance
(externally or internally).
-You may hurt yourself on the sharp edges of the
appliance.
• Do not clean the appliance with a steam cleaner.
-This may result in corrosion.
• Keep the inside of the oven clean. Food particles or
spattered oils stuck to the oven walls or oor can cause
paint damage and reduce the efciency of the oven.
• Do not use sealed containers. Remove seals and lids before
cooking. Sealed containers can explode due to the build up
of pressure even after the oven has been turned off.
• Take care that food you are cooking in the oven does not
come into contact with the heating element.
-This may result in re.
• Do not over-heat food.
-Overheating food may result in re.
• Use caution when opening or closing the door. Your ngers
may be pinched, resulting in physical injury.
• The door has wires at the bottom for connecting LED lights.
Be careful not to pull or cut the wires when handling the
door.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 18 2018-10-05  4:17:02

English 19
Introducing your new oven
What’s included with your oven
This oven ships with different kinds of accessories that help you cook what you
want.
Accessories for oven
Wire rack (1)* Gliding racks (2)* Divider (1)*
Temp probe (1)*
Wire rack Use these racks in the lower oven when baking and
broiling.
Gliding racks The fully extendable Gliding Rack makes food preparation
easier, especially when you are preparing heavier dishes.
Divider Use the Divider to divide the lower oven into two
cavities so you can cook two different items at the same
time.
Temp probe The Temp probe lets you cook meat to the exact internal
temperature you want, taking the guess work out of
determining whether a piece of meat is done or not.
Introducing your new oven
Overview
06
05
03
04
11
09 02 10
08
07
08
02
01
01 Control panel 02 Door latch 03 MWO door
04 Door LED light 05 Oven gasket 06 Oven door
07 LED lamp 08 Convection fan 09 Halogen lamp*
10 Water reservoir 11 Shelf position
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 19 2018-10-05  4:17:03

20 English
Before you begin
Introducing your new oven
Accessories for microwave
Roller ring* Turntable* Hot plate*
Low rack* High rack*
Roller ring Put in the center of the base. It supports the turntable.
Turntable Put on the roller ring with the center tting of the coupler.
It serves as a cooking base.
Racks Use one of these racks as appropriate to cook two dishes
simultaneously. A smaller dish on the turntable, and the
other on the selected rack. You can use these racks with
Broil or Convection function.
NOTE
Do not use wire racks with Microwave mode except
where specically noted in this manual.
Hot plate Put on the turntable. Use this to brown food, or to keep
pastries or pizza crisp.
NOTE
• Do not use the turntable without the roller ring.
• If you need an accessory marked with a *, you can buy it from the Samsung
Contact Center (1-800-726-7864).
Before you begin
Before using the top and bottom ovens for the rst time, remove all the
accessories, and then clean the ovens thoroughly. Then, set the lower oven to
Bake, and run it at 400 °F for 1 hour. Next, set the microwave (top) oven to Power
Convection, and then run it at 400 °F for 1 hour. There will be a distinctive odor.
This is normal.
Ensure your kitchen is well ventilated during this conditioning period.
Energy saving tips
• During cooking, the oven door should remain closed except when you turn
food over. Do not open the door frequently during cooking to maintain the
oven temperature and to save energy.
• If cooking time is more than 30 minutes, you can switch the oven off
5-10 minutes before the end of the cooking time to save energy. The residual
heat will complete the cooking process.
• To save energy and reduce the time needed for re-heating the oven, plan oven
use to avoid turning the oven off between cooking one item and the next.
• Whenever possible, cook more than one item at a time.
Turntable (For microwave oven)
3
Remove all packing materials inside the
oven.Install the roller ring and turntable.
Check that the turntable rotates freely.
NQ70M9770D_AA_DE68-04503A-02_EN+MES+CFR.indb 20 2018-10-05  4:17:03
