Samsung PS50B451B2W User manual

English - 1
The Supplied Accessoris
Owner’s Instructions Remote Control/
AAA Batteries (2ea)
Power Cord Cloth-Clean
Ferrite Core for
Power Cord
Screw (4ea) Cover-Bottom Holder-Ring (4ea)
Installing Batteries in the Remote Control
PDP TV
QUICK SETUP GUIDE
BN68-02137A.indd 1 2009-03-30 오후 3:45:25

English - 2
Installing the Stand
Step 1. Attach your PDP TV to the stand.
Firmly secure the stand to the TV before moving it, as the stand may fall and could cause serious injury.
Two or more people should carry the TV. Never lay the TV on the oor because of possible damage to the screen.
Always store the TV upright.
N
N
Step 1. Using the 4 screws for securing the stand base and the monitor, rmly attach the monitor to the stand base. (The exterior of
the set may be different than the picture.)
Step 3. In case of installing your TV on the wall, close the cover 1on the stand-base connection part using two screws for hiding.
Assembling the Cables
Enclose the cables in the Holder-Wire Cable so that the cables are not visible through the
transparent stand.
Using the remote control buttons
Back
Front Back
Front
Step 1 Step 2 Step 3
RETURN Button
Returns to the previous menu
EXIT Button
Exit the on-screen menu
MENU Button
Displays the favourites channel list.
ENTER E / Direction Button
Move the cursor and select an item.
Select the currently selected item.
Confirm the setting.
BN68-02137A.indd 2 2009-03-30 오후 3:45:28

English - 3
Plug & Play
When the TV is initially powered on, basic settings proceed automatically and subsequently.
If you want to reset this feature, press the MENU button to display menu.
You can set the Plug & Play by selecting Setup → Plug & Play.
On the screen, you can set as follows.
The each step may vary depending on the Antenna source. N
Plug & Play
Select the OSD Language.
E Enter
Language : English ►
Step 1
Plug & Play
Select the Antenna source to memorize.
Air
Cable Start
U Move E Enter Skip
Start
Step 4
Step 3
Plug & Play
Select Country.
E Enter
Country : United Kingdom ►
Step 2
Plug & Play
Select ‘Home Use’ when installing this TV in your
home.
Store Demo Home USE
L Move E Enter
Step 9
Enjoy your TV.
OK
Step 7
Step 5
Plug & Play
Select the Antenna source to memorize.
Digital & Analogue
Digital
Analogue
Start
U Move E Enter Skip
Start
Start
Step 6
Plug & Play
Auto Program in Progress.
Stop
3%
Channel 10
Digital Channels : 0 Analogue Channels : 0
Step 8
Plug & Play
Set the Clock Mode.
E Enter Skip
Clock Mode : Auto ►
E Enter Skip
HD Connection Guide
How to get the best performance from your new HDTV.
Step 1. Connect the HD Box to the TV using the HDMI or Component
cables.
HD box
TV rear view
1/2
Component Cable
r Next Skip
HDMI Cable
BN68-02137A.indd 3 2009-03-30 오후 3:45:30

English - 4
Connecting a AV device
WY R
WYR
R
G
B
WR
W R
RGB
HD connection
DVD / Blu-Ray player / Cable Box
/ Satellite receiver (STB)
Using a DVI Cable
AUDIO OUTDVI OUT
HD connection
DVD / Blu-Ray player / HD Cable
Box / HD Satellite receiver (STB)
Using an HDMI Cable
HDMI OUT
Audio/Video connection
VCR
Using an Audio/Video Cable
AUDIO OUTVIDEO OUT
Component connection
DVD / Blu-Ray player / Cable
Box / Satellite receiver
Using a Component Cable
AUDIO OUT COMPONENT OUT
HDMI/DVI
PC/COMPONENT
EXT/VIDEO
Best
Normal
VCR / DVD
Using a Scart Cable
EXT
BN68-02137A-00
BN68-02137A
BN68-02137A.indd 4 2009-03-30 오후 3:45:31
