Samsung NX583G0VBSR User manual

FREESTANDING
GAS RANGES
Refer to the service manual in the Global Service Partner Network (GSPN).
See rear cover for more information.
1. Precautions
2. Specications
3. Disassembly and
Reassembly
4. Troubleshooting
5. Wiring Diagrams
6. Schematic Diagrams
7. PCB Diagrams
GAS RANGES CONTENTS
BASIC: NX583G0VBSR
MODELS AND
MODEL CODES : NX58F5500SS
NX58F5500SB
NX58F5500SW
NX58F5300SS
VERSION : VER.00, VER.01

2
• Contents
1. Precaution ..............................................................................3
1-1 Forward 3
1-2 Safety Precautions 3
1-3 Important Safety Instructions 4
1-4 Model and Serial Number Label and Tech Sheet Locations                                     6
2. Specications ...........................................................................7
2-1 Features 7
2-2 Table of Specications 8
2-3 Accessories 10
3. Disassembly and Reassembly .............................................................11
3-1 Tool for assembly and disassembly 11
3-2 Removing the Rear Cover Panels 12
3-3 Removing the Assy-Frame Cooktop 14
3-4 Removing the Chassis Manifold Panel, Knob, Switch Ignition                                  15
3-5 Removing the Valve Cooktop 16
3-6 Replacing the Burner Cup 17
3-7 Replacing the Assy Door Latch 19
3-8 Replacing the Switch-Door Plunger 20
3-9 Replacing the Assy Lamp Bulb 21
3-10 Replacing the Sensor-Thermistor 22
3-11 Replacing the Gasket Door 23
3-12 Removing and Replacing the Door 24
3-13 Replacing the Handle-Door 25
3-14 Replacing the Glass-Inner 26
3-15 Replacing the Storage drawer 27
3-16 Replacing the Burner Broil 28
3-17 Replacing the HOT SURFACE IGNITOR (HSI) of the BURNER BROIL, NOZZLE Broil-Burner, and HOLDER
Broil-BURNER 29
3-18 Replacing the Burner Bake 30
3-19 Replacing the HOT SURFACE IGNITOR (HSI) of the BURNER BAKE, NOZZLE BAKE-BURNER, and
HOLDER BAKE-BURNER 31
3-20 Replacing the Assy Valve Safety 32
3-20 Replacing the Assy Valve Safety 33
3-21 Replacing the Assy Power cord 34
4. Troubleshooting ........................................................................35
4-1 Failure Display Codes 35
4-2 Cooktop Malfunction 48
4-3 Oven Malfunction 54
4-4 Control Malfunction 60
5. Wiring Diagram .........................................................................63
5-1 Wiring Diagram 63
5-1 Wiring Diagram 64

3
• Contents
6. Schematic Diagram ......................................................................65
6-1 Schematic Diagram NX58F5500SS, NX58F5500SB, NX58F5500SW, NX58F5300SS               65
7. PCB Diagrams ..........................................................................66
7-1 PCB Diagram
FX510BGS / NX583G0VBSR / NX58F5500SS / NX58F5500SB / NX58F5500SW /
NX58F5300SS (Main)    66

3
This document can not be used without Samsung’s authorization.
1. Precaution
1-1 Forward
This SAMSUNG Service Manual, “Freestanding Gas Ranges,” provides the technician with information on the
operation and service of freestanding self-cleaning gas ranges It is to be used as a training service manual For
specic information on the model being serviced, refer to the user manual or tech sheet provided with the gas
range
1-2 Safety Precautions
• Repairs of the appliance should be carried out by a licensed technician only Incorrect repairs may result in
dangerous situations If you need repairs, contact an SAMSUNG Service Center or your dealer
• If the power cord is defective, it must be replaced by a licensed technician with a UL-listed range cord
• If the gas supply is damaged or defective, it must be replaced by a licensed technician or gas supplier
• Electrical leads and cables should not be allowed to touch the oven
• Rating plate is located on the left side of the opening for the warming drawer or storage drawer
• The gas and electrical supplies to the appliance should be turned off and/or disconnected when the range is
being serviced or repaired
WARNING
• To avoid risk of death or severe personal injury from electrical shock, disconnect power before working
on/servicing the appliance
• To avoid risk of death, severe personal injury, or property damage from re or explosion, turn off the gas
supply before working on/servicing the appliance IF YOU SMELL GAS:
1 DO NOT light a match, candle, or cigarette
2 DO NOT turn on any gas or electric appliances
3 DO NOT touch any electrical switches
4 DO NOT use any type of phone in the building
5 Clear the room, building, or area of all occupants
6 Immediately call the gas supplier from a phone outside of the building Follow the gas supplier’s
instructions
7 If you cannot reach the gas supplier, call the re department
• To avoid risk of death, severe personal injury, or property damage from re or explosion, do not wear loose-tting,
or hanging garments near an open ame during operation and/or servicing the appliance
• When the oven operates, the interior parts will be very hot
SAMSUNG Electronics assumes no responsibility for any repairs made on our products by anyone other than
licensed technicians

4
1. Precautions
This document can not be used without Samsung’s authorization.
WARNING
Tip-Over Hazard
A child or adult can tip the range and be killed
Install anti-tip device to range and/or structure per
installation instructions
Engage the range to the anti-tip device installed to the
structure
Re-engage anti-tip device if range is moved
Failure to follow these instructions can result in death or
serious burns to children or adults
1-3 Important Safety Instructions
Read and follow all instructions before using or servicing the range to prevent death, personal injury, re,
explosion, and/or property damage This guide does not cover every possible condition that may occur For
further assistance, contact a licensed technician or the manufacturer
All electrical and gas equipment and their moving parts can be dangerous Please read the important safety
information on the appliance and in this manual The information must be followed to minimize the risk of death,
personal injury, and/or property damage
To reduce the risk of tipping the range, the range must
be secured by a properly installed anti-tip device To
check if the bracket is installed properly:
- Warming drawer: Grasp the top rear edge of the
range and carefully attempt to tilt it forward
Verify that the anti-tip device is engaged
- Storage drawer: Remove drawer and verify leveling
leg is inserted into and fully secured by the anti-tip
device
Refer to the installation manual for proper anti-tip
bracket installation
• Do not step, lean, or sit on the doors of the range
This can cause the range to tip, resulting in burns or
serious injuries
WARNING
• DO NOT TOUCH SURFACE BURNERS, SURFACE
BURNER GRATES, OVEN BURNERS, INTERIOR
SURFACES OF OVEN, OR WARMING DRAWER
HEATING ELEMENT – Burners, heating element, and
surfaces may be hot even though they are dark in
color Interior surfaces of an oven become hot enough
to cause burns During and after use, do not touch
or let clothing or other ammable materials contact
burners, heating element, grates, or interior surfaces of
oven until they have had sufcient time to cool Other
surfaces of the appliance may become hot enough
to cause burns Among these surfaces are oven vent
openings and surfaces near these openings, oven
doors, and windows of oven doors
This is the safety alert symbol It alerts you of
potential hazards that can kill or injure you or
others The following safety messages explain the
potential hazards:
DANGER
Hazardous situation that will result in death and/
or serious personal injury
WARNING
Hazardous situation that could result in death,
serious personal injury, and/or property damage
CAUTION
Hazardous situation that may result in moderate
personal injury, and/or property damage
• Be sure your appliance is properly installed and grounded
by a licensed technician
• Do not repair or replace any part of the appliance unless
specically recommended in the manual All other
servicing should be referred to a licensed technician
• Always disconnect power to the appliance before
servicing by turning off the circuit breaker or removing
the fuse
• Always turn off the main gas supply to this appliance
before servicing by closing the gas supply valve to this
appliance
• Always check gas ttings and components for leaks
before servicing the appliance If a leak is detected, shut
off the gas supply and notify a licensed technician and/or
gas supplier

5
1. Precautions
This document can not be used without Samsung’s authorization.
WARNING
To avoid risk of death or personal injury from
electrical shock, make sure your range has been
properly grounded and always disconnect it from
the main power supply before any servicing
• Do Not Leave Children Alone – Children should not be
left alone or unattended in area where appliance is in
use They should never be allowed to sit or stand on any
part of the appliance
•
Never Use Your Appliance for Warming or Heating the Room
• Storage in or on Appliance – Flammable materials should
not be stored in an oven or near surface units Be sure all
packing materials are removed from the appliance before
operating it Keep plastics, clothes, and paper away from
parts of the appliance that may become hot
• Wear Proper Apparel – Loose-tting or hanging garments
should never be worn while using the appliance
• Do Not Use Water on Grease Fires – Turn off oven to
avoid spreading the ame Smother the re or ame by
closing the door or using baking soda or a dry-chemical
or foam-type extinguisher
• Use Only Dry Pot Holders – Moist or damp pot holders
on hot surfaces may result in burns from steam Do not
let pot holder touch hot heating elements Do not use a
towel or other bulky cloth
WARNING
SURFACES
• DO NOT TOUCH SURFACE BURNERS OR
AREAS NEAR BURNERS – Surface burners may
still be hot after they have been turned off Areas
near surface burners may become hot enough to
cause burns During and after use, do not touch or
let clothing or other ammable materials contact
surface burners or areas near burners until they
have had sufcient time to cool Among these
areas are the cooktop, surface burner grates, and
surfaces close to the cooktop
CAUTION
Do not store items of interest to children in
cabinets above a range or on the backguard of
a range – Children climbing on the range to reach
items could be seriously injured
SURFACE BURNERS
• Use Proper Pan Size – This appliance is equipped
with one or more surface burners of different sizes
Select utensils having at bottoms large enough
to cover the surface burner ames The use of
undersized utensils will expose a portion of the
surface burner ames to direct contact and may
result in ignition of clothing Proper relationship of
utensil to burner will also improve efciency
• Never Leave Surface Burners Unattended at High
Heat Settings – Boilovers could ignite or extinguish
the burner ames Both conditions create an
explosion and/or re hazard
•
Protective Liners – Do not use aluminum foil to line
cooktop surface or oven bottoms, except as suggested
in the manual Improper installation of these liners may
result in a risk of electric shock, re, or burner damage
• Glazed Cooking Utensils – Only certain types of
glass, glass/ceramic, ceramic, earthenware, or other
glazed utensils are suitable for range-top service
without breaking due to the sudden change in
temperature
• Utensil Handles Should Be Turned Inward and
Not Extend Over Adjacent Surface Burners –
To reduce the risk of burns, ignition of ammable
materials, and spillage due to unintentional contact
with the utensil, the handle of a utensil should be
positioned so that it is turned inward and does not
extend over adjacent surface burners
• Surface Burner Components – The burners,
burner caps, and burner cups should always be
cleaned by hand They are not dishwasher-safe The
orices should always be checked for dirt and debris
whenever the burner cups are cleaned
• Be sure you know which control knob operates each
surface burner Make sure you turned on the correct
surface burner
C OOKTOP COOKING SURFACES
• Clean Cooktop With Caution – If a wet sponge or
cloth is used to wipe spills on a hot cooking area,
be careful to avoid steam burn Some cleaners can
produce noxious fumes if applied to a hot surface
• Clean cooktop surface with nonabrasive cleaner on
painted metal surfaces
VENTILATING HOODS:
• Clean Ventilating Hoods Frequently – Grease
should not be allowed to accumulate on hood or lter
•
When aming foods under the hood, turn the fan on.
DEEP-FAT FRYERS:
• Use extreme caution when moving the grease kettle
or disposing of hot grease

6
1. Precautions
This document can not be used without Samsung’s authorization.
1-4 Model and Serial Number Label and Tech Sheet Locations
These models have Model/Serial Number labels and Tech Sheets located as shown below
SELF-CLEAN OVENS
• Do Not Clean Door Gasket – The door gasket is
essential for a good seal Care should be taken not to
rub, damage, or move the gasket
• Do Not Use Oven Cleaners – No commercial oven
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven
•
Never keep pet birds in the kitchen – The health
of birds is extremely sensitive to the fumes released
during an oven self-clean cycle Fumes may be
harmful or fatal to birds Move birds to a well-ventilated
room
• Important Instruction – In the event the self-clean
mode “F” code goes on or three long beeps sound,
the oven is malfunctioning in the self-clean mode
Turn off or disconnect appliance from electrical and
gas supplies and have the appliance serviced by a
licensed technician
• Use Care When Opening Door – Let hot air or
steam escape before you remove or replace food in
the oven
• Do Not Heat Unopened Food Containers –
Buildup of pressure may cause container to burst and
result in injury
• Keep Oven Vent Ducts Unobstructed – The oven
vent is located above the left-rear surface unit This
area could become hot during oven use Never block
this vent and never place plastic or heat-sensitive
items on vent
• Placement of Oven Racks – Always place oven
racks in desired location while oven is cool If rack
must be moved while oven is hot, do not let pot
holder contact a hot oven burner or oven bottom
CAUTION
• BEFORE CLEANING, REMOVE BROILER PAN,
OVEN RACKS, AND UTENSILS
• WIPE EXCESS SPILLS FROM OVEN INTERIOR
• SEE USER INSTRUCTIONS
Model & Serial
Number Location
Model and Serial
Number Location
Tech Sheet
Location

7
This document can not be used without Samsung’s authorization.
2. Specications
2-1 Features
Features
Five Open-Port Surface Burners
- Simplest design promotes
serviceability and cleanability
BTU Ratings
NX58F5500XX NG LP
Right Front 17,000 12,500
Right Rear 5,000 4,000
Center Oval 9,500 7,500
Left Rear 9,500 7,500
Left Front 12,000 10,000
NX58F5300SS NG LP
Right Front 16,000 12,500
Right Rear 5,000 4,000
Center Round 9,500 7,500
Left Rear 9,500 7,500
Left Front 12,000 10,000
Membrane Control Panel and Digital Display
- All oven features and functions are controlled and
monitored by this easy-to-use control panel
Full-Width, Heavy-Duty Grates
- 3-piece grates t into cooktop Opening
and completely cover the cooktop from
edge to edge to enhance usability
Surface Burner Control Knobs
- Front-top location provides easy access to
enhance usability and safety
Large Capacity Oven
- Provides cooking ease and necessary
space for all recipes and meal items
BTU Ratings
ALL MODELS- NG LP
Broil Burner
(Upper) 13,500 11,500
Bake Burner
(Lower) 18,000 15,000
Storage Drawer
- Convenient, front-access drawer
for storage of cooking utensils
Semi-rapid burner [Left-Rear]
- NG : 9,500 BTU
- LP : 7,500 BTU
Auxiliary burner [Right-Rear]
- NG : 5,000 BTU
- LP : 4,000 BTU
Rapid burner [Left-Front]
- NG : 12,000 BTU
- LP : 10,000 BTU
Center Round [NX58F5300SS]
- NG : 9,500 BTU
- LP : 7,500 BTU
Power burner [Right-Front]
- NG : 17,000 BTU
- LP : 12,500 BTU
Center Oval [NX58F5500XX]
- NG : 9,500 BTU
- LP : 7,500 BTU

8
2. Specications
This document can not be used without Samsung’s authorization.
9
2. Specications
This document can not be used without Samsung’s authorization.
2-2 Table of Specications
Items BASIC MODEL NEW MODEL
NX583G0VBSR NX58F5500SS NX58F5500SB NX58F5500SW NX58F5300SS
Range Type Freestanding Gas Freestanding Gas
Range Color Black and Stainless Steel Black and Stainless Steel Black White Black and Stainless Steel
Overall
Dimensions
Width 30 in. (76.2cm) 30 in. (76.2cm)
Height 45.8 in . (116.2cm) 45.8 in . (116.2cm)
Depth 23.7 in. (60.2cm) 23.7 in. (60.2cm)
Controls
Cooktop Front-Top Control Knobs Front-Top Control Knobs
Oven SoftTouch SoftTouch
Display 2-Color LED 1-Color LED
Digital Electronic Clock Yes Yes
Electronic Door Lock Yes Yes
Audible Preheat Signal Yes Yes
Cooktop
Surface Burner Type Open-Port Open-Port
# of Surface Burners 5 5
Burner Ratings – BTUs NG LP
17,000 12,500
5,000 4,000
12,000 10,000
9,500 7,500
9,500 7,500
NG LP NG LP
17,000 12,500 16,000 12,500
5,000 4,000 5,000 4,000
12,000 10,000 12,000 10,000
9,500 7,500 9,500 7,500
9,500 7,500 9,500 7,500
Right Front
Right Rear
Left Front
Left Rear
Center
Oven
Capacity 5.8 cu.ft
5.8 cu.ft
# of Oven Burners 2 2
Upper Burner Rating - BTUs NG LP
13,500 11,500
18,000 15,000
NG LP
13,500 11,500
18,000 15,000
Lower Burner Rating - BTUs
Convection Fan System
Yes NO
# of Racks 2 2
Oven Light Yes Yes
Self-Cleaning Yes Yes
Interior Oven
Dimensions
(Width x Height x Depth)
25 x 21.125 x 19 in
(635 x 536 x 481)
25 x 21.125 x 19 in
(635 x 536 x 481)
Drawer
Type Storage Storage
Electric Warming Element No No
Range Weight, Net 187 Lbs (85Kg) 187 Lbs. (85Kg)
Required Electrical Supply
120-V, 60-Hz, 15- or 20-amp AC 120-V, 60-Hz, 15- or 20-amp AC
Required Gas
Supply
Natural Gas (NG) 5–13 in. WC 5–13 in. WC
Liquid Propane (LP) 10-13 in. WC 10-13 in. WC

10
2. Specications
This document can not be used without Samsung’s authorization.
2-3 Accessories
Item Description Code No. Quantity
Assy-Grate Side DG94-00468B 2
Assy-Grate Center DG94-00469B 1
Rack-Flat DG75-01001C 2
Plate Griddle DG61-00563A 1
The griddle is only provided for the NX58F5500SS, NX58F5500SB, NX58F5500SW model

11
This document can not be used without Samsung’s authorization.
3. Disassembly and Reassembly
3-1 Tool for assembly and disassembly
Item How to use Pictures
Screw driver Use for assembly and disassembly of all
screws
Tubing Wrench Use for assembly and disassembly of tubing to
the burner cup
7mm Vox Driver Use for assembly and disassembly of injector
nozzles [Cooktop / Broil / Bake burner]

12
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-2 Removing the Rear Cover Panels
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal
injury from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Cover-Wire LT/
RT
Cover-Wire LT Cover-Wire RT
1. Turn off the electrical supply
going to the range
2. Shut off the gas shut-off valve
in the gas supply line to the
range
3. Pull the range away from the
wall so that you can access the
rear panel
4. Remove 2 screws at the Cover
Wire LT/RT and pull out the
cover
Cover-Back
Guard Wire
Cover-Back Guard Wire
5. Remove 2screws at the cover
and pull out the cover from the
upper back of the range
Cover-
Convection
Cover-Convection
6. Remove 3screws at the cover
and pull out the cover from the
range

13
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-2 Removing the Rear Cover Panels (cont.)
Parts Explanation Photo Explanation
Cover-Back Main
Wire
7. Remove 9 screws and pull out
the cover from the middle back
of the range
PCB Assembly &
Spark Module
PCB assembly Spark Module
8. Remove screws of PCB
assembly and separate PCB
assembly (When you check
PCB, check the proper PCB in
default mode and check main
PCB)
9. Disconnect the wires to the
spark module to remove it
10. Remove 2 screws and the
spark module from the back of
the range
11. Disconnect the wire connectors
from the terminal on the spark
module
12. When service is complete,
replace the ve cover panels
on the back of the range
and secure each with the
appropriate screws.
13. Replace the PCB ASSEMBLY
and the spark module
14. Reconnect the gas supply line
to the range, if removed Open
the main gas shut-off valve and
check for gas leaks
15. Plug in the range and/or turn
on the electrical supply to the
range
16. Push the range back in place,
making sure to engage the
anti-tip bracket on the left-rear
leveling leg

14
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-3 Removing the Assy-Frame Cooktop
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal injury
from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Assy-Frame
Cooktop
ASSY GRATE
(2 SIDE / 1 CENTER)
BURNER CAP
BURNER HEAD
BURNER CUP
1. Turn off the electrical supply
going to the range
2. Shut off the gas shut-off valve
in the gas supply line to the
range
3. Lift off the three grates
4. Lift off the 5 burner caps and
the 5 burner heads from the
burner cups
5. Remove screws of the 5 burner
cups
Assy-Frame
Cooktop SPRING
COOKTOP
CHASSIS
MANIFOLD PANEL
FRAME
COOKTOP
ELECTRODE
6. Push the 2 spring located
between the frame cooktop and
the chassis manifold panel with
a thin iron plate
Knobs should be removed prior
to disassembling the cooktop
frame and take notice that
Chassis-Manifold Panel is not
damaged during the operation
7. Push the cups down below the
surface of the frame cooktop
NOTE: Make sure the electrodes
are below openings in the
cooktop to prevent interference
and damage during removal

15
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-4 Removing the Chassis Manifold Panel, Knob, Switch Ignition
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal
injury from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Knob
Pull the control knob straight off
1. Turn off the electrical supply
going to the range
2. Shut off the gas shut-off valve
in the gas supply line to the
range
3. Open the door or Remove it
4. Pull burner control knobs
straight off to remove them
from the valve shafts
Chassis Manifold
Panel
Screws from the bottom
5. Remove 2 screws from the top,
2 screws from the front and 4
screws from the bottom of the
chassis manifold panel
6. Remove the chassis manifold
panel from the front of the
range
Switch Ignition
Switch ignition
Connector
7. Place a nger behind each side
of the switch ignition and pull
it straight out to release it from
the control shaft Repeat for
each switch
8. Disconnect the wires at the
connectors

16
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-5 Removing the Valve Cooktop
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal
injury from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Switch
Ignition
SWITCH IGNITION
1. Turn off the electrical supply going
to the range
2. Shut off the gas shut-off valve in
the gas supply line to the range
3. Remove the ASSY FRAME
COOKTOP, knob and the chassis
manifold panel
4. Place a nger behind each side
of the switch ignition and pull it
straight out to release it from the
control shaft Repeat for each
switch
Fitting (Gas
line)
FITTING (GAS LINE)
5. Using a tubing wrench and a
channel-lock wrench, disconnect
the gas lines from the valve
cooktop Do not bend or crimp gas
lines during removal
Valve
Cooktop
ASSY VALVE-MANIFOLD
COATING
6. Remove 2 screws from ASSY
VALVE-MANIFOLD COATING
Note : When assembling and
disassembling the valve, the
torque should be 15Nm
7. Remove the valve cooktop

17
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-6 Replacing the Burner Cup
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal
injury from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Locking Clip
& Electrode
LOCKING CLIP ELECTRODE
BURNER CUP
TUBE
Injector
1. Turn off the electrical supply going
to the range
2. Shut off the gas shut-off valve in
the gas supply line to the range
3. Remove the frame cooktop
4. Using a tubing wrench on the
gas line tting and a channel lock
wrench on the burner cup base,
rmly hold the cup base in place
while disconnecting the gas line
5. To remove the electrode from
the cup, squeeze the two outside
edges of the clip under the
electrode together while pulling to
remove the locking clip Slide the
electrode and the wire from the
cup The burner cup can now be
removed

18
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
Parts Explanation Photo Explanation
Burner cup
WIRE HOUSING
6. To replace the electrode,
disconnect the wire connectors
from the terminal on the spark
module
7. To remove the gas orice, place
the burner cup in a vise and
remove the orice with a 9/32-inch
socket wrench
8. When service is complete, Install
the gas orice in the new burner
cup
NOTE: The new burner cup must
be the same size as the one
removed
9. Reconnect the electrode to the
new burner cup and replace the
burner cup in the reverse order
3-6 Replacing the Burner Cup (cont.)

19
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-7 Replacing the Assy Door Latch
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal
injury from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Assy Tube-
Manifold
ASSY BRACKET-B URNER BOX
1. Turn off the electrical supply going to
the range
2. Shut off the gas shut-off valve in the
gas supply line to the range
3. Remove the oven door and the
cooktop
4. Remove the control knob and the
chassis manifold panel
5. Remove the ASSY tube-manifold using
a tubing wrench
Assy Door
Latch
ASSY Door Latch
Bracket-Latch sub
6. Remove 2 screws from the Bracket-
Latch sub to the rear of the range
7. Disconnect wires of the door latch to
the rear of the range and remove it
8. Remove 2 screws holding the Assy
bracket-latch rear to the rear of the
range
9. Remove the latch-rod from the Assy
bracket-latch front
10. Remove 2 screws holding the Assy
bracket-latch front to the front of cavity
11. Reverse the order to install the ASSY
DOOR LATCH
12. Test the ASSY DOOR LATCH to
make sure it is latching and unlatching
properly

20
3. Disassembly and Reassembly
This document can not be used without Samsung’s authorization.
3-8 Replacing the Switch-Door Plunger
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing the range Replace all panels before operating range Failure to do so
can result in death or electrical shock
WARNING
EXPLOSION, FIRE, AND ASPHYXIATION HAZARD
Shut off gas supply to the range before servicing Check all gas lines and ttings for leaks before operating
the range Replace all panels before operating range Failure to do so can result in death or personal
injury from explosion, re, or asphyxiation
CAUTION
When you work on the gas range, be careful when handling sheet metal parts Sharp edges may be
present, and you can cut yourself if you are not careful
Parts Explanation Photo Explanation
Switch-Door
Plunger
SWITHCH-DOOR PLUNGER
1. Turn off the electrical supply going
to the range
2. Shut off the gas shut-off valve in
the gas supply line to the range
3. Open the oven door
4. Carefully pull out the switch door
plunger switch from the upper left
corner of the cavity front Gently
grasp the plunger with pliers
and work from side to side while
pulling Pull out far enough to
expose the wires
5. Note the location and mark the
wires; then disconnect the wire to
the switch door plunger
6. Replace with the switch-door
plunger, reconnect the wires
in their original positions, and
reinstall switch in the oven frame
