Samsung SW90P9 User manual

Fully Automatic
Washing Machine
user manual
imagine the possibilities
Thank you for purchasing this Samsung
product. To receive more complete service,
please register your product at
www.samsung.com/register
WA15P9
WA14P9
SW90P9
This manual is made with 100% recycled paper.
Code No. DC68-02561E-02_EN
WA14P9PIC-02561E-02_EN.indd 1 2013-01-15 �� 11:48:15

2_ features
features of your new washer
1. Air Turbo Drying System
Air Turbo technology spins hard and fast so you can spend less time drying.
Time Saving AIR TURBO saves your time, ensuring your clothes are dried 30%-40% faster
than line drying alone. Especially during the rainy season and in high-humid weather, laundry
that once took days to drip-dry, such as heavy jeans, bulky sweaters, and thick blankets are
dried more rapidly.
Easy-to-iron AIR TURBO is perfect for delicates and clothes made of synthetic fabrics.
No more hanging and waiting. Simply iron straight-out-of-the washer, since AIR TURBO
eliminates just enough moisture to keep clothes adequately damp for ironing.
2. Diamond Drum
The diamond shaped drum creates a high water pressure, removing dirt from the laundry
effectively. The diamond drum minimizes fabric damage extending the lifetime of the fabric.
The glittering inner tube is both beautiful and powerful in the wash effect it creates.
3. Tempered Transparent Door
Lets you observe while the washer is operating. Check on your laundry’s progress at any
time.
4. Digital Control
The digital control selects the optimal washing course by automatically sensing the washload
using artificial intelligence.
5. Magic Filter
The unique Magic Filter ensures that any and all lint inside the tub is captured for top quality
filtering results that deliver a consistent and effective cleaning result.
6. Auto Restart
The power is turned on automatically after a power failure and simply continues the previous
cycle. This saves time and ensures your wash is completed every time without fail.
7. Child-Lock Function
The Child-Lock function protects children from accidentally being hurt while playing with the
washer.
8. Energy Saving
With this course, you can save energy when using your washing machine. The wash
performance and damage test are recognized by registered institutions.
This manual contains important information on the installation, use, and care of your new
Samsung washer. Refer to it for descriptions of the control panel, instructions on how to use
the washer, and tips for making the most of its state-of-the-art features and functions. The
‘Troubleshooting and information codes’ section on page 26 tells you what to do if something
goes wrong with your new washer.
WA14P9PIC-02561E-02_EN.indd 2 2013-01-15 �� 11:48:15

safety information _3
safety information
Throughout this manual, you’ll see Warning and Caution notes. These
warnings, cautions, and the important safety instructions that follow do not cover
all possible conditions and situations that may occur. It’s your responsibility to use
common sense, caution, and care when installing, maintaining, and operating your
washer. Samsung is not liable for damages resulting from improper use.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
What the icons and signs in this user manual means:
WARNING
Hazards or unsafe practices that may result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when
using your washer, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
Read all instructions before using the appliance.
As with all any equipment using electricity and moving parts, potential hazards exist. To
safely operate this appliance, become familiar with its operation and exercise care when
using it.
Install and store your washer inside, away from exposure to weather.
Install and level your washer on a floor that can support its weight.
Your washer must be properly grounded. Never plug it into an ungrounded outlet.
Position the washer so that a wall plug is accessible after the installation is completed.
WA14P9PIC-02561E-02_EN.indd 3 2013-01-15 �� 11:48:15

4_ safety information
To reduce the risk of fire or explosion:
• Do not wash items that have been washed, soaked, or treated with gasoline, dry
cleaning solvents, or other flammable or explosive substances. They give off vapors that
could ignite or explode. Rinse by hand any material that has been exposed to cleaning
solvent or other flammable liquids or solids before putting in your washer. Be sure that
all traces of such liquids, solids, and fumes have been removed. Dangerous substances
include acetone, denatured alcohol, gasoline, kerosene, certain liquid household
cleaners and spot removers, turpentine, waxes, and wax removers.
• Do not put gasoline, dry cleaning solvents, or other flammable or explosive substances
into the washer.
• Under certain conditions, hydrogen gas may be produced in a hot water system – such
as your hot water heater - that has not been used for two weeks or more. HYDROGEN
GAS IS EXPLOSIVE. If your hot water system has not been used for two weeks or
more, turn on all hot water faucets in your home, and let the water flow for several
minutes before using your washer. This will release any hydrogen gas build–up. Since
hydrogen gas is flammable, do not smoke or light an open flame during this time.
Ventilate immediately without touching the power plug if there is a gas leak.
Unplug the power cord before servicing your washer.
Do not reach into the appliance when the tumbler is moving.
Do not reach under the appliance with your hands or with an object as you may be injured
by the spinning board beneath the washer.
Do not let children play on or in your washer. The washer door does not open easily from
the inside, and children may be seriously injured if trapped inside.
Do not let children attempt to look into the washer as falling into the washer is extremely
dangerous and may be fatal.
This appliance is not intended for use by young children or infirm persons unless they
have been adequately supervised by a responsible person to ensure that they can use the
appliance safely. Young children should be supervised to ensure that they do not play with
the appliance.
Do not repair, replace, or service any part of your washer yourself unless you fully
understand the recommended user–repair instructions and have the skills to carry them
out. Work done by an unauthorized person may void your warranty.
Store laundry detergents and other laundry supplies in a cool, dry place out of children’s
reach.
Disconnect the hoses and turn off the water when not using the washer.
If the power cord is damaged, it must be replaced by the manufacturer, a service agent or
similarly qualified person in order to avoid a hazard.
Do not forcefully bend the power cable or place any heavy objects on the cable.
Do not touch the power cord with wet hands.
Do not overload the power outlet with too many appliances.
safety information
CAUTION
WARNING
WARNING
WARNING
WA14P9PIC-02561E-02_EN.indd 4 2013-01-15 �� 11:48:15

safety information _5
Do not install the washer nearby electrical implements and do not place any candles or
cigarettes on the washer.
Do not go near the washer if it is flooded or under water, as there is a risk of electric shock.
Unplug the washer and drain the water completely.
Do not combine chlorine bleach, ammonia, or acids (such as vinegar or rust remover)
in the same wash. The fumes that can form when any of these items are combined are
hazardous.
Do not machine wash fiberglass materials. Small particles can stick to fabrics washed in
subsequent loads and cause skin irritation.
Before disposing of your washer, remove the door so that children or small animals cannot
get trapped inside.
Connect the washer to the main water supply using a new set of hoses. Do not reuse an
old set of hoses.
Water inlet hoses deteriorate over time. Check the hoses periodically for bulges, kinks, cuts,
wear, and leaks, and replace them as needed and at least every five years.
Before each wash, empty the pockets of your laundry. Small, irregularly shaped hard
objects, such as coins, knives, pins, and paperclips could damage your washer. Do not
wash clothing with large buckles, buttons, or other heavy metal objects.
If the washer does not stop within 15 seconds after you open the lid, call a service agent
immediately.
Connect the grounding wire to the shell plate, and bury it under at least 10 in (25 cm) of
earth: Alternatively, connect the ground wire to the appropriate pin on a properly grounded
power receptacle. Never connect the wire to a telephone line, lightning rod, or gas pipe.
For washers with ventilation openings in the base, that a carpet must not obstruct the
openings.
The product you have purchased is designed for domestic use only.
The use for business purposes qualifies as product misuse. In this case, the product will not
be covered by the standard warranty provided by Samsung and no responsibility can be
attributed to Samsung for malfunctions or damages resulting from such misuse.
The washing machine shall not be installed at a humid place.
WARNING
CAUTION
CAUTION
WA14P9PIC-02561E-02_EN.indd 5 2013-01-15 �� 11:48:15

6_ contents
contents
SETTING UP YOUR WASHER
7
7 Checking the parts and the control panel
9 Fuzzy course
9 Blanket course
10 Delicate course
10 Memory course
10 Clean Tub course
11 Quick course
11 Super Clean
11 Energy Saving program (SW90P9 Only)
11 ECO+ course (WA15P9,WA14P9 Only)
12 Delay Start
12 Air Turbo
13 Manual functions
14 Installing your washer
14 Selecting a location
14 Connecting the water supply hose
15 Assembling the Protection Panel (Optional)
15 Connecting the drain hose
17 Adjusting the height of the washer
WASHING A LOAD OF LAUNDRY
18
18 Basic instructions
18 Laundry guidelines
20 Detergent and additives information
21 Washing for the first time
21 Automatic sensing function
CLEANING AND MAINTAINING YOUR
WASHER
22
22 Keeping the tub clean
22 Cleaning the water supply connector filter
23 Cleaning the filter net
23 Cleaning the pump filter
TROUBLESHOOTING AND
INFORMATION CODES
24
24 Check these points if your washer...
26 Information codes
SPECIFICATION
27
WA14P9PIC-02561E-02_EN.indd 6 2013-01-15 �� 11:48:15

setting up your washer _7
setting up your washer
Be sure to have your installer follow these instructions closely so that your new
washer works properly and so that you’re not at risk of injury when doing laundry.
CHECKING THE PARTS AND THE CONTROL PANEL
Carefully unpack your washer, and make sure you’ve received all the parts shown below. If your washer was
damaged during shipping, or if you do not have all the parts, contact Samsung Customer Service or your
Samsung dealer.
01 SETTING UP YOUR WASHER
Water supply hose (Hot)
(Optional)
Water supply hose (Cold)
Drain hose (Pump) (Optional)
Detergent dispenser
Spin basket (Optional)
Power cord
Ground wire (Optional)
When the water pipe is
metal, make sure to cover
the end of the ground wire.
Water drain hose
(Optional)
Protection panel
(Optional)
Front control panel
Pulsator
Adjustable legs
Adjust the length
of the legs when
installing the washer.
Lid
Be sure to keep the lid closed
during washing and spinning.
Lint will be collected in the filter
during washing.
Filter
WA14P9PIC-02561E-02_EN.indd 7 2013-01-15 �� 11:48:16

8_ setting up your washer
POWER BUTTON Press this button once to turn the power on.
Press it again to turn the power off.
START/PAUSE
BUTTON
Press to pause and restart courses.
To change the washing procedure during an operation, press this button to
stop the operation, and press it again to restart the washer after changing
the washing procedure.
COURSE
SELECTION
BUTTON
Press this button repeatedly to cycle through the washing courses:
[Fuzzy  Blanket  Delicate  Memory  Clean Tub  Quick  Super
Clean  ECO +, Energy Saving]
RINSE BUTTON Press this button to perform only the rinse cycle or to adjust the amount of
rinse cycles.
SPIN BUTTON
Press this button to only perform a spin cycle or to adjust the spin time.
When only a spin cycle is selected, the spin time will be different from the
total remaining time. This is because the total remaining time includes the
actual spin time, the time for the water to drain and the washer to stop.
CHILD-LOCK
FUNCTION
The child lock function allows you to lock the buttons so that the selected
wash cycle can’t be changed. (This is a device that prevents children from
playing with the washer.)
Activating/Deactivating: Press both the Rinse and Spin buttons at the
same time for 3 seconds. (Note: This function cannot be performed without
the “Power” being on.)
WASH BUTTON Press this button to only perform a wash cycle or to adjust the wash time.
REMAINING TIME,
DELAY START
TIME, ERROR
DISPLAY
The display shows the remaining wash time, the reserved delayed start
time and error messages.
setting up your washer
6
5
4
3
2
1
7
8
9 8 7 6 5 4 3 2 110111213
WA14P9PIC-02561E-02_EN.indd 8 2013-01-15 �� 11:48:16

setting up your washer _9
AIR-TURBO
BUTTON
Press this button to fast-dry your laundry.
Press this button to toggle between the Air-Turbo options:
On  Off  On
This function can only be selected if a spin cycle has been set.
DELAY START
BUTTON
Press this button to finish the wash at a specified time. Turn your washer off
to cancel a previously delayed start time.
You can set the delayed start time from between 3 to 18 hours.
SOAK BUTTON
Press this button to add the soak time.
This is available as for all courses except for the Delicate and Clean Tub
courses.
The Soak function is automatically set for the Clean Tub course.
Press this button repeatedly to cycle through the soak time:
30 min.  15 min.  Off  30 min.
WATER LEVEL
BUTTON
The water level is automatically adjusted. However, you can select the
water level manually by repeatedly pressing this button.
WATER SUPPLY
BUTTON (Optional)
Press this button repeatedly to cycle through the water options:
Cold  Cold & Hot  Hot  Cold
To change the water options, turn off the Silver Water function.
Fuzzy course
Use this course to automatically select the optimal washing course.
1. Press the Power button to turn the washer “On”.
2. Press the Start/Pause button. The water level is selected automatically.
3. The wash, rinse, and spin cycles follow.
4. To pause a course, press the Start/Pause button again. You can change the course when it
is paused.
5. Close the lid.
Blanket course
Use this course for big volume laundry items such as blankets and bed cover sheets.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Pasue button. The water level is
selected automatically.
4. The wash, rinse, and spin cycles follow.
5. To pause a course, press the Start/Pause button
again. You can change the course when it is
paused.
6. Close the lid.
• Do not wash electric blankets and carpets.
• Fold big volume laundry items (blankets and bed cover sheets) in the following way
before adding them into the spin basket.
• Purchase a laundry net for light and big volume laundry items (e.g. cashmere, blankets)
as they may rise to the top of the washer and become damaged.
01 SETTING UP YOUR WASHER
9
10
11
12
13
WA14P9PIC-02561E-02_EN.indd 9 2013-01-15 �� 11:48:16

10_ setting up your washer
Delicate course
Use this course to wash delicate clothing items such as washable sweaters, cardigans, and
other delicate items.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Pause button. The water level is automatically selected at the mid-level
between Mid-low and Extra low. You can also adjust the water level manually.
4. The wash, rinse, and spin cycles follow.
5. To pause a course, press the Start/Pause button again. You can change the course when it
is paused.
6. Close the lid.
• You can select only Cold water.
• The last spin cycle is a light cycle to prevent wrinkles.
• Use only detergent indicated by the laundry.
• Refer to the Care Label on the clothing for the appropriate wash information.
• Make sure buttons are fastened and that clothing is turned inside out.
• In the Delicate course, Air Turbo and Silver Wash functions cannot be selected as it may
damage delicate items.
Memory course
Use this course to create your very own favorite or frequently used courses and store them in the
washer so that you can select them at any time.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Select your frequently used functions.
Select Wash, Rinse, Spin or Silver Wash according to your requirements.
4. Press the Start/Pause button to store them.
Only stored when the Wash + Rinse + Spin steps are selected.
5. Add detergent and softener according to the water level and close the lid.
• If you select the Memory course after turning the washer “On”, the stored settings are
automatically retrieved.
• To change the stored settings, select the Memory course, reconfigure the settings and
then press the Start/Pause button. Then, the changes are stored.
Clean Tub course
Use this course to clean the tub. It will keep the tub clean and sanitary.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Hold button.
4. Add a delicated detergent and close the lid.
• Never place laundry in the tub when cleaning inside the tub, as this can cause
discoloration or damage to the laundry.
• When doing the laundry after cleaning the tub, you may find some impurities. These are
just detergent residues and impurities after the tub cleaning. Perform the rinse cycle two
to three times.
• The Soak function is set automatically.
• The initial water level is selected at the mid-level between Maximum and Mid.
setting up your washer
WA14P9PIC-02561E-02_EN.indd 10 2013-01-15 �� 11:48:16

setting up your washer _11
Quick course
The Quick course is good for light or slightly stained laundry.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Pause button. The water level is selected automatically.
4. The wash, rinse, and spin cycles follow.
5. To pause a course, press the Start/Pause button again. You can change the course when it
is paused.
6. Close the lid.
Super Clean
Use this course to achieve the cleanest wash.
This course provides you with the optimum in washing performance through the 5-step super
clean system.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Pause button. The water level is selected at the mid-level between Mid and
Mid-low.
The water level is selected between Maximum and Mid or at the mid-level between Mid and
Mid-low.
4. Close the lid.
Energy Saving program (SW90P9 Only)
Use this course to save energy.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Pause button and put the proper amount of detergent into tub.
4. Close the lid.
ECO+ course (WA15P9,WA14P9 Only)
If you want to wash those frequently used towels or less dirty laundry time. Because washing is
speedy, it is good for light or less stained laundry.
1. Press the Power button to turn the washer “On”.
2. Press the Course select button.
3. Press the Start/Pause button.
4. The wash, rinse, and spin cycles follow.
5. To pause a course, press the Start/Pause button again. You can change the course when it
is paused.
6. Close the lid.
01 SETTING UP YOUR WASHER
WA14P9PIC-02561E-02_EN.indd 11 2013-01-15 �� 11:48:16

12_ setting up your washer
Delay Start
Use this to specify a time for the wash cycle to start, for example, when you need to go out and
are unable to monitor the washer.
1. Press the Power button to turn the washer “On”.
2. Press the Delay Start button once.
You may set the delay end time using the Delay Start button from between 3 to 18 hours.
3. Press the Start/Pause button and add the appropriate amount of detergent into the
detergent drawer.
4. Close the lid.
The wash will finish by the set time.
Add detergent and softener according to the water level and close the lid.
• Detergent must be added into the detergent drawer.
• If detergent is added onto the laundry directly, some clothes may become discolored
because the start has been delayed.
• To cancel a Delay Start, press the Power button.
Air Turbo
This course saves you valuable time, ensuring that your clothes dry faster than from line drying.
1. Press the Power button to turn the washer “On”.
2. Press the Air Turbo button.
Each time the Air Turbo button is pressed, the operations are performed in the following
order: On  OFF  On
3. Close the lid.
4. Press the Start/Pause button.
• This can be selected as an additional option for all courses except for Delicate and
Clean Tub course.
• The Air Turbo function is only available when spin cycle is selected.
• Select this when you want to half-dry the laundry.
setting up your washer
WA14P9PIC-02561E-02_EN.indd 12 2013-01-15 �� 11:48:16

setting up your washer _13
MANUAL FUNCTIONS
It is possible to select cycles manually.
(Example) A basic wash for lightly soiled laundry:
Power  Select the Quick course  Wash  Start/Pause
COURSE INSTRUCTIONS
WASH ONLY Press the Power button.
Press the Wash button.
Press the Start/Pause button.
When the Wash button is pressed while washing is in progress, the
wash time can be changed to between 6 and 30 minutes.
RINSE ONLY Press the Rinse button.
Press the Start/Pause button.
The rinse cycle is performed twice.
When the Rinse button is pressed during the rinse cycle, the rinse
time can be changed to between 2 to 5 times in duration.
SPIN ONLY Press the Spin button.
Press the Start/Pause button.
When the Spin button is pressed during the spin course, the spin
time can be changed to 1 to 9 minutes.
WASH AND RINSE
Press the Wash and Rinse buttons.
Press the Start/Pause button once.
The cycle detects the amount of laundry, and automatically
determines the wash and rinse times.
When the Wash and Rinse buttons are pressed while the washer
is in progress, the wash time is determined between 6 and 30
minutes, and the rinse time is determined between 1 and 5 times.
RINSE AND SPIN
Press the Rinse and Spin buttons.
Press the Start/Pause button once.
The rinse and spin cycles are performed.
When the Rinse and Spin buttons are pressed while the washer is
operating, the number of rinse cycles is determined between 2 and
5 times, and the spin time is determined between 1 and 9 minutes.
WASH, RINSE AND SPIN Press the Wash, Rinse and Spin buttons.
Press the Start/Pause button once.
The wash, rinse and spin cycles are performed.
01 SETTING UP YOUR WASHER
WA14P9PIC-02561E-02_EN.indd 13 2013-01-15 �� 11:48:17

14_ setting up your washer
INSTALLING YOUR WASHER
Selecting a location
Before you install your washer, make sure the location:
• Has a hard, level surface without carpeting or flooring that may obstruct ventilation and avoid
vibrations
• Allows at least 4 in (10 cm) between the washer and the wall
• Is away from direct sunlight and not exposed to rain as moisture may destroy the electrical
insulation causing an electrical shock hazard
• Has adequate ventilation
• Is not exposed to temperatures below freezing (below 32 ˚F and 0 ˚C)
• Is away from heat sources such as oil and gas
• Has enough space so that your washer doesn’t stand on its power cable
Connecting the water supply hose
Connecting the hose to the faucet
1. Remove the adaptor from the water supply hose.
2. Loosen the four screws on the adaptor using a “+” type
screwdriver. Then take the adaptor and turn part (b) following
the arrow until there is a gap of about 0.2 in (5 mm) between
part a and b.
3. Connect the adaptor to the water tap by tightening the
screws firmly. Then turn part (b) following the arrow, and
push (a) and (b) together.
4. Connect the water supply hose to the adaptor. Pull part (c)
(water supply hose) downwards. When part (c) is released,
the hose is automatically connected to the adaptor and
makes a ‘clicking’ sound.
5. Connect the other end of the water supply hose to the
inlet water valve at the back of the washer. Screw the hose
clockwise all the way in.
OR
Connect the other end of the water supply hose to the
inlet water valve at the top of the washer. Screw the hose
clockwise all the way in.
setting up your washer
a
b
c
WA14P9PIC-02561E-02_EN.indd 14 2013-01-15 �� 11:48:17

setting up your washer _15
If the water tap is a screw type, assemble a water supply hose that fits to the tap as shown.
After completing connection, if water leaks from the hose, then repeat the same steps.
If after completing the connection water leaks from
the hose, repeat the same steps again. Use the most
conventional type of faucet for the water supply. If the
faucet is square or too big, remove the spacing ring before
inserting the faucet into the adaptor.
Assembling the Protection Panel (Optional)
1. Push and insert the Protection panel towards the back
through the insert hole from the front.
2. If you have difficulty inserting the panel, lift the washer up a
little and then insert it.
The protection panel is not applied in some models
Connecting the drain hose
For non-pump drained washers
1. Press the joint ring and place it around the drain hose.
2. After placing the drain hose into a drain outlet, join the other
end of the hose to the drain outlet of the washer.
3. Ensure that they are connected tightly by pressing the joint
ring and pushing it into the drain-outlet.
• The length of drain hose is adjustable so that it can be
extended to the appropriate length.
Changing the direction of the drain hose
• Press the handle of the joint ring to pull out the drain hose.
Change the direction of the drain hose and follow the above
guidelines again.
01 SETTING UP YOUR WASHER
Front
drain-outlet
WA14P9PIC-02561E-02_EN.indd 15 2013-01-15 �� 11:48:18

16_ setting up your washer
Caution when inserting the drain hose
1. When extending the hose to another hose, the length
should not exceed more than 118.1 in (3 m).
2. Ensure that the end of the drain hose is lower than the
water level for the water to drain properly.
3. The drain hose should not have any obstacles higher than
2 in (5 cm) in their path.
4. Don’t install the drain hose underneath the washer.
For pump-drained washers
1. Remove the cap-hose and connect the outlet-hose.
2. Ensure that the drain hose is connected tightly to the drain-
outlet on the side of the washer.
3. Install the drain hose about 35~39 in (90~100 cm) above
the ground.
setting up your washer
cap-hose
35~39 in
(90~100 cm)
Less than
118.1 in (3 m)
Less than
118.1 in (3 m)
Less than
2 in (5 cm)
CAUTION
WA14P9PIC-02561E-02_EN.indd 16 2013-01-15 �� 11:48:19

setting up your washer _17
Adjusting the height of the washer
Make sure your washer is level by adjusting the leveling legs.
Beware of catching your hands under the legs.
1. Pull the handles located at the right and left front of the
washer and slide them off.
2. Adjust the height of the washer upwards or downwards.
3. When you have finished adjusting the height, push the
handles back to fix the adjusting legs in place.
Water drop mark Cause How to level
The front of the washer
is lower
Level the washer by adjusting the legs.
The back of the washer
is lower
Adjust the height by using the props at the
back.
The left of the washer
is lower
Adjust the left side by using the adjustable legs
at the front and props at the back.
The right of the washer
is lower
Adjust the left side by using the adjustable legs
at the front and props at the back.
Leveling your washer with the leveling screws (Optional)
1. Gently lift up the washer and turn the adjustable legs
to the left to find the optimal balance.
2. When done, return the washer to its original position.
3. After adjusting the legs, do not forget to lock the nut for
safety reasons. (Failing to do so may cause it to become
loose and and move out of position.)
01 SETTING UP YOUR WASHER
CAUTION
WA14P9PIC-02561E-02_EN.indd 17 2013-01-15  11:48:20

18_ washing a load of laundry
washing a load of laundry
With your new washer, the hardest part of doing laundry will be deciding which load
to do first.
BASIC INSTRUCTIONS
1. Load your laundry into the washer.
2. Close the door.
3. Turn the power on.
4. Add detergent and additives into the dispenser (see page 20).
Select the appropriate course and options for the load (see pages 9-12). The Wash Indicator light will
illuminate and the estimated course time will appear in the display.
5. Press the Start/Pause button.
LAUNDRY GUIDELINES
Follow these simple guidelines for the cleanest laundry and the most efficient wash. (It is important that the
checkpoints below are followed in order to avoid machine problems or clothing damage.)
If any problems arise due to the fault of the customer, a separate service fee will be charged to the
customer.
Always check the Care label on clothing before washing.
• You can fill the tub with dry, unfolded clothes; but do NOT OVERLOAD the tub. Overloading
may reduce washing efficiency, cause excess wear on your laundry and the washer, and
possibly cause creasing or wrinkling of the load.
• When washing big, bulky items or a few smaller items that don’t fill the tub completely - a
rug, a pillow, stuffed toys, or one or two sweaters, for example - add a few towels to improve
the tumbling and spinning performance.
• Check if any clothing items may bleach. Add liquid detergent to a white towel and the
garment if you are unsure whether it may bleach. Rub the two items together strongly. Check
if the color is transferred to the towel.
• Be especially careful with scarves and imported clothes since they discolor easily. Check for
stains or partial dirt. If stains are found, add some detergent to a cloth and rub the stain in
a single direction. Soil and dirt may rub against delicate garments causing damage and the
wash result may be unsatisfactory.
• If clothes are too soiled, remove them and wash them separately, as dirt may transfer to the
other clothing.
• Before washing the following items, sleeves, collars, dress
hems and pockets should be pre-treated by brushing them with
detergent. Wrinkle-processed clothing made of wool should be
specially treated by tying them together (using thread) before
washing. The thread is removed after the clothes have dried.
• Metal on clothing may damage your clothing as well as the tub. Turn
clothing with buttons and embroidered clothes inside out before
washing them. If pants and jacket zips are open during the wash,
the spin basket may be damaged. Zips should be closed before
washing.
• Clothing with long strings may become entangled with other clothes
and damage them. Be sure to fix the strings before starting the
wash.
• Turn delicate clothing inside out before washing it.
WA14P9PIC-02561E-02_EN.indd 18 2013-01-15 �� 11:48:20

washing a load of laundry _19
• Wash black clothing and cotton towels separately. If these are washed together, the towels
may become stained. Check before washing.
• Curtains, light garments or blue jeans should not float. If they are floating, stop the washer
by pressing the Start/Pause button and press them them down until they are soaked in
the water. If the wash continues with floating clothing, it may damage the laundry and the
washer, as well as resulting in an unsatisfactory washing result.
Check all pockets before washing! Hairpins and coins
may damage your clothing as well as your washer. It is
important that you check pockets for objects and remove
them.
Do NOT wash the following items
• Clothing that is easily disfigured even when simply soaking in water.
• Neckties, brassieres, jackets, suits and coats that are made mostly of rayon and other kind of
blended fabrics can be easily disfigured (e.g. shrinkage and discoloration).
• Wrinkle-processed, embossed, or resin processed products that are easily disfigured even
when simply soaking in water.
• Easily discolored products made of cotton and wool, wrinkled silk, leather products, leather
accessory, leather ornamented clothes and its accessories.
• Do not wash waterproof clothing (e.g. ski wear, diaper covers and matts/rugs). This may
cause the laundry to be ejected or cause the washer to vibrate abnormally, which may result
in personal injury or damage to the washer, the floor or the clothing. When the tub rotates,
water may become trapped in the waterproof clothing or fabric and can collect in a corner,
causing abnormal vibrations. In addition, the laundry rises and may be ejected and cause
personal injury.
Use a laundry net to wash the following items
• Use only commercial laundry nets.
• Place delicate clothes in a laundry net.
• Cashmilon and garments with a big volume and lightweight
(e.g. lace decorated clothing, lingerie, nylon stockings,
synthetic fabrics, etc.) may rise to the top of the washer
and damage clothing and the washer. Use a laundry net or
wash these items separately.
• Place long stringed and lace decorated clothing, bed
cover sheets, and woolen clothes into a laundry net before
washing them.
02 WASHING A LOAD OF LAUNDRY
CAUTION
WA14P9PIC-02561E-02_EN.indd 19 2013-01-15 �� 11:48:20

20_ washing a load of laundry
DETERGENT AND ADDITIVES INFORMATION
Which detergent to use
Use powdered or liquid detergent. Do not use soap as the tub may become dirty from dirt on it.
• When the detergent does not dissolve properly, use warm water to dissolve the detergent.
• Use the appropriate amount of detergent.
Even if an excessive amount of detergent is used, there is little difference in the washing
result. However, It may damage the garments as there may be insufficient rinsing.
• Bleaching agents may cause damage to garments as they are a strong alkali.
• Perform sufficient rinsing as powdered detergent can easily remain on the garments causing
bad odors.
• If too much detergent is used or cold water is used, the detergent doesn’t dissolve
completely and remains on the garments, hose or spin basket, contaminating the laundry.
• For a delayed start, the detergent must be added into the detergent drawer. If powder
detergent is spread directly onto the laundry, it may cause discoloration.
Detergent drawer
The detergent drawer is located inside the washer at the back.
Adding detergent
1. Open the detergent drawer and then add the powder
detergent into the detergent compartment.
2. Add detergent evenly so that it doesn’t brim over the
edge of the drawer.
• Use a reasonable amount of detergent.
If you use more detergent than the standard
quantity or the water temperature is too low and the
detergent does not dissolve in the water completely
causing it to remain on the laundry and in the hose and tub, it may cause damage such
as dirtying and discoloring the laundry.
• If you use a powder detergent and it remains on the laundry, it may cause a bad odor.
Rinse the laundry sufficiently in fresh water.
• If you spread a powder detergent over the laundry directly, it may result in discoloration.
Make sure to insert it into the detergent compartment.
If the water pressure is low, the detergent may remain in the detergent compartment.
Adding fabric softener
1. When the proper amount (one time dose) of fabric softener is stored in the softener inlet, it is
automatically added during the last rinse cycle.
2. Do not add detergent, bleach or starch into the softener inlet.
3. Using too much softener may produce unsatisfactory results.
4. Do not open the lid during the Spin cycle. If added too early, its effectiveness will decrease.
5. Do not leave the softener in the softener dispenser for a long time as it may congeal.
If the water pressure is low, the fabric softener may remain in the softener compartment. In
this case, put the fabric softener into the tub directly.
washing a load of laundry
CAUTION
CAUTION
WA14P9PIC-02561E-02_EN.indd 20 2013-01-15 �� 11:48:20
