Sankyo ICI3Q8-5293 User manual

Type Name :
Notes :
・ ・
・ ・
・ ・
・ ・
・ ・
Sym. Cha. No. Date By Appr.
Design H.Takahashi
AMO-NP-07533-01
Det-che
Appro.
No. S39Z-032-00-02D
Custody
2008.05.16
・ ・
Type Name ・ ・ NIDEC SANKYO CORPORATION
INSTRUCTION MANUAL
Spec. No.
Distribution
No. of sheet
Revision Page
Reference Document
ICI3Q8-5293
AMO-NP-15167-01

No AMO – NP – 15167 – 01 1
/11
-----Table of Contents-----
Contents Page
1. BeforeUse 2
2. ImportantNotice 2
3. Attentionstothisinstructionmanualandcautions 2
4. Scope 3
5. Equipmentsummaryandfunctions 3
6. Unpacking 5
7. Setup 5
7.1Howtoconnect 5
1)Powercable(Connector) 5
2)USBCable 6
3)Powercable(Plug) 6
Attentiontothepowersupply 6
7.2Howtopoweronandoff 7
1)Howtoturnonthepowersupply 7
2)Howtoshutoffthepowersupply 7
7.3Howtoreplaceafuse 7
7.4Howtoremoveajammedcard 8
8.Considerationsforcardhandling 10
9.Dailymaintenance 10
10.Notes 11

No AMO – NP – 15167 – 01 2
/11
1. Before use
This operation manual is written for technical staff experienced in the general operation
of magnetic and Non-contact IC card reader/encoders. It is intended to describe the
operation of NIDEC Sankyo 's model ICI3Q8-5293.
The terminal manufacturer shall be responsible to furnish an operation manual for end
users.
2. Important Notice
Misuse or mishandling may shorten product life or cause the product to malfunction or
operate improperly.
Please read this manual thoroughly to understand proper care and operation of the
ICI3Q8-5293.
3. Attentions to this instruction manual and cautions
This equipment is packaged for use in North America. Use in other areas will necessitate
substitution of the power cord. Please check with the terminal manufacturer for an
appropriate cable if used outside North America.
1) A user may not repair this equipment. Please ask specialized service personnel for
repair.
2) Repair or service by unqualified/untrained personnel may result in damage to the
equipment or personal injury. Please refer all repair/service operations to a trained
service technician.
3) Use of third party supplied spare parts, could result in damage to equipment or
personal injury. Use only factory supplied spare parts in service of this equipment.
4) Ensure product is placed in a clean and stable location to prevent from falling or
dropping. Please hold the product by the lower case when transporting or moving.

No AMO – NP – 15167 – 01 3
/11
4. Scope
This instruction manual is to describe proper handling procedures of the magnetic and
Non-contact IC card reader/encoder, model number ICI3Q8-5293.
5. Equipment summary and functions
Magnetic card reader/encoder, (hereafter referred to as MCRW), is a terminal with
enclosure, and embedded power supply. It is configured to read and encode magnetic cards,
working through an USB connection to the main computing system (hereafter referred to
as HOST).
Firmware is installed in the onboard flash ROM (F-ROM) and downloadable by the HOST
for ease of upgrade if required.
LED
Coverscrew
Equipmentupper
Uppercase
Frontcover
Equipmentside
Fig.1Equipmentappearance
Cover screw
Card insertion gate
Lower case

No AMO – NP – 15167 – 01 4
/11
LED
･POWER lamp: Lights when power is on.
･READY lamp: Lights or blinks as defined by operation and card processing status
･ERROR lamp: Lights or blinks when an error occurs.
LED
Coverscrew Cardgate
Rearside
Frontside
Inlet ACSwitch
AC Switch
Inlet Fuse
USBConnector Backside
Fig.2Equipmentappearance

No AMO – NP – 15167 – 01 5
/11
6. Unpacking
Includedinthecartonwiththe MCRW should be. Please inventory before
proceeding.
(1) MCRW 1 piece
(2)Cables
USB cable (SBE425501) 1 piece (to connect with Host computer)
Powercable(SBE426401) 1piece
USBcable
plug connector
Powercable
7. Setup
7.1Howtoconnect
1)Powercable(Connector)
Ensure that the AC switch is off. See section 7.2.
EnsurethatpowerLEDisnotlit.
Turn over the MCRW, and insert the power cable connector securely into
the inlet as shown in the figure below.
Inlet
Powercable Connector

No AMO – NP – 15167 – 01 6
/11
2)USBCable
EnsurethattheACswitchisoff.
TurntheMCRWoverandinserttheUSBcablesecurelyintotheUSB
connector. Connect the other end to the appropriate USB port on the
HOST.
USBConnector
USBCable
.
3)Powercable(Plug)
SettheMCRWinanuprightpositionandpluginthepowercable
securely to AC120V outlet (grounded triple pin).
Cautions
1.Donotexceedratedpowersupplyinputvoltage
2. The power cable supplied with the MCRW is rated +125V 15A. Do not use
underrated power cables or extension cords. Underrated power cables or
extension cords could cause a risk of fire or overheating.
3.Agroundedtriplepinoutletshouldbeusedforpower.
4. Please hold the plug portion when the power cable is inserted or removed.
Do not pull on the cable.

No AMO – NP – 15167 – 01 7
/11
7.2 How to turn on and shut off the power supply:
1)Howtoturnonthepowersupply:
TopowerON:pressthe" " ontheACswitch.
WhenthepowerisON,thepowerLED
on the front panel is lit.
2)Howtoshutoffthepowersupply:
TopowerOFF:pressthe" "ontheACswitch.
WhenthepowerisOFF,thepowerLED
onthefrontpanelisextinguished.
Pleaseallowatleasta5-secondinterval
before turning ON the power supply after
thepowerhasbeenshutOFF.
7.3 How to replace a fuse:
Pleasecontactatrainedrepairtechnician when you need to replace a fuse.
1)SwitchofftheACandensure that the power LED is extinguished.
2) Disconnect the power cable from the outlet.
3) Turn over the MCRW. Use a flathead screwdriver on the fuse holder and turn
gently to release. Pull out the fuse holder.
4) Remove the old fuse and, insert a new fuse of the proper rating.
5) Replace the holder in the original position . Push and turn it to the right
until it stops. Ensure that the holder is securely seated.
Power lam
p
on
Power on
Power lam
p
off
Power off

No AMO – NP – 15167 – 01 8
/11
Fuseholder
Fuse
Insertiondirection
Fuseholder
Insertionopening Fuseholderturnditch
FuseratedT2.5A/250V
7.4 Howtoremoveajammedcard:
Please refer to a trained technician for removal of a jammed card.
When removing the jammed card, please follow the process below.
1)SwitchofftheACandmakesure that the power LED is extinguished.
2) Loosen the cover screw on the upper case rear (use a Phillips-head
screwdriver.).
3) Push the upper case mark downwards, in the direction shown by arrow (1),
and pull in the direction of arrow (2) moving the case to rear.
4)Lifttheuppercasetoremove. .

No AMO – NP – 15167 – 01 9
/11
(1)
(2)
ACSwitch
Uppercase
5) Unhook the cover sheet from the top of the card reader and hold by the hook side.
6) Using tweezers, inserted from the top of the card reader, gently push the jammed
card towards the gate until it can be easily removed by hand.
7) Place the upper case on the main body as shown by arrow (4) and slide forward, in
the direction of arrow (5), then snap lock the upper case in place (6).
8) Fasten the cover screw (use a Phillips-head screwdriver).
Uppercase
Cover screw
Sheetcover Cardreader
Mainbody
Sheetcoverhook
(4)
(5)
UpperCase
Main
Lock (6)

No AMO – NP – 15167 – 01 10
/11
8. Considerations for card handling
Pleaseuseapplicablecards. Thisequipment cannot handle any cards other than
those specified.
1) Remove any foreign objects from the card.
Wipe moisture or oils from cards with a dry cloth prior to using.
Removeany,stickingtape,clips,oreraser residue to prevent card read errors.
2)Damagedcardsmaynotbeused on this equipment.
Warped, bent, curled, punctured, or cracked cards may cause read/write errors or
card jams.
3) Unreadable card
Damaged or demagnetized cards may make a normal read operation impossible.
9. Daily maintenance
Daily checks and maintenance shall be performed as follows.
1)Cautions
Maintenance must be done with the AC switch shut off. Any maintenance work
requiring with upper case removal, should be referred to a trained service
technician.
2) Daily maintenance
Each cable connector must be securely connected.
Cables shall not be placed under the equipment or removed.
3)Cleaning
Use a dry cloth to clean the MCRW case.
For more extensive case cleaning, a damp cloth with a neutral detergent should
be used. After cleaning the case should be wiped off with a dry cloth.
5) The magnetic head should be periodically cleaned. It is recommended that an
approved cleaning card be used for this purpose.
(Cleaning card :Sankyo P/N SBE018601)

No AMO – NP – 15167 – 01 11
/11
10.Notes
1)FCC WARNING
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Properly shielded a grounded cables and connectors must be used for connection
to host computer and/or peripherals in order to meet FCC emission limits.
2)NOTICE
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
