User’s Manual /1
Contents


1.Introduction .........................................................................................................................3
2.Safetyinstructions ...............................................................................................................4
2.1Safetylabelsandsymbols................................................................................................4
2.2Beforeusingthemower ..................................................................................................5
2.3Whenusingthemower....................................................................................................5
2.4Afterusingthemower .....................................................................................................7
3.UsageGuidelines..................................................................................................................7
3.1Preparingthemowerforwork……………………………………………………………....………………….7
3.11Mowerassembly………….…………………………………….……..……………………….……..……………7
3.12Fillingthemower’senginewithoil………………….…………..…………….…………..…..…………9
3.13Fillingthefueltank……………………………………………………………………………………….…………9
3.14Adjustingthecuttingheight.......................................................................................10
3.2Usingthemower............................................................................................................11
3.21Startingthemower ....................................................................................................11
3.22Movingthemower.....................................................................................................12
3.23Stoppingthemower...................................................................................................13
3.3Cleaning,storage,transportationandmaintenance.....................................................13
3.31Cleaningthemower ...................................................................................................13
3.32Storingthemower .....................................................................................................14
3.33Mowermaintenance..................................................................................................15
3.34Maintenanceschedule............................................................................................... 19
4.Specifications................................................................................................................................19
5.Troubleshooting.................................................................................................................21
6.EnvironmentalProtection..................................................................................................22
7.Aftersalesservice ..............................................................................................................22
8.Warranty ............................................................................................................................22
9.DeclarationofConformity .................................................................................................24
Notes......................................................................................................................................25
Warrantyregistrationcard ...............................................................................................27‐28





User’s Manual / 2
ModelLSP510S9B



MOWERDESCRIPTION
1Powerdrivelever 9Sparkplug
2Operatorcontrollever10Exhaust
3Throttlecontrol 11Sidedischargekit
4Quick‐releaseclamp 12Oilfilleranddipstick
5Rearspoilerprotection13Heightadjustmenthandle
6Transmissioncontrolcable 14Grasscollectionbag
7Fueltank 15Starterrope
8Airfilter16Handlebar
Partssupplied:sparkplugsocket,wrenches,2hose‐clamps,2straps,screwdriver,spanner,
combinationspanner




User’s Manual /3
1.Introduction

ThankyouandcongratulationsonyourpurchaseofanewSANLImower.We
areconfidentthatthisequipment,whenproperlymaintainedandadjusted,
willgiveyoumanyyearsoftrouble‐freeoperationenablingyoutofully
appreciateitsquality,performanceandeaseofuse.

Thismowerhasbeendesignedandmanufacturedwithutmostcarein
accordancewithSANLI’sstrictstandardsofsafety,reliabilityandeaseof
operation.

Pleasereadthismanualcarefullyandfamiliariseyourselfwithallofthe
mower’scontrolsbeforeusingthemachineforthefirsttime.

Pleaseadherestrictlytoallwarnings,explanationsandinstructionsgivenin
thismanualtoensuresafeandoptimaluseofyourSANLImower.
















PLEASE KEEP THIS OPERATOR’S MANUAL IN A SAFE PLACE

User’s Manual / 4
2.Safetyinstructions
Alwaysfollowtheinstructiongiveninthismanualwhenusingthemower.
2.1Safetylabelsandsymbols
IMPORTANT:Anumberofthelabelsandsymbolsillustratedbelowwillbe
foundonyourmower.Pleasestudythemandlearntheirimportance.Correct
interpretationofthesesymbolswillresultinefficientuseandreducedrisks.

Danger!Warning!Attention!
Thissymbolhighlightsadanger,awarningoracaution.Itindicatesthat
theoperator'ssafetyisatrisk.

Readthemanual
Themanualcontainsinformationintendedtodrawattentionto
possiblesafetyissuesanddeteriorationofthemachineaswellas
helpfultipsforgettingstarted,correctmoweruseandmaintenance.
Pleaserespectallofthewarnings,explanationsandinstructionsgiven
inthismanualforsafeandoptimaluseofthemower. 

Riskofflyingobjectsordebris
Beawarethatthereisariskofflyingobjectsand/ordebriswhenusing
themachine.

Keepasafedistance
Theoperatorisresponsibleforthesafetyofotherslocatedinthe
workingareaofthemachine.Donotcutthegrasswhileotherpeople,
especiallychildrenorpets,arenearby.

Riskofcutsorseriousinjury
Keephandsandfeetwellclearofthecuttingchamberwhenstarting
theengineandwhentheengineisrunning.

Immobilisethemachine
Turnofftheengineandremovethesparkplugcapbeforecleaning,
transporting,adjustingorleavingthemachineunattended.

Hazardousproducts
Thismachineusespetrolandoil.Beverycarefulwhenfilling,operating
andmovingthemower.Weareyeandhandprotectionwhenrefilling
themowerwithfueloroil.

Wearprotectiveequipment
Weareyeandhearingprotectionwhenusingthemower.

User’s Manual /5
2.2 Beforeusingthemower
•Studycarefullytheinstructionsgiveninthismanual.
•Familiariseyourselfwiththemower’soperationandhowtouseit
properly.
•Neverallowotherpeople‐especiallychildren‐tousethemachineif
theyhavenotreadandfullyunderstoodtheseoperatinginstructions.
•Ifthemoweristobeusedbysomeoneotherthantheowner,ensure
thattheyhavebeengiventhisinstructionmanualtoreadfirst.
•Neverremovelabelsorsafetydevicesfromthemachine.
•Checkthatallpartsandcomponentsaresecurelyfixedandattached.
•Ensurethatthecuttingbladeanditsfastenerareingoodconditionand
properlysecured.Cuttingedgesshouldnotbebluntordamaged.If
necessary,removeandsharpenorreplacetheblade.Beforedoingthis,
alwaysturnofftheengineandremovethecapfromthesparkplug.
•Neverusethemowerwhenitsprotectivegrille,oranyothersafety
deviceorguard,isdamagedormissing.
•Checktheoillevelbeforeeachmowingsession.
•Neveralterthebasicsettingsoftheengineanddonotoverspeed.
•Beforemowing,checkthecuttingareaandremoveanysolidobjectsor
debris(egstonesortwigs)thatmaybepickedupandthrownoutby
themower,injuringbystandersanddamagingthecuttingbladeand
engine.
2.3Whenusingthemower
•Mowonlyingood,cleardaylightconditions.
•Besuretocomplywithanylocalornationalregulationsgoverning
whenmowingmaybecarriedout.
•Donotusethemachineifyouarefeelingtired,unwell,haveconsumed
alcoholorareundertheinfluenceofmedicines/drugs.
•Nevermowwearinglooseclothing/shoesorwithbarefeet.Always
wearlongtrousersandsturdy,non‐slipfootwear.
●Starttheenginecarefullyinaclear,unobstructedareafollowingthe
instructionsforuse.Keephandsandfeetwellawayfromtheturning
blade.

User’s Manual / 6
•Neverleavetheenginerunningunattendedorinanenclosedarea
wheredangerouscarbonmonoxidefumescanaccumulate.
•Themower’soperatorisresponsibleforthesafetyofotherslocatedin
theworkingareaofthemachine.Nevercutthegrasswhileothers,
especiallychildrenorpets,arenearby.Doingsocanheightentheriskof
injurycausedbystonesorotherdebrisbeingejectedfromthemachine
whenmowing.
•Neverrunwhenusingthemower.Walksteadilyguidingthemachine
carefullyovertheground.
•Thelengthofthehandlebarsprovidesaminimumrecommendedsafe
distancefrommovingandhotpartsofthemachine.Respectthis
distance.
•Neverputhandsorfeetbeneaththecutterdeckorneartoanyother
movingparts.
•Keepclearofallareasofthemachinewhichmayejectdebris.
•Whenmowing,avoidobstaclessuchasmolehills,stumps,kerbs,posts
andotherobstructionswhichcannotbecutbythebladeandmay
damagethecuttingsystem.Donotworkclosetoditchesoron
soft/unstablegroundoranyotherareaswherethereisriskofrollover.
•Ifyouneedtoattendtooradjustthemachine,alwaysstoptheengine
andremovethecapfromthesparkplug..
●Ifthemachinehastobeliftedortransported,alwaysstoptheengine
andremovethecapfromthesparkplug.Neverliftortiltthemower
duringstartingorwhenthebladeisturning.
•Usearamporgethelpfromasuitablefitandhealthypersonwhen
lifting,loadingorunloadingthemower.
•Toavoidriskoffire,neverstartthemowerwherefuelhasbeenspilled.
•Beespeciallycarefulwhenturningwiththemowerandwhenpullingit
towardsyou.
•Maintainawell‐balancedpositiononslopinggroundandnevermowon
steepslopes.Beespeciallycarefulwhenchangingdirectiononslopes.
Alwaysmowacrossaslope,neverupanddown.
•Toavoidtheriskofseriousburns,nevertouchahotengineoranyofits
partsunlesswearingsuitableprotectivegloves.
•Observeanylocalornationalregulationsrelatingtotheuseofengine‐
poweredoutdoorequipment.

User’s Manual /7
2.4Afterusingthemower
•Allowtheenginetocoolbeforestoringthemowerinanenclosedarea.
•Neverstoreamowerwithfuelinitstankinanareawherepetrolfumes
maycomeintocontactwithaflameorspark.Topreventfirerisk,keep
theexhaustandtheareaaroundthefueltankfreeofgrass,leavesand
oil.
•Ifyouneedtodrainthefueltank,doitoutdoorsusingpurpose‐
designedfuelsuctionpump.
•Removegrass,greaseandoilfromthemowerbeforestoringit.
•Formaximumsafety,replacewornordamagedpartsimmediately.
•UseonlygenuineoriginalpartsorthoseapprovedbySANLI.


3.UsageGuidelines

Makinganyunauthorisedmodificationstothemower(i.e.modificationsthat
areunauthorisedbySANLIand/oranappointedSANLIdealer)canmakethe
machineunsafeandmayleadtosevereinjuriesduringuse.SANLIcanaccept
noliabilityformachinefailureorpersonalinjuryifthemachine’sowner
and/oroperatordoesnotcomplywiththisnoticeand/orwithnationalsafety
regulationsandguidelinesregardingtheuseofengine‐poweredoutdoor
equipment.

3.1Preparingthemowerforwork
3.11Mowerassembly
1.Mowershownindelivery
positionwithlowerhandles
unassembledandhandlebar
folded.(Fig.1)
2.Fitthelowerhandleswith
wingnuts,bolts,plain
washersandscrewssupplied.
(Fig.2)

User’s Manual / 8
3.Lockthehandlebarin
positionusingquick‐release
clamps.（Fig.3）
4.Fitthecableclampfrom
outsidetoinsidewithbolt
supplied.（Fig.4）
5.Assembletheoperator
controlleverand
transmissioncontrollever.
(Fig.5、Fig.6)
6.Assemblethegrass
collectionbag,securethe
grasscollectionbagwith
self‐tappingscrewthenfit
onthemachine.(Fig.7 、
Fig.8、Fig.9)
7.Assembletheside
dischargekitontothesteel
deck，ifyourmowermodel
isLSP5109SBorLBP510
9SB.(Fig.9.1)
8.Fastenthestartercordto
itsmachine.(Fig.10)
9.Theimageoffullyassembledmachine.(Fig.11)


User’s Manual /9
3.12Fillingthemower’senginewithoil(withB＆SEnginepleaserefertoB
＆Senginemanual)
Fortransportreasons,yournewmower’senginedoesnotcontainoilwhen
despatchedfromthefactory.Beforeuse,ensurethatthemowercontainsoil.
WARNING:Neverruntheenginewithoutoilevenforashortperiod.
•AlwaysuseahighqualityoilofAPISF
standardsandSAE30or15W40
viscosity.
•Whenfillingtheenginewithoil,
positionthemoweronafirmlevel
surface.Unscrewtheoilfillercap
andremovethedipstick.(Fig.12)
•Slowlypourintheoil.Thecorrect
capacityoftheengine’soilsumpis
650ml(600mlforB&Sengine).
Insertthedipstickuptothefiller
neckbutdonotscrewitin.Removethedipstickandreadtheoillevel
byholdingthedipstickhorizontally.Theoillevelmustreachthe
maximummarkonthedipstick.(Fig.13)
•Iftoomuchoilhasbeenaddedtotheengine,theexcesscanbedrained
outbytippingthemowerontoitssidewiththeairfilterand
carburettoruppermost.


3.13Fillingthefueltank

WARNING:Petrolishighlyinflammable.Alwayshandlefuelwithextreme
caretoavoidriskofburns,fireorexplosion.Thefueltankshouldbefilled
beforestartingtheengine.Yourmower’senginerunsonpetrolalone‐donot
addoiltothepetrol.
Alwaysuseunleadedpetrolofaminimum95RON.Buyonlythequantityof
fuelthatyouplantouseinamonth.Nevertransportandstorepetrolother
NOTE: THE OIL FILLER CAP MUST BE SCREWED IN FULLY BEFORE STARTING
THE ENGINE. NEVER REMOVE THE FILLER CAP WITH THE ENGINE RUNNING.

User’s Manual / 10
thaninacontainersuitableforthepurpose,approvedandlabelled
accordingly.
•Alwaysrefueloutdoors,neverinanenclosedspaceornearanaked
flameorheatsource.Neversmokewhilefillingthefueltank.
•Donotunscrewthetankcapwhentheengineisrunningorwhenthe
mowerishot.
•Toaddfuel,unscrewthefuelfillercap.
•Slowlypourthefuelintothetankusingthe
fuelcontainer’sspout(Fig.13.1)orafunnel.
•Thetank’scapacityisabout1litre(0.9litre
forB&Sengine).Avoidspillagesbynot
overfillingthetank.Leaveabout13mm
spacebeneaththethreadedcollartoallowforfuelexpansion.
•Iffuelshouldoverflow,donotstarttheengine.Movethemoweraway
fromtheplaceofspillageandcarefullywipedownthemower.Any
attemptatstartingshouldbeavoideduntilpetrolvapourshave
completelygone.
•Replacesecurelythecapsonthefueltankandthefuelcontainerand
placethelatterinasecureplaceawayfromheatordirectsunlight.
•Beforeeachmowing,visuallyinspecttheconditionofthemower’sfuel
tankanditscap,thefueldeliverypipeandthefuelfilter.

Ifafuelleakisseenorsuspected,donotstarttheengine.Drainthefuel
tankusingafuelsuctionpumpandimmediatelycontactanapproved
SANLIdealersforadvise.
3.14 Adjustingthecuttingheight

Forbestresults,alwaysadjustthecuttingheightofyourmowertosuitthe
mowingconditionsanddonottrytoremovetoomuchgrassinonepass.
AdjustmentofthecuttingheightformodelsLSP510S9A,LSP510S9B,LBP
510S9AandLBP510S9Bismadecentrally.
CAUTION:Neveradjustthecuttingheightwhentheengineisrunning.Always
removethesparkplugcapbeforemakinganyadjustments.


User’s Manual /11

•Takeholdoftheheightofcutadjustmentleverpositionedonthe
mower’sright‐handrearwheel.
•Movetheleveroutwardstoreleaseitfromits
locatingnotch(Fig.14).
•Movethelevertowardsthefrontofthemachine
toincreasethecuttingheightandtowardsthe
reartoreducethecuttingheight.
•Returnthelevertothelocatingnotchtosetthedesiredcuttingheight.
•Makesurethehandlefitssnuglyandsecurelyintoitsserratedholder.
Obstructionssuchasgrassclippingsshouldnothinderhismovementor
positioning.

3.2Usingthemower
Beforestartingandusingthemower,checkforthepresenceandoperationof
safetydevices.Also,checktheconditionofthebladeanditssecuringbolt.If
necessary,replaceorrepairdefectiveitems.UseonlygenuineSANLIpartsor
partsthathavebeenapprovedbySANLIdomesticofficeordealers.
Ifpossible,mowonlywhenthegrassisdry.Ifthegrassiswetorexcessively
long,performtwocuttingpasses.Makethefirstpassatmaximumcutting
heighttoavoidoverloadingthemower.Thesecondpassshouldbemadeat
therequiredfinishedheight.Ifgrassbuildsupbeneaththemower’schassis,
stoptheengineandremovethesparkplug’scapbeforecleaningthe
undersideofthecutterdeck.

3.21Startingthemower
•Beforestartingtheengine,pleasereadthoroughlytheinstructions
regardingsafeuseofthemower(seepages5–7).
•Slidethethrottlelevertoandforseveraltimestoensurethatitis
movingsmoothlyandcorrectly.
•CheckthatthefueltapisintheONposition(Fig.15)andthatthe
engine’soilleveliscorrect(seeparagraph3.12).

User’s Manual / 12
•Startthemowerinaclear,levelarea.Donotstarttheengineifthe
cuttingbladeisrestingonroughanduncutgrassasthismaycause
difficultiesatstart‐up.
•Foracoldstart,movethethrottlelevertothepositionmarked:
•Forahotstart,movethelevertothepositionmarked:
•Standbehindthehandlebar.Movetheoperatorcontrollever
positionedinfrontofthehandlebarrearwardssothattheleveris
restingagainstthehandlebar(Fig.16).Takeholdofthestarterhandle
firmlywiththeotherhand.
•Pullbackthestarteruntilyoufeelresistanceandthenpullthehandle
firmlyandbrisklytoturntheengine(Fig.17).
•Repeattheaboveprocedureasnecessaryuntiltheenginestarts.
•Whenstartingfromcold,graduallymovethethrottleleverto
thefullthrottleposition(asshownright)afterafewmoments
ofrunning.
WARNING:Thecuttingbladeturnswhentheengineisbeingstarted.

3.22Movingthemower
TheLSP510S9A,LSP510S9B,LBP510S9AandLBP510S9Bmowersare
equippedwithagearboxwhichallowsthemowertobeself‐propelled.When
thetransmissionisactivated,itengagestherear
wheelsofthemowerandthemowermoves
forwardunderitsownpower.
Toactivatethetransmission,pushthefull‐width
advanceleverattherearofthehandlebar
forwardssothattheleverpressesagainstthe
handlebar(Fig.18).
Whilethemachineismoving,holdtheleverflexiblysoitcanbereleased
easilywhenneeded.

User’s Manual /13
Tostopdrivetothewheels,releasethepowerdrivelever.

Note:Thetransmissionoperatesonlywhentheengineisrunning

Tousethemowermanuallywithoutdrivingthewheels,donottouchthe
powerdriveleverattherearofthehandlebar.
Similarly,whenmakingU‐turns,tightturnsorwhenfinishingoff,releasethe
powerdriveleverandmovethemoweracrossthegroundmanually.
3.23Stoppingthemower
Tominimisepossibleriskofaccidents,theengineofyourSANLIlawnmoweris
coupledtoanoperatorpresencecontrol.Whentheoperatorpresence
controlleverisreleased,itreturnsimmediatelytoitsrestpositionandthe
engineisautomaticallyturnedoff.
Tostopthemower,movethethrottlelevertoitsstoppositionand
releasetheoperatorpresencecontrollever.Theengineandthe
bladewillstopturningautomatically.
3.3Cleaning,storage,transportationandmaintenance
Beforeworkingonthecuttingsystemofthemachine,switchofftheengine,
removethesparkplugcapandwaitfortheenginetocooldown.
3.31Cleaningthemower
•Cutgrassisdamp.Regularcleaningaftereachusewillensurebetter
functioningofthemowerandreducetheriskofcorrosionorseizure.
•Havingfinishedmowing,allowtheenginetocoolthenremove
accumulatedgrassclippingsfromandaroundtheenginewithabrush.
•Cleanthegrasscollectionbagannuallywithabrushorgentlesprayof
water.
•Disconnectthesparkplugcapandtiltthemoweronitssidewiththeair
filterandcarburettoruppermost.
•Removeanyremainingcutgrassfromthecuttingsystemwithascraper
andabrush.
•Tipthemowerontoitsfourwheels.

User’s Manual / 14
•Ifusingapressurewasherorhotwatertocleanthemower.Becareful
toavoidsoakingpartssuchastheengine,aircleaner,wheelbearings
andmetalfastenings.Dryoffthemachinebeforestoringbyleavingit
runningforafewminutesonaflat,clearsurfacetopreventcorrosion
orseizure.
3.32Storingthemower
Storeyourmowerinadry,well‐ventilatedarea,awayfromflames,sparksor
heatsources.Ifthestorageareaisaccessibletochildren,immobilisethe
machinebydisconnectingthesparkplugcap.
Storingthemowerbeneathatarpaulinorsimilarcoverisnotrecommended
asitmaycauseabuild‐upofcondensationresultingincorrosionofthe
mower.

Extendedshutdownandwinterstorage
Thoroughlycleanthemower.Ideally,runtheengineoutdoorsuntilthefuel
tankisempty.Alternatively,emptyanyremainingfuelusingafuelsuction
pump.TurnthefueltaptotheOFF
position(Fig19).
Disposeofdiscardedfuelsafelyand
responsibly,rememberingthatpetrol
vapourscancauseexplosionorfire.Run
theengineuntilanyremainingfuelis
consumed.Allowtheenginetocool.
Checktheconditionandcleanlinessofthe
aircleaner(seepage24).
Removethesparkplugfromtheengine
andpouratablespoonofengineoilintothecylinder.Gentlypullthestarter
ropeseveraltimestoturnovertheengine,distributingtheoiltoprotectthe
cylinderoverwinter.Replaceandtightenthesparkplug.

Atthestartofthenewseason
Removethesparkplugandgentlycleanoffanycarbondepositsfromthetip
withasmallcopperwirebrush.Pullthestarterropeseveraltimestoexpel
excessoilfromthecylinder.Replaceandtightenthesparkplug.Fillthefuel
tankwithunleadedpetrol(95RONminimum)andmovethetaptotheON
position.(see3.21)


User’s Manual /15
Beforetransportingthemower
Thoroughlycleanthemower.Emptythefueltankusingasuctionpump.Turn
thefueltaptoitsOFFposition(Fig.19).
Disposeofdiscardedfuelsafelyand
responsibly,rememberingthatpetrol
vapourscancauseexplosionorfire.Run
theengineuntilanyremainingfuelis
consumed.Allowtheenginetocool.
Removethegrasscollectionbag.Loosen
thehandlequickrelease(Fig.20)andfold
downthetopsectionofthehandlestaking
carenottobendthecables.
Toavoidscratchingthemower,insertcorrugatedcardboardorsimilar
paddingbetweentheupperandlowerhandlebarsandtheengine.
Duetothemower’sweight,userampsorseekassistancewhenliftingor
loadingthemower.
3.33Mowermaintenance
Cuttingsystem
Beforeandaftereachmowingsession,checkthattheblade,itsattachmentbolts
anddriveshaftarenotdamagedorexcessivelyworn.Nevertrytostraightenabent
blade.Replaceadamaged,wornorbentbladeassoonaspossible.Useonly
genuineSANLIpartsorthoseapprovedbySANLI.Excessivevibrationwhenmowing
isagoodindicationofaproblemwiththecuttingsystem.
WARNING:Vibrationfromabentordamagedbladecancausecostlydamage
tothemower.Workingwithanexcessivelywornbladewastesfuelandcan
leadtoinjury.

Sharpeningtheblade
Forbestmowingresults,havetheedgessharpenedandthebladebalancedat
leastonceayearbyaspecialistservicedealeroragent.

Removingtheblade
Wearappropriateprotectiveglovestopreventpossibleinjurywhenhandling
theblade.Disconnectthesparkplugcapandtiltthemoweronitssidewith
airfilterandcarburettorsideuppermost.
Holdingthebladefirmlyinonehand,useaspannerorsockettoloosenthe
bladebolt.

User’s Manual / 16
Mountingtheblade
Wearappropriateprotectiveglovestopreventpossibleinjurywhenhandling
theblade.Disconnectthesparkplugcapandtiltthemoweronitssidewith
airfilterandcarburettorsideuppermost.
Checkthatallcomponents(theblade,key,bladeholder,screwsandwashers)
arepresent,cleanandingoodcondition.
Positionthebladeonitssupportwiththecoolingfinsfacingtheengine.
Checkthecorrectalignmentandmatchingofpadswiththeblade.Theblade
mustbepositionedpreciselyonitsstand.
Tightenthescrewsconnectingallofthecomponents.Makeafinalvisual
checkthatallpartsarepresentandalignedbeforetighteningthefixingbolt
veryfirmlywithawrenchwhileholdingthebladefirmlyinonehand(NB
wearsuitablegloves).

Sparkplug

Checkthesparkpluginitiallyafterthefirstfivehoursof
moweruse.Thereafter,maintenanceofthesparkplug
shouldtakeplaceevery25hours.
Removethesparkplugcap(Fig.21)andthenremovethe
sparkplugwiththewrenchprovided(Fig.22).
Cleanoffanycarbondepositsusingacopperbrushand
checktheelectrodegapwithafeelergauge(thegap
shouldbe≈0.7mm).
Replaceandretightentheservicedsparkplugand
replacethecap.
Ifthesparkplugiswornordamaged,replacewithanew
sparkplugofthesameorsuitabletypefortheengine.Ifindoubt,contacta
SANLIappointeddealer.

AirFilter

Anairfilterinpoorconditionwillreducethe
performanceandlifeoftheenginewhilemakingit
hardertostart.Regularchecksarethereforeessential,
especiallywhenusingthemowerindustyconditions.
Checkandcleantheairfilterevery25hoursofuseor
moreofteniftheengineisusedinadustyenvironment.

User’s Manual /17
Removetheairfilterlid(Fig.23、Fig.24)andcarefully
removethefoamfiltercartridge.Cleanthecartridgein
asmallbowlofwarmwatercontainingafewdropsof
washing‐upliquiduntilitisperfectlycleanandfree
fromalltracesofgreaseanddust.Rinsethefilter
cartridgeincleanwaterandthensqueezegentlyto
removemostofthewater.Letitairdryuntilitiscompletelydry.
WARNING:Nevercleanthefoamcartridgeinpetrol,whitespiritorother
solvents.Theseproductswilldegradethefiltercartridge.
Cleanthecoverandinsideoftheairfilterwithacleanlint‐freecloth.Applya
uniformlayerofoiltotheoutsideofthecartridgefilterwithabrush(youcan
usecleanengineoilforthis).Insertthefiltercartridgeintoitshousingand
replacetheairfilterlid,ensuringthateachcomponentisinplaceand
properlyinstalled.Ifthefiltercartridgeisdamagedorisverydirty,replaceit
usingagenuineSANLIpart.
WARNING:Donottwistthecartridgetocleanfoam,asyoucoulddamageit.
TheSANLILSP510S9AandLSP510S9Bmowerisequippedwithadual
filtrationsystemcomprisingafoampre‐filterandacartridgefilterpaper.
Themaintenanceofafoampre‐filterisidenticaltothatofafoamcartridge
filter,asdescribedabove.Thecartridgefilterpapershouldbecleanedwitha
vacuumcleaner.Ifitisdirtyorcontaminatedwithoilorpetrol,replaceit.
Cleanthecoverandinsideoftheairfilterwithacleancloth.Evenlyapplya
thinlayerofoiltotheoutsideofthecartridgefilterwithabrush(youcanuse
cleanengineoilforthis).Replacethefiltercartridgeinitshousingandthen
replacethelidoftheairfilter,ensuringthateachcomponentisinplaceand
properlyinstalled.

EngineOil
Checkingtheoillevel
Positionthemoweronafirm,levelsurface.Unscrewtheoilleveldipstick
(Fig.12)andwipedry.Insertthedipstickuntilitreachesthefillerneck,butdo
notscrewin.Removethedipstickandchecktheoillevelholdingthedipstick
horizontal.Theoillevelshouldbebetweentheminimumandmaximumoil
levelmarksonthedipstick(Fig.13).Addoilifnecessaryandrepeattheabove
checkingprocess.Runningtheenginewithoutoilorwithtoolittleoilcan
causeseriousenginedamage.


User’s Manual / 18
Changingtheoil
Thefirstoilchangeshouldbecarriedoutafterthefirst5hoursofmoweruse.
Thereafter,changetheoilafterevery25hours’useoratleastonceayear.
Leavetheenginerunningoutdoorsforseveralminutestowarmtheoiland
makeitmorefluid.Warning:Partsoftheenginewillbecomeveryhotandcan
causesevereburns.
Removethesparkplugcapandunscrewtheoilleveldipstick.Placeasuitable
containerbeneaththemower’soilfillerpipeandtiltthemowerontoitsside
withtheairfilterandcarburettoruppermost.Allowtheoiltodrain
completelyintothecontainer.Returnthemowerontoitsfourwheelsandfill
theenginewithnewoilasdescribedinsection3.12
Note:Disposeofusedengineoilcarefully,responsiblyandinaccordance
withlocalornationalregulations.
Adjustingthetransmissioncable
Initstransmission‐engagedposition,themower’spowerdriveleverispushed
fullytowardsthehandlebar.Anincorrectly‐adjustedtransmissioncablecan
causeprematureweartothemower’sdrivesystem.
Ifthetransmissioncableistootight,itwillbedifficulttomovethepower
drivelevertowardsthehandlebar.Conversely,ifthetransmissioncableisnot
tightenough,thetransmissionwillfunctionpoorlyandlackdrive.
Toadjustthetensionofthecabletransmission,increase
orreducethelengthoftheadjustmentdeviceusingthe
wrench(Fig.25).Checktheeffectivenessofthe
transmissionandtheresistanceofthelever.Once
properadjustmenthasbeenreached,securethe
adjustmentdevicebytighteningthelocknuts.
Note:Thereshouldbeabout2cmoffree‐playbeforethepowerdrivelever
engagesdrive.Themowershouldbegintomoveforwardsgraduallyfrom
thatpointonwards.
