Sanwa Hydrotech META MTFO User manual

Manual No.MTFO01C(E)/1506ATEX
Original Instruction
INSTRUCTION MANUAL
This instruction manual is for the person who actually operates the pump.
Please be sure this manual is provided to and understood by the operator
on the scene. If the instruction manual is also needed by personnel who
install the pump or by a staff of a plant constructor, please let us know. We
will supply another copy.
Machine Number Code Lot Number
To the on-site operator: please enter the pump’s code and lot number above and for future parts
order and inquiry.
SANWA HYDROTECH CORPORATION
STAINLESS STEEL MAGNET DRIVE PUMP
META SERIES
MTFO/MTFO-L/MTFO-H
Requirements

1
Introduction
Thank you very much for selecting a Sanwa Magnet Drive Pump. Our pumps
are manufactured under strict quality control standards to ensure that your
pump is in perfect operating condition. Improper handling or operation could
however inhibit the pump’s performance or lead to accidents. To use your
Sanwa Magnet Drive Pump in the manner for which it was designed, be sure to
closely follow the instructions contained herein. The instruction manual should
be kept in a safe place where it can be referred to whenever necessary.
For information concerning handling and operation of the motor, refer to the
instruction manual for the motor.
Safety
 Sanwa Hydrotech does not assume responsibility for damage or injury re-
sulting from failure to follow the safety instructions contained herein. Be
sure therefore to follow the instructions for safe and correct usage when op-
erating, performing maintenance, or inspecting the pump.
 The degree of potential danger as a result of improper handling or operation
is indicated by the following three classifications:
Situation where improper handling or operation would almost certainly
result in death or serious bodily injury.
Situation where improper handling or operation could result in death or
serious bodily injury.
Situation where improper handling or operation could result in bodily
injury or equipment damage.
Situation where improper handling or operation in hazardous location
could result ignition or explosion.
 Items indicated by could also lead to serious consequences ac-
cording to the circumstances. Be sure therefore to strictly observe items in-
dicated by any of these labels.

2
General
 Do not use the pump in the presence of explosive gas or powder. You may
cause an injury or start a fire.
 Do not use the pump to pumping a liquid with a low flash point or ignition
temperature.
 Be sure to turn the power off before performing any type of maintenance,
repair or inspection. Failure to do so could result in electrical shock.
 Use the material which is suitable to specification of liquid. Otherwise
leakage occurs.
Operation
 Absolutely do not touch or come close to turning parts. Doing so could result
in injury caused by entanglement in the rotating parts.
 In case of power failure, be sure to turn the power off to prevent the pump
from starting unexpectedly when the power is restored.
Maintenance and Inspection
 Be sure to connect the power cable in accordance with instruction manual
for the motor and the connection diagram in the terminal box. Failure to do
so could result in electrical shock or fire.
 Magnet drives cause strong magnetic fields. Persons with a pacemaker
should not stay close to the magnet drive or come into close bodily contact
with parts of it.

3
General
 If using in connection with the food processing, be sure to keep the pump
clean by washing. Failure to do so could enable germs to develop in the
pump.
 Do not insert your fingers or any other objects in the openings of the pump
motor. Doing so could result in electrical shock, injury or fire.
Installation and Adjustment
 Absolutely do not place inflammable materials in the area surrounding the
pump. Doing so could result in fire.
Operation
 Be careful of rotating parts.
Do not insert your fingers, etc., in the openings of the frame adaptor while
the pump is operating. Touching turning parts could result in injury.
Disassembly and Assembly
 Be careful with hazardous liquids.
If pumping dangerous chemicals, be sure to drain and wash well before
disassembling. A small amount of fluid may however remain in the screw,
faucet joint and engaged parts inside the pump.
If handling hazardous chemicals, be sure to wear protective equipment
such as glasses and rubber gloves, and proceed with caution while disas-
sembling the pump.
 Be careful not to get your hands or fingers pinched by machine parts.
Parts may be strongly attracted by magnetism when disassembling or as-
sembling the magnet coupling. Be careful not to let your hands or fingers
get pinched by magnetized parts.

4
General
 Transport, installation, piping and wiring connections, operation, adjust-
ment, maintenance and inspection should be carried out by qualified per-
sonnel. Having unqualified personnel perform these tasks could result in
electrical shock, injury or fire.
 Be sure to use only a power source of the voltage indicated on the name
plate of the motor. Not doing so could result in electrical shock, injury or
equipment damage.
 Do not use a damaged motor. Doing so could result in injury or fire.
 The customer should not modify the pump under any circumstances. Doing
so could result in an unexpected accident. Sanwa Hydrotech shall not be
responsible for accidents or damage resulting from equipment modified by
the customer.
 Do not block name plate or warning labels from view.
 Do not remove the name plate or warning labels.
Transport
 Beware of equipment falling or turning over during transport. Be sure to
use the hanger bolt if the pump is equipped with one. After installation,
however, you should avoid hoisting the entire machine by the hanger bolt.
Before lifting, check the weight of the pump by referring to the catalog, etc.
Do not lift a pump which exceeds the rated weight of the hoist. Doing so
could result in injury or equipment damage caused by bolt damage, falling
or turning over.
 The pump bearing is made of extremely rigid material, and cannot endure
rigorous vibration. The pump should be handled with care during
transport. The pump should also be handled with care when installing.
Unpacking
 Check the top and bottom of the package before unpacking. Failure to do so
could result in injury.
 Check the delivery specifications and name plate to make sure the mer-
chandise is as ordered. Installing the wrong equipment could result in in-
jury or equipment damage.

5
Piping and Wiring
 Be sure to connect the power cable in accordance with instruction manual
for the motor and the connection diagram in the terminal box. Failure to do
so could result in electrical shock or fire.
 Do not forcibly bend, pull or crimp the power cable or motor lead wires.
Doing so could result in electrical shock.
Installation and Adjustment
 Be sure to connect the earth terminal securely. Failure to do so could result
in electrical shock.
Operation
 Do not operate with the terminal box cover off. After wiring, be sure to re-
place the terminal box cover in its original position. Failure to do so could
result in electrical shock.
 Beware of high temperatures.
If handling high temperature fluids, do not place your hands, etc., near the
casing or frame adapter. Doing so could result in skin burning.
 Do not operate the pump to pumping gases. This pump is designed to pumping
liquids. Otherwise, the pump may have a high temperature or SiC bearings and
the rear casing shell may be broken.
 No-Load Operation
Absolutely do not operate the pump without a load. Doing so will cause the
inside to heat up and damage the bearings. Never operate the pump with-
out liquid inside of the pump. (This applies to when checking rotation di-
rection as well.) If heat is produced in the can, the temperature rises may
cause magnetism to reduce.
 Shut-Off Operation
Do not perform shut-off operation for more than one minute. Doing so will
cause a radical rise in temperature of the liquid in the pump, and could
result in an accident.

6
General
 The magnetic pump is designed for liquid only.
 If the pump is modified or changed without authority and/or other than
original spare parts are used for repair works, the explosion protection will
be forfeited.
Inadmissible mode of operation
 Driving motor must have approval for the use in areas subject to explosion
hazards.
Temperature limits
 When being operated to its designated use, the pump’s maximum surface
temperature must not exceed the temperature category of the explosion
protection zone.
Speed limits
 The maximum allowable speed is 3600rpm. If the pump is operated a speed
exceeding the maximum speed, explosion protection is no longer granted.
 Prior to operating the pump unit with a frequency converter it must be
checked, whether the driving motor is appropriate for that purpose.
Disassembly and Assembly
 Ensure that the driving motor and/or the entire equipment have been ap-
proved for the prevailing explosion protection zone.
 Instruction given in the operation manuals of the driving motor is to be
observed.
 If the pump is fitted with a heating jacket, the temperature of heating me-
dium must not exceed the maximum allowable surface temperature of the
pump.
Operation
 When a pump is operated which has not been completely filled, an ignition
source can develop due to heat input. The pump must be completely filled.
If cannot ensure that, appropriate monitoring must be taken.
 When the pump is operated in the closed circuit system, the temperature of
liquid and the surface of the pump will be increased. Use the monitor to
prevent the pump from excessively heating up.

7
 The situations below will increase the temperature of the pump surface. Do
not operate the pump these situations.
･Shut-off operating ･Low-flow operating ･Dry running
･Operating with “decoupling”
･Operating with “circulation-hole of casing cover and shaft is interrupt-
ed”
Maintenance
 If the clearance between rotating and stationary components is out of lim-
itation, it may happen that these component contact and resulting fric-
tional heat entail excessive temperatures.
 Ensure that the bypass-hole of casing cover and shaft is not interrupted.
 Ensure whether pump parts are not corroded. If corrosion occurred, exam-
ine the change of material. Give priority to experience on selection of ma-
terial.
To Prevent sparks
 To avoid the potential hazards from random induced current generating a
spark, the earth contact on the pump and motor must be used.
 To avoid electrostatic charge, do not rub non-metallic surfaces with a dry
cloth. Make sure the cloth is damp.

8
Contents
Introduction for safety
● Instructions for Safe Usage ............................................. 10
Equipment Failure / Accident Prevention and
Safe Operation Checks .................................................................... 10
Precautions When Pumping Special Liquids ................................... 11
● Transport and unpacking ................................................. 12
1. Transport ...................................................................................... 12
2. Unpacking .................................................................................... 12
● Preliminary Check ............................................................ 13
● Pump model identification ............................................. 14
1. Impeller Type ............................................................................... 14
2. Liquid Temperature Selection Guide ............................................ 14
3. Pump Size ................................................................................... 14
4. Magnet Type ................................................................................ 16
● Pump Specification .......................................................... 16
1. Design Pressure .......................................................................... 16
2. Casing Piping Connection ........................................................... 16
3. Viscosity ....................................................................................... 16
4. Motor ............................................................................................ 16
5. Parts Specifications of Each Liquid Temperature Range ............. 17
6. Ambient Temperature ................................................................... 17
7. Speed Limit .................................................................................. 17
8. Maximum and Minimum Flow Rate ............................................. 17
9. Temperature Classification .......................................................... 17
10. Marking ...................................................................................... 18
● Declaration Conformity .................................................... 19

9
● Pump Installation .............................................................. 21
1. Installation .................................................................................... 21
2. Piping ........................................................................................... 21
3. Wiring ........................................................................................... 22
4. Earthing ....................................................................................... 23
5. Cover ........................................................................................... 23
● Operation ........................................................................... 24
1. Pre-Operation Inspections (Be sure to turn the power
off before performing inspections!) .............................................. 24
2. Operation ..................................................................................... 24
Operation and handling ............................................................................ 25
3. Shutting Down ............................................................................. 28
● Maintenance and Inspection ............................................ 29
1. Routine Inspection ....................................................................... 29
2. Configuration and Location of Part .............................................. 30
Parts ......................................................................................................... 30
Configuration ............................................................................................ 31
3. Order of Disassembly and Assembly ........................................... 34
4. Checking parts dimension and clearance gap ............................. 37
5. Optimal Tightening Torque for Bolts and Nuts ............................. 39
● Troubleshooting ................................................................ 40
● Repairs and Warranty ....................................................... 42

10
● Instructions for Safe Usage
 In order to use your Sanwa Magnet Drive Pump in the manner for which it
was designed, be sure to read through and get a thorough understanding of
the contents of this manual and the installation instructions before at-
tempting to install, operate, perform maintenance or inspections. You should
also have a good understanding of the equipment itself, matters concerning
safe operation and handling, and other matters requiring attention before
attempting to use the pump.
Equipment Failure / Accident Prevention and Safe Operation Checks
 Pre-Operation Checks
The power source, wiring and connection, piping, priming, air purging and
rotation direction should be checked before starting operation.
 Checks for Test Operation and Actual Operation
Current, voltage, suction pressure, discharge pressure, and discharge flow
rate should be checked when starting test or actual operation. The pump
should also be checked for vibration, abnormal noise and leaks when opera-
tion is started.
 Be sure to take special precautions when performing test operation
checks if using hazardous, explosive or inflammable liquids.

11
Precautions When Pumping Special Liquids
 Sanwa pumps are used in various industries. Our stainless steel magnet
drive pumps in particular are frequently used for pumping hazardous liquids,
and fluids which tend to produce food germs. Mishandling in any of these
cases could lead to serious consequences such as bodily injury, loss of life or
property damage. To prevent these from occurring, you should get a thorough
understanding of the information contained herein and use the pump in the
manner for which it was designed.
 Special care and safety equipment are required for the following types of
liquid:
 Liquids which could produce a chemical reaction
 Liquids which could produce germs in connection with food
products, and liquids which are of a dangerous nature
 Liquids which could directly harm the human body
 Preventative measures should be taken to protect special pumps and pumps
used in the main production line from natural disasters, unexpected acci-
dents or equipment failure, the event of which could have a disastrous effect
on your production. If these are impossible, you should keep a spare pump on
hand for emergency use. (A pump with a suitable motor unit will be better.)

12
● Transport and unpacking
1. Transport
 When transporting the pump, be careful not to drop it or let it fall. Take
the appropriate method, such as picking up by two people or lifting by
belt, to avoid risk.
 Make sure the eyebolts (if the pump is equipped with them) are used to
secure the pump during transportation. However, do not use the pump’s
eyebolts to lift a machine after the pump is mounted on it. In case of no
the eyebolt, sling around the pump frame adapter and the motor. Before
suspending the pump, refer to leaflet or drawings to check the weight of
the pump and the motor. Never lift a pump that exceeds the rated load of
your suspension device. If you fail to heed this advice, the eyebolts may
be distorted, and the pump may drop or fall, and this may cause an injury
or damage the pump.
 The pump bearing is made of extremely rigid material, and cannot endure
rigorous vibration. The pump should be handled with care during
transport. The pump should also be handled with care when installing.
2. Unpacking
 Check the top and bottom of the package before unpacking. Failure to do
so could result in injury.
 Check the delivery specifications and name plate to make sure the mer-
chandise is as ordered.
Installing the wrong equipment could result in injury or equipment dam-
age.

13
● Preliminary Check
When your pump is delivered, you should check the following items:
 Are all of the accessories included in the package?
 Check the name plate to make sure the merchandise is as ordered.
 Check to make sure the pump has not been damaged or the bolts and
nuts loosened during transport.
If you discover any accessories to be missing or you find something wrong with
the merchandise, please contact your dealer or you may contact us directly.
MAT’L ：Material of pump parts(wet parts)
DATE：Manufactured year and month
TYPE：Pump type and size – Suction/Discharge/nominal impeller Dia.
（See next page）
ATEX marking：see Page.18
Nameplate of pump

14
● Pump Model Identification
MTF O －H 40X25-160 W
1 2 3 4
PUMP TYPE PUMP SIZE MAGNET
COUPLING TYPE
1. Impeller Type
O : OPEN IMPELLER
2: Liquid Temperature Selection Guide
(BLANK) : STANDARD MODEL
－L : LOW TEMPERATURE MODEL
－H : HIGH TEMPERATURE MODEL
TYPE Min. LIQUIDS
TEMP. (℃)
Max. LIQUIDS
TEMP. (℃)
MAGNET
MATERIAL
CONSTRUCTION
(BLANK)
－30 +150 Nd
－L －80 R.T. Nd Nitrogen purge
port
－H R.T. +280 SmCo Fin type frame
adapter
※When temperature fluctuate between extreme high and low, please
consult your distributer.
3: Pump Size
40 X 25 － 160
SUCTION SIZE DISCHARGE SIZE NOMINAL
(mm) (mm) IMPELLER SIZE
(mm)

15
PUMP
SIZE
SUCTION
SIZE (mm)
DISCHARGE
SIZE (mm)
MOTOR
(kW)
MOTOR
FRAME
40x25-160 40 25
3.7～22 112M～
180M/L
40x25-200
50x40-160
50 40 50x40-200
50x40-250
80x50-160 80 50
80x50-200
80x50-250 80 50
100x80-160 100 80
100x80-200 100 80
4. MAGNET TYPE
W : W TYPE COUPLING

16
● Pump Specification
1. DESIGN PRESSURE
DESIGN PRESSURE
(MPa) at 150℃
MTFO
MTFO-L
MTFO-H
40x25-160
1.4
40x25-200
1.2
50x40-160
1.0
50x40-200
1.2
50x40-250
1.4
80x50-160
1.0
80x50-200
1.2
80x50-250
1.4
100x80-160
1.2
100x80-200
1.2
2. Casing Piping Connection
Suction and Discharge：JIS 10K RF Flange (steel pipe flange JIS B 2220)
ASME 150lb RF Flange (ASME B16.5)
DIN PN16 Flange (Flanges and their joints EN1092-1)
Drain：Rc threads (taper pipe threads JIS B 0203/ISO 7-1)
3. Viscosity
≦300mPa・s
4. Motor
Rated Power :3.7kW to 22kW
Frame Size:112M to 180M/L

17
5. Parts Specifications of Each Liquid Temperature Range
RANGE
Parts (BLANK)
(−30～+150℃)
−L
(−80℃～R.T.)
−H
(R.T.～+280℃)
CASING
COVER
&
REAR
CASING
STANDARD MODEL
(with O ring)
EXTREME TEMP. MODEL
(without O ring)
SHAFT STANDARD MODEL HIGH TEMP. MODEL
MAGNET
COUPLING
STANDARD MODEL
(MAGNET：Nd
The mark includes the letter of “N”.
e.g. W20N , W36N)
HIGH TEMP. MODEL
(MAGNET：SmCo
The mark includes the
letter of “H”
e.g. V40H , V25H)
FRAME
ADAPTER
STANDARD MODEL LOW TEMP.
MODEL
(with N2 purge
port “Rc3/8”)
HIGH TEMP. MODEL
(with radiator fin)
Note： When temperature fluctuates between extreme high and low, please
consult your distributer.
6. Ambient Temperature
Ambient temperature: min. －20 ～ max. 40 degree C
7. Speed Limit
Operating speed: max. 3600 rpm
8. Minimum and Maximum flow rate
Minimum Flow rate: see “data sheet”
Maximum Flow rate: 1.1 x Qopt
※Qopt = Flow rate at Best Efficiency Point
9. Temperature classification
Refer to the following table for maximum allowable temperature of the pumped
liquid in accordance with the applicable temperature category.

18
The maximum surface temperature of the pump is the highest temperature
ascertained from any one of the following conditions:
1. the temperature of the liquid plus, 20℃
2. the temperature of the ambient temperature, plus 20℃
Thus, the maximum liquid temperature for each temperature class is below.
In case of categories T5 or T6,contact us for further information.
10. Marking
An example of ATEX equipment marking is shown blow. The actual classi-
fication of the pump will be engraved on the name plate.
For Gas atmosphere
Ⅱ 2 G c ⅡC T3/T4
① ② ③ ④ ⑤ ⑥
①Equipment Group ：Ⅱ (non-mining)
②Category ：2
③Gas：G
④Protection measure：c construction safety
⑤Gas Group：ⅡC
⑥Temperature Class：(see above chapter 9) It depends on the temperature of
pump liquid and ambient temperature.
For Dust atmosphere
Ⅱ 2 D c T＊℃
① ② ③ ④ ⑤
①Equipment Group ：Ⅱ (non-mining)
②Category ：2
Temperature class Maximum temperature of liquid
T1 280℃ (536°F)
T2 270℃ (518°F)
T3 175℃ (347°F)
T4 110℃ (230°F)

19
③Dust： D
④Protection measure：c construction safety
⑤Maximum surface Temperature：(see above chapter 9) It depends on the
temperature of pump liquid and ambient
temperature.
Declaration of Conformity
