Sanyo QUIK N EASY User manual

Use Componentor HDMI connections,and a High Definitionsource for
the best picture possible. Your AV equipmentOutput Jacks must be
connected to the HDTV’s Input Jacks. Always match the color of the
jacks and connectors.
QUIK ‘N EASY
Setup Guide
Attach the Stand Base to the HDTV.
Simple step by step procedures for correct HD hookups
and initial setup process.
Hookup your Audio/Video equipment to the HDTV.
Hook up your antenna or direct Cable service.
An indoor antenna should be placed at least 3 ft away from the HDTV.
For additional information, consult your HDTV’s owner’s manual.
For the best HD experience, be sure to use HD devices and/orHD off-air
signals transmitting HD content.
CONNECTION TYPE CABLE/CONNECTOR IMAGE QUALITY
Composite
Off-air HD signal or Digital Cable
HDMI
BEST
BEST
BETTER
GOOD
Component
HDTV’s bottom panel
COMPONENT/AV IN
may be used with
either Composite or
Component cables.
NOTE: See owner’s
manual for more
details
HDTV’s side panel
ANTENNA OR CABLE

Use the Setup Wizard to select your HDTV’s location.
Perform a Signal search.
Use the POWER key to turn on your HDTV.
Connect the AC cord to power outlet.
HDMI, the HDMI Logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
Aim Remote at the lower
left corner of the HDTV.
Press the CURSOR UP/DOWN key to select Antenna, Cable, or Set Top Box.
Press the CURSOR ENTER key to enter the next step, and then start a
Channel search for digital and analog channels.
For the first time after powering on your HDTV, the Setup Wizard appears.
Press the CURSOR UP/DOWN key to select Home Mode or Shop Mode.
NOTE: Selecting Home Mode will qualify as an Energy Star rating.
Please allow the HDTV a few minutes to complete the process.
Setup Wizard (1/5)
Cancel
Please select Home/Shop
Home mode default settings are recommended for
in-home use. ENERGY STAR®qualified.
Shop mode is intended for in-store display and resets
video settings at Power On.
Select
Home Mode
Shop Mode
Move ENTER
Setup Wizard (2/5)
Please select TV RF tuning band
Move Select
Antenna
Cable
Set Top Box
P revious Cancel
ENTER
Setup Wizard (3/5)
Please check that the RF cable is connected properly.
Scan time may take over 20 minutes.
Move Select
START
P revious Cancel
ENTER
Setup Wizard (4/5)
Searching CH
Digital Channels Found
Analog Channels Found
Channel 4
8
8
Searching. Please wait
Select
Cancel
50%
ENTER
Setup Wizard (5/5)
Congratulations. TV Setup is done.
Exit EXIT
Finalize the completed Setup process.
Choose the correct Input source.
Direct TV
Dish Network
Comcast
Cox
Verizon
ATT
10154, 960 (to activate INPUT feature)
590, 683, 589, 542, 652
10154
0154, 0088
0181, 0826, 0920
1045, 1062, 1095, 1380
Si necesita ayuda en ESPAÑOL, marque al 1-800-877-5032 y un asesor
estará dispuesto a ofrecerle ayuda con cualquiera de sus dudas.
NOTE: If you receive Satellite or Cable service through a set
top box, tune to the correct input on your HDTV and use the
receiver and its remote for channel viewing.
Use the INPUT key on your remote control to select from
the available Input sources on your HDTV.
Please allow the HDTV a few minutes to complete the process.
Use the EXIT key to finish the Setup Wizard.
You can now watch and enjoy TV programming on your HDTV!
Use the following codes to program your cable or satellite provider’s
remote control to work with your new HDTV.
NOTE: If these do not work, refer to your Cable or
Satellite manual.
