SC2000 LGR1556X User manual

4. Dimension
5. Models for selection
Beam Angle Viewing distance (850nm)
15° 340m
30° 260m
45° 180m
60° 130m
90° 100m
Viewing distance is tested by 1/3”Sony CCD camera. To achieve the distance
needed, please pay attention to your camera specification and lens before
purchase. It is normal phenomenon that distance may vary due to different cameras
and lens.
Our product is weatherproof and dustproof. Do not modify the shape, dismantle or
reconfigure the product, any inflow of water cause by which are not be responsible for
warranty repair.
Instruction of IR Illuminator
Please strictly follow the below instructions when install this product!
a: 261mm b: 202mm
c: 90mm d: 262mm
e: 54mm f: 24mm
g: 8mm h: 33mm

1. Description
• Accurate constant circuit drive develops excellent performance of LED;
Using high power LED, high efficacy and long service life;
• Improve performance of camera to get better pictures at night time.
• Fill Light for night vision camera
• Indoor/Outdoor use
• Easy installation
2. Specification
Quantity of LED 24PCS 2W High Power IR LED
Wavelength 850nm
BeamAngle 15°- 90°
Viewing Distance 340m-100m
Day/night Switch Auto
Working Voltage AC110-220V
Power consumption 48W
Panel Tempered glass panel
Housing Aluminum Die Casting Housing
Bracket Mount bracket
Working temperature -30℃to +55℃
Protection Level IP66
Color Beige
N.W 2.2 KG
G.W 2.5KG
Dimension 261*202*90mm
Packing dimension **mm
3. Installation
1. Installation Graph
2. Real Photos
Night time with IR Illuminator Night time without IR Illuminator
Light
Camera
Light
Camera
