SCHAKO | Ferdinand Schad KG Phone +49 (0) 7463-980-0
Steigstrasse 25-27 Fax +49 (0) 7463-980-200
D-78600 Kolbingen www.schako.com| [email protected]
Contents
General information ................................................... 2
Designated use ........................................................... 2
Construction ............................................................... 2
Adjusting the grille length .......................................... 3
Replacing the blades ................................................... 4
MOUNTING INSTRUCTIONS
GRILLE LENGTH ADJUSTMENT AND BLADE
PA-R
Roll-down grille
PA-R – Roll-down grille
MOUNTING INSTRUCTIONS
General information ꟾ Designated use ꟾ Construction
Construction subject to change.
No return possible. Version: 18.02.2021 | Page 2
GENERAL INFORMATION
Prior to installation, please read completely through this man-
ual.
Cement will damage the grille surface. Keep the roll-down
grille in the original packaging until it is installed. Before insert-
ing the grille, the frame in the floor must have been completely
mounted.
The inspection and installation of the grille must be carried out
by qualified skilled personnel only in compliance with the cur-
rent regulations.
If, after reading through the manual, you have further ques-
tions, please contact the manufacturer or the local sales office.
WARRANTY
The device warranty will be for two years starting from the
handover date and shall apply to all production faults.
Also excluded from the warranty is damage caused by compo-
nents that are not part of the device itself.
The warranty only covers the return and replacement of de-
fective materials.
LIMITATION OF LIABILITY
SCHAKO shall not give any warranty for damage resulting from:
--- Improper use caused by ignoring the instructions given in
this manual
--- Non-observance of the operating conditions of the de-
vice.
--- Installation and maintenance by personnel without
proper qualification.
--- Improper use of the device or operation under conditions
not conforming to the manual.
RECYCLING
SCHAKO recommends to recycle the device compo-
nents at the end of service life of the device as
much as possible or reuse them. Components that
cannot be recycled must be properly disposed of by
an authorized disposal company in accordance with
current legal regulations.
REQUIRED MATERIALS AND TOOLS
--- Measuring tape
--- Crosshead screwdriver
--- Holding tongs
--- Pincers
DESIGNATED USE
The SCHAKO roll-down grille is a walk-on grille for installation
in convectors and floor ducts
Suitable for the interior use in non-corrosive areas.
On demand, a special version for the use in swimmings pools
is available. The grille cannot be used in areas surrounded by
or in contact with water (danger of slipping).
CONSTRUCTION
Grille with anodised aluminium blades and a free cross-section
of approx. 70%.
IDENTIFICATION OF THE COMPONENTS
① Blade
② Spacers
③ Lag screws
④ Spring
NOTE
If the grille is delivered rolled up, it is possbile that the length
directly after unpacking is larger than the ordered length. After
some hours, the grille will return to its predefined length.
①
③
②
④
PA-R – Roll-down grille
MOUNTING INSTRUCTIONS
Adjusting the grille length
Construction subject to change.
No return possible. Version: 18.02.2021 | Page 3
ADJUSTING THE GRILLE LENGTH
Step 1: Loosen the spring
NOTE
If several holding tongs are available, the procedure can be carried out more
quickly by processing all the springs at the same time.
• Mesure the length of the frame on which the grille is to be placed.
• Adapt the holding tongs to the spring diameter.
• Separate the blades which are located in the exceeding part of the grille.
• Fasten the spring with the holding tongs.
Step 2: Remove the components
• Unscrew the screw.
• Remove the screw, the spacers and the desired blades.
NOTE
Do not dispose of the first blade removed! This is the only one
provided with a counterbore and will be inserted again at the
end of the process.
Step 3: Adjust the length
• Cut off the protruding part of the spring.
Step 4: Insertion
• Insert the removed blade and make sure that the counterbore points to the
outside.
• Insert the lag screws and tighten them.
• Loosen the holding pliers.
Step 6: Repeat the procedure for the other springs
• Repeat the procedure for the other springs (if a simultaneous processing was
not possible).
• If the tension between the springs must be increased, the lag screw can be ad-
justed at the end of the process.
PA-R – Roll-down grille
MOUNTING INSTRUCTIONS
Replacing the blades
Construction subject to change.
No return possible. Version: 18.02.2021 | Page 4
REPLACING THE BLADES
Step 1: Loosen the spring
NOTE
If several holding tongs are available, the procedure can be carried out more
quickly by processing all the springs at the same time.
• Adapt the holding tongs to the spring diameter.
• Tension one of the springs and separate the blade to be replaced from the rest.
• Fasten the spring with the holding tongs.
Step 2: Remove the components
• Unscrew the lag screws.
• Remove the lag screws, spacers and the desired blades.
NOTE
Do not dispose of the first blade removed! This is the only one
provided with a counterbore and will be inserted again at the end
of the process.
Step 3: Replace the defective blades
• Insert the new blades at their position.
Step 4: Insertion
• Insert the spacers and the blades that are not defective. At the end, insert the
blade with counterbore!
• Insert the lag screws and tighten them.
• Loosen the holding pliers.
Step 4: Repeat the procedure for the other springs
• Repeat the procedure for the other springs (if a simultaneous processing was
not possible).
• If the tension between the springs must be increased, the lag screw can be ad-
justed at the end of the process.
