Schebler eVent Series User manual
series
venting systems
for high efficiency
appliances
SUPERIOR SYSTEM DESIGN
eVent™DualSeal™with RapidLock™Connection System is a modular
double wall prefabricated vent and exhaust systems used in venting
high efficiency appliances that require a positive, neutral or negative
draft exhaust. The Patent Pending joint connection system ensures
quick and leak free connection with the industry’s highest pressure
rating. Connections are sealed with factory-applied gaskets and
pressure tight v-bands designed specifically to handle the temperature
and corrosive condensate produced by high efficiency appliances.
eVent™is a double wall product that utilizes AL 29-4C®or 316L inner
liner providing exceptional corrosive resistance meeting appliance
manufactures warranty requirements. A 1" air gap between the inner
and outer shell provides low clearance to combustibles and insulation
properties to improve natural draft. Schebler also offers 2" insulated
product, eVent™PLUS2, that provides enhanced insulation properties,
see eVent™PLUS2 brochure for more information.
LISTINGS AND VENTING APPLICATIONS
The Schebler eVent™DualSeal™leak free system is tested and listed
by Underwriters Laboratories Inc. (UL) under file number MH10056
for UL 1738 and ULC S636-95 vent. eVent™is a double wall special
stainless steel venting systems for gas fired appliances listed as
Category II, III, and IV with a maximum flue gas temperature of
550˚F, and 40" w.c. positive pressure. Gas vent - BH, Class I /
Class II - 245˚C.
COMPLETE LINE OF FITTINGS AND SIZES AVAILABLE
The eVent™series is available in even and odd diameters ranging
from 5" to 48". A complete line of straight sections, variable lengths,
tees, elbows, stack terminations, roof penetration components and
support members are offered. In addition to the standard components,
virtually any conceivable fitting is available as a special order item.
MATERIAL AVAILABLE
eVent™is available in a variety of materials allowing the proper
material selection for your specific application. The standard product
features AL 29-4C®or 316L stainless steel liner and a 430 stainless
steel outer shell.
SUPPORT LIMITS
Support plates and wall supports are utilized to support the weight
of the vent. In horizontal runs, supports should be placed adjacent
to fittings that are not otherwise supported. See the individual part
description for allowable support charts.
UNIQUE FEATURES
The eVent™series offers unique features that no other vent
manufacturer can provide.
• DualSeal™with RapidLock™Connection System
- Factory-applied gasket designed specifically for exhaust systems
- Superior flange to flange joint connection
- Greater sealing surface than male/female gasket designs
- Quick install v-band
- One piece/hinged design
- No loose bolts/nuts to install
• Pressure Rated at 40" w.c.
- Reduces risk of leakage
• Longest Straight Sections up to 59"
- Reduces installation time / cost
• Greater Distance Between Supports
- Reduces installation cost
- Solution to design challenges
• Union Made Product
• 3-Year Leak Free Guarantee
• Lifetime Warranty
SCHEBLER VALUE
• Fast Project Completion
- 2-week lead time (vs. industry standard 3-6 weeks)
- Trouble-free installation / detailed instructions
- No application of sealant required
• Maximum Strength / Long Life
- Unmatched dimensional accuracy for secure joint
connections
- Fully welded liners and shells
- Unequalled support limits
• Complete System Design
- CAD drawings
- 3D design solutions
- Complete BOM
- System sizing
• Special Fittings
2
To purchase or schedule a demonstration of the eVent™
with Connection System, call 563.359.0110 or visit
scheblerchimney.com/find-a-distributor/ to speak with a Schebler
Distributor today.
Dual
Seal
RapidLock
OPERATING TEMPERATURES AND
CLEARANCES CHART
eVent™and eVent™PLUS have been tested and listed for a maximum
flue gas temperature of 550°F, and ULC-S636-95 for gas vent-BH,
Class I / Class II - 245°C. The clearances shown are from the shell
to combustibles.
eVent™Series Clearance to Combustibles
Section Inside 550˚F
Diameter (288˚C)
5"-6" 1" (25mm)
7"-8" 1" (25mm)
9"-10" 1" (25mm)
11"-12" 1" (25mm)
13"-14" 1" (25mm)
15"-16" 1.5" (38mm)
17"-18" 1.5" (38mm)
19"-20" 1.5" (38mm)
21"-22" 2" (51mm)
23"-24" 2" (51mm)
25"-26" 3" (76mm)
27"-28" 3" (76mm)
29"-30" 3" (76mm)
31"-32" 3" (76mm)
33"-34" 4" (102mm)
35"-36" 4" (102mm)
37"-38" 4" (102mm)
39"-40" 4" (102mm)
41"-42" 4" (102mm)
43"-44" 5" (127mm)
45"-46" 5" (127mm)
47"-48" 5" (127mm)
Clearance to non-combustible materials for all diameters and
applications is 0" (0mm).
JOINT ASSEMBLY
1. Join the non-gasketed flange to the gasketed/collared flange of the
next section. Install inner band around the two flanges, and use a
3/8” nut driver to tighten inner band around sections. Tap on inner
band with rubber or rawhide mallet to ensure a proper tight joint.
2. Rotate flange bolt into the corresponding notch of the clip and
tighten both flange bolts evenly until secure.
3. Place outer band around both sections covering the space between
the shells. The flanges on the outer band fit into the grooves on the
shells. Use a 3/8” nut driver to tighten into place.
3
Ensure factory supplied gasket is in place and in
good clean condition. Damaged or missing gaskets
should be replaced before flue is installed.
Contact your Schebler exhaust system distributor
for additional gaskets.
ADAPTER KIT (FLANGED)
Part No. BKF
The Adapter Kit (Flanged) is
used for securing pipe to a
flanged appliance outlet. Beam
clamps are provided for
connection of the flanges, or
the flange can be drilled in the
field to match the appliance.
Includes 1 inner band and 1 seal
ring to cover the gap between
the inner and outer shells.
4
VARIABLE LENGTH
SECTION
Part No. 21VS and 39VS
The Variable Section adjusts
to provide a fixed odd length
between two sections. The
minimum length is 7", the
maximum is 21" or 39". This
part does not provide for
thermal expansion.
Includes 1 long and 1 short
inner liner section with
gaskets, 1 rectangular
gasket, 1 liner securing
collar & 2 outer shell halves.
ADAPTER KIT
(UNIVERSAL)
Part No. UNAK
The Universal Adapter Kit is
used for securing pipe to an
unflanged appliance outlet.
Includes 1 inner band and
1 seal ring to cover the gap
between the inner and
outer shells.
ABRUPT INCREASER
Part No. AI
The Abrupt Increaser is
used to connect two sections
of different diameters in
a shorter space than a
tapered increaser.
Includes 1 inner band of
larger and smaller sizes
and 1 seal ring.
SYSTEM COMPONENTS
CUSTOM DIMENSIONS ARE AVAILABLE TO SUIT YOUR NEEDS IN EVEN AND ODD SIZES
45˚ LATERAL TEE
Part No. 45LT
The 45˚ Lateral Tee is used for
low flow resistance entry into a
stack or breeching.
Includes 2 inner bands and
2 outer bands.
I.D. A B C
5-6" 4 7⁄8" 18 3⁄8" 13 1⁄2"
7-8" 5 1⁄4" 21" 15 3⁄4"
9-10" 5 11⁄16" 23 7⁄8" 18 3⁄16"
11-12" 6 1⁄16" 26 11⁄16" 20 9⁄16"
13-14" 6 1⁄2" 29 1⁄2" 23"
15-16" 6 15⁄16" 32 5⁄16" 25 7⁄8"
17-18" 7 5⁄16" 35 3⁄16" 27 13⁄16"
19-20" 7 3⁄4" 38" 30 1⁄4"
21-22" 8 3⁄16" 40 13⁄16" 32 11 ⁄16"
23-24" 8 9⁄16" 43 5⁄8" 35 11 ⁄16"
25-26" 9" 46 1⁄2" 37 1⁄2"
27-28" 9 3⁄8" 49 5⁄16" 39 7⁄8"
29-30" 9 13⁄16" 52 1⁄8" 42 5⁄16"
31-32" 10 1⁄4" 54 15⁄16" 44 3⁄4"
33-34" 10 5⁄8" 57 13⁄16" 47 1⁄8"
35-36" 11 1⁄16" 60 5⁄8" 49 9⁄16"
37-38" 11 1⁄2" 63 7⁄16" 52"
39-40" 11 7⁄8" 66 1⁄4" 54 3⁄8"
41-42" 12 5⁄16" 69 1⁄8" 56 13⁄16"
43-44" 12 11⁄16" 71 15⁄16" 59 3⁄16"
45-46" 12 3⁄4" 74 3⁄4" 61 5⁄8"
47-48" 13 9⁄16" 77 9⁄16" 64 1⁄16"
Part No. 45LT
SPLIT RING
FLANGE
BEAM
CLAMP
RAW
END
SM. DIA. I.D.
LG. DIA. I.D. + 1
A
B
C
45°
2˚ ELBOW
Part No. 02L
The 2° Elbow is used with the
88° Elbow to create the correct
pitch to allow for condensate to
flow to a stack drain.
LENGTH
STRAIGHT SECTION
Part No. 11S, 23S,
47S and 59S
Standard lengths are as follows:
Diameter 5" - 24" is 11", 23",
47" and 59"
Diameter 25" - 48" is 11", 23",
and 47"
Custom parts can be manu-
factured to any length over 3".
Includes 1 inner band and
1 outer band.
Most high efficient
category IV appliances
have adapters that are
specific to that make and
model. Consult with your
local Schebler distributor
to verify your appliances
needs.
5
TAPERED INCREASER
Part No. TI
The Tapered Increaser is used when a change in pipe diameter is required.
Includes 1 inner and 1 outer band of both smaller and larger size.
REDUCING
45˚ LATERAL TEE
Part No. R45LT
The Reducing 45° Lateral Tee
is used for low flow resistance
entry into a stack or breeching
when the stack or breeching
is a larger size. Specify size of
branch required.
Includes 1 each inner band and
outer band for larger and smaller
opening.
Available in odd sizes.
Call for odd diameter taper increaser information.
I.D. A B A B A B A B
6" 8" 15" 10" 18" 12" 21" 14" 24"
8" 10" 15" 12" 18" 14" 21" 16" 24"
10" 12" 15" 14" 18" 16" 21" 18" 24"
12" 14" 15" 16" 18" 18" 21" 20" 24"
14" 16" 15" 18" 18" 20" 21" 22" 24"
16" 18" 15" 20" 18" 22" 21" 24" 24"
18" 20" 15" 22" 18" 24" 21" 26" 24"
20" 22" 15" 24" 18" 26" 21" 28" 24"
22" 24" 15" 26" 18" 28" 21" 30" 24"
24" 26" 15" 28" 18" 30" 21" 32" 24"
26" 28" 15" 30" 18" 32" 21" 34" 24"
28" 30" 15" 32" 18" 34" 21" 36" 24"
30" 32" 15" 34" 18" 36" 21" 38" 24"
32" 34" 15" 36" 18" 38" 21" 40" 24"
34" 36" 15" 38" 18" 40" 21" 42" 24"
36" 38" 15" 40" 18" 42" 21" 44" 24"
38" 40" 15" 42" 18" 44" 21" 46" 24"
40" 42" 15" 44" 18" 46" 21" 48" 24"
42" 44" 15" 46" 18" 48" 21" ~ ~
44" 46" 15" 48" 18" ~ ~ ~ ~
46" 48" 15" ~ ~ ~ ~ ~ ~
48" ~ ~ ~ ~ ~ ~ ~ ~
Part No. TI
I.D. A B C
5-6" 4 1⁄16" 16 3⁄4" 12 15⁄16"
7-8" 3 7⁄8" 18 3⁄16" 14 3⁄4"
9-10" 4 1⁄4" 21" 17 3⁄16"
11-12" 4 11⁄16" 23 7⁄8" 19 9⁄16"
13-14" 5 1⁄16" 26 11 ⁄16" 22"
15-16" 5 1⁄2" 29 1⁄2" 24 7⁄16"
17-18" 5 15⁄16" 32 5⁄16" 26 13⁄16"
19-20" 6 5⁄16" 35 3⁄16" 29 1⁄4"
21-22" 6 3⁄4" 38" 31 11⁄16"
23-24" 7 3⁄16" 40 13⁄16" 34 1⁄16"
25-26" 7 9⁄16" 43 5⁄8" 36 1⁄2"
27-28" 8" 46 1⁄2" 38 7⁄8"
29-30" 8 3⁄8" 49 5⁄16" 41 5⁄16"
31-32" 8 13⁄16" 52 1⁄8" 43 3⁄4"
33-34" 9 1⁄4" 54 15⁄16" 46 1⁄8"
35-36" 9 5⁄8" 57 13⁄16" 48 9⁄16"
37-38" 10 1⁄16" 60 5⁄8" 51"
39-40" 10 1⁄2" 63 7⁄16" 53 3⁄8"
41-42" 10 7⁄8" 66 1⁄4" 55 13⁄16"
43-44" 11 5⁄16" 69 1⁄8" 58 3⁄16"
45-46" 11 11⁄16" 71 15⁄16" 60 5⁄8"
47-48" 12 1⁄8" 74 3⁄4" 63 1⁄16"
Pa r t No. R4 5 LT
45°
A
B
C
LENGTH
A
I.D.
6
SYSTEM COMPONENTS
CUSTOM DIMENSIONS ARE AVAILABLE TO SUIT YOUR NEEDS IN EVEN AND ODD SIZES
Part No. 90Y
90˚ TEE
Part No. 90T
The 90˚ Tee is used to join
horizontal and vertical
sections, as well as to provide
for connection of drain or
inspection fittings. Use
either the drain tee cap
or the end cap for closure
of the unused opening.
Includes 2 inner bands and
2 outer bands.
Note: Grease tees available
1 ½" containment dam located
at one opening.
REDUCING 90˚ TEE
Part No. R90T
The Reducing 90° Tee is used
to join horizontal and vertical
sections of different sizes, as
well as provide for connection
to drain or inspection fittings.
Use either the drain tee cap or
the end cap for closure of the
unused opening. Specify size of
branch required.
90˚ BOOT TEE
Part No. BT
The 90˚ Boot Tee is used
to join horizontal and vertical
sections with lower resistance
as well as to provide for
connection of drain or
inspection fittings. Use
either the drain tee cap
or the end cap for closure
of the unused opening.
Includes 2 inner bands and
2 outer bands.
90˚ WYE
Part No. 90Y
The 90˚ Wye is used for joining
runs where low flow resistance
is desired. All openings must be
the same size. For connection
to smaller diameter sections use
the tapered or abrupt increasers.
Includes 2 inner bands and
2 outer bands.
Note: Grease wye available
1 ½" containment dam located
at one opening.
I.D. A B
5-6" 10 ½" 7"
7-8" 11 ½" 7 13⁄32"
9-10" 12 ½" 7 13⁄16"
11-12" 13 ½" 87⁄32"
13-14" 14 ½" 85⁄8"
15-16" 15 ½" 91⁄16"
17-18" 16 ½" 97⁄16"
19-20" 17 ½" 97⁄8"
21-22" 18 ½" 10 9⁄32"
23-24" 19 ½" 10 23⁄32"
25-26" 20 ½" 11 1⁄8"
27-28" 21 ½" 11 17⁄32"
29-30" 22 ½" 11 31⁄32"
31-32" 23 ½" 12 3⁄8"
33-34" 24 ½" 12 25⁄32"
35-36" 25 ½" 13 3⁄16"
37-38" 26 ½" 13 11⁄16"
39-40" 27 ½" 14 1⁄32"
41-42" 28 ½" 14 15⁄32"
43-44" 29 ½" 14 27⁄32"
45-46" 30 ½" 15 1⁄4"
47-48" 31 ½" 15 11⁄16"
Part No. 90T/
R90T
I.D. A
5-6" 10 ½"
7-8" 11 ½"
9-10" 12 ½"
11-12" 13 ½"
13-14" 14 ½"
15-16" 15 ½"
17-18" 16 ½"
19-20" 17 ½"
21-22" 18 ½"
23-24" 19 ½"
25-26" 20 ½"
27-28" 21 ½"
29-30" 22 ½"
31-32" 23 ½"
33-34" 24 ½"
35-36" 25 ½"
37-38" 26 ½"
39-40" 27 ½"
41-42" 28 ½"
43-44" 29 ½"
45-46" 30 ½"
47-48" 31 ½"
A
A
A
4"
A
90°
A
B
AID
4"
Includes 1 each inner band
and outer band for larger and
smaller opening.
Part No.BT
I.D. A B
5" 6 1⁄2" 10 5⁄16"
6" 7" 11 3⁄16"
7-8" 8" 13 1⁄16"
9" 8 1⁄2" 13 15⁄16"
10" 9" 14 7⁄8"
12" 10" 16 11 ⁄16"
14" 11" 18 ½"
16" 12" 20 3⁄8"
18" 13" 22 3⁄16"
20" 14" 24"
22" 15" 25 13⁄16"
24" 16" 27 11⁄16"
A
B
A
Part No.BT
I.D. A
26" 20 ½"
28" 21 ½"
30" 22 ½"
32" 23 ½"
34" 24 ½"
36" 25 ½"
38" 26 ½"
40" 27 ½"
42" 28 ½"
44" 29 ½"
46" 30 ½"
48" 31 ½"
B
4"
4"
Part No. 30L
Part No. 45L
7
90˚ ELBOW
Part No. 90L
The 90° Elbow is used when
making a 90° directional
change. The 90° elbow is
available in sizes 5" through 24".
For a 90° directional change in
diameters from 25" through 48"
use two 45° elbows.
Includes 1 inner and 1 outer band.
45˚ ELBOW
Part No. 45L
The 45° Elbow is used when a vertical or
horizontal direction change of 45° is desired.
Includes 1 inner and 1 outer band.
I.D. A B C D
5-6" 7" 9 29⁄32" 23 29⁄32" 16 29⁄32"
7-8" 7 3⁄8" 10 7⁄16" 25 3⁄16" 17 13⁄16"
9-10" 7 3⁄16" 11 3⁄64" 26 43⁄64" 18 55⁄64"
11-12" 8 1⁄4" 11 43⁄64" 28 11⁄64" 19 59⁄64"
13-14" 8 5⁄8" 12 13⁄64" 29 29⁄64" 20 53⁄64"
15-16" 9 1⁄16" 12 13⁄16" 30 15⁄16" 21 7⁄8"
17-18" 9 1⁄2" 13 7⁄16" 32 7⁄16" 22 15⁄16"
19-20" 9 7⁄8" 13 31⁄32" 33 23⁄32" 23 27⁄32"
21-22" 10 5⁄16" 14 37⁄64" 35 13⁄64" 24 57⁄64"
23-24" 10 3⁄4" 15 13⁄64" 36 45⁄64" 25 61⁄64"
25-26" 11 1⁄8" 15 47⁄64" 37 63⁄64" 26 55⁄64 "
27-28" 11 9⁄16" 16 23⁄64" 39 31⁄64" 27 59⁄64 "
29-30" 11 15⁄16" 16 7⁄8" 40 3⁄4" 28 13⁄16 "
31-32" 12 3⁄8" 17 1⁄2" 42 1⁄4" 29 7⁄8"
33-34" 12 3⁄4" 18 1⁄32" 43 17⁄32" 30 25⁄32"
35-36" 13 3⁄16" 18 21⁄32" 45 1⁄32" 31 27⁄32"
37-38" 13 5⁄8" 19 17⁄64" 46 33⁄64" 32 57⁄64"
39-40" 14" 19 51⁄64" 47 51⁄64" 33 51⁄64"
41-42" 14 7⁄16" 20 27⁄64" 49 19⁄64" 34 55⁄64"
43-44" 14 7⁄8" 21 1⁄32" 50 25⁄32" 35 29⁄64"
45-46" 15 1⁄4" 21 9⁄16" 52 1⁄16"36 13⁄16"
47-48" 15 11⁄16" 22 3⁄16" 53 9⁄16" 37 7⁄8"
30˚ ELBOW
Part No. 30L
The 30° Elbow is used when a vertical or
horizontal direction change of 30° is desired.
Includes 1 inner and 1 outer band.
I.D. A B C D
5-6" 6 1⁄8" 6 1⁄8" 22 55⁄64" 13 13⁄64"
7-8" 6 3⁄8" 6 3⁄8" 23 51⁄64" 13 47⁄64"
9-10" 6 5⁄8" 6 5⁄8" 24 23⁄32" 14 9⁄32"
11-12" 6 15⁄16" 6 15⁄16" 25 57⁄64" 14 61⁄64"
13-14" 7 3⁄16" 7 3⁄16" 26 53⁄64" 15 31⁄64"
15-16" 7 7⁄16" 7 7⁄16" 27 3⁄4" 16 1⁄32"
17-18" 7 3⁄4" 7 3⁄4" 28 59⁄64" 16 45⁄64"
19-20" 8" 8" 29 55⁄64" 17 15⁄64"
21-22" 8 1⁄4" 8 1⁄4" 30 51⁄64" 17 23⁄32"
23-24" 8 1⁄2" 8 1⁄2" 31 23⁄32" 18 5⁄16"
25-26" 8 3⁄4" 8 3⁄4" 32 21⁄32" 18 55⁄64 "
27-28" 91⁄16" 91⁄16" 33 53⁄64" 19 17⁄32 "
29-30" 9 5⁄16" 9 5⁄16" 34 3⁄4" 20 1⁄16 "
31-32" 9 9⁄16" 9 9⁄16" 35 11⁄16" 20 39⁄64"
33-34" 9 7⁄8" 9 7⁄8" 36 55⁄64" 21 9⁄32"
35-36" 10 1⁄8" 10 1⁄8" 37 25⁄32" 21 13⁄16"
37-38" 10 3⁄8" 10 3⁄8" 38 23⁄32" 22 23⁄64"
39-40" 10 5⁄8" 10 5⁄8" 39 21⁄32" 22 57⁄64"
41-42" 10 15⁄16" 10 15⁄16" 40 13⁄16" 23 9⁄16"
43-44" 11 3⁄16" 11 3⁄16" 41 3⁄4" 24 7⁄64"
45-46" 11 1⁄2" 11 1⁄2" 42 59⁄64"24 25⁄32"
47-48" 11 3⁄4" 11 3⁄4" 43 55⁄64" 25 5⁄16"
Part No. 90L
I.D. A
5-6" 9 11 ⁄16"
7-8" 10 7⁄8"
9-10" 11 7⁄16"
11-12" 12 11⁄16"
13-14" 13 7⁄8"
15-16" 15 1⁄16"
17-18" 15 11⁄16"
19-20" 16 7⁄8"
21-22" 17 1⁄2"
23-24" 18 11⁄16"
A
A
A
A
B
C
D
D
A
A
B
C
D
D
88˚ ELBOW
Part No. 88L
The 88° Elbow is used with the
2° Elbow to create the correct
pitch to allow for condensate to
flow to a stack drain.
Part No. EXC
8
SYSTEM COMPONENTS
CUSTOM DIMENSIONS ARE AVAILABLE TO SUIT YOUR NEEDS IN EVEN AND ODD SIZES
DRAIN SECTION
Part No. DS
The Drain Section is used
to drain rain water and
condensation from within the
stack. The NPT nipple should be
connected to a suitable drain.
Includes 1 inner and 1 outer band.
HORIZONTAL DRAIN
Part No. HD
The Horizontal Drain is used
to drain rain water and
condensation from within the
stack. The NPT nipple should be
connected to a suitable drain.
Includes 1 inner and 1 outer band.
FLASHING
Part No. FL
The Flashing is used in
conjunction with the rain
collar to seal roof penetrations.
This part is designed for flat
roofs. Custom pitched flashings
are available upon request.
RAIN COLLAR
Part No. RC
The Rain Collar is used in
conjunction with the flashing
to seal roof penetrations.
BASE DRAIN SECTION
Part No. BD
The Base Drain Section
provides a bottom closure
and drain attachment for
base supported vents.
Includes 1 inner and 1 outer band.
EXIT CONE
Part No. EXC
The Exit Cone is used to
increase the flue gas velocity
exiting the stack. A drain
should be used at the base
of stacks to remove any
water that enters the stack.
Includes 1 inner band and
1 closure ring to seal outer
shell joint.
I.D. A B
6" 4 7⁄8" 5 3⁄8"
8" 6 1⁄2" 6 1⁄8"
10" 8 1⁄8" 6 3⁄4"
12" 9 3⁄4" 7 1⁄2"
14" 11 3⁄8" 81⁄8"
16" 13 1⁄8" 87⁄8"
18" 14 3⁄4" 91⁄2"
20" 16 3⁄8" 10 1⁄4"
22" 18" 10 7⁄8"
24" 19 5⁄8" 11 5⁄8"
26" 21 1⁄4" 12 1⁄4"
28" 22 7⁄8" 13"
30" 24 1⁄2" 13 5⁄8"
32" 26 1⁄8" 14 3⁄8"
34" 27 3⁄4" 15"
36" 29 3⁄8" 15 3⁄4"
38" 31" 16 3⁄8"
40" 32 5⁄8" 17 1⁄8"
42" 34 1⁄4" 17 3⁄4"
44" 35 7⁄8" 18 1⁄2"
46" 37 1⁄2" 19 1⁄8"
48" 39 1⁄4" 19 3⁄4"
END CAP
Part No. EC
The End Cap is used to close
an unused tee opening and to
provide a means of accessing
the interior of the system for
inspection and cleaning.
Includes 1 inner band.
DRAIN TEE CAP
Part No. DTC
The Drain Tee Cap is used to
close an unused tee opening
and to provide a drain at the
base of a vertical vent.
Includes 1 inner band.
10"
12"
PIPE ID + 9"
SQUARE SIZE =
PIPE ID + 17"
6"
A
B
17"
17"
9
INSULATED THIMBLE
Part No. IT
The Insulated Thimble is
used when penetrating a
combustible wall or roof. This
part is designed for flat roofs.
Custom pitched thimbles are
available upon request.
RAIN CAP
Part No. CC
The Rain Cap is used at stack
terminations to prevent water
from entering the flue. A drain
should be used at the base of
stacks to drain off water that
may be blown into the flue.
Includes 1 inner band and
1 closure ring to seal outer
shell joint.
TOP SECTION
Part No. TS
The Top Section is used to
protect the insulating space
between the inner and outer
shells when an open
termination is required.
A drain should be used at the
base of stacks to drain off water
that enters the system.
Includes 1 inner band and
shell joint.
FAN ADAPTER
Part No. FA
The Fan Adapter is used to
attach to an exhaust fan.
Includes 1 inner and 1 outer band.
Note: Plenum boxes available for
multiple fan systems.
HORIZONTAL
TERMINATION
Part No. HT
The Horizontal Termination
is used when the stack
terminates in a horizontal
position. Birdscreen covers the
opening to prevent any birds or
rodents from entering.
Includes 1 inner and 1 outer band.
GUY SECTION
Part No. GS
The Guy Section is to be used
when the chimney extends
beyond the vertical limits above
the roof line. The guy section
should be connected to guy
wires or a rigid guying structure.
Includes 1 inner band and
2 half outer bands.
Note: This part must be
placed at the connection
of two flue sections.
FULL RING
Part No. FR
The Full Ring is used to guide
horizontal and vertical runs.
The part is simply bolted
around the outer shell then
rigidly connected to the
building structure.
HALF RING
Part No. HR
The Half Ring is used to
support long horizontal runs,
placed under the flue and then
supported by rods connecting
to the building structure.
6"
22"
PIPE I.D. + 8"
OD + 8"
BOLTING TABS WITH
7/16" HOLES
Part No. FRG
10
SYSTEM COMPONENTS
CUSTOM DIMENSIONS ARE AVAILABLE TO SUIT YOUR NEEDS IN EVEN AND ODD SIZES
FLOOR/ROOF GUIDE
Part No. FRG
The Floor/Roof Guide is used
at the penetration of floors and
roofs to guide the vent. This part
is designed to absorb lateral
loads only. It will not support
vertical vent sections.
I.D. A
5" 8 7⁄8"
6" 9 3⁄8"
7-8" 10 3⁄8"
9-10" 11 3⁄8"
11-12" 12 3⁄8"
13-14" 13 3⁄8"
15-16" 14 3⁄8"
17-18" 15 3⁄8"
19-20" 16 3⁄8"
21-22" 17 3⁄8"
23-24" 18 3⁄8"
25-26" 19 3⁄8"
27-28" 20 3⁄8"
29-30" 21 3⁄8"
31-32" 22 3⁄8"
33-34" 23 3⁄8"
35-36" 24 3⁄8"
37-38" 25 3⁄8"
39-40" 26 3⁄8"
41-42" 27 3⁄8"
43-44" 28 3⁄8"
45-46" 29 3⁄8"
47-48" 30 3⁄8"
Part No. WG
WALL GUIDE
Part No. WG
The Wall Guide is used to
guide long vertical runs that
are placed adjacent to walls.
This part will maintain proper
clearance to combustibles
when properly installed.
I.D. A B
5-6" 11" 7 13⁄16"
7-8" 13" 81⁄2"
9-10" 14" 85⁄8"
11-12" 15" 9"
13-14" 17" 97⁄16"
15-16" 18" 9 3⁄4"
17-18" 20" 10 1⁄4"
19-20" 21" 10 9⁄16"
21-22" 23" 11 1⁄8"
23-24" 24" 11 5⁄16"
25-26" 26" 11 7⁄8"
27-28" 27" 12 1⁄8"
29-30" 29" 12 11⁄16"
31-32" 30" 12 15⁄16"
33-34" 32" 13 1⁄2"
35-36" 33" 13 11⁄16"
37-38" 35" 14 5⁄16"
39-40" 36" 14 1⁄2"
41-42" 38" 15 1⁄16"
43-44" 39" 15 5⁄16"
45-46" 44" 16 11⁄16"
47-48" 45" 16 7⁄8"
Part No. SP
SUPPORT PLATE
Part No. SP
The Support Plate is the
primary load carrying member
of the vent assembly. This part
is designed to support (B) (See
Chart Below) feet of vertical
vent section as well as provide
fixed points in breeching runs.
Includes 1 inner band and
2 half outer bands.
Note: This part must be
placed at the connection
of two flue sections.
WALL SUPPORT
Part No. WS
The Wall Support is used to
provide vent support along
a wall. The wall support will
maintain the required clearance
to combustible structures when
properly installed and can
support (C) (See Chart Below)
feet of vertical chimney.
Includes 1 inner band and
2 half outer bands.
Note: This part must be
placed at the connection
of two flue sections.
I.D. A B(FT)
5-6" 19 3⁄16" 403'
7-8" 21 3⁄16" 389'
9-10" 23 3⁄16" 375'
11-12" 25 3⁄16" 361'
13-14" 27 3⁄16" 347'
15-16" 29 3⁄16" 334'
17-18" 31 3⁄16" 320'
19-20" 34 3⁄16" 306'
21-22" 36 3⁄16" 292'
23-24" 38 3⁄16" 278'
25-26" 40 3⁄16" 264'
27-28" 42 3⁄16" 250'
29-30" 44 3⁄16" 236'
31-32" 46 3⁄16" 222'
33-34" 48 3⁄16" 208'
35-36" 50 3⁄16" 195'
37-38" 52 3⁄16" 181'
39-40" 54 3⁄16" 167'
41-42" 56 3⁄16" 153'
43-44" 58 3⁄16" 139'
45-46" 60 3⁄16" 125'
47-48" 62 3⁄16" 111'
Part No. WS
I.D. A B C(FT)
5-6" 11 " 12 3⁄8" 193'
7-8" 13" 14 3⁄8" 171'
9-10" 14" 15 3⁄4" 164'
11-12" 15" 17 1⁄16" 153'
13-14" 17" 19 1⁄16" 148'
15-16" 18" 20 7⁄16" 140'
17-18" 20" 22 1⁄2" 134'
19-20" 21" 24 1⁄8" 129'
21-22" 23" 26 3⁄16" 123'
23-24" 24" 27 1⁄2" 119'
25-26" 26" 29 1⁄2" 113'
27-28" 27" 30 7⁄8" 108'
29-30" 29" 32 7⁄8" 103'
31-32" 30" 34 1⁄4" 120'
33-34" 32" 36 1⁄4" 114'
35-36" 33" 37 5⁄8" 88'
37-38" 35" 39 9⁄16" 81'
39-40" 36" 40 15⁄16" 77'
41-42" 38" 42 15⁄16" 73'
43-44" 39" 44 5⁄16" 68'
45-46" 44" 47" 64'
47-48" 45" 49 11⁄16" 60'
A
B
A
11⁄8"
1⁄2" HOLES
A
B
A
A
11
SAMPLE SPECIFICATION - eVent™
eVent™WEIGHT CHART
The factory built modular vent shall be laboratory tested and listed in
accordance with Underwriters Laboratories Standard UL 1738 for use with
category II, III, & IV appliances with a maximum flue gas temperature of
550°F and ULC-S636-95 for gas vent - BH, Class I / Class II 245°C.
Product must have UL pressure rating of 40” w.c. Product to have leak free
guarantee for three (3) years and lifetime time product warranty backed by the
manufacture. Vent sections shall be sealed with ½" banded flanges and
factory applied gasket for temperatures up to 600°F with a UL tested
pressure rating of 40" w.c.
Inner shell material shall be type AL 29-4C®or 316L stainless steel. Inner shell
thickness shall be .024" (24 ga. eVent™) and .036" (20 ga. eVent™PLUS)
for 5" to 48" diameter systems. All inner shell seams shall be full penetration
welded. Riveted, tack or spot welded seams are not permitted.
Outer shell material shall be 430 stainless steel with a thickness of .028" for
5" to 48" diameter systems. Optional outer shell material can be aluminized
steel or 304 or 316 stainless steel. All outer shell seams shall be full penetration
welded the entire length of the pipe section. Riveted, tack or spot welded seams
are not permitted.
Between the inner and outer shells there shall be a minimum 1" air gap.
Stainless steel centering clips shall be welded to the outer shell to maintain
the 1" spacing and ensure concentricity of the shells.
Breeching and vent sections, when installed according to manufacturer’s
instructions, shall comply with national safety standards and building
codes. Stacks terminating above a roof must terminate as required by
code or NFPA 211.
6"
17" Straight Section 17S 18 lbs.
35" Straight Section 35S 25 lbs.
30 Degree Elbow 30L 8 lbs.
45 Degree Elbow 45L 9 lbs.
45 Degree Tee 45LT 18 lbs.
47" Straight Section 47S 23 lbs.
71" Straight Section 71S 50 lbs.
90 Degree Elbow 90L 12 lbs.
90 Degree Tee 90T 15 lbs.
Abrupt Increaser AI 7 lbs.
Base Drain BD 12 lbs.
Boiler Kit Flanged BKF 7 lbs.
Boiler Kit Raw BKR 4 lbs.
Drain Section DS 11 lbs.
Drain Tee Cap DTC 5 lbs.
End Cap EC 4 lbs.
Fan Adapter FA 7 lbs.
Flashing FL 11 lbs.
Floor/Roof Guide FRG 10 lbs.
Full Ring FR 3 lbs.
Guy Section GS 9 lbs.
Half Ring HR 2 lbs.
Horizontal Drain HD 11 lbs.
Insulated Thimble IT 20 lbs.
Nozzle Section NS 11 lbs.
Rain Cap CC 9 lbs.
Rain Collar RC 4 lbs.
Support Plate SP 31 lbs.
Tapered Increaser TI 13 lbs.
Top Section TS 3 lbs.
Variable Section VS 23 lbs.
Wall Guide WG 14 lbs.
Wall Support WS 51 lbs.
Inside Diameter (Inches)
All weights shown above are actual weights, for shipping weights multiply by 1.25
8" 10" 12" 14" 16" 18" 20" 22" 24" 26" 28" 30" 32" 34" 36" 38" 40" 42" 44" 46" 48"
21 25 29 32 36 39 43 47 50 54 58 61 77 81 85 103 108 113 118 123 128
26 29 33 38 42 46 50 55 59 63 67 72 90 95 100 121 126 132 138 144 150
10 12 15 18 20 23 26 30 33 36 40 44 47 51 67 85 91 98 105 112 119
11 14 17 20 24 27 31 35 40 44 49 54 59 64 85 108 116 125 135 144 154
26 34 43 53 64 76 88 102 117 133 150 168 186 205 283 356 388 422 457 493 531
30 36 43 49 - - - - - - - - - - - - - - - - -
52 58 66 76 - - - - - - - - - - - - - - - - -
17 23 30 38 46 55 65 76 88 - - - - - - - - - - - -
19 25 31 37 44 52 60 68 77 87 97 107 118 130 176 221 240 259 280 301 322
8 10 11 13 15 16 18 20 21 23 24 26 28 29 31 39 41 43 45 47 49
15 17 20 23 26 28 31 34 37 39 42 45 48 51 59 72 76 79 83 87 90
8 10 11 13 15 16 18 20 21 23 24 26 28 29 31 39 41 43 45 47 49
5 6 7 8 8 9 10 11 12 13 14 15 15 16 17 25 26 27 29 30 31
14 17 20 23 26 29 32 35 37 40 43 46 49 52 66 83 87 91 95 99 103
6 7 8 9 11 12 14 16 18 20 22 25 27 30 39 51 55 59 64 69 74
5 6 7 8 10 11 13 15 17 19 21 24 26 29 38 50 54 58 63 68 73
8 10 11 13 15 16 18 20 21 23 24 26 28 29 31 39 41 43 45 47 49
12 13 15 16 18 19 21 22 24 25 27 29 30 32 34 35 37 39 40 42 44
10 11 12 15 16 17 18 19 24 25 27 27 30 30 32 33 34 35 36 38 39
4 5 6 9 10 11 12 13 18 19 21 21 24 24 26 27 28 29 30 32 33
11 13 14 16 18 20 22 23 25 27 29 31 32 34 36 42 44 46 48 50 52
2 3 3 5 5 6 6 7 9 10 11 11 12 12 13 14 14 15 15 16 17
14 17 20 23 26 29 32 35 37 40 43 46 49 52 66 83 87 91 95 99 103
22 25 28 31 33 36 39 42 44 47 50 52 55 58 61 63 66 69 72 74 77
14 17 20 23 26 29 32 35 37 40 43 46 49 52 66 83 87 91 95 99 103
11 13 16 18 21 24 27 31 34 37 41 45 52 57 65 73 79 86 92 99 105
5 5 6 6 7 7 8 8 9 9 10 10 11 11 12 12 13 13 14 14 15
36 42 47 53 58 64 70 76 99 107 114 122 130 138 146 186 196 206 217 227 238
16 20 23 27 30 33 37 40 44 47 50 54 57 61 78 97 102 106 111 116 121
4 5 5 6 7 8 9 9 10 11 12 12 13 14 17 21 22 23 24 25 26
30 36 43 49 56 62 68 75 81 88 94 101 107 113 148 181 190 199 209 218 227
17 19 21 26 28 31 34 37 44 48 50 53 57 60 62 66 69 73 75 85 87
61 73 84 97 108 124 138 156 186 206 222 244 262 285 304 360 381 416 439 477 501
P 800.391.0009 • 563.359.0110
5665 Fenno Rd
Bettendorf, Iowa 52722
www.scheblerchimney.com
© 2019 Schebler Chimney Systems. All Rights Reserved.
AL 29-4C is a registered trademark of Allegheny Ludlum Corporation.
eVent™LIFETIME WARRANTY
The Schebler Company warrants eVent™ model
products installed in UL 1738 condensing applications
against defects in material and workmanship for the
entire duration the product is incorporated and used
in its original installation when said product is properly
installed per Schebler’s design and current installation
instructions or specifications, and is properly connected
to a code compliant venting system for category IV
appliances. This warranty is subject to all terms and
conditions described in The Schebler Company's
Standard Terms and Conditions of Sale.
The Schebler Company will, at its sole discretion, either
repair or replace any defective product covered by this
Limited Warranty at no charge, provided however Buyer
shall be responsible for all costs of removal, shipping,
and reinstallation of the product. Furthermore, this
warranty does not apply to any system component not
manufactured by Schebler Company and installed as
part of the UL system. Repair or replacement of products
provided under this Limited Warranty are similarly
warranted for the remainder of the original warranty term.
This limited warranty is extended solely to the original
owner subject to the satisfaction of the following conditions:
1) System sizing and design has been performed by
Schebler personnel and the design parameters
provided to The Schebler Company by the
responsible engineer were and are accurately
representative of the system operating conditions.
2) The undamaged components have been correctly
installed in accordance with Schebler system
design and sizing, and installation instructions
published by The Schebler Company.
3) All horizontal breeching in the system is properly
pitched back toward the appliances to allow
condensate to flow to, and be removed by,
horizontal drains, drain sections, drain tee
caps and/or base drain sections.
4) The Schebler Company has supplied the
entire vent system from connection to the
appliance to the termination of the vent.
5) Any portion of the system exposed to the
atmosphere has an outer shell constructed
of stainless steel.
The Schebler Company makes no other warranty,
whether expressed or implied. This warranty shall
be the sole and exclusive remedy of any Buyer,
whether in contract, tort or otherwise. UNDER NO
CIRCUMSTANCES SHALL THE SCHEBLER
COMPANY BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGE, OR COMMERCIAL
LOSS OR FROM ANY OTHER LOSS OR DAMAGE
EXCEPT AS SET FORTH HEREIN. The Schebler
Company assumes no liability for any damages
resulting in whole or part from misuse, improper
installation, or inadequate maintenance of the system
or component part thereof, nor assumes or authorizes
any other person or entity to assume on its behalf any
other liability in connection with the sale of its products.
Inner liner 1/2" rolled flange
eVent™spacer clip
Outer shell
Inner liner
Outer band
with clips
Inner V-band 1" air gap
eVent™spacer clip
Factory-applied gasket
AD&M - 2.19
Internal flange
collar
Table of contents
