Schmécké SHMCC0251SS User manual

CIGAR HUMIDOR COOLER
USER GUIDE
SHMCC0251SS | SHMCC0331SS | SHMCC0501SS

2
Thank you for purchasing the Schmécké Cigar Humidor Cooler.This User Guide is intended to provide you with
guidelines to ensure that operation of this product is safe and does not pose risk to the user.Any use that does
not conform to the guidelines described in this User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference.This product is intended
for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.See warranty
for details.
SAFETY PRECAUTIONS
• Never allow children to operate, play with,or crawl inside the cigar cooler.
• Never clean cigar cooler parts with flammable liquids,as the fumes can create a fire hazard or explosion.
• Do not store or use gasoline or any other flammable liquids in the vicinity of this appliance.The fumes can
create a fire hazard or explosion.
• Do not attempt to repair or replace any part of the unit.There are no user-serviceable parts.
• When choosing a location to store your cigar cooler, always ensure that the plug is accessible.
• Keep the unit out of direct sunlight
• Do not place the unit near any heat-generating appliances.
• Place the cigar cooler on a level surface that is strong enough to support the unit when it is fully loaded.
• Always keep the cigar cooler in a dry, well-ventilated space with an ambient temperature between 50°–
80°F (10°–26°C).
• Before connecting the unit to a power source for the first time,allow it stand upright for approximately two (2)
hours.This will reduce the possibility of any system malfunctions which may have occurred from handling
during shipping.
• When positioning the cigar cooler,be sure to leave at least 6 inches of space at the back and 10 inches on
both sides.This is to ensure that none of the ventilation openings are blocked.
• Do not place any objects on top of the unit as this may block air circulation.
• This unit requires a standard 110V-60Hz electrical outlet.The unit should be properly grounded for your safety
and in order to minimize the possibility of electrical shock.
• Never cut or remove the ground wire from the supplied power cord.
• We do not recommend using extension cords with this product.
• The cord should be secured behind the cigar cooler.Also,to prevent accidental injury, do not expose or
dangle the cord.
• Do not install the cigar cooler in a closed cabinet or any other area that lacks proper ventilation.
• Do not remove the feet on the bottom of the cigar cooler.The unit requires at least 2 inches (50 mm) of
ground clearance.
SAFETY PRECAUTIONS 2
BOX CONTENTS 3
REQUIRED TOOLS 3
PARTS 3
SETTING UP THE CIGAR COOLER 4
ATTACHING THE HANDLE 4
BEFORE FIRST USE 4
MAINTAINING CIGAR HUMIDITY 5
CALIBRATING YOUR HYGROMETER 5
CONTROL PANEL 6
TROUBLESHOOTING 6
SPECIFICATIONS 7
CUSTOMER SERVICE 7
CONTENTS

3
BOX CONTENTS
Cigar Cooler
2x screws for handle assembly
Handle
User guide
REQUIRED TOOLS
Philips-head screwdriver
PARTS
1. Cabinet
2. LED lamp
3. Wood shelves
4. Cigar drawer
5. Hygrometer
6. Plastic reservoir
7. Nonslip feet
8. Lower hinge
9. Door gasket
10. Tempered glass door
11. Upper door hinge with cover
Model SHMCC0251SS
Model SHMCC0331SS
Model SHMCC0501SS

4
SETTING UP THE CIGAR COOLER
1. When choosing a location to store the cigar cooler, be aware of the following:
a. Be sure that it is placed on a sturdy, level surface that is strong enough to support it when full.
b. Ensure there is at least 6-inches of space behind the cooler and 10-inces of space on either side.This will
ensure proper air ventilation.
c. It is not recommended to place the cooler on a carpet or rug.
2. Make sure the unit is level by rotating each of the bottom feet until it appears perfectly level and stable.You
may want to use a carpenter’s level to do this.
ATTACHING THE HANDLE
BEFORE FIRST USE
• When you first turn on the cigar cooler, or restart it after an extended period of non-use, there could be a
few degrees variance between the temperatures you select and the one indicated on the LCD readout.
- This is normal and it is due to the length of the activation time. Leave the cigar cooler on for a few hours,
and normal operation will resume.
• Place the cigar cooler in a dry, well-ventilated space with ambient temperature between 50°–80°F
(10°–26°C).
NOTE: If the ambient temperature is above or below the recommended range,the unit's performance may be
affected. Extreme cold or hot conditions may cause the interior temperature to uctuate.This will then prevent
the optimal interior temperature range from being reached.
In addition, the temperature may uctuate depending on whether the interior light is on or off, and whether the
cigars are located on the upper, middle, or lower racks. Environments that are air-conditioned or experiencing
exceptionally low or high humidity may affect performance. For best results, the humidity in the room should be
between 50% to 75%.
1. Lightly pull away the door
gasket, being careful not
to remove it completely. It
is located on the inner left
side of the door where the
handle is to be installed.The
gasket is easily removed by
hand, no tools necessary.
2. Guide the two (2) included
screws through the pre-drilled
holes in the door until they
are entirely through.Then
align the handle with
the door.
3. Tighten the screws using
a Philips-head screwdriver
(not included) until the
handle sits flush and is
secured tightly against
the door frame.
NOTE: DO NOT over-tighten,
as this will cause damage t
o the handle assembly.
4. Replace the door gasket
to its original position.

5
MAINTAINING CIGAR HUMIDITY
1. Fill the humidity tray (small plastic reservoir) to about ¾ full with 100% distilled water.
2. Place the filled reservoir onto the bottom of the cigar cooler.
3. Regularly check the water level and refill as necessary.
4. The recommended humidity level for cigars is between 65% and 75%.Use the built-in hygrometer to
moderate the humidity level.
a. If the humidity is less than 65%,leave the reservoir inside until the humidity rises above 65% but is less
than 75%
b. If the humidity is more than 75%, remove the reservoir (if it’s inside), then reduce the inside temperature
until the humidity falls below 75% but is more than 65%
c. If humidity exceeds the desired level,leave the door open until it reaches the desired level.This will only
work if the outside environment is at a lower humidity level than the unit.
The humidity level of cigars is a matter of personal taste, however we recommend the following levels:
65% – Ideal for Cuban cigars, and those who enjoy dryer cigars with a stronger burn.
69% – The standard level recommended by cigar manufacturers.
72% – The best choice for humidor seasoning. It is not recommended to consistently keep cigars at this level.
Once the desired level of humidity has been reached and the door to the unit is closed, it will work to maintain
that humidity level.
NOTE 1: any humidity level between 65% and 75% is appropriate for cigar storage.
NOTE 2:The readout on the built-in hygrometer is approximate and can vary +/- 3%.
CALIBRATING YOUR HYGROMETER
If you are unsure of whether your hygrometer’s reading is correct, you can use a simple process to check it.You
will need these items:
• Table salt
• Water
• A bottle cap
• A clear,re-sealable plastic bag or container
• A measuring spoon (teaspoon size)
Here is the process:
1. Push on the back of the hygrometer to disengage it from the drawer.
2. Measure one teaspoon of salt and place
it in the bottle cap.
3. Dampen it with a few drops of water (but
do not dissolve it).

6
PROBLEM POSSIBLE CAUSES POSSIBLE SOLUTIONS
The cigar cooler will
not operate
The power source may not match the
required power of the unit.
Plug the cooler into an appropriate
power source.
The circuit breaker may have tripped
or a fuse has blown.
Check your fuse box or contact a
qualified electrician.
The cigar cooler is not
cold enough.
The external environment may be too
hot.
Adjust the temperature settings.
The door may be opened too
frequently.
Keep the door closed as often as
possible.
The door is not closed completely. Make sure the door is completely
closed after every use.
The door seal does not seal properly. Contact Schmécké customer support.
The cigar cooler does not have
sufficient clearance.
Ensure there are at least 6 inches
behind the cooler and 10 inches on
either side.
TROUBLESHOOTING
CONTROL PANEL
1. Set the temperature inside the cigar cooler by pressing the (increase) and (decrease) buttons to adjust
the temperature in 1° increments.
2. To switch between Fahrenheit and Celsius, press and hold the button for 2 seconds.
3. To turn the interior light on or off, press the button.
NOTE:The light will turn off automatically if it remains on for 10 minutes.Press the button again to turn it back on.
4. Place the bottle cap and the hygrometer
inside the bag or container,then seal it.
8. Your hygrometer is now ready to be placed back into the unit, and it will show the actual humidity level inside
the unit.
5. Wait at least 6 hours.
6. Read the hygrometer without opening the bag
or container.The environment inside this bag or
container is now at 75% humidity.
7. If the hygrometer reads less or more than 75%, you can adjust the needle to the correct reading:
a. Insert a small, flathead screwdriver into the opening on the back.
b. Set the needle to 75%.
75%

7
SPECIFICATIONS
Questions or Problems? Contact Us!
[e-mail] | 833-876-2922
The cigar cooler
vibrates while
operating.
The cooler is positioned on an
unstable surface.
Make sure the unit is placed on a
level, stable surface.
The cigar cooler
produces a lot of
noise.
The cooler is positioned on an
unstable surface.
Make sure the unit is placed on a
level, stable surface.
The fan may not be working properly. Contact Schmécké customer support.
The cigar cooler will
not close properly.
The cooler is positioned on an
unstable surface.
Make sure the unit is placed on a
level, stable surface.
The doors are reversed and not
properly installed.
Review the instructions for installing
the door gasket in this user guide.
The seal has weakened. Contact Schmécké customer support.
The LED display does
not work.
The main control board may be
damaged or otherwise
malfunctioning.
Contact Schmécké customer support.
The plug may be damaged. Contact Schmécké customer support.
There is an LED display
error. There is a PCB problem. Contact Schmécké customer support.
The buttons do not
function.
The temperature control panel may
be damaged.
Contact Schmécké customer support.
Frost or ice developed
inside the cigar
cooler.
Ambient temperature too low.
Restart the unit.
SHMCC0251SS SHMCC0331SS SHMCC0501SS
Power Supply 115 V / 60 Hz 115 V / 60 Hz 115 V / 60 Hz
Rated Power 65 W 65 W 65 W
Temperature
Range
61°-72°F (16°-22°C) 61°-72°F (16°-22°C) 61°-72°F (16°-22°C)
Dimensions 9.9” x 19.7” x 17.8”
(
25.2 x 50 x 45.3 cm
)
13.6” x 20” x 18.9”
(
34.5 x 51 x 48 cm
)
13.6” x 20.5” x 25.4”
(
34.5 x 52 x 64.5 cm
)
Weight 20.9 lbs.
(
9.5 kg
)
25.6 lbs.
(
11.6 kg
)
31.7 lbs.
(
14.5 kg
)
Total Capacity 25 L / 0.9 ft³ 33 L / 1.2 ft³ 50 L / 1.8 ft³
SCHMECKE is a trademark of C&A IP Holdings, LLC in the US.
www.schmecke.com
Distributed by: C&A Marketing, Inc., 114 Tived Lane East, Edison, NJ 08837 USA
C&A Marketing UK LTD, 167 Hermitage Road, Crusader Industrial Estate, London N4 1LZ, UK
©2019 All Rights Reserved.
MADE IN CHINA
TROUBLESHOOTING (continued)
