USER MANUAL
3D
PluraView
PluraView
FOR D-STEREO
PROFESSIONALS
The new Schneider Digital D PluraView monitor with
innovative beam splitter technolog oers the highest quality
for stereoscopic display on desktop monitors.
CONTENTS
Advantages of stereoscopic visualization
Installing the monitor on the workstation
Product description
Control elements on the displays
Unpacking the monitor
Safety instructions
Legend
Stereo beam splitter Functionality
Adjusting the monitor
Scope of delivery
Cleaning and care
Mounting the monitor
Troubleshooting
Optional accessories
Technical data
EC declarations of conformity
Warranty & service case
04
14
06
17
08
20
24
05
16
07
19
10
23
25
26
27
29
User manual
ADVANTAGES OF STEREOSCOPIC
VISUALIZATION
For the highest demands in D stereo applications
SAFETY NOTE
It can happen that prolonged work at a VDU workstation causes discomfort or eye fatigue. In this case, we recommend taking
a break from screen work.
• Photogrammetry and remote sensing
• GIS and digital city and terrain models
• Geolog & geophysics
• Construction, visualization of molecules
• Gaming
• Oil and gas exploration
• Architecture, BIM & CAD models
• Stereophotography and videography
• D lm post-production and animation
• Medical imaging, CT & MRI
(surgical planning, training)
• Complex data analysis
• Quality assurance and material testing
• Remote control of vehicles and machines
Stereoscopic display is a component of many applica-
tions and is useful in the following areas:
Nature has given humans the ability to see stereoscopically,
i.e. spatially. This enables us to intuitively estimate our own
position in the environment and the distance to any other
points in our eld of vision.
The visual center of the brain generates a perception of depth
when the two slightly dierent image impressions from both
eyes are merged into a single image. This form of binocular
vision is also known as stereopsis.
We live in a three-dimensional world. For the past two
hundred years, more and more data has been generated that
enables spatial representation. In the past, this was mainly
analog (photographs, drawings), today it is almost exclusively
digital. Photographs, videos, laser scans and medical imaging
techniques (CT) make it possible to capture a wide range
of image information in the third dimension. Why not
take advantage of this and present the data as naturally as
possible?
The fatigue-free, stereoscopic visualization with the
sophisticated D PluraView stereo monitor helps the user to
interpret D data quickly, safely and eortlessly.
User manual
STEREO BEAM SPLITTER
FUNCTIONALITY
How the passive D stereo monitor works
The D PluraView beamsplitter monitor consists of a precisely
crafted, sturdy metal housing in which two LCD monitors are
installed at a specic angle to each other. This angle is divided
by a semi-transparent mirror, the beamsplitter. The mirror is
equipped with a reective coating on the upper side and an
anti-reective coating on the other side, so that reections
and thus double images within the mirror are avoided.
The lower monitor is viewed through the mirror and the upper
monitor is viewed on it. The image of the upper monitor
must be mirrored without latency. The D PluraView stereo
monitor does this by means of an integrated mirror card,
which converts the signal on its way to the upper monitor.
In principle, the beam splitter technolog works like this: one
monitor displays the left stereo image for the left eye and
one displays the right stereo image (with a slightly dierent
viewpoint) for the right eye. The dierent polarization of the
displays allows polarization of the displays allows excellent
eye separation by means of appropriately aligned polarizing
lter glasses. Each eye only sees the image intended for it,
while the other monitor is faded out. This allows the human
visual system to see the images spatially in a completely
natural way thanks to the depth perception made possible
in this way. And icker-free, with full monitor resolution and
high brightness for each eye.
The two D PluraView displays are polarized at ° and °
respectively. This feature makes it possible to use an
another monitor without the optical impairment of
the polarizing lter glasses if it is polarized at ° or
° polarized.
45° polarized
right eye image
135° polarized
left eye image
beam splitter
(half mirror)
45° polarizing filter
135° polarizing filter
So works 3D PluraView passive Stereo with Beam Splitter Technology
Copyright by Schneider Digital
113355°°
4455°°
113355°°
4455°°
User manual
PRODUCT DESCRIPTION
" and " D PluraView
D mode D mode
The current list of D PluraView-supported software
applications is available for download at:
https://www.d-pluraview.com/wp-content/downloads/software-overview/
d_pluraview_supported_stereoscopic_software-vendors.pdf
With the beamsplitter mirror folded up, the D PluraView can
be used without restriction for all applications and screen
content. Its QHD (") and K (") display deliver a sharp,
bright and high-contrast image.
The Beamsplitter mirror can be easily released from its
locking mechanism and folded down with a ick of the
wrist. With two full-resolution stereo channels and a wide
viewing angle, several users can view D stereo content at
the same time.
List of all applications
User manual
SCOPE OF DELIVERY
This is included in the package
The current list of D PluraView-supported software
applications is available for download at:
https://www.d-pluraview.com/wp-content/downloads/software-overview/
d_pluraview_supported_stereoscopic_software-vendors.pdf
x monitor stand with lower monitor, beamsplitter holder and pre-assembled
Displayport connection cables (m) to graphics card/workstation
x Upper monitor holder with pre-calibrated monitor
x Beamsplitter mirror with mirror holder and handle bar
x Plastic shims for the beamsplitter holder
x Knurled screws for mirror adjustment
x Allen key (., and mm)
x Power connection cable approx. . m
x Polarizing lter glasses "D PluraView" incl. microbre bag and cleaning cloth
1
2
3
4
5
6
7
8
1
34
5
6
7
8
2
User manual
UNPACKING THE
MONITOR
It is recommended that two
people unpack and set up the
D PluraView monitor
A video tutorial on unpacking and
connecting the D PluraView monitor
can be found here:
https://www.schneider-digital.
com/wp-content/downloadcenter/
Documents_Flyer/VIDEOS/D-
PluraVIEW/Tutorials/D-PluraView_
unboxing_-.mp
a.
b.
c.
d.
e.
f.
Open the box at the top
and remove the molded parts that hold the monitor in
place from above.
On one side is the monitor stand with the lower monitor
monitor on one side and the upper monitor on the other,
with the beamsplitter mirror in between.
Remove the folding box containing the cables and glasses.
First remove the upper monitor () and then the beam
splitter mirror () and place the parts safely on a clean
and level surface.
Finally, remove the monitor stand () with the lower
monitor and place it on the worktable. Allow the
pre-assembled power and Displayport cables to hang
down from the cable gland at the back.
ATTENTION! Please keep the complete shipping
packaging (outer box and foam padding) for any
returns in the event of support or warranty claims!
ab
cde
1
2
3
e
f
f
User manual
D PluraView
Plug & Play
Works without special driverswith
Microsoft / LINUX / macOS
User manual
MOUNTING THE
MONITOR
Adaptation of the D PluraView
workstation to the oor space
a.
b.
c.
Check that the table is level. If the stand wobbles, you can
adjust the rear feet using the mm Allen key.
By adjusting the rear monitor feet, the monitor can be
tilted by a few degrees to suit your needs.
Remove the two monitor covers from the upper
from the upper monitor section by loosening the two
bracket screws.
a
c
c
b
b
User manual
Attaching the upper monitor and
cable connection
d.
e.
f.
g.
h.
Hold the upper monitor holder so that the display is
facing you.
Insert the two hooks at the lower end of the upper
monitor holder into the slots in the oval tube of the
lower section. To do this, the upper monitor must be held
almost vertically.
Lower the upper monitor to the intended position and
slowly tilt it forwards. Take care not to pinch any cables.
Secure it with the two knurled screws at the rear end of
the monitor mount.
Lay the power and DP video cable to the front and
connect the top monitor.
Replace the two upper monitor covers one after the other
and secure them with the two U-bolts.
MOUNTING THE
MONITOR
e
f
g
h
d
1
2
User manual
MOUNTING THE MONITOR
i.
j.
k.
Remove the plastic shims, cables and the knurled screws
for ne adjustment of the mirror from the accessory box.
Place the washers on the rear bolts of the mirror arms.
Carefully remove the Beamsplitter mirror from the bubble
bag and store it with the rest of the packaging.
Handle the mirror with extreme care. It is made of non-
tempered glass and can therefore break or be scratched
relatively easily.
Hold the beam splitter mirror with both hands parallel
to the mirror arms without hitting it. Lower the rear of
the Beamsplitter mirror until the rear bolts slide into the
grooves in the mirror holder. Then pull the mirror slightly
forwards until the front bolts of the mirror arm also slide
Inserting and adjusting the mirror
into the grooves of the mirror holder. Do not release the mirror until you have made sure that it is correctly engaged on both sides
and is not resting crookedly on the mirror arm.
i
j
k k
User manual
MOUNTING THE MONITOR
l.
m.
n.
Screw the two knurled screws for ne adjustment left and
right into the mirror holder until the mirror lifts slightly.
Please carry out the adjustment (see page ) before
using the mirror for the rst time.
To fold up the mirror, always lift it up to the upper monitor
with both hands. You can now push the mirror all the way
back, where it will lock into the folded-up position.
If you want to bring the mirror into the working position, always pull it towards you with both hands and parallel to the top
screen as far as it will go and then lower it onto the mirror arm. Never let go of the mirror prematurely. Risk of breakage!
Change and possibilities of the mirror position
n
l
m m
n n
User manual
https://www.schneider-digital.com/wp-
content/downloadcenter/Tools_Ressourcen/D-
PluraView/Setup_AMD_RadeonPRO_FirePRO/
AMD_Quad-Buffer_passive-stereo_Dual-
Head_D_PluraView.mp
INSTALLING THE MONITOR
ON THE WORKSTATION
Connect, switch on and get started
Illuminated on/o switch
Fuse link with spare A fuse
IEC plug (V/V)
Displayport cable - 'Bottom' and 'Top'
USB connection
If you want to use the USB hub of the lower monitor, you
can connect the monitor to the workstation via this USB-B
interface.
a. Connect the two Displayport cables to the graphics card of
your workstation. You can nd the graphics cards suitable for
the D PluraView monitor here:
b. Connect the monitor to the mains using the power cable
supplied.
c. Start up the workstation, connect to the Internet and
download the latest driver for your graphics card:
d. Under the same link you will also nd the respective
uninstaller for the old driver, which you should also download
and run beforehand.
https://www.schneider-digital.com/de/
support-downloads/download-center/?url=/
driver/Grakkarten
e.
Follow this video tutorial if you are using an AMD
graphics card:
if you are using an NVIDIA graphics card:
f. The upper and lower displays now show the same picture
(clone).
g. To check the successful stereo setup, load and open the
following le:
https://www.schneider-digital.com/
wp-content/downloadcenter/Tools_
Ressourcen/D-PluraView/Setup_nVIDIA_
Quadro_RTX-PRO/NVIDIA_Quad-Buer_nVIEW_
Clone_D_PluraView.mp
https://www.schneider-digital.com/wp-content/
downloadcenter/Tools_Ressourcen/STEREO/
QuadBuer_Stereo-Test.zip
https://www.schneider-digital.com/wp-
content/downloadcenter/Documents_
Flyer/D-VR-Solutions/QuadBuffer-Stereo_
supported_Graphics-Cards.pdf
Redblue
Treiber
Grakkarten
15
4
3
2
User manual
D PluraView
The new D PluraView monitor with innovative beam
splitter technolog oers the highest quality for
stereoscopic display at the workplace.
User manual
a. The monitor has already been adjusted at the factory. However, it is necessary to set the correct mirror position using the two
knurled screws on the left and right of the mirror arm.
b. Download the test grid from our website as a PDF le and, if necessary, the Adobe PDF reader:
c. Use the key combination "Ctrl+L" to display the test pattern in full screen mode. Now fold down the Beamsplitter mirror and
place it carefully on the mirror arm support.
ADJUSTING THE MONITORS
Fine adjustment of the monitor
d. Please sit centered in front of the device with your eyes
approximately level with the top edge of the vertical monitor.
Some of the lines of the reference grid will not match until
the beamsplitter is correctly adjusted. Use the two knurled
screws to adjust the height of the beamsplitter until the grid
lines match and the text at the corners and especially in the
center is clearly legible.
https://www.schneider-digital.com/wp-content/
downloadcenter/Tools_Ressourcen/D-PluraView/User_
Manual/Test-Grid_for_D-PluraVIEW_adjustment.pdf
6
Adjusting the beamsplitter
User manual
Perfect for all
D applications
For all D stereo applications in
GEO/GIS, BIM, Medical, Bio-Tech & CAx
User manual
CONTROLS ON THE
DISPLAYS "
Operating display and menu
On/o display:
Blue: Normal operation
Orange: Energ management
On/o switch ( )
Menu / Select button (ENTER)
Scroll down / brightness button (/ )
Scroll up / ECO Mode button (/ )
Exit button (EXIT)
Input source button (INPUT)
1
1
1
2
2
2
3
3
3
4
4
4
5
5
5
6
6
6
7
7
7
ATTENTION!
The displays are optimally calibrated and set at the factory for the operation of the D PluraView monitor. No image-inuencing
changes (e.g. brightness, color or contrast) should be made in the OSD menu.
User manual
CONTROLS ON THE
DISPLAYS "
CONTROLS ON THE
DISPLAYS "
Views in detail
On/o switch ( )
Menu button (MENU)
Scroll up / Volume button (/ )
On/o display:
The LED is tted with a sliding cover to
prevent the user from being dazzled.
Blue: Normal operation
Orange: Energ management
Scroll down / ECO Mode button ( ‒ / )
Input source / Auto / Exit button (AUTO)
1
2
3
45
6
ATTENTION!
The displays are optimally calibrated and set at the factory for the operation of the D PluraView monitor. No image-inuencing
changes (e.g. brightness, color or contrast) should be made in the OSD menu.
1
1
2
2
3
3
4
4
5
5
6
6
Unique
D stereo
experience
The D PluraView is ideal for all stereo software
applications in a wide range of industries.
This manual suits for next models
1
Table of contents
