1-1
Section 1 Summary of Safety Warnings and Cautions
Following is a summary of the safety warnings and cautions which must be observed when
operating or servicing this equipment. WARNINGS indicate potential danger to personnel,
and CAUTIONS indicate potential damage to equipment. These precautions are repeated,
where applicable, throughout the manual.
Observance of these safety precautions will minimize the risk of personal injury and/or the
possibility of unit damage.
The operation and maintenance procedures recommended by Scientek™ are described in this
manual. Only these recommended maintenance procedures should be followed.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
WARNING: PERSONAL INJURY AND/OR EQUIPMENT DAMAGE
HAZARD
•To avoid personal injury or equipment damage read and understand
the manual.
•Only qualified service personnel should make repairs and
adjustments to this equipment. Maintenance done by unqualified
personnel or installation of unauthorized parts could cause personal
injury, or result in equipment damage.
•Performance of scheduled preventive maintenance and minor repairs
as described in this manual are required for safe and reliable
operation of the equipment.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
1-2
WARNING: ELECTRIC SHOCK HAZARD - Lock building electrical
supply switch to OFF before performing any service on unit.
WARNING: CHEMICAL BURN/EYE INJURY HAZARD
•When replacing chemical injection components or chemical
containers residual detergent might remain in used parts or tubing.
Severe injury may occur in contact with skin or eyes.
•Always refer to the chemical's Material Safety Data Sheet.
Wear gloves and face protection
WARNING: ELECTRIC SHOCK AND/OR BURN HAZARD
•Lock building electrical supply disconnect switch to OFF, close steam,
water and air supply valves, and position power switch to OFF before
performing any service on the unit. When the power switch in ON,
door switch(s) and valves are energized, and if cycle is started hot
water/steam would enter piping and washer.
Wear gloves and face protection
WARNING: BURN HAZARD
•Allow unit to cool down before performing any service on pump,
piping and valves. Motor, pump, valves and piping surfaces become
very hot during unit operation
Wear gloves and face protection
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
1-3
CAUTION: EQUIPMENT DAMAGE HAZARD
Be careful when choosing detergents for use with the washer. Detergents
with a very high PH can be harmful to stainless steel.
CAUTION: EQUIPMENT DAMAGE HAZARD
For units equipped with Quicklock connectors and carts, ensure that the
Quicklock cart connector flange is positioned correctly over the connection
point in the washer before operation of the unit. If the cart is not positioned
correctly, damage may result and unit will not effectively wash the load.
CAUTION: EQUIPMENT DAMAGE HAZARD
Use non-abrasive cleaners when cleaning the unit. Follow direction on
containers and rub in back-and-forth motion (in same direction as surface
grain). Abrasive cleaners will damage stainless steel. Cleaner rubbed in a
circular motion or applied with a wire brush or steel wool on door and
chamber assemblies can be harmful to stainless steel. Do not use these
cleaners on painted surfaces.
CAUTION: EQUIPMENT DAMAGE HAZARD
Solenoid valves are equipped with a special material which can be attacked
by oils and grease. When replacing entire valve, wipe threads clean of
cutting oils and use Teflon tape to seal pipe joints.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
2-1
Section 2 General Information
The product literature included in this section contains factual data relating to the principal
characteristics of the Scientek™ SW6000 Series of Cart and Utensil Washers / Cage and Rack
Washers.
This literature is informative rather than instructional. It provides and conveys, through text
and illustrations, a general concept of the equipment, its purpose, capabilities, limitations and
technical specifications.
The Allen Bradley Panel View 600 is an operator interface with a color touch screen. It is
programmed to display washer’s status information and gives you full control over the
washer. It facilitates easy access and adjustment of washer’s operating parameters, full access
to ten pre-programmed operating cycles and direct information feedback with Allen Bradley
icrologix 1500 series Programmable Logic Controller (P.L.C.)M
WARNING: PERSONAL INJURY AND/OR EQUIPMENT DAMAGE
HAZARD
•To avoid personal injury or equipment damage read and understand
the manual.
•Only qualified service personnel should make repairs and
adjustments to this equipment. Maintenance done by unqualified
personnel or installation of unauthorized parts could cause personal
injury, or result in equipment damage.
•Performance of scheduled preventive maintenance and minor repairs
as described in this manual are required for safe and reliable
operation of the equipment.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-1
Section 3 Principles of Operation
3.1 GENERAL
The Scientek™ SW6000 Series Cart & Utensil Washer / Cage and Rack Washer is equipped
with an Allen Bradley Micro Logic 1500 Series programmable controller which operates all
pre-programmed cycles. The cycle description and operation are described herein on the
main control panel (soiled side, if two door pass through unit). The display is furnished with
an Allen Bradley Panel View 600 color touch screen operator interface. The auxiliary control
on clean side (if two-door pass through unit), is furnished with indicator cycle status lights
and Start/Stop and Exhaust control switches.
3.2 CYCLE DESCRIPTION
3.2.1 Initial Start-Up
1. With the POWER switch in the OFF position, the power to the front (soiled end) control
panel and, if double door unit, the rear (clean end) control panel of the unit is
disconnected and the drain line valve is in the open position.
2. When the POWER switch is turned to the ON position, the front (soiled end) control panel
is energized and, if double door unit, the rear (clean end) control panel is also energized.
Door switch(s) on the front (soiled end) and, if double door unit, rear (clean end) of the
unit are energized. The START, STOP and other switches are also energized.
3. If a door is open, then the DOOR OPEN indicator or light (red) will illuminate. If a
double door unit, then opening either door will illuminate indicator and light on clean
end of the machine.
4. If the STOP button (red two-stage) is in the locked position, then the STOP indicator will
display. If a double door unit, stop indicator light is installed, on clean end.
5. The CYCLE COMPLETE indicator light (green) will illuminate for a double door unit,
on clean end and main control will display message indicator.
6. The drain line valve will energize and close the drain line.
7. When the START button (green momentary) is pressed, the controller initiates the wash
cycle.
3.2.1 Prewash
The Prewash step is designed to remove all of the loose soil from the items being washed.
The steps occurring during this step are as follows:
•The PREWASH indicator light (amber) on clean end and message display on control
panel is illuminated.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-2
•The controller checks the state of the wash sump float switch. If it is in the closed (sump
full) position, then the controller proceeds to the next step. If it is in the open (sump not
full) position, then the fill solenoid is opened and fills the sump until the float switch
closes at which time the fill solenoid is closed. On units equipped with the heat
exchanger option, the water is preheated to 180°F (82°C) prior to entering the unit. On
units equipped with the cold water prewash option, a separate fill solenoid, attached to a
cold water line, is used to fill the unit. While the machine is filling, the FILL indicator
message is displayed. When the fill solenoid closes, the FILL indicator display is
extinguished.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
•The recirculation wash pump is activated and the prewash water is pumped through the
piping, out the rotating arms and through the quicklock connection (if unit is so equipped)
to the quicklock cart. The prewash counter is also activated and the pump remains
energized until the counter times out. During the prewash, the Aqua-pulse control valves
sequentially turn on and off the flow of circulating water to the left and right side spray
arms, and (if so equipped) the quicklock connection.
•When the prewash counter has completed its time, the drain delay counter is initiated.
During the drain delay, all the Aqua-pulse valves are left open and the water is allowed to
flow out of the spray arms back to the sump. At the end of the drain delay, the Aqua-
pulse valves are closed.
•When the drain delay counter has completed its time, the power drain counter is
initiated. During the power drain, the drain line valve opens and the wash pump is
energized. This forces the bulk of the water from the sump to the drain.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
•When the power drain counter has reached its limit, the gravity drain counter is initiated.
During the gravity drain, the wash pump is deactivated, the drain valve remains open, and
(in units so equipped) the gravity drain valve is opened. This allows any residual water in
the sump, rotating spray arms and header to drain.
•When the gravity drain counter has reached its limit, the flush drain counter is initiated.
During the flush drain, the drain line valve remains open and the fill solenoid is opened.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-3
This flushes the sump and drain line, ensuring the complete removal of any remaining
prewash residue.
•When the flush drain counter has completed its time, the drain valve closes and the fill
solenoid remains open for the next step in the cycle.
•The PREWASH stage, which has remained displayed throughout this step, is now
deactivated.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
3.2.2 Wash
The Wash step is designed to remove all of the soil from the items being washed. The steps
occurring during this step are as follows:
•The WASH indicator message is displayed and the machine continues to fill from the end
of the prewash flush drain.
•During the fill, the DETERGENT indicator message is displayed, activates the pump
signal that energizes the detergent pump. When the detergent pump timer has reached its
limit, the detergent pump is deactivated.
WARNING: CHEMICAL BURN/EYE INJURY HAZARD
•When replacing chemical injection components or chemical
containers residual detergent might remain in used parts or tubing.
Severe injury may occur in contact with skin or eyes.
•Always refer to the chemical's Material Safety Data Sheet.
Wear gloves and face protection
•The float switch is monitored and when this switch closes, the fill solenoid valve is closed.
On units equipped with the heat exchanger option, the water is preheated to 180°F (82°
C) prior to entering the unit. While the machine is filling, the FILL indicator message is
displayed. When the fill solenoid closes, the FILL display is extinguished.
•The recirculation wash pump is activated and the wash water is pumped through the
piping, out the rotating spray arms and (if the machine is so equipped) through the
quicklock connection to the quicklock cart. During the detergent wash, the Aqua-pulse
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-4
control valves sequentially turn on and off the flow of circulating water to the left and
right side spray arms, and (if so equipped) the quicklock connection.
•If the washer is equipped with a detergent neutralization system, and the detergent wash
timer has completed, the detergent neutralizer pump timer is initialized. This energizes
the detergent neutralizer pump and the NEUTRALIZER indicator is displayed and
dispenses neutralizer into the unit. The wash recirculation pump remains on during this
time. When the detergent neutralizer pump timer has completed, the neutralizer pump is
de-energized, the NEUTRALIZER display is deactivated and the detergent neutralizer
wash timer is initialized. During this time, the wash recirculation pump and Aqua-pulse
system is active in order to provide complete mixing of the neutralizer and detergent.
•When the detergent wash timer (or detergent neutralizer wash timer, if installed) has
completed its time, the drain delay timer is initiated. During the drain delay, all the
Aqua-pulse valves are left open and the water is allowed to flow out of the spray arms
back to the sump. At the end of the drain delay, the Aqua-pulse valves are closed and
the power drain timer is initiated. During the power drain, the drain line valve opens
and the wash pump is energized. This forces the bulk of the wash water from the sump to
the sewer.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
•When the power drain timer has completed, the gravity drain timer is initiated. During the
gravity drain, the wash pump is deactivated and the drain valve remains open. This allows
any residual wash water in the sump, rotating arms and manifold to drain.
•When the gravity drain timer has completed its time, the flush drain timer is initiated.
During the flush drain, the drain line valve remains open and the fill solenoid is opened.
This flushes the sump and drain line, ensuring the complete removal of any remaining
wash residue.
•When the flush drain timer has completed, the drain valve closes and the fill solenoid
remains open for the next step in the cycle.
The WASH indicator display, which has remained illuminated throughout this section, is now
deactivated.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-5
3.2.3 Acid Wash (Optional)
•The WASH indicator message is displayed the machine continues to fill from the end of
the prewash flush drain.
•During the fill, the ACID indicator message illuminates and the controller activates the
acid pump signal that energizes the acid pump timer and pump. When the acid pump
timer has completed, the acid pump is deactivated and the ACID display is deactivated.
•The controller monitors the float and when the float rises, the controller closes the fill
solenoid. On units equipped with the heat exchanger option, the water is preheated to
180°F (82°C) prior to entering the unit. While the machine is filling, the FILL message
indicator is displayed. When the fill solenoid closes, the FILL indicator message is
extinguished.
WARNING: CHEMICAL BURN/EYE INJURY HAZARD
•When replacing chemical injection components or chemical
containers residual detergent might remain in used parts or tubing.
Severe injury may occur in contact with skin or eyes.
•Always refer to the chemical's Material Safety Data Sheet.
Wear gloves and face protection
•The recirculation wash pump is activated and the wash water is pumped through the
piping, out the rotating spray arms and through the quicklock connection to the removable
header. The acid wash timer is also activated and the pump remains energized until the
timer times out. This step removes all of the scale and similar soils from the items being
washed.
•When the acid timer has completed, the neutralizer pump timer is initialized. This
energizes the neutralizer pump and the NEUTRALIZER indicator is displayed and
dispenses neutralizer into the unit. The wash recirculation pump remains on during this
time. When the neutralizer pump timer has completed, the neutralizer pump is de-
energized, the NEUTRALIZER display is deactivated and the neutralizer wash timer is
initialized. During this time, the wash recirculation pump is active in order to provide
complete mixing of the neutralizer and acid.
•When the neutralizer wash timer has completed its time, the detergent pump timer is
initialized. The wash recirculation pump and Aqua-pulse system remains active. This
energizes the detergent pump and the DETERGENT indicator is displayed and dispenses
detergent into the unit. When the detergent pump timer has completed its time, the
detergent pump is de-energized, the DETERGENT display is deactivated and the
detergent wash timer is initialized. During the detergent wash, any remaining soils are
removed. During the detergent wash, the Aqua-pulse control valves sequentially turn on
and off the flow of circulating water to the left and right side spray arms, and (if so
equipped) the quicklock connection.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-6
•If the washer is equipped with a detergent neutralization system, and the detergent wash
timer has completed, the detergent neutralizer pump timer is initialized. This energizes
the detergent neutralizer pump and the NEUTRALIZER indicator is displayed and
dispenses neutralizer into the unit. The wash recirculation pump remains on during this
time. When the detergent neutralizer pump timer has completed, the neutralizer pump is
de-energized, the NEUTRALIZER indicator display deactivated and the detergent
neutralizer wash timer is initialized. During this time, the wash recirculation pump and
Aqua-pulse system is active in order to provide complete mixing of the neutralizer and
detergent.
•When the detergent wash timer (or detergent neutralizer wash timer, if installed) has
completed, the drain delay timer is initiated. During the drain delay, all the Aqua-pulse
valves are left open and the water is allowed to flow out of the spray arms back to the
sump. At the end of the drain delay, the Aqua-pulse valves are closed.
•When the drain delay timer has completed, the power drain timer is initiated. During the
power drain, the drain line valve opens and the wash pump is energized. This forces the
bulk of the wash water from the sump to the drain.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
•When the power drain timer has completed, the gravity drain timer is initiated. During
the gravity drain, the wash pump is deactivated and the drain valve remains open. This
allows any residual wash water in the sump, rotating arms and header to drain.
•When the gravity drain timer has completed, the flush drain timer is initiated. During
the flush drain, the drain line valve remains open and the fill solenoid is opened. This
flushes the sump and drain line, ensuring the complete removal of any remaining wash
residue.
•When the flush drain timer has completed, the drain valve closes and the fill solenoid
remains open for the next step in the cycle.
•The WASH indicator display, which has remained illuminated throughout this section, is
now deactivated.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-7
3.2.4 Rinse 1
•The RINSE 1 indicator light display message on the control panel illuminates and the
machine continues to fill from the end of the wash flush drain.
•The controller monitors the float and when the float rises, the controller closes the fill
solenoid. On units equipped with the heat exchanger option, the water is preheated to
180°F (82°C) prior to entering the unit. While the machine is filling, the FILL message
on the control panel also illuminates. When the fill solenoid closes, the FILL indicator
message is extinguished.
•The recirculation wash pump is activated and the rinse water is pumped through the
piping, out the rotating spray arms and through the quicklock connection to the removable
header. The rinse 1 timer is also activated and the pump remains energized until the
timer times out. This step provides thorough removal and rinsing of detergent wash water
from the items being washed and the inside of the cabinet. During Rinse 1, the Aqua-
pulse control valves sequentially turn on and off the flow of circulating water to the left
and right side spray arms, and (if so equipped) the quicklock connection.
•When the rinse 1 timer has completed, the drain delay timer is initiated. During the
drain delay, all the Aqua-pulse valves are left open and the water is allowed to flow out of
the spray arms back to the sump. At the end of the drain delay, the Aqua-pulse valves are
closed.
•When the drain delay timer has completed, the power drain timer is initiated. During the
power drain, the drain line valve opens and the wash pump is energized. This forces the
bulk of the wash water from the sump to the drain.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
•When the power drain timer has completed, the gravity drain timer is initiated. During
the gravity drain, the wash pump is deactivated and the drain valve remains open. This
allows any residual wash water in the sump, rotating spray arms and header to drain.
•When the gravity drain timer has completed, the flush drain timer is initiated. During
the flush drain, the drain line valve remains open and the fill solenoid is opened. This
flushes the sump and drain line, ensuring the complete removal of any remaining wash
residue.
•When the flush drain timer has completed its time, the drain valve closes and the fill
solenoid remains open for the next step in the cycle.
•The RINSE 1 indicator message, which has remained illuminated throughout this section,
is now deactivated.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-8
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
3.2.5 Rinse 2
•The RINSE 2 indicator message display on control panel illuminates and the machine
continues to fill from the end of the rinse 1 flush drain.
•The controller monitors the float and when the float rises, the controller closes the fill
solenoid. On units equipped with the heat exchanger option, the water is preheated to
180°F (82°C) prior to entering the unit. While the machine is filling, the FILL indicator
message control panel also illuminates. When the fill solenoid closes, the FILL message
is extinguished.
•The recirculation wash pump is activated and the final rinse water is pumped through the
piping, out the rotating arms and through the quicklock connection to the removable
header. The rinse 2 timer is also activated and the pump remains energized until the
timer times out. This step provides thorough final rinsing of the items being washed and
the inside of the cabinet. During Rinse 2, the Aqua-pulse control valves sequentially turn
on and off the flow of circulating water to the left and right side spray arms, and (if so
equipped) the quicklock connection.
•When the rinse 2 timer has completed its time, the wash recirculation pump is deactivated
and the controller verifies whether to hold or drain the final rinse water. If the controls
have been set to retain the water, then the unit proceeds to the exhaust step of the
program.
•If the controls have been set to drain the water, and the Rinse 2 timer has completed its
time, the drain delay timer is initiated. During the drain delay, all the Aqua-pulse valves
are left open and the water is allowed to flow out of the spray arms back to the sump. At
the end of the drain delay, the Aqua-pulse valves are closed.
•When the drain delay timer has completed, then the power drain timer is initiated.
During the power drain, the drain line valve opens and the wash pump is energized. This
forces the bulk of the rinse water from the sump to the sewer.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-9
•When the power drain timer has completed, the gravity drain timer is initiated. During
the gravity drain, the wash pump is deactivated and the drain valve remains open. This
allows any residual wash water in the sump, rotating arms and header to drain to the
sewer.
•When the gravity drain timer has completed, the drain line valve remains open and the
unit proceeds to the next step.
•The RINSE 2 indicator display message, which has remained illuminated throughout this
section, is now deactivated.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
3.2.6 Exhaust
•The unit is equipped with an exhaust duct for direct venting via power operated damper to
common house HVAC system, or via dedicated exhaust blower. In either case the P.L.C.
provides a dedicated signal to vent machine for timed period. The message display will
show exhaust time duration and will either command operation of damper or fan for given
time. When the exhaust timer signal is deactivated, the exhaust display is extinguished.
•The CYCLE END indicator message is now activated and remains active until the unit is
started again or the POWER is turned OFF. If the controls are set to drain the unit, then
the drain line valve is open and the sump is empty. If the controls are set to retain the
final rinse, then the drain line valve is closed and the sump is full.
The unit can now be unloaded and is ready to start again.•
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
3-10
3.2.7 Cycle Interruption
•When the two stage STOP button (red) is pressed during a cycle, all electrical components
shut off, stopping washer operation.
•If a door is opened during a cycle, the door switch is activated, all electrical components
shut off and the washer stops.
WARNING: FALL HAZARD
To prevent falls, keep floors dry. Promptly clean up any spills or drippage.
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
•The STOP button must be turned clockwise in order to release it. The unit will not start so
long as the STOP button is pressed and locked.
W
hen the START button (green) is pressed, the cycle resumes from where it left off.
WARNING: BURN HAZARD
•Allow unit to cool down before performing any service on pump,
piping and valves. Motor, pump, valves and piping surfaces become
very hot during unit operation
Wear gloves and face protection
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
4-1
Section 4 Description of Control Panel and Switches
4.1 POWER OFF/ON
Two position maintained - illuminated green “On”
Turns on the power to the washer controls (120 V). Initial start up procedure must be turned
to “On” position green illuminated.
The Power switch can also be used to reset the machine to clear an alarm or reset cycle.
However care should be taken as when power is “Off” drain valves will open and water will
be lost. Also neutralization will not take place with power “Off” as water is draining!
WARNING: BURN HAZARD
•Doors, washer interior and washed wares may be hot.
•Hot water/steam may be sprayed through door opening if door is
opened too soon - press STOP button and wait until water flow stops
before opening door.
Wear gloves and face protection.
4.2 STOP
Red mushroom headed maintained two-position switch, must be out to “Run”. This is used as
an emergency stop button or temporary "hold". It is two-stage button and must be turned
clockwise in order to release it. When pressed, this button will stop the cycle and turn off the
pump circulation tank sump heater and chemical injection system. When released, the sump
heaters will be reactivated but the start button must be pressed to activate the pump
circulation.
Note: there will often be two or more stop buttons located on the machine, so the correct
button has to be released, possibly more than one was activated! Message display will show
message: “Stop Button Pushed”, if one is still engaged. Upon release, display will show
“Machine Ready, Push Start Button”.
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]

Operating and Maintenance Manual
Scientek Washer Model SW-6000
Revision-3, Sept. 2007
4-2
4.3 SERVICE OFF/ON
Two position key operated switch give supervisor or maintenance personnel access to
“Locked-out” features. “Off” position with key removed would be the normal operating
condition for user. Key in and turned to “On” position unlocks access to touch screen
buttons, “Set-up Menu” and “Service Menu”. With these two buttons you can proceed
through screen menus to customize any parameters of cycle, or restrict access to certain
cycles, and perform diagnostic functions of energizing devices through PLC inputs and
outputs. For more information on these features refer to operator interface instructions,
ection “Set-up Menu” and “Service Menu”.s
WARNING: ELECTRIC SHOCK HAZARD - Lock building electrical
supply switch to OFF before performing any service on unit.
WARNING: PERSONAL INJURY AND/OR EQUIPMENT DAMAGE
HAZARD
•To avoid personal injury or equipment damage read and understand
the manual.
•Only qualified service personnel should make repairs and
adjustments to this equipment. Maintenance done by unqualified
personnel or installation of unauthorized parts could cause personal
injury, or result in equipment damage.
•Performance of scheduled preventive maintenance and minor repairs
as described in this manual are required for safe and reliable
operation of the equipment.
WARNING: ELECTRIC SHOCK AND/OR BURN HAZARD
•Lock building electrical supply disconnect switch to OFF, close steam,
water and air supply valves, and position power switch to OFF before
performing any service on the unit. When the power switch in ON,
door switch(s) and valves are energized, and if cycle is started hot
water/steam would enter piping and washer.
Wear gloves and face protection
Scientek Technology Corporation Tel: [phone]
7943A Progress Way, Delta, BC V4G 1A3 Fax: [phone]
