Scientek SW-4600GWD User manual

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
SCIENTEK
GLASSWARE WASHER / DRYER
MODEL SW-4600GWD
OPERATION AND MAINTENANCE MANUAL

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
TABLE OF CONTENTS SW-4600
SECTION 1 SUMMARY OF FEATURES AND OPTIONS 1-1
SECTION 2 GENERAL SYSTEM DESCRIPTION 2-1
2.1 MODEL COVERED 2-1
2.2 AVAILABLE OPTIONS 2-2
2.3 STANDARD TREATMENT CYCLE 2-3
SECTION 3 INSTALLATION 3-3
3.1 LOCATION 3-2
3.2 UTILITIES REQUIRED 3-2
3.3 ELECTRIC POWER CONNECTION 3-3
3.4 INSTALLATION CONSIDERATIONS 3-4
3.5 PRE-SERVICE OPERATION CHECKOUT 3-4
SECTION 4 OPERATION 4-4
4.1 PRELIMINARY PROCEDURE 4-2
4.2 LOADING WASHER 4-3
4.3 STARTING WASHER 4-3
4.4 SHUTTING-DOWN WASHER 4-4
SECTION 5 OPERATION THEORY 5-1
5.1 POWER "ON" CONDITION 5-1
5.2 WASH CYCLE START-UP OPERATION 5-1
5.3 STOP BUTTON OPERATION 5-1
5.4 WATER LEVEL SWITCH OPERATION 5-1
5.6 DETERGENT MODE OPERATION 5-2
5.7 EXTENDED WASH TIMER OPERATION 5-2
5.8 SUMP HEATER OPERATION 5-2
5.9 DRAINAGE 5-2
5.10 FINAL RINSE OPERATION 5-3
5.11 POWER "OFF" CONDITION 5-3
5.12 "IDLE" STATE CONDITION 5-3
5.13 MICROPROCESSOR CONTROL SYSTEM 5-3

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
SECTION 6 OPERATOR INTERFACE INSTRUCTION 6-1
6.1 INTRODUCTION TO PANELVIEW PV600 6-2
6.2 MAIN MENU SCREEN 6-3
6.3 OPERATION SCREEN 6-4
6.3.1 CONTROL BUTTONS: 6-5
6.3.2 NAVIGATION BUTTONS 6-7
6.3.3 STATUS INDICATION: 6-8
6.3.4 CYCLE SELECTION 6-10
6.4 SET-UP MENU 6-11
6.4.1 WASHER SET-UP MENU 6-12
6.4.1.1 CYCLE TIME SETTINGS 6-13
6.4.1.2 CYCLE TEMPERATURE SETTINGS 6-14
6.4.1.3 CYCLE WATER SUPPLY /DRAIN SETTINGS 6-15
6.4.1.4 CYCLE LOCKOUT 6-16
6.4.1.5 CYCLE DESCRIPTION 6-17
6.4.1.6 COMMON TIME SETTINGS 6-18
6.4.1.7 TEMPERATURE READING OFF-SET ADJUSTMENT 6-19
6.4.1.8 CHEMICAL DESCRIPTION 6-20
6.4.1.9 SYSTEM DATE/TIME ADJUSTMENT 6-20
6.4.2 CHEMICAL SYSTEM SET-UP 6-21
6.5 SERVICE MENU 6-22
6.5.1 TEST PLC INPUT SIGNALS (SENSORS) 6-22
6.5.2 TEST PLC OUTPUT SIGNALS (MOTORS,VALVES,LIGHTS) 6-23
6.5.3 PRIMING CHEMICAL PUMPS 6-24
6.5.4 TEST LOAD AND UNLOAD TABLES 6-25
6.6 ALARM LIST 6-26
6.7 PASSWORD MANAGEMENT 6-27
SECTION 7 MAINTENANCE 7-1
7.1 SCHEDULE 7-1
7.2 SURFACE CLEANING 7-1
7.3 CHAMBER INTERIOR 7-1
7.4 DEBRIS BASKETS AND SUMP SCREEN 7-1
7.5 STRAINERS 7-2
7.6 ROTARY SPRAY HEADERS 7-2
7.7 AIR INLET FILTER 7-3
7.8 PUMP MOTOR 7-3
7.9 PUMP 7-3
SECTION 8 TROUBLESHOOTING 8-1
8.1 PUMP PRESSURE LOW 8-1
8.2 MACHINE DOES NOT DRAIN 8-1
8.2 WATER FILL (HOT,COLD OR DI) CONTINUES TO RUN 8-1

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
8.4 SOLENOID VALVES 8-1
SECTION 9 MAINTENANCE PARTS 9-1
APPENDIX A: CONTROL PANELS 9-1
APPENDIX B: MICRO PROCESSOR INPUT/OUTPUT ADRESSES 9-1
APPENDIX C: PANEL ARRANGEMENT & PLC WIRING CONNECTION DIAGRAM 9-1
APPENDIX D: PROGRAM CYCLE CHARTS 1-10 AND COMMON SETTINGS 9-1
APPENDIX E: SMC VALVE CONFIGURATION 9-1
APPENDIX F: PIPING AND INSTRUMENTATION DIAGRAM 9-1
APPENDIX G: SHOP DRAWINGS 9-1
APPENDIX H: WARRANTY 9-1

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
Section 1 SUMMARY OF FEATURES AND OPTIONS
Features and Options Scientek SW-4600
Construction
Configuration
Load Size
Washing Action
304L Stainless Steel
Recessed into fascia wall at both ends
26”X 26“ X 27” H
(660mm X 660mm X 686mm)
Rotary Spray Arms
Door
Type
Number
Viewing window standard
Automatic Vertical lift type
Two (single option)
Washing Capacity
Number of loading shelves
Size of each shelf
Standard basket size
Load Throughput
8 baskets per cycle
Four
23-1/4” X 25” (591 X 635)
12” X 20” X 4” (305 X 508X 102)
16 Std. baskets per hour
Cycle Time
Pre-wash
Detergent wash
Rinse
final rinse treatment
Dryer
28 Minutes*
One minutes (adjustable)
Five minutes (adjustable)
One minutes (adjustable)
Three minutes (adjustable)
Eight minutes approx. (adjustable)
Controller Unit
Temperature Guarantee
Recording Device
Micrologix 1500 micro processor
185F / 85C (adjustable)
Optional Printer or PC connection standard
Display/Control Panel
Door-open
Cycle interrupt
Temperature readout
Wash cycle selection
LCD display / touch pad
LCD display / touch pad
LCD display / touch pad
LCD display / touch pad
LCD display / touch pad
Pump Capacity
Pump pressure
Circulatory piping
3 HP, 110 GPM
68’ head pressure
1 1/2” SCH 10 s/s pipe
Water Temperature Sump Heater Steam (120-185)
Electric (120-185) (optional)
Overall Machine Size 42" X 32" X 78"
(1067 X 813 X 1981)
Electrics includes dryer
Power Total
Voltage (options)
60 Hz / 3 phase
13 kw
208V / 220-240V / 460-480V / 575V-600V
Warranty 2 Years on part / 1 year labour
* See Appendix ‘D’ cycle 1 for full cycle description

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
2-1
Section 2 GENERAL SYSTEM DESCRIPTION
2.1 MODEL COVERED
This manual covers the SW-4600 SERIES washer, which has been designed to provide a fully
automatic programmed cycle for the processing of laboratory glassware and utensils. It is
available in the following cabinet configurations.
Type I: Single door, freestanding unit
Type II:Single door, Recessed on wall installation
Type III:Two door, Pass Thru, free standing, recessed one end or recessed two ends
All Scientek washers utilize a Micro-processor Control Unit (MCU) which has been designed to
provide ten pre-programmed timed cycles of washing, rinsing and drying.
The wash chamber can accommodate loads of up to 27" inches high, 26" wide and 26" in depth.
The SW-4600 has a full size glass door. Every washer comes standard with a multi-level, multi-
spray arm adjustable loading rack. The loading rack has a maximum of four levels to
accommodate 4" deep baskets. Each loading shelf can be removed to accommodate larger loads.
The washer comes equipped with blanking plates to divert water flow when any one of the four
levels is not in use. Scientek offers a stainless steel transfer cart with a lower support shelf, as
an option, to store and transport additional loading racks.
Washers are equipped with a 3.0 HP motor and stainless steel pump. The pump is pressure-
rated for 110 GPM at 68 foot head pressure. Water treatment is delivered to the processing load
through a 1-1/2 inch stainless steel circulatory piping system that provides a high impingement
pressure on both the interior and exterior surfaces of the load. As each processed load is treated,
the circulating water is filtered by two separate debris screens to remove suspended particles
and to prevent paper or foreign matter reaching the pump impeller.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
2-2
2.2 AVAILABLE OPTIONS
a. WATER TEMPERATURE BOOSTER raises the temperature of the supply water to
185°F ( 85°C ). There are two methods available:
Steam heater: 120oF (49oC) raise to 185oF (85oC)
Electric heater: 120oF (49oC) raise to 185oF (85oC)
b. DOOR CONFIGURATION GUILLOTINE DOOR TYPE Specially designed
door mechanism automatically opens and closes the door. For safety reasons the door
mechanism will automatically stop closing and will open the door automatically when
blocked by any obstruction.
TWO GUILLOTINE DOORS This configuration allows for "pass-through"
operation of the washer: soiled side is separated from clean side. Only one door can be
opened at one time and there is a door interlock system present to eliminate the
possibility of cross-contamination by preventing both doors from being opened
simultaneously.
c. FINAL RINSE will be with house supplied D.I. water and can be mixed, by factory
pre-programming, with a milk lubrication agent.
d. AUTOMATIC (LIQUID) DETERGENT DISPENSER SYSTEM includes a
detergent pump, which can be preprogrammed to issue the correct amount of cleaning
chemical per load.
e. AUTOMATIC (LIQUID) MILK LUBE SYSTEM includes a milk-lube pump,
which can be preprogrammed to issue the correct amount of lubricating chemical per
load.
f.AUTOMATIC (LIQUID) ENZYME DISPENSER SYSTEM includes an enzyme
pump, which can be preprogrammed to issue the correct amount of enzyme fluid at the
start of wash cycle, pre-programmed to client’s specifications.
g. PANEL MOUNTED DATA REPORT STRIP PRINTER shows events, times and
temperatures.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
3-3
2.3 STANDARD TREATMENT CYCLE
1. PRE-WASH
On initial start-up, the wash chamber fills with fresh WARM water. Pre-wash solution
tempers the instruments and glassware against possible thermal shock, and flushes loose
soil from the load. Upon completion of pre-wash, the process solution is power drained
to the sewer.
2. DETERGENT WASH
Detergent wash receives fresh hot water to treat the soiled instruments and glassware
load. Upon filling with water for the Detergent Wash, the detergent will be injected into
the wash chamber by the pre-programmed pump. Upon completion of Detergent Wash,
the water is power drained to sewer.
3. FIRST RINSE
Rinse 1 receives fresh hot water to remove the bulk of the detergent from the instrument,
glassware, piping, pump and wash chamber. Upon completion of Rinse 1, the water is
power drained to the sewer.
4. SECOND RINSE
Rinse 2 receives fresh hot water to remove any residual traces of detergent from the
instrument load and washer. Upon completion of Rinse 2, the water is power drained to
sewer. A temperature guarantee is programmed into this rinse to ensure the 182oF (83oC)
disinfection temperature is achieved.
5. OPTIONAL FINAL DI WATER RINSE
DI Rinse receives fresh D.I. water from the institutions supply to remove any residual
traces from the instruments and glassware. Upon the completion of the DI Rinse the
water is power drained to the sewer to prevent cross contamination.
6. MILK LUBE INJECTION
Milk lube injection shall be pre-programmed into final rinse for instrumentation cycles if
required.
7. OPTIONAL ENZYME INJECTION
Enzyme injection shall be pre-programmed into pre-wash (hot or cold water option) for
cycles as required.
Section 3 INSTALLATION

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
3-2
3.1 LOCATION
Install the washer as per installation details on the drawings provided for the unit. All local
municipal by-laws should be followed.
3.2 UTILITIES REQUIRED
a. ELECTRIC POWER
To be specified by customer:
Electric power supply Steam heated unit Electric heated unit
208 Volts, 3 phase, 60Hz 60 Amp service 125 Amp service
480 Volts, 3 phase, 60Hz 30 Amp service 60 Amp service
b. ELECTRIC POWER FOR CONTROLS
A step-down transformer is provided with the washer, which operates at 115 VAC and
a power supply is also provided for the 24 VDC controls.
c. HOT WATER
A tap water supply providing 12 gpm, at 30 to 60 psig is required. The water
temperature should be 120oF min. Approximately 44 gallons of water is used per cycle
(depending on pre-programmed cycle). The supply connection is 1/2" NPT.
d. DRAIN
The floor drain line connected to the machine must be 2" NPT. This will permit a
discharge of 8 - 10 gallons to the sewer in approximately 10 seconds.
e. AIR
An air supply at 80 psig is required to operate the pneumatic valves. Air consumption
is about 1 cubic ft. per wash cycle. The connection to the air supply is 1/4" NPT.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
3-3
f. D.I. WATER
A D.I. water supply providing 12 gpm at 30-60 psig is required. The supply
connection is 1/2" NPT. Approximately 10 gallons of D.I. water is used per cycle.
g. DRYING PACKAGE (Optional)
Will be preprogrammed into each cycle by the factory. The drying time will be
between 8 and 10 minutes per cycle
h. STEAM
A steam supply providing 393 lbs. per hour at 40-60 psig is required. The supply
connection is 3/4" NPT. Steam consumption is 45 lbs per cycle. This includes
consumption for heating DI water (optional).
i. VENT
Direct vent connection to facility duct system is not recommended. Collection hood(s)
over doors and vent is recommended. Total 300-500 cfm extraction capacity should be
provided.
j. MACHINE TANK OVERFLOW
The machine tank overflow is pre-plumbed into the piping of the washer.
k. COLD WATER DRAIN COOL DOWN (Optional)
For cold water pre-wash a 1/2” NPT cold water supply @ 12 GPM @ 30 - 60 psig is
required. Approx. 10 gal. of cold water is consumed per cycle.
Note: Required pressures given for water, steam and air supply lines, range from
minimum to maximum. If the services at the facility exceed these stated values a
suitable pressure regulator must be installed before the tie-in connection is made.
3.3 ELECTRIC POWER CONNECTION
a. The supply power connections as specified are made directly to the L1, L2, L3 line
terminals in the motor starter panel, for single circuit machines that are steam heated.
b. A separate fused disconnect switch should be provided in the power source for each
circuit to the washer.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
4-4
3.4 INSTALLATION CONSIDERATIONS
a. Shut-off valves should be installed in the air, water and steam supply lines. These
should be readily accessible for emergency shutdowns and regular maintenance.
b. A steam-trap is recommended for installation in the steam supply line to ensure dry
steam.
c. All installation details and instructions provided with the unit must be followed.
d. Installation should be performed by qualified personnel.
3.5 PRE-SERVICE OPERATION CHECKOUT
a. Open the following supply valves as applicable: Water, Steam, Air, D.I. Water.
b. Before turning on the main power to the washer, ensure that all the conditions under
which the unit is placed is safe and secure.
c. Turn the POWER ON button on the front control panel of the washer to the ON
position. This switch illuminates to indicate that the washer is active.
d. Operate the machine as directed in Section 3 through a complete cycle. Note that the
pump shaft must rotate in the correct direction. In the event that the shaft rotation is
not correct, disconnect the main power and reverse any two leads (L1, L2 or L3) in
the pump motor starter panel. This effectively reverses the polarity. Incorrect
rotation of the pump can result in pump damage.
e. The tank temperature is to be calibrated in the factory and should not require an
adjustment.
f. On washers equipped with steam sump heater, perform the following adjustment.
- check and secure fittings
- tighten the sump coil support nuts after two or three hours of operation
- re-check the tightness after 24 hours.
Section 4 OPERATION

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
4-2
4.1 PRELIMINARY PROCEDURE
a. Ensure that all conditions of SECTION 3 have been met.
b. 1) Turn “Power On” selector to ON position. Green illumination should be lit.
2) On touch screen “Main Menu” press Operation Screen button.
3) On Operation Screen press “Door Open” button.
4) Use transfer cart to position header inside the washer cabinet, and locate
header over quicklock connection.
5) On Operator Screen press “Close Door” button.
6) If correct cycle selection is not already indicated, press “Cycle List” navigation
button.
7) You will now scroll down through ten cycles with cursor. At desired
highlighted cycle press “Enter”
8) This will take you back to Operation Screen, where at the top will display new
choice of cycle.
9) If correct selection now press “Start” button.
10) Washer will proceed through steps of cycle to display at finish, “Cycle
Complete.Remove load.”
11) At the end of cycle the door will open automatically (For two door unit,
clean side door will open).
12) Use transfer cart to unload header and remove.
13) Close clean side door if two door pass through model, if single door prepare
next load for new cycle.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
4-3
4.2 LOADING WASHER
a. Adjust the header shelving height according to load basket heights.
b. Fill the multi-level loading rack with the items to be processed.
c. Position the loaded rack within the wash cabinet to fully engage over the quick-lock
connector.
Note: A transfer table will be used for transporting and loading headers into and out of
the washer.
d. Close the door by pressing "Door Close" button on touch pad.
4.3 STARTING WASHER
After the power to the washer has been turned on, the following steps should be followed:
a. Push the START button on touch pad control. The wash chamber begins to fill with
water. The water level in the sump is controlled by the liquid level switch.
b. After the initial fill, the Pre-wash indicator illuminates and the unit operates in the Pre-
wash stage of selected cycle.
c. A three-step drain sequence follows: power drain, gravity drain, flush drain.
d. The wash chamber will fill with hot water. While filling the water, the detergent will
be automatically injected into the wash chamber. Then the wash cycle begins to wash.
e. The unit continues through the wash cycle and the appropriate descriptions are shown
on the display screen to match the various stages of the cycle. Display screen will read
"Cycle Complete. Remove load" when wash cycle is complete.
f . All machines come with ten pre-programmed wash cycles. To customize wash cycles
please refer to section 6.4 ‘Set-up Menu’.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
4-4
4.4 SHUTTING-DOWN WASHER
a. Shut off the electric power to the washer.
b. Shut off all the supply lines connected to the washer: compressed air, steam, hot
(and/or cold) water, de-ionized water.
c. When the washer is shut down for the day, it is recommended that the debris baskets
and screens be removed from the washer, emptied and cleaned. Passing the baskets
and screens under a stream of water is usually sufficient.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
4-5

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
5-1
Section 5 OPERATION THEORY
5.1 POWER "ON" CONDITION
The washer is turned on by turning power switch to ON position. The switch illuminates, and the
drain valve closes automatically.
5.2 WASH CYCLE START-UP OPERATION
Pressing the START button on the panel display signals the microprocessor to begin a
programmed wash cycle. The microprocessor proceeds logically depending on the settings of the
various program parameters for a selected cycle..
5.3 STOP BUTTON OPERATION
The operation of the washer is halted when the STOP button is depressed. This condition is
indicated by a message on the operator interface and STOP light on the clean side control panel..
5.4 WATER LEVEL SWITCH OPERATION
The liquid level switch monitors the level of water in the sump. If the sump is not full, then the
microprocessor signals the water-fill solenoid to open, allowing fresh water to enter the wash
chamber. When a full condition is reached, the microprocessor proceeds to the next step of the
programmed wash cycle.
Timed fill delay option is available to compensate for the volume of water in re-circulating piping
and various headers.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
5-2
5.5 WASH CHAMBER "FILL" OPERATION
Before the fill solenoid is opened, the microprocessor checks the signal from liquid level switch.
If the signal is not present, then the microprocessor signals the fill solenoid to open. This allows
fresh water to enter and fill the sump. Once the tank is full, the fill solenoid is closed.
5.6 DETERGENT MODE OPERATION
Washers are programmed to automatically inject detergent at the start of wash cycle, a pre-set
value of 15 seconds for each cycle is standard and can be adjusted at user end.
Refer to the AVAILABLE OPTIONS section in this manual for complete listing and description
of the various detergent dispensing systems available.
5.7 EXTENDED WASH TIMER OPERATION
Refer to section 6.4.1.1 ‘Cycle time settings’ to adjust wash and rinse times in each individual
cycle, if you do not find the suitable times that are pre-set in the ten-cycle selection.
5.8 SUMP HEATER OPERATION
The sump heater can be specified to be electric or steam. The operation is controlled by the
microprocessor, and the liquid level switch. Only when the signal from liquid level switch
indicates full sump, the sump heater operate. This safety feature ensures that an over-heat dry
condition never occurs.
5.9 DRAINAGE
The programmed wash cycles include a specially designed three-sequence drain system. After
each washing and rinsing, water is drained in the following manner: power drain, gravity drain,
and flush drain.
Power drain activates the pump motor, and forces the water to drain quickly. Gravity drain de-
activates the pump motor, and allows the water to drain by gravity. Flush drain allows fresh
water to enter the wash chamber as the drain valve remains open for several seconds. This step
serves to flush out and rinse away any detergent residue at the bottom of the sump.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
5-3
5.10 FINAL RINSE OPERATION
Final rinse can use D.I. water or tap water. The milk lube can be injected if required. This will be
pre-programmed by the factory and can be altered to suit the facility.
5.11 POWER "OFF" CONDITION
To turn washer OFF, switch power switch to “OFF”, green light will go off. The drain valve
automatically opens to allow the sump to completely drain by gravity.
5.12 "IDLE" STATE CONDITION
The "idle" state condition describes the washer when it is in-between loads. After a wash cycle
has completed, and the next one has not yet begun, the only illumination on the display panel is
“Ready to Wash”, select cycle and press start button.
5.13 MICROPROCESSOR CONTROL SYSTEM
The Microprocessor Control System is based on an Allen Bradley Micrologix 1500 series
microprocessor controller.
The Allen Bradley microprocessor controller is an industrial grade controller that has proven its
dependability, durability and performance primarily in heavy industrial environments such as
pulp and paper mills, mining operations, and industrial plants for such functions as machine tools,
material handling, assembly machines, robotics, and energy management.
The heart of the system is the “Smart Control” operator interface. This is an Allen Bradley
PanelView 600 color touch screen interface, programmed with user display functions for
complete information feedback during all ten cycles.
Unit will also provide diagnostic and service functions for testing PLC inputs and outputs.

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
5-1

Operating and Maintenance Manual
Scientek Washer Model SW-4600GWD
Revision 4, June 2005
Scientek Technology Corporation Tel: [phone]
11151 Bridgeport Road, Richmond, BC V6X 1T3 Fax: [phone]
6-1
Section 6 OPERATOR INTERFACE INSTRUCTION
