Scion 2012 tC User manual

00505-QRG12-TC
QUICK
REFERENCE
GUIDE
tC 2012
GET INFORMED.
ROLL.
©2011 Scion, a marque of Toyota Motor Sales, U.S.A., Inc.
Printed in U.S.A. 5/11
11-TCS-05091
EMAIL
www.scion.com
Contact
-
CHAT
www.scion.com
Have a Question?
Contact
-
PHONE
1.866.70.SCION
-
MAIL
SCION
19001 S. Western Ave.
D102, P.O. Box 2742
Torrance, CA 90509-2742
USA
-
WEB
www.scion.com
-
11-TCS-05091_QRG_MY12_Scion_tC_1_0_lm.indd 1 5/14/11 8:05 AM
Information Provided by:

This Quick Reference Guide is a summary of basic vehicle operations.
It contains brief descriptions of fundamental operations so you can
locate and use the vehicle’s main equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for the
Owner’s Manual located in the vehicle’s glove box. We strongly
encourage you to review the Owner’s Manual and supplementary
manuals so you will have a better understanding of the vehicle’s
capabilities and limitations.
Your dealership and the entire staff of Scion, a marque of Toyota
Motor Sales, U.S.A., Inc., wish you many years of satisfied driving in
your new SCION tC.
2012
Scion tC OVE
FEAT
SAF
EME
IND
!A word about safe vehicle operations
This Quick Reference Guide is not a full description of SCION tC
operations. Every SCION tC owner should review the Owner’s
Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in
color throughout the Owner’s Manual. Each box contains safe
operating instructions to help you avoid injury or equipment
malfunction.
All information in this Quick Reference Guide is current at the
time of printing. Toyota reserves the right to make changes at any
time without notice.
2012Scion-tC.qxd 5/14/11 9:05 AM Page 2
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
1
Auto lock/unlock 8
Engine maintenance 8
Fuel tank door opener and cap 6
Hood release 8
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry 6
Smart Key system 7
Air Conditioning/Heating 14
Automatic Transmission 9
AUX port/USB port 14
Bottle holders 15
Clock 13
Cruise control 11
Cup holders 15
Light control-Instrument panel 13
Lights & turn signals 11
Moonroof 12
Parking brake 9
Power outlet 15
Seat adjustments-Front 10
Seat adjustments-Rear 10
Seats-Head restraints 10
Steering wheel switches 15
Tilt steering wheel 9
Windows 13
Windshield wipers & washers 12
Brake override 19
Door locks 16
Floor mat installation 19
Seat belts 16
Spare tire & tools 17
Star Safety SystemTM 18
Tire Pressure Monitoring (warning) System 16
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
INDEX
2012Scion-tC.qxd 5/18/11 12:35 PM Page 1
Information Provided by:

2
OVERVIEW
Power outside rearview mirror controls
Hood release
Headlight and turn signal controls
Paddle shift switches1
Wiper and washer controls
Cruise control1
Ignition switch (standard key)1
Steering wheel audio controls2
Air Conditioning controls
R
E
C
C
F
E
P
“
T
1
2
“
Instrument panel
2012Scion-tC.qxd 5/14/11 8:50 AM Page 2
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
3
Rear window defogger switch
Emergency flasher switch
Clock
Clock adjustment buttons
Front passenger occupant classification indicator
Engine immobilizer system indicator1
Power outlet
“ENGINE START STOP” button (Smart Key)1
Tilt and telescopic steering lock release
1If equipped
2For details, refer to the “SCION Audio System Owner’s Manual” or
“SCION Navigation System Owner’s Manual.”
2012Scion-tC.qxd 5/14/11 8:46 AM Page 3
Information Provided by:

4
OVERVIEW
2If th
Tachometer
Service indicator and reminder
Fuel gauge
Automatic Transmission shift position indicator (if equipped)
Speedometer
Odometer/trip meter display change button
Odometer/trip meter display
Low fuel level warning
Instrument panel light control knob
Instrument cluster
Seat belt reminder
(alarm will sound if speed is over 12 mph)
Brake system warning1
Charging system warning1
Low engine oil pressure warning1
Malfunction/Check Engine indicator1
Indicator symbols
Open door warning
AIR BAG ON and AIR BAG OFF indicator
1If indicator does not turn off within a few seconds of starting engine, there may be a
malfunction. Have vehicle inspected by your Toyota dealer.
For details, refer to “Indicators and warning lights,” Section 2-2, 2012 Owner’s
Manual.
2012Scion-tC-2ndpg 4_5.qxd:Layout 1 5/17/11 6:32 PM Page 2
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
5
2If this light flashes, refer to “Cruise control” Section 2-4, 2012 Owner’s Manual.
Anti-lock Brake System warning1
Engine oil replacement reminder1
Turn signal indicators
Headlight low/high beam indicator
Airbag SRS warning1
Low Tire Pressure Warning1
Cruise control indicator2
High coolant temperature warning1
Slip indicator
Low fuel level warning
Automatic Transmission fluid temperature warning1
Engine immobilizer system indicator
Vehicle Stability Control OFF indicator1
ECO driving indicator1
Low engine coolant temperature indicator
Traction Control OFF indicator1
Electric power steering system warning1
Smart Key system warning
s
2012Scion-tC.qxd 5/14/11 8:48 AM Page 5
Information Provided by:

6
OVERVIEW
Keyless entry
Push
Push ONCE: Driver door
TWICE: All doors
Locking operation
Unlocking operation
Panic button
Push and hold
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for
safety.
Fuel tank door opener and cap
Turn to open
Store
Pull up
NOTE: Tighten cap until one click is heard. If the cap is not tightened enough,
Check Engine “ ” indicator may illuminate.
Without Smart Key system
Without Smart Key system
With Smart Key system
With Smart Key system
Sm
Star
AC
ON
OF
With
STAR
NOT
Pow
Bac
Loc
Carr
Carr
NOT
2012Scion-tC.qxd 5/14/11 8:50 AM Page 6
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
7
for
tore
Smart Key system (if equipped)
Start function
Accessories such as the radio will operate.
Power ON; the engine not running.
All systems OFF.
ACC
ON
OFF
Push
Depress
brake pedal (A/T)
or clutch (M/T)
Carrying
Green indicator ON
Without depressing the brake pedal (A/T) or clutch (M/T), pressing the “ENGINE
START STOP” switch will change the operation mode in succession from:
NOTE: Doors may also be locked/unlocked using remote.
Power (without starting engine)
Back door lock/unlock
Push
Locking operation Unlocking operation
Carry remote to lock Carry remote to unlock
Push
Front door lock
Grasp
Carry remote to lock/unlock
Front door unlock
Push
NOTE: Automatic Transmission (A/T) - Gear shift lever must be in Park and brake
pedal depressed.
Manual Transmission (M/T) - Clutch must be pressed. Ensure the parking
brake is set and the vehicle is in Neutral.
2012Scion-tC.qxd 5/14/11 8:51 AM Page 7
Information Provided by:

8
FE
Au
* The
dep
Dow
For b
leve
Til
Hold
NOT
Pa
Engine maintenance
Windshield washer fluid tank
Engine coolant reservoir
Engine oil filler cap
Engine oil level dipstick
NOTE: Regularly scheduled maintenance, including oil changes, will help
extend the life of your vehicle and maintain performance. Please refer
to the “Warranty Maintenance Guide.”
Auto lock/unlock
Automatic door locks can be programmed to operate in four different modes, or
turned OFF.
-Doors lock when shifting from Park (Automatic Transmission only.)
-Doors lock when the vehicle speed goes above approximately 12 mph.
-Doors unlock when shifting into Park (Automatic Transmission only.)
Vehicles without Smart Key system
-Doors unlock when the ignition switch is set from “ON” to “ACC” or “LOCK” and
driver’s door is opened.
Vehicles with Smart Key system
-Doors unlock when the “ENGINE START STOP” switch is set to OFF and driver’s
door is opened.
Refer to the Owner’s Manual for more details.
Hood release
Pull Pull up latch and
raise hood
OVERVIEW
2012Scion-tC.qxd 5/14/11 8:51 AM Page 8
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
9
FEATURES/OPERATIONS
Automatic Transmission (if equipped)
Park*
Reverse
Neutral
Drive
P
R
N
D
N
“S” mode
* The “ENGINE START STOP”/ignition switch must be “ON” and the brake pedal
depressed to shift from Park.
Downshifting increases power going uphill, or provides engine braking downhill.
For best fuel economy during normal driving conditions, always drive with the shift
lever in the “D” position.
Tilt steering wheel
Hold wheel, push lever down, set angle and length, and return lever.
NOTE: Do not attempt to adjust while the vehicle is in motion.
Lock release lever
Angle
Length
Parking brake
Pull (2) Push
(1) Pull slightly
(3) Lower
Set Release
efer
or
nd
2012Scion-tC.qxd 5/14/11 8:51 AM Page 9
Information Provided by:

10
FEATURES/OPERATIONS
Cr
1 The
2 The
Tur
Lig
Hea
Tur
Park
Seat adjustments-Front
Seat position (forward/backward)
Height crank (driver side only)
Seatback angle
Seatback lock release
Seat adjustments-Rear
Seatback/Angle
adjusting lever*
* Pull the lever up to
adjust seatback angle,
or fold down
Seats-Head restraints
Height
Lock release button Lock release button
Front Rear
Height
2012Scion-tC.qxd 5/14/11 8:52 AM Page 10
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
11
Cruise control (if equipped)
1 The set speed may also be cancelled by depressing the brake pedal.
2 The set speed may be resumed once vehicle speed reaches 25 mph.
Turning system ON/OFF Functions
System ON/OFF
Resume2/Increase speed
Set/Decrease speed
Cancel1
Lights & turn signals
Headlights
Turn signals
Parking lights
High beam flasher
Low beam
Headlights
Right turn
Left turn
Lane change
Lane change
High beam
,
2012Scion-tC.qxd 5/14/11 8:52 AM Page 11
Information Provided by:

12
FEATURES/OPERATIONS
Intermittent windshield wiper
frequency adjustment
Wi
Auto
relea
oppo
Wind
rema
Windshield wipers & washers
Front
Rear (if equipped)
Interval wipe
Slow
Fast
Pull to wash and wipe
Single wipe
Interval wipe
Wipe
Wash and wipe
Wash and wipe
Moonroof (if equipped)
Opening operation Closing operation
Push and hold
Push once to tilt up; again to open
Push
Driv
Clo
Lig
Increase
Decrease
2012Scion-tC.qxd 5/14/11 8:52 AM Page 12
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
13
iper
Windows
Automatic operation (driver’s window) Push the switch completely down and
release to fully open. To stop window midway, lightly push the switch in the
opposite direction.
Window lock switch Deactivates all passenger windows. Driver’s window
remains operable.
Window lock switch
Driver door window controls
Up
Down
Clock
H-Hour set
M-Minute set
Light control-Instrument panel
+
-
Brightness
control
2012Scion-tC.qxd 5/14/11 8:53 AM Page 13
Information Provided by:

14
Air Conditioning/Heating
Airflow vent
“ ” mode uses fresh air (“ ” indicator OFF) to reduce window fogging.
Fan speed
Temperature selector
Air Conditioning ON/OFF
Rear window defogger
Windshield airflow
Recirculate cabin air (fresh air when OFF)
AUX port/USB port
FEATURES/OPERATIONS
Ste
“
P
sy
“
U
Refe
Own
AUX port
By inserting a mini plug (not included) into the AUX port, you can listen to music
from a portable audio device through the vehicle’s speaker system while in AUX
mode.
USB port
By connecting a USB memory or USB-compatible portable audio device to the USB
port, you can listen to music from the portable audio device or USB memory
through the vehicle’s speaker system.
Refer to the SCION Audio System Owner’s Manual or the SCION Navigation System
Owner’s Manual for more details.
Bo
Fro
Cu
Po
Desig
in th
2012Scion-tC.qxd 5/14/11 8:53 AM Page 14
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
15
g.
Steering wheel switches
“MODE”
Push to turn audio ON and select an audio mode. Push and hold to turn audio
system OFF.
“ ”
Use to search within the selected audio medium (radio, CD, iPod
®
, etc.).
Refer to the SCION Audio System Owner’s Manual or the SCION Navigation System
Owner’s Manual for more details.
>
>
Volume control
ic
X
USB
em
Bottle holders
Front Rear
Cup holders
Power outlet
Designed for car accessories. Ignition switch/“ENGINE START STOP” switch must be
in the “ACC” or “ON” position to be used.
2012Scion-tC.qxd 5/14/11 8:53 AM Page 15
Information Provided by:

16
SAFETY AND EMERGENCY FEATURES
After adjusting tire pressures, or after tires have been rotated or replaced, turn
the ignition switch to “ON” and press and hold the “ SET” button until indicator
blinks three times. Then allow the vehicle to sit for a few minutes to allow
initialization to complete.
Refer to the load label on the door jamb or the Owner’s Manual for tire inflation
specifications.
If the tire pressure indicator flashes for more than 60 seconds and then remains
on, take the vehicle to your local Toyota dealer.
If belt is fully extended, then retracted even slightly, it cannot be re-extended
beyond that point, unless fully retracted again. This feature is used to help hold
child restraint systems securely.
To find more information about seat belts, and how to install a child restraint
system, refer to the Owner’s Manual.
Keep as low on
hips as possible
Take up slack
Too high
Seat belts
Lock
Unlock
Door locks
Tire Pressure Monitoring (warning)
System
If tire pressure
indicator light is
on, check/adjust
each tire.
Sp
To o
Rem
(1) R
(2) L
Refe
2012Scion-tC.qxd 5/14/11 9:34 AM Page 16
Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
17
rn
ator
on
s
ld
s
st
Spare tire & tools
Tool location
Removing the spare tire
(1) Remove the spare tire cover.
(2) Loosen and remove the bolt.
Refer to the Owner’s Manual for jack positioning and tire changing procedures.
Wheel nut wrench Front towing eyelet
Jack handle
Spare tire
Jack
(1)
(2)
2012Scion-tC.qxd 5/14/11 8:54 AM Page 17
Information Provided by:

18
Star Safety SystemTM
VSC helps prevent loss of traction during cornering by reducing engine power and
applying brake force to selected wheels.
Toyota’s VSC monitors steering angle and the direction your vehicle is traveling.
When it senses that the front or rear wheels begin to lose traction, VSC reduces
engine power and applies braking to selected wheels. This helps restore traction
and vehicle control.
Vehicle Stability Control (VSC)
Anti-Lock Brake System (ABS)
Brake Assist (BA)
ABS helps prevent brakes from locking up by "pulsing" brake pressure to each
wheel. This limits brake lockup and provides the maximum brake effectiveness for
the current road conditions.
Toyota's ABS sensors detect which wheels are locking up and limits wheel lockup by
"pulsing" each wheel's brakes independently. Pulsing releases brake pressure
repeatedly for fractions of a second. This helps the tires attain the maximum
traction that the current road conditions will allow, helping you stay in control.
Brake Assist is designed to detect sudden or “panic” braking, and then add braking
pressure to decrease the vehicle’s stopping distance. When there’s only a split
second to react, Brake Assist can add additional brake pressure more quickly than
just the driver alone can.
VSC helps prevent loss of traction during cornering by reducing engine power, and
Traction Control helps maintain traction on loose gravel and wet, icy, or uneven
surfaces by applying brake force to the spinning wheel(s).
Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip.
TRAC limits engine output and applies the brakes to the spinning wheel. This
transfers power to the wheels that still have traction to help you drive safely.
Traction Control (TRAC)
Electronic Brake Force Distribution (EBD)
Toyota’s ABS technology has Electronic Brake-force Distribution (EBD) to help
maintain stability and balance when braking. Abrupt stops cause the vehicle to tilt
forward, reducing the braking power of the rear wheels. EBD responds to sudden
stops by redistributing brake force to maximize the braking effectiveness of all
four wheels.
Ther
has m
For s
•O
•Us
pl
•In
Flo
Bra
Smar
and
Brak
appli
per h
Brak
acce
with
SAFETY AND EMERGENCY FEATURES
All new Toyota vehicles come standard with the Star Safety SystemTM, which
combines Traction Control (TRAC), Electronic Brake-force Distribution (EBD), Vehicle
Stability Control (VSC), Brake Assist (BA) and an Anti-lock Braking System (ABS).
2012Scion-tC.qxd 5/14/11 8:54 AM Page 18
Information Provided by:
