SCOLTA RP-101 User manual

HANDHELD TRANSCEIVER
Versions:
RP-101:PMR446
RP-201:VHF
RP-301:UHF
INSTRUCTION
MANUAL

Waste disposal. Direcve 2012/19 / EU
Informaon on waste disposal of electrical and electronic equipment
(WEEE).
This symbol on the product means that the electrical and electronic prod-
ucts used must not be mixed with household waste. For proper treatment,
recovery and recycling, take this product to designated collecon points
where it will be accepted for free.
The correct disposal of this product will help save valuable resources and prevent possible
negave eects on human health and the environment, which could otherwise arise from
the improper handling of waste..
Contact your local authority for more informaon about the nearest collecon point.
Sancons may be applied for the incorrect disposal of this waste, in accordance with its
naonal legislaon.
These symbols on the baeries mean:
Pb = contains more than 0.004 percent by weight of lead
Cd = contains more than 0.002 percent by weight of cadmium
Hg = contains more than 0.0005 percent by weight of mercury
You can also send the transceiver and the baery to our warehouse. Postal fees must be
paid by the sender.
This product complies with Direcve 2011/65 / EU about restricons on the use of
certain hazardous substances in electrical and electronic equipment.
This transceiver is suitable for use as long as the user has a license or admin-
istrave authorizaon, issued and complying with the restricons dened by
the Telecommunicaons Authories of the state to which the user belongs.
You can request more informaon from your seller.
States of the European Union of permitted use:
AT BE BG HR CY CZ DK
EE FI FR DE EL HU IE
IT LV LT LU MT NL PL
PT RO SK SI ES SE UK

3
Inordertomakeyoufullyunderstandtheequipment,please
readthisusermanualbeforeusing.
RP-101
Programmedwith8/16PMR*channels.TXpower500mW.
Bandwidth12.5kHz.Noregistrationorfeesapply.Basedonthe
country’sregulationonlythechannels1-8or1-16arepermitted.
RP-201
CommercialradioVHF;147~174MHz
199programmablechannels.Registrationrequired,feesapply.Only
assignedfrequenciesandparametersarepermitted.Bandwidth12.5
kHzor25kHz.Max.TXpower5W.
RP-301
CommercialradioUHF;440~470MHz
199programmablechannels.Registrationrequired,feesapply.Only
assignedfrequenciesandparametersarepermitted.Bandwidth12.5
kHzor25kHz.Max.TXpower5W.
This transceiver comes in 3 dierent versions:
Thank you for purchasing our handheld transceiver. This model is
novel designed with stable performance and we want to develop
this model to be a portable equipment, also easy to operate with a
varietyofsophisticatedfunctions,soweareusingthemostadvanced
technology.Wedeeplycondentthatitsqualityandfunctionalitywould
makeyoufeelsatised!

Thetransceiverisaproductwithgooddesignandadvancedtechnology.
Thefollowingsuggestionswillhelpyouperformtheobligationsofwarranty
cause,understandandrealizethesecurityofusingtransceivers.
1. Put transceiver and all its parts and accessories in place out of
children’sreach.
2. Donottrytodisassembletransceiverasnon-professional’streatment
tothetransceivermaycausedamage.
3. Pleaseuseourcompany’sassortedbatterypackandcharger,avoid
damagetotransceiver.
4. Please use our company’s assorted antenna, to prevent shorten
communicationdistance.
5. Do not expose transceiver to sunlight for a long time or in the
overheatedareas.
6. Donotputtransceiverindustedorwetareas.
7. Do not clean transceiver with strong chemicals, cleaning agents or
stronglotion.
8. Donottransmitunlesstheantennahasbeeninstalled.
9. If you discover the transceiver giving o odor or smoke, please
immediately turn o the power of transceiver, remove battery pack
fromtransceiverandcontactwithdealers.
PRECAUTION
• Alltheproposalsaboveareequallyapplicabletoyourtransceiver
anditsaccessories.Iftheycannotworkproperly,pleasecontactwith
dealerspromptly.
• Ifyouuseaccessorieswhicharenotproducedorsoldbyour
company,wewillnotguaranteethesafetyandoperabilityofthe
transceiver.
ANNOUNCEMENT

CONTENTS
UNPACKING AND CHECKING EQUIPMENT............................. 7
PREPARATION............................................................................ 8
BASIC FUNCTIONS................................................................... 12
GENERAL FUNCTIONS............................................................ 14
CHANNEL SETTINGS............................................................... 17
DTMF.......................................................................................... 19
SPECIFICATIONS...................................................................... 20
TROUBLESHOOTING GUIDE................................................... 21
DCS / CTCSS CODES............................................................... 22
PMR446 CHANNELS................................................................ 22
DECLARATIONS OF CONFORMITY........................................ 23


7
UNPACKING AND CHECKING
Pleasetakethetransceiverfromthepackagecarefully.Wesuggest
thatyoushouldcheckthefollowingaccessoriesbeforethrowingawaythe
package.Ifanyitemsislostordamagedwhentransportation,pleasesubmit
aclaimtothedeliverymanimmediately.
ASSORTED ACCESSORIES
Item Qty.
Antenna(*) 1
Charger 1
Adapter 1
Batterypack 1
ScrewSet 1
Beltclip 1
Usermanual 1
(*)InPMRversiontheantennaisxed,ieitcannotberemovedfromthe
device.

8
PREPARATION
CHARGING THE BATTERY PACK
Thebatterypackisnotchargedatthefactory.Pleasechargeitbeforeusing.
Afterpurchasingorlongtimestorage(morethantwomonths),thebattery
can not reach its normal capacity when charge at the rst time. After
charging2-3timesthenthecapacityreachthenormalone.
CAUTION
• Donotrechargethebatterypackifitisalreadyfullycharged.
Otherwise,thebatterylifewillbeshortenordamaged.
• Afterrechargingthebatterypack,disconnectitfromthechar-
ger.Chargingthebatterypackmorethan5daysmayreduce
thebatterypacklifeduetoovercharging
NOTE:
• Theambienttemperatureshouldbebetween42and104°F(5to
40°C)whilechargingisinprogress.Chargingoutsidethisrangemay
notfullychargethebattery.
• AlwaysswitchOFFthetransceiverequippedwithabatterypack
beforecharging.Usingthetransceiverwhilechargingwillinterfere
withcorrectcharging.
• Evenaftercompletelycorrectcharge,theusingtimestillnot
increases,thenthebatterylifeisover,pleasereplacethebattery.

9
PlugtheChargerpowercableintoan
ACoutlet.
Insertthebatterypackortransceiverwitha
batterypackintothecharger.
• Makesurethebatterypackcontactwith
thechargingterminalscorrectly.
• ThechargerLEDlightsonandcharging
begins.
• Afterchargingtheassortedbatterypackfor4~8hours,takethe
batteryorthetransceiverwithbatteryfromthecharger.
• Thechargecompleteswhencharginglightturnsgreen.
• UnplugtheACadaptorfromtheACoutlet

10
Installing/Removing the Battery Pack
Theaverageusingtimeofthesuppliedbatterypackis8hours.Average
timesiscalculatedbyusing5%transmittime,5%receivetime,and90%
standbytime.
• Donotmakethebatteryterminalsshortcircuitordisposethe
batteryintore.
• Donottrytoremovetheshellfromthebatterypack.
CAUTION
Battery Latch.
Pullthelatchdownwardto
removethebatterypack

11
Installing the Antenna
Hold the antenna base and screw the antenna
clockwiseintotheantennaconnectoratthetopofthe
transceiver,untiltighten.
NOTES:
• In PMR version the antenna is xed, ie it can not be
removed from the device.
• Don’t hang keys, speaker or microphone on the antenna.
Otherwisetheantennawillbedamagedorperformanceof
theradiowillbedegraded.
Installing the Belt Clip
Ifnecessary,canusetwo3x8mmscrewsinthe
packagetoxthebeltclip.
NOTES:
• Ifnotinstallthebeltclip,itsinstallationlocationwill
gethotinthehotenvironmentorinthecontinuous
communication.
• Youmustremovethebeltclipbeforeremovingthebattery
pack.
Installing the Optional Speaker/
Microphone
Outwardapartthemoisture-proofrubberofthe
headphonemouth,Insertthespeaker/microphoneplugs
intothespeaker/micro-phonejacks.
NOTAS:
• The transceiver is not fully waterproof while using the
speaker/microphone.
• TheconnectioniscompatiblewithKenwood(3.5/2.5mm,
stereo / stereo) which can also be used as data transfer
cable.

12
BASIC FUNCTIONS
1. Antenna
2. LED indicator
• Lightsredwhiletransmitting.
• Lightsgreenwhilereceivingasignal.
• Purplelightashingwhentransmitwithlowbatterypower.
3. Speaker
4. Microphone
5. Hidden LCD
6. Channel selector
• Rotatetoselectchannels
7. Power switch / Volume control
• TurnclockwisetoswitchONthetransceiver.
• ToswitchOFFthetransceiver,turncounterclockwiseuntilaclick
sounds.
• Rotatetoadjustthevolumelevel.
8. PTT (Push-to-talk)
9. Multi-function keys PF1 y PF2
10. Speaker/ Microphone jack
11. Battery pack

13
ON / OFF
Toturntheradioon,turn theOn /Oswitch(7)clockwisebeyondthe
barrier.Abeeptoneisemittedifthebeeptonefunctionisactivated.There
are5dierenttonesavailable.
Toturnotheradio,pleaseturntheOn/Oswitch(7)counterclockwise
beyondthebarrier.
Volume control
To change the volumeleveluse the combined On/O-Volumekey(7).
ThedisplaywillshowthesymbolVOLandthevolumelevel(00-10).
Channel Selection
For channel selection, use the rotary channel selector (6) switch.The
channelsareselectedin theprogrammedorder.Thedisplaywillshow
thesymbolCHandtheactualchannelnumber.
Transmision
FortransmissionholdthePTTkey(8)untiltheendofthemessage.
Forbestsoundquality,talkintothemicrophone(4)withanormalvoice
atadistanceofapproximatly10cm.
DuringtransmissionthecontrolLED(2)lightsup:
Red=HighTXpower
Magenta=LowTXpower
UponreleaseofthePTTkey(8)theradioreturnsautomaticallyinto
receptionmode.
Reception
Uponreceptionofasignal,theLED(2)isblue.
If the selected frequency is decoded with a CTCSS- / DCS-code, all
signalsthatareencodedwithadierentcodewillbemuted.Theblue
LEDwilllightbutnosignalwillbeaudible.

14
GENERAL FUNCTIONS
Thefollowingsettingsconcernthegeneraloperationoftheradio.Theyare
indendentofthechannelsettings.
Time-out-timer (TOT)
FortheversionsPMR,theTOTtimehastoactivated,amax.of180s
ispermitted.Bydefault,theTOTtimeissetto180seconds.
ForthecommercialradioversionsUHFandVHF,theTOTfunctioncan
bedeactivatedorsetinarangebetween30-600seconds.
Apre-alertisavailableandcanbesetupto10sbeforeexpirationofthe
TOTtime.
Voice annunciation
Withactivatedvoiceannunciation,mostofthesettings,e.g.on/o,
channelselection,tx-powerswitch,etc.areannouncedinenglish.
Power on tone
Thereare5dierentpower-ontonesavailable.Thisfeaturecanbe
deactivated.
Squelch
Thesquelchcanbesetinarangebetween0-9.
(0=squelchdeactivated;9=lowestsensitivity,i.e.thesignalhastobevery
strongtoopenthesquelch).

15
LED Hidden Display
Theradiohasahiddendisplaylocatedonthefrontoftheradiobelowthe
speaker.Therearedierentsettingsfortheactivestatus.
• OFF:thedisplayisdeactivatedduringtransmissionandactive
duringstandbyandduringsignalreception.
• ON:thedisplayisalwaysactivated(withthissettingthepower
consumptionisveryhigh,thebatteryneedstoberechargedmore
frequently)
• Auto2-25:afterachannelswitchortheendofatransmissionor
receptionperiod,thedisplayisstillactivefortheselectedtime
period(inseconds).
VOX
ToaccesstheVOXfunction,oneofthefunctionkeyshastobeassigned
toVOX.Thesensitivitylevels1-10oftheVOXfunctioncanbeindiviually
adjustedbysoftware.
Warning Tone
Forsome setting changes (see multifunctionkey assignment),awarn
tone is available. By default, it is activated but can be deactivated by
software.
Power Save
This transceiver is equipped with a battery saving function to reduce
power consumption in standby mode.When the battery level is low it
canbeannouncedbyawarningtone,avoiceindicationand/oraLED
signal.Youcanalsosetanautomaticshutdown(APO).
Channel scan
The settings for the scan function include the dwell time (for the TO
mode),thedelaytime(afterendofsignal),themodeselectionTO(time
operated)/CO(signaloperated)/SE(endofscanafterasignalhasbeen
detected),thealarmtonesforthebeginningandtheendofscanning,as
wellastheLEDlightfortheactivestate.

16
Multifunction Key Assignment
2functionscanbeassignedto eachfunctionkey.Thesearetriggered
bypressingthekeyshortlyorlong.Howlongakeyhastobepressedto
triggerthesecondfunction,canbesetviasoftwareinarangeof0-7.5
seconds.Thefunctionsthatcanbeassignedare:
01–OFFnonfunction
02–AutoDial.TransmitselectedDTMFcode
03–Scan.Start/stop
04–VOX.On/O
05–Monitor
06–TX-powerselection(HighPower/LowPower)
07–Alarmtonefunction
08–Informsaboutactualbatterylevel
09–FMradioOn/o(holdkey)andscanstart/stop(pressshortly)
10–FirCH.Prioritychannel1
11–SecCH.Prioritychannel2
12–SquelchOFF.(ON/OFF)
Only for long press:
13–SquelchOtemp.squelchisoaslongasthekeyisheld.
14–1750Hz.Repeatertone1750Hz
Alarm function
An individual setup of the alarm function is possible with the many
settings of the alarm function. E.g. it is possible to dene an alarm
channel,whichisautomaticallysetoncethealarmfunctionisactivated.
Furtheritcanbedecidedifthealarmisaudiblelocal,i.e.onlyattheown
radio,orremote,i.e.allradiosthatusethesamechannel.
It is also possible to set the number of cycles of transmission and
receptionperiods.
FM Radio
FortheFMradiooperation,assignittoalong-statekey.Holdingthekey,
willstart/stoptheFMradiofunction.ToscanthenextavailableFMradio
frequency,pressthekeyshortly.Thescanfunctionstopsautomatically
onceachannelhasbeendetected.
Priority Channel 1/2
Bypushingtheassignedmultifunctionkey(FIRCH/SECCH),theradio
switchestotheprogrammedprioritychannel.

17
CHANNEL SETTINGS
Thefollowingoptionscanbeconguredtoeachchannelusingsoftware.
RX Freq / TX Freq
The radio has 199 programmable channels. The PMR version is
exclusively programmable with the 16 PMR frequencies (446 MHz).
The commercial versions UHF and VHF can be programmed in
the designated frequency band according to the individual licence.
For repeater operation, TX- and RX-frequencies are programmable
independently.
QT/DQT Dec - QT/DQT Enc
SomechannelsmayhavepresetQT/DQTtones.AQT/DQTtoneisa
subaudibletonewhichallowsyoutoignore(nothear)callsfromother
partieswhoareusingthesamechannel.
Whenyoureceiveasignalthathasatonedierentfromtheonesetup
inyoutransceiver,youwillnothearthesignal.Likewise,signalsthat
youtransmitwillonlybeheardbypartieswhoseQT/DQTtonematches
thetonesetupinyourtransceiver.
NOTA:AlthoughusingchannelssetupwithQT/DQTtonesrelievesyoufrom
listeningtounwantedcalls,itdoesnotmeanyourcallswillbeprivate.
TX-Power Selectio
InthePMRversion,thehighpower(HIGH)is500mW.Forcommercial
versionsofVHFandUHF,thehighandlowsettingscanbe
programmedaccordingtothevaluesassignedinthelicense.
Bandwidth (W/N)
InPMRversionthebandwidthissetat12.5kHz(N)accordingto
governmentregulations.Forcommercialversionsthebandwidthcanbe
N(12.5kHz)andW(25kHz)

18
Scan (Scan Add/Del)
You can add (add) or remove (del) the channel from the scan list
throughthesoftware.
Busy channel lock (BCL)
Using this function, the transmission is blocked if there is a signal
presentontheselectedchannel.
VOX
With VOX function it will activate the transmission with the voice
withouthavingto press PTT.The sensitivity of theVOX denes the
thresholdofthevoiceintensitytostartthetransmissionautomatically.
Inlevel1,thevoicesignal mustbeverystrongto activatetheVOX
function.Atlevel9theVOXfunctionismoresensitiveandtherefore
a lower voice level will be activated. Each VOX level (1-9) can be
adjustedusingsoftware.
TX Allow
Itispossibletoactivate/deactivatethetransmissionforeach
channel.
PTT-ID (BOT/EOT/Both)
ThetransceivercantransmitaDTMFcodeviaPTT-ID.The
transmissionofthecodeistriggeredbythePTTkey.Eachpressof
thePTTkeytransmitsthecode.
BOT:ThesignalistransmittedbypressingthePTTkey.
EOT:ThesignalistransmittedwhenthePTTkeyisreleased.
BOTH:Thesignalistransmittedbypressingandreleasingthe
PTTkey
Opt
TheradiooersDTMFasanoptionalcallingsignal.Eachchannel
hastobeactivatedforthisfeature.
FortransmissionofaDTMFcode,amultifunctionkeyhastobe
assignedtothesettingDIAL.AprogrammedDTMFcodeisthen
selectedfortheindividualchannel.

19
Dial
IfDTMFisused,oneofthemax.16programmableDTMFcodeshastobe
assigned.
SP Unmute
Thissettingdetermineswhenthesquelchwillopen,i.e.whenthespeaker
willunmute.Thereare4settingsavailable.
WAVE:signalregardlessofanycodes(CTCSS/DCSorDTMF)
CT / DQT:signalwiththeproperCTCSS/DCScode.
QD or Opt:signalwiththeproperCTCSS/DCScodeORDTMFcode.
QD and Opt: signalwiththeproperCTCSS/DCScodeANDDTMFcode.
DTMF
TheDTMFfunctionmustbeprogrammedbysoftware.Withits decoding
andencodingfeatures,DTMFcanbeusedasaselectivecallingsystem.
The automatic transmission of DTMF (PTT ID) codes and the STUN
function (which enables remote transmission to be disabled) are also
available.
EachDTMFencodecancontainamaximumof16symbols(0-9andA-F).
Themaximal16DTMFcallingcodescanbeprogrammedviasoftwarein
theAutoDialList.
For the PTT-ID feature - automatic transmission of a DTMF call upon
pushingorreleasingthePTTkey-2PTT-IDcodescanbe programmed
(beginningoftransmissionandendoftransmission).
TheDTMFradioIDdecodecanbecomposedofamaximumof10symbols
(0-9andA-F).Theusageofagroupsymbol(A-F)isenabled.Further,itis
possibletoactivateawarningtonethatwillbeaudibleintheeventofthe
receptionofacall.
The Stun functions allows to deactivate the transmission mode of a
remoteradio.Toactivatearadioforthisfeauture,thestuncodeneedsto
beassigned.Oncethisstuncodeisreceived,transmissionisdeactivated
(receptionisstillpossible).
Toreviveastunnedradio,thestuncode,followedbytheletterFhastobe
received.

20
SPECIFICATIONS
Frequencyrange
PMR:446.00625~446.09375MHz
VHF:147~174MHz
UHF:440~470MHz
Ratedvoltage 7.4V
Workingtemperature -20°C-+50°C
Antennaimpedance 50Ω
Dimensions 63x115x37mm
Weight 251gr.
TRANSMITTER
Poweroutput
PMR:500mW
VHF:5W
UHF:5W
Frequencystability ±2.5PPM
Maximumfrequencydeviation ≤±5kHz
Remanentradiation <-60dB
Modulationmode(W/N) 16KØF3E,11KØF3E
Maximumfrequencydeviation ≤2.5kHz(N),≤5kHz(W)
Audiodistortion ≤3%
Adjacentchannelpower ≥60dB
RECEIVER
RFsensitivity W:0.223uV>12dB
N:0.223uV>12dB
Audiodistortion ≤3%
AdjacentChannelSelectivity ≥60dB
IntermodulationRejection ≥60dB
Spuriousradiation ≥60dBm
This manual suits for next models
2
Table of contents
Popular Transceiver manuals by other brands

Kenwood
Kenwood TK-3170 E3 Service manual

Mixcder
Mixcder TR007 user manual

Yaesu
Yaesu FTDX101MP Operation manual

PRESIDENT
PRESIDENT Andrew J. 1012001 owner's manual

Delta Electronics
Delta Electronics 1x9 Bi-Directional Transceiver Module... Specifications

Vertex Standard
Vertex Standard VXR-9000U-A Alignment Guide
