R.V.R. Electronica PTRLNV/4 User manual

PTRLNV/4 & RXRLNV/4
USER MANUAL
VOLUME1
Manufactured by R.V.R ELETTRONICA S.p.A. Italy

PTRLNV/4 & RXRLNV/4 - User Manual
Version 1.0
© Copyright 2010
R.V.R. Elettronica SpA
Via del Fonditore 2/2c - 40138 - Bologna (Italia)
Telephone: +39 051 6010506
Fax: +39 051 6011104
Email: info@rvr.it
Web: www.rvr.it
All rights reserved
Printed and bound in Italy. No part of this manual may be reproduced,
memorized or transmitted in any form or by any means, electronic
or mechanic, including photocopying, recording or by any informa-
tion storage and retrieval system, without written permission of the
copyright owner.
File Name: PTRLNV_4&RXRLNV_4_ING_1.0.indb
Version: 1.0
Date: 09/06/2010
Revision History
Date Version Reason Editor
09/06/2010 1.0 First Version J. H. Berti

PTRLNV/4 & RXRLNV/4
ELETTRONICA
i
User Manual
Rev. 1.0 - 09/06/10
Table of Contents
1. Preliminary Instructions 1
2. Warranty 1
3. First Aid 2
3.1 Treatment of electrical shocks 2
3.2 Treatment of electrical Burns 2
4. General Description 3
4.1 Unpacking 3
4.2 Features 3
4.3 PTRLNV/4 Frontal Panel Description 6
4.4 PTRLNV/4 Rear Panel Description 7
4.5 PTRLNV/4 Connector Description 8
4.6 RXRLNV/4 Frontal Panel Description 10
4.7 RXRLNV/4 Rear Panel Description 11
4.8 RXRLNV/4 Connector Description 12
4.9 Technical Description 14
5. RXRLNV/4 quick guide for installation and use 15
5.1 Preparation 15
5.2 Operation 16
5.3 Setting and Calibration 17
5.4 Software 17
6. RXRLNV/4 quick guide for installation and use 24
6.1 Preparation 24
6.2 Operation 25
6.3 Setting and Calibration 26
6.4 Software 26
7. IdenticationandAccesstotheModules 31
7.1 IdenticationoftheModules 31

ii User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
This page was intentionally left blank

PTRLNV/4 & RXRLNV/4
ELETTRONICA
1/ 34
User Manual
Rev. 1.0 - 09/06/10
1. Preliminary Instructions
• General Warnings
This equipment should only be operated, installed and
maintainedby“trained”or“qualied”personnelwhoarefamiliar
with risks involved in working on electric and electronic circuits.
“Trained” means personnel who have technical knowledge of
equipment operation and who are responsible for their own
safetyandthatofotherunqualiedpersonnelplacedunder
their supervision when working on the equipment.
“Qualified” means personnel who are trained in and
experienced with equipment operation and who are
responsiblefortheirownsafetyandthatofotherunqualied
personnel placed under their supervision when working on
the equipment.
WARNING: Residual voltage may be present inside
theequipmentevenwhentheON/OFFswitchissetto
Off. Before servicing the equipment, disconnect the
power cord or switch off the main power panel and
makesurethesafetyearthconnectionisconnected.
Some service situations may require inspecting the
equipmentwithlivecircuits.Onlytrainedandqualied
personnelmayworkontheequipmentliveandshallbe
assistedbyatrainedpersonwhoshallkeepreadyto
disconnectpowersupplyatneed.
R.V.R. Elettronica S.p.A. shall not be liable for injury to
persons or damage to property resulting from improper use
oroperationbytrained/untrainedandqualied/unqualied
persons.
WARNING:Theequipmentisnotwaterresistant.
Anywaterenteringtheenclosuremightimpairproper
operation. To prevent the risk of electrical shock or
re,donotexposethisequipmenttorain,drippingor
moisture.
Pleaseobservelocalcodesandrepreventionruleswhen
installing and operating this equipment.
WARNING: This equipment contains exposed
livepartsinvolvinganelectricalshockhazard.Always
disconnectpowersupplybeforeremovinganycovers
orotherpartsoftheequipment.
Ventilation slits and holes are provided to ensure reliable
operation and prevent overheating; do not obstruct or
cover these slits. Do not obstruct the ventilation slits under
any circumstances. The product must not be incorporated
in a rack unless adequate ventilation is provided or the
manufacturer’s instructions are followed closely.
WA R NING : This e q uipm e n t can r a diat e
radiofrequencyenergyand,ifnotinstalledincompliance
with manual instructions and applicable regulations,
maycauseinterferencewithradiocommunications.
WARNING: This equipment is tted with earth
connectionsbothinthepowercordandforthechassis.
Makesurebothareproperlyconnected.
Operation of this equipment in a residential area may cause
radio interference, in which case the user may be required
to take adequate measures.
Thespecicationsanddatacontainedhereinareprovided
for information only and are subject to changes without prior
notice. R.V.R. Elettronica S.p.A. disclaims all warranties,
express or implied.While R.V.R. Elettronica S.p.A.
attempts to provide accurate information, it cannot accept
responsibility or liability for any errors or inaccuracies in this
manual, including the products and the software described
herein. R.V.R. Elettronica S.p.A. reserves the right to make
changestoequipmentdesignand/orspecicationsandto
this manual at any time without prior notice.
• Notice concerning product intended purpose and use
limitations.
This product is a radio transmitter suitable for frequency-
modulation audio radio broadcasting. Its operating
frequencies are not harmonised in designated user countries.
Before operating this equipment, user must
obtain a licence to use radio spectrum from the
competent authority in the designated user country.
Operating frequency, transmitter power and other
characteristics of the transmission system are subject to
restrictionsasspeciedinthelicence.
2. Warranty
La R.V.R. Elettronica S.p.A. warrants this product to be free
from defects in workmanship and its proper operation subject
to the limitations set forth in the suppliedTerms and Conditions.
Please read the Terms and Conditions carefully, as purchase
of the product or acceptance of the order acknowledgement
imply acceptance of the Terms and Conditions.
For the latestupdatedtermsand conditions,pleasevisitour web
siteatWWW.RVR.IT.Thewebsitemaybemodied,removed
or updated for any reason whatsoever without prior notice.
The warranty will become null and void in the event the
product enclosure is opened, the product is physically
damaged, is repaired by unauthorised persons or is used for
purposes other than its intended use, as well as in the event
of improper use, unauthorised changes or neglect.
In the event a defect is found, follow this procedure:
1 Contact the seller or distributor who sold the equipment;
provide a description of the problem or malfunction for
theeventaquickxisavailable.
Sellers and Distributors can provide the necessary
information to troubleshoot the most frequently encountered
problems. Normally, Sellers and Distributors can offer a
faster repair service than the Manufacturer would. Please
note that Sellers can pinpoint problems due to wrong
installation.
2 If your Seller cannot help you, contact R.V.R. Elettronica
S.p.A. and describe the problem; if our staff deems it
appropriate, you will receive an authorisation to return
the equipment along with suitable instructions;
3 When you have received the authorisation, you may
return the unit. Pack the unit carefully before shipment;
use the original packaging whenever possible and seal
the package perfectly. The customer bears all risks of
loss (i.e., R.V.R. shall not be liable for loss or damage)
until the package reaches the R.V.R. factory. For this
reason, we recommend insuring the goods for their full
value. Returns must be sent on a C.I.F. basis (PREPAID)
totheaddressstatedontheauthorisationasspecied
by the R.V.R. Service Manager.
IMPORTANT
The symbol of lightning inside a triangle placed on the product, evidences the operations for
which is necessary gave it full attention to avoid risk of electric shocks.
The symbol of exclamation mark inside a triangle placed on the product, informs the user
about the presence of instructions inside the manual that accompanies the equipment, im-
portantfortheefcacyandthemaintenance(repairs).

2/ 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
Units returned without a return authorisation may
be rejected and sent back to the sender.
4 Be sure to include a detailed report mentioning all
problems you have found and copy of your original
invoice (to show when the warranty period began) with
the shipment.
Please send spare and warranty replacement parts orders to
the address provided below. Make sure to specify equipment
model and serial number, as well as part description and
quantity.
R.V.R. Elettronica S.p.A.
Via del Fonditore, 2/2c
40138 BOLOGNA ITALY
Tel. +39 051 6010506
3. First Aid
All personnel engaged in equipment installation, operation
andmaintenancemustbefamiliarwithrstaidprocedures
and routines.
3.1 Electricshocktreatment
3.1.1 If the victim is unconscious
Followtherstaidproceduresoutlinedbelow.
• Laythevictimdownonhis/herbackonarm
surface.
• the neck and tilt the head backwards to free
the airway system (Figure 1).
Figure 1
• If needed, open the victim’s mouth and check
for breathing.
• Ifthereisnobreathing,startarticialrespiration
without delay (Figure 2) as follows: tilt the head
backwards, pinch the nostrils, seal your mouth
around the victim’s mouth and give four fast
rescue breaths.
Figure 2
• Check for heartbeat (Figure 3); if there is
no heartbeat, begin chest compressions
immediately (Figure 4) placing your hands in
the centre of the victim’s chest (Figure 5).
Figure 3 Figure 4 Figure 5
• One rescuer: give 2 quick rescue breaths after
each 15 compressions.
• Two rescuers: one rescue breath after each 5
compressions.
• Do not stop chest compressions while giving
articialbreathing.
• Call for medical help as soon as possible.
3.1.2 If the victim is conscious
• Cover victim with a blanket.
• Try to reassure the victim.
• Loosen the victim’s clothing and have him/her
lie down.
• Call for medical help as soon as possible.
3.2 Treatment of electric burns
3.2.1 Large burns and broken skin
• Cover affected area with a clean cloth or
linen.
• Do not break any blisters that have formed;
remove any clothing or fabric that is stuck to
the skin; apply adequate ointment.
• Administer adequate treatment for the type of
accident.
• Get the victim to a hospital as quickly as
possible.
• Elevate arms and legs if injured.
If medical help is not available within an hour, the victim is
conscious and is not retching, administer a solution of table
salt and baking soda (one teaspoon of table salt to half
teaspoon of baking soda every 250 ml of water).
Have the victim slowly drink half a glass of solution for four
times during a period of 15 minutes.
Stopattherstsignofretching.
Do not administer alcoholic beverages.
3.2.2 Minor burns
• Apply cold (not ice cold) strips of gauze or dress
wound with clean cloth.
• Do not break any blisters that have formed;
remove any clothing or fabric that is stuck to
the skin; apply adequate ointment.
• If needed, have the victim change into clean,
dry clothing.
• Administer adequate treatment for the type of
accident.
• Get the victim to a hospital as quickly as
possible.
• Elevate arms and legs if injured.

PTRLNV/4 & RXRLNV/4
ELETTRONICA
3/ 34
User Manual
Rev. 1.0 - 09/06/10
4. General Description
The PTRLNV/4 and RXRLNV/4 are, respectively a broadband radio transmitter
and receiver for the transport of audio signals as an auxiliary to the frequency
modulation sound broadcasting.
This type of equipment is often called STL (Studio-to-Transmitter Link).
The PTRLNV/4 is designed to work in an optimum way when connected to the
receiver RXRLNV/4.
Externally, it is a box to mount in a 19” rack, each one being 1HE high.
4.1 Unpacking
The PTRLNV
The package contains:
1 PTRLNV/4 and/or RXRLNV/4
1 User Manual
1 Mains power cable
The following accessories are also available from Your R.V.R. Dealer:
• Accessories,sparepartsandcables
4.2 Features
The standard working frequency bands are the following:
•1500-1525 MHz (25KHz steps)
•1650-1680 MHz (25KHz steps)
•1675-1725 MHz (25KHz steps)
•1700-1750 MHz (25KHz steps)
•1750-1800 MHz (25KHz steps)
•2368-2372 MHz (25KHz steps)
•2440-2450 MHz (25KHz steps)
•2468-2483 MHz (25KHz steps)
Note: the working frequency (and therefore the band) should be indicated when
the order for such product is placed.
WARNING: upon request, these links are available at other frequency bands and
steps, please contactact RVR in order to check the availability of modules at the
required frequency.

4/ 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
The PTRLNV/4 is available with internal stereo coder which can guarantee an
optimum stereophonic separation as well as a low level of harmonic distorsion. In
functionofyourownrequirementsitcanbeconguratedforthefunctioningunder
the Mono/MPX mode (that is to say when excluding the stereo coder and when
using the “left” inputs as a “mono” input or the BNC, which is always on, as “MPX”).
Thecongurationcanbedonebytheuserwiththehelpofsoftware.Ithasalso
two inputs (SCA1 and SCA2) for signals which are modulated on sub-carriers by
appropriated external coders, normally used in Europe for the RDS transmission
(Radio Data System).
In the standard version of the RXRLNV/4, the demodulated signal is available
in the MPX form (that is to say the complete basis signal band) and in the mono
version.
Moreover there are two connectors used for the respective SCA outputs. As an
option, the RXRLNV/4 can be equipped with a stereo decoder option. Also when
this option is present, apart from the outputs for the LEFT and RIGHT channels,
the outputs for the MPX signal are present and for the possible sub-carriers.
The important audio characteristics of this equipment are the low distorsion and
intermodulation values and the high S/N level; another important quality both of the
PTRLNV/4 and the RXRLNV/4 is its very simple construction and its easy use.
Both the PTRLNV/4 and the RXRLNV/4 were designed in a modular way: the
different functions are executed by modules connected directly with male and
femaleconnectorsorwithatcableswithconnectorsatbothends.Thistypeof
design makes the maintenance and the possible replacement of modules an easy
operation.
The microprocessor system includes an LCD display and an encoder that enable
the interaction with the user, and implements the following functions for the
transmitter:
•Display of the modulation
•Setting of the output power
•Setting of the working frequency
• Power Good feature (User-selectable output power alarm threshold).
•Measurement and display of the working parameters of the transmitter
These functions are implemented for the receiver:
•Display of the modulation
•Setting of the working frequency
•Setting of the muting threshold
•Measurement and display of the working parameters of the receiver
The system of the management software is composed of several menus.

PTRLNV/4 & RXRLNV/4
ELETTRONICA
5/ 34
User Manual
Rev. 1.0 - 09/06/10
The user can navigate between the different submenus by using the knob.
The status of the unit is indicated by four LEDs which are present on the front
pannel:
•ON, LOCK, FOLDBACK, RF OFF for the PTRLNV/4.
•ON, LOCK, PILOT, MUTE for the RXRLNV/4.
Both the transmitter and the receiver have an input for the external 24 Vcc supply.
This auxiliary supply source, that can be realized by the user with the help of rescue
batteries, is automatically used in case of AC voltage absence.

6/ 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
4.3 PTRLNV/4 Frontal Panel Description
[1] AIRFLOW Gridforthepassageoftheairowoftheforcedventilation.
[2] RF OFF Yellow LED, lit when the transmitter’s power output is inhibited
by an external interlock command.
[3] F.BACK Yellow LED, lit when the foldback function is operating
(automatic reduction of the delivered RF power).
[4] LOCK Green led, lit when the PLL is locked on the working
frequency.
[5] ON Green LED, lit when the transmitter is in RF ON.
[6] DISPLAY Liquid crystal display.
[7] CONTRAST Display contrast adjusting trimmer.
[8] ENCODER Knob and button in order to software control.
[9] SERVICE DB9 connector for factory parameters programming.
[10] POWER ON/OFF switch. It switches off the exciter without
disconnecting the AC supply.

PTRLNV/4 & RXRLNV/4
ELETTRONICA
7/ 34
User Manual
Rev. 1.0 - 09/06/10
4.4 PTRLNV/4 Rear Panel Description
[1] MAIN FUSE Fuse for mains supply.
[2] MAINS Standard IEC connector for mains supply 90 ÷ 260 V, +10/-
15%.
[3] AIRFLOW Gridforthepassageoftheairowoftheforcedventilation.
[4] R.F. OUT RF output connector, N-type.
[5] 24 VDC IN RED Positive connectors for the external 24V supply.
[6] 24 VDC IN BLACK Negative connectors for the external 24V supply.
[7] REMOTE DB15 connector to telemetry the equipment.
[8] PILOT OUT BNC output for the pilot tone. This can be used for external
devices synchronization (e.g. RDS coders).
[9] SCA 2 BNCconnector, for SCA2 input.
[10] SCA 1 BNCconnector, for SCA1 input.
[11] MPX BNCconnector, for MPX input.
[12] LEFT-MONO XLR connector, for balanced LEFT-MONO channel input.
[13] RIGHT XLR connector, for balanced RIGHT channel input.
[14] INTERLOCK IN BNC input interlock connector: the exciter is forced in stand-
by mode when the inner conductor is grounded.
[15] FWD EXT. AGC Trimmer to control the limitation on delivered power in function
of the FWD fold input (REMOTE connector).
[16] RFL EXT. AGC Trimmer to control the limitation on delivered power in function
of the RFL fold input (REMOTE connector).
[17] SCA2 ADJ Adjustment trimmer, for SCA2 input.
[18] SCA1 ADJ Adjustment trimmer, for SCA1 input.
[19] MPX ADJ Adjustment trimmer, for MPX input.
[20] LEFT-MONO ADJ Adjustment trimmer for the LEFT-MONO channel input.
[21] RIGHT ADJ Adjustment trimmer for the RIGHT channel input.

8/ 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
4.5 PTRLNV/4 Connector Description
4.5.1 Service (to program of factory parameters)
Type: DB9 Female
1 NC
2 TX_D
3 RX_D
4 Internally connected with 6
5 GND
6 Internally connected with 4
7 Internally connected with 8
8 Internally connected with 7
9 NC
4.5.2 Remote
Type: DB15 Female
Pin Name Type Meaning
1 Interlock IN Pull-up 5V (if GND then RF
MUTE)
2 FWD Foldback IN Ext. signal,1÷12V, for power
limitation (AGC)
3 GND GND
4 SDA IIC IN/OUT IIC communication serial data
5 VPA Tlm OUT 3,9V P.F.S.
6 FWD tlm OUT 3,9V P.F.S.
7 Power Good OUT Open or closed relay
collector selectable, enabled
when power exceeds the set
threshold.
8 GND GND
9 GND GND
10 RFL Foldback IN Ext. signal, 1÷12V, for power
limitation (AGC)
11 SCL IIC IN IIC communication clock
12 IPA Tlm OUT 3,9V P.F.S.
13 RFL Tlm OUT 3,9V P.F.S..
14 On cmd IN Pull-up 5V(one grounded
pulse of 500ms enables
power supply
15 OFF cmd IN Pull-up 5V(one grounded
pulse of 500ms disables
power supply
16
19

PTRLNV/4 & RXRLNV/4
ELETTRONICA
9/ 34
User Manual
Rev. 1.0 - 09/06/10
4.5.3 Left (MONO) & Right
Type: XLR Female
1 GND
2 Positive
3 Negative
2 1
3

10 / 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
4.6 RXRLNV/4 Frontal Panel Description
[1] HEADPHONE Jack plug for phone output.
[2] MPX MONITOR MPX Output Monitor BNC connector
[3] MUTE Yellow LED, lit on when the muting is activated, which means
thattheRFinputsignalhasdecreasedunderthedened
threshold.
[4] PILOT Green LED, lit on in the version with stereo decoder option,
in presence of pilot tone. In the version without decoder it is
always lit off.
[5] LOCK Green led, lit on when the PLL is locked on the working
frequency.
[6] ON Green LED, lit on when the receiver is working.
[7] DISPLAY Liquid crystal display.
[8] CONTRAST Display contrast adjusting trimmer.
[9] ENCODER Knob and button in order to software control.
[10] SERVICE DB9 connector for factory parameters programming.
[11] IF MONITOR BNC output connector for the 10.7 MHz sampling for tests.
[12] POWER ON/OFF switch. It switches off the exciter without
disconnecting the AC supply.

PTRLNV/4 & RXRLNV/4
ELETTRONICA
11 / 34
User Manual
Rev. 1.0 - 09/06/10
4.7 RXRLNV/4 Rear Panel Description
[1] MAIN FUSE Fuse for mains supply.
[2] MAINS Standard IEC connector for mains supply 90 ÷ 260 V, +10/-
15%.
[3] 24 VDC IN RED Positive connectors for the external 24V supply.
[4] AIRFLOW Gridforthepassageoftheairowoftheforcedventilation.
[5] R.F. INPUT RF input connector, N-type.
[6] MUTE IN/OUT BNC interlock connector.
If it is set as MUTE IN: muting of the audio outputs with an
external command.
If it is set as MUTE OUT (default): follows the MUTE LED, lit
on when contact is open or closed (internally selectable).
[7] REMOTE DB15 connector to telemetry the equipment.
[8] SCA BNC connector, for the unbalanced SCA output.
[9] MPX/SCA BNC connector, for the unbalanced MPX or SCA output.
[10] MPX BNC connector, for the unbalanced MPX output.
[11] MPX BNC connector, for the unbalanced MPX output.
[12] LEFT XLR connector, for balanced LEFT/MONO channel output.
[13] RIGHT XLR connector, for balanced RIGHT channel output.
[14] 24 VDC IN BLACK Negative connectors for the external 24V supply.
[15] SCA ADJ Adjustment trimmer, for SCA output.
[16] MPX/SCA ADJ Adjustment trimmer, for MPX/SCAoutput.
[17] MPX ADJ Adjustment trimmer, for MPX output.
[18] MPX ADJ Adjustment trimmer, for MPX output.
[19] LEFT ADJ Adjustment trimmer for the LEFT/MONO channel output.
[20] RIGHT ADJ Adjustment trimmer for the RIGHT channel output.

12 / 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
4.8 RXRLNV/4 Connector Description
4.8.1 Service (to program of factory parameters)
Type: DB9 Female
1 NC
2 TX_D
3 RX_D
4 Internally connected with 6
5 GND
6 Internally connected with 4
7 Internally connected with 8
8 Internally connected with 7
9 NC
4.8.2 Remote
Type: DB15 Female
Pin Name Type Meaning
1 Audio OFF IN Pull-up 5V(if grounded, it
inhibits the Audio)
2 N.C.
3 GND GND
4 SDA IIC IN/OUT IIC communication serial data
5 RF Input Level OUT 4V P.F.S. (R.S.S.I.)
6 LEFT Output Level OUT 2V F.S .
7 Muting TLS OUT Open or closed relay
collector selectable, contact
to GND
8 GND GND
9 GND GND
10 N.C.
11 SCL IIC IN IIC communication clock
12 MPX Output Level OUT 2V F.S.
13 RIGHT Output LevelOUT 2V F.S.
14 N.C.
15 N.C.
16
19

PTRLNV/4 & RXRLNV/4
ELETTRONICA
13 / 34
User Manual
Rev. 1.0 - 09/06/10
4.8.3 Left (MONO) & Right
Type: XLR Male
1 GND
2 Positive
3 Negative
2 1
3

14 / 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
4.9 TechnicalDescription
Parameters
PTRLNV/4 RXRLNV/4
Rated output power 5 W (1.6 GHz) or 2/5 W (2.4 GHz)
Frequency range
Operational Mode
Modulation type
Primary Power
AC power Consumption 50VA 25VA
Phisical Dimensions (W x H x D)
Weight 6 kg 5 kg
Environmental working temperature
Frequency stability
Asynchronous AM S/N ratio ≥60 dB
Synchronous AM S/N ratio ≥50 dB
Preemphasis
S/N FM Ratio
Frequency Response
Total Harmonic Distortion
S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Stereo separation
XLR F balanced XLR M balanced
Impedance: 10 k ohm Impedance: 100 ohm
Level: -13÷ +13 dB Level: -10÷ +12 dBu
XLR F balanced XLR M balanced
Impedance: 10 k ohm Impedance: 100 ohm
Level: -13÷ +13 dB Level: -10÷ +12 dBu
BNC unbalanced BNC unbalanced
Impedance: 10 k or 50 ohm Impedance: 100 ohm
Level: -13÷ +13 dBu Level: -10÷ +7 dBu
MPX Monitor 0 dBu
BNC unbalanced BNC unbalanced
Impedance: 10 k ohm Impedance: 100 ohm
Level: -13÷ +13 dBu Level: -10÷ +7 dBu
BNC unbalanced BNC unbalanced
Impedance: 10 k or 50 ohm Impedance: 100 ohm
Level: -13÷ +13 dBu Level: -10÷ +7 dBu
RF output / input
RF Monitor BNC; Level: 0 ÷ +10 dBm
IF Monitor BNC; Lvl: -5 dBm; Freq: 10,7 MHz
MPX Monitor BNC
Interlock in BNC - DB15
Interlock out / Mute BNC - DB15
Stereo headphone Jack 6,3 mm
VERSIONS
PTRLNV/4.1500-1525 LCD Radio Link transmitter 1490-1600 MHz
RXRLNV/4.1500-1525 LCD Radio link receiver 1490-1600 MHz
PTRLNV/4.1650-1680 LCD Radio Link transmitter 1600-1700 MHz
RXRLNV/4.1650-1680 LCD Radio link receiver 1600-1700 MHz
PTRLNV/4.1675-1725 LCD Radio Link transmitter 1600-1700 MHz
RXRLNV/4.1675-1725 LCD Radio link receiver 1600-1700 MHz
PTRLNV/4.1700-1750 LCD Radio Link transmitter 1700-1750 MHz
RXRLNV/4.1700-1750 LCD Radio link receiver 1700-1750 MHz
PTRLNV/4.1750-1800 LCD Radio Link transmitter 1750-1800 MHz
RXRLNV/4.1750-1800 LCD Radio link receiver 1750-1800 MHz
PTRLNV/4.2368-2372 LCD Radio Link transmitter 2300-2500 MHz
RXRLNV/4.2368-2372 LCD Radio link receiver 2300-2500 MHz
PTRLNV/4.2440-2450 LCD Radio Link transmitter 2300-2500 MHz
RXRLNV/4.2440-2450 LCD Radio link receiver 2300-2500 MHz
PTRLNV/4.2468-2483 LCD Radio Link transmitter 2300-2500 MHz
RXRLNV/4.2468-2483 LCD Radio link receiver 2300-2500 MHz
OPTIONS
/S-PTNV4 Stereo coder card option
/05-RXRLNV4 Stereo decoder card option
STANDARD COMPLIANCE
Safety
EMC
Spectrum Optimization
OTHER CONNECTIONS
Right
MPX unbalanced/RDS
AUDIO INPUTS / OUTPUTS
Left-Mono
SCA
MPX unbalanced/RDS
1.500-1.525 MHz; 1.650-1.680 M; 1.700-1.750 MHz;
1.750-1.800 MHz; 2.360-2.400 M; 2.400-2.440 MHz;
2.440-2.484 MHz (max 25 MHz band)
Other frequencies available on request
Mono, Stereo, Multiplex
Direct carrier frequency modulation
80 ÷ 260 VAC or 24 VDC
483 x 88 x 325 mm
>50 dB
-10 ÷50 °C / 95% relative Humidity non condensing
±1 ppm
0/50 (CCIR) μS, 75 (FCC) μS selectable by software
>75 dB (1600MHz); >70 dB (2400 MHz)
± 0.1 dB (40 Hz ÷ 100kHz)
≤ 0.1 %
EN 60215:1989
EN60215/A1:1992-07
EN60215/A2:1994-09
EN 301 489-1 V1.4.1 (2002-08)
EN 301 489-11 V1.2.1 (2002-11)
EN 300 454-2 V1.1.1 (2000-08)
N (50 ohm)
GENERALS
MONO/MPX OPERATION
OPTIONAL INTERNAL STEREO CODER OPERATION
>72 dB (1500 ÷ 1800MHz); >67 dB (2300 ÷ 2400 MHz)
± 0.1 dB (40 Hz ÷ 100kHz)
≤ 0.1 %

PTRLNV/4 & RXRLNV/4
ELETTRONICA
15 / 34
User Manual
Rev. 1.0 - 09/06/10
5. PTRLNV/4 quick guide for installation and use
This chapter contains the necessary instructions for the installation and use of the
equipment. In case some aspects are not totally clear, for instance when a user
isusingthisequipmentforthersttime,weadvisethenewusertoreadcarefully
the entire description contained in this manual.
5.1 Preparation
Unpack the exciter and before doing any other operation, be sure it has not been
damaged during transport. In particular check that all the connectors are in perfect
condition.
The main fuse can be accessed from the outside on the rear panel. Extract the
fuse carrier with a screwdriver to check its integrity or for replacement, if necessary.
The fuse to be used is this type:
• MAIN FUSE 3.15 A 5x20
Check that the supply voltage value coincides with the AC voltage available.
Theinputsupplyeldisof:
• PTRLNV/4 80-260 VAC
Check that the PTRLNV/4 mains switche is in the “OFF” position, it is placed on
the front panel and inhibits the switching power supply of the machine.
Connect the RF output of the exciter to the antenna cable or to a dummy load able
to dissipate the power generated by the PTRLNV/4.
Note: in case the load is not present, don’t touch the RF output connector during
the equipment operation to avoid electric shock and electrocution.
Connect the mains cable to the proper standard IEC plug, placed on the rear
panel.
Note: It is necessary that the mains system being provided with grounding to
ensure both the operators’ safety and correct operation of the equipment.
If the user intends to use external batteries in case of AC supply interruption,
connect them to the clamps situated at the back of the equipment being careful
to respect the polarity.
WARNING: Keep in mind that the general switch of the transmitter has an effect
on the AC supply, and not on the possible auxiliary supply. If you use an external
supply with continuous current, it is then necessary to have an external switch for
this purpose.

16 / 34 User Manual
Rev. 1.0 - 09/06/10
PTRLNV/4 & RXRLNV/4
ELETTRONICA
Connect the audio cable and RDS/SCA of the signal source to the proper input
connectors of the PTRLNV/4.
5.2 Operation
Switch on the transmitter by putting the switch, located on the front panel, on the
position “I” (on) .
Enter the “General Setting Menu” and set the working frequency desired.
With the help of “Audio Setting Menu”, set the characteristics (impedance,
preenphasis, and possibly stereo/mono) and the levels of the audio inputs and
RDS (if used).
Note: by factory, it is delivery with the output power adjustment at minimum and
in the “OFF” position. It is however recommended that you always check the set
level before activating power supply.
Set the desired power level from the “Power Setting Menu”.
Activate the output power from the “General Setting Menu”.
5.2.1 Encoder
The interaction between the user and the transmitter control software is performed
using the ENCODER.
Turn the encoder counterclockwise
to move the cursor downwards, to
decrease the value of a parameter
or to choose an element from a list
of possibilities
Turn the encoder clockwise to move
the cursor upwards, to increase the
value of a parameter or to choose
an element from a list of possibili-
ties
Push the button once to enter in the
desired menu, twice to modify the
selected paramenter.
The operations that you can perform on the ENCODER are:
• Rotation: moves the cursor shown on the display; if you turn the ENCODER to
the left (counterclockwise), the cursor moves downwards, if you turn it right the
cursor moves upwards; it also permits to increase or diminish the parameters
(turning the ENCODER left diminishes the parameter.
• Pushing: push the button once when the cursor is on the name of a menu to
enter in that menu, push it when the corsor is on the name of a parameter to
enterinmodicationmode(thecursorstartsblinking);afterthemodicationof
a parameter, push the button to save the new value.
This manual suits for next models
1
Table of contents
Other R.V.R. Electronica Transceiver manuals
Popular Transceiver manuals by other brands

Vertex Standard
Vertex Standard EVX-261 Service manual

3Com
3Com 3C12065 Installation and use

Adeunis RF
Adeunis RF BINDER CONNECTOR quick start guide

Telecast
Telecast CopperHead 3400 user guide

Technisonic Industries Limited
Technisonic Industries Limited TDFM-136 Installation & operating instructions

Oceanscience
Oceanscience HydroLink ML2 Series quick start guide
