Scott SDM25 User manual

FM RADIO with MP3/CD PLAYER AND
USB PORT
INSTRUCTION MANUAL
GB
SDM25

WARNING
CLASS 1 LASER PRODUCT
This product contains a low power laser device.
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
PRECAUTIONS
Follow the advice below for safe and appropriate operations.
ON PLACEMENT
• Do not use the unit in places which are extremely hot, cold, dusty, or humid.
• Placetheunitonaatandevensurface.
• Donotrestricttheairowoftheunitbyplacingitinaplacewithpoorairow,bycoveringitwithacloth, 
 orbyplacingitonacarpet.
ON SAFETY
• WhenconnectinganddisconnectingtheACcord,griptheplugandnotthecorditself.Pullingthecordmaydamage
it and create hazard.
• Whenyouarenotgoingtousetheunitforalongperiodoftime,disconnecttheACpowercord.
ON AC VOLTAGE
• Beforeuse,checkthattheratedvoltageofyourunitmatchesyourlocalvoltage.
ON CONDENSATION
• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the CD player.
• When there is condensation inside the unit, the unit may not function normally.
• Letitstandfor1to2hoursbeforeturningthepoweron,orgraduallyheattheroomupanddrytheunitbeforeuse.
* Ensureaminimumdistanceof5cmaroundtheapparatusforsufcientventilation.
* Ensurethattheventilationisnotimpededbycoveringtheventilationopeningswithitems,suchasnewspapers,
table-cloths, curtains, etc..
* Donotplacenakedamesources,suchaslightedcandlesontheapparatus.
* Take attention to the environmental aspects of battery disposal.
* Use the apparatus only in moderate climates (not in tropical climates).
* Donotexposetheapparatustodrippingorsplashing.
* Donotplaceobjectslledwithliquids,suchasvases,ontheapparatus.
• Mainsplugisusedasthedisconnectdevice.Itshallremainreadilyoperableandshouldnotbeobstructedduring
 intendeduse.Tobecompletelydisconnectedtheapparatusfromsupplymains,themainsplugoftheapparatusshall
be disconnected from the mains socket outlet completely.
Should any trouble occur, disconnect the AC power cord and refer servicing to qualied personnel.
Warning: Do not touch the lens.
DO NOT THROW BATTERIES IN FIRE !
ATTENTION : To reduce the risk
of electric shock, do not remove the
cover. There are no user serviceable
partsinsidetheunit.Referallservicing
toqualiedpersonnel.
The exclamation point within
thetriangleisawarningsign
alertingtheuserofimportant
instructions accompanying
the product.
The lightening flash
with arrowhead symbol
within the triangle is a
warning sign alerting
the user of "dangerous
voltage" inside the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Incaseofmalfunctionduetoelectrostaticdischarge,theapparatushastoberesetbydisconnectingitfrommainssupply.
THE MARKING PLATE IS LOCATED AT THE BOTTOM OF ENCLOSURE OF THE APPARATUS.

LOCATION OF CONTROLS
GB 1
USING THE MAINS SUPPLY
Beforeuse,checkthattheratedvoltageofyourunit
matchesyourlocalvoltage.
POWER SUPPLY
1. PLAY MODE BUTTON
2. PROG./CLOCK-ADJ. BUTTON
3. FOLDER DOWN BUTTON
4. FOLDER UP BUTTON
5. CD DOOR
6. STANDBY BUTTON
7. TELESCOPIC ANTENNA
8. CD OPEN/CLOSE BUTTON
9. BACK BUTTON
10. NEXT BUTTON
11. PLAY / PAUSE BUTTON
12. STOP /CLEAR/CD/USB
BUTTON
13. SPEAKERS
14. FM STEREO INDICATOR
15. LCD DISPLAY
16. CARRYING HANDLE
17. TUNING CONTROL
18. MODE SWITCH
19. AC SOCKET
20. BATTERY COMPARTMENT
21. FUNCTION SWITCH
22. VOLUME CONTROL
23. USB PORT
To AC outlet
To AC socket
USING BATTERIES
Disconnect the AC power cord
from the AC inlet of the unit.
Whentheunitispluggedintothe
mains supply, the battery power is
cut automatically
Insert six UM-2
(size C) batteries.
battery compartment door
When the volume decreases, or the sound becomes distorted,
replace all of the batteries with new ones.
ADJUSTING THE SOUND
Turn the VOLUME button to adjust the volume level.
VOLUME
MIN. MAX.

GB 2
AUDIO CONTROL
LISTENING TO THE RADIO
2 . Set the function switch to RADIO.
FUNCTION
4. TunetothedesiredradiostationbyusingtheTUNING
knob.Thefrequencyisdisplayed.
5. AdjustthevolumelevelusingtheVOLUMEbutton.
1 . Press the STANDBY button to turn on the unit.
TUNING
RADIO
VOLUME
MIN. MAX.
3 . Select the FM ST. (FM stereo) or FM MONO mode.
MODE
FM ST. FM MONO
Extend the antenna and adjust the angle to get a better reception.
FM
NOTE: 1. TheFMstereoLEDindicatorlightsiftheunitreceivesanFMstereobroadcastandtheMODEswitch
is set to "FM STEREO".
 2. WhentoomuchnoiseisheardduringFMSTEREOreception,settheMODEswitchtoFMMONO.
AFTER LISTENING
Press the STANDBY button to switch the unit off.
1. Press the standby button to switch the power on/off.
2. Press the STOP / CLEAR / CD / USB button repeatedly to
select CD or USB mode.
STOP / CLEAR /
CD/USB
The clock is displayed on the LCD display in standby mode.
1. Press the PROGRAM / CLOCK-ADJ. button,
2. Press the or button to select 12 hour or 24 hour display.
3.PressthePROGRAM/CLOCK-ADJ.button,Thehourdigitwillash.
4.Presstheorbuttontoadjustthehourdigit.
5.PressthePROGRAM/CLOCK-ADJ.buttonagain,Theminutedigitwillash.
6.Presstheorbuttontoadjusttheminutedigit.
7.PressthePROGRAM/CLOCK-ADJ.buttonagain,Thecorrecttimeisshownonthedisplay.
CLOCK ADJUSTMENT
PROGRAM/CLOCK-ADJ.
LCD display

FUNCTION
COMPACT DISC PLAYBACK
2 . Set the function button to the USB/CD position.
1 . 1.Press the STANDBY button to turn on the unit.
4.OpenthedischolderbypushingtheCDdoor
open button.
USB/CD
5. Insertadiscwiththelabelsidefacingup.
6 . Close the CD door. The disc will rotate and the
total number of tracks on the disc will show on
the display.
CD display
MP3 display
WMA display
GB 3
TO STOP PLAYBACK
Press the STOP / CLEAR / CD / USB button and
the display shows the total number of tracks on the disc.
7. Press the PLAY/PAUSE button.
Track number "01" ,"CD" and the symbol " "
 willbeshownduringnormalCDplayback.
Track number "001","CD", the symbol " " and
 "MP3"willbeshownduringMP3playback.
Track number "001", "CD", the symbol " " and
 "WMA"willbeshownduringWMAplayback.
Track number "001","CD", the symbol " " and
 “USB”willbeshownduringUSBplayback
USB display
TO INTERRUPT PLAYBACK
Press the Play/Pause button and the " " symbol
willash.Pressthebuttonagaintoresumeplayback.
CD display
MP3 display
WMA display
USB display
3 . Press the STOP / CLEAR / CD / USB button
repeatedly to select CD mode.

GB 4
TO SKIP TO THE BEGINNING OF A TRACK
• Presseitheroneofthe/skipbuttonsaccordingtothedesiredskipdirection.
• Play/back resumes from the selected track.
• Duringplay,pressthebuttononcetoreturntothestartofthecurrenttrack.
Press the button twice to return to the previous track.
• Duringplay,pressthebuttononcetoplaythenexttrack.
SEARCHING FOR A PASSAGE WITHIN A TRACK
• Holddowntheorbuttonduringplayback,andreleasethebutton
 assoonasyourecognisethedesiredpassage.ThennormalCDplaybackwill
resume from this point.
Note on CD-R/RW discs
- Becauseofthedenition/productionofnon-standardizedCD-R/RWformats,
 playbackqualityandperformancearenotguaranteed.
- ThemanufacturerisnotresponsiblefortheplayabilityofCD-R/RWduetorecordingconditions,
 suchasPCperformance,writingsoftware,mediaability,etc.
- Do not attach a seal or label to either side of the CD-R/RW disc, as it may cause a malfunction.
- ItisrecommendedtorecordonlyaudiolesonCD-R/RWdiscsforeasyreading
FOR PLAYBACK OF MP3/WMA FILES AND FILES ON
A /USB DEVICE
The different play modes available are displayed in the
following sequence: REPEAT ashes (repeat a le) >>
“REPEATFOLDER”ashes(repeatafolder)>>REPEAT
(repeatallles)>>“MIX”(randomplay)>>“CLEAR”.
DuringRepeat1mode,
the display shows:
DuringRepeat2mode,
the display shows:
DuringRepeat3mode,
the display shows:
DuringMixmode,
the display shows:
REPEAT AND MIX PLAYBACK
FOR NORMAL CD PLAYBACK
The different play modes available are displayed in the
followingsequence:“REPEAT”ashes(repeatonetrack)
>>“REPEAT”(repeatalltracks)>>“MIX”(randomplay)
>>“CLEAR”(normalplay).
DuringRepeat1mode,
the display shows:
DuringRepeat2mode,
the display shows:
DuringMixmode,
the display shows:
PressthePLAYMODEbuttonduringstopmodetoselectaplaymode.
Thefollowingplaymodesareavailable:singletrackrepeat,folderrepeat
(except for audio CDs), all tracks repeat or random playback.
FOLDER UP / DOWN
- Press the FOLDER UP or FOLDER DOWN button to select the desired folder.
- Press the button or button to select the desired track.button or button to select the desired track.to select the desired track.
-PressthePLAY/PAUSEbuttontostartplaying.

GB 5
FOR NORMAL COMPACT DISC PLAYBACK
Programmedplaybackallowsyoutoplaytracksonadiscinthedesiredorder.
Upto20trackscanbeprogrammed.
1. Press the “PROGRAM/CLOCK-ADJ.“ button.
2. Press the skip buttons to select the desired track number.
3. Pressthe“PROGRAM/CLOCK-ADJ.“buttonagaintomemorizethetrack.
4. Repeatsteps2and3untilallthedesiredtracksareprogrammed.
5. Press the “PLAY/PAUSE“ button to start. “PROGRAM“ is shown on the CD display.
6. Pressthe“STOP/CLEAR/CD/USB“buttontostopprogrammedplayback.
7. Press “PROGRAM/CLOCK-ADJ.“ and “PLAY/PAUSE“ buttons to resume
 programmedplayback.
8. TurnofftheCDplayertocleartheprogrammedmemory.
FOR MP3/WMA FILES AND FILES ON THE USB DEVICE
Programmedplaybackenablesfolders/albumsortracksonadisctobeplayedinthedesired
order.Upto20folders/albumsortrackscanbeprogrammed.
1. In stop mode, press the “PROGRAM/CLOCK-ADJ.” button.
2. Press the FOLDER DOWN/FOLDER UP button to select the number of the desired
 folder.Ifyouwouldliketoprogramthewholefolder,pressthePROGRAM/CLOCK-ADJ
 button.Toprogramotherfolders,repeatstep2.
3. Press the skip buttons to select the desired track number.
4. Pressthe“PROGRAM/CLOCK-ADJ.”buttonagaintomemorizethetrack.
5. Repeatsteps2to4untilallthedesiredtracksareprogrammed.
6. Press the “PLAY/PAUSE” button to start. “PROGRAM” is shown on the CD display.
7. Pressthe“STOP/CLEAR/CD/USB”buttontostopprogrammedplayback.
8. Press the “PROGRAM/CLOCK-ADJ.” and “PLAY/PAUSE” buttons to resume
 programmedplayback.
9. TurnofftheCDplayertocleartheprogrammedmemory.
Note:Programmingcanonlybecarriedoutwhentheplayerisinstopmode.
CD display
MP3/WMA/USB display
PROGRAM PLAYBACK
USB OPERATION
1. Connect the USB device or MP3 player to the USB port.
2. Press the STOP/CLEAR/CD/USB button repeatedly to select USB mode.
3. Press the PLAY PAUSE button to start playback.
Note:
TheUSBportisnotdesignedtobeconnecteddirectlytoacomputer.
The manufacturer is not responsible for the playability of a USB device or
MP3playerduetorecordingconditions,capacity,interfacecompatibility,etc.
Duetodifferentformats,someUSBdevicesorMP3playersmaytakelongertoberead.
AUSBdevicecanbeconnecteddirectlytotheunitorwithacablenolongerthan50cm.
USB display
CLEANING CD
IftheCDskipsorwillnotplay,thediscmayneedcleaning.Before
playing,wipethediscfromthecentreoutwithacleaningcloth.After
playing,storethediscinitscase.
MAINTENANCE
CLEANING THE CD LENS
If the CD lens is dusty, clean it with a brush-blower. Blow several times
onthelensandremovethedustwiththebrush.Fingerprintsmaybe
removed with a cotton swab moistened with alcohol.
CLEANING THE UNIT
Do not use volatile chemicals
on this unit. Clean by lightly wiping with a soft
cloth.
IMPORTANT NOTE
If an abnormal display indication or an operating
problem occurs, disconnect the AC power cord
and remove the batteries. Wait at least 5 seconds,
then reconnect the AC power cord or reinstall
the batteries.
WARNING
ShouldtheCDdoorbeopenedbeforethereading
oftheCDcompleted,ajammingnoisemayoccur.
ThisisresolvedbyclosingtheCDdoor.

CD SECTION
Channels: 2 channels
S / N ratio: 60 dB
Wow & Flutter: undetectable
Samplingfrequency: 44.1kHz8xoversampling
Quantization: 1 bit DA converter
Pickuplightsource: Semi-conductorlaser
Pickupwavelength 790nm
RADIO SECTION
Tuningranges: FM87.5-108MHz
Antennas: FM Rod antenna
GENERAL
Output power: 1W + 1W (RMS)
Power consumption: 8 W
Speaker: 3" 8 OHM
Power source: AC : 230V ~ 50Hz
DC : 9V ( 6 x 1.5V LR14/ "C"/UM2 )
Dimensions: 299(L) x 272(D) x 153(H)mm
Weight 1.7KGS
Duetocontinuingimprovement,thefeaturesandthedesignaresubjecttochangewithoutnotice.
Where to place the item :
Today’sfurnitureiscoatedwithawidevarietyoflacquersandsynthetic-coatingsthataretreatedwithan
extensiverangeofcleaningproducts.Therefore,thepossibilitythatsomeofthesesubstancescontain
components that react adversely to the rubber feet of the item and soften them, cannot be completely
excluded.Therubberfeetoftheappliancecancausediscoloringtofurnituresurfaces.Ifnecessary,
place the appliance on a non-slide surface.
SPECIFICATIONS
GB 6
If at any time in the future you should need to dispose of this product please note that
Waste electrical products should not be disposed of with household waste.Please
recyclewherefacilitiesexist.CheckwithyourLocalAuthorityorretailerforrecycling
advice.(WasteElectricalandElectronicEquipmentDirective)
