INSTRUCTIONS FOR
INDUSTRIAL HIGH VELOCITY DRUM FAN 42”
BELT DRIVE 230V
MODEL NO: HVD42B
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate
safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend
that a Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a
supply which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by
contacting your Sealey stockist.
You must also read and understand the following instructions concerning electrical safety.
9The Electricity at Work Act 1989 requires all portable electrical appliances, if used on
business premises, to be tested by a qualified electrician, using a Portable Appliance Tester
(PAT), at least once a year.
The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible
for the safe condition of those appliances and the safety of the appliance operators. If in
any doubt about electrical safety, contact a qualified electrician.
9Ensure that the insulation on all cables and on the appliance is safe before connecting it
to the power supply.
9Ensure that cables are always protected against short circuit and overload.
9Regularly inspect power supply cables and plugs for wear or damage and check all
connections to ensure that none is loose.
9Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
8DO NOT pull or carry the appliance by the power cable.
8DO NOT pull the plug from the socket by the cable.
8DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item repaired or replaced by a qualified
electrician. When an ASTA/BS approved UK 3 pin plug is damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer insulation extends
beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol , are fitted with live (brown) and neutral (blue) wires only.
To rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure
that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket
with your electrician.
9If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be absolutely sure that
the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the
use of 2.5mm² section cable. If extension reel is to be used outdoors, ensure it is marked for outdoor use.
1.2. GENERAL SAFETY
9Disconnect the fan from the mains power when not in use and before servicing or performing any maintenance.
9Use the fan in dry areas only. DO NOT use in wet or areas with high condensation such as showers, pools etc.
WARNING! If a fan falls into water or other liquid, immediately switch off and disconnect from the mains power supply. Do not touch the
fan until the mains power supply has been disconnected.
9Always disconnect the fan from the power supply when moving it from one location to another and ensure fan is stood on a level
surface.
9The fan air flow is powerful. Before use ensure that there is nothing nearby that will be damaged or displaced by the stream of air.
9Keep the fan clean and maintained in good condition. For motor service contact an authorised service agent.
HVD42B | Issue 4 18/01/17
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Indoor Use
Only
RECOMMENDED
FUSE RATING 5 AMP

9Use recommended parts only. Unapproved parts may be dangerous, and will invalidate your warranty.
8DO NOT operate the fan where there are explosive or flammable gases, fumes or other hazardous substances.
8DO NOT stand the fan on the power cable.
8DO NOT insert any objects through the fan guard.
8DO NOT cover the fan when in use.
8DO NOT immerse the fan in water or any other liquid.
8DO NOT allow children to operate the fan.
8DO NOT stand the fan where it may be knocked over or off a surface, or where the lead may cause a person to trip.
8DO NOT modify speed control or attempt to fit any additional external speed control device to the fan.
9When not in use place the fan in its original box, or cover, to protect from dust and store in a safe, dry, childproof location.
NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
2. INTRODUCTION
High velocity industrial two-speed drum fan suitable for movement of huge volumes of air. Professional belt drive motor ensures a
smooth and quiet performance. Robust unit with heavy-duty gauge steel casing, guard and frame. Handle, wheels and fully tiltable
cradle allows control of airflow to exactly where it is needed. Carefully balanced and fully guarded blades provided. Suitable for use
in industrial, commercial, agricultural, automotive workshop and showroom applications. Maximum Airflow: 350mtr³/min (12,300cfm).
Fitted with BS approved plug.
3. SPECIFICATION
Model No: .......................................................................................HVD42B
FanØ:...................................................................................... 1065mm (42”)
Speeds:........................................................................................................2
Speed Range:.............................................................................400-450rpm
Maximum Airflow:................................................... 350mtr³/min (12,300cfm)
Power:........................................................................................... 580-630W
Supply:...................................................................................................230V
Current:...................................................................................................2.7A
4. OPERATION
WARNING! Ensure you read, understand and apply the safety instructions in Section 1 before using the fan.
4.1. The fan is easily transportable by means of the wheels provided. Lift by the handle (fig.2) and manoeuvre the fan into position. Ensure that
there is nothing in front of the fan that may be disturbed when the fan is switched on.
The drum can be tilted by loosening the tilt locking handles on either side of the drum, tilt the drum to the required angle and re-tighten the tilt
locking handles.
4.2. Check that the switch situated on the side of the drum is set to “0” (fig.3). Uncoil the power lead from its stowage position (fig.2)
and plug into the mains power supply. Ensure that the power lead is not stretched or positioned in such a way as to cause a hazard.
Switch the power on.
4.3. Turn the fan on by pressing the switch to either “1” or “2” (fig.3) depending on the volume of air required.
4.4. After use ensure the switch is returned “0” and disconnect the fan from mains power.
4.5. Store the lead onto the stowage hook situated on the drum, near the lifting handle.
5. MAINTENANCE
WARNING! Ensure that the fan is disconnected from the mains power supply before attempting any of the following:
5.1. Use a soft, damp cloth to clean the fan. DO NOT immerse the fan in water and never allow water to drip onto the motor housing. DO
NOT use solvents, petroleum, paint thinner or other chemicals to clean the fan.
5.2. To clean the fan blade, undo the bolts around the circumference, remove the grille and clean the blade with a slightly damp cloth.
Replace the grille as required and refit the cross headed screws.
5.3. Should the motor, switch or the power lead require service or maintenance contact your local Sealey service agent.
5.4. When not in use place the fan in its original box or otherwise cover to protect from dust, and store in a safe, dry, childproof location.
HVD42B | Issue 2 18/01/17
Original Language Version
© Jack Sealey Limited
g.1 g.2 g.3

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
