Sealey RE024 User manual
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
equipment.
WARNING! DO NOTtouch the staple once it has been inserted into the staple gun and power has been switched on.
WARNING! High temperatures are reached and will inflict serious burns to skin upon contact with the staple.
WARNING! Allow to cool before removing any unused staples from the staple gun pin tip.
Familiarise yourself with the application, limitations and potential hazards of the staple gun.
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
Locate staple gun in a suitable working area, keep area clean and tidy and free from unrelated materials.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
Keep the staple gun clean for best and safest performance.
Ensure there are no flammable or combustible materials near the work area.
Wear approved safety eye protection (standard spectacles are not adequate).
Wear heat resistant gloves and appropriate protective clothing.
Ensure the workpiece is adequately held before operating the staple gun.
Always use staple gun in a well ventilated atmosphere and wear Personal Protective Equipment.
Ensure that when the staple gun is put down during use that the tip is not near to or in contact with any material that may burn or melt.
After use always keep the staple gun in its original package in a safe place away from children.
DO NOT touch the staple during its warm up phase.
DO NOT use in wet or damp conditions.
INSTRUCTIONS FOR:
PLASTIC REPAIR STAPLE GUN - CORDLESS
MODEL NO: RE024
1. SAFETY
Original Language Version
© Jack Sealey Limited
DO NOT operate the staple gun when you are tired or under the influence of alcohol, drugs or intoxicating medication.
DO NOT leave a hot staple gun unattended. (If you are leaving the work area even for a short period of time switch it off and allow to cool.)
DO NOT use the staple gun for any purpose other than that for which it has been designed.
DO NOT allow untrained persons to operate the staple gun.
DO NOT touch the workpiece as it will be very hot. Allow to cool.
DO NOT operate the staple gun if damaged.
1.2. ELECTRICAL SAFETY FOR USE OF CHARGER.
USE ONLY THE SUPPLIED CHARGER PLUG FOR CONNECTING TO THE POWER SUPPLY.
WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions:
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices. An RCCB (Residual Current
Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD (Residual Current Device)
is used with all electrical products, particularly portable equipment which is plugged into an electrical supply not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.2.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a
qualified electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.2.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
the safety of the appliance operator. If in any doubt about electrical safety, contact a qualified electrician.
1.2.3. You must ensure that you:
Inspect the charger plug, cable and connector for wear and damage to ensure items are safe before connecting to the mains power
supply. If worn or damaged DO NOT use.
Important: Check that the voltage marked on the charger plug is the same as the power supply to be used.
DO NOT pull the charger plug from the mains socket by the lead.
DO NOT use any other type of charger with this product.
DO NOT try to take the charger plug apart.
DO NOT use the charger plug to charge or power any other electrical item.
DO NOT get the charger wet, or use in wet, damp conditions (for indoor use only).
WARNING!NEVER substitute a standard 13amp 3 pin plug, or any other type of plug, for the charger plug.
1.3. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
DO NOT attempt to open, disassemble, modify or service the battery pack.
DO NOT crush, puncture, short external contacts or dispose of in fire or water.
DO NOT expose to temperatures above 60°C (140°).
Recycle or dispose of used battery as stipulated by local regulation.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
RE024 Issue: 1 - 09/04/14
Wear eye
Protection
Wear
Respiratory
Protection
Wear Heat
Resistant Gloves
Hot Surfaces
3. SPECIFICATION
4. OPERATION
Model No: .............................RE024
Battery: ................................Li-ion 3.7V - 6600MAh
Charging Time: ..........................3-4hours
Replacement Staples: ....................(Packs of 100) RE06 (0.6mm), RE06V (0.6mm), RE08 (0.8mm)
4.1. Fully charge the battery before rst use. Plug the charger cable into an electrical outlet and connect into the charging port (see g.1).
The charge indicator lights are on the top of the unit (see g.2). The green LED will light when it is fully charged, charging is denoted by
a yellow LED and low battery is the red LED. Unplug the cable once charged, and the unit is ready for use.
4.2. Choose a suitable heating repair pin and place it in the tip of the stapler.
4.3. Set the power switch (see g.2) according to the type of plastic (low for thin plastic, bumpers etc. high for thick or hard
plastic.)
4.4. Keep the stapler perpendicular to the damaged surface.
4.5. Press the switch button on the grip for 10 seconds until the pin is hot enough to weld. Then press the pin gently against the damaged
surface.
4.6. When the pin is half way into the plastic material stop pressing and release the power button. Wait for a few seconds until the repair
becomes rm.
4.7. Once plastic has cooled and staple is fully secure, pull stapler gun gently back to release.
4.8. If the damaged surface is very long or wide, insert extra pins, 1/2 inch apart.
4.9. Cut off the pins with a side cutter, then grind the remains of the pin with a sander/grinder.
NOTE: DO NOT press the repair pins too hard as it may penetrate the plastic too far.
NOTE: Rest the stapler for 5 to 10 minutes after 40 cycles of continuous use in order to extend the life of the product.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
sales@sealey.co.uk
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Original Language Version
© Jack Sealey Limited
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500.
g.1 g.2
Battery Removal
Undo the screw in the door in the base of the staple gun and remove the battery for correct disposal.
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential
purchasersofproductscontainingbatteries(asdenedwithintheseregulations),thattheyareregisteredwithValpak’s
registeredcompliancescheme.JackSealeyLtd’sBatteriesProducerRegistrationNumber(BPRN)isBPRN00705.
RE024 Issue: 1 - 09/04/14
2. INTRODUCTION
Pistol grip design improves control and accuracy when carrying out repairs. Features a LED work light, high and low power option, and a
Lithium-ion battery for prolonged usage. Capable of inserting 100+ staples from one full charge. Complete with staples; 100 x 0.6mm U-shaped,
100 x 0.8mm U-shaped, 100 x 0.6mm V-shaped.
