Sebart Mig29 3D-EDF User manual

SebArt professional line
Mig29 3D-EDF ARF
ASSEMBLY MANUAL
The real plane
The MiG-29 is a fourth-generation jet fighter aircraft designed in the
Soviet Union for an air su eriority role. Develo ed in the 1970s by the
Mikoyan design bureau, it entered service with the Soviet Air Force in
1983, and remains in use by the Russian Air Force as well as in many other
nations.
The MiG-29OVT “Red Star” version have thrust-vectoring engine and fly-
by-wire technology. It served as a thrust-vectoring engine test-bed and
technology demonstrator to show future im rovement in the MiG-29
series. The two RD-133 thrust-vectoring engines, each features unique
rotating nozzles which can rovide thrust vector deflection in all
directions. The OVT version is being demonstrated in various air shows
around the world for otential ex ort and as an aerobatic demonstrator.
Specifications:
Year Built: 1983
Primary Function: fourth-generation jet fighter aircraft
Length: 17.37 m (57 ft)
Wings an: 11.4 m (37 ft 3 in)
Weight Em ty: 11,000 kg (24,250 lb)
Max. S eed: 2.400 km/h ( 1,490 m h)
Engine: 2 × Klimov RD-33 afterburning turbofans, 8,300 kgf (18,300 lbf) each

The model
The Mig-29 3D EDF ARF, was designed by the 13 times Italian Cham ion
Sebastiano Silvestri, vice-Euro ean Cham ion and F.A.I World Cu
winner F3A.
This rofessional ARF kit is the result of Sebastiano’s long research,
ex erience in F3A and his assion for jet lanes. This combined with an
extremely light weight foam structure and with many small aerodinamical
tricks give the Mig-29 3D EDF an im ressive recision and easy control
at any airs eed and flight condition.
The Mig-29 3D EDF is the first in the world in his class: with the factory
installed gyro on the rudder-thrust verktor axis it can hover very easy!
The Mig-29 3D EDF can do it all…it is ready for any attern manouvers
as for unbelievable knifeedge flights, loo s, fli s, harrier, flat s ins,
hovering... and almost anything else you can dream u from an EDF foam
lane are waiting you!
.....the onl aerobatic-fun limit is our fantas !
Specifications:
Wing S an:………………...…….............................92 cm
Length:….......…….…………….........................…134 cm
Wing Area:……...................................................21,2 dm2
Weight:…….................................1.640g. RTF less battery
Radio:..................................................................7-Channel
Recommended battery ack……….…3400-4S or 4000-4S
Required radio and batter packs

Radio equi ment:
• Minimum 7-channel radio system and receiver
Recommended Li-Po battery ack for best erformance:
• 3400-4S for unlimited 3D erformances with a rox. 3,5 minutes flight time
• 4000-4S for 3D & recision with a rox. 4 minutes flight time
Warning
This RC aircraft is not a toy!
If misused, it can cause serius bodily harm and damage to property. Fly only in
open areas, preferably in official flying sites, following all instructions included
with your radio and motor.
Before starting assembl
Before starting the assebly, remove each art from its bag and rotection for a rior
ins ection. Closely ins ect the fuselage, wing anels, rudder, and stabilizer for
damage. If you find any damage or missing arts, contact the lace of urchase.
Warrant information
SebArt garantees this kit to be free from defects in both material and workmanshi at
the date of urchase.
This warranty does not cover any arts damage by use or modification, and in no case
shall SebArt’s liability exceed the original cost of the urchased kit.
Further, SebArt reserve the right to change or modify this warranty without notice. In
that SebArt has no control over the final assembly or material used for the final
assembly, no liability shall be assumed or acce ted for any damage of the final user-
assembled roduct. By the act of using the roduct, the user acce ts all resulting
liability.
If the buyer is not prepared to accept the liability associated with the use of this
product, the buyer is advised to return this it immediately in new and unused
condition to the place of purchase.
INSTALLATION INSTRUCTION

Remove each art from its bag and rotection.
Remove the cano y from the fuselage.

Locate the carbon rod, included in hardware ack, in the wing anel.
A ly the 5-minute e oxy into the slot and turn the carbon tube in his location.

Plug in the servo connector and match the olarity.
Check the alignment of the wing anel with the fuselage before glue it.

A ly a light coat of 5-minute e oxy on the wing anel.
Locate the wing anel in his osition on fuselage.

Make sure to check the alignment on the to of the wing anel to the fuselage.

Wi e off any e oxy that squeezes out with some rubbing alcohol on a a er towel.
Hold ressed the wing anel in his osition on fuselage. Re eat this ste s for the
other wing anel too.

Locate the stabiliser and the elevator linkage , included in the hardware ack.
Check the alignment of the stabiliser anel with the fuselage before glue it.

A ly a light coat of 5-minute e oxy on the stabiliser anel.

Locate the stabiliser anel in his osition on fuselage and check the alignment.
Wi e off any e oxy that squeezes out with some rubbing alcohol on a a er towel.

Hold ressed the stabilizer anel in his osition on fuselage.

Connect the elevator linkage in servo arm.

Connect the elevator linkage at elevator horn. Re eat this ste s for the other stabiliser
anel too.

Locate the rudder and connect the rudder servo connector matching the olarity.

Check the alignment, than a ly a light coat of 5-minute e oxy on the rudder anel
and install it on fuselage.
Wi e off any e oxy that squeezes out with some rubbing alcohol on a a er towel.

Hold ressed the rudder anel in his osition on fuselage. Re eat this ste s for the
other rudder anel too.
NOTE the alignment from the front view of wings, stablizers and rudders.

Install on fuselage the nose cone using 5-minute e oxy.

Wi e off any e oxy that squeezes out with some rubbing alcohol on a a er towel.
RADIO SET UP
Connect your 7-channel receiver to the servo wires as follow:
throttle = THROTTLE
aileron = AIL
to connect the 2 ailerons, use the “Y” included in hardware pack
elevator = ELE
rudder = RUDDER
here are factory connected toghter the 2 rudders and the thrust rudder axis
gear = GYRO SENS.
if your plane versions with gyro factory installed
aux 1 = VEKTOR 1
aux 2 = VEKTOR 2
