Sebart Sukhoi 29S 50E ARF User manual

SebArt professional line
New Sukhoi 29S50E
ARF
ASSEMBLY MANUAL
The new Sukhoi 29S 50E ARF was designed by Italy aerobatic
pilot, Sebastiano Silvestri and the design is based on of his new
Tournament Of Champion’s competition airplane.
This professional ARTF kit is the result of Sebastiano’s long
research in 3D performance. This combined with an extremely
lightweight structure, the all wood airframe, the big control
surfaces and the new revolutionary Lift Generator on landing
gear give the Sukhoi 29S 50E an impressive thrust-to-weight ratio
and crisp control authority at any airspeed and flight
condition….That for this small class of airplane is revolutionary!
The Sukhoi 29S 50E can do it all…unbelievable easy harriers,
torque rolls, blenders, waterfalls and almost anything else you can
dream up are waiting you!
.....the only aerobatic limit is your fantasy!
Specifications
Wing Span:……….….……... 154 cm (61 in.) Recommended power set up:
Length:…............…….….….. 154 cm (61 in.) Motor:........................... Hacker A50-16S
Wing Area:….…............. 51,6 dm2 (80 sq.in.) ESC:……………………. X70 SBec-Pro
Weight:…...2.400 g. RTF less battery (84,6 oz) Battery: FlightPower 3300-6S or 3700-6S
Radio:…...4-Channel with 4 standard servos Propeller: …….…………. APC 16x10E

2
Table of contents
Table of contents...............................................................................................................………..2
Required radio, motor and battery.............................................................................................….3
Additional required items, tools and adhesives.............................................................................. 3
Warning.......................................................................................................................................... 3
Before starting assembly ...........................................................................................................… 3
Using the manual........................................................................................................................... 4
Warranty information…................................................................................................................. 4
Section 1 – wing fillet installation…..............................................................................................5
Section 2 – ailerons installation......................................................................................................6
Section 3 – aileron servo & control horn installation…............................................................….7
Section 4 – rudder installation & tail wheel installation.................................................................10
Section 5 – elevator installation ………..…...................................................................................12
Section 6 – elevator servo & control horn installation................................................................... 14
Section 7 – rudder servo & control horn installation……………………………………………..16
Section 8 – landing gear & wheels installation…………………………………….……………..17
Section 9 – electric motor installation …..…..…………................................................................20
Section 10 – glow engine installation (option)…............................................................................22
Section 11 – cowl installation……........................................................................................…….22
Section 12 – final radio installation …………................................................................................24
Wings installation............................................................................................................................24
Decal set application....................................................................................................................... 25
Control throws................................................................................................................................ 25
Mixing………................................................................................................................................. 25
Rates and expos..........................................................................................................................….26
Recommended CG......................................................................................................................….26
Range test your radio..................................................................................................................….26

3
Required radio, motor and battery
Radio equipment:
•Minimum 4-channel radio system
•4 digital standard servo, recommended JR PROPO DS9401 or DS8301
•2 servo extension 600mm, for elevator and rudder servos
•2 servo extension 100mm, for aileron’s servos
Recommended electric motor for best performance:
•Hacker A50-16S + X70 SBec-Pro controller + APC 16x10E
Recommended Li-Po battery pack for best performance:
•Flight Power EVO 3300mAh 6S.….for unlimited 3D
•Flight Power EVO 3700mAh 6S…..for duration and precision
Additional required item, tools and adhesives
Tools:
•Drill
•Drill bits: 1,5mm, 2mm, 3mm
•Phillips screwdriver
•Hobby knife
•Sanding paper
•Masking tape
•Soldering iron
Adhesives:
•thin CA
•medium CA
Warning
This RC aircraft is not a toy!
If misused, it can cause serius bodily harm and damage to property.
Fly only in open areas, preferably in official flying sites, following all instructions included with
your radio and motor.
Before starting assembly
Before starting the assebly of your KatanaS 50E, remove each part from its bag and protection for a
prior inspection. Closely inspect the fuselage, wing panels, rudder, and stabilizer for damage. If you
find any damage or missing parts, contact the place of purchase.
If you find any wrinkles in the covering, use a heat gun or covering iron to remove them. Use
caution while working around areas where the covering material overlap to prevent separating the
covers.

4
Using the manual
This manual is divided into sections to help make assembly easier to understand and to provide
breaks between each major section.
In addition, check boxes () have been placed next to each step to keep track of each step
completed. Steps with two boxes indicate that the step will require repeating, such as for a right or
left wing panel, two servos, etc.
Rember to take your time and follow the directions.
Warranty information
SebArt garantees this kit to be free from defects in both material and workmanship at the date of
purchase.
This warranty does not cover any parts damage by use or modification, and in no case shall
SebArt’s liability exceed the original cost of the purchased kit.
Further, SebArt reserve the right to change or modify this warranty without notice.
In that SebArt has no control over the final assembly or material used for the final assembly, no
liability shall be assumed or accepted for any damage of the final user-assembled product. By the
act of using the product, the user accepts all resulting liability.
If the buyer is not prepared to accept the liability associated with the use of this product, the buyer
is advised to return this kit immediately in new and unused condition to the place of purchase.
SebArt di Sebastiano Silvestri
Via Roma 83/85
38017 Mezzolombardo (TN) – Italy
www.sebart.it

5
Section 1 – wing fillet installation




step 1
Locate the carbon tube and the wing to the fuselage. Locate the corresponding wing fillet to the
wing. Test fit the fillet and his alignment with the wing panel and fuselage.




step 2
Once satisfied with the fit, glue the wing fillet to the wing panel using medium CA. Use the glue
carefully avoid over runs onto the area to be covered with the material.




step 3
Remember to check carefully the wing fillet/wing panel alignment.

6




step 4
Use the covering iron carefully, at a medium temperature, to glue the cover material down around
the area of the fillet. Use caution while working around areas where the cover material overlaps to
prevent separating the covers.


step 5
Repeat steps 1 through 4 for the remaining wing panel and wing fillet.
Section 2 – ailerons installation




step 1
Trial fit the four aileron hinges, included in the hardware pack, in their place and verify the correct
position and alignment of the aileron with the wing panel.

7




step 2
Carefully glue, with some drops of thin CA, each of the four hinges in the aileron.




step 3
Locate the aileron and carefully glue, with some drops of thin CA, each of the four hinges into the
wing panel.




step 4
Work the aileron up and down some times to work the hinges and check for proper movement.


step 5
Repeat steps 1 through 4 for the remaining wing panel.
Section 3 – aileron servo & control horn installation




step 1
Locate the following items included in the hardware pack and the servo.

8




step 2
Install the servo hardware (gommets and eyelets) and put the servo into the wing panel, as per
pictures.




step 3
Drill using a 1,5mm drill bit, and install the servo into the wing panel using a Phillips screwdriver.

9




step 4
Glue the fibreglass horn with medium CA into the aileron.




step 5
Install the hardware and make the final adjustment as per pictures.


step 6
Repeat steps 1 through 5 for the remaining wing panel.

10
Section 4 – rudder installation & tail wheel installation


step 1
Test fit the rudder into the fuselage, check for a correct alignment.


step 2
Glue it carefully with medium CA.


step 3
Insert the three hinges in their appropriate slots and glue them with some drops of thin CA.

11


step 4
Drill in the rudder, 20mm from the bottom, the location for the tail wheel using a 2mm drill bit.
With the hobby knife cut a groove of 20mm length into the rudder.


step 5
Than locate the items included in the hardware pack and assemble them as per picture.


step 6
Drill on fuselage the screw locations for the tail wheel using a 1,5mm drill bit, and install it as per
picture.

12


step 7
Carefully put some drops of medium CA into the 2 mm hole, carefully locate the rudder and glue
the hinges with some drops of thin CA.


step 8
Work the rudder right and left some times to work the hinges and check for proper movement.
Section 5 – elevator installation


step 1
Insert in the elevator the four hinges into their appropriate slots and verify the correct position and
alignment of the elevator with the stabilizer. Than carefully glue the hinges, with some drops of thin
CA, in the elevator only.

13


step 2
Insert carefully the elevator through the fuselage.


step 3
Insert the stabiliser into fuselage space and locate the elevator hinges into the stabiliser.


step 4
Glue carefully the hinges in the stabiliser with some drops of thin CA.

14


step 5
Locate the carbon tube in his position and carefully check the alignment of the stabilizer with the
fuselage, as per pictures.


step 6
Once satisfied with the alignment, glue carefully with thin CA the stabilizer at the fuselage.
Section 6 – elevator servo & control horn installation


step 1
Locate the following items included in the hardware pack, servo extension 600mm long and servo.

15


step 2
Than install the servo hardware (gommets and eyelets) and locate the servo into the fuselage.


step 3
Drill using a 1,5mm drill bit, and install the servo into the fuselage using a Phillips screwdriver.


step 4
Glue the fibreglass horn with medium CA into the elevator. Than install the hardware and make the
final adjustment as per picture.

16
Section 7 – rudder servo & control horn installation


step 1
Locate the following items included in the hardware pack, servo extension 600mm long and servo.


step 2
Than install the servo hardware (gommets and eyelets) and locate the servo into the fuselage.


step 3
Drill using a 1,5mm drill bit, and install the servo into the fuselage using a Phillips screwdriver.

17


step 4
Glue the fibreglass horn with medium CA into the rudder. Than install the hardware and make the
final adjustment as per picture.
Section 8 – landing gear & wheels installation


step 1
Locate the following items included in the hardware pack.

18


step 2
Locate the landing gear on the fuselage and fix it with the screws included in the hardware pack.




step 3
Sand with the sanding paper the inside of the wheel pant; locate the wood reinforcement, glue it
with some drops of medium CA and drill the location for the wheel axis screw using a 3mm drill bit
as per pictures.




step 4
Install wheel and wheel pant as per pictures.

19




step 5
Drill the location for the wheel pant fixing screw using a 1,5mm drill bit and than fix the wheel pant
with the screw included in the hardware pack.




step 6
Test fit the L.G. Lift Generator and his alignment with the fuselage.




step 7
Glue carefully the landing gear fillet with some drops of medium CA, as per picture.


step 8
Repeat steps 3 to 7 for the other side of the landing gear.

20
Section 9 – electric motor installation
For best performance, we recommend to use HACKER motor.


step 1
Locate the engine mount on the fuselage, fix it using the four screws included in the hardware pack
and than glue it carefully with medium CA.


step 2
Locate the motor and fix it with the four screws included in the motor hardware pack.
